Used 4-Axis Cnc Wire Bending Machine for sale (101,459)

Condition: new, Year of construction: 2024, pipe diameter (max.): 38 mm, bending angle (max.): 190 °, bending radius (max.): 250 mm, total length: 4,280 mm, total width: 1,000 mm, total height: 1,500 mm, warranty duration: 12 months, sheet thickness steel (max.): 3 mm, MAXIMUM CAPACITY : Ø38X3MM MAXIMUM BENDING RADIUS : 250MM DEGREE OF TWIST : 190 DEGREE WORKING LENGTH : 3000MM MOTOR POWER : 7.5KW LENGTH : 4650MM WIDTH : 1000MM HEIGHT : 1500MM BENDING SPEED : CHANGEABLE STANDARD FEATURES One set of bending molds in the dimensions required by the customer Servo Motorized Feed Axis Servo Motorized Rotation Axis Automatic Mailing of Detailed Work Report Nksdpfx Ahju Hi T Eovow Servo Bending Axis (SFB 38-CNC/R1) Gearbox Driven Bending System (51-65-76-90) CNC Control Unit with mobile 21" color screen 3D Simulation Twisting Displaying Daily, Weekly and Monthly Total Production Amount Calculating the total length of material to be used Calculate the estimated bending process time Convert X-Y-Z data to Y-B-C Getting remote assistance Portable foot pedal with emergency stop Manual - Automatic Twisting Bending with - Without Bending Safety plate with switch behind the bending head Automatic headstock lubrication system (SFB 38 CNC/R1) Hydraulic Crimping Hydraulic Malafa Hydraulic Stop Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Clamp Electrical panel safety lock and keyed panel lock Electric Panel Cooler Protected Against Overload

Condition: new, Year of construction: 2025, MAXIMUM CAPACITY: Ø51X3MM MAXIMUM BENDING RADIUS: 250MM BENDING DEGREE: 190 DEGREES WORKING LENGTH: 3000MM MOTOR POWER: 13.5 KW BENDING SPEED: CHANGEABLE STANDARD FEATURES A set of bending molds in the dimensions requested by the customer Servo Motorized Progress Axis Servo Motorized Rotation Axis Automatic Emailing of Detailed Work Report Servo Bending Axis (SFB 38-CNC/R1) Reducer Driven Bending System (51-65-76-90) Mobile 21” color screen CNC Control Unit 3D Simulation Bending Daily, Weekly and Monthly Total Production Quantity Display Total material length calculation Estimated bending process time calculation Nkjdpevyzwrefx Ahvow X-Y-Z data Y-B-C conversion Remote assistance Portable foot pedal with emergency stop Manual – Automatic Bending Mandrel – Non-Mandrel Bending Switched Safety Plate behind the bending head Automatic Mandrel lubrication system (SFB 38 CNC/R1) Hydraulic Clamping Hydraulic Mandrel Hydraulic Support Hydraulic Oil Cooler Hydraulic Linear Slider system Hydraulic Collet Electrical panel safety lock and keyed panel lock Electrical Panel Cooler Protected Against Overload

Condition: used, Year of construction: 2019, machine/vehicle number: 0191, A 4-axis CNC profile machining centre Emerald F260, year of manufacture 2019, sourced from a professional production environment. The machine is perfectly maintained, damage-free, and fully operational. Axes: X / Y / Z / A (4-axis interpolation) Control: PA8000 (Germany) Spindle: HSD (Italy) – 9 kW, up to 24,000 rpm A-axis rotation: +90° to -90° Working area: Up to 7000 mm length (depending on clamp configuration) Tool magazine: ISO30 – 9 positions Applications: Milling, Drilling, Tapping, Grooving, Angular machining Materials: Aluminium profiles, light alloys, UPVC Nkjdpfx Ahjx R U Eievow

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 5002, travel distance X-axis: 850 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller manufacturer: FANUC, controller model: Oi-MC, table width: 600 mm, table length: 1,050 mm, table load: 850 kg, spindle speed (max.): 15,000 rpm, spindle motor power: 7,500 W, number of spindles: 2, number of slots in tool magazine: 24, tool diameter: 40 mm, number of axes: 4, Equipment: chip conveyor, documentation/manual, Tool Standard is BT-40. 4th axis: rotary table included; Nksdpfx Asx Nctfohvjw

