Gear Shaping MachineLIEBHERR
WSC 501
Machine data
- Machine type:
- Gear Shaping Machine
- Manufacturer:
- LIEBHERR
- Model:
- WSC 501
- Year of construction:
- 1985
- Condition:
- used
Price & Location
- Location:
- , Germany
Details about the offer
- Listing ID:
- A20354620
- Reference number:
- 1113-25066
- Update:
- 15.01.2026
Description
max. wheel diameter: 780 mm
gear width: 130 mm
max. module: 10
weight of the machine ca.: 8,5 t
no. of strokes: 30 Hub/min
Kedpfx Aexqgv Reh Njll
Hier fully functional machine, Little used
There are some Tools and Change gears
Liebherr WSC501 CNC gear shaping machine, used, ready for use
Manufacturer: Liebherr
Type: WSC 501
Mach.- No.: 4407/05
Year of manufacture: 1985
Details:
Max. gear shaping module: 8mm
(30°gears possible up to module 10°)
Max. gear width: 130mm
Diameter of the machine table: 500mm
Maximum wheel diameter: 780mm
Shut height – table: 650mm
Stroke rate min. 30DH/min
Continuously adjustable max. 1500 DH/min.
Operating voltage: 380V
Frequency: 50Hz
Control voltage: 110V
Connected load: 36 kVA
Rated current: 55A
Weight: 8500kg
Dimensions: approx. 4,85 x 3,655 x 3,78
(width x depth x height in m)
The machine has seen only very limited use in our company. It remains fully operational and can be demonstrated in function upon appointment. Comprehensive documentation is also available
The machine is particularly suitable for:
? Internal and external gearing in small batch sizes
? Internal gears in blind holes (non-through bores)
? External gears without run-out, where hobbing would not be possible
Typical workpieces include: internal gear rings for planetary gear systems, drive shafts, coupling hubs, and more.
Attractive Offer – Liebherr WSC501 CNC Gear Shaping Machine ?????
? ISO 9001 + EN 9100 Certified
? Excellent opportunity to acquire a robust German-made gear shaping machine
? Fully operational, with very limited usage history
? Demonstration possible upon appointment
Highlights:
- Suitable for internal and external gear shaping in small to medium batch sizes
- Unique capability for internal gears in blind holes
- Ideal for external gears without run-out, where hobbing would not be possible
- Applications: planetary gear rings, drive shafts, coupling hubs, and more
????? Benefit: Save costs compared to new machines while still relying on Liebherr quality.
Interested? Contact us today to arrange a viewing or request further technical details.
*
