Used Lever Punch for sale (2,954)

Condition: good (used), 2-column punching tool, separating tool, punching tool, punch, punching die, punching stamp, column frame Ledpfxsyv Apto Ahveri -Punch tool: Stroke 20 mm -Hole Ø 50 mm -Sheet width: up to 993 mm -Punch dimensions: 96 cutouts 22 x 3.5 mm -Individual components: see photos -Dimensions: 1400/820/H380 mm -Weight: 732 kg

Condition: new, Year of construction: 2024, TP turret punch presses With Durma TP series punch presses, you can achieve top quality with precise and fast turret, improved hydraulics and 3 automatic index stations. With movable platen, part unloader, automatic clamps, Cad/Cam software and control unit, Durma turret punch presses are easy to use. With automation systems that increase both work safety and productivity, user safety is also increased while reducing wasted time. Punching force: 30 tons Working area: 3.000+R x 1.500 mm X-axis movement: 3.000+R mm (repositioning) Y-axis movement: 1.500 mm Y-axis speed: 60 m/min X-axis speed: 70 m/min speed combined X+Y: 92 m/min max. stroke rate (in 1 mm steps, 1 mm sheet thickness): 1,100 1/min max. stroke rate (in 25 mm steps, 1 mm sheet thickness): 325 1/min max. marking speed: 1.200 1/min. main cylinder stroke: 40 mm max. punching stroke: 25 mm max. cutting capacity with fixed tool station steel: 6 mm max. cutting capacity with fixed tool station NiRo: 3 mm max. cutting capacity with index station Stah: 3 mm max. cutting capacity with index station NiRo: 1,5 mm Tool changer (27 stations without tool and holder): Lrjdeg Admfjpfx Ahvji 11 x A-station fix: 0,8-12,7 mm 11 x B-station fix: 12,8 - 31,7 mm 2 x C-station fixed: 31.8 - 50.8 mm 1 x D station fixed: 50.9 - 88.9 mm 3 x D-station index: 50.9 - 88.9 mm Positioning accuracy: +/- 0.1 mm Repeating accuracy: +

Condition: used, Punching Machine MUHR & BENDER - MUBEA Type KL 350 / 203 Machine No. Year of manufacture 19 Punching force 35 tons Throat depth 203 mm Ram stroke 22 mm Capacity Ø 28 mm in 10 mm sheet (at 450 N/mm²) Ø 23 mm in 12 mm sheet (at 450 N/mm²) Ram plate 117 x 70 mm Table plate 175 x 100 mm, thickness 100 mm Drop-through opening in table cutout Ø 56 mm Stroke release Single stroke via foot switch Motor power 1.5 kW Power supply 400 Volt, 50 Hz - Electric foot switch for stroke release - Manual lever positioning device for punch movement - Equipped with a Ø 8 mm punching tool - Support tables approx. 270 x 230 mm each on left and right of punching unit - Metal base frame Space requirement L x W x H 750 x 720 x 1500 mm Weight 430 kg Lrsdpfx Aeyvvkwohvei In very good condition

Condition: good (used), Year of construction: 2011, operating hours: 87,995 h, functionality: fully functional, X working area max.: 3000 mm Y working area max.: 1500 mm Machine - Working area 3000 x 1500 mm - Rigid, easily accessible C-frame - Coordinate guidance for high-precision machining - Linear magazine with 18 tool stations incl. 3 clamps - Drives with maintenance-free three-phase motors - Repositioning device with programmable hold-down - Ball tables - Part chute 500 x 500 mm - Good parts bin - Chip container - Automatic shut-off - Initial oil fill - Transport and installation device Punching head - Hydraulic punching head - Rotatable mono tool holder - Manually adjustable hold-down force - Programmable hold-down - Tool length compensation - Punch pin spray lubrication - Slug extraction - Forming Control - Open control based on Siemens Sinumerik 840D - Operator panel with 12" TFT color display - Program management Lrjdpfjyvugqox Ahvei - Integrated technology data - Remote teleservice via Internet - Integrated e-shop Programming - Shopfloor programming based on TruTops Punch Basic - Easy programming Data transfer - USB interface and network connection Safety - CE marking - Multi-beam safety light curtains - Hydraulic quick-stop - Sheet bulge detection - MultiTool function - MultiShear function - MultiBend function - Thread forming function - Engraving function - Deburring and roller technology - Marking/rapid bead function - MultiShear function - Adaptive stroke calibration - Spray lubrication for die - Active die - Additional clamp - Individually opening clamps - Repositioning cylinder - Sensor for part chute - Vibration-damped installation - Sheet bulge detection - Chip conveyor with tilting container - Brush tables with loading and unloading aids - Ejector device for small parts Automation SheetMaster Standard features: - Peeling suction unit - Vacuum sensors - Central lubrication - Sheet thickness measuring device for double sheet detection - Automatic clamp closing - Modular suction plate - Simultaneous loading and unloading during main time GripMaster - Scrap skeleton tongs with sensors - Scissor lift table 400 mm - Scrap skeleton pallet tiltable 1250 x 2500 mm ToolMaster 40 - Simultaneous operation for ToolMaster SortMaster Pallet L2

