Automatic powder coating system

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 270, center width: 900 mm, center height: 210 mm, spindle speed (max.): 3,000 rpm, Equipment: CE marking, TECHNICAL DETAILS Swing diameter over bed: 420 mm Klodpfx Ajy Rx A Sjfgjt Centre height: 210 mm Centre distance: 900 mm Spindle bore: 55 mm Spindle speed: 4 - 3,000 rpm MACHINE DETAILS Control type: Teach-in Control system: CNC EQUIPMENT Digital readout (Weiler) Documentation available CE marking

Condition: like new (used), Year of construction: 2023, operating hours: 800 h, functionality: fully functional, total length: 1,400 mm, total height: 2,300 mm, total width: 250 mm, workpiece weight (max.): 72 kg, For sale: Nearly new automatic powder coating line, installed in 2023, with approximately 800 operating hours. Current layout footprint: approx. 12 x 28 m, H 5 m. Price and dismantling timeline subject to individual agreements. Layout modifications available: pre-treatment tunnels can be added, and the curing oven can be reconfigured as a straight-through tunnel suitable for parts exceeding 6 meters in length. We can provide a complete quotation including dismantling and international relocation upon separate arrangement. Excellent opportunity to acquire an almost-new line at a lower price and with much shorter lead times compared to a new installation. Monorail conveyor: - Speed: 0.9 – 3.3 m/min - Automatic lubrication - Automatic chain tensioning unit - Chain pitch: 270 mm - Total length: 131 m - Total load capacity: 9500 kg - Steel supports between the floor and conveyor Automatic powder coating booth Gema: - PVC booth: MagicCompact EquiFlow BA04 - MagicControl 4.0 control panel - Photo-cell frame for automatic gun control - 16 x OptiGun GA03-P automatic guns - 1 x OptiSelect GM04 manual gun - 17 x OptiSpray AP01.1 powder feed pumps - OptiCenter OC07 powder feeding system - Ultrasonic sieve US07 for OptiCenter - 2 x ZA07-23 reciprocators with X-axis automatic control - MonoCyclone EZ05-16, 16,000 m³/h - Powder filter: 16,000 m³/h, 30 kW - Big-Bag system for waste powder collection - CO₂ explosion protection system - Manual spray wall / trolley unit shown in pictures NOT INCLUDED Kljdpfx Afjx H Tadegst Powder curing oven: - Hybrid heating (electricity or gas) — offers unique flexibility to choose the most economical energy source - Installed capacity: 300 kW - Max. temperature: 220°C - Siemens PLC control panel

Condition: ready for operation (used), Year of construction: 2014, machine/vehicle number: 441, functionality: fully functional, pressing force: 28 t, throat depth: 220 mm, overall weight: 3,600 kg, working width: 1,000 mm, Equipment: CE marking, TECHNICAL DETAILS Pressing force: 28 t Max. working width: 1,000 mm Column gap: 950 mm Throat depth: 220 mm Back gauge depth: 415 mm MACHINE DETAILS Dimensions & Weight Kjdoy Rxy Djpfx Afgjlt Dimensions (L x W x H): 1,500 x 1,150 x 2,400 mm Weight: 3,600 kg Transport packages: 1 Power: 3.0 kW EQUIPMENT CE marking Documentation

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, machine/vehicle number: 3098034, travel distance X-axis: 203 mm, travel distance Z-axis: 762 mm, spindle speed (max.): 1,800 rpm, bed width: 445 mm, center width: 900 mm, TECHNICAL DETAILS Swing diameter over bed: 900 mm Centre height: 450 mm Centre distance: 900 mm Klsdpfx Afey Rxxmoget Bed width: 445 mm X-axis travel: 203 mm Z-axis travel: 762 mm Spindle bore: 60 mm Max. spindle speed: 1,800 rpm MACHINE DETAILS Control: CNC Dimensions & Weight Dimensions (L x W x H): 2,400 x 1,600 x 1,950 mm Weight: 2,000 kg Transport packages: 2 pcs EQUIPMENT Documentation CE marking

Condition: new, Year of construction: 2024, Working width: 600 mm Working height: 150 mm Units: 4 brush units separately adjustable 1st unit, rotor group: group of 5 oscillating rotor brushes, Ø 115, each with a 3 kW motor 2nd unit, rotor group: group of 5 oscillating rotor brushes, Ø 115, each with one 3 kW motor 3rd unit, brush: Scotch Brite Hard / diameter 220mm, Vario drive 4th unit, brush: Scotch Brite Hard / diameter 220mm, Vario drive Height adjustment: electric Height display: digital Control: touchscreen Ksdjug Ty Hepfx Afgjlt Feed speed: 4 - 12 m/min Motor power feed: 0.37 kW Machine length: Machine width: Weight:

