Laser cutter

BLM LC5

The COMBO BLM LC5 FIBER laser for cutting sheets, pipes and profiles in Fiber 2D technology was built in 2016 in Italy (laser installation: 2017). The laser has a transversely replaceable table, equipped with a module for cutting pipes and profiles. It also has a profile feeder and a receiving table. It works in an automatic cycle, so the operator's work on the machine only involves loading a bundle of profiles onto the feeder and collecting finished parts from the unloading table belt. The machine is designed in such a way that it optimizes the distribution of parts on one profile - after its previous measurement. LC5 allows for cutting pipes and sheets on one machine. This is the only solution on the market that guarantees double possibilities on one machine. The laser allows for performing machining tasks on materials such as: steel, stainless steel, brass, copper and aluminum. It cuts small and large formats of materials with the highest quality and efficiency.

laser source: IPG 4.0 kW, fiber optic
- Precitec Procutter head, with automatic focal length change
- automatic nozzle exchange
- sheet format: 3000 x 1500 mm
- maximum cutting thickness, mild steel: up to 6 mm (Nitrogen), 20 mm (Oxygen)
- maximum cutting thickness, stainless steel: up to 6 mm
- maximum cutting thickness, aluminum: up to 15 mm
- maximum cutting thickness, copper, bronze: up to 6 mm
- processing of pipes and closed profiles: up to fi 120 mm
- automatic profile loading: from 6.5 m
- maximum detail length, unloading length: 4500 mm
- inline or crosswise pallet exchange
- seam detection

BLM LC5 machine components:
- sheet metal module
- pipe module
- IPG resonator
- cooler
- exhaust
- automatic lime dispenser for aluminum cutting
