Floor Type Boring and Milling M/C - Hor.

WOTAN Rapid 2 K

Condition: used, Year of construction: 1980, spindle diameter 130 mm x-travel 7700 mm y-travel 1500 mm Control Siemens type Sinumerik 840 C spindle taper ISO 130 turning speeds 1490 U/min power capacity 45 kW Plate area 9000x6000 mm workpiece weight 100 t Überholt 2007 Panel is optional and we charged extra The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. Tsdpfoyt Rzqsx Apdsd We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Year of construction: 2002, Ref. -No.: 10633 Manufacturer: ANAYAK Type: VH Plus 2000-MG Year of construction: 2002 Type of control: CNC-Steuerung Control: Heidenhain Storage location: Halberstadt Country of origin: Germany serial number: M200XXX X-Travel: 2000 mm Y-Travel: 1500 mm Tsdpfx Aezc D Enspdod Z-Travel: 1500 mm No. Of Working Stations: 90 Control: 106.253 H machine: 93.170 H Program run: 41.859 H Head and turntable: 1600 x 1450 mm

Condition: good (used), functionality: fully functional, Year of construction: 1998, control type: NC control, degree of automation: semi-automatic, actuation type: hydraulic, controller manufacturer: Siemens, controller model: Simatic OP7, number of rollers: 4, roller (bottom) diameter: 470 mm, roller (top) diameter: 530 mm, side roll diameter: 400 mm, roller diameter: 530 mm, roller length: 3,100 mm, working width: 3,000 mm, working height: 2,000 mm, sheet thickness (max.): 50 mm, sheet thickness steel (max.): 65 mm, sheet thickness stainless steel (max.): 50 mm, overall weight: 40,000 kg, total length: 6,000 mm, total width: 2,900 mm, total height: 2,900 mm, power: 55 kW (74.78 HP), input voltage: 380 V, input frequency: 50 Hz, number of digital displays: 4, Equipment: cone bending device, documentation/manual, emergency stop, hardened rollers, swiveling upper roller, plate bending roll capacity 3000x50 mm Davi modelMCB3053 Hydraulic 4 roll plate bending machine, year 1998 plate width 3000 mm thickness rolling 50 mm pre-bending 40 mm width on the rolls 3100 mm upper roll size 530 mm Tjdpey D Ngzjfx Apdod lower roll 470 mm side rolls 400 mm Power electric 70Hp on hydraulic unit voltage 380/50 - Installed configuration Hardened surface of the 4 rolls conical bending attachment – hardened cone bending Console electric with digital position readout of the rolls Controller Siemens Simatic OP7 NC programmer for automatic rolling Hydraulic power driven the central rolls with axial gearbox Pre-pinch pressure adjustable plate edge pre-bend. Drop-end open front for unloading closed shells Rerolling system for calibration roundness of welded shells. Safety and emergency system installed. Manuals original for operation and maintenance Dimension 6000x2900 x h 2900 mm weight 40000 kg

Condition: good (used), total height: 2,500 mm, total length: 5,300 mm, total width: 2,500 mm, feed length X-axis: 1,550 mm, feed length Y-axis: 600 mm, grinding height: 800 mm, overall weight: 7,800 kg, GER RS 15/60 grinding machine Table 1500 x 600 mm X-axis travel 1550 mm Y-axis travel 600 mm Maximum grinding height 800 mm Wheel size 400 x 100 mm Tedpfx Apevli H Sjded Automatic infeed Yes Dovetail accessory Yes Cooling system Yes Machine dimensions (width x length x height) 2500 x 5300 x 2500 Weight 7800 kg

Condition: good (used), Year of construction: 2023, functionality: fully functional, DMG Mori M2 Pro, Year of manufacture 2023 / Commissioned in 2024, Siemens Sinumerik ONE control system, Travel range X/Y/Z 1100/550/510 mm, Table size 1400 x 600 mm, 24-position tool changer, Linear axis speeds X/Y/Z 24 m/min, Tool holder SK 40, Spindle speed up to 12,000 rpm, Chip conveyor, Renishaw probing system kit, Coolant spray gun, Enclosure roof, Internal high-pressure cooling 20 bar, Tjdpfxjza Apao Apdjd Bed flushing via M-function, Job Shop package for SIEMENS SINUMERIK ONE, Mechanical preparation for oil mist separator Ø 150 mm, 4th axis package, LEHMANN rotary table EA-520.L, with automatic spindle clamping, Center height: 180 mm, Compact and stable tailstock with large roller bearing, Prepared for automatic clamping, Permissible hydraulic pressure max. 220 bar, Steel clamping bridge L/W 600/270 mm, Base plate steel, Tropical package, Active cooling unit for control cabinet, Blow-off air externally and internally (through spindle center) can be activated via M-function, External electronic handwheel, Software option - DXF import, Machine with 2100 spindle hours.

