Used Module for sale (4,459)

Condition: used, Year of construction: 2017, EUROMEC EASY LAMI 2 - Year 2017 Module for laminated glass cutting Module adaptable to any cutting table for customers who need to cut and break laminated glass. Usable cutting length: 2600 mm Fjdpfx Aszz Snmsk Uspl Cutting thicknesses: 2-28-8 mm Plastic thickness: 0.78 mm Minimum cut size: 0 mm Cutting tolerance: +/- 0.3 mm Head axis movement: Pinion with guide and RPP belts Length x Width x Height: 3800 x 1200 x 1400 mm Weight: 600 kg Air pressure: 6 bar Air consumption: 45 l/min Voltage: 400V 3-phase, with neutral and earth Frequency: 50 Hz / 60 Hz Total power: 6 kW

Condition: used, Year of construction: 1980, functionality: fully functional, For sale is a gear hobbing machine. Manufacturer: LIEBHERR Table diameter: 315 mm Fsdozz I Naspfx Ak Uopl Table hole diameter: 80 mm Maximum gear diameter: 300 mm Hobbing length: 225 mm Maximum module: 6.0 Hobbing length: 225 mm Maximum diameter of hob tool: 140 mm Maximum length of hob tool: 152 mm Maximum length of workpiece: 680 mm Minimum number of teeth cut: 4 Machine dimensions: 3.3 x 1.9 x 2.2 m Machine weight: approx. 6.0 t

Condition: excellent (used), For sale: SEW-EURODRIVE MOVIDRIVE inverter, complete with a power module. Visual condition as shown in the photos. Technical data: Control unit: Manufacturer: SEW-EURODRIVE Model: MDX61B0550-503-4-00 Controller type: MDX61B-00 P/N: 08279691 Control unit P/N: 08243492 SO#: 01.1304473308.0001.09 Control unit SO#: 0189307 Protection class: IP00 Country of manufacture: Germany (Made in Germany) Power module: Model: MDX60A0550-503-4-00 Sach. Nr.: 8226636 Nr.: 0591425 Input power supply: 3×380–500 V AC ±10% Fpsdjzphccjpfx Ak Usl 50–60 Hz ±5% 94.5 A AC (400 V) Operating temperature: 0…40°C Protection class: IP10 Output: 3×0 V 0–180 Hz 105 A AC (400 V) 73.5 kVA Lastart: M Installed communication modules: DFP21B DEH11B Additional markings: SEW Werk Wien service sticker: Rep. No.: 12424 Repair: 12/2011 Final inspection: 42/2011 Weight: 32.75 kg Condition: Visually in good condition. The housing has a crack (visible in the photos). Normal signs of use, minor scratches, and scuffs are visible. Sold exactly as shown in the photos.

Condition: used, Year of construction: 1990, External/Internal Cylindrical Grinding TARDUGNO RIBON type MODULE 2A Between points: 1000 mm Centre height: 180 mm Workpiece holder spindle CM4 Maxi grinding diameter: Ø 360 mm Workpiece holder rotation: from 35 to 310 RPM Year of construction: 1990 Fsdpfxjzww Sio Ak Uopl Tilting table - 9° / + 6° Grinding wheel dimensions: Ø 406 mm x thickness 60 mm Scale on table X Spindle speed: 1500 - 1730 RPM Grindstone motor: 5,5 CV Hydraulic tailstock CM3 Auto wheel advance Internal grinding spindle: Max speed 20000 RPM Maxi boring: from 14 to 75 mm Lubricant tank+ paper filter Diamond system Tilting grindstone holder trolley Supplied with grinding wheels + steadies Voltage: 380 V Dimensions (L x W x H): 3800 x 2000 x 2200 mm Weight: approx 3,2 T

Condition: excellent (used), functionality: fully functional, Siemens SIMODRIVE 611 Testing and Repair Station For sale: a professional testing and repair station for Siemens SIMODRIVE 611 LT modules and control units. Suitable for testing, diagnosing, troubleshooting, repairing, and performing functional checks on various Siemens SIMODRIVE 611 components. Suitable for: * 6SN1123 – LT/power modules * 6SN1118 – Control units Ideal for repair shops, CNC service providers, maintenance departments, and industrial electronics. The testing station is suitable for functional testing and diagnosing components before or after repair. Fedszzlu Hepfx Ak Ujpl Sold complete as shown in the picture.

