Used Copying Lathe for sale (5,796)

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 7213, Country of manufacture: Switzerland Net weight: approx. 2550 kg Customs tariff number: 8458.11 20 Dimensions: 2000 x 1260 x 1950 mm TECHNICAL CHARACTERISTICS 10-axis machine – standard version 10 axes, 6 spindles: Axes and spindle designation: - 1 sliding headstock: Z1, S1 - 2 independent vertical gangs: X1Y1, S6 – X2Y2, S2 - 1 unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent rotating sub-operation axis: X4, S5 Bar feeder position: right of the operator Machine axis height: 1100 mm Main spindle travel: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: Guide bush machining: 180 mm Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (no. 76-201) Guide bush: fixed / rotating Collet for guide bush, type: Meister 605 Fgodpfxsw T Tcwo Ab Tjk Number of lateral tool stations, combined: Fixed: 2 x 5 Rotating: 3 + 3 Number of frontal tool stations, combined: Fixed: 4 Rotating: 3 Number of rear tool stations, combined: Fixed: 3 + 3 Rotating: 3 + 3 Tool section: 12 x 12 mm Standard revolving toolholder: ESX 20 Bar feeder: yes Part catcher: yes All technical details are provided without guarantee and subject to errors or omissions.

Condition: used, Year of construction: 2000, centre height 280 mm centre distance 1200 mm turning diameter over bed 570 mm turning diameter over slide 365 mm turning length 1000 mm spindle taper DIN 55027 Gr. 8 control Sinumerik 810 D SIEMENS bed width 360 mm spindle bore 62 mm turning speed range 3 - 2500 U/min feed: 5000 mm / min Fjdpfxex E Dn Aj Ab Tsgk rapid travel - longitudinal/face 10 m/min 3-jaw-chuck diameter 250 mm quick change toolholder SANDVIK Coromant Capto drive capacity - spindle motor 25 kW taper in tailstock-quill MK 5 dia. of quill 100 mm quill stroke 190 mm voltage 400 V weight of the machine ca. 5,0 t dimensions of the machine ca. 3,55 x 2,20 x 1,95 m - Serial No.: 2022-3742-03 - CNC-Control SIEMENS Sinumerik 810 D - Rapid feed - Coolant equipment - Machine lamp

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 4209.08, turning diameter: 670 mm, spindle speed (max.): 2,000 rpm, travel distance X-axis: 440 mm, travel distance Z-axis: 2,000 mm, controller model: Heidenhain Manual Plus 4110V2, TECHNICAL DETAILS Fsdpfx Aox Ex A Ujb Tsgk Maximum turning diameter: 670 mm Travel X-axis: 440 mm Travel Z-axis: 2,000 mm Rapid traverse Z-axis: 5 m/min Rapid traverse X-axis: 10 m/min Spindle bore: 106 mm Speed range: 1 – 2,000 rpm Spindle power: 33 kW Spindle mount: DIN 55026 – A8 Turret mount: Quick-change toolholder Multifix type C Number of turret stations: 1 Tailstock taper: MT5 MACHINE DETAILS Control system: Heidenhain Manual Plus 4110V2 Dimensions & Weight Machine dimensions (L x W x H): 1.9 m + center distance x 2.1 m x 1.9 m Control cabinet dimensions (L x W x H): 1.2 m x 0.5 m x 1.6 m Weight: 5,100 kg EQUIPMENT Ethernet and USB interface for network connectivity Chip conveyor Fixed and traveling steady rest Self-centering 3-jaw chuck (diameter 400 mm) Independent 4-jaw chuck (diameter 600 mm) Faceplate (diameter: 650 mm) Various clamping jaws and top jaws Fixed and revolving centers Approx. 30 Multifix holders type C Drill chuck with MT5 shank

Condition: repair required (used), Year of construction: 1999, functionality: not functional, Not functional machine, needs to repair or for spare parts. Spindle boring 65 mm Fgedjx Ew Hfepfx Ab Tjk Max. working length 120 mm 2 x head Number of tools: 2 x 8 Spindle revolutions 5.000 rpm Machine dimensions: 7560 x 1645 x 1765 mm Machine weight ca. 5000 kg Siemens Sinumerik 840C, oposite spindle, 2 heads, driving tools Bar feeder 3000 mm, chip conveyor, tool holders

