Used Angular for sale (471)

Condition: new, Bernardo Universal Lathe Smart 410 x 1500 Pro Vario Technical Specifications Centre distance: 1500 mm Centre height: 210 mm Swing over bed: 420 mm Swing over gap: 580 mm Swing over cross slide: 255 mm Bed width: 250 mm Spindle bore: 52 mm Spindle mount: DIN 55029, D1 – 6 Speed range, 2 stages: 30 – 550 / 550 – 3000 rpm Longitudinal feed range (17): 0.05 – 1.7 mm/rev Cross feed range (17): 0.025 – 0.85 mm/rev Metric threads (42): 0.2 – 14 mm Imperial threads (45): 2 – 72 TPI Quill diameter: 50 mm Quill travel: 140 mm Quill taper: MT 4 Motor power: 5.5 kW (7.5 HP) Machine dimensions (W x D x H): 2590 x 1050 x 1600 mm Weight: approx. 1325 kg Features • Equipped as standard with Delta frequency inverter for high torque at low speeds and nearly constant speed under load • Infinitely variable speed control, selected speed displayed digitally • Prism bed made of cast iron, inductively hardened and precision ground • Central, user-friendly feed and thread control with leadscrew and feed shaft • Modern main spindle bearings with precision angular contact ball bearings • Standard features include frequency inverter and 3-axis digital readout • Hardened and ground gears and shafts, including in the feed gearbox • Speed and feed settings are simple, smooth, and precise to operate • Adjustable tailstock for taper turning, handwheel with fine scaling (0.02 mm) • Removable bridge allows machining of large-diameter workpieces Scope of Delivery • 3-axis digital readout ES-12 V with LCD display Ihedoxl Ta Sjpfx Ahvow • 3-jaw steel chuck PO3-200 mm / D6 • Faceplate 350 mm • Fixed steady – max. workpiece diameter 135 mm • Travelling steady – max. workpiece diameter 65 mm • Foot pedal with brake function according to CE • Four-way tool post • Safety guard for four-way tool post • Micrometer longitudinal stop • Turret stop with fine adjustment • Frequency inverter • First fill with Shell Tellus 46 • Coolant system • Slip clutch • Thread dial indicator • LED machine lamp • Change gears • Reducing sleeve • 2 dead centres • Chip guard/rear screen • Operator tools

Condition: new, Bernardo Universal Lathe Titan 560 x 3000 Pro Vario Technical Specifications Centre distance: 3000 mm Centre height: 280 mm Swing over bed: 560 mm Swing over gap: 785 mm Swing over cross slide: 350 mm Bed width: 350 mm Spindle bore: 105 mm Spindle mount: DIN 55029, D1 – 8 Speed range: 25 – 220 / 220 – 1500 rpm Longitudinal feed range (42): 0.055 – 3.061 mm/rev Cross feed range (42): 0.025 – 1.384 mm/rev Metric threads (41): 0.1 – 14 mm Inch threads (60): 2 – 112 TPI Quill diameter: 75 mm Quill stroke: 185 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (L): 4340 mm Width x Height: 1150 x 1610 mm Weight: approx. 3000 kg Features • Standard with Delta frequency inverter for high torque at low speed and nearly constant speed under load • Stepless speed control, with digital speed readout • Versatile applications in general engineering, production, single-part manufacture, etc. • Removable gap bridge allows machining of large-diameter workpieces • Rapid traverse longitudinally and in cross direction as standard, reducing non-productive time Ijdpfx Aoxl Tdqshvehw • Modern main spindle bearing with precision angular contact ball bearings • The machine bed is made from a single casting, extremely torsion-resistant and low-vibration, providing the foundation for precise turning • Tailstock is adjustable for taper turning • Central lubrication system for carriage Scope of delivery • 3-axis digital readout ES-12 V with LCD display • 3-jaw chuck PS3-315 mm / D8 • Fixed steady rest – max. workpiece diameter 180 mm • Travelling steady rest – max. workpiece diameter 120 mm • Foot pedal with CE-compliant brake function • Safety guard for quick-change tool post • LED machine lamp • Initial fill with Shell Tellus 46 • Faceplate 450 mm • 2 centre points • Frequency inverter • Digital speed readout • Safety slip clutch • Rapid traverse longitudinally and in cross direction • Coolant system • Quick-change tool post with 4 holders • Change gears • Reducing sleeve • Chip guard tool kit

