Used Copying Lathe for sale (5,788)

Condition: used, Year of construction: 1971, functionality: fully functional, turning diameter over bed: 900mm turning diameter over slide rest: 800 mm Center distance: 2.000 mm turning diameter: 1.200 mm turning diameter in the gap (with guide spindle pulled out to the right): approx. 1.460 max. width of the adjustable bed: 900 mm spindle bore: 85 mm turning rate: 14 - 710 min-1 dimensions (LxWxH), approx.: 4.705 x 2.060 x 2.000 mm equipment: 4 fold tool clamping system, HEIDENHAIN three-axis digital readout, Three jawchuck FORKARDT F400, Vibration damping elements Bodpoy Ifdkofx Ak Eslg The main spindle box was completely overhauled approx. 10 years ago. The vibration-damping elements are included in the scope of delivery. The machine is from the original owner.

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, turning diameter over bed: 540 mm turning length: 1.500 mm Blsdpfxjy Ifcas Ak Eog turning diameter in the recess: 580 Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 U/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 73 mm bed width: 403 mm Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: used, Year of construction: 2006, Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 Turning diameter: 650 mm Turning length: 1,500 mm Total power requirement: 33 kW Center distance: 1,500 mm Swing diameter over bed: 650 mm Swing diameter in recess: 670 mm Swing diameter over face slide: 260 mm Bodpfx Akoy Ifaxo Ejlg Face slide travel: 380 mm Main drive Drive power AC motor - 40/60/100% duty cycle: 33/27/22 kW Spindle box Spindle bore diameter: 106 mm Spindle diameter in front bearing: 140 mm Speed range (V constant): 1 - 2,000 rpm Cross slide Feed range, face: 0.001 - 1,000 mm/rev Feed range, face, optional up to: 5,000 mm/rev Feed range, longitudinal and thread pitch: 0.001 - 2,000 mm/rev Feed range longitudinal and thread pitch, optional up to: 13,000 mm/rev Feed force flat: 9,000 N Feed force longitudinal: 12,000 N Automatic tool turret Number of tool stations: 12 With tool drive for 6 stations Tool holder system (DIN69880) VDI40 Equipment SIMENS SINUMERIK 840D sl (Shop Turn with manual functions) COMBI control station C-axis with drilling, milling, and engraving cycles Residual material detection and machining – during roughing and contour pockets MULTIFIX C forne setup Three-jaw chuck SMW AUTOBLOK: HI-GRIP HGF260-81-3 Oil emulsion mist filter for work area extraction: MAHLE LTA600

Condition: good (used), Year of construction: 1972, functionality: fully functional, Swing diameter over bed: 1,650 mm Swing diameter over support: 1,350 mm Turning length: 10,000 mm Bed width: 1,120 mm Speed range: 1.4 - 280 rpm Max. torque (approx.): 20,000 Nm Workpiece weight between centers, max.: 10,000 kg with 1 steady rest / follower rest: 12,500 kg Equipment Bjdpfoy Id U Uex Ak Eslg 3-axis digital readout: ACU RITE 1 steady rest 1 roller support Chip conveyor: KABELSCHLEPP Chuck guard The machine comes from first ownership, is free from defects, and is in very good condition. In 2023, the headstock was overhauled; among other things, the main spindle bearings were replaced and the main spindle and bull gear (bearing seat) were hard-chromed and reworked. The guideways are also in very good condition for its age.