Condition: excellent (used), functionality: fully functional, Siemens SIMODRIVE 611 Test and Repair System – E/R Modules For sale is a professional test and repair system for Siemens SIMODRIVE 611 feed and return modules (E/R modules). The test system was designed for testing, diagnosing, troubleshooting, repairing, and performing functional checks on SIMODRIVE 611 E/R modules. Suitable for various Siemens SIMODRIVE 611 E/R modules in the series: 6SN1145… 16 / 21 kW * 6SN1145-1BA01-0BA0 * 6SN1145-1BA01-0BA1 * 6SN1145-1BA01-0BA2 36 / 47 kW * 6SN1145-1BA02-0CA0 * 6SN1145-1BA02-0CA1 * 6SN1145-1BA02-0CA2 Fedpfx Akezzlx Eo Uopl 55 kW * 6SN1145-1BA01-0DA0 * 6SN1145-1BA01-0DA1 80 kW * 6SN1145-1BB00-0EA0 * 6SN1145-1BB00-0EA1 120 kW * 6SN1145-1BB00-0FA0 * 6SN1145-1BB00-0FA1 The test system is particularly suitable for: • Testing of SIMODRIVE 611 E/R modules • Repair and overhaul • Functional testing after repair • Fault diagnosis and troubleshooting • Testing of power electronics • Service and maintenance • CNC service and drive technology • Industrial electronics repair The complete test and repair system, as shown in the pictures, is being sold. Ideal for repair shops, service companies, maintenance, CNC service, and industrial electronics.

Condition: like new (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 6SL3130-1TE24-0AA0, overall weight: 13 kg, Siemens SINAMICS S120 Basic Line Module – 6SL3130-1TE24-0AA0 Input: 3AC 380–480 V, 50/60 Hz Output: DC 600 V, 67 A Power: approx. 40 kW Enclosure: Booksize, internal air cooling Interface: Drive-CLiQ Additional Information Quantity available: 3 units Weight: 13 kg Fodpsw R Ad Ejfx Ak Uopl Dimensions (packaging): 57 × 29 × 40 cm Year of manufacture: 2022? Condition: New / Unused Manufacturer: Siemens AG Made in: Germany Storage location: P1H1V1

Condition: new, Year of construction: 2023, functionality: fully functional, overall weight: 14 kg, For sale is 1x Siemens SINAMICS S120 Active Interface Module for 16kW Active-Line Modules, with article number 6SL3100-0BE21-6AB0. Series: SINAMICS S120 Fodpfx Ajzxp Dmjk Uopl Type: Active Interface Module The item comes from stock/spare parts inventory. The optical condition can be seen in the attached pictures. We will gladly provide further technical documentation or detailed images upon request. Inspection and collection are possible by arrangement. Shipping is possible at the buyer’s expense. Subject to prior sale, errors and changes.

