Used Cnc Horizontal Boring Machine for sale (66,905)

Condition: refurbished (used), Year of construction: 1985, functionality: fully functional, travel distance X-axis: 1,200 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 1,500 rpm, spindle speed (min.): 5 rpm, feed length X-axis: 1,200 mm, feed length Y-axis: 2,000 mm, feed length Z-axis: 700 mm, feed rate X-axis: 1,000 m/min, feed rate Y-axis: 1,000 m/min, feed rate Z-axis: 1,000 m/min, total width: 4,000 mm, San Rocco Horizontal Boring Machine Fully overhauled San Rocco horizontal boring machine, originating from a high-end aerospace manufacturing facility. The machine is equipped with a Siemens SINUMERIK 840D CNC control system with SIMODRIVE 611 drive technology. The machine is fitted with modern digital drive systems and is designed for high-precision multi-axis machining in continuous operation. It was fully overhauled in 2024, including brand-new telescopic covers on all axes, as well as numerous additional essential refurbishments to the hydraulic system, CNC components, hoses, seals, and related assemblies. Travels X-axis (longitudinal): 1,200 mm Y-axis (cross): 2,000 mm Z-axis (vertical / spindle axis): 700 mm Spindle Data Boring spindle diameter: 100 mm Tool interface: ISO 50 Milling spindle diameter: 185 mm Spindle axial travel: 700 mm Feeds and Rapid Traverses Automatic feeds (spindle and vertical axis): 2 × 1,000 mm/min Rapid traverse (spindle and vertical axis): 5,500 mm/min Distances Minimum spindle height above table: 0 mm Maximum spindle height above table: 1,500 mm Kedpfex Rhlcex Ahvjdi Maximum distance from spindle nose to table center: 1,850 mm Spindle Speeds Torque range: 5 to 14 rpm Continuous power range: 15 to 1,450 rpm Number of gearbox ranges: 4 Speed ranges: 6–51 / 49–160 / 140–460 / 440–1,450 rpm Table Data Rotary table size: 1,100 × 1,300 mm Longitudinal travel: 1,200 mm Cross travel: 2,000 mm Table Feeds Automatic feeds X and Y: 1,000 mm/min Rapid traverse X and Y: 5,500 mm/min Table Rotation Continuous rotation: 30 to 100 degrees per minute Rapid rotation: 5,000 degrees per minute Drive System Siemens SIMODRIVE 611 E/R module 36/47 kW LT modules 108 A and 2 × 25 A Lifting and Transport Data Group 1 Steel bar Ø 70 mm, length 1,600 mm Steel bar Ø 70 mm, length 2,400 mm Four spacer rings for lifting slings Four steel slings Ø 22 mm Weight approx. 12,500 kg Group 2 Two steel slings, minimum Ø 18 mm Weight approx. 3,500 kg Group 3 Manual lifting Weight approx. 1,300 kg Condition The machine is in very good technical condition and can be inspected and tested under power by appointment.

Condition: like new (used), Year of construction: 1987, Used Giddings and Lewis Model MC 50 Twin Pallet Horizontal Machining Centre with Live Spindle, 60 ATC and G&L 8000A Control System. Serial # 445-1052.Year of Manufacture: 1987 Machine Formerly Installed at Rolls Royce Plc In Derby UK. Immediately for Sale and now Located in Belgium where it can be Inspected. Spindle Diameter - 130 MM Kjdpfx Asu Dahnjhvedi Spindle Taper - 50 ISO Spindle Travel (Z Axis) - 915 MM Spindle Speeds (4 Ranges) - 5 to 1500 RPM Main Motor - 30 HP Pallet Size - 1219 x 1245 MM Pallet Rotation Increments - 0.001 DEG (360,000 POSITIONS) Pallet Changer Max Load - 5000KGS Pallet Max Load Without APC - 9000 KGS Longitudinal Travel (W) - 1700 MM Vertical Travel Of Head (Y) - 1500 MM Cross Travel (X) - 1800 MM Feed Rates Per Minute - 1.00MM/MIN TO RAPID RATE Rapid Traverse Rate Per Minute (X And Y) - 4500 MM / MIN Rapid Traverse Rate Per Minute (Z And W) - 3000 MM / MIN Auto Tool Changer - 60 POSITIONS Electrical Supply - 415V, 3PH, 50HZ FEATURES AND EQUIPMENT High Pressure (25 Bar) Through Spindle Coolant, High Tolerance Machine. Accurate Machine which was well Maintained and Regularly Calibrated by Manufacturer. Renishaw Probing. Length - 11679 MM Width - 6502 MM Height - 4423 MM Weight - 40329 KGS

