Gibbs Machinery Company

Condition: excellent (used), Year of construction: 2018, Functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 655 mm, travel distance Z-axis: 750 mm, controller manufacturer: Siemens, controller model: Sinumerik 840 D, workpiece diameter (max.): 700 mm, spindle speed (max.): 18,000 rpm, distance between spindles: 700 mm, number of spindles: 2, number of slots in tool magazine: 80, Two complete and one partial 5-Axis CNC high production flexible machining lines manufactured by Grob are available for negotiated sale. Each line has a Fanuc Robot "load-in" station where the part is introduced to the Grob integrated gantry system. The gantry system has two traveling arms for loading/unloading parts in to the (8) Grob G326 Dual Spindle 5-Axis CNC Machining Centers and (3) Sugino JCC-W6650TE Jet Clean Center CNC Washing and Deburring Machines. Parts are then removed and placed in dunnage by a Fanuc Robot "load-out" station. Line 1 (8) GROB G326 Dual Spindle 5-Axis CNC Horizontal Machining Centers (2018 - 2021): Siemens Sinumerik 840 D CNC Controls, (2) HSK-A63 18,000 rpm Spindles per Machine, (2) 80 Pocket ATC per Machine, Independent Z-Axis, Independent X-Axis, XV-Axis, Spindle/Tool Seating, Spindle No Load Monitoring, Gantry Top Door Loading, 600 mm X-Axis, 655 mm Y-Axis, 750 mm Z-Axis, 700 mm Distance Between Spindles, 2.3 Seconds Chip-to-Chip Time, 1070 kg Max Table Load Spindles Replaced 2022 GROB SPC: Part Handling Transfer Station (2) SUGINO JCC-W6650 CNC Turret Type High Pressure Washing & Deburring Machine (2018): Fanuc Series Oi-MF Control, HP Water Deburring - Variable Up to 7,250 PSI, Sugino OEM Tri-Plex Plunger Pump, 0.08 mm Positioning, Turntable, 6-Tool Turret, 650 mm X-Axis, 500 mm Y-Axis, 500 mm Z-Axis, 48 m/min Rapid Feed, Multiple Filtration Options to 5-10 Microns (1) SUGINO JCC-VCD55SNE CNC Vacuum Dryer (2018): Fanuc Oi-MF Control, 5.5 kW Vacuum Drying Pump, Omron F3SJ Safety Light Curtain, Signal Tower (3-Layers), Ethernet I/P, 4-Axis (X,Y,Z,A), Manual Pulse Generator (2) FANUC Robots: R30iB Controller, Control Pendant, Safety Guarding GROB: Integrated Gantry System Line 2 Klolhcjv Dydxocqlsr (8) GROB G326 Dual Spindle 5-Axis CNC Horizontal Machining Centers (2018 - 2021): Siemens Sinumerik 840 D CNC Controls, (2) HSK-A63 18,000 rpm Spindles per Machine, (2) 80 Pocket ATC per Machine, Independent Z-Axis, Independent X-Axis, XV-Axis, Spindle/Tool Seating, Spindle No Load Monitoring, Gantry Top Door Loading, 600 mm X-Axis, 655 mm Y-Axis, 750 mm Z-Axis, 700 mm Distance Between Spindles, 2.3 Seconds Chip-to-Chip Time, 1070 kg Max Table Load GROB SPC: Part Handling Transfer Station (2) SUGINO JCC-W6650 CNC Turret Type High Pressure Washing & Deburring Machine (2018): Fanuc Series Oi-MF Control, HP Water Deburring - Variable Up to 7,250 PSI, Sugino OEM Tri-Plex Plunger Pump, 0.08 mm Positioning, Turntable, 6-Tool Turret, 650 mm X-Axis, 500 mm Y-Axis, 500 mm Z-Axis, 48 m/min Rapid Feed, Multiple Filtration Options to 5-10 Microns (1) SUGINO JCC-VCD55SNE CNC Vacuum Dryer (2018): Fanuc Oi-MF Control, 5.5 kW Vacuum Drying Pump, Omron F3SJ Safety Light Curtain, Signal Tower (3-Layers), Ethernet I/P, 4-Axis (X,Y,Z,A), Manual Pulse Generator (1) FANUC Robot: R30iB Controller, Control Pendant, Safety Guarding GROB: Integrated Gantry System Line 3 (4) GROB G326 Dual Spindle 5-Axis CNC Horizontal Machining Centers (2018 - 2022): Siemens Sinumerik 840 D CNC Controls, (2) HSK-A63 18,000 rpm Spindles per Machine, 80 Pocket ATC, Independent Z-Axis, Independent X-Axis, Spindle/Tool Seating, Spindle No Load Monitoring, Gantry Top Door Loading, 600 mm X-Axis, 655 mm Y-Axis, 750 mm Z-Axis, 700 mm Distance Between Spindles, 2.3 Seconds Chip-to-Chip Time, 1070 kg Max Table Load GROB: Integrated Gantry System