Condition: used, Year of construction: 2020, Overview Krones Ergomodul modular container labeller. Containers run anticlockwise after the infeed in a frontal arrangement with two discharge starwheels. Finish RAL 9018 papyrus white in the wet-line section. Two docking positions at the carrousel, both in operation, accept the four labelling stations without tools, so cold-glue and self-adhesive labelling run on the same carrousel; height adjustment of the top part and each station is motorised with container type preselection. Technical data - Manufacturer: Krones - Model: Ergomodul - Year of manufacture: 2020 - Table pitch diameter: 1,200 mm - Rotary plates: 30 - Machine pitch: 125.6 mm - Main drive: controlled servo motor; Danfoss servo motors, container table - Cold-glue stations (2x): ERGOMATIC-CL, 8-shaft glue pallet carrousel, 8-section gripper cylinder d = 350 mm, unwinding length 40-130 mm, steel glue roller, integrated glue pump, gluing height 5-215 mm, housing stainless steel, AISI 304-similar - Self-adhesive stations (2x): AUTOCOL-TS 120, web speed 120 m/min, supply tolerance +/- 0.5 mm, four-axis stand (application height, container diameter, conicity, sloping position), two-reel holder with automatic splicing and end-of-reel detection, driven carrier-film rewinder, ionisation unit, reels up to 390 mm outer diameter, carrier film up to 150 mm - Container infeed: worm with servo drive; detects damaged and fallen-over containers - Container orientation: prepared for camera orientation at the carrousel (360-degree monitoring, one camera); electrical interface prepared, mechanical adjustment unit not installed - Coding: prepared for a laser coder at the carrousel, with laser guarding, safety switch, clock pulse, oil-free air supply - Conveyors: flat-top chain, 83.8 mm wide, stainless steel (AISI 304-similar); servo-driven infeed, PM-motor discharge, centralised frequency inverter control - Machine guarding: lifting doors at the carrousel (polycarbonate), hinged doors at the front table (tempered safety glass) - Pneumatics: Festo; Bosch-Aventics, Norgren Herion, SMC, Bürkert components - Electrical: 400/230 V, AC 3/N/PE, 50 Hz, 28 A full load, 50 A back-up fuse; UPS 400/230 V, 17 A - Media: 92.4 m³/h oil-free compressed air, 0.009 m³/h process water - Weight: approx. 10,600 kg total (carrousel 3,200 kg, front table 3,000 kg, 1,100 kg per cold-glue station, control cabinet 1,000 kg) Equipment - 2x ERGOMATIC-CL cold-glue labelling stations, interchangeable - 2x AUTOCOL-TS self-adhesive labelling stations, interchangeable - Stand-alone control cabinet with Krones iPanel operator terminal - Central lubrication (Lincoln progressive distributor with motor pump) - Ecopush rejection module - Handling parts set on trolleys Fpjdpfx Akezzz N Hs Uol The inspection unit (Checkmat) and the container coding device used with this labeller are not part of this machine. Condition Used, still installed and under power in an operating line; on-site inspection possible before purchase. Availability Available now. The machine is in Belgium and will be dismantled and moved to our location in Germany; dismantling, loading and transport quoted on request.

Condition: good (used), Year of construction: 2007, power: 9.1 kW (12.37 HP), Manufacturer: Ilsa Multimatic Type: Topline 320 Fpodsw I Ddhepfx Ak Uel Designation: Cleaning machine Distillation module: VD160 Tank volume: 320 L Spin speed: 550 rpm Power: 9.1 kW Year of manufacture: 2007

Condition: used, Advanced Semiconductor Materials Lithograph Holding N.V. Interface Module YieldStar S-200B, 4022 636 68175, MSMR TM Fpedsx I Ak Iepfx Ak Ujl Model: 402263668175 Type: MSMRTM Condition: Used General Information: Central electronic interface for the MSMR measuring system of an ASML Yieldstar S-200B Rugged industrial enclosure in pull-out/rackmount design Distribution of voltages (e.g., 24 V, 13 V) Protection and safeguarding via multiple circuit breakers (F1…F5) Connection to measuring and control components via X-ports Interface to I/O, sensor systems, thermal control, and fan-filter units

Condition: excellent (used), functionality: fully functional, Year of construction: 2019, Precision solar simulator for the measurement and calibration of solar cells and modules. Simulates the solar spectrum using a xenon or LED-based flash light source. Uniform irradiation area, automated test procedures, and integrated control via touch panel. Compact, sound-insulated enclosure with safety interlock, signal lamp, and test chamber access via sliding door. Fedpfx Asxzuiaek Ujpl

Condition: used, Year of construction: 2010, Brooks Automation Wafer Front-End Module, 300mm, ASYST Spartan EFEM, Sorter Model: ASYST Spartan EFEM Type: Sorter Condition: Used Technical Data: Fpodpfsx I Ax Sjx Ak Uol 100-240V AC 50/60Hz 10A General: 300-mm EFEM with 3 load ports, cleanroom mini-environment, and integrated wafer transfer robot This unit is an Equipment Front End Module (EFEM) from the ASYST Spartan series, designed for fully automated handling of 300 mm silicon wafers in semiconductor manufacturing. It features three load ports, a mini-environment with ULPA air filters, internal lighting, comprehensive safety controls, and all necessary interfaces for seamless integration into production lines. In addition, it comes with a fully integrated wafer transfer robot that extracts wafers from FOUP/carrier load ports, separates them, and precisely delivers them to downstream process modules. Year of manufacture: 27.12.2010 Including CD with operating, service, and installation manuals (9701-3060-01 Rev G)

