Used Boring And Milling Machine for sale (69,707)

Condition: excellent (used), functionality: fully functional, feed length X-axis: 4,000 mm, feed length Y-axis: 1,000 mm, feed length Z-axis: 1,500 mm, feed rate X-axis: 15,000 m/min, feed rate Y-axis: 15,000 m/min, feed rate Z-axis: 15,000 m/min, spindle speed (max.): 3,000 rpm, table length: 4,000 mm, table width: 1,000 mm, CNC ECS 2301 (with the possibility of retrofitting) SPINDLE ISO 50 DIN 2080 taper AC motor: 28 kW (S1/100%) Constant torque from 0 to 250 rpm Constant power from 250 to 3.000 rpm Two automatic ranges TABLE (X-axis) Length 4.000 mm Width 1.000 mm Travel 4.000 mm Number of T-slots: 7 Width of slots: 18 mm Working feed rate 0 – 8.000 mm/1' Rapid feed rate 15.000 mm/1' HEAD (Y-axis RAM) Y-axis travel 1.000 mm Working feed rate 0 – 8.000 mm/1' Rapid feed rate 15.000 mm/1' Dcjdpjw Axmnefx Ac Hji VERTICAL CARRIAGE (Z-axis) Z-axis travel 1.500 mm Working feed rate 0 – 8.000 mm/1' Rapid feed rate 15.000 mm/1' COLUMN (W-axis) W-axis travel mm 1.300 Working feed mm/1' 0 – 8.000 Rapid feed mm/1' - 15.000 ACCESSORIES: 40-position tool magazine

Condition: used, Year of construction: 1995, SECOND-HAND END-CUT OFF BORING AND MILLING MACHINE BACCI MOD. TTF1 - CE RULES - Volt. 380/50 - S/N 333 Dodpfx Acjmxfhmj Hjci - Year 1995

Condition: new, Year of construction: 2025, functionality: fully functional, travel distance X-axis: 375 mm, travel distance Y-axis: 230 mm, spindle speed (max.): 1,700 rpm, spindle speed (min.): 115 rpm, type of input current: three-phase, overall weight: 200 kg, table length: 700 mm, table width: 190 mm, power: 0.75 kW (1.02 HP), distance table to spindle center: 405 mm, WMD32G - ROGI Gear-Driven Milling and Drilling Machine Drilling Capacity ----- 32 mm Face Milling Capacity ----- 63 mm End Milling Capacity ----- 16 mm Work Table Dimensions ----- 700 x 190 mm Dcedpfxjx N Ndqs Ac Hji T-Slot Dimensions ----- 12 mm Spindle Taper ----- ISO30 Max. Distance Spindle - Table ----- 405 mm Spindle Travel ----- 75 mm Head Tilting ----- Left / Right 45 Degrees Table Longitudinal Travel ----- 375 mm Table Cross Travel ----- 230 mm Speed Range 115 - 1700 rpm Weight ----- 200 KG Motor ----- 750W AC Voltage ----- 230V (INVERTER) INCLUDES * 3-axis digital readout SINO * Floor stand * Digital depth stop * ISO30 milling arbor including 6 collets * Drill chuck with shank DIN2080 / ISO30 * Left / Right switch * Spindle guard * Drift key