Condition: excellent (used), Year of construction: 2018, Heidenhain iTNC 640 CNC control Table dimensions: 1800 x 2200 mm Max. workpiece weight: 25,000 kg X-axis travel: 3,500 mm Y-axis travel: 2,500 mm Z-axis travel: 1,600 mm Spindle/cone diameter: 130 mm Speed range: 3,000 RPM Spindle power: 46 kW Max. torque at 100% duty cycle: 1,000 Nm Machine weight: 38,000 kg Power-on hours: 16,631 Spindle hours: 4,430 Kedow Hbnvjpfx Ahvjdi Accessories: – Controlled B-axis – 40-position tool changer / chain-type magazine – Belt filter system with high-pressure pump – Chip conveyor – Heidenhain TS 460 workpiece probe – Automatic milling head type HUI 50 – Movable operator cabin Yp = 1,600 mm, Zp = 600 mm – Centralized lubrication system – Pfannenberg oil cooler – Documentation

Condition: used, Year of construction: 2018, total height: 2,300 mm, total length: 3,870 mm, total width: 1,900 mm, Empty weight: 2.500 kg - Year: 2018 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AH/121500 - Number of milling spindles [pcs.]: 12 - Type milling table: Flat table - Tool changer positions [pcs.]: 8 - Table length [mm]: 2570 - Table width [mm]: 1290 - Working range X [mm]: 2486 - Working range Y [mm]: 1255 - Z-axis working range [mm]: 150 - X-axis maximum stroke [mm]: 3120 - Y-axis maximum stroke [mm]: 1685 - Z-axis maximum stroke [mm]: 250 - Transport dimensions: 3870mm x 1900mm x 2300mm (l x w x h) - Transport weight [kg]: 2500kg - Transport packages [pcs.]: 1 Financial information Kdsdpfx Asxrdngjhvji VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2017, operating hours: 1,717 h, total height: 2,700 mm, total length: 40,000 mm, total width: 2,400 mm, Price: On request The blade unit has a flange connection so fixed blade ( max 1000mm diam ) with 55kw at 4000rpm 5axis unit 12kw is a milling group with toolchanger Kedpowf Hw Hsfx Ahvsdi C1: 540° B1: 250° C2: 540° B2: 90° Installed dimensions: 19300x7100xH4400mm - Year: 2017 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 904B0018 - Operating hours: 1717 - Number of milling spindles [pcs.]: - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 2 - - Main motor power [kW]: 55 - Saw unit present: Yes - Table length [mm]: 14400 - Table width [mm]: 3500 - X-axis maximum stroke [mm]: 5000 - Y-axis maximum stroke [mm]: 15870 - Z-axis maximum stroke [mm]: 1000 - Voltage [V]: 400 - Current consumption [A]: 130 - Power [kW]: 65.0 - Transport dimensions: 40000mm x 2400mm x 2700mm (l x w x h) - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: good (used), Year of construction: 2012, Ref. -No.: 10558 Manufacturer: YOU JI Type: HMC 1200 BP Year of construction: 2012 Type of control: CNC Control: FANUC Series 18i-MB Storage location: Halberstadt Country of origin: Taiwan X-Travel: 1800 mm Y-Travel: 1500 mm Z-Travel: 1360 + 990 mm B-Axis: 360 ° W-Axis: 700 mm Kdjdpfx Aexxpbxjhvoi Table Dimensions (Lengthxwidth): 1200 x 1400 mm Table Load: 5.000 kg Max. Tool Weight: 25 kg Max. Tool Length: 400 mm Max. Tool Diameter: 125 mm Spindle Speed: 30 - 3.500 RPM Numbers Of Pallets: 2 Further information: 4-axis simultaneous machining IKZ (internal spindle cooling) AKZ (external spindle cooling) Synchronized walking (rigid thread cutting) Renishaw RMP60 workpiece probe (radio) Number of pallet changers for automatic pallet change: 2 Size: 1200 x 1400 mm Tool magazine, number of tools: 60 The machine is currently in production and can be viewed by appointment.

