Used Linear Module for sale (6,071)

Condition: ready for operation (used), Year of construction: 2005, operating hours: 18,700 h, controller manufacturer: SIEMENS, controller model: Sinumerik, table load: 3,100 kg, overall weight: 24,500 kg, spindle speed (max.): 12,000 rpm, spindle motor power: 35,000 W, tool weight: 6,000 g, number of axes: 3, This 3-axis DECKEL MAHO DMF 250 linear was manufactured in 2005. It features a robust vertical machining center with a high-speed main drive up to 40 kW and rapid traverse rates of 100 m/min on the X-axis and 60 m/min on Y- and Z-axes. The work table measures 3,100 × 900 mm with a load capacity of 3,100 kg. If you are looking to get high-quality milling capabilities consider the DECKEL MAHO DMF 250 linear machine we have for sale. Contact us for more information. Additional equipment • Safety Equipment: Monitored and locked work area door; Key switch for normal and set-up mode; Limited functions when the door is open Machine Benefits Technical Machine Benefits • Feed speed: up to 20000 mm/min • Clamping surface: 3100 × 900 mm • T-slots: 9 pieces, 100 mm apart • Tool magazine capacity: 30 places • Resolution of measuring system: 0. 001 mm Lodpfex Nr Tuox Ahvshd • Electrical connections: mains connection 3n/pe~400/230 v, 50/60 hz; power consumption 82 kva • Pneumatics: compressed air 5. 5-8 bar; air volume 25 m³/h (without cooling), +20 m³/h with cooling • Weight (kg): with accessories: up to 29280 kg Extra Information Room Temperature: +15°C to +35°C Humidity: 20-75% Tool magazine size 120 -Magazine cabinet -Tool change is performed via a shuttle -Tool holder only on request and subject to availability (extra) -Machine is a 3-axis machine (rotary table not available) A further configuration or the AB is no longer available. Z-axis brake defective, roller shutter in machine room defective, screen cable defective

Condition: ready for operation (used), Year of construction: 2002, controller manufacturer: HEIDENHAIN, number of axes: 3, This 3-axis DECKEL MAHO 64 V linear was manufactured in 2002. It features an SK40 tool holder and a 30-tool automatic tool changer. The machine includes a paper band filter. Note, the probe requires servicing due to a communication error. If you are looking to get high-quality milling capabilities, consider the DECKEL MAHO 64 V linear machine we have for sale. Contact us for more information. • ATC capacity: 30 tools Lodpfox D E Hhjx Ahvohd Additional equipment • Paper band filter (coolant filtration) • Probe (needs service; communication error) Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2002, controller manufacturer: SIEMENS, controller model: 840D Powerline, number of axes: 4, This 4-axis DMG CTX 420 Linear V6 was manufactured in 2002. It features a Siemens 840D Powerline control, VDI 40 tool holder, Y-axis, chip conveyor, and a counter spindle. The machine has been fully overhauled by Eichten Werkzeugmaschinen GmbH, ensuring it is in perfect condition. If you are looking to get high-quality turn-mill capabilities, consider the DMG CTX 420 Linear V6 machine we have for sale. Contact us for more information. Lhedpfx Ahjx D R Hgjvsd Additional equipment • PCU 50 • Y-axis • KSA pump • Hollow clamping cylinder 65 mm • Counter spindle with ejector cylinder • Parts catcher • Discharge conveyor • Sauter star turret with angled tools • Preparation bar loader Machine Benefits Technical Machine Benefits • In the event of sale, some tool holders, including driven tools, would also be sold. Extra Information The machine was completely dismantled, cleaned, checked for all functions, and overhauled by Eichten Werkzeugmaschinen GmbH in December 2023 before it was put into operation. It is therefore technically in perfect condition.

