Used Chisel Mortiser for sale (399)

Condition: used, Year of construction: 1973, Storage location: Nattheim Kjdpevvkt Ujfx Ahvodi

Condition: used, Year of construction: 2007, Fully programmable 3 axis horizontal CNC swing chisel mortiser suitable for general joinery and furniture production. By a combination of automatic movement of the mortisting head in the x axis and an automatic gripper that positions the timber no manual movement or handling of the component is required other than loading and positioning the timber against the pneumatic reference stop and then unloading when the mortising cycle is finished. The complete movement, clamping and, mortising cycle is fully automatic. X, Y and, Z axis movements are all via re-circulating ball and screw drives and using linear slideways to give maximum positioning accuracy. Thanks to the programmable Z axis it is possible to produce off line mortises, double mortises or produce thicker mortise slots with the same chisel. Programming is very simple thanks to the 'user friendly' graphic touch screen controller were programs can be memorised and stored under a number or specific name up to 8 characters. The swing chisel cutter itself produces a very clean mortise slot and if required for deep mortises up to 3 depths of cut can be programmed to give a 'woodpecker' type cutting operation. Other programming options include working off either the face of the timber or the thickness and the possibility to produce mirror image components (left/right hand) in one program. Year - 2007 CE X axis stroke 1100mm. Y axis stroke 250mm. Max. depth of cut 120mm (depending on chisel size) Z axis stroke 100mm Max. workpiece height of 120mm. All movements on re-circulating ball and screw drive with brushless motor Max. workpiece width 200mm Max. swing chisel thickness 20mm. Min . slot length 25mm approx (with swing chisel) Min. slot thickness 6mm. 3 vertical pneumatic clamps. 3 horizontal pneumatic clamps. 4 hp main motor. 'Power 1000' touch screen graphic controller with 99 programs each with 50 lines. USB key facility. Programmable speed for cutting depth. Anti splinter guards with air blowers and dust extraction points. Working table dimensions 1210mm x 215mm Kjdpfx Aheymnbnjvsdi Air supply 6 bar / 470 l/min consumption. Fitted with separate dedicated programmable hollow chisel head for producing the small mortises for glazing bars

Condition: used, Square Mortise Drill, 4-sided Mortiser Kdjdpfxjxw Rbde Ahvji Chain Mortiser, Tenon Mortise Machine MAKA (Max Mayer) TYPE ED 30 Serial No. 3130 Tenon width: 75 mm Throat depth: 0 to 75 mm (without wood plate) Hand lever stroke: approx. 125 mm Max. clamping width: 140 mm Chisel width: 8 mm Speed: 2800 rpm Motor power: 0.3 kW Power connection: 380 Volt, 50 Hz - Adjustable mortise stroke via eccentric shaft - Depth feed via hand lever - Mortiser adjustable up to 75 mm via threaded spindle - Quick-release lever for clamping device - Double column guide, robust design - Suitable for mortising rectangular holes for tenon joints Dimensions (L x W x H): 420 x 360 x 400 mm Net weight: 38 kg Very good condition

Condition: ready for operation (used), Technical characteristics Table dimensions 1000 x 300 mm Control on the chassis + pedal Motor power : 2,2 kW Mechanical counter SIKO Protected machine MortaisageChisel Power and Motors Voltage: 380 V Pluging: Three-phased Kjdot T Igpspfx Ahvsdi Motor: 3 CV Overall dimensions Weight: 650 Kg

Condition: ready for operation (used), Technical characteristics Square mortises, chipped, without lubrication Horizontal frontal stroke 90 mm Pneumatic feed Tilting head Pneumatic presser Aluminium table 1200 mm Ideal machine for furniture and carpentry Kedpet Dgbmjfx Ahvedi Power and Motors Pluging: Three-phased Overall dimensions

Condition: ready for operation (used), Technical characteristics Kdjdpfx Ahjt Dgb Hjvei Square mortises, without lubrication Horizontal front stroke 90 mm Pneumatic feed Tilting head Pneumatic presser Aluminium table 1200 mm Ideal machine for furniture and carpentry Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Square mortises, chipped, without lubrication Horizontal front stroke 90 mm Pneumatic feed Tilting head Pneumatic press Kodpfxouaiike Ahvjdi Aluminium table 1200 mm Ideal machine for furniture and carpentry MortaisageChisel Power and Motors Overall dimensions