Condition: good (used), Year of construction: 2004, Ref. -No.: 10520 Manufacturer: TOS VARNSDORF Type: WHNQ 13 CNC Year of construction: 2004 Type of control: CNC Control: HEIDENHAIN TNC 430 Storage location: Halberstadt Country of origin: Czech Republic Machine-No.: 23XX X-Travel: 3500 mm Y-Travel: 2500 mm Z-Travel: 1250 mm W-Axis: 800 mm Table Load: 12.500 kg Clamping Area: 1800 x 2500 mm Tool Taper: SK 50 Tool Piece Magazine With: 60 Pcs./pcs. Spindle Speed: 3.000 RPM Max. Torque: 3323 Nm Rapid Travel X/Y/Z: 10000 mm / min Drive Capacity - Spindle Motor: 37 / 1500 kW Kedpew Nmw Hefx Ahvedi Weight Of The Machine Ca.: 40 t Further information: - Tools + accessories - Angle head - Angle up to 2.5m - Chip conveyor - 3D measuring probe - Clamping device Machine is still in production and can be inspected under power by arrangement.

Condition: excellent (used), Year of construction: 1998, Used cnc horizontal milling boring machine Brand: AYCE Model: AC100-k4 Serial number: 740 Year: 1998 Power: 16kw Weight: 12,700kg AC100-K4 MODEL WITH CONTINUOUS ADVANCE VARIATION Kodpeizxbijfx Ahvedi Numerical control: Heidenhain TNC124 with 4 axes (X, Y, Z, B) Number of bench supports: 4 (K4) OPTIONALS: - Cnc Heidenhain - Automatic positioning of the table rotation 4 x 90º. - Vertical course 1200mm (Instead of 1000mm that the standard model has) - Refrigeration equipment - Face plate and clamping arm - Universal vertical apparatus, Huron type with hydraulic tool clamping - Rest for vertical course of 1200mm - Table rotation display 4th AXIS (B) Principal axis: - Shaft diameter: 100mm - Inner cone: ISO 50 with quick tool clamping (Instead of Morse 5) - Drill mounting diameter: 171.45mm - Horizontal course of the main axis: 700mm - Vertical course of the main axis: 1200mm - Number of turning speeds: 18 - Speed range: 12-1200 rpm - Maximum distance between plate and steady rest: 2250mm Advances: - Number of work advances in all directions: INFINITE - Min/max value of work progress: 2 - 1500 mm/min. - Rapid advances in carriages and head: 3000 mm/min. - Rapid advance main axis: 1500 mm/min. - Rapid table rotation advance: 600 degrees/min. Rotary table: - Turntable dimensions: 1100x1200mm - Table longitudinal course without steady rest: 1500mm - Curos longitudinal table with lunette: 1200mm - Cross course: 1700mm - Distance between axis/maximum table center without steady rest: 1975mm - Distance between axis/maximum table center with steady rest: 1600mm Automatic centralized greasing. Hardened and rectified guide. Telescopic guide protectors. Ball screws in the 3 axes. Automatic hydraulic locks in all movements.