Condition: used, Year of construction: 2015, machine/vehicle number: 25600, rotational speed (min.): 30 rpm, grinding wheel speed: 17,000 rpm, grinding wheel diameter: 300 mm, overall weight: 29,000 kg, grinding wheel width: 60 mm, table diameter: 930 mm, Equipped with: Siemens Sinumerik 840D Control Extended 1500 mm Gear Diameter Extended Working Stroke (Y Axis) 1500 mm CNC Dresser Prepped for Internal Grinding BfG Best-Fit Grinding Software High Speed Grinding Steady Rest Onboard Inspection (Profile, Lead, Spacing) Upgraded Inspection for Scanning/Digital Measurement Hydraulic Clamping System Profile & Lead Modifications Double-Helical Grinding Grind from Solid Root Grinding Kjlhcsvggwwecqljlr Hydraulic Unit Lubrication System Chiller Specifications: Operating Range: -Maximum Gear Outside Diameter: 1,500 mm -Maximum Stroke Length: 1,500 mm -Maximum Stroke Length of Tailstock: 1,500 mm -Minimum/Maximum Center Distance Above Table: 500 - 2,000 mm -Minimum Module: 0.5 -Maximum Pivoting Angle: -45 / +120 Degrees -Maximum Grinding Spindle Drive Power: 38.5 kW -Maximum Grinding Wheel Outside Diameter: 300 mm -Maximum Grinding Wheel Width: 60 -Maximum Stroke Speed: 12,000 mm/min -Minimum/Maximum Workpiece Table Speed: 0 - 30 RPM -Maximum Workpiece Table Load: 8,000 kg -Workpiece Table Diameter: 930 mm -Total Weight, Approximate: 29,000 kg -Space Requirement (width x depth x height): 5,2 x 6,9 x 3.6 m

Year of construction: 2023, Condition: new, Functionality: fully functional, operating temperature: 1,500 °C, COMPLETE SYSTEM INCLUDING: (2) NEL C30 Hydrogen Generators On Site Gas System N-500 TGN Nitrogen Generator 110 MoLa Carrier Tray Sets RO/DI Water System Kleletxbuxohccqljr Bus Rail TRAY SIZE: 330 mm W x 330 mm L LOADING HEIGHT: 300 mm H CAPACITY IN 316L CYCLE: 8-10 Trays/hr NUMBER OF REST DEBINDING ZONES: 10 x 20 kW Top/Bottom Control NUMBER OF SINTERING ZONES: 10 x 30 kW SEGMENTS OF COOLING ZONE: 2 x 3m, 1 x 2m +Belt Drive and Return MAXIMUM TEMPERATURE REST DEBINDING: 800 C MAXIMUM SINTERING TEMPERATURE: 1,500 C PROCESS GAS CONSUMPTION (H2): 30-50 m3/h PURGE LOCK NITROGEN GAS CONSUMPTION: 34 m3/h POWER CONSUMPTION: 70kWh COOLING WATER CONSUMPTION: 3 m3/h POWER: 3 x 480V / 60Hz INSTALLED POWER: 500 kW IDLE MODE NITROGEN GAS CONSUMTPION: 15-16 m3/h IDLE MODE HYDROGEN GAS CONSUMPTION: 1-1.5 m3/h

