Used Pertici for sale (18)

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, power: 4.4 kW (5.98 HP), cutting height (max.): 6,000 mm, saw blade diameter: 500 mm, tilt adjustment saw blade: 90 °, rotational speed (max.): 2,800 rpm, On sale Pertici saw that is no more required. wo headed automatic saw for cutting aluminium profiles. Saw blade diameter: 500 mm Max cutting lenght: 6000mm Min cutting lenght: cca 330 mm Engine power: two three-phase motors, each one 2,2 kW (summary4,4 kW), 2800 rpm Head tilt: 90-45° Bwsdpeztc Dcsfx Amrsu Year of production : 2016 Price: 9300€ The machine can be seen in Rugvica, Croatia (nearby Zagreb).

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, maximum distance between units: 3.3 m Bjdpszxpr Defx Amrowu two motors, 2.2 kW each blade tilt adjustable cutting angle in the range of -45/+45 degrees maximum blade diameter: 330 mm pneumatic clamping devices blade speed: 3765 rpm CE marking

Condition: ready for operation (used), Year of construction: 2022, This 3-axis PERTICI 600TSE Circular Metal Saw was manufactured in 2022. It features a cutting length of 5100 mm and a saw blade diameter of 600 mm. The machine is equipped with a hydropneumatic feed mechanism and a double-cylinder clamping system for enhanced precision. If you are looking to get high-quality cutting capabilities, consider the PERTICI 600TSE machine we have for sale. Contact us for further details. Bodpfx Ajzzp Nbomrowu - Cutting Length: 5100 mm- Saw Blade Diameter: 600 mm- Controlled Axes: 3 controlled axes (Electronic positioning X-axis, controlled tilting angles)- Cutting Angles: Inward up to 45°, Outward up to 20° (Variable angle range 20° - 135°)- Feed Mechanism: Hydropneumatic cylinder with infinitely variable feed adjustment and rapid return, linear guide rails with recirculating ball bearings- Clamping System: Double-cylinder horizontal clamping system and vertical material clamping system for both heads- Safety System: Local pneumatic drop-down safety guards on both heads- Control Unit / Display: Industrial PC panel with 15" TFT Touchscreen monitor, USB port, Ethernet port (LAN)- Operating System: Windows Embedded- Control Features: Memory capacity up to 1000 profile data, cutting list optimization, online diagnostic assistance

Condition: used, Year of construction: 2017, Motor 3+3kW Blades diameter 400mm Pneumatic pressure 6-7 Bars Oleopneumatic saw descent system Bsdpozwv Hrjfx Amrowu Horizontal and vertical component pushers Total machine length with extension 880cm/110cm +- 600kg Maximum straight cut length 6080mm Minimum length of straight cut 540mm Maximum cutting length with a 45° bevel 6080mm Minimum length of mini cut with 45° incline 500mm Maximum cutting length with head orientation at 45° 6080mm Minimum cutting length with head orientation at 45° 1080mm Automatic lubrication of saw cylinders Cutting lubrication on blades Mobile digital control panel following length to be realized Programmation possible Automatic support spacer for the longest lengths Double command de protection Commissioning documents, control panel user manual and electrical diagrams 400V

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 195, Corner Crimping Machine - Pertici HP 601, year 1995 Hydraulic corner crimping machine designed for the processing of aluminium profiles: Its cast iron and steel construction makes it robust and reliable, ensuring consistent crimping quality over time. The crimping heads are controlled by a single mechanical command, guaranteeing perfect synchronization of movements. Bsdsznkfqspfx Amrjwu The machine is equipped with a hydraulic clamping wedge that ensures maximum profile holding during the crimping operation. The easy adjustment of the knife blocks allows quick and efficient profile changeovers. Kls Dkklsy R S Uujn Tjw Technical specifications: Maximum crimping force: 3500 Kgp Maximum punching height: 120 mm Nominal pressure: 6,5 bar Dimensions (L x H x D): 850 x 1250 x 800 mm Weight: 300 kg

Year of construction: 2018, condition: good (used), functionality: fully functional, 4-axis machining center PERTICI P104 Bsdpfxoyxtbls Amrjwu

Condition: good (used), Year of construction: 2000, functionality: fully functional, input voltage: 400 V, input frequency: 50 Hz, type of input current: three-phase, saw blade diameter: 500 mm, Double mitre saw Pertici 500F2K, Bsdszfmkwjpfx Amrjwu capable of double cuts, saw blade diameter 500 mm, positioning via machine control, horizontal and vertical clamping units, seal holder.