Condition: used, CNC 5-Axis HMC – Horizontal Machining Center, Milling Center, Manufacturing Center Nksdpfxst Ac Efj Ahvjw Manufacturer: LICON Model: Liflex 1266 PC B1 Year of construction: 2016, Commissioned: 2017 Equipped with SIEMENS 840D SL (Solution Line) CNC path control, with 5 simultaneously controlled axes Travel paths X: 1200 mm, Y: 660 mm, Z: 650 mm A-axis as swivel bridge +/– 135° (270°) B-axis 360° continuous Axis acceleration X + Y-axis 6 m/s² Axis acceleration Z-axis 9 m/s² Feed force X + Y-axis 7500 N Feed force Z-axis 10000 N Positioning tolerance (X/Y/Z) 0.008 mm A-axis swivel speed 180° rotation in 4 sec. Interference diameter on the swivel bridge max. 1400 mm Transport load on the swivel bridge max. 700 kg Tool holder HSK 63 Spindle speed max. 12,000 rpm, stepless Spindle power 37kW at 40% duty cycle Spindle torque at 40% duty cycle 85 Nm Maximum spindle torque 100 Nm Tool change time (chip-to-chip) approx. 3.7 sec. Tool diameter with adjacent slots occupied Ø 140 mm Tool diameter with adjacent slots free Ø 250 mm Maximum tool length 400 mm Maximum tool weight 20 kg Power supply 400 Volt, 50 Hz Connected load 80 kVA Compressed air connection 5-8 bar - LIFLEX MSP 80/63/85/12,000 motor spindle (output 37kW/40% duty cycle) with liquid cooling and recooling unit - 2-axis rotary tilting table LICON as B- and C-axis, with hydraulic axis clamping - Zero-point clamping system on the swivel axis turntable - Dual pallet changer, without pallets (these need to be newly sourced) - Media transfer of 5 single-action pressure lines for oil or air, for workpiece clamping on the pallets Hydraulic functions from 30-150 bar, with pressure monitoring (controllable via M-functions) - Tool changer with 30 tool positions, disc turret type - Machine designed for dry machining with minimal quantity lubrication (MQL) system - MQL-TSC, internal MQL lubrication supply through the spindle - Scraper belt chip conveyor, discharge height 1150 mm - Licon ECO-Mode (energy-efficient aggregate operation) - Direct linear measurement system on all axes - Operating hours (control voltage on) ≈ 7,500 h Space required for operation L x W x H 9,000 x 5,000 x 3,800 mm Space required for transport L x W x H 6,100 x 4,400 x 3,600 mm Base machine weight approx. 21 tons Total weight: approx. 24 tons Very good condition

Condition: as good as new (ex-display), Year of construction: 2023, Control : Sonstige Hurco Max 5 Njdpfxjlf E Ais Ahvokw Spindle Speed : 12,000 U/min Power : 11 kW Holder : SK 40 Torque : 61 Nm In general Travel X : 660 mm Travel Y : 406 mm Travel Z : 508 mm Rapid traverse X/Y/Z: 28 m/min Table : 762 x 406 mm Table load : 1,500 kg

Condition: excellent (used), Year of construction: 2018, Clausing Colchester 4VSQ MLLPWR CNC Turret Milling Machine Acu-rite Mill Power 3 Axis CNC Control Table Size 1370 x 254mm Travels: X – 1050mm Y – 390mm Z (Quill) – 115mm Z (Knee) – 355mm Vari Speed Head Spindle Taper IS040 Spindle Speeds Low 60 – 500rpm Spindle Speeds High 55 – 4300rpm Weight: 1850Kgs 3 Phase Electrics Manufactured: 2018 Complete with: Nsdpfox Af I Aex Ahvokw Vice Interlocking Table Guards Air Draw Bar Tooling Packaged (ISO40) Power Rise and Fall to Knee Auto Lube Worklight Coolant & Swarf Guards / Tray *For sale with Jet Machinery Ltd* Jet Machinery Stock No: #79028 Machine Serial Number: TC0015 Cost: £12,500.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 103, travel distance X-axis: 740 mm, travel distance Y-axis: 185 mm, travel distance Z-axis: 220 mm, controller model: NUM 1060, spindle speed (max.): 12,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X: 740 mm Travel Y: 185 mm Travel Z: 220 mm A-axis: 110° C-axis: 360° Tool holder: ISO25 Spindle speed: 50–12,000 rpm Minimum resolution: 0.001 Nkedpfx Aextm Nvehvjw MACHINE DETAILS Control: NUM 1060 Connected load: 10 kVA Dimensions & Weight Dimensions (L x W x H): 2,215 x 2,500 x 2,650 mm Machine weight: 3,550 kg EQUIPMENT Various tool holders Operating manual / Electrical schematic