Condition: excellent (used), Year of construction: 2014, Functionality: fully functional, center height: 250 mm, grinding length: 1,500 mm, grinding wheel diameter: 610 mm, grinding diameter: 480 mm, distance between centers: 1,520 mm, 2014 CNC Cylindrical Grinder Immediately Available, Inquire for CIF Pricing Kljlhccqsr I A Uijljr Equipped With: Fanuc OiM CNC Controller SBS SB-100 Wheel Balancer Pendant Controller CNC Diamond Dresser Touch Probing Live Headstock with Center Tailstock with Center Coolant System

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Klslhccerualpeqljr Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Klelhcoruakgjcqler Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: good (used), Equipped with: Kelheruaiqeccqljlr Siemens Simatec Panel PC Qass Crack Detection Headstock Tailstock Load Unload Panel Chiller Specifications: 4 Ton Capacity 500mm Maximum Workpiece Length

Condition: good (used), Year of construction: 1993, Equipped with: 9" Cutter Head Power Stocks Crowning Auto Loader Heidenhein Scales Kelhccqjruahweljlr Variable Feed/Speed Cutter Head RS232 Serial Port Trabon Lube Coolant W/Magnetic Chip Separator AC Servo Motors Full Splash Guards Stack Light Manuals Specifications: Work Gear Pitch Diameter 9" & 12" Cutter Head: 1-12", 1-8" Work Gear Max. O.D. 9" & 12" Cutter Head: 12 1/2", 8 1/2" Diameter Pitch Range: 4-20 Distance Between Centers: 23" Cutter RPM 9" & 12" Cutter Head" 50-500, 50-400 Max. Table Travel Conventional, Tangential, Diagonal: 5", 2" 5"-2" Diagonal Traverse Angle Straight Shaving: 0 Deg. - 90 Deg. Traverse Angle Crown Shaving: 45 Deg. Max. Approx. Max. Table Angle Crowning: 5 Deg. Max. Table Angle Taper: 1 Deg 30' Max. Cutter Head Crossed Axes Angle Left & Right: 25 Deg. Table Cross Feed Inches Per Minute: .5-35 Table Up-Down Feed Inches Per Minute: .004-12.5 Table Up-Down Travel: 8 1/8" Approx. Weight: 9600 lbs

Condition: good (used), Equipped with: Automatic Backlash Control Spindle Taper Adapter Motors and Controls Hand Remote Worklight Specifications: Distance from center of gear spindle to nose of pinion spindle (maximum): 26" (660mm) Distance from center of gear spindle to nose of pinion spindle (minimum): 6" (152mm) Distance from center of pinion spindle to nose of gear spindle (maximum): 18" (457mm) Distance from center of pinion spindle to nose of gear spindle (minimum): 5" (127mm) Offset of gear spindle above center of pinion spindle (maximum): 5.5" (140mm) Offset of gear spindle below the center of pinion spindle (maximum): 3.5" (89mm) Diameter of gear (maximum): Bevel/Hypoid Gears w/ pinion below center of gear: 36.5" (927mm) Keloruahdshccqlslr Hypoid Gears with pinion 1" above the centerline of gear: 34.5" (876mm) Hypoid Gears with pinion 2" above the centerline of gear: 32.5" (825mm) Hypoid Gears with pinion 3" above the centerline of gear: 30.5" (774mm) Hypoid Gears with pinion 3.5" above the centerline of gear: 28.5" (724mm) Pinion Spindle: Diameter of taper hole at large end: 6" (152mm) Taper per foot: 0.75" (19mm) Depth of taper: 6" (152mm) Diameter of hole through spindle: 5 9/18" (141mm) Gear Spindle: Diameter of taper hole at large end: 3 29/32" (100mm) Taper per foot: 39/64" (15mm) Depth of taper: 6" (152mm) Diameter of hole through spindle: 2.5" (64mm) Electrical Equipment: Main Motor - 2 Speed: 7-1/2 / 3-3/4 HP, 1800/900 RPM Lapping Pump Motor: 1/2 HP, 1800 RPM Drive Spindle: 900/450 RPM Floor Space: 68" x 69" (173mm x 175mm) Net Weight: 7,000 Lbs. (3,175kg) Shipping Weight, Boxed for Export: 7,800 Lbs. (3538 kg)

