Used Okuma Engine Lathe for sale (167)

Year of construction: 2005, condition: ready for operation (used), A CNC 4-axis lathe Okuma including a conventional external cylindrical grinding machine TOS BUAJ 28 is available. 1) Lathe, year of manufacture: 2005, turret: 2-disc turret, tool positions: 12/8, tool holder: VDI40, speed: 3800rpm, turning diameter: 370mm/530mm, turning length: 600mm, machine dimensions X/Y/Z: approx. 4000mm/2300mm/2200mm, weight: approx. 6800kg, control: Okuma OST E100L. Includes clamping device design, part catcher, part conveyor, and chip conveyor. Without tailstock, bar loader, spindle reduction, and VDI holders. 2) TOS, year of manufacture: 1988, max. grinding diameter: 280mm, center height: 140mm, distance between centers: 630mm, max. workpiece weight: 120kg, headstock: MT4, workpiece spindle swivel range: +/-90°, grinding head swivel range: +/-45°, grinding wheel dimensions X/Y/Z: 400mm/40mm/127mm, speed: 2560rpm, feed rate: 7m/min. Machine dimensions X/Y/Z: approx. 2000mm/1500mm/1500mm, weight: approx. 2000kg. Includes accessories and grinding wheels. Documentation available. An on-site inspection is possible. Itsdpew Rqwyofx Afion

Condition: used, max. 800 mm turning length max. 800 mm chuck ohne documentation inkl. Itjdsh D Anaspfx Afion weight of the machine ca. 8 t

Condition: used, Year of construction: 2017, operating hours: 33,500 h, functionality: fully functional, machine/vehicle number: W6212-T63-280, We have a CNC lathe for sale, brand Okuma-Genos, which is ready for operation. The machine is fully functional and has been regularly maintained and serviced. - Y-axis Itodpfow Np Uhex Afien - Main and sub spindle - Tool probe - Parts catcher Spindle speed: 3800 rpm Spindle operating hours: 20,503 h A detailed description of the machine is included in the attachment. Technical condition: Good. The machine has been in our facility since new, purchased in 2017 and commissioned in the first quarter of 2018. The lathe is connected to power and currently in operation. Viewing and functional inspection possible under power in our workshop. Reason for sale: ongoing changes in our projects. Optionally, an LNS bar feeder may be purchased for €7,000 and an oil mist separator for €1,500 (both visible in the pictures).

Condition: ready for operation (used), Year of construction: 2005, operating hours: 23,082 h, functionality: fully functional, machine/vehicle number: 114599, turning length: 541 mm, turning diameter: 210 mm, travel distance X-axis: 192 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 700 mm, TECHNICAL DETAILS Machining specifications Turning length: 541 mm Turning diameter: 210 mm Axes and travels X-axis travel: 192 mm Y-axis travel: 50 mm Z-axis travel: 700 mm Spindle Spindle speed: 6,000 rpm Spindle motor power: 11 kW Feed Ijdpfxow Ekruj Afijtn X-axis feed rate: 30 m/min Z-axis feed rate: 40 m/min MACHINE DETAILS Electrical data Supply voltage: 400 V Phases: 3 P Frequency: 50 Hz Operating hours On time: 92,265 h Spindle hours: 23,082 h Total weight: 8,000 kg EQUIPMENT Documentation/manual Chip conveyor Note: The machine will remain powered until the end of the auction, after which it will be dismantled.

Condition: good (used), travel distance X-axis: 798 mm, travel distance Z-axis: 358 mm, Chip conveyor  SMW Front and Rear chuck 700 mm  Double revolver 6+8 positions Big Bore 360 mm Tailstock with power quill Tooling package included with inserts and jaws Max. turning Ø:665mm Itjdpewxb Erjfx Afien X-Axis: 798mm Z-Axis: 358mm Spindle bore: 360mm Speedrange: 500Rpm Spindle power: 45kW Pinole taper: 6Mk Stroke pinole: 230mm Quill Ø: 150mm Length: 8100mm Width: 275mm Height: 2100mm Weight: 13000kg