Condition: new, Industrial belt sander Scantool 75 x 2000 sanding belt 75 x 2000 mm Working width: - 75 mm Engine: - 4,1 HP Speed: - 34 m/sec Table height: - 475 to 1240 mm grinding belt dimensions: - 75 x 2000 mm surface grinding surface: - 530 mm Weight: - 76 kg The industrial belt grinder models Scantool 75 x 2000 and 150 x 2000 are powerful quality machines, built according to the strictest environmental and safety regulations. Iedpod Dw Ncofx Ahvehw The belt grinders are equipped as standard with motor brake, adjustable working height, eye protection, angle stop and motor protection switch with Zero-voltage release built. The low-noise machine with CE mark is ideal for grinding all metals. Motor protection switch with zero voltage release Separate emergency stop Motor Brake Adjustable angular stop Eye protection The infinitely variable working height enables an ergonomically correct working position Perfect construction for fast, effective and safe grinding Self-adjusting strap tension Danish top quality

Condition: new, Bernardo Universal Lathe Titan 660 x 3000 Technical Specifications Distance between centers: 3000 mm Center height: 330 mm Swing over bed: 660 mm Swing over gap: 900 mm Swing over cross slide: 460 mm Bed width: 400 mm Spindle bore: 105 mm Spindle mount: DIN 55029, D1-8 Speed range: (16) 25 - 1600 rpm Longitudinal feed range: (25) 0.044 - 1.48 mm/rev Cross feed range: (25) 0.022 - 0.740 mm/rev Metric threads: (54) 0.45 - 120 mm Inch threads: (54) 7/16 - 80 TPI Tailstock quill diameter: 90 mm Tailstock quill travel: 235 mm Tailstock taper: MK 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (W x D x H): 4630 x 1200 x 1520 mm Approx. weight: 3300 kg Features • Versatile use in general mechanical engineering, production, single-part manufacturing, etc. • Central, user-friendly control for feeds and threading with leadscrew and feed shaft • Prism bed made of cast iron, inductively hardened and precision ground • Modern main spindle bearings with precision angular contact roller bearings • Hardened and ground gears and shafts, also in the feed gearbox • Rapid traverse longitudinal and cross as standard to reduce non-productive times • Large spindle bore (105 mm) for machining workpieces with large diameter • Smooth start-up via mechanical multi-plate clutch • Electromechanical foot brake to reduce non-productive times • Optimal cutting performance even during facing operations Iodpjxxayfofx Ahvehw • Bed reinforced with robust ribs to stiffen the guideway and minimize vibration influences Scope of Delivery • 3-axis digital readout ES-12 V with LCD display • Slip clutch • Rapid traverse longitudinal and cross • LED machine light • 3-jaw steel chuck PO3-315 mm / D8 • Face plate 450 mm • Fixed steady rest – through hole diameter max. 180 mm • Travelling steady rest – through hole diameter max. 120 mm • 2 live centers • Motor with magnetic brake to CE standard • Foot pedal with brake function to CE standard • Initial filling with Shell Tellus 46 • Coolant system • Quick-change tool post with 4 holders • Safety device for quick-change tool post • Change gears • Reducing sleeve • Chip guard rear panel • Cable management via energy chain • Operating tools

