Used Grid for sale (1,495)

Year of construction: 2006, condition: excellent (used), Transport and automation system for motor housings with control system Technical parameters of motor housing Inner diameter: 66 mm, 70 mm, 74.2 mm Wall thickness: 2 mm Length: 87.8 mm – 135 mm Material: Steel, painted Technical parameters of grinding machine - Two-belt grinding machine, type M2-120, manufacturer Weber - Includes continuous prism conveyor with adjustable speed via frequency converter System output: max. 52 pieces per minute Functional description: The motor housings are manually removed from the grid box by one person and placed on a buffer table in a defined position. A row pusher moves the foremost row onto a permanent magnetic articulated belt conveyor. The motor housings are automatically transported and transferred to a permanent magnetic combination conveyor. After a 90° deflection, the housings are buffered in a roller track. One housing is released at a time and fed to a prism conveyor. The combination conveyor is axially adjustable, so that a centric feed to the prisms is ensured depending on the housing length. Pgodpfjzww Ecex Akqjr After the grinding process, the motor housings are transferred to another permanent magnetic combination conveyor. After a 90° deflection, the housings are brought into a stationary position and guided onto a permanent magnetic articulated belt conveyor. With stamping number control system Syscona For secure and reliable detection of stamping numbers in metal tubes. Detection station with high-resolution CCD black and white camera with scan sensor. With control system Syscona For detection of bumps in tubes according to a pattern. HighVision HV video camera system Defective motor housings are identified and transmitted accordingly to the rejection device. A swivel cylinder directs the housings onto a parallel articulated belt conveyor, which transfers them to a buffer table. DISMANTLING by customer!

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 3695 € 2400 x 1200 mm 3000 kg 482 kg 200 mm 16 mm THIS MODEL FORMS THE BASIS OF THE ENTIRE SYSTEM. IT CAN BE EXTENDED ON ALL FIVE SIDES AS REQUIRED. Our tables are characterised by the high degree of hardness with our Cr75M+ hard chrome plating, the very high degree of accuracy of +/- 0.05 mm on the entire table surface and the tolerances of the hole diameters of the entire hole pattern. 3D standard welding and clamping table, 2400 x 1200 x 100 mm with Cr75M+ hard chrome plating Pgsdpfxsyq Sr Es Akqer Table system: 16 mm Material thickness: 12 mm Including table substructure and standard table legs * S355J2+N with Cr75M+ hard chrome plating * Hole: 16 mm, material thickness: 12 mm * Including coated table substructure * Side panel 100 mm with 2-row hole pattern and 25 mm hole spacing * Table top with 2-sided fine scaling and 50 x 50 mm grid line * Rounded edges and holes * Solid standard table legs with load capacity 1 tonne per leg; 500 kg per leg for castor model

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 4400 € 2400 x 1200 mm 850 mm 8000 kg 945 kg Pgsdpfxewiriij Akqor 200 mm 28 mm - Fully milled table top 25 mm in S355J2+N with high degree of accuracy (+/- 0.05 mm) and rounded edges and holes - Hard chrome-plated table surface Cr75 The main advantage of our tables compared to conventional systems is with the hard chrome plating Cr75, that this process achieves a much deeper penetration into the base material of up to 0.07 mm and the hardness of the surface reaches up to HV750. This also ensures optimum and lasting anti-spatter adhesion on the surface, which is one of the most efficient on the market. - Exact dimensional and fitting accuracy of the tools with 28 mm perforation (compatible with comparable premium suppliers) - Grid lines 100 x 100 mm - 4 solid table feet withload capacity 2 ton/feet and levelling option - Different foot variants available (standard, height-adjustable and with castors) - Load capacity 8 to - All-round 200 mm high side cheeks with diagonal perforation - 2-sided millimetre scaling - Substructure with stiffeners

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 4862 € 3000 x 1500 mm 3000 kg 755 kg 100 mm 12 mm 16 mm THIS MODEL FORMS THE BASIS OF THE ENTIRE SYSTEM. IT CAN BE EXTENDED ON ALL FIVE SIDES AS REQUIRED. Our tables are characterised by the high degree of hardness with our Cr75M+ hard chrome plating, the very high degree of accuracy of +/- 0.05 mm on the entire table surface and the tolerances of the hole diameters of the entire hole pattern. 3D standard welding and clamping table, 3000 x 1500 x 200 mm with Cr75M+ hard chrome plating Table system: 16 mm Material thickness: 12 mm Psdsyq Srlspfx Akqsgr Including table substructure and standard table legs * S355J2+N with Cr75M+ hard chrome plating * Hole: 16 mm, material thickness: 12 mm * Including coated table substructure * Side panel 200 mm with 2-row hole pattern and 25 mm hole spacing * Table top with 2-sided fine scaling and 50 x 50 mm grid line * Rounded edges and holes * Solid standard table legs with load capacity 1 tonne per leg; 500 kg per leg for castor model