Condition: ready for operation (used), Year of construction: 2013, travel distance X-axis: 630 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 850 mm, controller manufacturer: SIEMENS, controller model: 840 D, table width: 500 mm, table length: 500 mm, spindle speed (max.): 18,000 rpm, spindle motor power: 20,000 W, number of slots in tool magazine: 303, number of axes: 4, This DMG DMC 60H Linear Horizontal Machining center was manufactured in the year 2013 and has 46048 production hours. It is equipped with a Siemens 840 D control unit and has 4 axis. The machine has a spindle speed of 18000 rpm. See original delivery note as PDF (German) attached to see all technical positions. Additional equipment • Scraper belt chip conveyor with coolant system 980 liter, paper belt filter, discharge height 950 mm, width 380 mm, IKZ 80 bar / 14 l/min through spindle center (AD), pressure infinitely programmable, selectable via NC program, Roof flushing of the working area 180 l/min via flushing nozzles with a ripple valve • Rotating viewing window / work area door • Flushing gun with pump • Double gripper • Wheel magazine • NC rotary table Ø 630 mm • 3D path control Machine Benefits Qualitative Machine Benefits Lsdpfxjyi Ekfs Ahvehd • Mcis tdi tool management (module tdi machine) - overview , tool handling, planning • Extraction mechanical and electrical preparation for oil mist extraction • Tool breakage check mechanical design Technical Machine Benefits • Number of pallets: 12 // round pallet storage: rs 12 • Rotary pallet changer // work table with pallet support // permissible load: 600 kg // 2 pallets 500 x 500 mm with t-slots // pallet management // pallet changer cladding // claw flushing pallet • Cooling through the spindle center: 80 bar • Tool magazine: wheel magazine (5 wheels) with 303 magazine slots hsk a63 • Infrared measuring probe renishaw pp60 optical (omp60) hsk-a 63 • Mpc machine protection control (machine protection through rapid shutdown) • Laminated glass safety pane for right-hand cabin door window Extra Information Documentation and Electrical circuit diagram (German) available

Condition: ready for operation (used), Year of construction: 2009, travel distance X-axis: 750 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 520 mm, controller manufacturer: SIEMENS, spindle speed (max.): 24,000 rpm, spindle motor power: 35,000 W, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 70 EVO Linear was manufactured in 2009. It features a working area with X-axis travel of 750 mm, Y-axis travel of 600 mm, and Z-axis travel of 520 mm. The machine is equipped with a high-speed spindle capable of reaching 24,000 rpm and a tool magazine with a capacity of 120 positions. It includes a DMG PH 150 L8 automation. If you are looking to get high-quality machining capabilities, consider the DMG DECKEL MAHO DMU 70 EVO Linear machine we have for sale. Contact us for further details. • Feed rates: linear 20,000 mm/min; rapid traverse 50,000 mm/min • Table: clamping surface 700 × 500 mm • Tool magazine: 120 positions • Through-spindle coolant: high-pressure 40 bar • Documentation: instruction manuals and CE declaration Additional equipment • Coolant tank with paper filter, 600 L • Measuring probe • Chip conveyor • Electronic handwheel (remote) • Pallet changer system DMG PH 150 L8, 8 stations (pallets not included) Technical Specification Lhodpfoymcvmex Ahvod Taper Size HSK 63

Condition: ready for operation (used), Year of construction: 2011, operating hours: 35,000 h, number of axes: 3, This 3-axis CONCEPT LASER M3 Linear was manufactured in 2011. It features a robust power supply with a total consumption of 7.4kW, supporting a laser system, IT, and control voltage components. Essential for operations requiring compressed air and nitrogen, it ensures a steady flow and pressure. Ideal for precision metal 3D printing. Contact us for more information about this machine. Machine Benefits Technical Machine Benefits • Machine connection: cee plug, 400v 32a 6h, 3-meter cable • Compressed air: pressure: 7-8 bar, unlubricated • Flow rate: 130 l/min • Machine connection: coupling plug nw 7. 2, 3-meter fabric hose • Nitrogen n2: pressure: 5 bar, purity: >2. 5 • Flow rate: 100 l/min • Machine connection: hose nipple with sealing cone - 60° cone, 3-meter fabric hose Extra Information Power supply: Supply voltage: 3P/N/PE AC 400V, 10%, 50Hz-60Hz Fuse: 32A Power consumption: Laser system: Max. 34kW IT: 05kW Control voltage: 05kW NC (incl. axes): 10kW Extraction: 12kW Lhsdpfx Ahjx Nh Rcovsd Air conditioning unit: 08kW Total: 74kW