Condition: ready for operation (used), Year of construction: 2002, Immediately available from facility closure: CNC Horizontal Machining Center MAZAK Type FH 5800 Kdodpjyvzd Nofx Ahvei The machine is sold with all tools, pallets, and tool magazines. CNC control Mazatrol PC Fusion CNC 640 M Travel paths X/Y/Z: 710/610/660 mm Table indexing: 360 x 1 degree Pallets: 6 units Pallet size: 400 x 400 mm Spindle: SK 40 Tool magazine: 120 positions Spindle speed: 35 – 15,000 rpm Knoll high-pressure cooling system Chip conveyor Weight: 15 tons Offered at a price of EUR 18,000 plus VAT ex location

Condition: used, Year of construction: 2013, travel distance X-axis: 730 mm, travel distance Y-axis: 730 mm, travel distance Z-axis: 740 mm, controller manufacturer: Mazatrol, controller model: Matrix Nexus, workpiece weight (max.): 700 kg, total height: 2,814 mm, total length: 4,690 mm, total width: 2,330 mm, table width: 500 mm, table length: 500 mm, overall weight: 11,000 kg, spindle speed (max.): 18,000 rpm, Equipment: documentation/manual, CNC Horizontal Machining Centre CNC Control Mazatrol Matrix Nexus Pallet table size 500 x 500 mm Number of pallets 2 Table load 700 kg Movement X-Y-Z-axis 730x730x740 mm Table indexing 0,001 ° Spindle taper CAT 40 Spindle speed 18.000 1/Min Spindle motor 30/22 kW Magazin capacity 40 Kdjdpfjytc Nmjx Ahvsi If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail.