Condition: excellent (used), Year of construction: 1992, functionality: fully functional, machine/vehicle number: 06651, travel distance X-axis: 6,800 mm, travel distance Y-axis: 3,700 mm, travel distance Z-axis: 1,500 mm, feed rate X-axis: 15 m/min, feed rate Y-axis: 15 m/min, feed rate Z-axis: 10 m/min, total length: 15,000 mm, total width: 7,500 mm, spindle speed (max.): 4,000 rpm, total height: 7,000 mm, table height: 1,100 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 10 m/min, distance between stands: 3,300 mm, type of input current: three-phase, table load: 50,000 kg, rotational speed (max.): 4,000 rpm, distance table center to spindle nose: 2,110 mm, overall weight: 110,000 kg, spindle motor power: 50,000 W, control cabinet length: 7,000 mm, control cabinet height: 2,000 mm, control cabinet width: 600 mm, Equipment: rotational speed infinitely variable, MODEL: Portal Type AGE: 1992 S/N #: 06651 CATEGORY: Mills, Planer Type, CNC CAPACITY: X-Axis Travel: 6800 mm Y-Axis Head Travel: 3700 mm Z-Axis Ram Stroke: 1500 mm, fixed crossrail Ram Cross Section: 500 mm x 500 mm Distance Between Columns: 3300 mm Distance Table To Ram Face: 2110 mm, vertical passage 2000 mm Table Size: 6000 x 2500 mm Spindle (Quill) Diameter: 250 mm Spindle Taper: ISO #50 Spindle Speeds: 0-4000 RPM Spindle Motor: 50 KW EQUIPPED WITH: FIDIA System C20 CNC Control, new in 2002 CNC biaxial continous milling head Universal Milling Head with Auto Indexing Right Angle Head with Auto Indexing Straight Milling Head Wagons for Head Change and Tool Pick-up Change Hydrostatic Bearings Coolant System Dcjdpfx Acjyahv Sj Hji Full Length Chip Conveyors both side Way Covers Rapid movements: Z-10.000 mm/min, X and Y-15.000 mm/min Table load: max 50.000 kg Weight of the machine: 110.000 kg Outside dimensions: 15.000 x 7.500 x 7050 mm Machine has been tested before dismantling and is fully operational, all mechanical components in excellent condition, electrics new in 2018. Machine available from stock. The price is now SPECIAL FROM STOCK. Once we will reassemble the machine, price will grow significantly. We can assist you to assemble and run up the machine.

Condition: like new (used), Year of construction: 2008, functionality: fully functional, Complete factory equipment for sale: weaving, embroidery, dyeing, finishing, and processing. Many more machines are available. Textile Department * Jacquard Weaving: 11 × Picanol looms, Model 2004, XC 870 (Belgian) * Air-Jet Jacquard Weaving: 8 × Picanol looms, Model 2004 XL Dcsdpfx Aoziz Dyec Hsi * Air-Jet Jacquard Weaving: 6 × Picanol looms, Model 2004, 5400 Jacquard Bonas, Jumbo * Complete set of air compressors, dryers, and air tanks required for operating the weaving machines. * Dobby Weaving: 4 × Picanol Omni looms, Model 1999 * Air-Jet Dobby Weaving: 8 × 2004 looms, 2.5 m working width, suitable for producing linen, gabardine, and dress fabrics (Picanol Omni Plus) * Rapier Weaving Machines (Chinese): Model 2014 – 4 units * Modern Warping Machine: 720 / 11 cones – 1 unit * Karl Mayer Weaving Machines: Model 2021 – 4 units * Karl Mayer Weaving Machines: Model 2017 – 2 units * Sizing Machine: 3 units ⸻ Embroidery Department * Saurer Epoca Embroidery Machines: 4 machines, equipped with 5 special attachments * Spooling/Winding Machines: Belinda – 9 units * Spooling/Winding Machines: Barmag – 1 unit, Kaltema – 2 units * Complete set of air compressors, dryers, and air tanks required for operation. * Mouline Thread Production Line with all accessories (embroidery threads). ⸻ Finishing Department * Rams: 1 × Brückner, 6-chamber, with Mahlo, Model 2002 * Stenters: 3 Turkish Damson machines * Fabric Inspection Machine: 1 unit * Sewing Machines: 30 units * Fabric Pressing and Packaging Machine ⸻ General Factory Utilities * Industrial Chillers: 2 units * Steam Boiler: 6 tons, Riello burner, 2018 * Steam Boiler: 0.5 ton * Fabric Dyeing Jet Machine: 50 kg * Yarn Dyeing Machine (Hank): 600 kg * Yarn Dyeing Machine: 2 × 300 kg, complete with winding and unwinding system * Hydro Extractor: 1 for yarn + 1 for fabrics + 1 for hanks

