Used Granite Measuring Plate for sale (17,852)

Condition: new, neu ca. 10 Wochen ab Auftrags Türkei 5100 € 98.43 € 1050 mm 2 mm 75 mm 1.5 kW 1610 mm 700 mm 1160 mm 385 kg 3 rolls asymmetric rolls - prebending 2 rolls driven by brakemotor lateral roll adjustable by ratchet lever longitudinal grooves in lower and lateral roll tiltable upper roll right / left rotation with double foot switch user manual in GERMAN or ENGLISH OPTION (PRICE ON REQUEST): Predpfx Asy Dvlksf Seb hardened rolls

Condition: used, Werth Type: Werth SCOPE-CHECK 400 3D coordinate measuring machine Technical data: Measuring capacity (X x Y x Z): 400 x 200 x 200 [mm] Work table with integrated electrical cabinet: 1600 x 950 x 780 [mm] Max. weight on table: 20 [kg] Operating conditions: * Relative humidity: 40 - 70 [%] * Temperature: 10 - 40 [°C] Measuring precision (20°C, 8 kg, magnification 5X, resolution 0.5 microns) On table, E1 = 1.8 + L/120; E2 = 2.0 + L/150 All positions, E1 = 2.5 + L/120; E2 = 2.9 + L/100; E3 = 4.5 + L/75 Incremental scales Ball screw drive with servo motor Optical magnification (video): 0.5X to 5X Optical field (video): 13 x 10 [mm] to 1.3 x 1 [mm] Movement on linear guide with ball bearing Combinable lighting: diascopic, episcopic, ring-shaped LED/axial Voltage: 230 [V] Frequency: 50 [Hz] Power: 2 [kW] Weight: 300 [kg] Accessories CN Lighting control via software Video sensor IP for detection of measuring contour (screen display) Electronic control for table movement Manual control for table via joystick Predisposition for mechanical probe Calibration, 3D measurement, probe communication software Software: WinWerth v8.40 Predpfx Aszh Dq Hef Sjb Scope of delivery: (Werth coordinate measuring machine with accessories as shown) Condition: used (Changes and errors in the technical data are subject to change!) Please inquire about transport options before purchase. We will be happy to answer any further questions you may have by telephone.

Condition: used, Year of construction: 2000, table width: 2,700 mm, table length: 3,300 mm, total length: 3,800 mm, total width: 1,000 mm, total height: 2,700 mm, overall weight: 2,000 kg, No. 04544 Perforated plate press Hess JULIA Used, year of construction 2000 Dimensions of the perforated plate 3300 x 2700 mm LW 4 manual hydraulic cylinders (2 in need of repair) 12 pneumatic cylinders (2 magnetic and with angle adjustment) Transport dimensions approx. 3800 x 1000 x 2700 mm LWH Weight approx. 2000 kg Podpjy E N Izjfx Af Sjrb To avoid possible misunderstandings, an on-site inspection by appointment is possible and recommended Sold as is Technical specifications, condition description, year of construction and scope of delivery according to manufacturer’s brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “sold as seen” Payment terms: Prices plus VAT, payment before collection or shipment Delivery terms: ex warehouse

Condition: used, Year of construction: 1985, sheet width 3100 mm plate thickness 4.0 mm thickness at "Niro-steel" 2.5 mm cutting angle adjustment 1.0 ° back stop - adjustable 10 - 1000 mm adjustment speed 180 mm/s down holder 21 Stück strokes per minute 18 - 31 oil volume 160 L Control ELGO P8511 column arm 200 mm distance between columns 3050 mm 0 max. 300 bar voltage 400 V main drive 9.0 kW weight of the machine ca. 4800 kg. dimensions of the machine ca. 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear "swing cut" - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left * for positioning the electro-motoric rear stop * target/actual position value input possible * adjustment by three-phase motor via toothed belt - support table with ball rollers * there are recessed grips between the table plates - front finger guard - hydraulically acting sheet metal hold-down device - 1x freely movable foot switch - emergency stop button at the front - movable scrap switch - original operating instructions + circuit diagram Special accessories included: - EHT pneumatic sheet metal holding device for thin sheet metal cuts - 1x EHT extra long side stop 3.000 mm with mm scale & support foot Psdpsxab Tvofx Af Sorb - 1x EHT extra long support arm with 3.000 mm with scale & Support foot - EHT additional support arms with mm scale