Condition: new, Bernardo Universal Lathe Smart 410 x 1000 Pro Vario Technical Specifications Centre distance: 1000 mm Centre height: 210 mm Swing over bed: 420 mm Swing over gap: 580 mm Swing over cross slide: 255 mm Bed width: 250 mm Spindle bore: 52 mm Spindle mount: DIN 55029, D1 – 6 Speed range, 2 steps: 30 – 550 / 550 – 3000 rpm Longitudinal feed range (17): 0.05 – 1.7 mm/rev Cross feed range (17): 0.025 – 0.85 mm/rev Metric threads (42): 0.2 – 14 mm Inch threads (45): 2 – 72 TPI Quill diameter: 50 mm Quill travel: 140 mm Ijdpjxl Tarefx Ahvohw Quill taper: MT 4 Motor power: 5.5 kW (7.5 HP) Machine dimensions (W x D x H): 2090 x 1050 x 1600 mm Weight approx. 1145 kg Features • Standard with Delta frequency inverter for high torque at low speeds and nearly constant speed under load • Infinitely variable speed control, with set spindle speed displayed digitally • Prism bed made of grey cast iron, induction-hardened and precision ground • Central, user-friendly controls for feeds and threading with leadscrew and feed shaft • Modern main spindle bearing arrangement with precision angular contact ball bearings • Standard with frequency inverter and 3-axis digital readout • Hardened and ground gears and shafts, including those in the feed gearbox • Simple, smooth, and precise adjustment of speed and feed settings • Sliding tailstock for taper turning, handwheel with adjustable fine scale (0.02 mm) • Removable gap bridge for machining large-diameter workpieces Scope of Delivery • 3-axis digital readout system ES-12 V with LCD display • 3-jaw steel chuck PO3-200 mm / D6 • Face plate 350 mm • Fixed steady rest – max. capacity dia. 135 mm • Travelling steady rest – max. capacity dia. 65 mm • Foot pedal with brake function, CE compliant • Four-way tool post • Safety guard for four-way tool post • Micrometer longitudinal stop • Indexing stop with fine adjustment • Frequency inverter • Initial fill with Shell Tellus 46 • Coolant system • Slip clutch • Thread dial indicator • LED machine lamp • Change gears • Reducing sleeve • 2 centre points • Chip guard (rear) • Operating tools

Condition: new, Bernardo Universal Lathe Solid 460 x 1000 Pro Vario Technical Specifications - Distance between centres: 1000 mm - Centre height: 230 mm - Swing over bed: 460 mm - Swing over gap: 690 mm Ihodsxl Tcaspfx Ahvew - Swing over cross slide: 270 mm - Bed width: 300 mm - Spindle bore: 80 mm - Spindle mount: DIN 55029, D1-8 - Spindle speed range: 25 – 250 / 250 – 1700 rpm - Longitudinal feed range (42 rates): 0.055 – 3.065 mm/rev - Cross feed range (42 rates): 0.025 – 1.386 mm/rev - Metric thread pitches (41): 0.1 – 14 mm - Inch thread pitches (60): 2 – 112 TPI - Quill diameter: 60 mm - Quill travel: 130 mm - Quill taper: MK 4 - Motor power: 5.5 kW (7.5 HP) - Machine dimensions (W x D x H): 2300 x 1080 x 1600 mm - Weight: approx. 1730 kg Features • Modern headstock spindle bearing with precision angular contact ball bearings • Standard-equipped with Delta frequency inverter for high torque at low speeds and near-constant speed under load • Infinitely variable speed control; set speed is shown on the digital display • Hardened and ground gears and shafts, including in the feed gearbox • Standard longitudinal and cross rapid traverse for minimized idle times • Central, user-friendly controls for feeds and threading, with leadscrew and feed rod • Large-size gears, hardened and precision-ground • Simple, smooth and precise speed/feed adjustments • Machine bed is one-piece cast, extremely rigid and low-vibration for accurate turning Scope of Delivery • 3-axis digital readout ES-12 V with LCD display • 3-jaw chuck PS3-250 mm / D8 • Fixed steady rest – max. diameter 150 mm • Travelling steady rest – max. diameter 110 mm • Initial fill with Shell Tellus 46 • Face plate 450 mm • Quick-change toolpost with 4 tool holders • Safety guard for quick-change toolpost • Foot pedal with CE-compliant braking function • Coolant system • Frequency inverter • Slip clutch • Longitudinal and cross rapid traverse • Change gears • Reducing sleeve • 2 dead centres • Thread dial indicator • LED machine lamp • Chip guard • Operating tools