Condition: used, Year of construction: 2014, total height: 2,800 mm, total length: 10,300 mm, total width: 2,450 mm, Empty weight: 6.600 kg Price: On request - Details: - └ Description: Machine currently not working: Problem in the canbus system - Year: 2014 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA2/002546 - Number of milling spindles [pcs.]: 1 - Type milling table: Beam table - Tool clamping system: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - Tool changer positions [pcs.]: 24 - System/software: Xilog plus - Safety feature: Safety light curtain, Door interlock switches, Enclosed fence - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: Vtlf 250 - └ Year of manufacture: 2008 - └ Main motor power [kW]: 5.5 - └ Connection diameter [mm]: 70 - └ Oil free: Yes - Tools included: Yes - CNC options: Offcut conveyor, Manual control - CNC documentation available: USB stick - Table length [mm]: 5200 - Table width [mm]: 1300 - Voltage [V]: 400 - Current consumption [A]: 64 - Transport dimensions: 10300mm x 2450mm x 2800mm (l x w x h) - Transport weight [kg]: 6600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT Kdjdpeytcl Isfx Ahvei VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2014, total height: 2,800 mm, total length: 6,900 mm, total width: 2,800 mm, Empty weight: 6.100 kg Price: On request - Details: - └ Description: Needs repair to B-axis and leaks to seals - Year: 2014 - Documentation available: No - CE certificate present: No - Serial number: 10333 - Number of milling spindles [pcs.]: 2 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 5 - └ Milling spindle 2: - - Number of controlled axes [pcs.]: 3 - Type milling table: Beam table - Tool clamping system: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - Tool changer positions [pcs.]: 45 - System/software: BiesseWorks - Safety feature: Safety mat, Enclosed fence, Door interlock switches - Vacuum pump present: Yes - └ Number [pcs.]: 2 - └ Brand: Becker - └ Type: Vtlf 2.250 - └ Year of manufacture: 2011 - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 244 - └ Connection diameter [mm]: 60 - └ Vacuum pressure [bar]: 200 - └ Oil free: Yes - Tools included: Yes - CNC documentation available: User keys/licenses, USB stick Kdjdpsyr Rnuefx Ahvji - Table length [mm]: 4800 - Table width [mm]: 1500 - Voltage [V]: 400 - Current consumption [A]: 39 - Fuse [A]: 63 - Power [kW]: 22.8 - Transport dimensions: 6900mm x 2800mm x 2800mm (l x w x h) - Transport weight [kg]: 6100kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, Year of construction: 2012, operating hours: 6,586 h, total height: 2,700 mm, total length: 8,100 mm, total width: 2,450 mm, Empty weight: 4.665 kg Price: On request - Year: 2012 - Documentation available: No - CE certificate present: No - Serial number: AA2/001992 - Operating hours: 6586 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: Kdedpfx Aoyr Iqaohvsi - - Number of controlled axes [pcs.]: 4 - - C-axis present: Yes - └ Milling spindle 2: - - C-axis present: Yes - Type milling table: Beam table - Tool clamping system: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Vertical drilling spindles [pcs.]: 2 - Tool changer positions [pcs.]: 12 - System/software: Xilog plus - Safety feature: Door interlock switches, Enclosed fence, Safety mat - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: Vtlf 250 - └ Year of manufacture: 2001 - └ Main motor power [kW]: 5.5 - └ Capacity [m³/h]: 250 - └ Connection diameter [mm]: 70 - └ Vacuum pressure [bar]: 800 - └ Oil free: Yes - Tools included: Yes - CNC options: Manual control, Offcut conveyor - Table length [mm]: 6000 - Table width [mm]: 1300 - Voltage [V]: 400 - Current consumption [A]: 47 - Fuse [A]: 63 - Transport dimensions: 8100mm x 2450mm x 2700mm (l x w x h) - Transport weight [kg]: 4665kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: used, CNC Gantry-Type Boring and Milling Machine ANAYAK Type HVM-3800-P Bed type milling machine, structure similar to a plate-type boring mill with fixed table Machine No.: M-20021203 Year of manufacture: 2002 ("Refurbished 2025") The machine will be completely workshop overhauled in 2025 and can then be inspected in storage at 37235 Hessisch Lichtenau. Travel distances: X: 3,200 mm, Y: 1,200 mm, Z: 1,500 mm Table size: 3,800 x 1,200 mm T-slots: 8 pieces, 22 mm, spacing 130 mm Table load: max. 25 tons (stationary table – virtually unlimited load capacity) Spindle taper: ISO 50 (DIN69871-A) (drawbar: DIN 69872-B) Spindle speed: 60 – 4,000 rpm, stepless Feed rate: up to 10,000 mm/min, stepless Rapid traverse X + Y: 20 m/min Rapid traverse Z: 10 m/min Spindle drive: 22 / 30 kW Electrical connection: 400 Volt, 50 Hz, 50 kVA - Automatic tool changer for 30 tools - Spindle drive with 2 speed ranges - With automatic tool changer and tool magazine - Orthogonal milling head with hydro-mechanical tool clamping - Orthogonal milling head fully automatic swiveling in two 45° planes – B+C axis - HEIDENHAIN iTNC 530 control, with electronic handwheel - Prepared for wireless touch probe (probe and receiver not included) - Additional HF-spindle, 18,000 rpm – for attachment - Free-standing control cabinet - Chip conveyor positioned between the gantry bed and the machine table - 32,078 operating hours recorded - Coolant system - Free-standing hydraulic unit Ksdpfjxcgtgex Ahvedi - Operating manual with circuit diagrams Installation area (L x W): approx. 1,000 x 700 cm Installation height: approx. 410 cm Weight (total): approx. 33 tons Good condition

Condition: good (used), Year of construction: 1987, Control: Siemens 8-M X-axis travel: 10,500 mm Y-axis travel: 5,000 mm Z-axis travel: 1,250 mm W-axis travel: 1,250 mm Spindle diameter: 225 mm Spindle taper: SK 60 with adapter for SK 50 Spindle power: 100 kW Spindle speed: up to 750 rpm Spindle speed multiplier 1:4 = 3,000 rpm Kdodpfsyrb I Eex Ahvji Spindle torque: 18,000 Nm Ram cross-section: 460 x 550 mm Feed rate: 4 m/min Rapid traverse X/Y: 5,800 mm/min Rapid traverse Z/W: 4,800 mm/min The machine is supplied without clamping plate and without table.