Condition: used, Year of construction: 1959, total length: 3,500 mm, total width: 1,200 mm, total height: 1,500 mm, Colour: Green Empty weight: 2.000 kg - Year: 1959 - Documentation available: No - CE certificate present: No - Serial number: 37 - Drive system: Conventional - Centre height [mm]: 270 Bedpfey Idtwsx Ak Eolg - Swing over bed [mm]: 540 - Carriage turning diameter [mm]: 360 - Distance between centres [mm]: 1500 - Bed width [mm]: 450 - Spindle bore [mm]: 62 - Min. spindle speed [rpm]: 14 - Max. spindle speed [rpm]: 710 - Options: Fixed steady, Three-jaw chuck - Transport dimensions: 3500mm x 1200mm x 1500mm (l x w x h) - Transport weight [kg]: 2000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Year of construction: 2009, functionality: fully functional, CNC Lathe TRAUB TNX 65/42 Year of manufacture: 2009 Control: Traub TX 8i-s TECHNICAL DATA - Number of spindles: 2 - Number of axes: 12 - Number of turrets: 2 MAIN SPINDLE - Spindle nose: A2-6 - Spindle drive power: 24 kW - Spindle speed: 5,000 rpm - Max. bar diameter: 65 mm - Max. diameter of main spindle chuck: 175 mm - Minimum C-axis resolution: 0.001 degrees SUB SPINDLE - Spindle nose: A2-5 - Spindle drive power: 28 kW - Spindle speed: 7,000 rpm - Max. bar diameter: 42 mm - Minimum C-axis resolution: 0.001 degrees - Travel: 700 mm Bedpfx Aksyw H Szs Ejlg LEFT UPPER TURRET - Number of stations: 10 - Number of live stations: 10 - X/Z-axis travel: 175 / 650 mm - Y-axis travel: +/- 40 mm - Tool type: VDI 30 - Driven tools speed: 6,000 rpm - Driven tools power: 5.5 kW RIGHT LOWER TURRET - Number of stations: 10 - Number of live stations: 10 - X/Z-axis travel: 175 / 650 mm - Y-axis travel: +/- 40 mm - Tool type: VDI 30 - Driven tools speed: 6,000 rpm - Driven tools power: 5.5 kW ELECTRICAL SUPPLY - Supply voltage: 400 V - Total power: 95 kW WEIGHT AND DIMENSIONS - Footprint: 5,450 x 2,318 mm - Machine height: 2,258 mm - Machine weight: 10,000 kg New spindle since 04/26 ACCESSORIES - 3-color status signal lamp - Coolant tank: RESY * with high-pressure pump * with paper filter - Chip conveyor - Parts extraction - Parts belt conveyor

Condition: used, (CMZ TL20M) Spinner TS66LMC CNC lathe with C-axis FANUC 21i-TB with Manual Guide MAX. TURNING LENGTH: 600 mm Blsdpfsy Ib A Ajx Ak Ejg LIVE TOOLS: Yes – 12 stations Main spindle specification: 12 kW, 4000 rpm, 46 Nm MAX. BAR DIAMETER: 66 mm MAX. TURNING DIAMETER: 400 mm YEAR OF MANUFACTURE: 2006 Travel -X 240 mm, -Z 640 mm Equipment: 5 live tools (3/2), tailstock, tool presetter, parts catcher, chip conveyor. Very good condition.

Condition: like new (used), Year of construction: 2018, Manufacturer: Optimum Maschinen Germany GmbH Model: L34HS Blodpfx Aey Ia Uqsk Eeg Serial Number (SN): 11261804002 Machine Type: Flat-bed CNC Lathe Year of Manufacture: 2018 Motor Power: 3.7 kW Power Supply: 400 V / 50 Hz Spindle Speed Range: approx. 30 – 3500 rpm Maximum Spindle Speed: 3500 rpm Maximum Turning Diameter: approx. 350 mm Turning Diameter over Cross Slide: approx. 146 mm Distance Between Centres: approx. 600 mm Travel X/Y/Z-Axis: approx. 185 / 185 / 540 mm Taper / Mount: MT 3 Weight: approx. 1200 kg

Condition: used, total length: 4,000 mm, total width: 1,200 mm, total height: 1,500 mm, Empty weight: 4.000 kg Price: On request - Documentation available: No - CE certificate present: No - Transport dimensions: 4000mm x 1200mm x 1500mm (l x w x h) Bljdpfx Asy Ia T Hok Eeg - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Lukas van Rossum

Condition: good (used), Year of construction: 2007, turning diameter 1600 mm Bedpfx Ajwzmqrok Eslg control Sinumerik 840D workpiece dia. 1400 mm boring diameter 100-500 mm weight of the machine ca. 35 t dimensions of the machine ca. 5,60x3,20x4,00 m

Condition: used, Year of construction: 1994, turning diameter over bed 350 mm turning diameter over slide rest 310 mm turning length 700 mm total power requirement 4,6 kW weight of the machine ca. 1,0 t Dimensions (HxWxD) 2.200 x 1.300 x 1.175 mm --> Technical data Centre height: 175 mm --> Centre width: 800 mm --> Swing diameter over bed: 350 mm --> Swing diameter over support: 310 mm --> Gap length in front of the faceplate: 145 mm --> Cross slide travel: 205 mm --> Top slide travel: 100 mm --> Tool cross-section: 20x20 mm --> Bed Width: 220 mm --> Height: 300 mm --> Headstock Spindle bore: 46 mm --> Spindle nose: DIN 55027-5 --> Spindle inner taper: 1:20 Bsdewc Dzwspfx Ak Eslg --> Tool holder: MK-3 --> Spindle speeds: 18 --> Speed range: 25 - 2000 rpm --> Tailstock Quill diameter: 50 mm --> Quill inner taper: MK-3 --> Quill travel: 140 mm --> Lateral adjustment: 10 mm --> Feed range Number of feeds: 256 --> Longitudinal feeds (128): 0.042 - 0.929 mm Rev --> Cross feeds (128): 0.015 - 0.338 mm Rev 3 - jaw chuck Multifix steel holder size B, 1 x inserts 2 x travelling steady rest, Operating instructions