Condition: good (used), Year of construction: 2007, sheet width 1350 mm plate thickness 4.0 mm thickness at "Niro-steel" 2.0 mm no. of strokes max. 35 Hub/min cutting angle 2.0 Grad table height 945 mm distance between columns 1361 mm Control CIDAN / SIEMENS engine output 5.5 kW weight of the machine ca. 1400 kg range L-W-H 2200 x 2000 x 1550 mm Features: - robust / motorized swing cut guillotine shears - unbreakable and torsion-free welded steel construction - compact and clear machine construction - NC electro-motorized backgauge, with digital display * Target / actual value stop value input * stepless adjustment over the entire travel range - 1x hold-down bar - 1x material side stop - recessed grips in the front support table - Manual cutting gap adjustment from the front Prodpfx Aeyuzcujf Sjb - Rear sheet holding device for thin sheets - 1x freely movable foot switch - Operating instructions (PDF)

Condition: used, Year of construction: 1997, sheet width 3100 mm plate thickness 6.35 mm thickness at "Niro-steel" 4.00 mm cutting angle 0.5 - 2.5 ° cutting gap adjustment 0.05 - 0.8 mm no. of strokes 12 - 50 Hub/min back stop - adjustable 1000 mm Control DELEM DAC 360 oil volume 120 ltr. engine output 9.5 kW weight 7000 kg. range L-W-H 3950 x 1950 x 1680 mm well-maintained condition (!!) equipped with new DELEM control unit Equipment: - electro-hydraulic, guided plate shear - DELEM CNC control unit type DAC 360 * front control panel, swiveling front left - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment Prsdjy I Dbbspfx Af Sjb - electro-motorized backgauge, with ball screws - 1x extra-long side fence with T-slot mm scale

Condition: new, sheet width 3100 mm plate thickness 10,0 mm thickness at "Niro-steel" 6,0 mm down holder 14 Stück no. of strokes 13 Hub/min oil volume 260 ltr. cutting angle 2,0 ° throat 350 mm engine output 22,0 kW back stop - adjustable 1.000 mm Pedpfx Afsxabdbe Serb weight 10.575 kg. range L-W-H 4,05 x 2,5 x 2,17 m ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball rollers in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 3100 mm plate thickness 13,0 mm pre-bending 10,0 mm diameter of upper rolls 300 mm side roll diameter 210 mm diameter of lower rolls 270 mm total power requirement 11,0 kW Furnishing: - electro-hydraulic 4-roller bending machine - 2x driven main rollers (upper & lower roller) - with hydraulic conical bending device - Induction hardened rollers - including straightening function for welded pipes - Control unit / display with touch screen function * digital position display for the two side rollers - mobile control panel - 2x bending speeds selectable Predpfx Aoxabflof Ssb - hydraulic folding bearing - Safety device (safety line with switch unit) - Pressure gauge / pressure indicator for the rollers - CE mark + declaration of conformity - Operation manual

Condition: new, sheet width 1600 mm plate thickness 15,0 mm ST pre-bending 13,0 mm ST diameter of upper rolls 230 mm side roll diameter 210 mm diameter of lower rolls 190 mm total power requirement 7,5 kW weight of the machine ca. 4225 kg. dimensions of the machine ca. 4000 x 1300 x 1440 mm Furnishing: - electro-hydraulic 4-roller bending machine - 2x driven main rollers (upper & lower roller) - with hydraulic conical bending device - Induction hardened rollers - including straightening function for welded pipes - Control unit / display with touch screen function * digital position display for the two side rollers - mobile control panel - 2x bending speeds selectable - hydraulic folding bearing - Safety device (safety line with switch unit) - Pressure gauge / pressure indicator for the rollers Prodoxabkhjpfx Af Ssb - CE mark + declaration of conformity - Operation manual

