Used Gear Griding Machine for sale (91,389)

Condition: used, Year of construction: 2004, workpiece diameter 125 mm module 4 control SIEMENS SINUMERIK travel -x axis 105 mm travel -y axis 40 mm travel -z axis 500 mm workpiece diameter 17 - 39,5 mm Dedpfx Afox Szm Ajnjkg workpiece height 6 - 15 mm Gear Honing Machine | GLEASON-HURTH - ZH 125 The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: ZH125 | ZH-125

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, table bore: 80 mm, table diameter: 145 mm, gear diameter: 125 mm, controller manufacturer: Siemens, controller model: SINUMERIK 840 D, TECHNICAL DETAILS Working Area Maximum wheel diameter: 125 mm Maximum module: 3 Maximum gear width (spur gears): 24 mm Centre distance: -25 to +180 mm Dsdpewyn Amofx Afnjkg Maximum swivel angle: 12° Maximum helix angle: 45° Table Table diameter: 145 mm Table bore: 80 mm Infinitely variable table speeds: 0.03 – 50 rpm Shaper Spindle Strokes (double strokes): 1,500 – 3,000 DS/min Stroke position adjustment: 70 mm Stroke length min./max.: 0 – 30 mm Shaper spindle diameter: 85 mm Cutter holder interface: HSK 80 B Tool and Workpiece Tool number of teeth: 1 – 200 Minimum tool module: 0.05 Workpiece number of teeth: 1 – 1,500 Minimum workpiece module: 0.05 Control Control system: SINUMERIK 840 D MACHINE DETAILS Electrical Data Drive power: 7.5 kW Total connected load: 30 kVA Weight and Dimensions Machine weight: approx. 8 t Space requirement: approx. 4.3 × 2.8 × 2.9 m EQUIPMENT Swiveling counter holder with 4 positions Automatic workpiece changer Linear workpiece conveyor

Condition: excellent (used), Year of construction: 1998, operating hours: 50,000 h, functionality: fully functional, Technical Data – Gear Grinding Machine Reishauer RZ 362A Machine type Gear Grinding Machine Manufacturer Reishauer AG, Wallisellen, Switzerland Model RZ 362A Year of manufacture 1998 Machine number 73889 Commission number 309 CE compliant Yes Electrical data Mains connection 3 x 400 V, 50 Hz Machine voltage 3 x 400 V, 50 Hz Control voltage 1 x 230 V, 50 Hz / 1 x 24 V DC Contactor voltage 1 x 24 V DC Valve voltage 1 x 24 V DC Electrical diagrams standard Grinding wheel dimensions Minimum / maximum outside diameter 280 / 350 mm Maximum width with limitations 84 / 104 mm Number of starts with limitations up to 3 Maximum usable width (with shifting motion) 90 mm For module > 7 or more than 3 starts, Reishauer guidelines apply Grinding wheel speeds Djdpox Sxbdefx Afnjkg During grinding 1,100 – 2,300 rpm During profiling 50 – 95 rpm During setup (special mode) max. 200 rpm Grinding infeed In grinding mode per grinding stroke 0.01 – 1.0 mm Total infeed (fx tot) 9.99 mm In setup mode (special mode) max. 2 m/min Grinding stroke Maximum grinding stroke 175 mm Automatic grinding wheel return stroke for workpiece change 65 mm Shifting movement Maximum shifting travel continuous shifting per 1 mm grinding stroke 0 – 1.0 mm Workpiece data Minimum workpiece pitch diameter depending on grinding wheel diameter Grinding wheel Ø 280 mm: 50 mm Grinding wheel Ø 320 mm: 10 mm Grinding wheel Ø 350 mm: 10 mm Automatic centering with sensor (RZ 362A only): 20 mm Maximum workpiece outside diameter 360 mm With “Felsomat” loader (optional, RZ 362A only): 300 mm With automatic centering using sensor (RZ 362A only): 320 mm Minimum distance from grinding wheel center to workpiece center 165 mm Maximum face width 175 mm For pitch diameters < approx. 150 mm, face width is reduced due to clamping chuck and tailstock design Maximum workpiece weight 60 kg With “Felsomat” loader (optional, RZ 362A only): 4 kg Center distance Fixed manual tailstock (optional): 645 mm Special manual tailstock (optional): 745 mm Hydraulic tailstock (optional, RZ 362A only): 515 mm (645 mm with reduced grinding stroke) Gear data Number of teeth minimum 6, maximum 600 Module without automatic centering minimum module 0.5 (DP 48) Module with automatic centering minimum module 0.8 (DP 32) Maximum module 7.0 (DP 3.5) Helix angle Minimum 10° Maximum 40° Maximum inclination angle left and right 45° Shifting limitations apply for large helix angles, especially above 30° Crowning and profile modification Tip relief and crowning height Crowning length and taper Maximum modification depends on profiling tool and process data Weights (without oil filling) Machine weight approx. 5,000 kg Electrical cabinet approx. 1,100 kg Hydraulic unit approx. 600 kg Grinding oil unit RTO 100 (optional) approx. 1,600 kg Grinding oil unit RTM 100 with magnetic pre-filter (optional) approx. 1,650 kg Grinding oil unit RTA 150 (optional) approx. 2,500 kg “Felsomat” gantry loader (optional, RZ 362A only) approx. 1,600 kg Loading unit approx. 1,000 kg Workpiece storage approx. 400 kg