Condition: excellent (used), Year of construction: 2010, XYZ SMX 5000 3 Axis CNC Bed Milling Machine ProtoTRAK SMX Control Spindle: 7.5Hp – Programmable 70 – 5000rpm ISO40 Quill Dia 105mm Manufactured 2008 Table: 1930 x 355mm Dcedjy Ni Ivopfx Ac Hsi 4 off T Slots size 15.9mm Max load 850kgs Travel: X – 1524mm Y – 596mm Z – 584mm Dims: W - 5805mm D – 2530mm H – 3143mm Weight - 3100Kgs For sale with *Jet Machinery Ltd* Stock No: 79199 Serial No: 11273 Price: £24,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: excellent (used), Year of construction: 2017, XYZ 2000 Turret Milling Machine (2017) (Ex College) 3 Axis Newhall DRO (X, Y & Knee) Spindle Taper R8 Spindle speeds to 500 – 4200 rev/min Table Size 1270 x 254mm Table Travel: X - 812mm Y - 406mm Knee Travel: Z - 406mm Quill Travel Z - 127mm For sale with Jet Machinery Ltd Jet Machinery Stock No: #79047 Machine Serial Number: 12907 Cost: £9,950.00 + VAT Djdpfxexxb Rrj Ac Hsci Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: excellent (used), Year of construction: 2021, XYZ RMX 3500 3 Axis CNC Bed Milling Machine ProtoTRAK RMX Control YOM 2021 Spindle: Dcodsx D Tbmepfx Ac Hji 5HP – Programmable 40 – 5000rpm 2 Ranges 40 – 600 & 300 – 5000rpm ISO40 Quill Dia 105mm Table: 1370 x 355mm 4 0ff T Slots T Slot size 15.9mm Max load 600kgs Travel: X – 787mm Y – 508mm Head Vertical (Z) – 500mm Quill (Z) 127mm Dims without travel – 1905 x 2069 x 2225mm Dim with travel – 2758 x 2869 x 2490mm Weight 2430Kgs Power Requirements 22A Air Requirements 6bar YOM 2021 For Sale with Jet Machinery Ltd Jet Machinery Stock Number: #78900 Machine Serial Number: RM310097 £35,000.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, machine/vehicle number: 05 17 1994, travel distance X-axis: 2,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,250 mm, controller model: Heidenhain TNC 415, swivel angle B-axis (max.): 360 °, TECHNICAL DETAILS Travel range X-axis: 2,000 mm Travel range Y-axis: 2,000 mm Travel range Z-axis: 1,250 mm B-axis: 360° Table size: 1,600 x 1,800 mm Djdszha Injpfx Ac Hsci MACHINE DETAILS Control system: Heidenhain TNC 415 Tool holder: SK 50 ATC: 60 Note: Angles are not included in the scope of delivery. The machine has already been disassembled.

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 7853, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, spindle speed (max.): 3,000 rpm, controller model: Heidenhain TNC 426 C, No minimum price – guaranteed sale to the highest bidder! Loading can be carried out by the seller for €750! TECHNICAL DETAILS Travel in X-axis: 4,000 mm Travel in Y-axis: 1,200 mm Travel in Z-axis: 2,000 mm Spindle type: ISO 50 Spindle power: 50 kW Spindle speed: up to 3,000 rpm Table length: 5,000 mm Tool changer: 30-position ATC MACHINE DETAILS Control system: Heidenhain TNC 426 C Headstock Swiveling: Automatic Increment: 1 degree / 2.5 degrees / stepless Dimensions & Weight Dimensions (L x W x H): 9,000 mm x 5,000 mm x 5,000 mm Weight: 35,000 kg EQUIPMENT Hydrostatic guideways in all axes Tool holders Coolant preparation/filtration system Chip conveyor Cooling system, manufacturer: Deerosdassi Dcedpezdtxfsfx Ac Hoi Control cabinet system Note: The machine has already been professionally disassembled and is in storage.