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 106, travel distance X-axis: 740 mm, travel distance Y-axis: 185 mm, travel distance Z-axis: 220 mm, controller model: NUM 1060, spindle speed (max.): 12,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X: 740 mm Travel Y: 185 mm Travel Z: 220 mm A-Axis: 110° C-Axis: 360° Tool holder: ISO 25 Spindle speed: 50–12,000 rpm Minimum resolution: 0.001 MACHINE DETAILS Control: NUM 1060 Connected load: 10 kVA Nkodpfx Ahjxtm H Iovjw Dimensions & Weight Dimensions (L x W x H): 2,215 x 2,500 x 2,650 mm Machine weight: 3,550 kg EQUIPMENT Renishaw probing system Various tool holders Operating manual Electrical diagram

Condition: used, Year of construction: 2017, Operating hours: 51,800 h Program run hours: 15,100 h Technical Data: Travel paths/axes X = 800 mm Y = 850 mm Z = 1,050 mm B = 360°, 0.001° Max. spindle speed: 12,000 rpm Total connected load: 77 kVA Required space, LxWxH: 9,000 x 5,500 x 4,000 mm Weight: 18,100 kg Equipment: - Siemens 840D - Electronic handwheel - Heavy-duty machining package - Tool changer, rotary magazine with 180 places - Tool holder HSK 100 - Operator control panel - Internal coolant supply - Measurement and monitoring: Renishaw, infrared TDS, MPC Nodpsxqp Ivsfx Ahvekw

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 3,200 mm, travel distance Z-axis: 1,400 mm, table length: 6,000 mm, table width: 3,000 mm, spindle speed (max.): 24,000 rpm, distance between stands: 4,000 mm, Technical Specifications • Table clamping area: 6,000 × 3,000 mm • X-axis (longitudinal travel): 6,000 mm • Y-axis (cross travel): 3,200 mm • Z-axis (vertical travel): 1,400 mm • Distance between columns: 4,000 mm Njdpfexlip Aex Ahvekw • Feed speed: 30,000 mm/min • Table load: 4,000 kg/m² • Max. spindle speed: 24,000 rpm • Max. spindle power (S1-100%): 42 kW • Max. spindle torque (S1-100%): 67 Nm • Tool holder: HSK63A • Tool changer: 24 positions • C-axis: ±360° • A-axis: +95° / -110°

Condition: excellent (used), Year of construction: 2005, travel distance X-axis: 1,500 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 650 mm, rapid traverse X-axis: 8,000 m/min, rapid traverse Y-axis: 8,000 m/min, rapid traverse Z-axis: 8,000 m/min, table width: 610 mm, table length: 1,850 mm, table load: 1,000 kg, 3-axis CNC machine (VMC) STYLE - BT 1500 MACH-ID 9263 Make: STYLE Type: BT 1500 Year: 2005 Closed housing Chip conveyor Under power X - Travel: 1500mm Y - Travel: 650mm Z - Travel: 650mm Table Length: 1850mm Table Width: 610mm Table load: 1000 Feed rate X-Axis: 8000mm/min. Feed rate Y-Axis: 8000mm/min. Feed rate Z-Axis: 8000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 14kW Speeds / ranges: 6000Rpm ATC / revolver: 24 Number of controlled axis:3 Nkjdpfx Ahjxlgqksvsw Coolantsystem: Yes Length: 3100mm Width: 2300mm Height: 2500mm Weight: 5300kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Year of construction: 2022, condition: excellent (used), 5-axis Machining center independent clamp movement 16 positions tool magazine chip conveyor belt (horizontal) 2° chip conveyor belt (vertical) tool lenght probe 10 toolholders HSK 63 UPS Njdpju A Uq Isfx Ahvekw 11 kW spindle with liquid cooling 5 axis blade diam 450 mm automatic greasing kit extra blade unit 90° on moveable carriage wireless bor code reader

Condition: used, Year of construction: 2014, 5 axis machine QUASER MF400C/12C Year of production: November 2014 Installation date 2015 Table: ∅320 mm Passages: X- 410 mm Y- 610 mm Z- 510 mm A- +30° -120° C- 360° Tool holder: BT40 Tool magazine: 30 pcs Max spindle speed: 12,000 rpm Cooling through the spindle Nkedpfxjuclilo Ahvow Control: CNC SIEMENS SINUMERIK 828D Tool probe very good condition of the machine machine can be loaded on a standard truck height of the machine 275cm width 245cm length 300cm weight of machine 7300kg