Condition: ready for operation (used), Technical characteristics Mortise length : 20 to 110 mm Mortise thickness : 2 to 29 mm Max. mortise depth : 110 mm Cast-iron frame, aluminum table Manual workpiece clamping (2 vertical pressers and 1 front presser) Motor 1.1 kW (1.5 hp), 3000 RPM Wood dimensions : Width : 30 to 150 mm Thickness : 15 to 80 mm Automatic part feed from magazine Automatic mortising head feed Power and Motors Voltage: 380 V Pluging: Three-phased Power: 1,5 Kw Motor: 1,5 CV Overall dimensions Lenght: 4100 mm Width: 1350 mm Height: 1500 mm Ksdpjt Dgacsfx Ahvsdi Weight: 600 Kg

Condition: ready for operation (used), Technical characteristics 3-axis controlled mortising machine Max. machinable solid part size : 275 x 160 mm Max. mortising depth : 130 mm Hydraulic motor : 0.75 kW Work table : Kdsdpfx Ahot Dgaievsi Dimensions : 1000 x 310 mm Longitudinal travel : 400 mm Cross travel : 150 mm 2 extensions, length 1200 mm Extension with electronic stop : 2600 mm Electronic stop travel speed : 40 m/min Workpiece clamping with hydraulic pistons (2 front and 2 vertical) Mortising heads : Manual vertical adjustment Motorized vertical adjustment Vernier for quick calculation of chisel oscillation angle 2.2 kW motor Pneumatic circuit operating pressure : 6-8 bar Upper suction mouth diameter : 80 mm Suction speed : 25-30 m/sec Power and Motors Voltage: 380 V Pluging: Three-phased Power: 3 Kw Motor: 3 CV Overall dimensions Lenght: 1000 mm Width: 1400 mm Weight: 850 Kg

Condition: new, Automatic mortising machine with 3 heads Kdjdpen Nv Txjfx Ahvji Worktable dimensions 3000 x 300mm Cast iron construction to give maximum rigidity 3 x vertical hydraulic work piece clamps 3 x horizontal hydraulic work piece clamps Speed movement in adjustable through hydraulics Automatic operation Mortising heads x 3. Manually positioned in X axis with mechanical locks Mechanical siko readouts for height position - Z axis Double eccentric operation of the mortising heads (patented design) Motor HP3 RPM 2800mm Max distance between 2 x outside mortising heads 2800mm Min distance between 2 x outside heads 180mm - ctre to ctre of mortise. Dust extraction outlets 100mm Hydraulic pump motor 10hp

Condition: new, Centauro BETA 3 Axis CNC Swing Chisel Mortiser A new fully programmable 3 axis horizontal CNC swing chisel mortiser suitable for general joinery and furniture production. By a combination of automatic movement of the mortisting head in the x axis and an automatic gripper that positions the timber no manual movement or handling of the component is required other than loading and positioning the timber against the pneumatic reference stop and then unloading when the mortising cycle is finished.The complete movement, clamping and mortising cycle is fully automatic. X,Y and Z axis movements are all via re-circulating ball and screw drives and using linear slideways to give maximum positioning accuracy. Thanks to the programmable Z axis it is possible to produce off line mortises, double mortises or produce thicker mortise slots with the same chisel. Programming is very simple thanks to the 'user friendly' graphic touch screen controller were programs can be memorised and stored under a number or specific name up to 8 characters. The swing chisel cutter itself produces a very clean mortise slot and if required for deep mortises upto 3 depths of cut can be programmed to give a 'woodpecker' type cutting operation. Other programming options include working off either the face of the timber or the thickness and the possibility to produce mirror image components (left/right hand) in one program. On request the machine can be equipped with a separate dedicated programmable hollow chisel head for producing the small mortise holes for glazing bars. Alternatively a horizontal milling head can be specified that can be used for hinge recessing, slotting for louvre doors etc etc. X axis stroke 1100mm. Y axis stroke 250mm. Max. depth of cut 120mm (depending on chisel size) Kdjdeb Tmpqepfx Ahvji Z axis stroke 100mm Max. workpiece height of 120mm. All movements on re-circulating ball and screw drive with brushless motor Max. workpiece width 200mm (wider on request). Max. swing chisel thickness 20mm. Min . slot length 25mm approx (with swing chisel) Min. slot thickness 6mm. 3 vertical pneumatic clamps. 3 horizontal pneumatic clamps. 4 hp main motor. 'Power 1000' touch screen graphic controller with 99 programs each with 50 lines. USB key facility. Programmable speed for cutting depth. Anti splinter guards with air blowers and dust extraction points.1 x 80mm 1 x 60mm dia. Working table dimensions 1210mm x 215mm Installed power 3.6kw. (std machine) Air supply 6 bar / 470 l/min consumption.

