Used Draw Press for sale (14,009)

Condition: as good as new (ex-display), Year of construction: 2017, machine/vehicle number: DF0052, pressure:200 t distance between columns:1200x1000 mm stroke:600 mm total power requirement:32,5 kW weight of the machine ca.:20,5 t dimensions of the machine ca.:4000x2600x5000 m draw back pressure:20 t Master cylinder:1 Stück Bjdpfsfxyirox Abbewh voltage:400 V frequency:50 Hz :24 V :BOSCH/REXROTH dayligth:800 mm :1200x1000 mit T-Nuten nach Kundenwunsch DIN 650-22 mm work height max.:1100 mm pre-running speed:170 mm/sec return speed:150 mm/sec Speed printing phase:15 mm/sek. Hydraulic block:REXROTH demand for oil:500 l pressure control:über PLC (Mindestdruck 20t) Oil Cooling:elektrisch :220 (im Schaltschrank) V memory:200 Programme :über Monitor von 20-200 t Controll:Zweihandbedienung beweglich :2-10 mm/sec :0-10 sec

Condition: reconditioned (used), Year of construction: 2002, 4200 x 2500 x 650 mm Table size Bedpjgphaxjfx Abbswh The table moves 3000 mm outwards for loading For tools up to 4200x2500x1500mm Tool weight up to 40 T Speed at 700 T still 62 mm/sec, at 1200 T still 35 mm/sec. ram size is 4200x1750 mm maximum open height 2200 mm drawing cushion with 50 to 500 T drawing cushion stroke 400 mm drawing cushion size 3100x1600 mm drawing cushion speed 150 mm sec. ram drawing cushion with 150 mm stroke 1600 mm stroke 475 KW, 890 Amps 210 T machine weight new motors new control system Was used for 3 years at a German automotive company and then sold to Brazil to an auto parts manufacturer. Worked there until 2020.

Condition: used, machine/vehicle number: 4396, pressure:200 t distance between columns:1200x1000 mm stroke:600 mm total power requirement:32,5 kW weight of the machine ca.:20,5 t draw back pressure:20 t :1 Stück voltage:400 V frequency:50 Hz :24 V :Rexroth/Bosch dayligth:800 mm working area:1200x1000 mm :1200x1000 mm work height max.:1100 mm :170 mm/sek. :150 mm/sek. :15 mm/sek. quantity of oil:500 l :220 V memory:200 Programme :20-200 über Monitor t :5-170 mm/sec. :0-10 sec :2-10 mm/sec :750x950 mm :300 mm :5-50 t Bwsdpfx Ajfxyh Aebboh :2-80 mm/sec :1000 kg

Year of construction: 1999, condition: used, Technical details: Press area: 2350 x 1300mm Dimensions (LxWxH) approx: 4200 x 3200 x 2400mm Weight approx: 8000kg Item Description: Machine number 99-0211, equipped with a sliding table 2350 x 1300mm, workpiece dimensions max. 2100 x 1100mm, workpiece thickness max. 38mm, control with touchscreen. Bwjdpof D Aq Ajfx Abbeh

Year of construction: 1981, condition: like new (used), Second hand hydraulic (triple acting) deep drawing press LAUFFER 400t. The press is already dismantled and in excellent condition as it has been little used. Technical data: Year of manufacture: 1981 Pressing capacity in t: 400 Height above floor in mm: 5940 Stroke in mm: 800 Table size (lxb) in mm: 1600 x 1300 Ram size (lxb) in mm: 1500 x 1300 Daylight in mm: 850 Bedpfxod Ntd Ds Abbowh Upper ejector stroke in mm: 160 Upper ejector force in t: 6,3 Lower ejector stroke in mm: 200 Lower ejector force in t: 12 Total power consumption in kW: 150 Overall size (lxbxh) in mm: 3550 x 1200 x 5940 Total weight in kg: 50000

Condition: like new (used), Year of construction: 2019, pressure:400 t stroke:900 mm Table dimensions:1200 x 1200 mm Deep-Drawing Pillow:150 t travel away deep-drawing pillow:280 mm Daylight Opening:1100 mm Bwjdpfjfh Izmox Abboh