Condition: like new (used), Year of construction: 2011, functionality: fully functional, spindle motor power: 15,000 W, spindle speed (min.): 5,000 rpm, travel distance X-axis: 157 mm, travel distance Y-axis: 35 mm, travel distance Z-axis: 464 mm, rotational speed (max.): 6,000 rpm, total height: 1,885 mm, total length: 3,675 mm, total width: 2,258 mm, overall weight: 9,000 kg, CNC controller: Fanuc 18i-TB Capacity X-axis travel mm: 157,5 Y-axis travel mm: 35 Z-axis travel mm: 464,8 B-axis travel mm: 600 C-axis: 360º (0,001º) Turning length mm: 399 Max. turning diameter mm: ø: 190 Distance between spindle centers mm: 750 Bar work capacity mm: 52 Upper turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Number of upper turrets: 1 Fedpfxoxiwnnj Ab Tsgk Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 6.000 Drive power driven tools kW: 5.5 / 3.7 Milling function: Both Turrets Number of lower turrets: 1 Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 15 / 11 Counter spindle Speed spindle rpm: 4.500 Drive power spindle kW: 11 / 7.5 Equipment Part catcher Workarea light Bar Loader ILS - RBK Machine running time: Nominal Kva: 67,2 Basic machine dimensions / weight Length mm: 3.675 Width mm: 2.258 Height mm: 1.885 Weight kg: 9.000

Condition: good (used), Year of construction: 2012, turning diameter: 360 mm, CONTROLS .. CNC controls BASIC FUNCTIONS .. number of x/z slides: 1 WORKING RANGE TURNING .. swing diameter (max): 360 mm .. worpiece length max.: 800 mm MAIN SPINDLE .. spindle revolutions (min): 25 /min .. spindle revolutions (max): 4000 /min ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz Fedpfx Abex Ewd Do Tjgk DIMENSIONS / WEIGHTS .. total weight approx.: 1400 kg 25 x 25 Toolholder

Condition: excellent (used), Year of construction: 2005, machine/vehicle number: P15143, Manufacturing origin JP Voltage 400 V Netweight 2400 kg Dimensions 2450x1320x1700 mm mm with bar-feeder LNS Express 200 Fsdpogfqu Sjfx Ab Togk TECHNICAL DATA Main spindle Max machining diameter Ø 16 mm Max turning length, without re-chucking 200 mm Through-hole diameter Ø 20 mm Speed 10'000 min-1 Indexing 0,001° Drive 2,2 kW Sub-spindle Max machining diameter Ø 16 mm Speed 10'000 min-1 Indexing 0,001° Drive 0,75 kW No. of rotary tools at vertical tool holder 4 Speed of rotary tools 8'000 min-1 Drive power 0,75 kW No. of tools at turret 10 Speed of rotary tools 6’500 min-1 Drive power 0,75 kW Tools 5 Drill holder for back machining 3/2 rotary (option) Collet sleeve diameter Ø 19,05 mm Tool holders, rotary tools (shank section) 10 mm Collet type (spindle and sub-spindle) F20 (138E) Drill collets ER11 Guide bush(Neukomm) F605 (61.002) Rapid feed rates, all axes 20m/min errors and omissions excepted-data given without obligation