Year of construction: 1993, condition: reconditioned (used), year - 1993 / 2020 complete reconditioned with new PLC Management tube diameter max. 100 mm Nksdpfx Ahsiau Uuevow wall thicknes - 10 mm pull up length of tube - 6000 /12000 mm Mandrel pipe bending up to 4 mm pipe wall thickness and pipe bending without mandrel from 5.0 - 10 mm pipe wall thickness accuracy of bending angle ± 0,2 ° total power requirement - 50 kW weight of the machine ca. 6 t

Year of construction: 1997, condition: good (used), Machine info: EVG Polybend stirrup machine PBE 2-16 come with 2 Pay offs - build in 1997 comes with a complete new control unit - original EVG Single wire: 6 –16 mm Twin strand: 6 –12 mm Voltage 400 Volt 50 Hz 30 Kw Njdpfxon Ut A Ss Ahvskw Production year: 1997

Year of construction: 2017, condition: like new (used), 2D Wire Bending Machime Year - 2017 Nkodemqk Tpjpfx Ahvjw Manufacturer - VIBRA Wire diameter - 1-4 mm Capacity - 30pieces/ min Power - 3,5 kw

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 630 mm, travel distance Y-axis: 710 mm, travel distance Z-axis: 630 mm, overall weight: 26,000 kg, TECHNICAL DETAILS X-travel: 630 mm Y-travel: 710 mm Z-travel: 630 mm (Previous) Application: Cylinder head production Engine type: 4-cylinder diesel (EA189) Production volume: approx. 2,000 parts/day MACHINE DETAILS Nkjdpfx Asv S H N Dehvjw Space requirement: approx. 5.7 × 3.4 × 3.2 m Machine weight: approx. 26 t EQUIPMENT - A-axis - Double spindle

Condition: ready for operation (used), Year of construction: 2002, machine/vehicle number: 32-45326, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 710 mm, number of slots in tool magazine: 52, Equipment: rotational speed infinitely variable, The machine is particularly suitable for machining cylinder heads and cylinder block housings. Maintenance and service intervals have been observed. TECHNICAL DETAILS X-travel: 800 mm Y-travel: 800 mm Z-travel: 710 mm Workpiece contour: Ø900 x 1000 mm Speeds Feed rate in X, Y, and Z axes: 36,000 mm/min Rapid traverse rate: 36,000 mm/min Spindle Tool holder: SK 50 Spindle diameter: 100 mm Speed: max. 12,000 rpm Pallets & Magazine Pallet size: 500 x 630 mm Tool magazine capacity: 52 Ball screw accuracy: Ø50 x 20 mm Nksdpfx Ahev Tlrajvjw MACHINE DETAILS Machine weight: approx. 12.5 t Total power requirement: 62 kW EQUIPMENT - B-axis - Continuously adjustable speed - Position measuring system

Condition: ready for operation (used), Year of construction: 2002, operating hours: 9,366 h, functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 610 mm, travel distance Z-axis: 560 mm, spindle speed (max.): 10,000 rpm, number of slots in tool magazine: 40, TECHNICAL DETAILS X-axis travel: 1,020 mm Y-axis travel: 610 mm Z-axis travel: 560 mm Spindle Spindle speed: 10,000 rpm Spindle power: 11–15 kW Pallet system Number of pallets: 2 Pallet size: 1,050 × 550 mm Cooling system High-pressure coolant system: 15 bar Tool changer Tool magazine: Chain type Number of tool positions: 40 Control system Control system: Fanuc 18M MACHINE DETAILS Overall dimensions (L × W × H): 4,020 × 2,660 × 3,080 mm Machine weight: 12,000 kg On-time: 37,210 h Operating hours: 9,366 h Nodpfxjwi Iw As Ahvekw EQUIPMENT - Chip conveyor included - 4th axis integrated as a table

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 80,000 m/min, rapid traverse Z-axis: 48,000 m/min, table width: 835 mm, table length: 3,500 mm, table load: 3,500 kg, 1 Axis CNC Swivel head, infinitely variable Axis drive with ball screw drive Roller linear guides in all axes Direct path measuring systems Full work area encosure with roof Chip conveyor Coolant unit X - Travel: 3000mm Y - Travel: 825mm Z - Travel: 1100mm B - Axis: - 3 to + 105° Table Length: 3500mm Table Width: 835mm Table load: 3500 Feed rate X-Axis: 48000mm/min. Feed rate Y-Axis: 80000mm/min. Feed rate Z-Axis: 48000mm/min. Spindle Taper: HSK 100ISO/Bt/Mk Power on spindle: 37kW Speeds / ranges: 8000Rpm Nkjdpfjwyv Nzex Ahvew ATC / revolver: 40 Coolant through spindle / Bar:25 Number of controlled axis: 4 Chip conveyor: Yes Coolantsystem: Yes Length: 8000mm Width: 3800mm Height: 3800mm