Condition: new, sheet width 3100 mm plate thickness 13,0 mm thickness at "Niro-steel" 8,0 mm down holder 14 Stück no. of strokes 11 Hub/min oil volume 310 ltr. cutting angle 2,0 ° throat 350 mm table height 900 mm total power requirement 22,0 kW weight of the machine ca. 12200 kg range L-W-H ca. 4100 x 2300 x 2235 mm Prodpfoxaa U Sjx Af Seb ----- heavy electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Number of pieces * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: good (used), Year of construction: 2005, sheet width 3050 mm plate thickness 12.0 mm ST plate thickness 8.0 mm VA no. of strokes 7 - 14 Hub/min Psdszr Rqnspfx Af Sorb down holder 18 Stück cutting angle 0.5 - 3.0 ° work height max. 930 mm back stop - adjustable 1000 mm Control SP 8 total power requirement 22.5 kW weight 8500 kg range L-W-H 4180 x 2030 x 2210 mm from a maintenance workshop good / well-maintained condition (!!) Equipment: - electro-hydraulic guillotine shear with guided blade beam - includes HACO NC control system "SP 9" * in like-new condition * backgauge pre-selection positioning * digital display of actual value * electro-hydraulic cutting angle adjustment with digital display * emergency stop switch - NC motorized backgauge on recirculating ball screws - manual blade gap adjustment, adjustable from the rear - front finger guard - 1x side gauge ... 1,000 mm - rear sheet metal chute - 1x movable foot pedal - operating manual

Condition: used, Year of construction: 2019, sheet width 6080 mm plate thickness 6.0 mm rear stop 1000 mm cutting angle 0.5 - 2.0 ° down holder 29 Stk no. of strokes ca. 10 Hub/min total power requirement 22.0 kW dimensions of the machine ca. 7300 x 2150 x 2750 mm Prsdpfozvq Etex Af Seb weight 25500 kg Current list price: approx. 150.000 euros Features: - Electro-hydraulic, slide-guided sheet metal shear - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - Electrically driven backgauge with ball screws - Manual central lubrication - Cut line illumination - Ball bearings in the table - Fold-up finger guard, 1.000 mm - Side stop with T-slots, tilting stop, and scale - 5 support arms with T-slots - Photoelectric sensors on the rear of the machine - 1 freely movable foot switch Includes optional equipment: - Pneumatic sheet metal holding device

Condition: new, sheet width 3100 mm plate thickness 8,0 mm ST pre-bending 6,0 mm ST diameter of upper rolls 230 mm side roll diameter 210 mm diameter of lower rolls 190 mm total power requirement 7,5 kW weight of the machine ca. 6.020 kg. dimensions of the machine ca. 5142 x 1390 x 1300 mm Furnishing: - electro-hydraulic 4-roller bending machine - 2x driven main rollers (upper & lower roller) - with hydraulic conical bending device - Induction hardened rollers - including straightening function for welded pipes - Control unit / display with touch screen function * digital position display for the two side rollers - mobile control panel Podpfoxabm Asx Af Sjrb - 2x bending speeds selectable - hydraulic folding bearing - Safety device (safety line with switch unit) - Pressure gauge / pressure indicator for the rollers - CE mark + declaration of conformity - Operation manual

Condition: new, sheet width 2100 mm plate thickness 6,0 mm ST 42 thickness at "Niro-steel" 4,0 mm VA cutting angle 1,2 Grad no. of strokes 28 Hub/min oil volume 150 ltr. down holder 11 Stück control CYBELEC CybTouch engine output 11,0 kW back stop - adjustable 1.000 mm table height 800 mm weight 4.500 kg range L-W-H 3.010 x 2.100 x 1.640 mm Prjdjxaa Acopfx Af Sjb ----- electr. / hydraulic CNC swing cut shears * with CYBELEC CNC touch screen control * with electr. / hydr. Kerf adjustment ----- Furnishing: - CNC electr. / hydraulic swing cut shears - CYBELEC CNC touch screen controller, model CybTouch 8 * Backgauge preselection - X axis * Cutting gap adjustment * Quantity * Cutting length limitation * Material preselection, including sheet thickness * Cutting line lighting - motorized backgauge, travel = 1,000 mm (X axis) * on ball screws * autom. Can be folded up at vel, for longer cuts - 1x side stop - 2x front support arms - Ball casters in the front support table - hinged finger protection, with safety switch - BOSCH / HOERBIGER hydraulic system - SIEMENS electrical system - light barrier behind the machine (safety device) - foot switch - CE mark / declaration of conformity - User manual: machine and control in German