Condition: used, Single-Column Eccentric Press RASTER ZEULENRODA Type PDA 100 Year of manufacture: 1995 Pressing force: 100 tons Throat depth: approx. 360 mm Table size: 1200 x 710 mm Ram area: 900 x 500 mm Table opening: 400 x 120 mm Stroke adjustment: 6 to 82 mm Ram adjustment: 100 mm Installation height, max. stroke, ram Top Dead Center (TDC): max. 469 mm Installation height, max. stroke, ram Bottom Dead Center (BDC): max. 387 mm Strokes per minute: 50-200 s.p.m. Main drive motor power: 18.5 kW Power supply: 400 Volt, 50 Hz - Hydraulically actuated multiple-disc wet clutch and spring-loaded safety brake - Infinitely variable drive via PIV gearbox with inching mode for automatic stroke adjustment and setup operations - Hydraulic overload protection in the ram - Press force and process monitoring via UNIDOR APS - Pneumatic, steplessly adjustable ram weight compensation - Roller feeder MABU WE16, 160 x 3 mm, programmable feed length - Central grease lubrication - Operating manual and documentation for the press Included: Roller feed unit MABU Type WE16 Strip width: 160 mm Strip thickness: max. 3 mm Strip cross-section: max. 300 mm² Lrjdpfx Ahex U Eiaovei Roller diameter: 63 mm Strip speed: 40 m/min - Adjacent feeder control MABU Space requirements for eccentric press L x W x H: 270 x 240 x 350 cm Weight of the press: 13.5 tons

Year of construction: 1995, condition: ready for operation (used), Immediately available at location: Boschert punching nibbling machine Type KST 40 / 750 PowerLine digital Year of manufacture 1995 Press force 40 tons Stroke height 40 mm Punch diameter max 105 mm Sheet thickness max 10 mm Extension tables left and right Quick-change system Lrsdpfx Aoyw I H Tjhvsi Digital backgauge system x-axis 0 – 1500 mm left y-axis 0 – 750 mm Tools Weight 3 tons At the price of Euro 2,000.-- plus VAT ex location.

Condition: excellent (used), Year of construction: 2002, Model .Amada. Vipros 368 King Stock number 01967 Year of manufacture 2002 Frame Construction ... Bridge Type Press Capacity ... 30 Tonnes (294 kN) Press Type ... High Speed Hydraulic Servo Ram Axis Traverse Distance ... 1525 x 2000 mm Workable Max. Sheet Size ... 1525 x 4000 mm (with auto repositioning) Max. Material Thickness ... 3.2 mm mild steel Max. Hole Dia. Max. Material ... . (shearing strength 36 kg/mm2) 82 mm dia Max. Material Weight ... 75 Kg Max. Material weight ( Max. Speed) ... 60 Kg Lrsdpfsvn D Tfox Ahvei Max. Hole Dia. ... 114.3 mm Number Of Stations ... 58 stations:24 x 12.7 mm 24 x 31.7 mm 4 x 50.8 mm 2 x 88.9 mm Auto Index 2 x 31.7 mm 2 x 114.3 mm Axis Speed ... 113.0 m/min Hits Per Minute (2mm pitch) ... 860 H.P.M./3 mm stroke (8mm pitch) ... 560 H.P.M./3 mm stroke (25mm pitch) ... 460 H.P.M./3 mm stroke Turret Speed Bi-Directional ... 30 R.P.M. Punching Accuracy ... ± 0.1 mm (incl. 1 reposition) Ram Stoke Length (maximum) ... 40 mm Tool Lubrication ... Air Blow System Axis Drive ... AC Servo Motor Turret Drive ... AC Servo Motor Electric Power Required ... 28 kVA 400V +/- 10% 50Hz Air Pressure Required ... 5.0 Kgf/cm2 Air Flow ... 250 1/min Cooling Water Flow ... Min 40 1/min. Machine Length ... 5025 mm Machine Width ... 4120 mm Machine Height ... 2630 mm (3190 mm to mirror) Machine Weight ... 18000 Kg