Condition: excellent (used), Year of construction: 2004, We are offering an exceptionally high-quality precision lathe. Within its class, this is likely the best German lathe ever built. BOEHRINGER Precision Lathe Model DUE 500 Year of manufacture: 2004, including CE certification and central lubrication Machine No.: T1022.2027-00 Center height: 240 mm Swing diameter over bed: 500 mm Swing diameter over cross slide: 285 mm Center distance: approx. 1,200 mm Effective turning length: approx. 1,000 mm Bar capacity: 62 mm Spindle nose: DIN 55027 Size 6 Spindle bore: 100 mm Drive power: 11 kW Maximum torque: 2,000 Nm 24 spindle speeds: 11.2 – 2,240 rpm 60 cross feeds: 0.03 – 28 mm/rev 60 longitudinal feeds: 0.06 – 56 mm/rev Tailstock quill stroke: 190 mm Tailstock taper: MK 5 Machine footprint (LxW): approx. 4,000 x 1,525 mm Weight: approx. 4,300 kg Accessories: - HEIDENHAIN 3-axis digital readout - Central lubrication system - Electrically interlocked chuck guard - Coolant system - Chip protection rear panel Fgsdpfx Ajw Rdtheb Tok - Röhm chuck, T 250 mm, with various jaws - Telescopic cover for lead and feed screw, support to bed - Machine lamp - Multifix C + 4 quick-change tool holders - Live center - Operating manual - Circuit diagram - Rapid traverse in longitudinal and cross slides Condition: The machine is in very good technical and visual condition. Backlash on cross slide approx. 0.3 mm, on compound slide approx. 0.15 mm Spindle nose runout approx. 0.006 mm Bed geometry: deviation approx. 0.01 mm over approx. 750 mm bed length (measured on flat guideway towards chuck using dial indicator) The following parts have been renewed: - Oil change - New hoses for central lubrication - New wipers - Key for operating lever replaced - Locking pin for interlock replaced Price is net, ex stock, loaded free of charge. Delivery by company truck can be arranged at extra cost.

Condition: good (used), functionality: fully functional, turning diameter over cross slide: 240 mm, spindle bore: 54 mm, turning diameter over bed slide: 390 mm, 3-jaw chuck digital read-out Multifix tool holder device tail stock steady rest Technische Daten / technical details: Spitzenweite / center to center 765 mm Umlaufdurchmesser über Bett / rotary diameter over bed 390 mm Umlaufdurchmesser über Schlitten / rotary diameter over sledge 240 mm Umlaufdurchmesser in der Kröpfung/ rotary diameter in the gap 580 mm Spindelbohrung / spindle hole 54 mm Drehzahlbereich 16-stufig / spindle speed 16-steps 25-2000 UpM /rpm Antriebsleistung / drive capacity 5,5 kW Gewicht der Maschine ca. / weight ca. 1300 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Fjdpfxsx Evzbs Ab Tsgk Technical data, accessories and description of the machine are not binding.

Condition: good (used), Year of construction: 1990, functionality: fully functional, CNC Lathe YCM TC-2 Item number: 04-02-090 Manufacturer: YCM Good overall condition Workshop-tested machine Delivery time: Immediately – subject to prior sale Year of manufacture: approx. 1990 Dimensions (L x W x H): approx. 2400 x 1400 x 2100 mm Weight: approx. 3600 kg Control: Fanuc O-T Technical specifications: Swing over bed: approx. 480 mm Swing over cross slide: approx. 310 mm Spindle bore: approx. 52 mm Max. machining diameter: approx. 250 mm Distance between centers: approx. 550 mm Spindle speed range: approx. 110–3500 rpm Feed rate X-axis: approx. 10 m/min Feed rate Z-axis: approx. 15 m/min Turret: 8 stations Accessories: 3-jaw chuck Various tool holders Chip conveyor Machine leveling feet Fedpfx Ajwfw Sujb Tegk Documentation Live center Various chuck jaws Further accessories available on request. Price and additional technical details available upon request.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 1600x330x420 mm Fjdpfxov A Hwis Ab Tegk Weight 130 kg Total power requirement 1,1 kw

Condition: good (used), Year of construction: 2001, functionality: unexamined, machine/vehicle number: 2491, Country of manufacture: Switzerland Net weight: approx. 2550 kg Customs tariff number: 8458.11 20 Dimensions: 2000 x 1260 x 1950 mm TECHNICAL CHARACTERISTICS 10-axis machine – standard version 10 axes, 6 spindles: Axes and spindle designation: - 1 sliding headstock: Z1, S1 - 2 independent vertical gangs: X1Y1, S6 – X2Y2, S2 - 1 unit with 4 rotating spindles: X3Z3, S3 - 1 independent sub-spindle: Y4Z4, S4 - 1 independent rotating sub-operation axis: X4, S5 Fgodpsw Uc D Hsfx Ab Tjk Bar feeder position: right of the operator Machine axis height: 1100 mm Main spindle travel: max. 255 mm Bar capacity: 1 to 16 mm Spindle speed: 12,000 rpm Spindle feed rate: max. 20 m/min Bar capacity, min./max.: 13 mm / 16 mm Max. workpiece length: Guide bush machining: 180 mm Collet machining: 30 mm Sub-spindle speed: 12,000 rpm Main spindle drive power: 2.2 kW (continuous) / 3.7 kW (intermittent) Sub-spindle drive power: 1.5 kW (continuous) / 2.2 kW (intermittent) Clamping collet, type: F20 (no. 76-201) Guide bush: fixed / rotating Collet for guide bush, type: Meister 605 Number of lateral tool stations, combined: Fixed: 2 x 5 Rotating: 3 + 3 Number of frontal tool stations, combined: Fixed: 4 Rotating: 3 Number of rear tool stations, combined: Fixed: 3 + 3 Rotating: 3 + 3 Tool section: 12 x 12 mm Standard revolving toolholder: ESX 20 Bar feeder: yes Part catcher: yes All technical details are provided without guarantee and subject to errors or omissions.