Condition: new, Bernardo Goliath 500 x 1500 Production Lathe Technical Specifications Centre distance: 1500 mm Centre height: 250 mm Swing diameter over bed: 500 mm Swing diameter over gap*: 720 mm Swing diameter over cross slide: 310 mm Bed width: 400 mm Spindle bore: 80 mm Spindle mount: DIN 55029, D1-8 Speed range (24 steps): 9 – 1600 rpm Longitudinal feed range (80 steps): 0.063 – 6.43 mm/rev Cross feed range (80 steps): 0.027 – 2.73 mm/rev Metric threads (46): 1 – 224 mm Inch threads (44): 1/8 – 28 TPI Quill diameter: 75 mm Quill stroke: 150 mm Quill taper: MT 5 Motor power: 7.5 kW (10.0 HP) Machine dimensions (L x W x H): 3020 x 1240 x 1550 mm Weight approx.: 3285 kg * Removable gap bed section length: 200 mm Features • Versatile applications in general mechanical engineering, production, single-part manufacturing, etc. • One-piece cast machine bed ensures maximum rigidity and minimal vibration, providing the essential prerequisite for precise turning • Modern precision angular contact ball bearing spindle bearings • Central, user-friendly feed and thread control, with lead and feed shafts • Rapid traverse in longitudinal and cross directions as standard to reduce idle time • Large-dimension, hardened and precision-ground gears • Removable gap bridge allows machining of large-diameter workpieces • Adjustable tailstock for taper turning, handwheel with fine graduation (0.02 mm) • Electromechanical foot brake to minimise non-productive time • Excellent cutting performance, even during facing operations Scope of delivery • Slip clutch • Rapid traverse longitudinal and cross • LED machine lamp • 3-axis digital readout ES-12V with LCD display • 3-jaw chuck PS3-250 mm / D8 • Face plate 400 mm • Fixed steady rest – max. through diameter 200 mm • Follow rest – max. through diameter 110 mm • 1 live centre / 1 revolving centre • Motor with magnetic brake as per CE standards • Foot pedal with brake function as per CE • Initial fill with Shell Tellus 46 • Coolant system • Quick-change tool post with 4 holders • Safety device for quick-change tool post Iedpfx Ahexl D Aksvjhw • Reducing sleeve • Chip guard (rear) • Operating tools

Condition: new, Industrial belt sander Scantool 75 x 2000 with integrated with double suction sanding belt 75 x 2000 mm Working width: - 75 mm Engine: - 4,1 HP Speed: - 34 m/sec Table height: - 475 to 1240 mm grinding belt dimensions: - 75 x 2000 mm surface grinding surface: - 530 mm Weight: - 100 kg Ihedpfeflt Amsx Ahvsw The industrial belt grinder models Scantool with double extraction 75 x 2000 and 150 x 2000 are powerful quality machines, built according to the strictest environmental and safety regulations. The belt grinders are equipped as standard with motor brake, adjustable working height, eye protection, angle stop and motor protection switch with Zero-voltage release built. The low-noise machine with CE mark is ideal for grinding all metals. Motor protection switch with zero voltage release Separate emergency stop Motor Brake Adjustable angular stop Eye protection The infinitely variable working height enables an ergonomically correct working position Perfect construction for fast, effective and safe grinding Self-adjusting strap tension Danish top quality