Condition: good (used), Year of construction: 2002, LANDIS 3SE 14"x 60"ANGLEHEAD CNC GRINDER REBUILT BY LANDIS & TOOLED 2002 Equipped with: NEW FANUC CONTROL 2007 2-Axis Template Truform Servo Step Profile 30 Degree 30" Wheel Dead Headstock Table Traverse Marposs E39 Marposs Table Gauge Lateral Locator 3-Gauge TIR Gauge Steady Rests Wheel Balance Servo Motor-Traverse Stepping Motor Mist Collector Specifications: Swing: 14" Center Distance: 60" Motor: 1200 rpm Motor Pulley Diameter: 7.031" Spindle Pulley Diameter: 6.5" New Wheel Diameter: 30" Worn Wheel Diameter: 22" Max. Wheel: 8500 sfpm Max. Workhead: 333rpm X-Axis Ball Screw Pitch: 5mm per rev. X-Axis Total Stroke: 14.74" X-Axis Motor Pully Wheel Feed Diameter: 3" X-Axis Ball Screw Pulley Diameter: 3" Z-Axis Ball Screw Pitch: 10mm per rev. Z-Axis Total Stroke: 72.88" Z-Axis Motor Pulley Diameter: 3" Z-Axis Ball Screw Pulley Diameter: 6" Total Stroke: +/-2mm Total Marposs Voltage Output: =/-10vdc Dresser One Revolution of the Stepping Motor: .045" Diamond One Revolution of the Stepping Motor: .005" Klslhccertr Eaoqlor Weight: 25,000 lbs.

Condition: good (used), Year of construction: 1998, grinding wheel diameter: 915 mm, overall weight: 14,000 kg, GIUSTINA Grinder R242 to ground big bearings (up to 800mm). All machine's actions are controlled by Bosch Control. Beside controlling parts grinding process, the NC programs are also an operator guide for the machine set up and a source of information about wheel wear, thus allowing the operator to check wheels without opening the hood. Equipped with: Bosch CNC Control Specifications: Wheel Rotation Axis: Horizontal Grinding Wheel Size (OD): 915 mm Grinding Wheel Size, Usable Width: 65 mm Grinding Wheel Size, Peripheral Speed: 30 ms Spindle Motors: 75 kw Grinding Feedrate: 0.1 - 1000 mm/min Spindle Type: Moving Quill Angular Contact Spindle Bearings (Precision): ABEC-7 (ISO4) Slide Position Accuracy: 0.001 mm Kolhcertr D Iscqlelr Coolant Flow Rate: 600 l/min Work Capacity (Approx) Rotary: 20 -200 Dia. In.

Condition: good (used), Year of construction: 2003, NAGEL MODEL TBT M320-6 6 SPINDLE CNC HORIZONTAL GUN DRILL, 2003 Equipped with: Panel Mate Power Pro Control Kolhccortrztjqlelr Counter Rotation Cross Drilling High Pressure Coolant System Auto Loader Magnetic Chip Separator Hydraulic System Chiller Specifications: Maximum Drill Depth (Approx): 16" Maximum Drill Length: 36" Number of Drill Spindles: 6 Spindle Motors (3): 7.5HP HP Per Spindle: 3.75 Drill Head Slide Stroke: 16.9" Maximum Diameter Mild Steel: 0.750"

Condition: good (used), Year of construction: 2013, TOYODA (JTEKT) GL32M-63 CNC UNIVERSAL CYLINDRICAL GRINDER Equipped with: CBN Grinding Wheel Flagging Steady Rest Workhead Mounted Rotary Dresser Marposs P3SE System Monitoring Toyoda In Process Gaging Marposs E20N Acoustic Controller Air Gap Eliminator Workpiece Collision Control Coolant Pumps W/Magnetic Separator Pendant Control RH Workhead with Center LH Workhead with Center Work Rests Worklight Light Curtains Stacklight Extra Wheels Specifications: -Grind Center to Floor: 1,000 mm -Swing Over Table: 320 mm -Distance Between Centers: 630 mm -Grinding Diameter Range: 10 - 150 mm -Floor Space (Base machine w/auxiliary equipment): 3,400 x 5,000 mm -Net Machine Mass (approx.): 10,500 kg Grinding Wheel: -Type: CBN Wheel -Wheel Size (OD): 350 mm -Maximum Wheel Width: 60 mm -Surface Speed: 120 m/s Wheelhead: -Spindle Bearing: TOYODA STAT Bearing -Slide: V and Flat Kolhccsrtrzpjqlolr -Feed System: Ballscrew -Rapid Feed (on diameter): 30 m/min -Minimum Incsrement (on diameter): 0.0001 mm Workhead: -Type: Dead Spindle -Work Speed (Max): 500 rpm -Center Taper: MT #4 Footstock: -Type: Hydraulic -Taper Compensation: Manual -Maximum Center Retraction: 60 mm -Center Taper: MT #4 Motors: -Wheel Drive Motor: 15 kW, Belt-Drive -Wheelhead Feed Servomotor: 1.3 kW Tank Capacities: -Wheel Spindle Lubrication Oil: 80 L -Hydraulic/Lubrication Oil: 20 L