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, paper weight (max.): 208 g/m², paper width (max.): 350 mm, paper height (max.): 500 mm, production capacity: 4,500 unit/h, No minimum price – guaranteed sale to the highest bidder! Auction of a brochure production line! TECHNICAL DETAILS Gathering towers Models: Horizon VAC-100a / VAC-100m Number of towers: 2 Stations per tower: 10 Feeder system: Air suction feeder Voltage: 230 V Frequency: 50 Hz Current draw: 10.4 A per section Booklet making and folding module Model: Horizon SPF-200A Voltage: 230 V Frequency: 50/60 Hz Current draw: 3.4 / 3.2 A Booklet making heads: 2 Brochure thickness: up to 4.5 mm Functions: Wire stitching and center folding Front trimmer Model: Horizon FC-200A Function: Automatic front trimming Operating mode: Inline operation with Horizon SPF-200A Cutting quality: High-precision cut Stacking unit Model: Horizon ST-40 Voltage: 230 V Frequency: 50 Hz Fjdpfxszy Hhxs Ak Uopl Current draw: 4.7 A Function: Automatic stacking of finished brochures Production capacity: max. 4,500 brochures/h Feeder stations: 10, expandable to max. 60 Sheet format max.: approx. 350 × 500 mm Paper weight: 52–208 g/m² Booklet thickness: max. 2 mm for saddle stitching Processing: Gathering, stitching, folding, and stacking in one system MACHINE DETAILS Production counter: approx. 1,800,000 brochures EQUIPMENT Horizon VAC-100a gathering tower Horizon VAC-100m gathering tower Horizon SPF-200A booklet making and folding module Horizon FC-200A front trimmer Horizon ST-40 stacking unit Data sheets for the individual components of the system, including further detailed technical data, can be found in the appendix.

Year of construction: 2011, condition: used, functionality: fully functional, machine/vehicle number: 11ED18A, For sale: 2 National Instruments PXI-6511 Digital I/O Modules, in fully working condition. Both can be sold separately for €300 each. Manufacturer: National Instruments (NI) Model: PXI-6511 Quantity: 2 units Condition: Used – Tested and Working Fpedpszh H Sgefx Ak Ujl Channels: 64 digital input channels Isolation: Bank-isolated, ±30 VDC Interface: PXI Driver: NI-DAQmx compatible Both units are fully functional. Ideal for industrial automation, production line control, and testing systems. Removed from a working industrial environment, no faults found. Shipping from Hungary. International shipping available. Carefully packed with antistatic protection. Please contact us if you have any questions!

Condition: ready for operation (used), Year of construction: 1990, functionality: fully functional, machine/vehicle number: 018.0402, gear diameter: 300 mm, controller model: Optronic CNC D140, workpiece width (max.): 2,300 mm, workpiece height (max.): 500 mm, center height: 250 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Fpjdpjzzba Sjfx Ak Ujl Gear diameter: 300 mm Module range: 0.5–8 mm Pressure angle: 35° Max. workpiece width: 2,300 mm Max. workpiece height: 500 mm Max. workpiece weight: 100 kg Center height: 250 mm Table length: 2,300 mm Grinding spindle travel: 200 mm MACHINE DETAILS Control system: Optronic CNC D140 Dimensions & Weight Dimensions (L x W x H): 5,900 x 1,300 x 2,000 mm Net weight: 7,500 kg Shipping packages: 5 units

Condition: used, Excelitas Deutschland GmbH Yieldstar Illumination Module, 4022 642 3857 1, LISA III Model: 402264238571 Type: LISAIII Condition: Used Technical Data: 230V AC 50/60Hz Fpodpfex I Autex Ak Uol General Information: YS Illumination Module LISA III (Qioptiq Photonics) is a high-quality optical illumination module (light source/illumination) from the ASML YieldStar S-200B. The LISA III / LISA series is a family of mini-optics or LED lenses (light-shaping elements) used, for example, in illumination or projection applications.