Condition: ready for operation (used), Year of construction: 2004, operating hours: 18,504 h, spindle speed (max.): 4,000 rpm, travel distance X-axis: 550 mm, travel distance Y-axis: 110 mm, overall weight: 20,000 kg, controller manufacturer: SIEMENS, controller model: Sinumerik 840D Powerline, number of axes: 7, This 7-axis DMG Gildemeister GMX 400 linear was manufactured in 2004, featuring a maximum turning diameter of 640 mm and a turning length of 1,585 mm. It includes a Sinumerik 840D Powerline control, a milling spindle with a max speed of 12,000 rpm, and a tool magazine with up to 120 positions. If you are looking to get high-quality turn-mill capabilities, consider the DMG Gildemeister GMX 400 linear machine we have for sale. Contact us for more information. Additional equipment • Oil mist extraction • Coolant tank with belt filter system • Internal coolant system with 80 bar pressure • Approx. 30 tool holders Machine Benefits Technical Machine Benefits • Drive power - main spindle: max. Torque 600 nm • B-axis: +/- 120° • C-axis resolution: 0. 001° and 1° • Maximum turning diameter: 640 mm • Turning length: 1585 mm • Standard turning diameter: 400 mm • Distance between centers of main spindle: max. Bar diameter 90 mm • Chuck diameter: 250 mm (max. 400 mm) • Number of tool positions: 12 positions • Turret tool holder: 40 mm din 69880 Extra Information Ledpfx Ajx D S Dgehvjhd Machine still under power

Condition: ready for operation (used), Year of construction: 2005, operating hours: 42,768 h, controller manufacturer: HEIDENHAIN, spindle speed (max.): 18,000 rpm, number of axes: 5, This 5-axis DMG DECKEL MAHO DMU 50 eVo linear was manufactured in 2005. It features a HEIDENHAIN control, a 40bar IKZ, a 60-tool magazine, and a spindle speed of 18k rpm. The machine includes automation capabilities fully adjustable for different product formats and positioning. If you are looking to get high-quality milling capabilities, consider the DMG DECKEL MAHO DMU 50 eVo linear machine we have for sale. Contact us for more information. • Tool magazine: 60 tools Lodex Rd Hpjpfx Ahvshd • Through-spindle coolant (IKZ): 40 bar • Spindle overhauled in 2024 • B and C axes overhauled in 2024 Additional equipment • Automation (product handling), freely adjustable for product format and positioning • Paper belt filter • Blum laser tool break detection • Extraction system excluded Technical Specification Taper Size SK 40

Condition: ready for operation (used), Year of construction: 2004, operating hours: 31,960 h, controller manufacturer: HEIDENHAIN, number of axes: 2, This 2-axis DMG GILDEMEISTER CTX 320 linear V3 was manufactured in 2004. A versatile turn-mill centre, it offers robust construction and precision for complex machining tasks. If you are looking to get high quality turning and milling capabilities consider the DMG CTX 320 linear V3 machine we have for sale. Contact us for more information. Lhsdpfxjx Nr T Ue Ahvsd Additional equipment • Bar package with a pick-up device and parts conveyor belt • Bar guide for 1.5 metre bars and workpiece stop • Hainbuch SK 65 clamping top • Indicator light for machine's operating status • Cooling unit for air conditioning the control cabinet • OPTIONAL: A basic tool kit / A large selection of Hainbuch SK 65 clamping heads Machine Benefits Technical Machine Benefits • 12-position tool turret with driven tools at all stations Extra Information Machine still under power

Condition: ready for operation (used), Year of construction: 2007, operating hours: 3,395 h, controller manufacturer: SIEMENS, controller model: 840D, number of axes: 3, This 3-axis Gildemeister CTX 620 linear was manufactured in 2007. A horizontal turning machine, it includes tool holders and a tail stock. Consider the opportunity to buy this Gildemeister CTX 620 linear horizontal turning machine. Contact us for more information. Siemens 840D with shopturnSpindle with integrated motorTailstockChip conveyorSpray gunAutomatic doorHollow clamping cylinder SMW 121 mmSMW Autoblok 400 BHD-FL ø 118 hollow Lhedpsx Stlqjfx Ahvsd Additional equipment • Tool holders (as shown in pictures) will follow • Tailstock will follow