Year of construction: 2022, condition: excellent (used), 5-axis Machining center independent clamp movement 16 positions tool magazine chip conveyor belt (horizontal) 2° chip conveyor belt (vertical) tool lenght probe 10 toolholders HSK 63 UPS 11 kW spindle with liquid cooling 5 axis blade diam 450 mm automatic greasing kit extra blade unit 90° on moveable carriage Bjdpfx Aou A Uq Ismrewu wireless bor code reader

Condition: used, CNC Profile Processing Line, consisting of: 1) 1-Axis CNC Cutting Centre – Pertici SC55, Year 2018 The Pertici SC55 is a 1-axis CNC cutting centre designed for the automatic cutting of PVC profiles. Thanks to its automatic loading system, the machine automatically feeds the bars, performs the cutting operations according to the production list, and unloads the finished workpieces. The Pertici software is compatible with the main optimization and production management programs available on the market. The automatic magazine can accommodate up to 10 bars with a maximum length of 6.6 metres. The cutting area is fully enclosed by protective guards, ensuring maximum operator safety and easy maintenance access. The machine is also equipped with an automatic chip and scrap evacuation system, automatic unloading of finished parts, and a collection table with a capacity of up to 12 workpieces. Main Features 1-axis CNC controlled cutting centre Bjdpozg Eggofx Amrjwu Automatic cutting of PVC profiles Automatic loader for up to 10 bars Maximum bar length: 6,600 mm Automatic bar detection system Compatible with the main optimization and production software Automatic unloading of finished parts Automatic chip and scrap extraction Fully enclosed safety guards with front access Collection table for finished parts Cutting Angles The SC55 automatically performs cuts at: 45° 90° 135° (Intermediate angles available as an option.) Cutting Capacity SC55 (Ø500 mm saw blade) Maximum profile height at 90°: approx. 155 mm Maximum profile height at 45° / 135°: approx. 155 mm Maximum profile width: approximately 160 mm Minimum workable profile width: approx. 25 mm Technical Data Installed power: 6.8 kW Power supply: 380 V three-phase Frequency: 50 Hz Air pressure: 6.5 bar Weight: 1,490 kg 2) CNC Machining Centre – Pertici FC1000, Year 2018 The Pertici FC1000 is a high-productivity CNC machining centre for PVC profile processing. It automatically loads, positions, machines and unloads profiles, ensuring fast and efficient production. Equipped with 7 machining spindles and an automatic screwdriving unit, it performs all machining operations in a single cycle. The machine is controlled by Pertici CNC software, compatible with the main production management systems, and features an automatic magazine for up to 10 bars with a maximum length of 6,100 mm, processing profiles from 35 to 130 mm wide. Main Features 7 machining spindles Integrated automatic screwdriving unit Automatic magazine for up to 10 bars Fully automatic loading and unloading Pertici CNC software Automatic profile handling and positioning system Heavy-duty industrial frame Soundproof safety enclosure Technical Data Installed power: 6.8 kW Power supply: 380 V three-phase Frequency: 50 Hz Air pressure: 6.5 bar Weight: 1,490 kg Maximum bar length: 6,100 mm Profile width: 35–130 mm Available for immediate delivery from October 2026.

Condition: used, Double-Head Mitre Saw for Aluminium Profiles – Pertici Univer 403 P Main Features Double-head mitre saw for aluminium profiles Numerical control for managing cutting dimensions Cutting heads with rotation and tilting functions Automatic positioning of the movable head Pneumatic profile clamping system Suitable for aluminium window and door manufacturing Maximum cutting length: 3,200 / 3,300 mm Technical Data Blade diameter: Ø 400 mm Blade bore: Ø 30 mm Blade speed: 3,180 rpm Installed power: 3.1 kW Power supply: 380 V three-phase – 50 Hz Current consumption: 6.2 A Operating pressure: 6.3 bar Air consumption: 13.9 Nl/cycle Weight: 370 kg Applications Aluminium window and door manufacturing Bsdpfx Amjzb Ehnerowu Doors and windows Curtain wall systems Light metal fabrication and construction work

Condition: reconditioned (used), functionality: fully functional, Profile cutting center Scarabeo 55 CNC cutting center with 1 controlled axis, designed to cut PVC profiles with the highest cutting speed and quality. It consists of four different components connected in an automatic line: 1. Automatic bar stock magazine - steel body with 6 grippers moved by belts, driven by electric motors - max. capacity 8-10 profiles (depending on their width) - equipped with a bar presence detection device 2. Automatic Profile Feeding Unit 3. Automatic cutting unit - ø 500 mm blade - electromotor 3 kW, 2,800 RPM - cuts at three main angles: 45° – 90° – 135° - special centering device which allows the blade center of rotation to be positioned in the center of the profile section, so that wedge cuts can also be made automatically - equipped with a special evacuation system for waste and cutting chips - fully enclosed with a front door for free access to the cutting area for calibration, cleaning, and maintenance purposes - pneumatic pistol for blowing chips 4. Automatic unloading unit - automatic discharge device with pneumatic control - flat table for storing cut profiles Bjdpfx Ajrungaemrswu - safety guard for moving parts Power: 7.2 kW Weight: 1,500 kg - Industrial computer - TFT color LCD screen - Keyboard - data retrieval from the keyboard or ON-LINE - control of each function on the monitor - Virtually unlimited number of data on the profiles to be cut - label printer with choice of format and letter size - collection of data on the remains of cut profiles (waste) - the ability to collect statistical data (weekly and monthly report) - Automatic fault diagnosis Sizes: width: 2300 mm, length: 12500 mm Completely refurbished, 6 months warranty on parts. Ready for work Available for viewing at the company's headquarters.