Condition: new, Year of construction: 2025, Dimensions (L/W/H) 3750x1400x1750 mm Weight 1600 kg Fgjdpsv A Huhofx Ab Tok Total power requirement 8 kw

Year of construction: 2010, condition: excellent (used), machine/vehicle number: 9589 (232-0001), Manufacturing origin CH Netweight 1600 kg Custom position 8458.9120 Fsdpfxof Nqzqj Ab Tjgk Dimensions 167x87x165 cm With bar-feeder LNS Tryton 112 TECHNICAL DATA Control Fanuc série 32i-B 5 linear axes : Longitudinal travel of main spindle Z1 Longitudinal travel of backwork counter spindel Z4 Cross travel of tools X1 (turning operations and cross milling) Cross travel of tools Y1 (tools selection and milling operations) Radial plunge of 2 tools (T21 et T22) X2 Spindel (mounted on Z1-axis) : Max bar capacity 10 mm Work travel 20 mm Type of drawed collet W15 Max speed 15'000 min-1 Linear tools system mounted on 2 axes X1 and Y1 Tools system for turning comprising 2 slides controlled by X2-axis Backwork counter-spindle with motor (on axis Z4) : Max clamping 10 mm Work travel 120 mm Type of pushed collet F13 (76-00357) Max speed 15'000 min-1 Spindles denomination S1 et S4 Least increment for axes programming 0.1 µ Coolant pump max flow 50 L/min Pump motor 1,1 kW Oil tank 130 L errors and omissions excepted-data given without obligation

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: NT315HF0043, Control MSX-711 (Fanuc 3Li) for 5axes simult. Spindel A2-5 40 pos. ATC type Capto C5 Bar-feeder LNS MoveS2 INVENTORY NR.2180207, MACHINE EQUIPPED WITH : Control MSX-711 (FANUC 3Li) for 5 axes simultaneous machining, color screen 15’’ and dialog system MAPPS III Memory capacity up to 1000 programs Options : tools correctors (milling spindle), B tools life gestion, input of tools correctors G10, 3 interpolations, variable thread step (G34), circular threading, personalised macro, high precision contouring control (control II contour AI), card ATA 1 GB, offset tool for 5 axes machining Chips conveyor (with chain) model/500 B-axis with direct motor (DDS) ATC type CAPTO C5/ 40 positions Tools to zero setting system with automatic arm for milling spindle High-pressure cooling system type KNOLL with 500L tank, pump and paper filtration, for cooling through spindle centre Cutting fluid coolant unit Type KNOLL Linear measuring system for Axes X1 / Y / Z1 Tool monitoring system through control of main spindle motor and feed motors Automatic workpiece measuring system with touch-test RENISHAW and macro B for use in Milling spindle Light signal Fgedpfx Abod Hkucs Tok Automatic machine stop Workpieces receptor vat Ø52mm, L120mm 10 additional M functions Flange for cylinder, threaded ring, traction tube, bore Ø 52 Clamping chuck HAINBUCH Spanntop Axzug Nova, with stop type 100 for pieces in chuck and for jobs in bars with passage, clamping head type 32, A2-5 direct mounting, adapter Hydraulic chuck KITAGAWA, type BB206A5, Ø170mm, A2-5 direct mounting, passage Ø52mm Bar-feeder LNS, Type Move S2 Diameter of roung bars : Ø8 – 80 mm, bars length : 700 mm – 1600 mm ; loading from the front ; longitudinal shift : 470 mm ; set of guidings Ø18-20 Ø24-26 and Ø28-30 ; pushers : 1x Ø 8 – 1x Ø 15 mm ; guiding devices for main spindle Ø 21 – 26 and 31 mm Fire extinctor through carbonic gas type Tyco KLA III with 10kg CO2 Aspiration system ELBARON RON/A 3000 D-2H with full rest