Condition: used, Year of construction: 2012, total height: 2,700 mm, total length: 7,700 mm, total width: 2,420 mm, Empty weight: 7.390 kg CNC machining centre SCM Morbidelli M-600 Kdsdpfx Ahownhccevsi 5-axis machine Year of construction 2012 Machine no. AA2/002032 Working distance X-axis 5020 mm Working distance Y-axis 1680 mm Working distance Z-axis 250 mm Tool positions 36 Vertical drilling spindles 24  Software SCM XILOG MAESTRO SCM PRISMA K SCM TTS system Milling spindle liquid-cooled SCM TecPad MORBIDELLI TV Matic SCM PRO-SPACE SCM RAPID 12 SCM RAPID 24 Including vacuum pump Capacity 250 m3/h Disassembled for transport Weight 7450kg - Year: 2012 - Documentation available: No - CE certificate present: No - Serial number: AA2/002032 - Drilling unit present: Yes - └ Vertical drilling spindles [pcs.]: 24 - Tool changer positions [pcs.]: 36 - System/software: SCM Maestro - Vacuum pump present: Yes - └ Capacity [m³/h]: 250 - Working range X [mm]: 5020 - Working range Y [mm]: 1680 - Z-axis working range [mm]: 250 - Transport dimensions: 7700mm x 2420mm x 2700mm (l x w x h) - Transport weight [kg]: 7390kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: good (used), Year of construction: 2013, Ref. -No.: 10636 Manufacturer: TOS VARNSDORF Type: WHN 13 CNC Year of construction: 2013 Type of control: CNC Control: Heidenhain 530 Kjdpfxeyqmvxs Ahvedi Storage location: Halberstadt Country of origin: Czech Republic X-Travel: 3500 mm Y-Travel: 2000 mm Z-Travel: 1250 mm W-Axis: 800 mm B-Axis: 360 ° Table Load: 15.000 kg Tool Taper: SK 50 Turning Speeds: 1400 RPM Spindle Speed: 2000 RPM Further information: - The control system was converted to a HEIDENHAIN 530i in 2013. - All drives were upgraded to digital. Thrust bearing replacement on the tower also renewed in 2013. - Accessories: - 3D probe - Heidenhain, large spindle support - 1x Heidenhain axis module (completely overhauled), - 1 new axis module is installed in the machine. - Newly packaged spare parts, covers from the machine. - All bearings have been replaced on the machine in recent years. - Tools and milling cutter heads are available. The machine is first-hand. The machine is still powered up and in production. The machine can be viewed by appointment.

Condition: used, Year of construction: 1999, functionality: fully functional, travel distance X-axis: 13,000 mm, travel distance Y-axis: 5,000 mm, travel distance Z-axis: 1,000 mm, travel distance W-axis: 1,200 mm, MAKE: PAMA Kdjdpfxjyari As Ahvoi MODEL: SPEEDRAM 4 CATEGORY: Floor Type CNC Boring Mill YEAR OF MANUFACTURE: 1999 CNC CONTROL: Siemens Sinumerik 840C Spindle Internal Boring Spindle Taper: ISO 50 Boring Spindle Diameter: Ø 180 mm Spindle Speed Range: 2 – 1,600 rpm Spindle Motor Power: 100 kW Machine equipped with through-spindle coolant Working Capacity X Axis (Column Longitudinal Travel): 13,000 mm Y Axis (Head Vertical Travel): 5,000 mm Z Axis (Ram Cross Travel): 1,000 mm W Axis (Quill Stroke): 1,200 mm V Axis (Table Cross Travel): 3,000 mm Ram Section Dimensions: 440 x 500 mm Machine equipped with Heidenhain linear scales on all axes Table & Floor Plates Rotary Table Dimensions: 4,000 x 4,000 mm Rotary Table Load Capacity: 80 tons Rotary Table Continuous Rotation: 360,000 positions, minimum angle 0.001° Number of Floor Plates: 2 Each Floor Plate Dimensions: 7,100 x 2,400 mm Total Floor Plate Area: 7,100 x 4,800 mm Accessories Chip conveyor Coolant tank with high-pressure pump for through-spindle coolant (CTS) 1 x 90° milling head, indexing every 2.5° (C axis) Spindle oil chiller and hydraulic unit Operation manuals and electrical schematics