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 3420 € 2000 x 1000 mm 850 mm 8000 kg 712 kg 200 mm 28 mm - Fully milled table top 25 mm in S355J2+N with high degree of accuracy (+/- 0.05 mm) and rounded edges and holes - Hard chrome-plated table surface Cr75 The main advantage of our tables compared to conventional systems is with the hard chrome plating Cr75, that this process achieves a much deeper penetration into the base material of up to 0.07 mm and the hardness of the surface reaches up to HV750. This also ensures optimum and lasting anti-spatter adhesion on the surface, which is one of the most efficient on the market. - Exact dimensional and fitting accuracy of the tools with 28 mm perforation (compatible with comparable premium suppliers) - Grid lines 100 x 100 mm - 4 solid table feet withload capacity 2 ton/feet and levelling option - Different foot variants available (standard, height-adjustable and with castors) - Load capacity 8 to - All-round 200 mm high side cheeks with diagonal perforation - 2-sided millimetre scaling Pjdpfx Ajwir A Nekqsgr - Substructure with stiffeners

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 2860 € 1500 x 1000 mm 850 mm 8000 kg 541 kg 200 mm 28 mm - Fully milled table top 25 mm in S355J2+N with high degree of accuracy (+/- 0.05 mm) and rounded edges and holes - Hard chrome-plated table surface Cr75 Pgodowiripopfx Akqjr The main advantage of our tables compared to conventional systems is with the hard chrome plating Cr75, that this process achieves a much deeper penetration into the base material of up to 0.07 mm and the hardness of the surface reaches up to HV750. This also ensures optimum and lasting anti-spatter adhesion on the surface, which is one of the most efficient on the market. - Exact dimensional and fitting accuracy of the tools with 28 mm perforation (compatible with comparable premium suppliers) - Grid lines 100 x 100 mm - 4 solid table feet withload capacity 2 ton/feet and levelling option - Different foot variants available (standard, height-adjustable and with castors) - Load capacity 8 to - All-round 200 mm high side cheeks with diagonal perforation - 2-sided millimetre scaling - Substructure with stiffeners

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 2022 € 1500 x 1000 mm 3000 kg 272 kg 100 mm 12 mm 16 mm THIS MODEL FORMS THE BASIS OF THE ENTIRE SYSTEM. IT CAN BE EXTENDED ON ALL FIVE SIDES AS REQUIRED. Our tables are characterised by the high degree of hardness with our Cr75M+ hard chrome plating, the very high degree of accuracy of +/- 0.05 mm on the entire table surface and the tolerances of the hole diameters of the entire hole pattern. 3D standard welding and clamping table, 1500 x 1000 x 100 mm with Cr75M+ hard chrome plating Podpsyq Srxofx Akqjgr Table system: 16 mm Material thickness: 12 mm Including table substructure and standard table legs * S355J2+N with Cr75M+ hard chrome plating * Hole: 16 mm, material thickness: 12 mm * Including coated table substructure * Side panel 100 mm with 2-row hole pattern and 25 mm hole spacing * Table top with 2-sided fine scaling and 50 x 50 mm grid line * Rounded edges and holes * Solid standard table legs with load capacity 1 tonne per leg; 500 kg per leg for castor model

Condition: new, neu ca. 2 - 4 Wochen ab Auftr 2697 € 2000 x 1000 mm 3000 kg 348 kg 100 mm 12 mm 16 mm THIS MODEL FORMS THE BASIS OF THE ENTIRE SYSTEM. IT CAN BE EXTENDED ON ALL FIVE SIDES AS REQUIRED. Our tables are characterised by the high degree of hardness with our Cr75M+ hard chrome plating, the very high degree of accuracy of +/- 0.05 mm on the entire table surface and the tolerances of the hole diameters of the entire hole pattern. 3D standard welding and clamping table, 2000 x 1000 x 100 mm with Cr75M+ hard chrome plating Table system: 16 mm Material thickness: 12 mm Including table substructure and standard table legs * S355J2+N with Cr75M+ hard chrome plating * Hole: 16 mm, material thickness: 12 mm Pjdpeyq Srrefx Akqsgr * Including coated table substructure * Side panel 100 mm with 2-row hole pattern and 25 mm hole spacing * Table top with 2-sided fine scaling and 50 x 50 mm grid line * Rounded edges and holes * Solid standard table legs with load capacity 1 tonne per leg; 500 kg per leg for castor model

Condition: excellent (used), Separator screen, slotted screen basket, slotted screen baskets, replacement basket, replacement baskets, separator basket, separator slotted screen, separator filter grid, separator grid, separator screen for slurry separator, round screen, slotted screen Pedpswx E Taofx Akqsgr -Slotted sieve: Separator sieve -Inner diameter: 129 mm -Dimensions: Ø 136 x 800 mm -Weight: 3.8 kg