Condition: used, Year of construction: 2002, functionality: fully functional, stroke length: 2,600 mm, overall weight: 12,000 kg, punching force: 20 t, Amada Europe 2510 machine, in perfect working condition. Sheet metal working dimensions: 3500 mm x 1500 mm, with thicknesses up to 5 mm. Equipped with a fully operational automatic loading system. Ledpoywwztsfx Ahveri

Condition: good (used), functionality: fully functional, Year of construction: 2019, controller model: Rexroth IndraMotion MTX, laser type: CO₂ laser, laser hours: 980 h, laser power: 4,000 W, punching force: 22 t, Equipment: CE marking, nozzle changer, safety light barrier, Machine - C-frame - Coordinate guide - Linear magazine with 25 stations for clamps and tools - 4 x hydraulic clamps - Drives with maintenance-free three-phase motors - Repositioning system with programmable hold-down - Flap for punched parts 500x500mm incl. sensor - Foot pedal for closing clamps - FocusLine - NitroLine - FastLine - FlyLine - Additional XP and Yp axes - Ejector cylinder for laser parts - Fast flap for laser parts 500x500mm incl. sensor - Liftable laser cutting support TRUMPF Laser - TruFlow 4000 laser incl. LensLine and optimized standby - High-frequency excitation - Fine filtration of compressed air for beam tube ventilation - Closed beam guidance Cutting Head - Lens cutting head with 170mm focal length - Universal quick-change device for cutting head - LensLine - ControlLine Punching Head - Electro-hydraulic punching head - Rotatable mono-tool holder - Programmable hold-down position - Tool length compensation - Punch slug extraction - Calculation of fill level in the punching console - Stroke counter for punches - Spray lubrication for punches - Fill level monitoring for tool lubrication - Stripper position measuring system with sheet thickness measurement function Control System - TRUMPF control based on Rexroth IndraMotion - Touch panel with 19" TFT color display - Integrated technology data - Programmable cutting gas pressure - Remote Support interface - Automatic shut-off with wake-up function - Production planner Functions - PlasmaLine Data Transmission - USB interface - RJ-45 network interface - Wireless Operation Point Safety - CE marking - Two-beam safety light barrier - Monitoring system for gas pressure, temperature and cooling water - Emergency stop for drives - Warp detection - Protection against stray radiation Extended Standard Equipment: - Network installation via Remote Support - Chiller (water-air) - Compact extraction system - 1st locating pin (inside right) - 2 finished parts containers - Chip container - 40 used RTC cassettes + die plate Punch Quality Package - MultiShear - Deburring and rolling technology - Adaptive stroke calibration - StripLine Forming Package - Thread forming incl. thread former breakage control - Marking/fast beading - MultiBend - Height-adjustable clamps Lrodjyu S D Aopfx Ahvoi - Automatic nozzle changer - MultiTool - Engraving - Smart Punch Monitoring with sheet format detection - 4 individually openable clamps - Automatic clamp closing with mechanical sensor zero stop - Repositioning cylinder - Vibration-damped installation - Chip conveyor with tilting container - Foot pedal start incl. rear-view mirror - Brush tables with loading and unloading support - Ejector unit for small parts - CO2 extinguishing system for compact extractor - Connection piece for exhaust air duct of compact extractor MobileControl App SheetMaster (AK08) UF - Loading station with spreader magnet - Simultaneous loading and unloading during main time - Peeling system incl. positioning aid for oversize formats - Additional positioning aids for medium format - Additional positioning aids for large format - First add-on package with 9 suction cups (incl. vacuum ejector) - Unloading monitoring for laser parts - Loading of blanks GripMaster 4000 x 1500 mm SortMaster Pallet 4 pallets longitudinal ToolMaster Linear 54 stations with simultaneous tool setup during main time - Safety devices for warehouse connection incl. 2nd light barrier circuit - Warehouse interface