Condition: good (used), Year of construction: 2008, Ref. -No.: 10621 Manufacturer: PAMA Type: Speedmat 3/TR16 Year of construction: 2008 Type of control: CNC Ksdsym Nfujpfx Ahvodi Control: SIEMENS SINUMERIK 840 D PL Storage location: Halberstadt Country of origin: Italy X-Travel: 3500 mm Y-Travel: 2500 mm Z-Travel: 2200 mm W-Axis: 800 mm Bore Spindle Diameter: 160 mm Table Load: 12000 kg Table surface: 1600 x 2000 mm Tool Taper: ISO 50 BIG PLUS Turning Speeds: 3500 RPM Max. Torque: 2.765 Nm Rapid Travel X/Y/Z: 25000 mm / min Drive Capacity - Spindle Motor: 46 kW Internal cooling: 15 / 45 bar External cooling: 50 / 4 bar Spindle speed gear stage 1: 2.120 1 / min Spindle speed gear stage 2: 2.765 1 / min Further information: Automatic tool changer SK50 DIN 69871, 80 positions. Automatic angle milling head TS 35 with 360 positions, speed 2,000 rpm and torque 2,000 Nm. Automatic universal milling head TU25C (2-axis), speed 3,000 rpm and torque 800 Nm. Automatic accessory changer, 2+1 units. Touch probe (Renishaw). The machine can be inspected under power.

Condition: good (used), Year of construction: 2004, Ref. -No.: 10604 Manufacturer: UNION Type: TC 110 Year of construction: 2004 Type of control: CNC Control: SINUMERIK 840 D Powerline Storage location: Halberstadt Country of origin: Germany X-Travel: 2000 mm Y-Travel: 1250 mm Z-Travel: 1000 mm W-Axis: 550 mm Table Height: 1050 mm Spindle Diameter: 110 mm Number of T-slots: 10 Kedpfx Ajym Ndwshvodi Max. Workpiece Weight: 6000 kg Clamping Area: 1250 mm T - groove width: 22 mm T - slot spacing: 125 mm Tool Taper: ISO 50 Max. Torque: 1639 Nm Feed Speeds X/Y/Z Axis: 6000 mm / min Rapid Traverse X-Axis: 15000 m / min Rapid Travel Y-Axis: 15000 m / min Rapid Traverse Z-Axis: 15000 m / min Feed Capacities X/Y/Z: 16000 x 16000 x 20000 N swivel angle: 360 ° Further information: Includes angle head 0,001° The machine can be viewed under power.