Condition: ready for operation (used), Year of construction: 2008, controller manufacturer: HEIDENHAIN, controller model: Plus IT 3D CNC Pilot 4290 plus it, number of axes: 7, This 7-axis DMG GILDEMEISTER GMX 250S Linear was manufactured in 2008. A turn-mill centre featuring the advanced Heidenhain Plus IT 3D CNC Pilot 4290 control unit, it represents the pinnacle of turning and milling capabilities. Contact us for more information. • Control unit: Heidenhain Plus IT 3D CNC Pilot 4290 plus it • 4th axis with tailstock (special feature) Ledpfxeyfv Rbo Ahvohd • Tool magazine with 22 tool positions (optional) • Description: The pinnacle of turning and milling! Additional equipment • Chip tray

Condition: used, Vibrating feeder, vibrating track, vibrating parts feeder, linear vibrating feeder, RNA SLL400-400, Used machine Manufacturer: RNA Type: SLL400-400 Overall dimensions: Width: 675 mm Depth: 690 mm Height: 1600 mm Lhedpfxoyrti Ij Ahvsd Electrical data: 230V; 0.60A; 120VA Hopper size: 500 x 495 mm Vibrating track size: 500 x 100 x 70 mm

Condition: good (used), Lightbus combined input/output module, input/output module, parallel input/output, analog output, input module, Lightbus analog input module -Manufacturer: tac, Input/Output module for DIN rail -Type: TAC Xenta 422 -Input voltage: 24 V DC -Number: 3 modules available -Price: per piece Ledpew Av Atsfx Ahvohd -Dimensions: 110/90/H80 mm -Weight: 0.3 kg/pc.

Condition: used, Linear unit, linear axis, gantry axis with servo drive, synchronous servo motor, electric slide, loading unit, linear guide with servo motor and pneumatic gripper SCHNEIDER ELECTRIC / FESTO type PAS43SBG1800 / BMH1002T07F2A Year of manufacture: 2012 Vertical stroke via Schneider Electric linear axis PAS43SBG1800 Travel distance: 1800 mm Travel per revolution: 20 mm Maximum speed: 1 m/s Drive element: ball screw Lhedpfx Ahow Uc T Ijvjd Guide type: recirculating ball guide size 20 Payload: 60 kg Maximum speed of ball screw: 3000 rpm Motor type: Schneider Electric BMH1002T07F2A Rated voltage: 240 Vrms Rated power: 1.912 kW Rated speed: 3500 rpm Max. current consumption: 29.4 A Horizontal travel: 670 mm via Festo pneumatic cylinder Gripper opening: 600 - 670 mm - Pneumatic gripper on guide carriage - Gripper jaws open pneumatically - Unit is mounted on a welded square tube frame Total weight: approx. 380 kg Overall dimensions (W x H x D): 1280 x 2950 x 1150 mm Very good condition Nearly identical linear unit available under stock number 59700

Condition: used, Linear unit, linear axis, gantry axis with servo drive, synchronous servo motor, electric slide, loading unit, linear guide with servo motor and pneumatic gripper SCHNEIDER ELECTRIC / FESTO Type PAS43SBG1800 / BMH1002T07F2A Year of manufacture 2012 Vertical stroke via linear axis Schneider Electric PAS43SBG1800 Travel distance 1800 mm Travel distance per revolution 20 mm Maximum speed 1 m/s Drive element Ball screw drive Guide type Recirculating ball bearing guide size 20 Payload 60 kg Maximum speed ball screw 3000 rpm Motor type Schneider Electric BMH1002T07F2A Rated voltage 240 Vrms Rated power 1.912 kW Rated speed 3500 rpm Current consumption max. 29.4 A Horizontal travel 670 mm via Festo pneumatic cylinder Gripper opening 600 - 670 mm - Pneumatic gripper on guide carriage - Gripper opens pneumatically - Unit is mounted on welded square tube frame Total weight approx. 380 kg Overall dimensions W x H x D 1280 x 2950 x 1150 mm Very good condition Almost identical linear unit under stock number 59702 Ljdpfx Ajgf Ix Aohvshd