Condition: good (used), Year of construction: 2000, Gebruikte pons- en snijlijn van Voortman | CNC-pons- en snijlijn voor platte staven Capaciteit: Plat 500 x 22 mm Vierkant 150 x 150 x 15 mm Inclusief teller Lredpsyu Sq Nefx Ahvoi Video beschikbaar op aanvraag

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, table length: 2,500 mm, table width: 1,250 mm, Available: medium-format Trumpf CNC punching machine, complete with SheetMaster, SortMaster Box Linear Special, and GripMaster. All functions available: multi-tool, threading, high-speed marking, SoftPunch. Punching force: 220 kN, max sheet thickness: 8 mm, X/Y travel: 2535 mm / 1280 mm, max workpiece weight: 200 kg, X/Y feed rates: 100 m/min / 60 m/min, simultaneous: 116 m/min, punching/marking rate: 1200/min / 2800/min, C-axis tool rotation: 330 rpm. Machine dimensions X/Y: approx. 6800 mm / 6100 mm, weight: approx. 15,000 kg, operating hours: approx. 58,000 h. Documentation available. On-site inspection possible. Offers and videos of the plant in operation can be provided upon request. Lsdpfjywg Agox Ahvori

Year of construction: 1991, condition: used, Standard equipment Lsdpjbnggzsfx Ahvori

Condition: used, Punching Machine MUHR & BENDER - MUBEA Model KL 350 / 203 Machine No. KL3509864 Year of manufacture: 1998 Punching force: 35 tons Throat depth: 200 mm Ram stroke: 22 mm Capacity: Ø 28 mm in 10 mm sheet (at 450 N/mm²) Ø 23 mm in 12 mm sheet (at 450 N/mm²) Ram plate: 265 x 70 mm Ram plate thickness: 25 mm outside / 50 mm in the center Table plate: 285 x 250 mm, thickness 40 mm Table cutout: 115 x 85 mm Drop-through opening in table cutout: 115 x 25 mm Installation height: 125 mm (with table and ram plate) Lredpoxf Utaefx Ahvsi Number of strokes: single stroke via foot switch Motor power: 1.5 kW Power supply: 400 Volt, 50 Hz - Electric foot switch for stroke activation - Manual lever search device for punch movement - Special tool as punching tool Space required (L x W x H): 800 x 800 x 400 mm Weight without tool: 340 kg Weight with tool: 370 kg Good condition

Condition: good (used), Year of construction: 2009, operating hours: 899 h, machine/vehicle number: SN20090545, punching force: 30 t, sheet thickness (max.): 6 mm, table length: 2,000 mm, table width: 1,270 mm, overall weight: 11,000 kg, working range: 40 mm, ERMAK RPP 1270x30 Ton Punching Machine, Year 2009 Brand: Ermak Model: RPP 1270x30 Serial Number: SN20090545 Year: 2009 Main Features: Operating Hours: - POWER ON Hours: 899 hours - Punching Hours: 1 hour 6 minutes - Punching Force: 30 tons - Maximum Capacity: - Sheet Thickness: 6 mm - Sheet Dimensions: 1270 mm (width) x 2000 mm (length) - Travel: 40 mm - Axis Travels: - X-axis: 2000 mm - Y-axis: 1270 mm - Travel speed: - X-axis: 70 m/min. - Y-axis: 70 m/min. - C-axis speed: 100 rpm. - Strokes per minute: Up to 700. - Accuracy: - Positioning: ±0.03 mm - Position tolerance: ±0.1 mm - Numerical control (CNC): GE Fanuc 18i-PB - Oil capacity: 300 liters. - Power: 15 kW - Machine dimensions: Lsdpjv S Ufysfx Ahvori - Length: 4250 mm. - Width: 4000 mm. - Height: 2330 mm. - Weight: 11,000 kg.