Condition: used, Year of construction: 1986, max. wheel diameter 150 mm max. module 5 min. module 0,5 weight of the machine ca. 10.000 t Dkedpfx Ajxzuziofnsg dimensions of the machine ca. 6500 × 2700× 3600 m

Condition: good (used), Year of construction: 2009, functionality: fully functional, Technical details max. wheel diameter 2-45 mm gear width 250 mm Dodpfx Asx Sqiyefnjkg max. module 1,5 mm min. module 0,5 mm Control Fanuc 18i-MB weight of the machine ca. 2,2 t dimensions of the machine ca. 2100 x 1440 x 1700 m Additional information The combined CNC gear hobbing and worm milling machine KOEPFER MZ 120 is characterized by its flexible usability and is used in the small module area. Just by swiveling the milling spindle from the horizontal to the vertical position and selecting the corresponding operating mode of the CNC control, the worm milling machine becomes a gear hobbing machine and vice versa. CNC control Fanuc 18i-MB (Dialog/ISO) CNC axes = X-axis plunge axis Z-axis longitudinal axis C-axis workpiece spindle B-axis tool spindle V-axis loader axis longitudinal A-axis swivel axis tool spindle head (included as an option) Y-axis shift axis (included as an option) With the following production programs: Worm milling Hobbing Worm hobbing Bevel gear and spur gear milling Bevel gear hobbing Milling cycles = straight, oblique, crowned toothing, radial, radial-axial, co- and counter-rotating milling, roughing, finishing, worm gears, straight-toothed bevel gears, face gearing (option only in the partial process) Worms [Equipment] Coolant tank 300 liters KF with LNS Turbo MS 250 Chip conveyor, built in 2021!!! Kraft and Bauer fire extinguishing system Spiral conveyor Machine documentation [Technical data] Workpieces: Workpiece diameter 2-45 mm Max. workpiece length 250 mm Tooth length 150 mm Max. module in steel= 1 mm (gear hobbing) 1.5 mm (worm milling) 0.5 mm (bevel gear hobbing) Tools: Cutter diameter= 16-32 mm (gear hobbing) 40-63 mm (worm milling) Machine: Max. setting angle of milling head= +/- 45° (gear hobbing) +/- 30° (worm milling) Shift travel= 34 mm (manual adjustment) 34 mm (CNC axis) Collet/retraction mandrel W 20 Max. speed of workpiece spindle 770 rpm. Milling spindle drive 0.55 kW Max. milling spindle speed 8000 rpm Axis drives = X-axis (plunging) / travel 80 mm via CNC Z-axis (longitudinal feed) / travel 190 mm via CNC C-axis (workpiece axis) via CNC Rapid traverse = X-axis 6000 mm/min. Z-axis 6000 mm/min. Hydraulic unit 0.37 kW

Condition: good (used), Year of construction: 2004, Ref. -No.: 10612 Manufacturer: LIEBHERR Type: LC 3002 Year of construction: 2004 Type of control: CNC Control: LIEBHERR Storage location: Halberstadt Country of origin: Germany Serial no.: 30XX Dedpfx Afjx R R E Eonskg Max. Module: 30 mm Min. Module: 4 mm Max. Workpiece Diameter: 3000 mm ambient temperature: +15...+38 ° cutting speed: 25 - 250 m / min Milling head swivel angle: 0,001 ° Resolution accuracy: 0,1 Degree Workpiece table load: 300 kN Operating voltage: 400 V control voltage: 24 V frequency: 50 Hz Max. rated current: 230 A Fuse in the supply line: 250 A Max. milling diameter spur gears/helical gears: 3.000 mm Further information: Suitable for internal and external gear cutting. The machine can be viewed by appointment.