Year of construction: 1997, condition: repair required (used), Mortising machines Maka Db-6 v Second hand 1977 Make: Maka Model: Db-6 v Description: Kdedpfx Ahsfd Rxqsvei VERTICAL MORTISER MAKA DB-6 V Year of construction: 1977 Machine condition: very good afer repairs capital Offertype: used machine offer Location: Poland Technical data: AFTER REPARIRS VERY IMPORTENT VERTICAL Year: 1977

Condition: reconditioned (used), Mortising machine, swing chisel mortising machine MAKA type DB 5 with many mortising tools, see pictures Workpiece stop 2 pieces Stop rail right / left 2150 mm Workpiece blow-out 2x Foot switch Pneumatic workpiece clamping on the side 1 piece Pneumatic workpiece clamping from above 2 pieces Kdjdjv Hm Nmspfx Ahvji Extraction connection D 120 mm Weight approx. 550 kg Dimensions approx. L x W x H = 1200 mm x 800 mm x 1500 mm (without stop rails) Note on used machines: • Errors in technical information and prior sale reserved. • Prices stated are pick-up prices from location - free loading! • The machines have been cleaned and function-tested. • All machines are purchased as seen without any claim to warranty. The buyer is free to inspect the machines on site. • Special agreements are only possible in writing. (We will only answer inquiries if you provide your address + telephone number!)

Condition: good (used), Code: 0284 Brand: MASTERWOOD Model: LABOR B1/V - CE Standard 1-Head vertical chisel mortising machine for wooden frames, doors, solid wood and various - CE Standard Technical data Head motor Hp 3 Head vertical stroke mm 150 (useful mm 110) Kdedjtmvpzjpfx Ahvji Head longitudinal stroke mm 285 Head transversal stroke mm 80 Worktable vertical stroke mm 260 Pneumatic workpiece clamping Overall dimensions mm 900 x 900 x 1800 h Weight kg 410

Condition: excellent (used), GSP M 743 mortising machine Stroke (mm): X450 Y500 Slide travel (mm): 300 Max. table tool distance (mm): 450 Gooseneck (mm) : 590 Slot width 25 30 mn Ksdpfoulfuzex Ahvsdi Table diameter (mm): 700 Feed speed (mm/mm): 0.1-2.5mm/Cp Main motor power (HP): 6 Machine equipped with : Automatic feeds/Slide tilting Dimensions WxDxH (mm) : 2300x1700x2600 Machine weight (T) : 3.5 Overall dimensions 2500x 2200 height 2400

Condition: excellent (used), Year of construction: 1998, Haffner Door Lock Mortising Machine used, in good condition Manufacturer: Haffner Model: SL 100 Machine No.: 5372 Column-type machine Chain mortising unit Door support Workpiece support Handle hole motor Faceplate motor Lubrication system Extraction connection D 80/100 mm Space requirements approx. 1200 mm x 700 mm x 2000 mm Weight approx. 300 kg Storage location: at customer's site Sale as is, as inspected, without guarantee or warranty Kedoyuty Sepfx Ahvedi

Condition: like new (used), Chain Mortiser LS 103 EO - 8.7 kg - Year of manufacture: 2016 - 230 Volt - with stand - 2600 Watt Kdedpfx Aeyty I Hjhvei

Condition: new, Year of construction: 2026, Number of boring spindles 1 St. Boring depth max. 150 mm Kdjdpfx Aeytx Uxjhvsi Motor output 1,5 kW