Condition: new, Bernardo universal lathe Titan 660 x 2000 Technical Specifications Centre distance 2000 mm Centre height 330 mm Swing diameter over bed 660 mm Swing diameter over cranking 900 mm Swing diameter over cross slide 460 mm Bed width 400 mm Spindle bore 105 mm Spindle mounting DIN 55029, D1-8 Speed range (16) 25 - 1600 rpm Range of longitudinal feeds (25) 0.044 - 1.48 mm/U Plan feed range (25) 0.022 - 0.740 mm/U Metric threads (54) 0.45 - 120 mm inch thread (54) 7/16 - 80 Gg/1″ Pinol diameter 90 mm Sleeve travel 235 mm Sleeve holder MK 5 Engine power 7,5 kW (10,0 PS) Machine dimensions (W x D x H) 3630 x 1200 x 1520 mm Weight approx. 2900 kg Features & Benefits Versatile application possibilities in general mechanical engineering, production, single part production, ... Central, handy switch for feeds and threads with guide and feed spindle Prism bed made of grey cast iron, inductively hardened and precision ground Modern main spindle bearings with angular contact roller bearings in precision design Hardened and ground gears and shafts, also in the feed gear Iedpfxofbbx Rj Ahvshw Rapid traverse lengthwise and flat as standard to reduce non-productive times Large spindle bore (105 mm) for large diameter workpieces Soft start due to the mechanical multi-disc clutch Electromechanical foot brake to reduce non-productive time Best cutting performance even during face turning For stiffening the bed guide and for minimizing

Condition: new, Bernardo universal lathe Compact 400 V Technical specifications Top width 850 mm Tip height 200 mm Swing over bed 400 mm Swing over cross slide 245 mm Bed width 260 mm Spindle hole 52 mm Ijdpfxed Ertre Ahvshw Spindle mount DIN 55029, D1-5 Speed range, 2 levels 50-450 / 450-2500 RPM Range of longitudinal feeds (20) 0.025 - 2 mm / Rev Area plan feeds (20) 0.012 1 mm / Rev Metric threads (26) 0,2-14 mm Inch thread (42) 1-80 Gg/1 " Quill diameter 50 mm Tailstock runner way 120 mm Spindle mount MT 3 Power 5,5 kW (7,5 HP) Machine dimensions (W x D x H) 1900 x 1000 x 1610 mm Weight approx. 1185 kg Properties Standard with Delta frequency inverters for high torque in the lower revs and nearly constant speed under load Infinitely variable speed control, the set speed can be read off on a digital display To minimize vibration influences the massive Prism bed is equipped in addition with ribs Versatile applications in general engineering, production, item creation... Modern main spindle bearings with angular contact ball bearings in precision design The machine bed, cast in one piece, is extremely rigid and vibration, which satisfies an essential prerequisite for precise turning Space-saving installation possibility through to the front pull-out chip tray Standard with 52 mm spindle bore for manipulating large wave

Condition: reconditioned (used), Year of construction: 2002, CNC vertical machining center MIKRON VCP 800 W With path control Heidenhain iTNC 530 Year of construction: 2002 Travels: X 800 Y 650 Z 500 Speed range: 0 - 20,000 rpm infinitely variable With the following accessories: Rigid angular table 900 mm x 600 mm clamping surface Vertical tool changer with 30 magazine slots (HSK 63) Ihodpjviq U Eofx Ahvow Fully protected cabin with sliding doors and interior lighting Electronic handwheel Tool measurement in the work area ( BLUM laser ) 3 D measuring probe infrared Renishaw Chip conveyor Coolant device 4 pcs. Height-adjustable machine shoes Operating instructions

Condition: used, Guillotine shear, sheet metal guillotine DIGEP type OL 3 Workshop-refurbished guillotine shear Serial no.: 1312 Year of manufacture: 1977 Cutting length: 1250 mm (nominal cutting length) Max. cutting length: 1300 mm Cutting thickness at 450 N/mm²: 3 mm Simple backgauge: 500 mm Frame depth: 200 mm Cutting angle: 2° Strokes at full cutting length: max. 50 strokes/min Working height: 860 mm Motor power: 2.2 kW Ijdpfx Ajlpkcnjhvjhw Main connection: 380 Volt, 50 Hz - LED cutting area lighting - Simple backgauge with manual adjustment - Mechanical foot switch - Front angular stop left - 1 piece front sheet support 300 mm Dimensions (L x W x H): 1660 x 1350 x 1200 mm Weight: 1600 kg Good condition