Condition: good (used), Heavy-duty transport rollers, machine rollers, transport trolleys, heavy-duty trolleys, tank rollers, machine transport rollers steering gear -Manufacturer: Jung, Machine transport roller: Steering mechanism type JL 12 K -Load capacity: 12 t (with chassis approx. 24 t) -Support surface: Ø 170 mm -Support height: 110 mm -Chassis: 4 transport rollers in stock can be supplied for an additional charge, see ID 35936 -Transport dimensions: 970/950/H260 mm -Weight: 67 kg Djdpsww Uzksfx Afnskg

Condition: used, Year of construction: 2007, max. dia. of teeth cutting 2000 mm workpiece dia. 2700 mm Diameter of the table 1500 mm max. module 22 Control 840D turning speeds 3,5 U/min table load capacity 20000 KG Distance of shafts 70...1220 mm Stroke length 30...330 mm no. of strokes 10...200 Hub/min total power requirement 138 kW weight of the machine ca. 38 t dimensions of the machine ca. 11x5 m machine: Full CNC machine with electronic rolling coupling for C- and D-axes and digital INDRAMAT drive technology. Stiff machine bed in welded construction. Radial axis (X-axis) with hardened guideways, sliding guide with wraparound, longitudinal guide with roller recirculating shoes. Ground preloaded ball screw with play-free preloaded nut. Digital AC drive technology with play-free gearbox. Linear measurement system for radial positioning. Freestanding machine table with electrohydraulically play-free preloaded double worm gear, part wheel diameter 1365 mm, hydrostatic axial and radial bearings, automatic compensation of the workpiece weight. Table hole with a diameter of 500 mm through and open at the bottom. Water-cooled digital AC servo motors. The machine is to be installed on a foundation. Machine stand: as a highly rigid cast construction for axial travel of 1200 mm. Axial axis (Z-axis) with hardened guideways, slide-guided, longitudinal guide and wraparound with roller recirculating shoes. Ground ball screw with play-free preloaded nut. Digital AC drive technology. Encoder for axial positioning. Shapping head: SK 4.1 with hydraulic NC servo drive for impact spindle movement and cutting wheel lifting, stroke length 330 mm, impact spindle diameter 160 mm. Hydrostatically supported impact spindle, linear guide and lateral guide for the lifting mechanism. Maximum tool diameter 300 mm. Drive motor power 30 kW. Stroke rates from 10 - 200 DH/min, stroke speed from 5 - 45 m/min. Impact spindle speed for working and return stroke independently programmable. In the cutting area, the spindle speed remains constant. Maximum cutting wheel speed 10 rpm, digital AC drive technology. Cutting wheel lifting correction for internal and external gearing manually reversible. Dkodpfx Afox R U Hmjnog Lateral offset of the impact spindle axis up to 50 mm from the machine center to prevent return stroke collision of the cutting wheel, manually adjustable.

Condition: used, Year of construction: 2004, Technical details: max. wheel diameter: 130 mm gear width: 25 mm module max. : 3 Djdjvi Ninopfx Afnekg module min. : 0,5 control: Siemens 840D work-spindle diameter: 85 mm strokes - infinitely variable: 500 - 2500 Hub/min stroke: 30 mm total power requirement: 48 kVA weight of the machine ca.: 11,5 t space requirements approx. LxWxH: 4,7 x 3,0 x 3,3 m Equipment: -Counterholder with tip -chip conveyor -hydraulically operated counterholder arm and linear guides *

Condition: used, Year of construction: 1989, max. wheel diameter 150 mm max. module 5 min. module 0,5 Dksdpfx Afewhq Egsnog weight of the machine ca. 10.000 kg dimensions of the machine ca. 6500x 2700x 3600 m