Condition: used, Year of construction: 2022, total height: 2,400 mm, total length: 5,300 mm, total width: 2,350 mm, Colour: Grey Empty weight: 4.000 kg What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Year: 2022 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 30B.11.040.22 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 4 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 11 - Type milling table: Beam table - Tool holder: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 4 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Tool changer positions [pcs.]: 12 - System/software: WoodFlash - Safety feature: Safety light curtain - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: PICCHIO 2200 - └ Year of manufacture: 2022 - Tools included: Yes - CNC options: Manual control - CNC documentation available: User keys/licenses, USB stick - Table length [mm]: 3300 - Table width [mm]: 1280 - Working range X [mm]: 3300 - Working range Y [mm]: 1280 - Z-axis working range [mm]: 250 - X-axis maximum stroke [mm]: 4000 - Y-axis maximum stroke [mm]: 1670 - Z-axis maximum stroke [mm]: 500 - Voltage [V]: 400 - Current consumption [A]: 40 - Power [kW]: 18.0 - Installed length [mm]: 6250 - Installed width [mm]: 3494 Pgjdpezwul Hofx Akqjr - Installed height [mm]: 2300 - Transport dimensions: 5300mm x 2350mm x 2400mm (l x w x h) - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2002, MOSCA KZD-311 – Fully Automatic Pallet Strapping Machine Used, fully automatic MOSCA KZD-311 pallet strapping machine for vertical strapping of palletized products. The system is designed for integration into automated conveyor and packaging lines. Technical data: • Manufacturer: MOSCA Verpackungstechnik • Type: KZD-311 • Machine No.: 67045 • Year of manufacture: 2002 • Design: Fully automatic pallet strapping machine • Performance: Up to 61 pallets/hour • Strapping: 2 vertical straps per pallet Pgedezwqxpopfx Akqor • Passage width: 1,400–2,400 mm • Grid: 3/N/PE • Operating voltage: 400/230 V AC • Frequency: 50 Hz • Connected load: 6.5 kW • Rated current: 20 A • Control voltage: 24 V DC

Condition: used, Year of construction: 2007, Second-hand machine Year of manufacture: 2007 Features and technical specifications: Nesting system with grid table Machining dimensions: - X: 5000 mm - Y: 1240 mm - Z: 135 mm Pgedpszk Nvgefx Akqer Travel ranges: - X: 5665 mm - Y: 1650 mm - Z: 325 mm with milling unit 7933: - Motor 11 kW (S6) - HSK 63 - water-cooled with C-axis with 18-position disc-type tool changer with 250 m³ vacuum pump with manual control unit with central lubrication with minimum quantity lubrication system Availability: at short notice Location: Röllbach

Condition: used, Year of construction: 2019, Holz-Her Dynestic 7532 10.5 automatic CNC nesting machining center with Holz-Her Store-Master 5110 panel storage system Used machine Year of manufacture: 2019 Features and Technical Specifications: - Designed for classic nesting machining with a wear plate - Welded machine frame with ground and hardened prismatic guides for the traveling column, toolhead, and consoles - Gantry-style moving column - Rack-and-pinion drive, helical teeth, in the X and Y directions; ball screws in the Z direction for precise positioning - Machining dimensions: - Max. support area on nesting table: X = 3100 mm Y = 1560 mm - Max. travel ranges: X = 4695 mm Y = 2100 mm Z = 293 mm - Max. clearance height of DYNESTIC table Z = 100 mm from top edge of table (without wear plate) - Maximum programmable speed Vector speed: 128 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min - DYNESTIC table: - Rigid, continuous machining table with grid markings - continuous slots in the X and Y directions - Slot spacing: 50 mm - Includes 25 meters of sealing cord for securing the wear plate - Vacuum fields: 1-circuit vacuum system - Drilling unit 7877: - 19 spindles - Drive power: 1.7 kW - 13 vertical spindles: - individually controllable - U-shaped arrangement - 5 in the X direction and 4 in the Y direction - 32 mm pitch - max. drill bit diameter: 35 mm - Total drill length: 70 mm from the mounting end (depending on panel thickness) - Spindle extension stroke: 70 mm - Rotation direction: Alternating clockwise and counterclockwise - n(max): 1000–4400 rpm, continuously adjustable - Mounting: M10 thread – 11 mm interference fit - Tool-free, without mounting adapter - 6 horizontal spindles: - 2 double drilling spindles in the X direction - 1 double drilling spindle in the Y direction - Mounting: M 10 thread, 11 mm interference fit - Total drill length: max. 63 mm from mounting end - Tool-free, without chuck - Milling unit 7842: - Power: 12.0 kW (S6) - n(max) = 1,000–24,000 rpm, continuously variable - Max. power at 12,000 rpm to 24,000 rpm - Air-cooled - With HSK-F 63 tool holder - With right-hand threaded nut (for right-hand rotating tools) - With collet chuck with HSK shank - Ceramic ball bearings (hybrid bearings) - Max. tool weight: 6 kg (including holder) - Tools: Milling and grinding tools, max. Ø 160 mm - Safety guarding in accordance with CE standards - Protective fencing on the sides and rear - Vacuum pump: 500 m³/h, dry-running - Operator safety via light curtains in the front area of the machine - Handheld control unit for remote control of the machine with the following operating functions: - Start/Stop of the machining program - Speed control of the machining cycles - Reset button - Manual feed/rapid traverse for all axes - Emergency Stop - CAMPUS V7 CAD/CAM software, 1 machine license consisting of: - CAMPUS NC-HOPS: - Graphical variant system with WOP and CAD/CAM features for creating part variants using macro technology - CAMPUS MT-Manager - CAMPUS Workcenter - CAMPUS DXF interface - Automatic centralized lubrication - Automatic lubrication according to defined lubrication intervals - Additional dust sealing via positive pressure in each guide carriage Pgedpfx Akjzlbrpoqsr - Simultaneous lubrication: - for all linear guides in the X, Y, and Z directions - for all ball screws in the Y and Z di...