Condition: like new (used), Year of construction: 2023, functionality: fully functional, total length: 1,310 mm, total width: 390 mm, total height: 40 mm, 120 pcs. Shelves approx. 131 x 39 x 4 cm , SSI Schäfer R3000 , II. choice (new) Shelving racks Workshop shelving , Storage racks , Manual storage , Push-in shelving , Small parts storage B40/392/70 , ZB341315 , ZB9414 Data : - Length: approx. 131.2 cm - Width: approx. 39 cm - Height: approx. 4 cm - Scope: 120 pcs. Shelves SSI Schäfer R3000 - Load : max. 100 kg per shelf - Surface : sendzimir galvanized - II. CHOICE (NEW GOODS)(This is a II. Wahl product, new and unused.II. Choice means there may be dust deposits, minimal scratches or soiling). - ex warehouse Wietmarschen Price : 960,00 € net 1142,40 € gross You will receive an invoice with VAT shown. Transportation : The delivery is carried out on request by our partner forwarding agency, the costs depend on the postal code. Fpsdpfxozy Utpj Ak Usl Assembly : If required, our trained staff will be happy to assist you with the professional assembly and disassembly of your factory equipment. Our recommendation : Let us know what you need... We will be happy to help you with the realization of your projects, from planning and ordering to installation.

Condition: excellent (used), Year of construction: 2016, operating hours: 16,000 h, functionality: fully functional, nominal power (apparent): 11 kVA, controller manufacturer: haas, spindle speed (min.): 10 rpm, spindle speed (max.): 10,000 rpm, spindle motor power: 11 W, number of spindles: 1, number of slots in tool magazine: 21, Equipment: chip conveyor, Here is the complete reference sheet combining the Haas DT-1 machine specifications, probing package, and 5-axis setup in metric units. 2016. Located in Israel Transport cost to Erope 8000 Euro Fjdpfxjzwxz Es Ak Uopl under power Machine Travels & Work Envelope X-Axis Travel: 508 mm Y-Axis Travel: 406 mm Z-Axis Travel: 394 mm Spindle Nose to Table Top: 152 mm – 546 mm Worktable Table Size (L x W): 660 mm x 381 mm Max Weight on Table: 113.4 kg T-Slot Width: 15.9 mm – 16.0 mm T-Slot Center Distance: 125 mm (3 standard slots) Spindle Specs Spindle Taper: BT30 Max Speed: 10,000 RPM ATC 20+1 5-Axis Setup (TRT100 Dual-Axis Rotary Table) Rotary Unit: TRT100 dual-axis tilting trunnion (mounted on the table). Platter Diameter: 100 mm Max Part Swing: 213 mm Weight Capacity on Platter: 6.8 kg (3+2 positioning) / 2.3 kg (simultaneous 5-axis) Travel: A-axis (Tilt) ±120°, C-axis (Rotation) 360° continuous Indexing Speeds: 1,000 deg/sec on both axes Control Requirements: 4th & 5th-axis drive options installed on the machine control. Key Software Features: Supports 3+2 indexing and continuous 5-axis simultaneous machining. DWO/TCPC (Dynamic Work Offsets / Tool Center Point Control): Manages work offsets automatically as part angles tilt/rotate, eliminating the need to re-post programs when mounting locations change. Working Clearance: The TRT100 unit consumes ~230 mm of vertical space, leaving a tight Z-axis machining clearance window (~160 mm) inside the machine's 394 mm total Z-travel. Probing & Tool Measurement (WIPS-R / Renishaw) Hardware Package: Workpiece Spindle Probe: Renishaw OMP40-2 (BT30 optical touch probe) Tool Setter Probe: Renishaw OTS (Table-mounted optical tool setter) Receiver: Renishaw OMI-2T (Modulated optical transmission) Tool Setter Functions: Automatic tool length offset setting, rotating tool diameter offset calibration, and in-cycle tool breakage detection. Workpiece Probe Functions: Work Coordinate System (G54–G59) setting, feature inspection (bores/bosses/surfaces), and part alignment skew angle calculation.