Year of construction: 1978, Condition: good (used), U.S. MODEL 50TX120 VERTICAL PULL DOWN BROACH Equipped with: Retriever Puller Hydraulic System Coolant System Chiller Chip Conveyor Manuals Specifications: Normal Broaching Capacity: 100,000 Lbs at 922 PSI Peak Force Capacity: 133,600 Lbs at 1350 PSI Main Slide Stroke (Bump Inches): 106 Maximum Cutting Speed: 20 Ft/Min. Maximum Return Speed: 40 Ft/Min. Main Pump Motor: 75 HP at 900 RPM Hydraulic Reservoir: 365 Gallons Handling Pump Motor: 10 HP at 1200 RPM Coolant Pump Motor: 1.5 HP at 1800 RPM Coolant Pump Capacity: 100 Gallons / Min at 23 Head Ft. Klelortrzlehccqlsr Coolant Reservoir Capacity: 600 Gallons Approx. Floor Space ( Width x Depth x Height): 65" x 96" x 243" Net Weight, Approximate: 79,000 #

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Kolhertrzdeccqlslr Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: good (used), overall weight: 10,364 kg, Year of construction: 2019, 2019 GENERAL BROACH 10-30 GBTU VERTICAL TABLE UP BROACH Klslortrzashccqlsr Equipped with: Retriever Shuttle Table Chip Conveyor Auto Load Grayco Lube AB Panelview Coolant Tank & Pump Specifications: Capacity: 10 Ton Stroke: 30" Table Up 1″ Puller / Retriever Hydraulic Power Unit Chip Conveyor Machine Dimensions (approx.): 165″ x 48″ x 60″ Machine Weight Total (approx.): 22,800 lbs. Machine Column (approx.) : 13,000 lbs. Base w/ Chip Conveyor (approx.): 4,700 lbs. Electrical Panel (approx.): 600 lbs. Hydraulic Power Unit (approx.): 4,500 lbs.

Condition: good (used), Year of construction: 2011, CNC 235 BUDERUS HARD TURNING/GRINDING CENTER, 2011 Equipped with: Main Spindle 2-I.D. Grinding Spindles 8 Position Turret Siemens 840D Control Hydraulic Chucking Rotary Dresser Chip Conveyor Gantry Loader Marposs E9066M Hydraulic System Chip Bucket Fire Suspension Sysem Chiller Klolhccertryyoqler Specifications: Number of Main Spindles: 1 Maximum Work Part Diameter: 200 mm Maximum Part Length: 150 mm Maximum Number Machining Station: 4 Rapid Feed/Speed X/Z: 90/30 m/min

Condition: good (used), Year of construction: 2013, 2013 Gleason 175GMM Gear Inspection System Equipped with: Windows 7 Upgrade 2016 New Computer Upgrade 2016 GAMA Software Update 2016 New Rotary Table Installed 2018 Klelertryrohccqlor Specifications: Nominal Workpiece Diameter: 175 mm Module Range: 0.4-6.35 Center Distance: 380 mm