Condition: new, sheet width 2600 mm plate thickness 10,0 mm pre-bending 8,0 mm diameter of upper rolls 230 mm side roll diameter 190 mm diameter of lower rolls 210 mm total power requirement 7,5 kW weight of the machine ca. 5.560 kg. range L-W-H 4.650x1.380x1.300 mm Furnishing: - electro-hydraulic 4-roller bending machine - 2x driven main rollers (upper & lower roller) - with hydraulic conical bending device - Induction hardened rollers - including straightening function for welded pipes - Control unit / display with touch screen function * digital position display for the two side rollers - mobile control panel - 2x bending speeds selectable - hydraulic folding bearing Prsdjxaalqjpfx Af Sjb - Safety device (safety line with switch unit) - Pressure gauge / pressure indicator for the rollers - CE mark + declaration of conformity - Operation manual

Condition: used, Year of construction: 1978, sheet width 3100 mm plate thickness 2 mm rear stop 1000 mm cutting angle 1°06 ° no. of strokes 45 Hub/min total power requirement 3,0 kW dimensions of the machine ca. 3600 x 2200 x 1600 mm weight 4500 kg Equipment: - Electric motorized backgauge - With digital ELGO position display - Manual cutting gap adjustment - 1x side stop with mm scale - 2x support arms - 1x freely movable double foot switch - Front finger guard Psdpfx Afsuagxpj Serb Special accessories included: - Pneumatic sheet metal holding device for thin sheet metal cuts

Condition: excellent (used), Year of construction: 2006, operating hours: 11,533 h, travel distance X-axis: 8,000 mm, travel distance Y-axis: 4,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 2,500 rpm, feed length W-axis: 800 mm, spindle diameter: 160 mm, table load: 80,000 kg, table length: 8,000 mm, table width: 4,000 mm, overall weight: 65,000 kg, grinding spindle motor power: 41 W, Equipment: rotational speed infinitely variable, JUARISTI MX-7 RAM CNC – CNC BORING AND MILLING MACHINE, FLOOR-MOUNTED DESIGN Manufacturer: Juaristi Model: MX-7 RAM Year of Manufacture: 2006 CNC Control: Heidenhain iTNC 530 Travel Ranges - X-axis: 8,000 mm - Y-axis: 4,000 mm - Z-axis (RAM / Slide): 1,000 mm - W-axis (Spindle Stroke): 800 mm Mounting Plates / Base Plates - Mounting Surface: 8,000 × 4,000 mm - Maximum Table Load: 80,000 kg Main Spindle - Spindle Diameter: 160 mm - Tool Holder: SK 50 (ISO 50) - Main Motor Power: 41 kW - Maximum Torque: 2,024 Nm - Spindle Speed Range: - 5–1,182 rpm (low speed range) - 1,182–2,500 rpm (high speed range) CNC & Drives - CNC Control Heidenhain iTNC 530 - Siemens Feed Motors - Absolute Heidenhain Measuring System Tool and Head Equipment - Automatic Tool Changer (ATC) with 30 positions - Automatic clamping system for RAM accessories - Manual swivel head Cooling System - Internal cooling through the spindle Prsdpfx Aez Aplrof Seb - External cooling system Mechanical Equipment - Hydraulic-electronic RAM compensation system - Independently vertically adjustable operator platform - Chip conveyor - Complete enclosure / complete protective guard Documentation - Complete original machine documentation available

Condition: good (used), number of rollers: 3, roller (top) diameter: 130 mm, sheet thickness (max.): 3 mm, - Capacity: 1550 x 3 mm - Top roll diameter: 130 mm Psdpjz Ayp Ijfx Af Sjrb - Roll length: 1550 mm - 380V