Condition: like new (used), Year of construction: 2023, functionality: fully functional, total length: 1,280 mm, total width: 390 mm, total height: 40 mm, 120 pcs. Shelves approx. 128 x 39 x 4 cm , SSI Schäfer R3000 , II. choice (new) Shelving racks Workshop shelving , Storage racks , Manual storage , Push-in shelving , Small parts storage B40/392/70 , ZB341315 , ZB9414 Data : - Length: approx. 128.1 cm - Width: approx. 39 cm - Height: approx. 4 cm - Scope: 120 pcs. Shelves SSI Schäfer R3000 - Load : max. 100 kg per shelf - Surface : sendzimir galvanized - II. CHOICE (NEW GOODS)(This is a II. Wahl product, new and unused.II. Choice means there may be dust deposits, minimal scratches or soiling). - ex warehouse Wietmarschen Price : 960,00 € net 1142,40 € gross You will receive an invoice with VAT shown. Transportation : The delivery is carried out on request by our partner forwarding agency, the costs depend on the postal code. Fpsdezy Uyvepfx Ak Ujl Assembly : If required, our trained staff will be happy to assist you with the professional assembly and disassembly of your factory equipment. Our recommendation : Let us know what you need... We will be happy to help you with the realization of your projects, from planning and ordering to installation.

Condition: like new (used), Year of construction: 2023, operating hours: 100 h, functionality: fully functional, nominal power: 9 kW (12.24 HP), overall weight: 2,100 kg, type of input current: three-phase, The Crossline 650 automatic cut-off saw is equipped with a rotating table and a 650 mm diameter saw blade that can rotate +/-70°. Material inserted into the machine is automatically detected, and its length is determined. The material is then fed using a push-type clamping device. Cutting accuracy is ensured by two independent upper and side clamping devices. Once the material is firmly clamped, the saw blade rises for cutting. After cutting, the material is pushed onto the output table. The machine can operate in manual mode or automatically, connected to the WinCreator software or with data from other commonly used programs. Crossline 650M The Crossline 650M is equipped with a grooving module. Its use is intended for situations where the production of trusses needs to be combined with cutting material for wall panels, ensuring precise positioning of studs and components in the structure. Thanks to its functionality, the Crossline 650M is an efficient, comprehensive solution and is often an alternative to complex machining centers in the prefabrication of wood-based panels. Fpodpfjzz A Iwex Ak Uol Groove width max. 60 mm (depending on the tool). Technical data for Crossline 650 and 650M: Industrial PC Beckhoff with 12" touch screen Saw blade Ø 650 mm, 2800 rpm, motor 7.5 kW Blade stroke adjustment Cutting accuracy ± 0.5 mm/meter Feed rate 0-60 m/min Automatic material measurement Cutting diagram for Crossline 650, 650M

Condition: good (used), Year of construction: 2010, functionality: fully functional, Corner cutting module Fpjdouxn H Iepfx Ak Uel with its electrical panel

Year of construction: 2014, condition: repair required (used), functionality: not functional, machine/vehicle number: M755, Technical characteristics: # Workspace: 1,130 × 860 × 1,080 mm (W × H × D) # Tank capacity: 420L # Mechanical weight: 1,900 Kg Electrical Equipment # Power supply: 400 VAC, 3-phase, 50 Hz # Generator output: From 3 kW up to >100 kW (with pulse technology) Dimensions # Machine dimensions (L×W×H): 2,100 × 2,000 × 2,600 mm Equipment consists of: # Main machine, electrolyte filtration system, industrial cooler, electrolyte treatment (CR-6 elimination) # Dosing unit for electrolyte # Control system: Siemens S7-300 with Visual WIN CC/User-friendly interface: Touch panel with integrated tool menu # Communication module for tooling requirements: up to 8 signals # Safety features: Light curtain or sliding door for operator protection # Process monitoring: Real-time data tracking and short-circuit detection Machine status: NOT WORKING # Safety Light barrier # Communication module Festo # Pump for filtration system Fsdpfx Aoxwmikjk Uspl