Year of construction: 2008, condition: excellent (used), SMG HZPU 8000-3000/2100-S1 Hydraulic Drawing Press Brand SMG Type HZPU 8000-3000/2100-S1 Year 1995 Description Hydraulic Drawing Press H frame hydraulic press Pressing force 800 ton Clamping area Approx. 3,000 x 2,100 mm Bwjdpfx Abjn Awd Reboh Installation height Max. 1,400 mm

Condition: used, Year of construction: 1987, functionality: unexamined, Press force: 200 kN Ram stroke, constant: 210 mm Adjustable strokes per minute: 20 - 60 Usable working energy per cycle: 15 kJ Drive power: 24 kW Tool installation height between table and ram, stroke down, adjustment up: 500 mm Ram adjustment: 100 mm Ram clamping area: 600 x 600 mm Bedswy Sqzspfx Abbjwh Table clamping area: 600 x 600 mm Ejector stroke: 90 mm Weight: 20 t

Condition: used, Thrust: 600 TON. Barbed points: no. 2 Model: AF 600 MB 30-60 Year of construction: 1994 Table size: 3,000 X 1,600 mm. Slide size: 3,000 X 1,600 mm. Front passage: 3,000 mm. Bwedpfxjq N Etts Abbsh Side passage: 1,200 mm. Slide registration: 150 mm. Strokes per min: 20- c/min. Stroke : 500 mm. Mold clearance at PMI: 1,118 mm. Main motor power: 30 kw Hydraulic Safety: present Weight: 110 ton.

Condition: used, Year of construction: 1987, pressure 125 t Bwsdpfx Aot Hwuijbbeh distance between columns 1050 mm stroke 250 mm total power requirement 40 kW weight of the machine ca. 8,5 t dimensions of the machine ca. m

Condition: used, Year of construction: 1977, pressure 160 t throat 360 mm stroke 560 mm total power requirement 33 kW weight of the machine ca. 6000 kg Bwedpfx Abet Hw E Iobsh dimensions of the machine ca. 2000x2400x3650 mm

Condition: excellent (used), Thrust: 300 TON. RATED CAPACIT Model: 2MR TYPE Year of construction: 2000 YEAR OF CONSTRUCTION Table size: 1.750 x 1.250 mm TABLE DIMENSIONS Bsdpfx Asq N Etzsbbowh Slide adjustment: 160 mm SLIDE ADJUSTMENT Strokes per min.: 10-30 c/min. CONTINUOUS SPEED (variable) Stroke: 250 mm SLIDE STROKE Mold clearance at BDC: 500 mm SHUT HEIGHT Main motor power: 32 kw MAIN MOTOR POWER Hydraulic Safety: present Hydraulic Safety

Condition: used, HYDRAULIC PRESS SMG PRESSURE 300t LENGHT OF STROKE 700mm POWER 30kw UP TABLE DIMENSIONS 1500(1600)x1300mm DOWN TABLE DIMENSIONS 1500(1600)x1300mm CUSHION 100t Bwedstndu Uspfx Abbjh CUSHION LENGTH OF STROKE 280mm WEIGHT 28.000kgr FULL RECONDITION LIKE NEW CHANGE EVERYTHING (SEALS PUMPS etc)

Condition: used, Year of construction: 1992, HYDRAP type HPSKZ 63t / 20t Pressure: 63t Down table dimensions: 700x700 mm Bwodpfx Aow Slnisbbjh Up table dimensions: 600x600 mm Stroke length: 600 mm Daylight: 800 mm Cushion: 20t

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t Bjdovxwh Dopfx Abbjwh stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW Bodpfx Absvxwmmobowh weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1974, pressure 600 t distance between columns 2600 mm stroke 900 mm distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm Bodjvxwg Tepfx Abbswh die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled overhauled in 2005