Condition: good (used), gear diameter: 508 mm, total height: 1,780 mm, total length: 2,990 mm, total width: 2,200 mm, MODEL 610 GLEASON GEAR ROUGHER/FINISHER Equipped with: Hydraulic Workholding Pendant Control Chip Conveyor Index Plate Geneva Cam Change Gears Hydraulic System Coolant System Manuals Specifications: Maximum Gear Pitch Diameter: 20" Cutter Diameters: 9", 10.5", 12",14",16", 18" Whole Depth: 1.250" Root Angle: 60 to 80 deg. Face Width: 3.0" Extreme Ratio (Minimum): 2.25 to 1 Kslhccjrtrykoqlelr Number of Teeth: 20 to 75 Diameter of Taper Hole at Large End: 3-27/64" Cutter Speeds (Per Minute) for Roughing: 15.6' to 87.7' Feeds (Seconds Per Tooth) for Roughing: 3 to 35 Cutter speeds (Per Minute) for Finishing: 6.8' to 20.5' Feeds (Seconds Per Tooth) for Finishing: 3 to 9 Floor Space: 118" x 86.5" x 70" H Weight: 17,500 lbs.

Condition: good (used), overall weight: 8,500 kg, total length: 3,990 mm, total width: 2,280 mm, total height: 2,500 mm, Year of construction: 2013, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks Kelsrtrx Rshccqljlr (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: good (used), Year of construction: 2011, LANDIS LT-2 TWIN WHEEL CNC ORBITAL CRANK GRINDER Equipped with: Landis 6400 CNC Control Siemens TOUCH HMI Arobetech Steady Rest Marposs P7 Gage System Lateral Locator Twin CBN Grinding Wheels Rotary Dresser Headstock Tailstock Rittal AC Units Specifications: Klolhccqsrtrxxoljr Maximum Center Distance: 680 mm

Condition: good (used), Year of construction: 1973, FELLOWS 70-15 GEAR SHAPER - Model 70-15 Fellows heavy duty vertical gear shaping machine , suitable for the manufacture of external straight spur gears up to 70" pitch diameter, as well as internal spur gears and splines within a range of 0" to 88" pitch diameter, regardless of shaper-cutter radius. This unique feature, combined with the machines 15" face-width capacity and 1.7DP cutting capability in steel, provide a formidable platform for producing a wide range of larger geared part members. Equipped with: * Machine Main Base With Work-table, Upper Column, Cutter Ram and Slide of "Super Robust" Construction * Machine with "Saddle Backoff" Method of Cutter Relieving * Cutter Spindle 6.25" diameter w/Standard Straight Spur Guide * Cutter Positioning via Stroke Jog-Button * Rapid Rotation of Work Spindle for Trueing Work-Piece * Rapid Saddle Traverse for Traversing Saddle Relative to Work * Automatic Depth Feed Mechanism for One to Four Cuts, With 4 Speed Motor Kelhertrxijccqlolr Providing Speed Change on Finishing Cut * Assorted Work and Feed Change Gears * Assorted Stroke Change Gears * 2" Riser Plate * Main Drive Motor 15HP, 650/220 rpm, 240 Volt 60Hz w/Westinghouse Rectifier Unit for AC * Power Forced Lubrication to Working Elements with "Lubriquip Lub Controller" * Coolant Tank, Pump, and Piping, With Chip Pan * Full Complement of Electrics * Assorted Guards, Covers * 84" T-Slotted Table * Hydraulic System * Work Lamp * Work Platform * Cutter Adaptor * Manuals Specifications: Max. Diameter External Gear Cut (Nominal): 70" Max. Diameter Internal Gear Cut (Nominal): 88" Max. Diameter Workpiece Accommodated: 104" Worktable Diameter: 84" Max. Permissible Weight of Workpiece & Fixture: 36,000 Lbs. Max. Distance Workspindle Centerline to Centerline of Cutter Spindle: 35" Min. Distance Workspindle Centerline to Centerline of Cutter Spindle: 0" Max. Work & Fixture Clearance Height w/Cutter Spindle in Upper Position: 28" Max. Diametral Pitch (full length teeth): 2 DP Max. Diametral Pitch (stub teeth): .75 DP Max. Diameter Pitch (30P.A. splines): 2-5/5 DP Diameter of Cutter Spindle: 6.25" Max. Stroke Length: 19.118" Max. Face-Width (nominal): 15" Stroking Speeds (infinitely variable): 5 to 122 S.P.M. Max. Infeed of Cutter Ram: .0020 inch/min. Min. Infeed of Cutter Ram: .0005 inch/min. Max. Rotary Feed Per Stroke (per 1" of cutter diameter): .0068"/Min. Min. Rotary Feed Per Stroke (per 1" of cutter diameter): .0006"/Min. Approximate Machine Dimensions: 192"L x 144"W x 150"H Approximate Machine Weight: 95,000 Lbs.