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, Reference: LT-2501 Manufacturer: Okuma Model: LB4000EX-MC x 750 CNC Control: Okuma OSP-P200L Year of Manufacture: 2007 Keyboard/Software Language: International / Spanish Country of Origin: Japan Technical Specifications: Capacity: Maximum swing over bed: Ø 670 mm Maximum swing over carriage: Ø 480 mm Distance between centers: 770 mm Maximum turning diameter: Ø 430 mm Maximum turning length: 750 mm Maximum bar capacity: Ø 90 mm (requires modification) Main Spindle: Spindle diameter: Ø 160 mm Spindle nose (type): JIS A2-11 Spindle bore: Ø 112 mm Speed ranges: 2, infinitely variable Spindle speed: 30 – 3,000 rpm Motor: 37 / 30 kW (30 min / continuous) Motor type: PREX Motor Tailstock: Rotating center: MT 5 Travel (W axis): 780 mm Rapid traverse: 12,000 mm/min Maximum thrust: 7,500 N Z Axis: Travel: 840 mm Cutting feedrate: 0.001 – 1,000.00 mm/rev Rapid traverse: 30,000 mm/min X Axis: Travel: 300 mm Cutting feedrate: 0.001 – 1,000.00 mm/rev Rapid traverse: 25,000 mm/min Itsdpew Dvb Sefx Afien C Axis: Controlled angle: 360° (0.001° increment) Turret: Type: M-V12 NC Number of tool stations: 12 x BMT40 (L or M) Indexing speed: 0.2 sec/position Tool Dimensions: External turning: 25 x 25 mm Internal turning: Ø 40 mm Driven Tool: Speed: 45 – 6,000 rpm Number of speed ranges: 1, infinitely variable Motor: 7.5 / 4.3 kW (25 min / continuous) Motor type: PREX Motor Dimensions and Weight: Machine height: 1,955 mm Floor space required: 3,050 x 1,900 mm Machine weight: 6,300 kg Included Options: SCHUNK ROTA THW plus 315-104 quick-change chuck (3 jaws, Ø 315 mm) CROMAR chip conveyor Assisted programming (ONE Touch IGF Advanced) Rigid tapping DNC-T1

Condition: ready for operation (used), Year of construction: 2005, operating hours: 36,000 h, functionality: fully functional, CNC Turning Machine Okuma LU300-2ST 350 Year of manufacture: 2005 - Control: Okuma OSP E100L - Clamping system: Chuck SK65 - 2 disc turrets with VDI40 (12 + 8 stations) - Parts catcher with conveyor belt - Chip conveyor Iedpfxsw Darbo Afistn Without tailstock Without bar feeder Without spindle reduction Without VDI tool holders Machine weight: 6.8 t

Condition: repair required (used), turning length: 400 mm, spindle bore: 75 mm, spindle speed (max.): 3,800 rpm, General information about the machine We are offering a used lathe from the manufacturer Okuma. The machine is offered as a spare parts carrier. The machine is running but not all functions can be guaranteed. The keys for operation are missing. The machine is in our warehouse and can be inspected under power Technical data Isdpfx Asugmzksfietn - CNC control: OSP 5000L-G CNC system (German) - Tool turret: 12 positions - Lathe chuck: 250 mm - Spindle: 70-3800 rpm (11 kW, 30 min; 7.5 kW - continuous operation) - Spindle bore diameter: 75 mm - X-axis travel: 400 x 0.001 mm - Z-axis travel: 500 x 0.001 mm - Cutting speed XZ: 0.01-1000 mm / U - Rapid traverse up to: 12,000 mm / min. - Power supply: 380V - Rated power of the machine: 21 kVA - Maximum load current: 36A - Machine dimensions (width x depth x height): 3.9 m (with chip conveyor) x 1.8 x 1.8 m - Machine weight: 4500 kg

Condition: used, Year of construction: 2017, operating hours: 34,000 h, functionality: fully functional, machine/vehicle number: W6212-T63-280, We have an Okuma Genos CNC lathe for sale, fully operational and immediately ready for work. The machine is in excellent working order, regularly maintained and serviced. - Main spindle and sub-spindle - Tool probe - Parts catcher Itedpfxew Np S He Afisn Spindle speed: 3,800 rpm Technical condition: Good. The machine was purchased new for our facility in 2017 and commissioned in the first quarter of 2018. The lathe is connected to power and currently in operation. It is possible to inspect and test the machine under working conditions at our site. The decision to sell is due to changes in our projects. Optionally, an LNS bar feeder is available for €10,000 and an oil mist separator for €1,500 (both visible in the photos).