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, Fanuc 31i, turning bush, pcs catcher, pcs conveyor, pce ejector, coolant tank, Robobar SBF-532 bar3600mm Manufacturing origin Japan Voltage 400V Netweight 3000 kg Dimensions 240x138x205 cm Total power Custom position 8458.11 20 TECHNICAL DATA Number of axes 8 Number of spindles 2 Control Fanuc 31i Main spindle Max bar diameter 25.4 mm Travel 230 mm Speed 10'000 min-1 Power 5.5 kW C-axis indexing precision 0.1° Counter-spindle Max bar diameter 25.4 mm Spindle speed 10'000 min-1 Power 5.5 kW C-axis indexing precision 0.1° Number of guide bushes 2 Guide bush 1 Number of positions 10 Number of motorised positions 4 Live tools speed 10’000min-1 Guide bush 2 Number of positions 6 Number of motorised positions 2 Live tools speed 10’000min-1 End-attachment Number of positions 4 Secondary operations Number of positions 2 Voltage 400V Installed power 14kW errors and omissions excepted-data given without obligation Inventory nr.2180201, machine equipped with : Control Fanuc 31i Rotating guide bush Parts catcher Parts conveying band Parts ejector Fgjdod Hihyopfx Ab Tok Coolant tank Bar-feeder Robobar SBF-532, longueur barre max 3600 mm

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 16380, CNC automatic lathe CITIZEN CINCOM L-20 VIII with Fedek STM-326 bar feeder, year 2008. Machine is fully controlled by Citizen. Supplied with geometric protocol. Fgodpfew T Stzex Ab Tsk

Condition: refurbished (used), Year of construction: 2004, machine/vehicle number: 350735, Manufacturing origin Swiss Voltage 380/50/3 Netweight 1570 kg Custom position 8458.1120 Dimensions 1830x1260x1700 mm TECHNICAL DATA Capacities Max. turning diameter Ø 270 mm Max. swing over carriage Ø 115 mm Centre height over carriage 60 mm Turning length B32 265 mm Headstock A2-4 Spindle for Schaublin collets W20 / W25 / F38 / B32 Spindle speed, continuous 50 - 5'000 min-1 Spindle inner diameter (without chuck key) 39 mm Max. bar passage in collet W20 14,5 mm Max. bar passage in automatic chuck 32 mm Max. recommended turning diameter 200 mm Pneumatic clamping Adjustable axial clamping force, force at 5 bar 1'150 daN Cross slide Cross travel, X axis 180 mm Fgodpfshr Rtnsx Ab Tjk Resolution, X-axis (at radius) 0,0005 mm AC motor drive, continuous / intermittent torque 4 / 14 Nm Ball screw, diameter x pitch Ø 20 x 5 mm Longitudinal travel, Z axis 390 mm Resolution, Z axis 0.001 mm AC motor drive, continuous / intermittent torque 4 / 14 Nm Ball screw, diameter x pitch Ø 32 x 5 mm Feed rates Working feeds, X and Z axis, stepless 0 - 5 m/min Rapid feeds, X and Z axis 8 m/min Feed forces, X / Z axis, continuous 503 / 503 daN Tooling system: Revolver Standardised tool holder attachment VDI 20 Number of tool stations 8 Number of live tool stations 4 AC motor drive, continuous / intermittent 0.55 / 1.1 kW Spindle speed, stepless 30 - 5'000 min-1 Max. tool cross-section 16 x 16 mm Integrated coolant and indexing in both directions yes Cooling Tank capacity 55 L Pump capacity 10 L/min Pressure 1.7 bar Pneumatic tailstock Taper of the spindle sleeve Morse 3 Spindle outer diameter 45 mm Spindle stroke 70 mm Adjustable contact force 25 - 260 daN Tip height from ground 1'162 mm errors and omissions excepted data gived without obligation