Condition: used, Year of construction: 1974, pressure 600 t distance between columns 2600 mm stroke 900 mm distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Bwedpfxsvxwg Hj Abbsh overhauled in 2005

Condition: used, Year of construction: 1973, pressure 1600 t distance between columns 3160 mm Bwedpfx Absvxwhwsbeh ram stroke 1450 mm distance table/blankh.,max. stroke up,adjustm. up 2250 mm table surface area 4000 x 2200 mm ram pressure 1000 t pressure of blank holder 600 t stroke of blankholder at the bottom 1000 mm stroke of blankholder with adjustment 0-100 mm 1450 mm blank holder size 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 275 / 400 mm ram surface 4000 x 2200 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled oil volume 9000 l total power requirement 390 kW weight of the machine ca. 250 t dimensions of the machine ca. 6,0 x 4,3 x 10,5 m Head press (1600 tons) of a press line with five subsequent presses (800 tons)

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled die-cushion inside the table hydraulic, controlled total power requirement 200 kW Bedpovxwm Tofx Abbjwh weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1972, pressure 800 t distance between columns 3160 mm stroke 1100 mm control Siemens S5 distance table/blankh.,max. stroke up,adjustm. up 1900 mm table surface area 3100 x 1900 mm die-cushion pressure inside the table 300 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 80 t stroke of drawing cushion in table 150 mm ram surface 3100 x 1900 mm die-cushion in pusher hydraulic, controlled Bsdpfxsvxwgte Abbswh die-cushion inside the table hydraulic, controlled total power requirement 200 kW weight of the machine ca. 150 t dimensions of the machine ca. 4,95 x 3,3 x 10,2 m

Condition: used, Year of construction: 1973, pressure 1000 t distance between columns 4150 mm stroke 1200 mm distance table/blankh.,max. stroke up,adjustm. up 2100 mm table surface area 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 300 mm die-cushion pressure in pusher 100 t stroke of drawing cushion in pusher 150 mm ram surface 4000 x 2200 mm Bjdpfovxwhkex Abbowh column travel -side 1300 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Cut Shock absorption hydraulic weight of the machine ca. 280 t The machine was overtaken 1999.

Condition: used, Year of construction: 1976, machine/vehicle number: 8841, pressure:25 t throat:260 mm stroke:500 mm Bjdscxxp Espfx Abbjwh die cushion capacity:10 t die cushion stroke:200 mm Size of table plate:500 x 500 mm total power requirement:11 kW weight of the machine ca.:3 t dimensions of the machine ca.:1,40 x 1,10 x 2,80 m

Condition: used, Year of construction: 1973, pressure 1000 t distance between columns 4150 mm stroke 1200 mm distance table/blankh.,max. stroke up,adjustm. up 2100 mm Bedpjvxwggofx Abbswh table surface area 4000 x 2200 mm die-cushion pressure inside the table 360 t stroke of drawing cushion in table 300 mm die-cushion pressure in pusher 100 t stroke of drawing cushion in pusher 150 mm ram surface 4000 x 2200 mm column travel -side 1300 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled Cut Shock absorption hydraulic Control Siemens S7 height over floor 7,7 m total power requirement 300 kW weight of the machine ca. 280 t dimensions of the machine ca. 5,75 x 4,3 x 9,55 m Year of construction 1973 Modernization 2005 with oil-hydraulic drive, hydraulically controlled drawing cushion in the table and Ram, hydraulic cutting impact damping stored dismantled - short video available from the seller before dismantling

Condition: used, Year of construction: 1974, pressure 600 t distance between columns 2600 mm stroke 900 mm Bwedpovxwgysfx Abbjh distance table/blankh.,max. stroke up,adjustm. up 1600 mm table surface area 2500 x 1730 mm die-cushion pressure inside the table 250 t stroke of drawing cushion in table 400 mm die-cushion pressure in pusher 63 t stroke of drawing cushion in pusher 150 mm ram surface 2500 x 1730 mm column travel -side 1100 mm die-cushion inside the table hydraulic, controlled die-cushion in pusher hydraulic, controlled overhauled in 2005