Condition: ready for operation (used), Year of construction: 1984, functionality: fully functional, travel distance X-axis: 1,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, spindle speed (max.): 3,000 rpm, controller model: DIXI CNC 4400, TECHNICAL DETAILS Travel range, X-axis: 1,000 mm Travel range, Y-axis: 1,000 mm Travel range, Z-axis: 1,000 mm Vertical movement with pallet changer (Y-axis): 880 mm Distance from spindle axis to top of table: 0 – 1,000 mm Distance from spindle axis to top of table with changer: 0 – 880 mm Table dimensions without changer: 840 x 1,000 mm Table dimensions with standard changer: 800 x 800 mm Max. table load: 2,000 kg Max. table load with pallet changer: 1,200 kg Table rotation: 360° continuous Rapid traverse: 1,500°/min T-slots: 7 equally spaced slots, width 18 H7 Tool interface: ISO 50 Spindle speeds: 8 – 3,000 rpm (in 3 ranges) Drive power: 11 kW Drive power with overload: 13.75 kW Max. torque: 200 kpm Working feed rates (X, Y, Z): 1 – 9,999 mm/min Rapid traverse (X, Y, Z): 9,999 mm/min Measuring system resolution: +/- 0.001 mm / 0.001° Positioning accuracy: 0.001 mm / 0.001° Dcsdpfx Acezd Rizj Hei Distance from table axis to spindle flange: 390 mm to 1,390 mm MACHINE DETAILS Control system: DIXI CNC 4400 Installed total power: 47 kW Compressed air requirement: 6 kg/cm² Dimensions & Weight Dimensions (L x W x H): 4,835 x 4,160 x 3,190 mm Machine weight: approx. 17 t Compressed air requirement: 6 kg/cm²

Condition: used, Year of construction: 2014, power: 75 kW (101.97 HP), controller model: BECKHOFF CONTROL, TECHNICAL DETAILS Number of upper units: 4 With NC positioning: yes Lateral horizontal units: yes Upper vertical units: yes Horizontal units: yes Number of upper vertical units: 4 With NC positioning: yes Dcjdpozf Ibwsfx Ac Hei With NC "Z"-axis positioning: yes Spindles for vertical drilling: 112 Number of lateral horizontal units: 4 With NC positioning: yes With NC "Z"-axis positioning: yes Spindles for horizontal drilling: 12 MACHINE DETAILS Control system: BECKHOFF CONTROL Total installed power: 75 kW EQUIPMENT Protective grid attached to the machine Safety light barriers Automatic waste disposal system The machine is sold and delivered in its actual and legal condition ("as is, where is") based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 8649

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 0-253-05-4317, workpiece height (max.): 60 mm, workpiece length (max.): 1,250 mm, workpiece width (max.): 800 mm, controller model: Powercontrol PC85T mit Woodwop software, TECHNICAL DETAILS Process: horizontal drilling – injecting adhesive – driving in dowels Workpiece length min/max: 20 mm / 1,250 mm Workpiece width min/max: 50 mm / 800 mm Workpiece thickness min/max: 10 mm / 60 mm MACHINE DETAILS Control system: Powercontrol PC85T with Woodwop software Dowels: 8 mm x 30 mm, 8 mm x 35 mm Voltage: 400 V Frequency: 50 Hz Phases: 3-phase Dcjdszhm Sgepfx Ac Hoi EQUIPMENT Drilling unit: 1 drilling and dowel insertion unit, freely programmable Z-axis manually adjustable Drilling depth manually adjustable Center stop pneumatically lowerable 4 vertical clamping cylinders Double diaphragm pump 1:1

Condition: ready for operation (used), Year of construction: 2017, functionality: fully functional, machine/vehicle number: F3S171901, table width: 180 mm, table length: 600 mm, coolant tank capacity: 30 l, pump capacity: 15 l/min, TECHNICAL DETAILS Clamping table dimensions: 600 x 180 mm Tool holder: SK30 Dcedpfx Acszhm Afs Hji Drawbar: M12 x 220 mm T-slots: similar to DIN 650 MACHINE DETAILS Coolant tank: 30 l Delivery rate: 15 l/min Saddle adjustment: handwheels Spindle drive: 2-pole motor via multi-ribbed belt EQUIPMENT Arbor clamping Cooling system with 30-liter tank Coolant tank with quick-release fastener Control panel Work light Coolant hose CE marking