Condition: used, Year of construction: 1989, turning diameter over bed 300 mm turning diameter over slide rest 150 mm turning length 800 mm spindle bore 36 mm turning speed range 42 - 2000 U/min feeds 0,011 - 0,91 mm/U tailstock quill taper MT 3 total power requirement 2,2 kW weight of the machine ca. 0,75 t dimensions of the machine ca. 1,7 x 0,8 x 2,0 m Blodpfx Aerdwfzok Esg Machine had been active in the school centre very little used!

Condition: good (used), Year of construction: 1989, functionality: fully functional, Mazatrol T32 control, turret, tailstock, extensive accessories Blsdpfx Akey H Iz Nj Eog

Condition: refurbished (used), Product information "Leadscrew and feedscrew lathe Kern D 20 A" Leadscrew and feedscrew lathe from Kern Bedpfx Asy H Iqwok Eelg Type / Model: D 20 A Condition: Overhauled Technical data: Centre height: 215 mm Centre distance: 600 mm Spindle bore: 50 mm Bed width: 300 mm Spindle speed (12): 31.5 - 1400 rpm Motor power: 4 kW Quill stroke: 150 mm Weight: approx. 1500 kg Dimensions (W x D x H): approx. 2180 x 1180 x 1560 mm Equipment: - 3-axis digital readout - Emergency stop push button - Multifix quick-change toolpost system - Machine light - Coolant system - Live centre

Condition: good (used), Year of construction: 2008, For sale: 1 unit Scherer VDZ 80 DS with the following technical specifications: Swing diameter: 120 mm Z-axis (vertical): 265 mm X-axis (horizontal): 280 mm Front bearing diameter: 85 mm Rear bearing diameter: 75 mm 2 x A4 spindle Spindle drive unit rated power: 16.8 kW Rated torque: 100 Nm Speed: 1,000 – 7,000 rpm Travel speed Z-axis: max. 30 m/min Travel speed X-axis: max. 30 m/min Blsdpfjy H Iglox Ak Eeg Dimensions: 2.44 x 2.3 x 1.42 m (L x H x W) Weight: 9,000 kg Complete documentation available. Note: The system will likely require some reprogramming, as it was previously integrated into a complete processing line. However, a stand-alone program is available. Transportation and loading can be organized Europe-wide at extra cost upon request. Prices are subject to VAT. Inspection possible by appointment. Please contact us; our team will be happy to assist you. Machinery Purchase / Sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINERY, MACHINE TOOLS, AND MORE. Are you looking for a high-quality yet affordable machine for your production? Or do you wish to sell your machine? For further information or contact options, please reach us via the contact form.

Condition: good (used), Year of construction: 2004, For sale are 2 units of Scherer VDZ 80 DS with the following technical specifications: Swing diameter: 120 mm Z axis (vertical): 265 mm X axis (horizontal): 280 mm Blodpsy H Ifuefx Ak Eeg Front bearing diameter: 85 mm Rear bearing diameter: 75 mm 2 x A4 spindle Spindle drive rated power: 16.8 kW Rated torque: 100 Nm Speed range: 1000 - 7000 rpm Traverse speed Z axis: max. 30 m/min Traverse speed X axis: max. 30 m/min Dimensions: 2.44 x 2.3 x 1.42 m (L x H x W) Weight: 9000 kg Complete documentation available. Attention! The system will likely need some reprogramming as it was part of a complete production line. However, an individual program is available. On request, transport and loading can be organized throughout Europe for an additional charge. Prices are subject to VAT. Inspection possible by appointment. Please contact us; our team looks forward to assisting you. Machinery Purchase / Sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MORE. Are you looking for a high-quality yet affordable machine for your production? Or do you want to sell yours? For more information or contact options, please reach us via the contact form.