Condition: refurbished (used), Year of construction: 2019, functionality: fully functional, travel distance X-axis: 7,000 mm, travel distance Y-axis: 2,500 mm, travel distance Z-axis: 420 mm, feed length W-axis: 900 mm, spindle diameter: 130 mm, table load: 15,000 kg, table length: 2,000 mm, table width: 1,800 mm, Union GERA BFP 130 CNC milling machine with Heidenhain 355 control, mechanically refurbished in 2019, in excellent condition, including base plates. Travel in X-axis: 7,000 mm Travel in Y-axis: 2,500 mm Travel in Z-axis: 420 mm Table load capacity: 15,000 kg Spindle diameter: 130 mm Table length: 2,000 mm Table width: 1,800 mm Pedpjz Ahqyjfx Af Serb Travel of W-axis: 900 mm

Condition: used, Year of construction: 2011, functionality: fully functional, Auriga 60 Computer-Controlled FE-SEM with patented GEMINI® electron optics and field emission cathode, designed for analytical applications and high-resolution imaging under high-vacuum conditions. Year of manufacture: 2011 FIB column type: Cobra FIB column SEM column type: Schottky field emitter Installed detectors: • SESI (commercial) • InLens • ESB • 4QBS (pneumatic) • STEM (pneumatic) • EDX X-MAX 80 mm (Oxford) • EBSD (HKL Channel 5) • Charge compensation Gas injection system: Platinum Pjdpszz H I Iofx Af Ssrb Maintenance report: The system has been serviced annually, with a service report provided each time. Operating hours: 13,290.33 hours (with current filament) PC and software included: Yes Included components: All pumps, cooling systems, and control units are included, except for the dampers. Software Version: • SEM: SmartSEM Version 6.00 (June 9, 2016) • EDX: INCA software package – Version 5.03 Price: Negotiable price excluding VAT and delivery

Condition: ready for operation (used), OGP Smartscope CNC 250 Measuring Device / Measuring Microscope / Video Measuring System Travel ranges (XYZ): 250mm / 150mm / 200mm Dimensions: approx. 740mm x 640mm x 810mm (L x W x H) Weight: approx. 115 kg Scale resolution: 0.5 µm For further technical details, please refer to the images. Podpfjxxx Syox Af Sorb You are welcome to visit for an inspection. We can also arrange affordable shipping for you! You will receive a proper invoice. For international customers, a net invoice can be issued provided a valid VAT ID number is supplied. Subject to prior sale. Visit our shop and take a look at our other offers. All company names and trademarks mentioned are the property of their respective owners and are used for identification and description purposes only. Deviation from technical data and errors in the description of the item may occur and are subject to change.

Condition: used, Year of construction: 1983, Used Machine Year of manufacture: 1983 Features and technical specifications: - Automatic - Cutting length: 5,300 mm - Cutting height: 2,200 mm - Max. horizontal cutting height: 2,100 mm Prodpezyy Edofx Af Seb - Max. cutting depth: 80 mm - Motor: 5.5 kW - Saw blade diameter: 300 mm - Speed: approx. 5,000 rpm - Dimensions (L x W x H): approx. 6,550 x 1,500 x 2,950 mm

Condition: excellent (used), Year of construction: 2016, operating hours: 2,615 h, functionality: fully functional, plate width: 1,600 mm, plate length: 2,108 mm, KODAK Magnus VLF large-format thermal plate setter with MCU multi-cassette unit (four cassettes) New TH 7 laser (August 2022) with only 2615 laser hours 2400 dpi Z-speed Total number of exposed printing plates: 395,443 pieces Minimum size: 483 x 394 mm Maximum size: 1600 x 2108 mm Prsdpfx Asytawnsf Seb Material flow from left to right, Print Console enabled for all RIP software, Dell PowerEdge T330 server.

Condition: used, Bore measuring screws – internal measuring screw from the manufacturer Busch D.B.P.a. Ausl.PAT. 3-point internal micrometer – used bore micrometer with wooden case – Friedr. Strack Wuppertal Measuring range [mm] 25-30 / 30-40 Scale value [mm] 0.005 Testing device – internal measuring device – with 3-point contact Psdpfxezumc Sj Af Ssrb 2 units available Price upon request All technical specifications are subject to typographical errors and inaccuracies. Sale exclusively to countries within the EU.

Condition: used, functionality: fully functional, Year of construction: 2004, machine/vehicle number: 220692, Equipment: emergency stop, sheet width 1550 mm Psdpfx Aozxt Txof Sorb plate thickness 6 mm diameter of upper rolls 228 mm drive elektronisch zwei angetri