Condition: used, CNC tool milling machine MAHO type MH 400 E Machine No. 43072 Year of construction 1989 travel X: 400 mm Y: 250 mm Z: 375 mm table size 700 x 270 mm distance spindle nose / table max. 410 mm tool holder ISO 40 with draw pin type B spindle speed 80 - 4000 rpm. 18 steps feed speed 1-1500 mm/min. infinitely variable Rapid traverse (X, Z and Y) 2,5 m/min. Pinol shift vertical 50 mm spindle drive 2,2 kW mains connection 400 Volt, 50 Hz, 19 kVA - swivelling control panel with CNC path control PHILIPS 432 - LCD monitor VISCOTECH - hydro-mechanical tool clamping - swiveling device for the vertical milling head - Splash guard cabin as table enclosure with 3 folding doors - Electrical control cabinet fixed to the machine - Interface V24 (RS 232) for data transmission - 52470 operating hours, main switch on - rigid angular table - coolant unit with coolant pump adjacent under the machine - central oil lubrication Vogel - operator's manual, electrical circuit diagram space requirement L x W x H 2250 x 1800 x 1850 mm weight approx. 1,5 ton. good condition Ijdpfoh Ic Ufox Ahvohw

Condition: excellent (used), Year of construction: 1995, x-travel 14000 mm y-travel 5000 mm z-travel 1500 mm w-axis 3000 mm column daylight 4000 mm column: max. dist. table - spindle nose 4500 mm workpiece weight 100 t table dimension - longitudinal 9000 mm table dimension - cross 3000 mm spindle taper ISO SK 50 spindle turning speed range 2-2500 U/min spindle motor 113 kW spindle diameter 200 mm max. torque on the spindle 9500 Nm feed in x - axis 1-10000 mm/min feed in y - axis 1-10000 mm/min feed range Z-direction 1-10000 mm/min rapid traverse 20000 mm/min height over floor 8600 mm control SIEMENS 840C weight of the machine ca. 360 t ATTACHMENTS angular milling head yes autom. tool clamping yes ball spindles yes guideway covers yes coolant unit yes high pressure cooling syst. (through spindle) yes closed cabin yes chip conveyor yes TECHNICAL DESCRIPTION 2 portal milling centres, each with 3 table pallets 9000 x 3000 mm: - Tool changer with 420 tools - Head pick-up system - Video monitoring via camera - High pressure lubrication unit for inner cooling 70bar AVAILABLE HEAD UNITS: - Fixed angle head HS800C600 105 Kw 600 long - Fixed angle head HSD350C850 50 Kw 850 long - Fixed angle head HSD 40C880 12 Kw 880 long - Fixed angle head HSD 190C1000 30 Kw 1000 long - Vertical spindle unit VS800C 105 Kw 900 long - Universal spindle unit USIO40C 20 Kw B-axis rotatable at 1° at a time - Angle spindle unit SO800C905 - 22,5° fix - Angle spindle unit HSE1200CS -25° fix - Universal spindle unit (fork milling) USP475C 75 Kw 1/2° Hirth --> 1.350 1/min , B-Achse 0,5 Grad Hirth One additional drilling extension SE 350C plus 1 SE500C. DESCRIPTION OF CONDITION In 2011/2012 these 2 identical machines were retrofitted The milling length was extended to 14meters and an automatic changing system for table pallets was installed. Both machines can be seen under power by prior appointment. Ihsdovwgm Hjpfx Ahvow

Condition: good (used), Year of construction: 1980, well-preserved slotting machine from the reputable manufacturer Okoma, with 40 mm spindle Isdpfx Ahexvllzovjhw

Condition: excellent (used), Year of construction: 1992, beautiful machine in good condition as it came from a small business with little use. with IV 68 tool Ihsdsu S Afcspfx Ahvew is still in operation ready for demonstration

Condition: new, Shaft diameter: 580working speed: 3-6motor power: 30length: 2760width: 2310heigth: 2680weight approx.: 14400 Technical specifications: Welded steel construction frame 3 rollers are driven Hardened and ground shafts made of high-strength special steel Rollers are hardened and ground Horizontal and vertical working position Hardened standard rollers Mobile control panel Angular side guide rollers Isdpoh Alh Hjfx Ahvshw Brake motor equipped for precision bending Digital displays (2 pieces) Options: Digital display STANDARD NC unit 10 screen EURO 11,500.00