Condition: excellent (used), Year of construction: 2014, operating hours: 5,650 h, functionality: fully functional, machine/vehicle number: 243-0011, CNC AUTOMATIC LATHE TORNOS EVODECO 16/10 with bar-feeder LNS Fanuc 31iB - 5646 hours Manufacturing origin CH Voltage 400 V Netweight 2700 kg Dimensions 2135x1250x2114 mm TECHNICAL DATA Number of axes 10 Number of spindles 2 Main spindle Maximum bar diameter 16 mm Maximum machining length 180 mm Spindle speed 12'000 min-1 Spindle power 15.8 kW Fedpfxskhnqgj Ab Tsgk Indexing accuracy C-axis 0.001 Counter spindle Maximum bar diameter 16 mm Spindle speeds 12'000 min-1 Spindle power 15.8 kW Indexing accuracy C-axis 0.001 Tool gang 1 Number of positions 5 Number of motorized positions 3 Rotating tool speed 8'000 min-1 Tool gang 2 Number of positions 5 Number of motorised positions 3 Speed of rotating tools 8'000 min-1 End attachment Number of positions 4 Number of motorised positions 3 Speed of rotating tools 8'000 min-1 back operation Number of positions 6 Number of motorised positions 6 Rotating tool speed 8'000 min-1 Power supply Supply voltage 400V Errors and omissions excepted-data given without obligation

Condition: excellent (used), Year of construction: 2012, functionality: fully functional, machine/vehicle number: 14891, Year 2012 with Fanuc 18i-TB Fully inspected by Citizen and ready for production Country of manufacture: JP Voltage: 200V/50-60Hz/3ph. Dimensions: 1400x900x1300 mm Net machine weight: 950 kg TECHNICAL SPECIFICATIONS Controller: Fanuc Series 18i-TB 6 axes: (X1/Y1/Z1/X2/Y2/Z3) Fgedpew T S Iljfx Ab Tsk Maximum bar diameter: Ø 4 mm Maximum turning length: 40 mm Main spindle, max. speed: 16,000 rpm (12,000 rpm) Indexing: 1° Maximum speed of driven tools: 8,000 rpm Sub-spindle, max. speed: 10,000 rpm, 1° indexing Tool posts: total of 8 tools Guide bushing unit: standard Technical data provided subject to errors and omissions.

Year of construction: 1998, condition: excellent (used), machine/vehicle number: 988e510044, Control Fanuc 18i - turret1 with 12 posts turret 2 with 10 posts - chips conveyor Fodpfx Absiy A Iue Tegk

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 2410, Year 2001 with Fanuc Deco and 10 axes Fully inspected and partially overhauled as per report. Country of manufacture: Switzerland Net weight: 1500 kg Customs tariff number: 8458.11 20 Dimensions: 1650x1050x1850 mm TECHNICAL SPECIFICATIONS (standard execution) Headstock (Z1 axis) (+C axis optional) Maximum bar passage diameter: 10 mm Maximum workpiece length, depending on guide bush: 60/90 mm Programmable spindle speed: 0-16,000 rpm Positioned and indexed stops, increment: 0.1° Maximum spindle power: 1.1 (3.7) kW Tool post (X1/Y1) (X2/Y2) Number of turret tools (2 slides; 2 x 2 axes): 2 x 4 Tool section: 8 x 8 mm Number of transverse drilling/milling tools on turret: 4 Programmable rotation speed: 0-12,000 rpm End-working attachment (X3/Y3) Max. number of end-working tools: 3 Programmable rotation speed: 0-12,000 rpm Sub-spindle and secondary operation (X4/Z4) (+C axis optional) Maximum clamping capacity: 7 mm Programmable rotation speed: 0-16,000 rpm Positioned and indexed stops, increment: 0.1° Maximum number of secondary operations: 4 Number of fixed or rotating spindles: 4 Maximum spindle speed: 9,000 rpm Tornos-Bechler/Fanuc specific CNC control Processor type: 486 DX2 Number of simultaneous axes: 10 Machine versions 9 axes + spindle C axis and/or sub-spindle C axis Fgodpfx Abew T Tfre Tsk All technical details are subject to verification and provided without guarantee.