Condition: used, Year of construction: 2019, Second-hand machine Year of manufacture: 2019 Only 110 operating hours! Features and technical specifications: Machining paths: - X = 1800 mm - Y = 900 mm - Z = 80 mm Made from 18 mm Koskisen boards Milling bed made from 19 mm MDF as a sacrificial plate with guide rails and slot blocks, used as a clamping method. Base frame with bracing, cast in polymer concrete, prepared for transport by pallet truck or forklift. Mechanical kit comprising profile guides including guide carriages, as well as ball screws 2010 and 1605 for all axes. Shaft couplings and high-performance grease for lubricating the individual carriages, as well as energy chains including connection sets. Control kit comprising a Triple Beast for controlling 3 axes, with an Ethernet connection. Leadshine driver board for the fourth motor. Four stepper motors, 5.0 A, 3 Nm, with motor cables, plus a switching power supply rated at 48 V, 6.7 A, LED board for breakout board, ribbon cable and proximity sensors, small parts such as wires, wire end ferrules, control cable, heat-shrink tubing and cable lugs. Fully installed in an aluminium housing, including electrical kit and emergency stop. - 21.5-inch monitor as a built-in display, including a mini PC with Windows 7, Rhino 5.0 CAD software, Estlcam G-code generator, Beamicon2 control software, as well as a mouse and keyboard, pre-installed in an ergonomic console. Tool length sensor for determining the length and adjusting the active zero-point offset. Optional extras: - High-frequency spindle with 2.2 kW, including union nut, frequency converter, mains filter, braking resistor and collet set. Pgsdpfx Aszk Npgjkqsr - PC with 8 GB RAM and AMD processor - Rhino 5.0 CAD software for creating both simple 2D data and 3D solid models Availability: at short notice Storage location: Flörsheim

Condition: ready for operation (used), Year of construction: 2001, travel distance X-axis: 2,800 mm, travel distance Y-axis: 1,252 mm, travel distance Z-axis: 200 mm, number of axes: 3, spindle speed (max.): 24,000 rpm, This 3-axis Weeke OPTIMAT BP 120 was manufactured in 2001. It features a working area of 2800 mm in the X direction, 1252 mm in the Y direction, and 200 mm in the Z direction. The machine includes an automatic tool changer with an 8-position tool magazine and a maximum spindle speed of 24,000 rpm. If you are looking to get high-quality CNC wood machining capabilities, consider the Weeke OPTIMAT BP 120 machine we have for sale. Contact us for further details. • CNC software: HOMAG WOODWOP 4.0 • Electrical: 400 V, 50 Hz, 3~ + N; rated current 32 A; control/aux voltage 24 V; fuse rating 35 A • Automatic tool changer: Yes; tool magazine capacity: 8 positions Pgodpfxezwnh Ue Akqer • Table: Console / Pod & Rail; table length 3260 mm; number of consoles: 6 • Main spindle: quantity 1; tool holder HSK-F63 • Drilling spindles: vertical 21; horizontal (X) 4; horizontal (Y) 2 • Grooving saw: X direction • Material clamping: Vacuum clamping; vacuum system: Yes