Condition: used, Year of construction: 1996, functionality: fully functional, travel distance X-axis: 260 mm, travel distance Z-axis: 1,020 mm, spindle motor power: 15 W, rapid traverse X-axis: 15,000 m/min, rapid traverse Z-axis: 20,000 m/min, OKUMA LB15II-MW CNC Turning Center The OKUMA LB15II-MW is a dual-spindle CNC turning center with a driven tool turret, designed to ensure high precision, flexible productivity, and complete machining in a single setup. Perfect for complex turning operations and series production. General data: Year of manufacture: 1996 CNC control: OKUMA OSP7000L Machine weight: 5,900 kg Dimensions (LxWxH): 3,315 x 1,895 x 1,905 mm Machining capacity: Max swing over bed: Ø530 mm Max turning diameter over cross slide: Ø340 mm Max turning length: 1,000 mm Distance between centers: 1,020 mm Spindle bar capacity: Ø62 mm Axes and travels: X axis: 260 mm Z axis: 1,020 mm C axis: 0.001° (full 360° continuous control) Spindles: Main Spindle: Speed: 45 – 4,500 rpm Spindle nose: ASA A2-6 Power: 11/15 kW (cont. 20/30 min) Sub-Spindle: Speed: 45 – 4,500 rpm Iodowxypijpfx Afietn Spindle nose: ASA A2-5 Power: 7.5/11 kW Turret: 12 stations (powered tool positions available) Tool dimensions: 25 x 25 mm / Ø40 mm boring bars Powered tool speed: 3,000 rpm Included tooling: 17 fixed tools (10 boring bar holders + 7 external turning holders) 6 powered tools (3 angle heads + 2 double axial + 1 single axial) Feed rates: X-axis rapid traverse: 15,000 mm/min Z-axis rapid traverse: 20,000 mm/min Equipment and accessories: LNS MOVE bar feeder, capacity up to 3,200 mm Mayfran chip conveyor Coolant tank with wash-down pump High-pressure pump with integrated tank Tool presetting arm Manuals, electrical diagrams, and CE declaration A complete and compact solution, ideal for bar machining and secondary operations on the sub-spindle. The presence of the driven tool turret enables complex processes in a single cycle, reducing both machining and setup times.

Condition: good (used), Year of construction: 2007, turning length: 1,065 mm, turning diameter: 470 mm, Chip conveyor SMW 315 3 chuck 2 x Radial live tooling holders 2 x Axial live tooling holders Spindle bore 80 mm BMT-Tooling system Tool measuring probe Spindle hours 6960 / 6270 Running hours Max. turning Ø: 470mm X-Axis: 260mm Z-Axis: 1065mm Spindle bore: 80mm Speedrange: 4200Rpm Spindle power: 30kW ATC / revolver: 12 BMT Tool system Speed live tools:6000Rpm Power live tools:7,1kW Length: 3310mm Width: 1900mm Height: 1970mm Itodpfxswq Rpwj Afisn Weight: 6100kg

Condition: good (used), Year of construction: 2018, operating hours: 6,177 h, functionality: fully functional, machine/vehicle number: L3M0060, turning length: 450 mm, turning diameter: 300 mm, rotational speed (max.): 4,500 rpm, bar diameter (max.): 69 mm, TECHNICAL DETAILS Max. turning diameter: 300 mm Max. swing diameter: 520 mm Max. turning length: 450 mm Itedpfeww Ikxox Afion Main spindle Bar capacity: 69 mm Spindle nose: ASA8 Spindle motor power: 22 kW Spindle speed: 20 / 42 m/min Spindle chuck diameter: 10″ Driven tools Power: 7 kW Speed: 4,500 rpm Tailstock Tailstock taper: MT5, rotating MACHINE DETAILS Power-on time: 8,666 h Spindle hours: 6,167 h CNC control: CNC OSP P300LA-e (15″) Weight: 5,000 kg Connected load: 28.6 kVA Total power-on time: 16,620 h CNC control operation time: 8,667 h Spindle run time: 6,177 h Cutting time: 6,004 h EQUIPMENT - Manual presetting device - Roller-type chip conveyor - Rotating MT5 tailstock - High-speed driven tools - CNC control with large 15″ screen