Condition: used, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm # 2809 Weinig Unicontrol 6 ----- Technical Data Summary (Please inquire about any additional accessories included) Item 1: Cut-off saw ----- > Number of tools: 1 pc. > Spindle speed: 2,800 rpm > Spindle diameter: 40 mm > Maximum tool diameter: 400 mm > Motor power: 3.0 kW > Laser guide light for identifying the saw cut CNC-controlled length stop ----- > Length: 3,600 mm > Electronic length stop including positioned cut-off saw Item 2: Tenoning spindle ----- > Number of tools: 3 (stroke 2 x 100 mm) or 4 (Stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 3000 rpm > Maximum tool swing diameter: 320 mm > Spindle diameter: 50 mm > Maximum tool diameter: 360 mm > Motor power: 11 kW Item 3: 1. Profiling spindle (co-rotation and conventional) ----- > Position: vertical right > Number of tools: 1 pc. > Tool clamping length: 120 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 7.5 kW Item 4: 2. Profiling spindle ----- > Position: Vertical right > Number of tools: 3 (stroke 2 x 100 mm) or 4 (stroke 3 x 80 mm) > Tool clamping length: 320 mm > Pneumatic vertical spindle stroke: 240 mm for wood thicknesses 68 - 92 mm > Spindle speed: 6000 rpm > Spindle diameter: 50 mm > Maximum tool swing diameter: 232 mm > Motor power: 11 kW 2 axially indexed feed rollers opposite the profiling spindle, for the production of narrow, short parts (e.g., glass-dividing muntins) Munch guide consisting of: Munch support strip from above in the area of ??the vertical right-han d profile milling unit and profiling spindle. Item 5: Horizontal top profile milling unit ----- > Clamping length: 40 mm > Spindle diameter: 40 mm > Motor power: 3.0 kW > Spindle speed: 5,850 rpm > Maximum tool swing diameter: 130 mm > Axial travel: 52 mm, indexed in 2 positions > Radial travel: 125 mm, indexed in 2 positions Item 6: 3rd profiling spindle (fitting spindle) ----- > Position: Vertical right > Tool clamping length: 160 mm > Axial travel: 90 mm, indexed in 3 positions > Radial travel: 100 mm, indexed in 2 positions > Spindle speed: 5,850 rpm > Spindle diameter: 40 mm > Maximum tool swing diameter: 210 mm > Motor power: 3.0 kW Further features ----- > Electric feed height adjustment including mechanical digital display and manual feed bar clamping > Rebating device for tear-out-free rebating > Double part package > Return conveyor for 1-person operation: swivel conveyor > Screen control > Angled window device Isdpextvgksfx Ahvohw > Electronic angle display for angled windows > Industrial PC with Windows PC control/NEXUS Extraction nozzle diameter: ----- Crosscut saw 80 mm Tenoning spindle 140 mm Profile spindle 1 140 mm Profile spindle 2 140 mm Grooving device from above 80 mm Hardware spindle 120 mm ----- Price of The above-men...

Condition: ready for operation (used), Year of construction: 2004, operating hours: 42,832 h, functionality: fully functional, travel distance X-axis: 3,000 mm, travel distance Y-axis: 2,100 mm, travel distance Z-axis: 760 mm, controller model: FANUC SERIES 18i MB, clearance between the columns: 2,300 mm, TECHNICAL DETAILS Travel X-axis: 3,000 mm Travel Y-axis: 2,100 mm Travel Z-axis: 760 mm Distance between columns: 2,300 mm Table size: 3,020 mm × 2,010 mm Maximum table load: 10,000 kg Spindle taper: ISO-50 Standard spindle speed: 6,000 rpm Max. tool diameter / with empty magazine slot: 127 mm / 215 mm Max. tool length: 350 mm Max. tool weight: 20 kg Tool changer capacity: 32 tools Rapid traverse (X-axis): 20,000 mm/min Rapid traverse (Y-axis): 15,000 mm/min Rapid traverse (Z-axis): 15,000 mm/min Feed rate: approx. 1 – 10,000 mm/min MACHINE DETAILS CNC control: FANUC SERIES 18i MB Spindle motor power (continuous / 30 min): approx. 22 / 26 kW Ijdpfx Aoymxi Aohvjhw Operating hours, feed time: 42,832 h Operating hours, automatic mode: 53,246 h EQUIPMENT Automatic head changer (with angular milling head) RENISHAW probe