Year of construction: 2022, condition: used, Main Dimensions and Capacity Chuck size 165 mm (6.5") Max swing diameter 419 mm (16.5") Max cutting diameter, BOT/VB turret 305 mm (12.0") Max cutting diameter, BMT65 turret 173 mm (6.8") Max cutting length 406 mm (16.0") Bar capacity 44 mm (1.75") Travel and Feed Rates X axis 200 mm · rapid 12.0 m/min Y axis ± 51 mm · rapid 12.0 m/min Fedpfozz H Nrox Ak Ujpl Z axis 406 mm · rapid 30.5 m/min Spindle and Sub-Spindle Main Spindle Spindle nose A2-5 Power 11.2 kW (15 hp) Max speed 6,000 rpm Max torque 102 Nm @ 1,300 rpm Drive Belt drive Sub-Spindle (A2-5) Sub-spindle rated at 6,000 rpm with an A2-5 spindle nose, for finish-machining the second side of the workpiece. Part off-loader included. Compatible with an automatic part loader (APL) for loading/unloading from the main spindle. Turret and Tooling Turret 12-station hybrid (6x VDI40 + 6x BOT) Live tooling 4,000 rpm, with C axis Bar Feeder – Haas Bar Feeder V2 Bar diameter 9.5–79.4 mm Bar length up to 1,219 mm Installation kit For 44 mm bar capacity (9–38 mm liners) included Weight 408 kg Control and Connectivity ● Haas NextGen control with touchscreen ● 1 GB onboard program memory ● Ethernet interface and WiFi connectivity ● HaasConnect – remote machine monitoring ● HaasDrop – wireless file transfer from a mobile device ● Visual Part Programming System plus user-definable macros Additional Equipment Included ● Coolant tank, 114 liters, with pump ● Hydraulic chuck, 165 mm, A2-5 ● Bolt-on tool holder kit ● Automatic parts probe (manual and automatic mode) ● Chip conveyor, hinged-belt type ● CNC control cabinet cooler ● Air blast on chuck and air jet on sub-spindle ● Parts catcher system for unattended machining ● Rigid tapping (synchronized, up to 8x feed-back speed) ● Spindle orientation ● Power outage detection module ● Lifting eyes for machine transport ● Metric measurement units Weight and Electrical Machine weight 3,584 kg Electrical connection 220 VAC / 40 A or 440 VAC / 20 A, 3-phase Air requirement 113 l/min @ 6.9 bar (min 5.5 bar)

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, resolution (max.): 360 dpi, paper width (min.): 290 mm, paper width (max.): 750 mm, paper height (min.): 360 mm, paper height (max.): 1,200 mm, TECHNICAL DETAILS Production Speed Production speed, UV spot coating: max. 3,123 ISO-B2 sheets/hour Production speed, Evo 75: max. 4,200 ISO-B2 sheets/hour Production speed, Evo 75: max. 2,291 ISO-B1 sheets/hour Production speed, hot foil embossing: max. 2,300 B2 sheets/hour Fodszrfh Ijpfx Ak Ujpl Format and Printing Area Paper width: min. 290 mm Paper width: max. 750 mm Paper height: min. 360 mm Paper height: max. 1,200 mm Sheet format: min. 420 mm × 297 mm Sheet format: max. 750 mm × 1,200 mm Printable width: max. 540 mm or 730 mm Hot foil embossing area: max. 740 mm × 1,190 mm Resolution Resolution max.: 360 dpi Material Thicknesses and Basis Weights Material basis weight: min. 135 g/m² Material basis weight: max. 800 g/m² Material thickness before printing and lamination: min. 150 µm Material thickness before printing and lamination: max. 800 µm Material thickness for hot foil embossing: min. 150 µm Material thickness for hot foil embossing, standard version: max. 600 µm Material thickness for hot foil embossing, optional: max. 800 µm Foil Rolls Foil roll diameter: max. approx. 300 mm Foil roll length: 400–2,000 m Number of foil rolls that can be used simultaneously: max. 5 Foil roll width: min. 100 mm Standard core diameter: 1 inch MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 12,720 x 1,860 x 1,840 mm Weight: approx. 4,524 kg EQUIPMENT iFOIL-L module for hot foil finishing Evo-75 version for sheet formats up to 750 mm × 1,200 mm Holder for up to five foil rolls on one shaft Quick-change core for 1-inch foil rolls