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, turning diameter over cross slide: 500 mm, turning length: 1,630 mm, turning diameter: 500 mm, spindle bore: 62 mm, spindle speed (max.): 4,500 rpm, spindle speed (min.): 45 rpm, travel distance X-axis: 430 mm, travel distance Y-axis: 190 mm, travel distance Z-axis: 1,474 mm, spindle motor power: 22,000 W, rapid traverse X-axis: 25 m/min, rapid traverse Y-axis: 12 m/min, rapid traverse Z-axis: 20 m/min, total height: 23,000 mm, total length: 54,050 mm, total width: 28,880 mm, Equipment: documentation/manual, Okuma MacTurn 30 - 1500 OSP U100L CNC-Controller Ijdpfx Afsrdvhhoistn Number of axis - 5 +2 Swing over bed - Ø500mm Swing over carriage - Ø500mm Max dia. turning - Ø500 mm Max turning length - 1474 mm X axis Upper travel - 430 mm X axis Lower travel - 140 mm Z axis Upper travel - 1474 mm Z axis Lower travel - 1305 mm Y axis travel - 190 mm (+95/-95mm) W axis travel - 1305 mm C axis 360° (0.001 increment) Rapid travers Upper X-axis 20,000 mm/min Lower X-axis 15,000 mm/min Upper Z-axis 25,000 mm/min Lower Z-axis 20,000 mm/min Y -axis 12,000 mm/min C-axis 200 rpm Spindle nose - JIS A2-6 Main spindle speed - 45-4500 rpm Sub spindle speed - 45-4500 rpm Main spindle power - 15 kW Sub spindle power - 15 kW Main spindle diameter - Ø100 mm Sub spindle diameter - Ø100 mm Main spindle boring - Ø62 mm Sub spindle boring - Ø62 mm Rotary tool spindle - 6000rpm Rotary tool spindle - 6,8kW ATC Magazine - BT40 Tool storage capacity - 40 tool Max tool dia. - Ø110 mm Max. tool lenght 300 mm Max. tool mass - 10 kg Chip conveyor type high Wight - 12100kg

Condition: good (used), Year of construction: 1997, Technically in good condition and functional. Year of manufacture 1997. Max. turning diameter 250 mm. Max. diameter over bed 530 mm. Max. turning length 500 mm. Isdjwn Dbnepfx Afijtn Length x Width x Height approx. 3315 mm, 1895 mm, 1900 mm. Machine weight approx. 6 tons.

Condition: not inspected (used), Seriennummer: 0697 Itjdewm Rrqjpfx Afisn

Condition: excellent (used), Okuma lc40 spindle stock Isdpfx Ajwqgb Njfistn

Condition: good (used), Year of construction: 1998, functionality: fully functional, Controller OSP700L Swing dia 300 mm Turning dia 170 mm Between centers 340 mm X travel 150 mm Z travel 350 mm C axis 360/0,001 degree Spindle hole D42 mm Chuck dia 200 mm Turret 12-fold Tool holder type VDI30 Spindle speed 50 - 6000 rpm Spindle power 5,5/7,5 kW Power required 400V, 15 kVA Weight 3500 kg Dimensions LxWxH = 2300 x 1635 x 1850 mm Ijdpevmzc Uefx Afiotn Accessories - C axis and live tool turret - Hydraulic tailstock - Coolant unit - Chip conveyor - Hydraulic 3 jaws, D160 mm chuck - Machine light Good condition, still under power.