Condition: good (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 3467, Country of manufacture: Switzerland Net weight: 3000 kg Customs tariff number: 8458.11 20 Dimensions: 215 x 150 x 215 cm TECHNICAL SPECIFICATIONS (standard) Headstock (Z1 axis) (+C optional) Maximum bar capacity: dia. 20 mm Maximum part length depending on type of guide bush: 200 mm Programmable spindle speed: 0–12,000 rpm Spindle positioning and indexing increment: 0.1 degree Maximum spindle power: 3.7 (5.5) kW Tool holder (X1/Y1) (X2/Y2) Number of tools on turret (2 slides; 2 x 2 axes): 2 x 5 Tool section: 16 x 16 mm Number of cross drilling/milling stations on turret: 4 Programmable rotational speed: 0–8,000 rpm End working attachment (X3/Y3) Maximum number of end working tools: 4 Programmable rotational speed: 0–8,000 rpm Fodpfx Abjw Uczxj Tsgk Sub-spindle and secondary operation (X4/Z4) (+C optional) Maximum clamping diameter: 20 mm Programmable spindle speed: 0–12,000 rpm Spindle positioning and indexing increment: 0.1 degree Maximum number of secondary operations: 7 Number of fixed or rotating spindles: 7 Maximum spindle speed: 8,000 rpm Tornos-Bechler/Fanuc dedicated CNC Processor type: 486 DX2 Number of simultaneous axes: all All technical data are provided without guarantee and subject to change and error.

Condition: like new (used), Year of construction: 2022, operating hours: 3,800 h, functionality: fully functional, Year 2022 - 3800 hours MultiSwiss 8x26, 6 Y-axes 8 motor spindles, 11 kW – 8000 rpm max Spindle capacity 26 mm, Z stroke 75 mm (max. workpiece 65 mm) 2 X-slide units in positions 1-8, stroke 80 mm 6 X-Y slide units in positions 2-3-4-5-6-7, X stroke 55 mm, Y +/-16.5 mm Counter spindle 11 kW – 8000 rpm max Z stroke 150 mm, X 170 mm HP ejector adaptation for counter spindle (requires 3010 or 3020) Fanuc 30iB CNC control Integrated PC with Windows 10 operating system Fjdpfx Asxrfunob Tegk 21.5" color touchscreen Independent C axis on each spindle in main and counter operations (requires 0060 or 0065 or 0070 or 0075)

Condition: refurbished (used), Year of construction: 2000, functionality: fully functional, machine/vehicle number: 341966, Country of manufacture: Switzerland Voltage: 400/50/3 Net weight: 2640 kg Customs tariff number: 8458.1120 Dimensions: 2301 x 1438 x 1676 mm TECHNICAL SPECIFICATIONS Capacities: Maximum turning diameter: 330 mm Maximum diameter admitted over cross slide: 160 mm Center height over cross slide: 83 mm Maximum diameter admitted over bed: 430 mm Turning length (depending on equipment): 650 mm Headstock: Standardized spindle nose, suitable for use with various collets and chucks using adaptation accessories. Collet accessories (SCHAUBLIN): B45/F48 Maximum bar capacity, diameter: 36 mm / 42 mm Automatic chuck, standard diameter: 170 mm Direct drive via AC motor, power at 100% / 50% duty: 15 / 18.5 kW Maximum torque at 100% / 50% duty: 135 / 165 Nm Maximum spindle speed: 5000 rpm C axis: Pneumatic clamping cylinder: 2700 daN Cross slide: Transverse travel, X axis: 240 mm Radial resolution: 0.0005 mm AC motor drive, nominal torque: 3 Nm Ball screw, diameter x pitch: 32 x 5 mm Longitudinal travel, Z axis: 720 mm Resolution: 0.001 mm AC motor drive, nominal torque: 6 Nm Ball screw, diameter x pitch: 32 x 10 mm Feeds: Stepless working feeds, X/Z axes: 0–5000 mm/min Rapid traverse feeds, X/Z axes: 8 / 10 m/min Feed force, X/Z axes: 420 / 670 daN Turret tool system: Number of tool stations: 8 Standardized tool holder mounting: VDI 30 Max. tool shank size: 20 x 20 mm Integrated coolant Indexing in both rotation directions Coolant system: Tank capacity: 120 liters Pump flow rate: 10 l/min Fedsw T Smhjpfx Ab Togk Pressure: 5 bar Unless otherwise specified, the above technical details are provided without commitment or liability.