Condition: excellent (used), Year of construction: 1987, Profile steel shear, profile shear, punch, punching machine, hole punch, hydraulic flat/profile and bar steel shear -Manufacturer: Peddinghaus, hydraulic profile steel shear type Peddiworker 400 -Drive: hydraulic -Pressure force: 40 tons -Equipment: large support table with stops for die-cutting, various stamps and dies Lrjdpfeyupxwox Ahvsi -Production: Punching, shearing, cutting, pipe notching -Dimensions: 870/660/H1630 mm -Weight: 860 kg

Condition: used, Year of construction: 2002, The equipment described is a register punch manufactured by Bacher. This specific model is known as the ZollRegister punch Control 2000 Zoll and was produced in the year 2002. The machine has a size of 1400 mm. It is currently in stock and located in Germany. The register punch is reported to be in good condition, suggesting that it has been well-maintained and is ready for use. Format: 1400 mm Lrsdpfswzxzpsx Ahvoi Equipment: Register punch Good condition

Condition: excellent (used), functionality: fully functional, IMS punching machine, model PHY 45. Punching: diameter 27 x 13 mm. Used machine. Internal code: SVR 402. Lrjdpeyv Hqzefx Ahvei

Condition: like new (used), functionality: fully functional, punching force: 30 t, total length: 1,000 mm, sheet thickness (max.): 6 mm, sheet thickness steel (max.): 6 mm, Euromac Punching Machine Cx 1000/30, 30 Ton, CNC, Sheet Length 1000 mm, Maximum Thickness Standard Steel 6 mm. Used machine. Internal code: svr 405. Ledsyv Hntopfx Ahvsri

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2010, operating hours: 55,582 h, machine/vehicle number: A0110A0058, controller model: BOSCH PNC-P, laser power: 2,000 W, number of slots in tool magazine: 21, TECHNICAL DETAILS Laser Power: 2,000 W Laser Model: TCF1 Cutting Head Lens Size: 5" Maximum Part Size for Part Chute: 300 x 500 mm Number of Tool and Clamp Positions: 21 MACHINE DETAILS Control Model: BOSCH PNC-P Lsdpfx Ahjyv Ddrsvjri Power-On Hours: 25,582 h EQUIPMENT - Robust C-frame - Coordinate guide with integrated linear scale - 2 clamps - Maintenance-free three-phase servo motors - Brush tables - HI-LAS high-pressure cutting - Rapid processing with SprintLas - Programmable scan feed - Quick-change cutting head device - APC capacitive height control - Lens monitoring sensors - Laser logbook function - Compact nesting table - Rotatable tool holder - Automatic repositioning device with hold-down - Automatic part chute - Sliding part container - Spray lubrication for punch - 2 lubricant containers - Punch slug extraction - Chip bin - Hydraulic quick shut-off - External control panel - 15" TFT color touchscreen - USB port - 3.5" floppy disk drive - Safety device - RJ45 network connection - Network integration - Comprehensive operating manual - Remote diagnostics SPECIAL FEATURES - Thread forming function - Softpunch function - Height-adjustable clamp - Repositioning cylinder - Vibration-dampened installation - Sensor for part chute - Spray lubrication for die - Brush-assisted loading and unloading Note: The machine has already been dismantled (by a certified TRUMPF used machinery partner) and is ready for shipment.

Year of construction: 2006, condition: good (used), functionality: fully functional, machine/vehicle number: 358-2003, We are offering this used Leithold bridge punch, year of manufacture 2006. Type 6005/B/400kN Weight 3,800 kg Lodpfsyvui Sjx Ahveri Rated power 7 kW If you have any questions or require more information, please feel free to send us a message or call us.

Condition: refurbished (used), Year of construction: 2004, operating hours: 5,000 h, functionality: fully functional, total height: 4,300 mm, ram adjustment: 100 mm, installation height: 500 mm, table height: 1,000 mm, total width: 2,200 mm, table length: 1,400 mm, pressing force: 200 t, control cabinet width: 2,000 mm, stroke length: 160 mm, clearance between the columns: 1,450 mm, working width: 1,100 mm, distance between side stands: 400 mm, overall weight: 27,000 kg, height adjustment type: electric, space requirement height: 4,500 mm, space requirement length: 2,200 mm, space requirement width: 1,800 mm, High-precision cutting and embossing press, U.T accuracy +/- 0.01, ideal for the production of fuel cell stacks or hydrogen electrolyzers. hydrogen electrolyzers. The press is also suitable for (smooth) fineblanking, stroke rate 1 - 70 /min. Lodpfst Nf Agex Ahveri Eccentric loads are also possible without any problems thanks to 4 connecting rod rams. It is also not possible for the press to jam. The press is completely overhauled and supplied with a new Siemens S7 control system.