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 13,000 mm, travel distance Y-axis: 5,000 mm, travel distance Z-axis: 1,200 mm, spindle speed (max.): 2,500 rpm, position of the milling head: Testa ad assi ortogonali indexati - TTL2 25 360, spindle diameter: 180 mm, travel distance W-axis: 1,000 mm, table load: 100,000 kg, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, table length: 3,000 mm, table width: 3,500 mm, quill travel distance: 2,500 mm, quill diameter: 180 mm, spindle stroke: 1,000 mm, workpiece weight (max.): 100,000 kg, torque: 9,050 Nm, CNC BORING MACHINE PAMA mod. SPEEDRAM 2000 Hydrostatic CNC Control: Siemens Sinumerik 840D Axis X: 13,000 mm Axis Y: 5,000 mm Axis Z: 1,200 mm Axis W: 1,000 mm Total axial travel (Z+W): 2,200 mm Working feed on all axes: 8,000 mm/min Rapid traverse on all axes: 20,000 mm/min Spindle: Boring spindle diameter: 180 mm Spindle carrier ram dimensions: 400 x 440 mm Spindle speed (3 ranges) max: 2,500 rpm Spindle power (S1): 91 kW Spindle nominal torque (S1): 9,050 Nm Spindle internal taper: ISO 50 DIN 69871 AD-Type Big Plus Orthogonal axis indexed head – TTL2 25 360 Tool taper: ISO 50 DIN 69871/2 AD-Type Big Plus Max spindle power: 25 kW Max spindle speed: 2,500 rpm Speed ratio: 1:1 Spindle indexing: +/- 100°, 200 positions per 1° Head indexing: +/-180°, 360 positions per 1° Max spindle nominal torque: 1,000 Nm TH 100 rotary-travelling table: Table dimensions: 3,000 x 3,500 mm Table load capacity: 100 Ton Central T-slot size: 36h7 mm Lateral T-slot size: 36h12 mm T-slot pitch: 320 mm Tsdpfx Apeyxg Hbjded Longitudinal travel V-axis: 2,500 mm Feed/rapid traverse V-axis: 10,000 mm/min Chain-type tool magazine with 80 tools (capacity CU 145 R80) Machine weight approx. 160/165 Ton Complete with: - Hinged belt chip conveyor - No. 02 side chip conveyors for rotary table - Fixed closed accessory magazine with 2+1 positions - Fixed tool rack (ISO50, 6 positions) - Internal and external tool coolant system, 30 bar - Wireless workpiece probe (Renishaw) USED MACHINE YEAR: 2009

Year of construction: 2010, condition: ready for operation (used), - USED - CNC DOUBLE RAM VERTICAL LATHE MAX ROTATING DIAMETER: 3000 mm MAX TURNING HEIGHT: 800 mm Tjdpfx Apeyyrh Hjded MAX TURNING DIAMETER: 2800 mm SPINDLE: 1-160 rpm; 71-114 kW; 68500 Nm; 2500 mm X-AXIS TRAVEL: -150+1780 mm Z-AXIS TRAVEL: 900 mm RAPID FEEDS X-Z: 8 - 10 m/min TOOL MAGAZINE: BASKET-TYPE ; TYPE CAPTO C5; 24 POS. POS CONTROL UNIT: SIEMENS 840D MAX ADMITTED LOAD: 15000 Kg WEIGHT: 54000 Kg ACCESSORIES: SWARF CONVEYOR ; TOOL SETTER ; AUTOMATIC DOOR ; HEAD COOLING SYSTEM ; TOUCH PROBE ; PORTABLE HANDWHEEL

Condition: good (used), Year of construction: 2007, control 840 D x-axis 2500 mm y-axis 2500 mm z-axis 1700 mm Control system - Siemens Sinumerik 840 D Max. workpiece weight - 6000 kg Spindle diameter - 130 mm Quill stroke - 700 mm Tool holder - ISO 50 DIN 69871 - AD Tjdpfjwzyp Ujx Apdsd Max. torque at the spindle - 1847 Nm Total power requirement - 65 kW Machine weight approx. 45 t Space requirement approx. 10.9 x 9.3 x 5.7 m

Condition: used, Year of construction: 2001, functionality: fully functional, travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,700 mm, feed length X-axis: 5,700 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,700 mm, position of the milling head: Testa birotativa A+B 1° + 3°, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, spindle speed (max.): 4,000 rpm, table length: 7,300 mm, table width: 1,090 mm, spindle motor power: 30 W, Equipment: documentation/manual, rotational speed infinitely variable, - FIDIA C20/H6 numerical control - Electronic handwheel - Operator platform - Spindle cooling system - 24-position tool magazine Todpfozix Rwjx Apdjd - 3 longitudinal tables, 1520 x 1000 x 900 mm - Splash guard enclosure - CE marking

Condition: good (used), Year of construction: 1984, max. wheel diameter 250 mm gear width 275 mm max. module 6 weight of the machine ca. 5,5 t The gear hobbing machine ZFWZ 250 is suitable for the economical production of all hob-processable cylindrical gear types, such a: - spur and helical gear, wormgears and worms, splined shafts, keyed shafts, serrated profiles, chain wheels and ratchet wheels,as well as conical and crowned spur and helical gears. Interchangeable wheels and milling accessories Technical data: - Workpiece diameter (max): 250 mm - Module (max): 6 mm - Axial feed travel (max): 275 mm - Tangential feed travel (max): 100 mm - Tooth helix angle (max): 45 degrees - Milling cutter diameter (max): 145 mm - Milling cutter length (max): 170 mm - Table clamping surface (min): 195 mm - Table clamping surface (max): 470 mm Power Milling cutter speeds - Stepped in 2 ranges: 56 ... 250 rpm - (Standard version): 90 ... 400 rpm - Infinitely variable in 2 ranges: 63 ... 180 rpm - (special version DC motor): 140 ... 400 rpm Tsdpfjv T Nqajx Apdsd Weights - Machine net: approx. 5000 kg - Electrical cabinet: approx. 800 kg - Hydraulic unit + coolant tank + chip transport: approx. 700 kg Overall dimensions (with oil mist filter) - Length: Standard version: 3950 mm DC drive: 3450 mm (or 3350 mm according to table) - Width: 3300 mm - Height: Machine: 1980 mm Machine with DC drive: 2150 mm Electrical cabinet: 2200 mm