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, spindle speed (max.): 12,000 rpm, feed length X-axis: 400 mm, feed length Y-axis: 400 mm, feed length Z-axis: 250 mm, type of input current: three-phase, rotational speed (max.): 12,000 rpm, grinding spindle speed: 12,000 rpm, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 250 mm, grinding spindle motor power: 10,500 W, power: 10.3 kW (14.00 HP), input current: 30 A, input frequency: 50 Hz, input voltage: 400 V, year of last overhaul: 2024, Equipment: rotational speed infinitely variable, For Sale: 2008 Schütte 305 Linear 5-Axis CNC Tool & Cutter Grinder | Siemens 840D | New Spindle | Medical-Grade Machine Now available at Used Machine Tools Ireland Ltd, this high-precision Schütte 305 Linear 5-Axis CNC Tool and Cutter Grinder (2008) is an exceptional solution for tool regrinding, complex geometry grinding, and high-volume production. Previously in operation at a leading medical device company, this machine has been meticulously maintained, with a brand-new spindle installed in 2024. This grinder is fully equipped with modern tooling support systems including fire suppression, Absolent mist extraction, Ebbco coolant filtration, and in-line chiller, making it production-ready for demanding grinding applications. 🔹 Manufacturer: Alfred H. Schütte 📅 Year of Manufacture: 2008 📍 Location: Ireland ⚙️ Condition: Very Good – Ex-medical device use 🚀 Availability: Immediate 🔧 Spindle: Replaced in 2024 🛠️ Technical Specifications: Machine: Schütte 305 Linear CNC Tool & Cutter Grinder Machine Type: 5 Axis CNC Grinder Model: 305 Linear Year: 2008 Control: Siemens 840D with Windows XP Axes: 5-Axis CNC X-Axis Travel: 400 mm X-Axis with Tailstock: 400 mm Y-Axis Travel: 400 mm Z-Axis Travel: 250 mm Lodpfx Aew Nyc Aehvshd Spindle Motor Power: 14 HP Spindle Speed: Up to 12,000 RPM Software: SIGS – Schütte Integrated Grinding Software Condition: Very good – Ex-medical device industry Spindle Replaced: 2024 (new) ⚙️ Equipped With: 🔥 Fire Suppression Unit 🌫️ Absolent Mist Extraction System 💧 Ebbco Coolant Filtration Unit ❄️ Ebbco In-line Chiller 🧠 Advanced SIGS Grinding Software 🛡️ New Spindle (2024) 💡 Ideal Applications: Tool & cutter regrinding Custom tooling production Precision carbide & HSS grinding Medical, aerospace, and high-specification manufacturing Schütte 305 Linear for sale Used 5-axis CNC tool grinder Tool and cutter grinder Siemens 840D Schütte SIGS software grinder CNC tool regrinding machine Ireland Schütte tool grinder with mist extraction Medical-grade grinding equipment High-performance cutter grinder 5-axis Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, spindle speed (max.): 12,000 rpm, feed length X-axis: 400 mm, feed length Y-axis: 400 mm, feed length Z-axis: 250 mm, type of input current: three-phase, rotational speed (max.): 12,000 rpm, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 250 mm, grinding spindle motor power: 10,500 W, power: 10.3 kW (14.00 HP), input current: 30 A, input frequency: 50 Hz, input voltage: 400 V, grinding wheel speed: 12,000 rpm, year of last overhaul: 2024, Equipment: rotational speed infinitely variable, For Sale: 2008 Schütte 305 Linear 5-Axis CNC Tool & Cutter Grinder | Siemens 840D | New Spindle | Medical-Grade Machine Now available at Used Machine Tools Ireland Ltd, this high-precision Schütte 305 Linear 5-Axis CNC Tool and Cutter Grinder (2008) is an exceptional solution for tool regrinding, complex geometry grinding, and high-volume production. Previously in operation at a leading medical device company, this machine has been meticulously maintained, with a brand-new spindle installed in 2024. This grinder is fully equipped with modern tooling support systems including fire suppression, Absolent mist extraction, Ebbco coolant filtration, and in-line chiller, making it production-ready for demanding grinding applications. 🔹 Manufacturer: Alfred H. Schütte 📅 Year of Manufacture: 2008 📍 Location: Ireland ⚙️ Condition: Very Good – Ex-medical device use 🚀 Availability: Immediate 🔧 Spindle: Replaced in 2024 🛠️ Technical Specifications: Machine: Schütte 305 Linear CNC Tool & Cutter Grinder Machine Type: 5 Axis CNC Grinder Model: 305 Linear Lodsw Nyciepfx Ahvshd Year: 2008 Control: Siemens 840D with Windows XP Axes: 5-Axis CNC X-Axis Travel: 400 mm X-Axis with Tailstock: 400 mm Y-Axis Travel: 400 mm Z-Axis Travel: 250 mm Spindle Motor Power: 14 HP Spindle Speed: Up to 12,000 RPM Software: SIGS – Schütte Integrated Grinding Software Condition: Very good – Ex-medical device industry Spindle Replaced: 2024 (new) ⚙️ Equipped With: 🔥 Fire Suppression Unit 🌫️ Absolent Mist Extraction System 💧 Ebbco Coolant Filtration Unit ❄️ Ebbco In-line Chiller 🧠 Advanced SIGS Grinding Software 🛡️ New Spindle (2024) 💡 Ideal Applications: Tool & cutter regrinding Custom tooling production Precision carbide & HSS grinding Medical, aerospace, and high-specification manufacturing Schütte 305 Linear for sale Used 5-axis CNC tool grinder Tool and cutter grinder Siemens 840D Schütte SIGS software grinder CNC tool regrinding machine Ireland Schütte tool grinder with mist extraction Medical-grade grinding equipment High-performance cutter grinder 5-axis Notes: *Specifications are given in good faith but not guaranteed*