Condition: ready for operation (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 610555, travel distance X-axis: 610 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 510 mm, spindle speed (max.): 6,000 rpm, controller manufacturer: Fanuc, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel X-axis: 610 mm Travel Y-axis: 460 mm Travel Z-axis: 510 mm Spindle speed: 60 - 6,000 rpm Tool holder: BT40 Table length: 950 mm Table width: 560 mm MACHINE DETAILS Control: CNC Control system brand: Fanuc Power: 7.5 kW Kljdpfxey Rxu Uo Afgot Number of axes: 3 pcs. Dimensions & Weight Dimensions (L x W x H): 2100 x 2600 x 2600 mm Weight: 3,800 kg Shipping units: 1 pc.

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: 675002, travel distance X-axis: 650 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 500 mm, Equipment: chip conveyor, TECHNICAL DETAILS Klodpfxoy Rxryo Afget Travel X-axis: 650 mm Travel Y-axis: 1,100 mm Travel Z-axis: 500 mm C-axis rotation: 360° MACHINE DETAILS Control: CNC Dimensions & Weight Dimensions (L x W x H): 3,500 x 1,800 x 2,800 mm Net weight: 13,000 kg EQUIPMENT Chip conveyor Tool magazine Probe

Condition: good (used), Year of construction: 2016, functionality: fully functional, Used Durma CNC press brake Type: AD Servo 30175 Capacity: 3050 x 175 tons Cybelec ModEva 15T CNC control CNC-controlled Y1, Y2, X and R axes CNC crowning Akas Fiessler laser safety Includes tooling set Kljdpfx Afox Iflzeget

Condition: ready for operation (used), Year of construction: 1979, functionality: fully functional, spindle speed (max.): 450 rpm, workpiece weight (max.): 5,000 kg, working width: 2,000 mm, spindle diameter: 105 mm, TECHNICAL DETAILS Kljdpfsy Rxrtjx Afget Swing diameter over bed: 1,050 mm Working width: 2,000 mm Working depth: 1,050 mm Max. workpiece weight: 5,000 kg Spindle diameter: 105 mm Spindle bore: 105 mm Spindle speed: 2.24–450 rpm Thickness: 105 mm Distance between centers: 2,000 mm Max. workpiece weight: 5,000 kg MACHINE DETAILS Motor power: 22 kW Dimensions & Weight Dimensions (L x W x H): 4,900 mm x 1,900 mm x 1,700 mm Weight: 8,000 kg Control: Conventional EQUIPMENT Four-jaw chuck Steady rest

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 16090455, travel distance X-axis: 850 mm, travel distance Y-axis: 435 mm, travel distance Z-axis: 210 mm, table width: 500 mm, table length: 1,570 mm, TECHNICAL DETAILS X-axis travel: 850 mm Y-axis travel: 435 mm Z-axis travel: 210 mm Table length: 1,570 mm Table width: 500 mm Main spindle power: 3.8 kW Number of axes: 3 pcs. MACHINE DETAILS Control: CNC Control manufacturer: Heidenhain Power: 16.0 kW Dimensions & Weight Kljdoy Rxq Ajpfx Afgjt Dimensions (L x W x H): 2,800 x 1,800 x 2,300 mm Transport weight: 3,500 kg Transport packages: 3 pcs. EQUIPMENT Tools included External cooling Documentation

Condition: good (used), Year of construction: 2009, functionality: fully functional, machine/vehicle number: GG520A-17518 & GG502S-16471, total width: 5,100 mm, total length: 5,350 mm, total height: 1,500 mm, overall weight: 3,250 kg, type of input current: three-phase, input frequency: 50 Hz, pressure: 8 bar, cutting length (max.): 3,700 mm, Maximum measurement: 3210 mm Minimum measurement: 150 mm Maximum cutting length: 3700 mm Minimum cutting length: 250 mm Monolithic: 3–10 mm Laminated: minimum 2+0.38+2 (22-1) Ksdpfx Aoycgiiofgolt maximum 8+4.56+8 (88-12) Maximum glass weight for loading/unloading on arms: 450 kg

