KASTO KASTOflex F

KASTO KASTOflex F

Condition: excellent (used), max. workpiece diameter 600 mm threading length 7000 mm max. module 8 / 12 min. module 1 swival range ° diameter of hob 63 - 140 mm spindle turning speed - stepless 45 - 450 U/min Bljdpfjwgizdex Aa Eod weight of the machine ca. 12,5 t dimensions of the machine ca. 9,0 x 2,0 x 2,2 m Condition: In good condition, checked and partially overhauled by a specialist. The existing milling head was replaced by an overhauled universal milling head. Furnishing: Differential for inclined machining Automatic indexing device (indexing discs changeable!) For multi-wedge, multi-thread parts, then extensive bushings, support rollers and around 70 Change gears. Conversion of the milling head speed to a frequency converter with corresponding powerful motor is a great thing and saves a lot of set-up time. Equipment: Around 70 change gears, 3 bushing sticks of different sizes, around 20 Bushings, 2 roller mountings, 2 tips for direct mounting on the Clamping spindle, 350 mm chuck, 2 spare part disks.

Condition: used, Specifications Manufacturer LORENZ Model LS 630 Condition Used Stock Number DCL1722 Module 12 Max diameter 630 mm Working stroke 220 mm Center distance worktable / cutter spindle 450 mm Bjdjwr Dx Ujpfx Aa Ejld Machine weight 10.000 kg Spindle diameter 110 mm Table diameter 730 mm distance between table and spindle 580 mm Ø table hole 450 mm Description Equipped with : Change gears Manuals

Condition: used, Year of construction: 1992, Technical details: spindle diameter: 100 mm x-travel: 1500 mm y-travel: 1450 mm z-axis: 930 mm w-axis: 506 mm B-axis (table): 360 ° control for program: HdH TNC 407 tool taper: SK50 number of spindle speeds: 5 - 1.600 / stufenlos table load: 4,0 t table-size: 1100 x 1400 mm table rotating: 360 ° feed steps: X/Y/W/Z-Achse: 2 - 2000 mm/min Rapid feed X axis: X/Y/W/Z-Achse 5000 mm/min. total power requirement: 40 kW dimensions electric cabinet: 2000 x 600 x 2000 mm machine dimensions LxWxH: 4,9 x 3,7 x 3,8 m weight of the machine ca.: 14 t CNC drilling-milling machine with hydraulic power unit. Working paths from the table: X-axis table transverse 1500mm W-axis table longitudinal 1000mm 9x T-slots according to DIN 650 Equipment: measuring probe electronic handwheel Bljdsu Idqbspfx Aa Ejd hydr. weight compensation Y-axis universal milling head And some accessories, ask for them! i.D. *

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, Multifunctional CNC Turning, Boring and Milling Centre / Manufacturer: WFL Type: M120 MILLTURN x 3000 / Year of construction: 2008, Overhauld in 2025 TECHNICAL DATA: Working range: Blodjxt Uqhjpfx Aa Ejd - Centre distance / turning length (depending on clamping device): 3.000 mm - Swing diameter over bed (max. nominal dimension): 1.220 mm - Swing diameter over top of slide: 1.140 mm Accessories / Equipment: - Siemens SINUMERIK 840D CNC control pl - Turning/drilling/milling unit - NC tailstock - External tool magazine, 90-positions - Pick-up station - Cooling system - Chip conveyor - Further extensive equipment ... Detailed technical data sheet and information on equipment available on request. There is no guarantee for correctness and completeness of the technical details and accessories. - Subject to prior sale -

Condition: excellent (used), Year of construction: 2017, Max. turning length: 1,214 mm Max. turning diameter: 420 mm Chuck size: 305 mm Max. swing over bed: 700 mm Travel distances - X-axis: 280 mm - Y-axis: 120 mm - Z-axis: 1,390 mm Rapid traverse - Rapid traverse X/Y/Z: 20 / 10 / 24 m/min Spindle - Bar capacity: 89 mm - Max. speed: 2,500 rpm - Drive power: 22 / 18.5 kW - Torque: 1,050 / 883.8 Nm Blsdpfxew Tcvme Aa Eod Turret - Tool stations: 12 - Driven tool stations: 12 - Tool holder: BMT-65 Accessories: • Box ways • C-axis • Y-axis • Air blow gun • Steady rest base • Manual steady rest, manufacturer RICHTER • Chip conveyor • Automatic tailstock and quill • Work light • Coolant tank capacity: 240 liters Connected load: 55 kVA Weight: approx. 7,800 kg

Condition: ready for operation (used), Year of construction: 1984, Press force: 3600kN, press force stroke: 1.7mm, press work capacity: 6120J. Stroke: 60mm, installation height: 340mm. Table clamping width/depth: 440mm/525mm, tool holder width/depth: 440mm/320mm. Dimensions X/Y/Z: 1300mm/2000mm/2230mm, weight: approx. 6300kg. Blsdpfjr A Eifjx Aa Eed