Condition: new, Year of construction: 2026, functionality: fully functional, machine/vehicle number: RR500FB, conveyor belt length: 5,000 mm, conveyor belt speed: 800 mm/s, total length: 5,250 mm, total width: 1,250 mm, total height: 1,900 mm, overall weight: 105 kg, discharge height: 1,900 mm, power: 0.37 kW (0.50 HP), input voltage: 230 V, input frequency: 50 Hz, input current: 16 A, SCHORR Firewood Conveyor Belt, Electric, 5m, 230V Directly from the splitter to the trailer Anyone who makes firewood knows the time-consuming task: it's not the splitting that strains your back, but the bending, collecting, and throwing afterward. The electric SCHORR conveyor belt takes over precisely this step: the logs fall directly from the splitter onto the belt or are simply placed on it unsorted; the cleats and the conveying trough safely guide them upwards, and in the end, they end up where they belong: on the trailer, in the container, or in the grid box. With a belt speed of 0.8 m/s, the belt easily keeps pace with the splitter and saw. You continue working at your own pace, and the belt clears away behind you: stacking instead of hauling. 5 meters in length, up to 1.9 meters discharge height Five meters of conveying distance and a discharge height of up to 1.9 meters: this allows you to fill high sideboards, grid boxes, and containers without lifting a single log by hand. The installation angle can be used up to a 19° inclination, and up to 100 kg can be placed on the belt at the same time. The trough-shaped conveying trough (390 mm wide at the top) keeps the logs in line, and the cleats reliably carry them along, even uphill. And the belt can be set up quickly: you can easily pull it to the next work location using the two wheels, and you can adjust the discharge height using the height-adjustable support stand. This ensures a continuous supply of logs, from the first to the last log of the load. Socket instead of high voltage Pjdpfx Aszwm Dnekqjgr The 370-W electric motor runs on any standard 230-V socket: no high-voltage connection, no gasoline, no noise, no exhaust fumes. This means that the conveyor belt can also be used in the hall, barn, or at the house connection, where internal combustion engines and 400-V devices would be unsuitable. The technology behind it is deliberately kept simple: robust PVC belt, solid frame construction, few wear parts, easy to maintain and repair. And if something does happen: wear and spare parts are in stock, and we carry out repairs in our own workshop. You buy directly from the manufacturer and receive personal advice. Technical data Manufacturer: SCHORR Model: RR500FB Type: Belt conveyor with cleats Drive: Electric, 230 V / 50 Hz Motor power: 370 W Conveying length: 5000 mm Max. discharge height: 1900 mm Max. inclination: 19° Max. belt load: 100 kg Belt speed: 0.8 m/s Belt: PVC, 100 mm wide Cleat height: 30 mm Conveying trough (top / bottom): 390 / 104 mm Switch: 230 V, 16 A Cable length: 1,850 mm Dimensions (L × W × H): 5,250 × 1,250 × 1,900 mm Weight: 105 kg

Condition: ready for operation (used), Year of construction: 2015, travel distance X-axis: 4,200 mm, travel distance Y-axis: 1,550 mm, travel distance Z-axis: 270 mm, number of axes: 5, spindle motor power: 10,000 W, spindle speed (max.): 24,000 rpm, This 5-axis HOMAG V BMG 311/42/F/K Venture was manufactured in 2015. It features a working dimension of 4,200 mm in X, 1,550 mm in Y, and 270 mm in Z. The machine is equipped with a powerful 10 kW main motor and a maximum rotation speed of 24,000 rpm. If you are looking to get high-quality CNC wood machining capabilities, consider the HOMAG V BMG 311/42/F/K Venture machine we have for sale. Contact us for further details. • Tool clamping: HSK-F63 • Tool changer: 18 positions • Vertical drilling spindles: 17 • Horizontal drilling spindles: X = 2, Y = 2 • Groove saw: 90° turnable • Machine type: Gantry • Machine table: Pod and rail • Number of consoles: 6 • Positioning aid • Crosshair laser • Vacuum pumps: 2 units, total capacity 180 m³/h • Safety device: Bumper • Stops: Two rows of stops Pgjdpfx Akjzwmu Teqor • Workpiece support aids: Stop for top layer protrusion • Control: HOMAG powerTouch • Software: HOMAG WOODWOP 7.0 • Declaration of CE-conformity