Condition: ready for operation (used), functionality: fully functional, A used gear hobbing machine with a maximum workpiece diameter of 1250mm and maximum machinable module of 16. Cutter speed: 250 rpm, max. machinable module: 16/DP1.5, max. workpiece diameter: 1250mm, table diameter: 1100mm, index wheel diameter: 987mm, workpiece bore: 250mm, workpiece insertion depth: 525mm, min. cutter adjustment above table: 390mm, hob carriage travel: 1000mm, rapid traverse: 800mm/min, max. table load: 8000kg, weight: approx. 21000kg. Djdpfxsx Rylbo Afnskg

Condition: good (used), Year of construction: 2000, Ref. -No.: 10609 Manufacturer: GLEASON - PFAUTER Type: P 2400 G Year of construction: 2000 Type of control: CNC Control: Siemens 840 D Storage location: Halberstadt Country of origin: Germany Machine length: 1100 mm Machine width: 6585 mm Machine Height: 5200 mm Max. Workpiece Diameter: 2640 mm Weight Of The Machine Ca.: 23 t Grinding Wheel Diameter: 400 mm Spindle Speeds (Infinitely Variable): 600 bis 6000 mm Grinding Wheel Width: 80 mm X-Axis: 1200 mm Y-Axis: 300 mm Z-Axis: 1000 mm Z2 - axis: 150 mm Sandable profile depth: 80 mm Workpiece table: 0 bis 5 1 / min Feed rate X-axis: 3000 mm Dkjdpfx Aox R R Exofneg Feed rate Y-axis: 5000 mm Z-axis feed rate: 6000 mm Further information: - Fully automatic centering device - Oil mist separation - Gear tooth measurement - “Profile grinding” software package - Error diagnosis - IFK2 internal milling head - Milling mandrel with spacer discs - Chip conveyor - Oil mist extraction - Technical documentation

Condition: good (used), Year of construction: 1987, operating hours: 2,685 h, functionality: fully functional, feed length X-axis: 240 mm, feed length Y-axis: 200 mm, feed length Z-axis: 400 mm, total length: 5,235 mm, total height: 3,045 mm, total width: 3,990 mm, spindle speed (max.): 640 rpm, spindle speed (min.): 55 rpm, overall weight: 11,000 kg, Equipment: documentation/manual, Gear cutting machine Pfauter PE 300 Model: SK07E 20100 Control: Sinumerik System 3 Fully functional machine, which was completely overhauled just a few years ago. Investments made: - Overhaul including milling head (2021) approx. €70,000 - All hydraulic hoses renewed (2021) approx. €3,500 - New oil mist separator (2021) approx. €5,000 Dkedpfxew Dcx Re Afnsg Numerous tools and clamping devices available, see pictures and attachment.

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm gear width 320 mm Djdpfx Aox R U Hgefnjkg max. module 4,5 min. module 0,5 Control SIN 840D ical angle +/- 45 ° total power requirement 68 kW weight of the machine ca. 15500 Kg dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Wekal loading cell

Condition: used, Technical details: Dkjdpfov U T Dyox Afnog center height over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm hobbing length: 2000 mm number of teeth: 2 - 50 feed:: 0,023 - 5,17 / mm/min module max. : 8 / 12 spindle bore diameter: 102 mm workpiece rpm : 18 - 224 U/min tailstock quill adjustment: 100 mm total power requirement: 9,5 kW weight of the machine ca.: 5,2 t dimension machine xH: 3,6 x 2,1 x 2,0 m

Condition: used, Year of construction: 1987, max. wheel diameter 150 mm Djdpjwhq Afofx Afnskg gear width . mm max. module 5 min. module 0,5 Control . total power requirement . kW weight of the machine ca. 10.000 t dimensions of the machine ca. 6500 × 2700× 3600 m

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, CNC Spiral Bevel Gear Cutting Machine Gleason No 631 Year of manufacture: 2011 Control: SIEMENS 840d Retrofitted in 2011/2012 with new control, drives, etc. Dkodpfx Afjw Tfb Senjg The machine was fully overhauled in 2011. A new control system and drives were installed.