Condition: new, Year of construction: 2020, End Milling Machine – Pertici ML200A - Brand new – Year 2020 The ML200 by Pertici Industries is an automatic vertical-axis end milling machine designed for processing aluminium and PVC profiles. The machine allows machining operations with angles from 90° to 22.5° and from 90° to 157.5°, ensuring precision and reliability during end milling operations. Bwodpfxey N S Ule Amrou Heavy-duty electro-welded steel structure with high-rigidity cast iron bench, complete with sliding milling unit on precision-ground guide rods. Equipped with: Quick pneumatic cutter change system Lubrication system 5 pneumatic clamping cylinders Three-phase motor 1.4 / 1.9 kW – 1400 / 2800 rpm Oil-pneumatic feed system for the milling unit Adjustable feed speed Profile support with vertical and horizontal clamps Anti-vibration feet User and maintenance manual Ideal machine for professional aluminium and PVC window and door manufacturing. Technical specifications: Motor power: 1.4 / 1.9 kW Power supply: 400V – 50Hz – Three-phase Motor speed: 6700 / 3350 rpm Maximum tool diameter: Ø 250 mm Tool bore: Ø 32 mm Maximum profile height: 130 mm Maximum profile width: 350 mm Maximum machining height: 145 mm Required air pressure: 6 – 7 bar Air consumption: 30 L/min Machine dimensions: Length (a): 1020 mm Height (b): 1700 mm Depth (c): 1410 mm Weight: 310 kg

Condition: new, Year of construction: 2024, Corner Crimping Machine - Pertici HP 601, year 2024 - BRAND NEW Hydraulic corner crimping machine designed for the processing of aluminium profiles: Its cast iron and steel construction makes it robust and reliable, ensuring consistent crimping quality over time. The crimping heads are controlled by a single mechanical command, guaranteeing perfect synchronization of movements. The machine is equipped with a hydraulic clamping wedge that ensures maximum profile holding during the crimping operation. The easy adjustment of the knife blocks allows quick and efficient profile changeovers. Technical specifications: Maximum crimping force: 3500 Kgp Maximum punching height: 120 mm Nominal pressure: 7 bar Dimensions (L x H x D): 850 x 1250 x 800 mm Weight: 300 kg Bwsdpfey R S Uusx Amrou

Condition: used, Year of construction: 1996, machine/vehicle number: 96T233, SECOND-HAND DOUBLE SIDED CUTTING SAW PERTICI TYPE UNIVER 330IP - CE RULES Bodpfx Aoqmpl Ajmrjwu - Working length 3300 mm - Tilting blades 45° - N. 2 motors 1.1 kw - Blade diam. 330 mm - V. 380/50 - S/N 96T233 - Year 1996

Condition: used, Year of construction: 1999, machine/vehicle number: 99T318, SECOND-HAND DOUBLE SIDED CUTTING SAW PERTICI TYPE UNIVER 330IP - CE RULES - Working length 3300 mm - 4.5 kw - Blade diam. 330 mm - V. 380/50 - S/N 99T318 - Year 1999 Bwedjqmpnajpfx Amrju

Condition: excellent (used), Double miter saw Pertici Haffner DGS180 Cutting length: 3300 mm Cutting width: 140 mm Two adjustable cutting angles Maximum saw blade diameter: 330 mm Bedpfx Amjxg Hanerowu Pneumatic material clamps 3 operating modes

Condition: new, CNC double-head mitre saw equipped with Ø 600 mm saw blades, designed for precise and automated cutting of profiles. The machine features a robust electro-welded steel base and consists of one fixed cutting unit and one mobile cutting unit with electronic positioning along the X-axis. Both cutting heads are equipped with controlled rotary axes (RF and RM), allowing automatic positioning of the cutting units at angles ranging from 45° inward to 20° outward. The saw blades are operated by hydro-pneumatic cylinders, with adjustable feed speed and rapid return. Main features: CNC double-head mitre saw Ø 600 mm saw blades One fixed and one mobile cutting unit Electronic positioning of the mobile unit – X-axis Controlled rotation of both cutting heads – RF and RM axes Cutting angle range: 45° inward to 20° outward Hydro-pneumatic blade feed Adjustable blade feed speed Rapid blade return Horizontal clamping system with double cylinders Vertical profile clamping system Pneumatically operated safety guards for the cutting areas 15” touch-screen monitor Windows 10 platform Programming and management of cutting operations via touch-screen interface Provision for an industrial label printer for workpiece identification and association with the corresponding production order Bwsdpfxeztb Hpj Amrsu The machine is designed to provide precision, productivity and ease of operation, and can be easily integrated into the production process.

Condition: new, Tilting Transfer Table Bwsdpfxoy A Imds Amrou Brand: Pertici Model: BF TEA 20-14 Tilting and extendable assembly table for the production of sashes and frames. Complete with pneumatic retractable roller conveyor. Work surface with profiles equipped with anti-scratch gasket. Dimensions: Minimum width: 2,000 mm Maximum width: 3,900 mm Minimum depth: 1,374 mm Maximum depth: 2,400 mm Working height: 932 mm