Condition: good (used), Year of construction: 1981, Ref. -No.: 10447 Manufacturer: SKODA Type: WD 200 Year of construction: 1981 Retrofit: 2010 Type of control: CNC Control: SIEMENS SINUMERIK 840D Storage location: Halberstadt Country of origin: Germany X-Travel: 9000 mm Y-Travel: 4000 mm Z-Travel: 1450 mm Kdedpfxoym Nbpj Ahvji W-Axis: 2000 mm Bed width: 2000 mm Bed height: 550 mm Spindle Diameter: 200 mm Quill Stroke: 1600 mm Rotary Table (Lxw): 4000 x 4000 mm Table Load: 80000 kg Clamping Area: 3000 x 3000 mm Turning Speeds: 257 - 2570 RPM Spindle taper: 120 Automatic feeds: 342 mm / rev Spindle Turning Speed - Stepless: 1,5 - 630 RPM Max. Torque On The Boring Spindle: 20000 Nm Rapid Traverse: 16000 m / min Drive Capacity - Spindle Motor: 9,8 - 35,5 kW Total Power Requirement: 75 kW Bore Depth: 2000 mm Vertical headstock movement on the column: 3150 mm transverse movement of the stand on the bed: 4000 mm Lowest position of the spindle axis above the bed: 1100 mm Spindle speed when moving the quill forward: 1,6 - 300 max. rpm Drill feeds (spindle, quill) continuously variable in the range: 1,6 - 1600 mm / min Milling feeds (headstock vertical, column horizontal) infinitely variable: 1,6 - 1600 mm / min Machine length: 11350 mm Machine width: 5450 mm Machine Height: 7350 mm Weight Of The Machine Ca.: 65 t Further information: Threading: 22 metric threads, pitch range 0.5 - 12mm 32 Whitworth threads, pitch range 28 - 1 (gears) Accessories: - console for tools - 1 set of operating tools - ejector and fastening wedges for spindle - lubricating press - 1 set of spare parts for electrical equipment - clamping base plate - setting stick with electrical equipment Machine can be inspected under power by appointment.

Condition: good (used), Year of construction: 2008, Ref. -No.: 10335 Manufacturer: HüLLER HILLE Type: NBH 170 Year of construction: 2008 Type of control: CNC Control: Sinumerik 840D pl Storage location: Halberstadt Country of origin: Germany X-Travel: 1000 mm Y-Travel: 800 mm Z-Travel: 800 mm B-Axis: 360 ° Distance spindle center - table: 150 mm Table Dimensions (Lengthxwidth): 500 x 630 mm Table Load: 800 kg Max. Workpiece Weight: 40 kg Max. Tool Length: 650 mm Max. Tool Diameter: 325 mm Ksdpfjym I U Ujx Ahvodi Workpiece Diameter At Full Load: 100 mm Tool Taper: HSK - 100 Spindle Speed: RPM Rapid Traverse: 60 m / min Machine length: 9500 mm Machine width: 4500 mm Machine Height: 3500 mm Further information: Coolant system = 1250 l

Condition: excellent (used), Year of construction: 2011, Axis travel: 560x560x620 mm MSX-501 control system Machine is stocked in our Bulgaria warehouse. IN OUR STOCKS WE HAVE: *Horizontal Machining centers *CNC lathes 2 axis *CNC lathes 2 axis + C axis *CNC lathes 2 acis + C axis + Y axis *CNC tapping centers *CNC vertical machining centers %100 owned +50 CNC machine tools in stock! Kdedpfxonyh R Tj Ahvei You are welcome to contact us for your further questions CNC World Machine LTD

Condition: used, Horizontal machining center with 2-fold shuttle table STEINEL type BFZ 5 with CNC control SIEMENS Sinumerik 810 M serial no. 34 year of construction 1988 Travel X: 500 mm, Y: 400 mm, Z: 320 mm Clamping surface, table surface 500 x 400 mm Tool holder ISO 40 Spindle speed max. 6300 rpm infinitely variable Main spindle drive 12 kW Mains connection 380 Volt, 50 Hz, 30 kVA - Tool changer with 24 tool positions - Changing table with 2 stations - Interface for data transfer - Coolant unit with chip conveyor Kjdpfx Aheutuyisvjdi Space requirement L x W x H 4100 x 2500 x 2650 mm Weight approx. 8 tons good condition Transport dimensions: Machine L x W x H 3200 x 2500 x 2650 mm, approx. 7.5 tons. Chip conveyor L x W x H 3500 x 1100 x 2100 mm, approx. 600 kg

Condition: used, Year of construction: 1986, spindle diameter 1 mm x-travel 1 mm Kodjylzv Ajpfx Ahvjdi y-travel 1 mm total power requirement 1 kW