Condition: new, Features > 5-axis simultaneous CNC machine > Basic structure made of polymer concrete > Wet/dry machining > Workpiece zero-point clamping system > Servo drives with absolute encoder > Integrated control with touchscreen Options > Machine base frame > Various Zero-point clamping devices: T-slotted plate, four-jaw chuck, precision vice and blank holder Dcodpfx Aehqhkiec Hoi > Automatic placement system > 3D measuring probe > Why buy? Simply finance. Talk to us! The iMG 1010 is a compact solution for processing workpieces up to 100x100x100 mm. With its basic structure made of polymer concrete, it enables precise processing of numerous materials such as titanium, steel, CoCr, ceramics, sapphire, zirconium or aluminum. Particularly noteworthy is the arrangement of the Y-axis, which ensures high stability and enormous vibration damping thanks to its installation positions. Almost all positions on the workpiece can be reached without reclamping. The selection of workpiece clamping devices and holders in conjunction with the zero-point clamping system makes the machine a versatile machining center. Its design enables wet/dry machining without time-consuming retooling. The CNC machine can be extended with an optional loading and unloading system, which accesses the machine room from the right, left or from above. This allows workpieces to be changed automatically. The zero-point clamping system serves as an interface and ensures the exact and repeatable positioning of the workpiece. The system can be integrated into network-controlled, automated production processes using software interfaces. The maintenance-friendly design and the long-lasting direct spindle drives save service costs and time and offer a reliable machining system. During the design phase, care was taken to ensure that all elements are easily accessible and yet protected from external influences in order to guarantee a long service life. The sophisticated system offers numerous options for expansion.

Condition: new, Portal machine - the space miracle! CNC portal milling machine for large traverse paths with small space requirements! ADVANTAGES: -optimized space utilization, completely free table clamping area -best possible chip protection due to overhead axes -particularly suitable for high and bulky components -PILZ safety technology -Windows 10 APPLICATIONS: -chipping -measuring and testing -dosing applications FOR MACHINING: -Aluminum / light metals -Milled plastics -Ceramics -Non-ferrous metals (brass, bronze, etc...) Dcsdpfxshqhlve Ac Hji -Plastics -Wood Maximum functionality with minimum space requirements is the motto of the OverHead Gantry M. The basic machine can be optimally configured for many sectors and work areas using a variety of variable equipment features and additional options. The possible applications of the OverHead Gantry M include measuring, testing and metering applications in addition to machining. The power of the milling motor of up to 2.2 kW and 20,000 rpm and a traverse speed up to 250 mm/sec make it suitable for processing wood and plastic as well as light and non-ferrous metals. The free processing area and its excellent price/performance ratio off er decisive benefits compared to similar products. The OverHead® Gantry M is available in five different sizes for different process areas from M20 to M50. Do you require the control cabinet on the right-hand side or would you prefer the control panel to be on the left? No problem – we will be happy to accommodate your requirements. And of course we will take care of maintenance and support for your OverHead® Gantry M. Our service technicians can be reached by telephone and can attend to you quickly on-site as needed. In addition, we also off er our in-house isy-CAM 2.8 software and can advise you on your specific application. BENEFITS: -Optimal use of space -Free machining area -Fixed table, mobil portal -Variable clearance of 340- 590 mm -Also suitable for a large chip volumes SET UP: Portal: mobil, Table: Fixed

Condition: new, machine/vehicle number: 280261 0001, Features > CNC machine ready for mains connection > Low-noise due to maintenance-free servo motors > ergonomically slim design > powerful isel control with maintenance-free servo motors > reliable linear units with steel ball screws are installed as drives > effortless operation thanks to height-adjustable display Dodpfxjlnikkj Ac Heci > network-compatible control PC with WINDOWS > user-friendly soft-lift hood > clamping of the workpieces by means of T-slot plate options > milling spindle 500W - 1200W > Linear tool changing station > Tool cooling as cooling spray or air version (CoolMin) > Length measuring probe > Vacuum clamping table > Maintenance unit with valve terminal > Substructure table with swivel screen and integrated keyboard > Substructure table is used to install the vacuum pump, cooling unit and other peripheral devices > Automatic hood opening > Safety light curtain > Why buy? Simply finance. Talk to us! The iCV 4030 EC is a compact tabletop machine with a proven, optimized chassis design. A practical substructure table with monitor and integrated keyboard is available as an option. The CNC machine has a modular design; all control components, including the isel CNC control and the control computer, are installed at the rear and are easily accessible for servicing. All linear axes mounted in the machine are from the isel range; they run with linear ball bearings on ground precision steel shafts. Backlash-free ball screw drives with various spindle pitches are used as drives. The machine table made of face-milled T-slot profiles offers a wide range of clamping options for individual workpiece fixtures and clamping devices. The iCV 4030 EC is suitable for numerous areas of application and industries; experience has shown that it is preferably used for machining. A comprehensive range of accessories tailored to your application rounds off the program.