Condition: excellent (used), Year of construction: 2014, operating hours: 68,000 h, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 3,500 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 50 m/min, feed rate Y-axis: 50 m/min, feed rate Z-axis: 30 m/min, spindle speed (max.): 15,000 rpm, rapid traverse X-axis: 50 m/min, rapid traverse Y-axis: 50 m/min, rapid traverse Z-axis: 30 m/min, torque: 167 Nm, overall weight: 35,000 kg, Initial commissioning: December 2014 Control system: Fidia X-axis: approx. 2,200 mm Y-axis: approx. 3,500 mm Z-axis: approx. 1,200 mm A-axis: ± 100° C-axis: ± 275° Machine operating hours: approx. 68,000 h Total spindle hours: approx. 26,500 h Lsdpfx Ahoyrc Akevjhd Clamping table: 2,000 x 3,500 mm with T-slots 2-axis fork milling head Spindle power: 70 kW Spindle speed: max. 15,000 rpm Torque: max. 167 Nm Tool holder: HSK 100A Tool clamping: hydraulic Linear axis drives Feed rate X, Y, and Z axes: up to 50 m/min / 30 m/min Connection data Voltage: 400 V Frequency: 50 Hz Dimensions, weights Required space for machine without peripherals: approx. 8,000 x 6,000 x 5,000 mm Total weight: approx. 35,000 kg Additional equipment - Coolant system - 26-place tool changer - Work area enclosure - Chip conveyor Available at extra charge: - Wireless touch probe - BLUM laser Condition of the machine Fully operational, very good condition. Can be inspected under power.