Condition: ready for operation (used), Year of construction: 2023, travel distance X-axis: 3,710 mm, travel distance Y-axis: 1,620 mm, number of axes: 5, spindle motor power: 13,500 W, spindle speed (max.): 24,000 rpm, This 5-axis SCM Morbidelli M100 CNC Wood Machining Centre was manufactured in 2023. It features an impressive X-axis working range of 3,710 mm and a Y-axis working range of 1,620 mm. The machine is equipped with a 5-axis milling unit and a drilling unit with 13 vertical spindles, providing versatile woodworking capabilities. If you are looking to get high-quality woodworking capabilities, consider the SCM Morbidelli M100 machine we have for sale. Contact us for further details. • Working area • Max. panel loading width / Y passage: 2,200 mm • Z-axis workpiece passage: 250 mm Pedezwfnxspfx Akqjgr • Pendulum working length: 1,700 + 1,700 mm • X+Y vector speed PRO-SPACE: 56 m/min • X+Y vector speed PRO-SPEED: 78 m/min • PRO-SPACE safety configuration: X-axis limited to 25 m/min for operator safety • 5-Axis Milling Unit – JQX • 5-axis JQX electrospindle, HSK 63F • B-axis rotation: ±185°, speed: 7,000°/min • C-axis rotation: ±320°, speed: 7,000°/min • Programmable CW/CCW rotation, ceramic bearings, liquid-cooled • Automatic extraction hood: 3 positions + excluded position • Drilling Unit – F23L • 13 independently selectable vertical spindles • 5 horizontal drilling heads with double output (3 in X, 2 in Y) • Drilling spindle speed: 4,200 rpm (standard) / 3,000–8,000 rpm (with inverter) • Integrated saw blade in X; max diameter 125 mm; thickness 2.2–6 mm • Blade speed: 5,000 rpm (standard) / up to 10,000 rpm (with inverter) • Drilling motor power: up to 3.9 kW • Max drill length: 70 mm; spindle spacing: 32 mm; Weldon Ø10 mm tool connection • High-pressure air assistance: >64 kgf per spindle • Tool magazines (total up to 28 positions) • TRB14: 14 tools; max tool Ø 300 mm (3-axis) / 350 mm (5-axis); max tool weight 8 kg • FAST14: 14 tools; max Ø 225 mm (saw) / 180 mm (circular tools/angle aggregates); max tool weight 8 kg • Worktable and clamping • 6 × TV FLEX 1600 tables/bars; pneumatic lock/unlock • Automatic reference stops: 6 rear, 6 intermediate, 4 lateral • Additional front stops H=75 • 4 pneumatic panel lifting devices H=75 • Pendulum machining capability • Vacuum clamping system • Vacuum equipment • Vacuum pump: 250 m³/h • 18 fixed cups: 145 × 145 mm, H=75 mm • 6 rotating cups: 145 × 55 mm, H=75 mm • Measuring / positioning • Automatic tool length sensor • Dual laser positioning (one projector per working area) • Automatic workpiece positioning references • Control & software • Maestro Active CNC HMI; Maestro CNC CAD/CAM • DXF import; PGM import / conversion to PGMX • Parametric programming; Tool Manager; Maestro APPS • Graphical worktable setup; collision checking; cycle-time estimation • Remote assistance capability; network connection • Operator console • eye-M PRO integrated industrial PC, 21.5" Full HD touchscreen (1920 × 1080) • Intel i7 2.80–3.60 GHz; 8 GB DDR4 RAM; 500 GB HDD • Ethernet RJ45; USB 3.0 • Wired TECPAD 7" remote control; cable length 6.5 m • Installation data • Installed power: 23–28.5 kVA; 400 V; 50 Hz; 3 phases • Air consumption: 450 Nl/min • Extraction air speed: 30 m/s; extraction connection Ø 250 mm Additional equipment • Tool holders and collets: not included in the offer • No other external accessories (robots, automation, chip conveyor, bar feeder, etc.) are specified as included

Condition: used, Year of construction: 2022, SCM Morbidelli N100 22-31 PROSPACE Year of manufacture: 2022 Condition: Used, recently serviced Machine type: CNC machining center Model: 22-31 PROSPACE Machine weight: approx. 4,000 kg Work table: Complete nesting table Technical data 3-axis CNC machining center 9.5 kW electric spindle HSK tool clamping system 13-position linear tool changer, automatic Drilling unit Complete work table for nesting applications 2 vacuum pumps Podpfozwfivex Akqegr Automatic tool length measurement TECPAD control panel SCM Maestro software 3 software licenses: Maestro Base Maestro Nesting Maestro Freeform Application areas Nesting Drilling Milling and contour machining Freeform machining Complete CNC machining of panels and components Included in the scope of supply Complete nesting table 9.5 kW electric spindle Drilling unit 2 vacuum pumps TECPAD control panel 13-position HSK linear tool magazine Automatic tool length measurement system SCM Maestro software with Base, Nesting, and Freeform licenses