Condition: excellent (used), Year of construction: 2010, Used Hankook model 7NB x 4000 2 axis CNC lathe Year 2010, serial number 41L09117 Manufacturer Hankook Country of Origin South Korea Model Protec 7NB x 4000 mm Machine Type Description 2 Axis CNC flat bed turning Centre CNC Control Fanuc 21- iT with MG-i MACHINE CONSTRUCTION & FEATURES  Heavy Cast iron Construction  Heavy Duty Hardened & Ground Solid Slideways  Large Spindle Bore  Full Length Rear Chip Guard  Automatic Lubrication to All Critical Areas MACHINE CAPACITIES Swing Over Bed Ø 750 mm Swing Over Carriage Ø 480 mm Max. Turning Dia. Ø 750 mm Distance Between Centres 4,000 mm Load Capacity 3,000 Kg SPINDLE Spindle Bore Ø 176 mm Nose A2-11 Spindle Centre Taper MT #6 Spindle Speed 3 – 1,000 RPM Spindle Speed Range Manual 2 Step AUTOMATIC V8 TURRET Number of Tools 8 Holder Diameter Ø 60 mm Mechanism Electric FEEDS Rapid Traverse X 3 m/min Z 6 m/min Travel X 425 mm Z 2070 mm TAILSTOCK Taper/Diameter MT #6 Quill Diameter Ø 112 mm Max. Quill Travel 200 mm MOTORS Spindle 15/18 Kw X - Axis 1.2 Kw Z - Axis 3 Kw WEIGHT Weight 5,520 Kgs STANDARD MACHINE FEATURES • CNC System • Single Front Door • Coolant System • Foundation Bolts and Liners • Work Light • Work Light • Centre Sleeve MT #6 x Taper 1/10 • Tool Box • Centre MT #6 • Full Length Rear Guard • Live Centre MT #6 STANDARD FITTED MACHINE OPTIONS • Fanuc 21-iT • Transformer for 415V, 3Ph, 50Hz Bljdpev Rqftefx Aa Eod HANKOOK 7NB x 4000mm with Fanuc 21-iTB Modified guarding for long boring bars 20” Chuck Steady rest 50 - 250mm Steady rest 250 - 450mm Algra Automatic 8 station Turret Boring Bar attachment 100mm diameter 60mm diameter boring bar toolholder (1 off) Inch Metric conversion Custom Macro B Additional Block Skip G Code System B/C Programmable Data Input Actual Spindle Speed Output tool offsets 32 Pairs Extended Part Program Edit Manual Guide i External i/o device control External data Input High Skip ADDITIONAL ACCESSORIES INCLUDED • Special Revolving Centre (TBC) • Marposs TT30 Removable Tool setting Arm • Short LNS swarf conveyor and coolant / swarf trays • Sandvik damped/tuned boring bar of size 100mm dia x 1500mm length supplied with the boring attachment. • Filtermist filtration • Additional door guarding.

Condition: like new (used), Year of construction: 2021, operating hours: 1,200 h, functionality: fully functional, turning diameter: 1,100 mm, power: 46 kW (62.54 HP), distance between centers: 2,000 mm, load hours: 1,200 h, A DMT CD1100 lathe with Heidenhain control and only 1,200 operating hours is available. The working area offers a swing diameter of approx. 1,100 mm over the bed and approx. 800 mm over the cross-slide. The tool holder is a Multifix D1. The distance between centers is 2,000 mm. The main spindle drive is a motor with 46 kW output at 60% duty cycle and two gearbox stages. Bodpfoxlza Hox Aa Esld Tailstock: - Quill diameter: 125 mm - Taper: 6 Morse taper Delivery: Collection by the buyer Payment: 100% via bank transfer immediately upon invoicing, prior to collection All information is non-binding. Subject to prior sale. The machine is sold without any guarantee or warranty claims and remains our property until full payment is received.

Condition: used, Year of construction: 1990, functionality: fully functional, machine/vehicle number: 07-16 1990, travel distance X-axis: 2,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 800 mm, A machine in good condition, as shown in the pictures, manufactured in 1990 and equipped with NCT 90 control. It has been used very little and is being sold due to underutilization. The total weight of the machine is 33 tons. The machine is fully operational. Disassembly and transportation are the responsibility of the buyer. Bljdpfx Asw Sx Agsa Esd

Condition: ready for operation (used), Year of construction: 2005, operating hours: 42,768 h, controller manufacturer: HEIDENHAIN, spindle speed (max.): 18,000 rpm, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 50 eVo linear was manufactured in 2005. It features a HEIDENHAIN control, a 40bar IKZ, a 60-tool magazine, and a spindle speed of 18k rpm. The machine includes automation capabilities fully adjustable for different product formats and positioning. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 50 eVo linear machine we have for sale. Contact us for more information. • Tool magazine: 60 tools • Through-spindle coolant (IKZ): 40 bar • Spindle overhauled in 2024 • B and C axes overhauled in 2024 Additional equipment • Automation (product handling), freely adjustable for product format and positioning • Paper belt filter • Blum laser tool break detection • Extraction system excluded Technical Specification Bledpfx Aaox Rd Hpj Eod Taper Size SK 40