Condition: good (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 42L09420, Hankook Protec 9NC x 5000 CNC Lathe with Fanuc 32i Control and large spindle bore. Bljdpfx Akswcq Tmj Eeg MACHINE CONSTRUCTION & FEATURES  Heavy One Piece Cast Iron Bed Construction  Heavy Duty Hardened & Ground Solid Slideways  2 Step manual Gear Change  Heavy Duty Tailstock MACHINE CAPACITIES Swing Over Bed Ø 950 mm Swing Over Carriage Ø 630 mm Chuck Size Dia. Ø 32” Distance Between Centres 5000 mm Load Capacity Between Centres 5000 Kgs SPINDLE Speed 2 -630 Rpm Spindle Bore Ø 254 mm Spindle Nose A2-15” Speed Range Manual 2 Step Centre taper MT #6 Carriage Toolpost Automatic V8 Tool Size 32 x 32 mm X Axis Travel 535 mm Z Axis Travel 4845 mm X Axis Rapid 4 M/min Z Axis Rapid 6 M/min TAILSTOCK Quill Diameter Ø 180mm Spindle Taper MT #6 Max Quill Travel 250 mm BED Width 630 mm Length 6715 mm MOTORS Spindle 30/37 Kw Feed X 1.8 Kw Z 4.2 Kw POWER SUPPLY Electrical Supply 415V, 3Ph, 50Hz DIMENSIONS & WEIGHT Length 7470 mm Width 2205 mm Height 1890 mm Weight 10280 Kgs STANDARD MACHINE FEATURES • Fanuc 32i-A CNC Controller • Centre MT #6 • 4 Jaw Independent chuck • Automatic Spindle Shifting • Built in Live Tailstock Spindle • Coolant System • 2 Speed Tailstock Spindle • Work Light • Main Drive Motor & Elect equipment • Centre Sleeve • Chuck Cover Full Rear Guard 5000 between Centres 4-Jaw Independent Chuck & Flange Φ32" (Bore Ø254mm) 4-Jaw Independent Chuck & Flange Φ32" (Bore Ø254mm) Steady Rest(Roller Jaw) Φ250mm - Φ450mm Steady Rest (Roller Jaw) Φ450mm - Φ650mm Live Centre MT #6 Automatic Index Turret Electric V8 in lieu of manual H-4 3 Off OD Tool Holders 3 Off Boring Tool Holders Φ63mm 2 Off Facing Tool Holders Boring Bar Device Ø 150mm (Bar Excluded) Chip Conveyor 5000 Mm Transformer CE Specification Spindle Motor Upgrade 30/37 Kw Fanuc Option A (as detailed below) 1st Spindle Orientation Dynamic Graphic Display Continuous Threading Custom Macro B Extended Part Program Edit Tape Memory 320M Inch/Metric Conversion Manual Guide i Playback Programmable Data Input Run Hours & Parts Counter Tool Offsets 32 Pairs Variable Lead Threading Graphic Function Spindle Positioning Program Restart External Data Input

Condition: used, HERBERT 9C-30 TURRET LATHE MAKE HERBERT, MADE IN ENGLAND MODEL 9C - 30 MAX DIAMETER OVER BED 762.0 mm CHUCK TYPE 4 JAW CHUCK SIZE 630.0 mm MAX DIAMETER OVER CROSS SLIDE 535.0 mm MAX DIAMETER IN FRONT OF CROSS SLIDE 737.0 mm LENGTH BETWEEN CHUCK FACE -TURRET FACE 1505.0 mm TRAVEL OF TURRET 1066.0 mm DIAMETER OF HOLE THROUGH SPINDLE 125.0 mm Bjdpfx Ajy H Hc Eek Eolg SPINDLE SPEED 7 – 600 RPM PLUS OPERATOR SAFETY DOOR GOOD RANGE OF ACCESSORIES

Condition: new, Year of construction: 2024, NEW, unused machine!!! DN SOLUTIONS PUMA 5100LMB Year of manufacture: 2024 C-axis with driven tools Control: FANUC OiF touch Chuck: 21 inches (535 mm) Spindle bore: 166 mm Travels: X – 362 mm Z – 2,155 mm Maximum turning length: 2,002 mm Maximum turning diameter: 650 mm 12-position head BMT 75 Bsdsy H D Ufjpfx Ak Ejlg Knoll chip conveyor

Condition: used, Year of construction: 1983, functionality: fully functional, spindle bore: 95 mm, turning diameter: 800 mm, turning diameter over bed slide: 800 mm, turning diameter over top slide: 530 mm, turning length: 10,000 mm, For sale: PORĘBA TPK-80/10M universal lathe, year of manufacture 1983, in very good technical condition. Availability: in stock, under power, available for inspection and testing at any time. Standard equipment: Tailstock Bsdpfx Asyxgm Usk Eslg Coolant pump Tool holder Additional equipment: 1 x Traveling steady 1 x Steady rest 40–400 mm 1 x Steady rest 400–600 mm 1 x 3-jaw self-centering chuck Ø 500 mm Technical specifications: Distance between centers / turning length: 10,000 mm Swing over bed: 800 mm Swing over carriage: 530 mm Swing in gap: 1080 mm Spindle bore: 95 mm Max. workpiece weight: between centers: 6,000 kg between centers + 1 steady rest: 7,500 kg between centers + 2 steady rests: 9,000 kg Number of spindle speeds: 21 Speed range: 8 – 800 rpm Number of feeds: 80 Feed range: Longitudinal: 0.1 – 12.8 mm/rev Cross: 0.05 – 6.4 mm/rev Main motor power: 16/22 kW (1st / 2nd gear) Dimensions: Total length: 12,500 mm Width: 1,800 mm Height: 1,800 mm Weight: 11,200 kg