Condition: good (used), functionality: fully functional, Year of construction: 2018, control type: CNC control, laser power: 8,000 W, CNC laser cutting system TruLaser 5030 Fiber (L68) 8000 Watt with LiftMaster X working area max.: 3000 mm Y working area max.: 1500 mm Z working area max.: 115 mm Control system: Siemens Sinumerik 840D SL Laser power: 8000 Watt Standard equipment: Machine - Enclosed machine frame - Power supply for TruDisk integrated into the machine - Torque drive in combination with linear direct drives - Enclosed beam guidance via laser light cable (LLC) - Machine cooling unit (water-air) - Integrated control cabinets - Integrated cabinet - Automatic pallet changer in longitudinal direction - Longitudinal conveyor - Work area lighting - Positioning laser diode - Spray device - PierceLine - FocusLine - NitroLine - PlasmaLine - Automatic nozzle cleaning TRUMPF laser - Solid-state laser TruDisk 4001 with one LLC outlet - LLC according to standard layout (cable directly next to the machine) - Laser cooling unit (water-air) - Excitation via pump diodes - Laser power control The TruDisk laser is subject to international export control. According to EC Dual-Use Regulation 428/2009 (laser covered under 6A005). Cutting head - Universal cutting unit with fully adaptive lens system - Single cutting head strategy - Protective glass against lens contamination - Online condition monitoring of the protective glass - ControlLine: Height control and sheet edge detection Control system - SINUMERIK 840D SL control system - Simple workshop programming - Fast reproduction - Integrated technology data - Automatic shutdown - Programmable cutting gas/pressure selection - FastLine - FlyLine - Microweld - AdjustLine - Multi-sheet processing - Condition Guide - Extended machine sensor system for Condition Guide - 19" touch color screen Data transfer - USB interface - RJ-45 network connection - Central Link - Wireless Operation Point (basis for Visual Online Support) Safety - CE marking - Light curtains - Multi-chamber extraction system - Compact dust extraction system - Machine cladding, certified viewing window, door on the right - Electric roll-up roof + Solid-state laser TruDisk 8001 with 1 LLC outlet - BrightLine fiber - High-speed cutting package - Smart Beam Control (intelligent beam monitoring) - Performance package for fusion cutting + Smart Nozzle Automation - Nozzle changer - Automatic nozzle inspection Pgodpfx Akszv Trvsqsr + High-speed cutting package Eco + Integrated camera 1 for process monitoring (view of the first 2.5m) + CoolLine + Copper cutting package (includes cutting data) + Brass cutting package (includes cutting data) Automation + Basic LiftMaster unit - incl. stainless steel grid (tine spacing 67mm, interchangeable tines), suction frame, stripping device, double sheet detection, symmetrical arrangement) + Loading station - for stack height up to 200mm + Separation of thin sheet metal - Available for sheet thicknesses s = 0.8-2.0mm + Unloading platform + Loading platform + Right-hand arrangement

Condition: new, Year of construction: 2025, Grid / Mesh Welding Machine Type KMP180 CE certified Operated: Pneumatic Pressure: 4-8 bar Power: 180KVA Welding Capacity(mesh/grid): (4+4mm mild steel) 4 wire same time Water-cooled Transformer Construction: Primary winding: Copper wire Pgodpfx Ajuy U Hwekqor Secondary winding: Copper bar Core: Silicon steel EI core Epoxy resin coated transformer Maximum Force: 305-610 daN Input Voltage: 380V/50Hz Protection Fuse: 300A Power Level: %0-99 power adjustable by digital microcontroller Weld Time: 1-99 Cycle (20ms - 2s) adjustable by digital microcontroller Arm Length: 550mm Cooling: Water cooling (30L/min) Power Input Cable: 3m Protection Class: IP21 Dimensions (W/L/H): 4500m x3500mm x 2150mm Weight: 2850Kg