Condition: new, Year of construction: 2026, Number of boring spindles 1 St. Boring depth max. 150 mm Motor output 1,8 kW Götzinger HR 150 - Hoffmann system The machine that gives you the highest precision when drilling two levels guaranteed. Frame and slot drilling machine, enables drilling in two levels in one clamping. - Well thought-out, precise and practical stop system - particularly smooth and play-free grid positioning, Feed and transverse adjustment Kdodpoytx T Ijfx Ahvji - Guidance systems for the highest demands - Special drill chuck - precise, quiet concentricity - for drilling levels via digital display - Two side stops offer enormous advantages, center stop on request - Continuous front stop with position markings - Drilling pattern depending on the wood profile - free choice, in a 12 mm grid Special grids also possible - integrated dust extraction - the exchangeable additional equipment (e.g. drill heads, Miter stops, parapet railing device, side and folding stops) can be easily installed without tools. and dismantle. Technical data: Drilling unit ----- Height adjustment in 2 levels via digital display Height adjustment 100 mm pneumatically Drilling stroke/depth 150 mm by hand Transverse adjustment 320 mm via grid Drilling pattern width 12 mm pitch, standard Three-phase motor 230/400 V, 50 Hz, 1,420/2,840 rpm, 1.3-1.8 KW Tool holder ----- Special drill chuck with 2 tool changing inserts 1 x M10, 1 x D 16 stop system ----- 2 side stops can be swiveled in/out 1 longitudinal stop (tube) with adjustable folding stop approx. 1500 mm Elongated hole stop left and right Workpiece clamping ----- pneumatically via foot valve Dust extraction Special accessories - see PDF attachment (technical data according to manufacturer - no guarantee!)

Condition: excellent (used), Chain milling machine - Wall-mounted with multiple chains - 3 rails - robust design - 380 volts Kdedpfxeytvr Is Ahvei

Condition: used, used, in good condition with double-sided handwheel adjustment with digital displays for tool diameter - milling depth - jaw offset Manufacturer: Panhans Type: 204 Kdsdeyt R Nzopfx Ahvji Cast iron fence jaws Jaw length right: 450 mm Jaw length left: 450 mm Digital displays for: - Diameter - Cutting depth - Jaw offset Original price approx. 6,000 EUR Extraction connection D 120 mm Weight approx. 66 kg Location: 97447 Gerolzhofen, loaded free on truck, unpacked Offered in as-inspected condition, without warranty or guarantee

Condition: used, Year of construction: 1980, Used machine Year of manufacture: 1980 Features and technical data: - Lock case milling unit Kdsdpfeyq T Ibsx Ahvji - Handle hole borer - Face plate milling cutter - 1.5 kW motor - 2800 rpm Availability: short-term Location: 63934 Röllbach

Condition: used, Lower and upper drill, tiltable, for chair seats of Old America type or similar products no. 4 independent lower groups, tiltable Kedpfx Ahjytr Edevsdi No. 2 upper vertical oscillating groups

Condition: used, used, good condition, low operating hours, with accessories with pneumatic lift for drilling on two levels Make: Ganner Model: Junior Motor: 1.5 kW Two-lever operation Table size 850 x 360 mm Drill chuck 20 mm Dowel drilling device with 24 positions Kdedpfjythcrsx Ahvji Workpiece stop Central stop Pneumatic lift Pneumatic workpiece clamps, 2 pcs Space requirement approx. 300 x 1000 x 1300 mm Weight approx. 270 kg Storage location: 97447 Gerolzhofen, free loading, unpacked Delivery in current condition as inspected, function tested without overhaul, without guarantee or warranty

Condition: used, Year of construction: 1938, used, in good condition, low operating hours Kodpeythcfsfx Ahvjdi including various chain sets Manufacturer: Haffner Model: KF20 Year of manufacture: 1978 Machine no.: 20378 Column machine + chassis Chain set 12-17 / 50 x 175 J3 Door support Required space approx. 750 x 800 x 2000 mm Weight approx. 200 kg Storage location: 97447 Gerolzhofen, free loaded, unpacked Handover in current condition as inspected, without guarantee or warranty