Condition: excellent (used), Year of construction: 2019, operating hours: 2,044 h, functionality: fully functional, machine/vehicle number: 223697, turning length: 950 mm, turning diameter: 340 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 1,010 mm, rotational speed (max.): 5,000 rpm, Machine with Big-Bore Spindle TECHNICAL DETAILS Spindle speed: 45 to 4,200 rpm Spindle motor: 30/22 kW Spindle mount: JIS A2-8 Spindle bore: ø91 mm Axes and Travel Turning length: 950 mm Turning diameter: 340 mm C-axis control: 360° at 0.001° increments X-axis travel: 260 mm Y-axis travel: 120 mm; +70 mm / −50 mm Z-axis travel: 1,010 mm Tool Turret Turret type: V12, radial, for L and M tools Tool holder mount: VDI Speed: 45 to 6,000 rpm Rotary tool motor: VAC 7.1/4.1 kW Control CNC control: OSP-P300LA with 15" touch panel Pitch error compensation: X-/Y-/Z-axes Workpiece ejection detection: available Smart Interface: included API Library 2: activated Virus Protection System - OSP-VPS: available Software Functions One Touch IGF Advanced M-E Kit: standard Optional IGF Advanced M-D Kit: available Multitasking coordinate conversion: available Profile generation: available Cycle time inspection and reduction: available Hi-Cut Pro: available Load monitoring, spindle & feed axes: available NC operation monitoring: available Spindle speed control: variable Y-axis turning: available Helical milling for MY machine: X/Y surface, Y/Z surface Cooling and Lubrication Coolant pump: 0.25 kW Coolant tank: L-type, replacing I-type High-pressure coolant pump: 0.8 kW Lubrication monitoring: A-1 incl. hydraulic pressure monitoring Dimensions and Construction CE marking and EMC: available IEC standard compliance: available Power supply CE-compliant: adapted to local standards Guideway extension for steady rests: available TAS-C: available Chip and Coolant Management Chip tray: side extraction Chip conveyor H-type: side, CE-compliant Fully enclosed with coolant protection: available MACHINE DETAILS Height: 2,444 mm Footprint: 3,420 x 2,041 mm Ijdownqdiopfx Afietn Weight: 6,600 kg

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 109566, turning length: 480 mm, turning diameter: 340 mm, spindle speed (max.): 4,500 rpm, spindle diameter: 100 mm, Machine with a large V12 turret for L- or M-sized tools and a hydraulic tailstock. TECHNICAL DETAILS Swivel diameter over bed: 530 mm Swivel diameter over longitudinal slide: 530 mm Swivel diameter over cross slide: 410 mm Number of controllable axes: 4 Turning length: 480 mm Turning diameter: 340 mm Speed: 4,500 rpm Spindle diameter: 100 mm Spindle Spindle diameter: 100 mm Spindle head type: JIS A2-6 Taper bore: Ø70 (2.75) x 1/10 mm Spindle bore: 62 mm Spindle speed: 38 - 4,500 rpm Longitudinal slide (Z-axis) Axis stroke: 500 mm Feed: 0.001 - 1,000 mm/rev Rapid traverse: 25,000 mm/min Cross slide (X-axis) Axis travel: 280 mm [70 + 210] Itodev I Tkaepfx Afisn Feed: 0.001 - 1,000 mm/rev Rapid traverse: 20,000 mm/min Y-axis Axis travel: +70 to -50 mm Feed: 0.001 - 1,000 mm/rev Rapid traverse: 10,000 mm/min Turret Type: V12 Number of tools: 12 (L or M tools) Tool size (external turning tools): 25 x 25 mm Tool size (internal turning tools): 40 mm C-axis Control angle: 360° (increment: 0.001°) Rapid traverse: 200 °/min Tailstock & Motor Tailstock spindle diameter: 90 mm Tailstock spindle stroke: 120 mm Spindle drive motor: 15/11 kW (20 min/continuous operation) Longitudinal slide feed (Z-axis): 6 kW Cross slide feed (X-axis): 4 kW MACHINE DETAILS Machine height: 2,200 mm Floor area: 2,200 x 1,720 mm Weight: 5,200 kg EQUIPMENT - Hydraulic tailstock