Condition: refurbished (used), Kern Lead Screw and Feed Shaft Lathe Type / Model: D 20 A Condition: Refurbished Technical Data Bedpfey H Eckjx Ak Eolg Centre height: 215 mm Centre distance: 600 mm Spindle bore: 50 mm Bed width: 300 mm Speed range (24): 31.5 - 1400 rpm Motor power: 4 kW Quill stroke: 150 mm Weight: approx. 1500 kg Dimensions (W x D x H): approx. 2180 x 1180 x 1560 mm Equipment: - 3-axis digital readout - Emergency stop button - Quick-change tool post, Multifix system - Machine light - Coolant system - Rotating centre

Condition: excellent (used), Year of construction: 1991, Technical Specifications HBX 360 Bodpfx Akoy H Dxwo Eelg Distance between centers (mm): 750 Center height (mm): 180 Maximum turning diameter over bed (mm): 360 Maximum turning diameter over cross slide (mm): 180 Spindle bore (mm): 37 Maximum cross slide travel (mm): 180 Cross slide width (mm): 160 Tailstock quill travel (mm): 150 Tailstock quill diameter (mm): 46 Bed width (mm): 335 Compound slide travel (mm): 110 Compound slide width (mm): 110 Type of quick-change toolpost Spindle taper type Tailstock Morse taper: MT5 Spindle speed (rpm): 50 to 3000 Spindle speed variator: Yes (hydraulic) Spindle motor power (kW): 4.5 Cross feed range (m/min): 0.0125 to 5.6 Rapid longitudinal feed range (m/min): 56 to 112 Thread cutting: Yes Metric threading (number) (mm); Whitworth thread range (tpi) Brake motor Electrical supply: 380V three phase Overall dimensions (mm): 2000 x 1000 x 1250 Weight (kg): [not specified] Chuck: Manual/Hydraulic 3-jaw Equipment: - 2-axis Heidenhain digital readout - Work light - 3-jaw manual chuck - Quick-change toolpost - Foot brake

Condition: used, Year of construction: 2001, Universal lead and feed screw lathe Manufacturer: GDW Model: LZ 360 S Year of manufacture: 2001 - workshop tested Machine no.: 1104 071 Geometric acceptance with test protocol Centre height: 175 mm Centre distance: 800 mm Accessories: - 3-axis digital display FAGOR NVP 300 TS-RS with switchable constant cutting speed - Retrofit kit for converting tailstock from crank tailstock to lever drilling tailstock - Chuck guard with electrical interlock - Braked drive motor - Emergency stop (dual, left and right) - Quick-change tool post, base body size B - Bed stop Bsdpfoy H Di Njx Ak Eelg - Rear chip guard - Removable chip tray - Coolant unit - 2 fixed centers MK 3/60° - Safety driver plate - Operation keys - CE declaration of conformity - CE documentation (operation manual) Used, sold as-is without warranty The machine's technical specification corresponds to the manufacturing year.

Condition: excellent (used), Swing over bed 330 mm Distance between centers 650 mm Spindle speeds 30-5000 rpm Spindle taper ASA A2-5 Bodpfx Akjy H Dkme Ejlg Control: FANUC 18i-T Misc. accessories MARCELS MASCHINEN CH

Condition: ready for operation (used), Year of construction: 2003, turning diameter 815 mm centre distance 3000 mm swing diameter over slide rest 485 mm spindle bore 137 mm spindle turning speed range max. 1200 rpm rapid traverse 5 m/min spindle motor 28 kW tailstock quill diameter 115 mm tailstock quill stroke 250 mm total power requirement 30 kW weight of the machine ca. 7,0 t dimensions of the machine ca. 5,87 x 2,10 x 2,10 m Equipment: * CNC-control E.C.S. 2402 Bjdpfx Aey H A Nzok Eolg * 3-jaw chuck * 4-jaw faceplate, diameter 700 mm * 4-jaw faceplate, diameter 400 mm * 3 Steady rests * Chip Conveyor Without boring bar holder and boring bar.