Condition: ready for operation (used), Year of construction: 1969, x-travel 700 / 710 mm y-travel 275 mm z-travel 350 mm Dsdpfozkbnzox Ac Hjci taper in main spindle ISA 40 table surface area 900 x 250 mm T-slots 3 x 18 x 60 Stk. turning speeds 32.0 - 2000 U/min feed stepless 15 - 750 mm/min voltage 400 V total power requirement 4.0 kW weight of the machine ca. 1400 kg range L-W-H 1000 x 1400 x 1800 mm from a training workshop (vocational school) Features: - Robust, electric-motor-driven universal milling machine - With horizontal and vertical main spindles * Vertical main spindle can be swiveled 360° in two planes - Sturdy T-slot clamping table with 18 mm T-slots - Electric feed control - Stepless speed adjustment - Swiveling machine light - Control cabinet, installed on the right - Original operating instructions Machine data sheet

Condition: as good as new (ex-display), CNC Engraving Machine, CNC Milling Machine, CNC 3020 Desktop Engraving Machine / Mini CNC Milling Machine – 200 × 300 mm Working Area, Used Machine Manufacturer Engraving Machine Model 3020 Overall Dimensions Width: 400 mm Depth: 530 mm Height: 400 mm Controller Dimensions Width: 290 mm Depth: 325 mm Height: 175 mm Shipping Dimensions 500 × 400 × 390 mm 410 × 345 × 280 mm Technical Specifications Machine Type: Engraving Machine / Mini CNC Milling Machine Model: 3020 Serial Number (SN): 2501053020CZ12-11 Effective Working Travel: X-axis: 200 mm Y-axis: 300 mm Z-axis: 50 mm Power Supply: AC 200–240 V, 50 Hz (operates from a standard 230 V household/workshop power supply) Dodozka R Uopfx Ac Hsci Manufacturer Information Manufacturer: Changzhou Huajiang Electrical Co., Ltd. (China) European Importer / Distributor: CNCworld Group Sp. z o.o. (Jednia-Letnisko, Poland) Certifications CE RoHS FCC

Condition: used, Year of construction: 1986, Serial no. 2203-1703, travel range X/Y/Z 500 x 400 x 400 mm, universal milling table 660 x 380 mm (rotatable and swiveling), active digital display, lighting, maximum speed 3,150 rpm, tool vice. Dcodpezkaq Iofx Ac Hoi +++ ATTENTION: This machine is part of an online auction! +++

Condition: new, Centauro ALFA NC Machining Centre For Joinery Components & Doors A versatile and flexible NC controlled machining centre suitable for a variety of machining operations including hinge recessing, lock slots, handle holes, key slots and euro grooves etc. Programming is extremely simple thanks to the colour graphic touch screen controller using pre-installed electronic macros. As standard the machine can be equipped with one milling head that automatically moves for either vertical or horizontal machining. It also has interpolation of the axis. Optional additional machining operations include producing a square corner hinge plate recess or lock face recess by means of the additional milling unit. The operator simply selects in the program if they want a radius or square corner and the machine does the rest. In addition the same milling head can be used to make the small pilot hole for hinge screws etc. There is also the possibility to produce a square end tenon, round end tenon or dovetail / dovetail slot when the special front table is fitted. Lastly on request the machine can be configured to import ISO files from external design software (e.g ARTCAM Express) to enable detailed engraving of items such as name plates etc. Axis capacity - X 2800mm, Y 180mm, Z 150mm. (2400mm X capacity when optional drilling head fitted). 1 x ER32 collet for milling cutter 16mm max. dia. Max working table dimensions - 3000x618mm X axis positioning speed 35m/min. Y axis / Z axis positioning speed 6m/min. Retractable pneumatic positioning stops 2 off - on front of table Adjustable pneumatic workpiece clamps x 3 - mounted on rear of table. Left hand side ref. stop. Front table extension supports x 2 Dcedpfeb Tmngox Ac Hoi Router motor power 3.3kw. Router motor RPM 0-18,000 rpm. Touch screen controller - Elco Power 1000. Dust extraction outlet x 1 80mm dia, 2 x 100mm dia CE side and rear safety guards with front light curtain.