Condition: good (used), functionality: fully functional, Siemens SINAMICS G120D Power Module 6SL3525-0PE17-5AA1 with Control Unit “Function tested; item comes from the dismantling of a production line of an automotive supplier.” Manufacturer: Siemens Type: SINAMICS G120D Power Module PM250D (6SL3525-0PE17-5AA1) Power: 0.75 kW, 3-phase, 380–500 V AC Rated current: 2.2 A, max. 4.4 A Lhsdjyq Sb Hjpfx Ahvjd Protection class: IP65 (without control unit) Special features: Integrated class-A line filter, capable of energy regeneration, high overload capacity (200% for 3 s, 150% for 60 s, 100% for 300 s) Weight: approx. 5.7 kg Including Control Unit 6SL3544-0FB20-1FA0

Condition: used, Year of construction: 2003, turning diameter max. 246 mm turning length 600 mm control 840 D Powerline Siemens greates pass round over bed 400 mm Swing dia. over traverse guideway 300 mm centre distance 600 mm turning speed range - main spindle max. 6.000 min/-1 power capacity - main spindel 16 kW max. Torque 155 Nm spindle diameter in front bearing 100 mm spindle bore 68,5 mm spindle nose 140H5 Spindle speed range subspindle max. 4.000 min/-1 power capacity - Sub spindle 7,5 kW max. Torque 48 Nm spindle diameter in front bearing 75 mm spindle bore 37 mm spindle nose 140H5 number of toolpositions 12 pos. Ledpfxoypv Tqe Ahvohd Number of driven toolspositions 12 pos. Spindle speed - driven tools max. 5.000 min -1 power capacity - driven tools 3,7 kW max. Torque 24 Nm tool taper VDI 30 Tool dimensions with square shank 20 x 20 mm x-axis 160 mm z-axis 450 mm rapid traverse X: 60 m/min rapid traverse Z: 45 m/min Feed force X: 2,5 kN Feed force Z: 4 kN rapid traverse C: 200 1/min max. Torque C: 155 Nm total power requirement 32 kVA weight of the machine ca. 3,8 t dimensions of the machine ca. 8,0 x 3,0 x 2,7 m CNC - Turning- and MillingCenter GILDEMEISTER - CTX 320 linear V5 - Main- and Subspindle - tool-drive - C-Axis - ShopTurn

Condition: like new (used), Year of construction: 2023, functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 1,000 mm, Equipment: documentation/manual, SEPRO Success 11C (2023) Linear cartesian robot , 1500mm Number of axis: 3 X = 1500 mm Y= 500 mm Z= 1000 mm Payload: 5 kg Euromap 67 More information in photos of this robot, complete manuals available. SEPRO SUCCESS 11 – Technical Data (Summary) Robot type: Success 11 Serial number: R009519 Mechanics 1. Payload: 5 kg 2. Robot weight: 204 kg 3. Robot dimensions: 2430 × 1200 × 1570 mm 4. Max. pneumatic pressure: 7 bar 5. Air consumption: 140 l/min (normal), 260 l/min (peak) Stroke axes X-axis (horizontal stroke): 1. Stroke: 1500 mm 2. Speed: 2.0 m/s 3. Repeatability: ±0.1 mm Y-axis (horizontal take-out): 1. Stroke: 500 mm 2. Speed: 2.0 m/s 3. Repeatability: ±0.1 mm Z-axis (vertical): 1. Stroke: 1000 mm 2. Speed: 3.0 m/s 3. Repeatability: ±0.1 mm Rotations 1. R1 pneumatic rotation: 0–90° 2. R3 pneumatic rotation: 0–180° or 0–90° Control system – Visual 2 Ledpox Dnc Sjfx Ahvshd 1. Weight: 43.5 kg 2. Dimensions: 550 × 400 × 295 mm 3. Power supply: 3×400–480 V ±10% 4. CPU: i.MX537 / Cortex A8 @ 800 MHz 5. Memory: 512 MB DDR + 512 MB Flash 6. SD card: 4 GB 7. I/O: 8. Robot: 16 inputs / 16 outputs 9. Cabinet: 7 inputs / 8 outputs 10. USB ports: 1× Master USB, 1× Slave USB 11. Ethernet 10/100 Pneumatics 1. 2 pneumatic circuits 2. Vacuum and pressure functions available Environmental conditions 1. Operating temperature: +5 to +40 °C 2. Storage temperature: –25 to +55 °C 3. Humidity: 30–95% (non-condensing) 4. Protection rating: IP22 / IK07 Options 1. PC Editor (Windows XP to Windows 7) 2. Conveyor control (3×42V AC to 3×550V AC) 3. Safety kit for access door 4. 1× conveyor