Year of construction: 1989, condition: ready for operation (used), travel distance X-axis: 2,500 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 800 mm, controller manufacturer: HEIDENHAIN, controller model: iTNC 530, overall weight: 50,000 kg, spindle motor power: 65,000 W, spindle speed (max.): 2,000 rpm, table length: 2,500 mm, table load: 25,000 kg, table width: 2,000 mm, tool weight: 40,000 g, number of slots in tool magazine: 40, swivel angle B-axis (max.): 360 °, number of axes: 6, This 6-axis DÖRRIES SCHARMANN Heavycut 1.2 TDV4 was manufactured in 1989. It features an impressive X-axis travel of 2,500 mm, Y-axis travel of 2,500 mm, and Z-axis travel of 800 mm. The machine includes a robust table size of 2,000 x 2,500 mm with a maximum table load capacity of 25,000 kg. If you are looking to get high-quality boring capabilities, consider the DÖRRIES SCHARMANN Heavycut 1.2 TDV4 boring machine we have for sale. Contact us for further details. Pedpfxozv Ruhs Akqsgr Technical Specifications * Control: Heidenhain iTNC 530* X-Axis Travel: 2,500 mm* Y-Axis Travel: 2,500 mm* Z-Axis Travel: 800 mm* W-Axis Travel: 700 mm* V-Axis Travel: 1,500 mm* B-Axis: 360°* Work Spindle Diameter: 150 mm* Tool Holder: ISO 50 DIN 2079* Number of Gear Stages: 3* Table Size: 2,000 × 2,500 mm* Table Height: 1,050 mm* Table Load Capacity: 25,000 kg* V-Axis Feed Rate: 1–10,000 mm/min* B-Axis Feed Rate: 2.4 rpm* X/Y/Z/W Rapid Traverse: 10,000 mm/min* X/Y/Z/W Feed Rate: 1–10,000 mm/min* Gantry Beam Cross-Section: 325 × 325 mm* Tool Magazine: Chain Magazine* Tool Magazine Capacity: 40 tools* Max. Tool Diameter: 340 mm* Max. Boring Bar Diameter: 500 mm* Max. Tool Length: 500 mm* Max. Tool Weight: 40 kg* Tool Magazine Rapid Speed: approx. 40 m/min* Tool Magazine Creep Speed: approx. 1.2 m/min* Coolant System: Coolant through spindle* Coolant System: External coolant nozzles* Coolant Filtration: Paper band filter* Process Monitoring: Adaptive Control* Handwheel: HR 550 FS* DNC: Heidenhain DNC* Load Adaptive Control: Yes* KinematicsOpt: Yes* Global Program Settings: Yes* HDR and SIK: Yes Additional equipment / accessories * WFK 100 S* WFK 50 S* Automatic mounting of milling head* Automatic milling head clamping* Milling head drive via controlled shaft* Tool cooling with 4 nozzles* Chip conveyor* Torque monitoring* Position displays Retrofit / Modernization in 2013 * CNC Control: Heidenhain iTNC 530* 19" TFT colour flat-panel display BF 760* TE 745 TouchPad with integrated machine control panel* HR 550 FS electronic handwheel with grid and connection components* HDR and SIK* Global Program Settings* KinematicsOpt* Load Adaptive Control* Heidenhain DNC Technical Specification Taper Size ISO 50 Through-spindle Coolant Yes

Condition: new, empty load weight: 2,900 kg, maximum load weight: 7,600 kg, overall weight: 10,500 kg, axle configuration: 2 axles, loading space length: 6,200 mm, loading space width: 2,480 mm, suspension: steel, tire size: 245 / 70 R 17,5, wheelbase: 990 mm, color: other, gearing type: other, front tire size: 245 / 70 R 17,5, rear tire size: 245 / 70 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Loading height approx. 890 mm, vehicle interior width approx. 2,480 mm, front panel made of galvanized steel, 600 mm aluminum sideboards, foldable and removable, removable posts, 40 mm wooden floor, 3 post pockets in the center for plug-in posts 80 x 80, 6 tie-down points, outer frame with tie-down eyes, reinforced transmission support with load and fast gear, contour marking and side impact protection, mudguards and spray suppression, at the rear, surcharge for front panel grid 1,600 mm high (perforated sheet metal), price: 1,400 euros, surcharge for aluminum ramps, load capacity per pair 8 tons, and 2 folding supports at the rear, price: 1,900 euros, -- printing errors, mistakes and changes reserved, sample images --, more data under: !, More Details: ! Pjdpfxozv Ncke Akqegr

Condition: used, Year of construction: 2015, operating hours: 19,402 h, total height: 2,250 mm, total length: 2,500 mm, total width: 1,900 mm, Colour: White Empty weight: 1.600 kg Price: On request - Year: 2015 - Documentation available: Yes - └ Type Documentation: User manual, Electrical diagrams, Technical data, Operating system - CE marking present: Yes - CE certificate present: No - Serial number: AB/224221 - Operating hours: 19402 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 1 - - Max. spindle speed [rpm]: 18000 - - Main motor power [kW]: 5.6 - Type milling table: Flat table - Tool holder: ISO30 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Motor power [kW]: 2.64 - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 11 - Saw unit present: Yes - Tool changer positions [pcs.]: 0 - System/software: SCM Maestro - Safety feature: Door interlock switches, Safety light curtain - Tools included: Yes - CNC options: Barcode reader, Manual control - CNC documentation available: USB stick, User keys/licenses - Table length [mm]: 3960 - Table width [mm]: 840 - Working range X [mm]: 3050 - Working range Y [mm]: 900 - Z-axis working range [mm]: 60 - Voltage [V]: 400 - Current consumption [A]: 35 - Fuse [A]: 63 - Power [kW]: 10.0 - Installed length [mm]: 4500 - Installed width [mm]: 1900 - Installed height [mm]: 2250 - Transport dimensions: 2500mm x 1900mm x 2250mm (l x w x h) - Transport weight [kg]: 1600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Pgodpfxszmvftj Akqsr Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Pgsdpoxwaz Hofx Akqjr