Condition: as good as new (ex-display), Year of construction: 2025, The machine is on display. OPTIMUM F 200 HSC Premium CNC milling machine, directly from the manufacturer. F 200 HSC – The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control system is characterized by its performance, speed, precision, and long service life. Heavy-duty design · High productivity · High reliability · Heavily ribbed, torsion-resistant machine base · Profile rail with recirculating roller guides for high rapid traverse speeds in all axes · Powerful servo drives in all three axes · Telescopic guide cover on all three axes · Automatic lubrication · Solid, precise milling table with five T-slots, large dimensions, and precision-ground surface · The portable, electronic handwheel with feed override button and emergency stop switch facilitates the easy execution of programs Nwswouy Tckex Eb Ncsi · Coolant system with chip flushing system and cleaning gun · Spindle internal cooling with 20 bar · Chip conveyor in belt design ensures efficient chip removal · Chip cart · RJ45 connection and power connection 230 V · Enclosed control cabinet with integrated heat exchanger ensures optimal temperature and prevents the ingress of dirt particles · Machine light in the work area · Additional package SIEMENS material defect liability and free online/on-site service OSS Plus · 1 year maintenance contract Basic included in D/A/CH Milling spindle Inline spindle Machine data Electrical connection 400 V / ~50 Hz Total connected power 20 kVA Milling spindle Drive motor S1 operation 10.5 kW Torque of drive motor S1 operation 50 Nm Drive motor S6-30% operation 26.4 kW Dcsdpfxozi Ex Ue Ac Hoi Torque of drive motor S6-30% operation 125 Nm Spindle mounting SK 40 / DIN 69871 Coolant system Performance of coolant pumps, 3 pieces 1 kW Flow rate 35 l/min Tank capacity 200 liters Cleaning pump Performance of cleaning pump 530 W Milling accuracy Repeatability ± 0.005 mm Positioning accuracy ± 0.005 mm Tool changer Type Double-arm gripper Number of tool positions 24 Tool diameter max. 78 mm Tool diameter (auxiliary positions free) max. 120 mm Tool length 300 mm Tool weight max. 8 kg Time for tool change: Tool to tool 2.5 seconds Travel range X-axis 850 mm Y-axis 500 mm Z-axis 550 mm Feed drive Rapid traverse X, Y, Z axis 48 m/min Torque motor X/Y/Z axis 16 Nm / 16 Nm / 20 Nm Feed forces X/Y/Z axis 5.34 kN / 5.34 kN / 6.68 kN Speed range Speeds* 12,000 min-1 Pneumatics Air pressure 6 - 8 bar Air consumption per hour 6 - 8 kg/m³ Milling table Distance spindle - table 100 - 650 mm Table length x width 1,000 x 500 mm T-slot size / number / spacing 18 mm / 5 / 100 mm Load capacity max. 500 kg Dimensions Length x width x height 2,400 x 2,355 x 2,860 mm Total weight 5,500 kg

Condition: excellent (used), Year of construction: 1996, completely overhauled in 2005 Number of spindles: 2 Drilling capacity per spindle, steel: 1-6 mm Drilling depth: max. 350 mm Z travel: 350 mm W travel: 350 mm Drive power per spindle Djdpfey Eykgjx Ac Hsci - 100% duty cycle: 3.7 kW - 50% duty cycle: 5.5 kW Spindle speed: 3,000 - 27,000 rpm Spindle mounting: Ø 10 - 60 mm Coolant pressure: max. 150 bar Coolant flow: 48 l/min Coolant volume: 1,000 l Compact band filter High-pressure pump

Condition: excellent (used), Long-hole drilling machine HT200 - with laser Dcodpoy Tub Aofx Ac Hoi - swiveling - 2 levels - outriggers on the left and right - year of manufacture: 1994 - swivel range 65°-0-65° - 400 volts - pneumatic clamping and feed system

Condition: used, functionality: fully functional, ERNAULT SOMUA Milling Machine Dcjdpfx Acsziy A Ue Hji Type: ZHV1 Travel: 750 x 250 x 400 Table surface: 1200 x 300 Weight: 1400 kg