Condition: defective spare-parts repository (used), Year of construction: 2004, Spare parts from Deckel Maho DMF 360 linear for sale. The machine is used exclusively as a spare parts donor. The machine is complete in all components. For example: iTNC 530 control, complete control cabinet, SK50 spindle as new, cooling unit, partition wall, rack wall, SK50 swivel head Hirth (defective), chip conveyor, high-pressure coolant system 80 bar, various other used parts in good condition. Prices on request, plus 19% VAT. Lhodpfx Ahjytx Dmoved

Condition: like new (used), Year of construction: 2018, operating hours: 25,000 h, functionality: fully functional, travel distance X-axis: 2,600 mm, travel distance Y-axis: 1,100 mm, travel distance Z-axis: 900 mm, controller manufacturer: Heidenhain, controller model: iTNC 530, table width: 1,100 mm, table length: 3,200 mm, number of slots in tool magazine: 60, DMG MORI DMF 260/11 LINEAR 5 AXIS MACHINING CENTER (Champion) TECHNICAL SPECIFICATIONS Brand: DMG MORI Model: DMF 260/11 Linear 5 Axis (Champion) CNC: Heidenhain iTNC 530 Table size: 3,200 x 1,100 mm Travel X / Y / Z: 2,600 x 1,100 x 900 mm Table load capacity: 4,000 kg Rotary table capacity: 1,200 kg Lodpfx Ajytrzxshvjhd Machine weight: 27,750 kg Taper: DIN 2080 A-50 (ISO 50) Tool magazine capacity: 60 positions Spindle speed: 10,000 rpm Blum tool probe Additional machine equipment and maintenance carried out - Internal and external air and coolant supply, through the spindle via M function (40/80 bar) - Upper external air cooling (evacuation for higher chip volume via M function) - Headstock vibration control module - Preventive maintenance up to date: oil changes, filters, coolant, performed as per manufacturer’s schedule or operational needs - Y-axis spindle replaced at 9,256 hours - Belleville washers replaced at 13,903 hours - Mechanical tool probe with option for Blum laser installation (laser included) - DMG probe - 3D QuickSET - Coolant gun - X-axis linear drive - Basic machine dimensions: Length: 8,600 mm; Width: 5,800 mm; Height: 3,200 mm - Chip conveyor

Condition: reconditioned (used), Year of construction: 2010, CNC Vertical Machining Center DECKEL MAHO DMU 50 eVo linear NEW DMG Design With Heidenhain iTNC 530 Path Control Lodpfx Ahoyn Nx Revjhd Year of Manufacture: 2010 Travel distances: X 500 Y 450 Z 400 Spindle speed range: 0 – 18,000 rpm, stepless (SK 40) Including the following accessories: 2-axis NC rotary tilting table 500mm x 380mm Vertical tool changer with 120 magazine slots Full splash guard cabin with sliding doors and interior lighting Electronic handwheel Operating mode 3 ICS 40 bar with paper band filter Chip conveyor 3D measuring probe BLUM tool measuring system in the working area 4-color signal lamp DMG Automation PH 150/8 16 pallets with Allmatic + Lang vices Coolant unit BEMA coolant nozzle 4 height-adjustable machine feet Operating manuals

Condition: as good as new (ex-display), From checkweigher to filling scale The single-head weigher is the most cost-effective solution for partially automating manual filling. With reproducible accuracy, the filling speed can be significantly increased. Features of the weigher - Simple operation and cleaning - Low maintenance requirements - Parts in contact with the product suitable for food (1.4301, NBR) - Operation via a 7" touchscreen - Technical documentation from regional partners - Coarse/medium/fine flow for precise weighing results - Infinitely adjustable vibration system - Purely electrical operation possible Lodpfxohuah Dj Ahvehd Technical data - Number of weighing containers: 1 - Weighing hopper volume: 4.5 liters - Volume hopper: 20 liters - Weighing range continuously adjustable between 20 and 3,000 grams - Accuracy: 0.5-3g depending on product - Speed: up to 15 weighings per minute, depending on product, set weight and desired accuracy - Power: 0.7kW / 230V / 50Hz - Dimensions: 860mm x 570mm x 920mm