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 750 mm, spindle speed (max.): 12,000 rpm, number of axes: 3, TECHNICAL DETAILS X-axis travel: 1,000 mm Y-axis travel: 750 mm Ksdpfx Aey Rxqvefgelt Z-axis travel: 750 mm Tool holder: ISO40 Max. spindle speed: 12,000 rpm MACHINE DETAILS Control: CNC Power: 22.0 kW Number of axes: 3 Weight: 10,500 kg

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,067 h, functionality: fully functional, machine/vehicle number: 122616, travel distance X-axis: 500 mm, travel distance Y-axis: 95 mm, travel distance Z-axis: 1,650 mm, controller model: OKUMA OSP P200L, center width: 1,500 mm, TECHNICAL DETAILS Travel in X-axis: 500 mm Travel in Y-axis: 95 mm Travel in Z-axis: 1,650 mm Swing over bed: 550 mm Power: 22.0 kW Distance between centers: 1,500 mm Spindle bore: 80 mm Counter spindle speed: 4,500 rpm Tool magazine: 44 tools Tool holder: HSK-F63 Kjdoy Rxprspfx Afgslt Spindle speed: 12,000 rpm MACHINE DETAILS Control system: OKUMA OSP P200L Dimensions & Weight Dimensions (L x W x H): 5,100 x 2,800 x 2,900 mm Shipping weight: 13,700 kg Shipping packages: 7 pieces Operating hours: 19,067 h EQUIPMENT Automatic workpiece loader with controlled arm from Pneumotec Automatic bar feeder from LNS Quick Load Servo III Counter spindle VAC-MB11 Milling head with automatic tool changer Turret: 12 tool positions Chip conveyor Turret head Powered tools Bar loader 3-jaw chuck Tool magazine C-axis Documentation CE marking

Year of construction: 2011, condition: good (used), Offer 24370 Kedpfxot Srkpj Afgolt Sludge filtration system in a sea container + conveyor belt Technical data: - Sludge filter press JUNGHANS with cylinder unit - Flocculation system - Pumps - Separate conveyor belt for sludge removal, length 8.0 m - Control cabinet with electrical equipment - Water collection tray made of aluminum on the entire container floor - Lighting - Sea container with 4 doors - Space requirement for the container: approx. W 6.0 x H 2.4 x D 2.4 m - Weight: approx. 5000 kg - Space requirement for the conveyor belt: approx. W 8.0 x H 0.8 x D 1.0 m - Weight: approx. 1000 kg

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2006, operating hours: 14,434 h, controller model: Siemens Sinumerik 840D, laser power: 4,000 W, sheet thickness steel (max.): 20 mm, sheet thickness stainless steel (max.): 15 mm, travel distance X-axis: 3,000 mm, travel distance Y-axis: 1,500 mm, Equipment: safety light barrier, TECHNICAL DETAILS Laser power: 4,000 W Travel range X-axis: 3,000 mm Travel range Y-axis: 1,500 mm Sheet metal thickness, steel (max.): 20 mm Sheet metal thickness, stainless steel (max.): 15 mm MACHINE DETAILS Control model: Siemens Sinumerik 840D Beam-on hours: 14,434 h Power-on hours: 39,875 h EQUIPMENT Closed machine frame with integrated laser unit Laser unit: CO2 laser TFL 3200 high-frequency unit, maintenance-free turbo-radial blower, mirror telescope Automatic pallet changer Longitudinal conveyor belt for small parts/waste Drives: Maintenance-free three-phase AC servo motors Additional high-dynamic Xp-axis Cutting head quick-change device Kedpfx Afjy Rk Uyjgjlt Laser cutting head with 5" lens and 7.5" lens Cutting gas pressure setting, programmable APC capacitive height control and process control Automatic focus position adjustment AutoLas Plus Laser power control Positioning laser diode HI-LAS high-pressure cutting Fast processing with SprintLAS ContourLAS for producing smaller holes PMS plasma sensor Automatic sheet metal edge detection Programmable power cycles Compressed air cutting PCS Process Control System Microweld Spraying device for safe thick sheet metal processing Automatic shutdown Work area lighting Workshop programming ToPs 100 lite Control: Siemens Sinumerik 840D Open control system based on PC, easy operation, online help, integrated e-shop, diagnostic function, maintenance log, technology data, teleservice Safety equipment: Multi-beam light barriers, beam guidance completely encapsulated and ventilated, monitoring system, multi-chamber extraction and compact dust collector, protective cabin