Condition: good (used), Year of construction: 1972, table diameter: 700 mm, total length: 5,970 mm, total height: 3,500 mm, total width: 2,920 mm, workpiece diameter (max.): 900 mm, overall weight: 8,545 kg, PFAUTER P-900 Gear Hobber for sale, max dia. 36", axial travel 19.685", hob dia. 7.559", Includes chip conveyor, coolant system, change gears and arbors.. Equipped with: Differential Two-Cut Cycle Tangential Cycle Tailstock W/Center Change Gears Arbors Chip Conveyor Coolant System Kjlhccqjrtrxbelslr Specifications: Maximum Workpiece Diameter: 35.433" Maximum Axial Travel: 19.685" Worktable Diameter: 27.559" Workhead Spindle Bore: 7.087" Maximum Radial Center Distance: 21.654" Minimum Radial Center Distance: 1.969" Maximum Hob Diameter: 7.559" Maximum Hob Length: 8.465" Maximum Hob Shift Travel: 7.874" Hob Speed Range (Inf. Variable): 45 - 280 RPM Rapid Traverse Radial: 0.069 in/min Machine Weight: 18,739# Plant Power: 460 VAC, 60 Hz Machine Dimensions (lxwxh): 235.433" x 114.764" x 137.795"

Condition: good (used), Year of construction: 2013, travel distance X-axis: 1,050 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 510 mm, controller manufacturer: Fanuc, controller model: 31Ia, total height: 2,920 mm, total length: 2,870 mm, total width: 2,590 mm, overall weight: 7,250 kg, spindle speed (min.): 100 rpm, spindle speed (max.): 20,000 rpm, Equipped with: 31ia Fanuc Control 4th/5th Axis 20,000 RPM Spindle (30) ATC Coolant System Chip Blaster High Pressure Coolant Chiller LNS Chip Conveyor Specifications: Table Work Surface Area: 49.61″ x 23.62″ Kljlhccsrtrw Tjqlsr Max. Workpiece Weight Loadable on Table: 2646 lbs Travel on X-Axis（Table right/left): 41.34″ Travel on Y-axis（Saddle back/forth): 20.87″ Travel on Z-axis（Spindle head up/down): 20.08″ Distance From Table Top Surface to Spindle Nose: 5.91″ – 25.98″ Distance From Column Front to Spindle Center: 24.25″ Distance From Floor to Table Work Surface: 35.43″ Spindle Speed: 100 – 20,000 RPM Number of Spindle Speeds: (Electric): 2 Steps Spindle Nose:（nominal number): No. 40 Type of Tool shank: CAT40 Number of stored tools: 30 ATC

Condition: good (used), Year of construction: 2007, machine/vehicle number: 8580-20, Equipped with: Fanuc PNC Deco Whirler IEMCA GN120-37 Bar Feed Coolant Tank Chip Conveyor CE Mark Specifications: Sliding headstock (axis Z1/C1) Max. bar passage o 20 (25,4) mm Length of parts - guide bush turning 200 mm Programmable spindle rotation speed 100-10000 rpm Positioned indexing and stop, increments 0.1 degree Max. spindle power 3.7 (5.5) kW Guide bush holder (X1/Y1) (X2/Y2) Number of tools in the guide bush (fixed or turning) 2 x 5 Tool section 16 x 16 mm Number of cross millers/drillers in the guide bush 4 Programmable rotation speed 100-8000 rpm Max. power of turning spindles 1.5 (2.2) kW End unit (X3/Y3) Max. number of end tools (fixed or turning) 4 Programmable rotation speed 100-6000 rpm Max. power of turning spindles 1.5 (2.2) kW Counter-spindle and back-operation (X4/Y4/Z4/C4) Max. diameter clamping capacity 20 (25.4) mm Standard length of parts 200 mm Programmable rotation speed 100-10000 rpm Positioned indexing and stop, increments 0.1 degree Max. number of back-operations Number of fixed and turning spindles 7 Programmable spindle rotation speed 100-8000 rpm Max. power of turning spindles 1.5 (2.2) kW Kolhsrtrv Ieccqlslr