Condition: excellent (used), Year of construction: 2006, travel distance X-axis: 3,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 770 mm, rapid traverse X-axis: 30,000 m/min, rapid traverse Y-axis: 30,000 m/min, rapid traverse Z-axis: 30,000 m/min, table width: 1,000 mm, table length: 4,150 mm, table load: 4,000 kg, Magnum: powerful machining in machine construction and tool making Sk50 with extremely powerful spindel 50kw Glas scales in X/Y/Z Chip conveyor and coolant system X - Travel: 3500mm Y - Travel: 1000mm Z - Travel: 770mm Table Length: 4150mm Table Width: 1000mm Table load: 4000 Feed rate X-Axis: 30000mm/min. Feed rate Y-Axis: 30000mm/min. Feed rate Z-Axis: 30000mm/min. Spindle Taper: 50ISO/Bt/Mk Power on spindle: 50kW Nkodpowycmmofx Ahvew Speeds / ranges: 4500Rpm ATC / revolver: 50 Number of controlled axis:3 Chip conveyor: yes Coolantsystem: yes Length: 8000mm Width: 5000mm Height: 3700mm Weight: 30000kg

Condition: good (used), Year of construction: 2009, travel distance X-axis: 1,120 mm, travel distance Y-axis: 510 mm, travel distance Z-axis: 510 mm, rapid traverse X-axis: 36,000 m/min, rapid traverse Y-axis: 36,000 m/min, rapid traverse Z-axis: 36,000 m/min, table width: 510 mm, table length: 1,460 mm, table load: 800 kg, Renishaw measuring probe MP-12 IKZ 15 Bar Interface set Performabnce software package Monitoring B prepared not included Nodpfxow Rm Dij Ahvskw X - Travel: 1120mm Y - Travel: 510mm Z - Travel: 510mm Table Length: 1460mm Table Width: 510mm Table load: 800 Feed rate X-Axis: 36000mm/min. Feed rate Y-Axis: 36000mm/min. Feed rate Z-Axis: 36000mm/min. Spindle Taper: 40ISO/Bt/Mk Power on spindle: 18.5kW Speeds / ranges: 12000Rpm ATC / revolver: 30 Coolant through spindle / Bar:Yes Number of controlled axis: 3 Chip conveyor: Yes Coolantsystem: Yes Length: 3300mm Width: 2850mm Height: 2800mm Weight: 6100kg

Condition: good (used), Year of construction: 1999, functionality: fully functional, operating hours: 52,964 h, travel distance X-axis: 800 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 550 mm, controller model: Heidenhain MillPlus, spindle speed (max.): 12,000 rpm, No reserve price - guaranteed sale at the highest bid! TECHNICAL DETAILS X-axis: 800 mm Y-axis: 650 mm Z-axis: 550 mm Control: Heidenhain MillPlus Table Table length: 1,100 mm Table width: 650 mm Table load: max. 800 kg Feed rate X-axis: 20,000 mm/min Y-axis: 20,000 mm/min Z-axis: 20,000 mm/min Spindle Spindle mount: 40 ISO / BT / MK Spindle power: 15 kW Speed: max. 12,000 rpm Tool changer Number of tools: 24 Number of controlled axes: 3 MACHINE DETAILS Length: 3,400 mm Width: 2,400 mm Nkedpfx Ahjwnbqgovow Height: 2,800 mm Weight: 8,700 kg EQUIPMENT - 4th axis - Chip conveyor - Coolant system - Control cabinet

Condition: refurbished (used), Centreless grinding machine GHIRINGHELLI M2150 CNC 4 axes grinding wheel 200x610 CNC 4 axes Variable speed drive on grinding wheel complete overhaul with electric / electronic retrofit Machine in our warehouse in Gussago BS Mimu machine tools (Italy) Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. Nodpjgmf Rrefx Ahvekw During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is given to them with the aid of a tool. The through-feed grinding or also through grinding and longitudinal grinding: pieces to be worked proceed uninterruptedly with axial feed through the rectification gap. Grinding wheel width: 200 Grinding wheel diameter: 610 CNC: 4 axes