Condition: excellent (used), Year of construction: 2009, max. wheel diameter 315 mm gear width 280 mm max. module 8 min. module 1 Control Siemens 840 D distance cutter centre - clamping area 20 - 245 mm distance spindle /table 190 - 470 mm diameter of hob 160 mm tangential adjustment 110 mm ical angle 45 ° min. number of teeth 4 / 8 cutter length max. 200 mm table surface area 295 mm milling spindle speeds (infinitely variable) 50 - 400 U/min total power requirement 58 kW Dksdpsx N Ndksfx Afneg weight of the machine ca. 8,5 t dimensions of the machine ca. 4,1 x 3,5 x 2,6 m The machine was completely overhauled by SerWeMa in 2009 equipped with a Siemens Sinumerik 840D control. Possible uses: Straight and helical gears, crowned or tapered spur gears, Worm wheels for single or multi-start worms, Worms, sprockets, ratchet wheels, splines

Condition: used, Year of construction: 2012, max. wheel diameter 300 mm gear width 320 mm max. module 10 min. module 0,5 ical angle 45 ° frequency 50 Hz voltage 400 V main fuse 125 A x-axis 270 mm y-axis 250 mm z-axis 320 mm A - axis +/- 45 ° B - axis 360 ° C-axis 360 ° total power requirement 89 kW weight of the machine ca. 23,5 t dimensions of the machine ca. 11,2 x 5,5 x 2,9 m Dsdpox R U Hajfx Afnokg automated Oil slinger station EWAB workpiece storage Hoffmann coolant filter system HSF 100 SE/K Minimax fire extinguishing system W+W air filter system Promot Automation "Cellmaster" (3 cells) year 2019

Condition: used, Technical details: z-travel: 1250 mm swing diameter over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm center height over bed: 260 mm hobbing length: 2000 mm module max. : 8 / 12 total power requirement: 9,5 kW Djdov U Un Hopfx Afnskg weight of the machine ca.: 3,8 t

Condition: used, Year of construction: 1998, max. wheel diameter 85 mm gear width max. 125 mm max. module 3 Control ja total power requirement 30 kW weight of the machine ca. 8 t Dkodpfxjwhqx Tj Afnog

Condition: excellent (used), max. wheel diameter 130 mm gear width 180 mm Dksdpfex N Nddox Afnjg max. module 2,5 min. module 0,3 turning speeds 140 - 900 U/min min. number of teeth 4 clamping length max. 200 mm Control Siemens max. workpiece diameter 80 mm total power requirement 3,5 kW weight of the machine ca. 2,9 t dimensions of the machine ca. 1,8 x 1,6 x 1,9 m

Condition: used, Year of construction: 2003, max. wheel diameter 275 mm gear width 58 mm Dsdpfxsx R U E No Afnjkg max. module 13 min. module 2 Control SINUMERIK 840 D number of teeth 5 - 200 ratio of transmission 10:1 cutter diameter max. 228 mm x-axis 25 - 350 mm y-axis +/- 175 mm z-axis 125 - 600 mm b-axis -5 / +90 ° total power requirement 75 kW weight of the machine ca. 11,7 t dimensions of the machine ca. 12,5 x 3,0 x 3,0 m Equipped for dry milling Pressure deburrer Deburring device with driven brush Integrated magnetic chip conveyor Promot Cellmaster Cartridge pulse filter system User interface control works with Gleason Summary

Condition: used, Year of construction: 2005, weight of the machine ca. 7.800 kg Dkodpfx Afsudc S Hjnog dimensions of the machine ca. 3.380 x 3950 x 3015 m

Condition: used, Year of construction: 2008, max. wheel diameter 300 mm max. module 8 min. module 0,7 Control SINUMERIK 840 D min/max. pitch cone angle - 90 / + 90 ° workpiece spindle - bore 127 mm grinding wheel diameter 50 - 230 mm spindle speeds (infinitely variable) 7.500 U/min work piece spindle speed 700 U/min total power requirement 146 kW weight of the machine ca. 21 t dimensions of the machine ca. 9,5 x 3,6 x 3,1 m Measuring probefor tooth gap(integrated on the grinding head) External grinding spindle cooling system ELBARON oil mist extraction (integrated in the machine) Hoffmann coolant filter system Was used for the serial production of spiral-toothed ring gears No clamping devices No grinding wheels / grinding wheel flanges Dkedpovxww Sofx Afnog No dressing wheels