Condition: good (used), functionality: fully functional, Year of construction: 2008, operating hours: 41,804 h, Used TRUMPF TruMatic 6000 (K01) – Medium format Technical data: Lodpfxowkd Efj Ahvori Year of manufacture: 2008 Last maintenance: 18.03.2025 Laser TrueFlow 2000 with laser power: 100-2,000 watts NC operating hours: 41,804 Resonator hours: 14,466 Beam-on hours: 2,054 Y-axis: 1,300 mm Additional equipment: various tools Recently installed new parts: Conversion to TASC5 laser control (01/2025) Control panel with display (01/2025) Box PC (01/2025) Hydraulic punching head/multilayer (10/2021)

Year of construction: 1998, condition: ready for operation (used), A hydraulic sheet punching machine Indumasch without sheet manipulation axes, but with CNC backgauges for manual sheet positioning, is available. Punching force: 40t, max. sheet thickness: 10mm, stroke rate: 150/min, max. punching diameter: 105mm, working dimensions X/Y: 1000mm/750mm, positioning accuracy: 0.1mm, weight: approx. 3500kg. Without tools. The controls were overhauled in 2014. Documentation available. An on-site inspection is possible. Lodpsyviyljfx Ahveri

Condition: used, Year of construction: 1985, operating hours: 35,288 h, machine/vehicle number: 10661, total height: 2,200 mm, total width: 1,200 mm, total length: 1,700 mm, pressing force: 25 t, DGUV certified until: 06/2026, year of last overhaul: 2025, For sale is a MABU 25 VP /RC, which, given its age, is in good condition. The machine is still in use in serial production and operates reliably. An inspection and test run are possible in ongoing production until the end of week 18/2026. This gives you the opportunity to personally verify the machine’s performance and functionality. Nominal force: 250 kN Stroke rate: 12⅓–500 spm Feed: MABU 120/150 Adjustable stroke: 7–62 mm Main drive: 3.7 kW Power supply: – Adjustable stroke: 7–62 mm Table dimensions: 400 x 360 mm Adjustable strip entry height: 10–140 mm Max. strip width: 35 mm Max. material thickness: 1.5 mm Machine dimensions: 2115 x 1662 x 1190 mm Weight: 2500 kg "Main drive on (runtime) (Control cabinet counter)" 35,288 h A sound enclosure is optionally available for purchase. Lrodjyu S Etepfx Ahvei

Condition: used, Year of construction: 1995, operating hours: 42,416 h, functionality: fully functional, machine/vehicle number: 10317, total height: 3,100 mm, feed length X-axis: 120 mm, ram adjustment: 64 mm, table height: 1,250 mm, pressing force: 50 t, stroke length: 16 mm, stroke adjustment: 51 mm, clearance between the columns: 1,200 mm, DGUV certified until: 06/2026, year of last overhaul: 2025, For sale is a Bruderer BASTA 50 UL, a high-performance stamping press designed for precise and reliable results in series production. The machine is currently integrated into ongoing production and can therefore be viewed and tested under real operating conditions. Inspection and extensive functional testing are possible until the end of calendar week 20/2026. Thanks to continuous use, the machine is in excellent technical condition and ready for immediate operation. All maintenance and servicing work has been carried out regularly and meticulously. Ljdpfeyu Sn Iex Ahveri Technical data: Rated force: 500 kN Strokes per minute: 100-1120 spm Feeder: BBV 202/120 Adjustable stroke: 16-51 mm Die space / Clamping plate: 760-940 mm Main drive power: 22 kW Power supply: 400 V / 50 Hz Adjustable stroke: 16-51 mm Ram surface: 980 x 420 mm Table surface: 940 x 580 mm Adjustable strip entry height: 50-140 mm Max. strip width: 203 mm Max. material thickness: 2 mm Machine dimensions: 2700 x 1800 x 3100 mm Weight: 8150 kg "Main drive on (actual running time): 42,416 hours" An acoustic enclosure is available as an option.