Year of construction: 2007, condition: good (used), Make: Okuma Type: LVT-300 M Control: OSP-P200L Year: 2007 X Travel 210 Z Travel 360 Power 22 kW Iedpfx Aoku Aaasfistn Driven live tools 7.5 kw / 3000 Rpm In feed table Out feed table Package jaws Package tool holders Chip conveyor Coolant system 9 Bar Grundfos Specifications Metric US Standard Max. turning Ø 280 mm Table Ø 210 mm Horizontal movement support 360 mm ATC / revolver 12 Speeds / ranges 4000 Rpm C-Axis 360000 ° Dimensions (Estimate) There are no dimensions for this machine (yet). Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: used, Seriennummer: 0419 Itodpfxjwm Rrde Afisn

Condition: good (used), Year of construction: 1993, functionality: fully functional, turning diameter over cross slide: 530 mm, turning length: 850 mm, turning diameter: 450 mm, spindle bore: 80 mm, spindle speed (max.): 3,000 rpm, spindle speed (min.): 10 rpm, travel distance X-axis: 330 mm, travel distance Z-axis: 850 mm, spindle motor power: 30,000 W, total height: 1,800 mm, power: 30 kW (40.79 HP), Equipment: documentation/manual, Okuma LB35 II M, OSP 5020LG, tailstock, touch setter, extraction, coolant pump 8 bar, chip conveyor, in good condition in relation to its age, very few spindle hours and very well maintained. Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, a tour of our showroom (30 Okuma machines) including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage. Iedpfx Aovta H Ejfietn

Year of construction: 2008, condition: good (used), functionality: fully functional, Machine is provided free loaded. TECHNICAL DETAILS turning length over bed / saddle: 670 / 480 turning length: max. 750 mm turning diameter: max. 430 mm Bar diameter: max. 102 mm speed: 42 - 4200 rpm travel X / Z: 300 / 840 mm rapid traverse: 30 / 25 m/min spindle power cont. / 30 min: 30 / 22 kW spindle nose: ASA 11 tool holder: 12 places tool size: 25 x 25 mm / 40 mm tool speed: 45 / 6000 rpm MACHINE DETAILS weight: 6700 kg dimensions: 4500 x 1900 x 2320 mm EQUIPMENT Chip conveyor tool presetting Isdpfxjpgrzce Afijtn automatic door opening high pressure pump. 6 bar drive tools and various static tools (see picture)

Condition: excellent (used), Year of construction: 2010, operating hours: 15,600 h, functionality: fully functional, Spindle speed: 50-6000rpm Movement XA-XB: 205mm Isdjwfr R Eepfx Afijtn ZA-ZB: 700mm W: 730mm YA-YB: 95mm Turrets: 2x 16pos Multitasking V16 Spindlespeed live tools: 45-6000rpm Motors live tools: 5.5/3.7kW Spindle motors: 22/15kW Manufacturing year: 2010.12 Length: 3300mm Width: 2500mm Height: 2500mm Weight: 9000kg Robot interface

Condition: good (used), Year of construction: 2004, functionality: fully functional, turning length: 600 mm, turning diameter: 400 mm, spindle speed (min.): 3,800 rpm, power: 22 kW (29.91 HP), Equipment: documentation/manual, rotational speed infinitely variable, Okuma LU300MY, with E-100L control, A-turret V12 all driven VDI4-40 M-function for milling, B-turret V-8, tailstock, chip conveyor, coolant system 8 bar, MY function Y-axis, touch setter, approx. 15,500 spindle hours, built in 2004, good condition and fully functional, available immediately. Itodpfx Afevta Nyoisn Neff The Okuma specialist and NeffBuy We are also happy to provide you with the all-round carefree package, viewing in our showroom including demonstration and acceptance, loading, transport, assembly and commissioning of the machine as well as instruction and subsequent service. We operate Okuma CNC service throughout Europe, both electronically and mechanically, and on top of that we have a 1200 m2 inventory of all Okuma spare parts, please visit us on our homepage.