Condition: excellent (used), For sale: professional cutter and drill bit sharpener, model PP U3. Condition: very good, complete unit ready for operation. Included in the set: • Set of grinding wheels • Adjustable angular tool holder • Workshop lamp with flexible arm • Keys and clamping elements Specifications: Ihedpfxjxdh Hqe Ahvjw • For sharpening cylindrical and spiral end mills • For sharpening step and cylindrical drills • Wheel linear speed up to 35 meters per second • Maximum noise level: 66 dB • Machine weight: 41 kg Solid, stable construction—ideal for precise tool machining. A reliable solution for tool rooms, CNC workshops, and machine shops.

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 156560 € 2958.98 € 1200 mm 850 mm 1200 x 500 mm 1200 mm 1200 500 mm 5 - 30 m/min 0 - 5000 mm/min 0,001 mm 560 mm 0 - 2000 mm/min 0.001 mm Ihedpfx Ahowiryzovew 500 - 2200 1/min 11 kW 3.7 kW 3.1 kW 2.4 kW 4600 mm 2950 mm 2745 mm 4610 x 2290 x 2500 mm 6400 kg 900 mm 930 kg 1250 kg 405 x 50 x 127 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 6 angular contact ball bearings (P4, checkout 7) Air purge spindle Longitudinal guides with double V shape, with Turcite-B coating Transverse and vertical feed with precision ball screws (class C2) and servo motors Longitudinal feed hydraulically Linear scale on Y-axis 675mm Fully enclosed splash guard with lamp Electromagnetic chuck plate 1200 x 500 mm Coolant system with automatic paper filter and magnetic separator automatische Abziehvorrichtung am Tisch montiert, ohne Diamant, mit automatischer Kompensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Heat exchanger for electric cabinet Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH PRICE FOB TAIWAN * The exact configuration of the dresser must be clarified before ordering

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 21560 € 413.95 € 457 mm 460 x 146 mm 450 x 150 mm 482 mm 180 mm Ihodswirn Espfx Ahvow 1900 mm 1400 mm 2130 mm 680 kg 208 x 12,7 x 31,75 mm 1,5 kW 3 mm 0,01 mm man. vertical feed grinding wheel spindle on 4 high precision angular contact bearings electro-magnetic chuck150x450 mm coolant equiptment with filter manual dresser with diamond grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 48720 € 930.55 € 610 mm 600 mm 610 x 305 mm 300 x 600 mm 650 mm 700 mm 5 - 25 m/min 1.100 mm/min 1 - 12 mm 370 mm 1.5 kW 0.004 kW 0.19 kW 7,4 kW 2670 mm 1810 mm 2050 mm 2100 kg 355 x 50 x 127 mm 1.450 U/min 3,7 kW 4 mm 0,02 mm 0,2 mm 0,002 mm control panel on swiveling arm aut. vertical feed hardened slide ways in all 3 axes with needle rollers grinding wheel spindle on 4 high precision angular contact bearings electro-magnetic chuck coolant equiptment with aut. paper filter and magnetic separator manual extractor with diamond Ihjdpfewirh Sox Ahvjw grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH

Condition: new, Year of construction: 2025, neu 2025 050068 prompt, Zwischenverkauf v Taiwan 39860 € 761.33 € 1 457 mm 450 mm 457 x 203 mm 200 x 450 mm 500 mm 530 mm 5 - 25 m/min 960 mm/min 0,4 - 6 mm 230 mm 0,002 - 0,04 mm/min 2850 1/min 1,5 kW 0.75 kW 0.04 kW 0.19 kW 3,7 kW 2200 mm 1575 mm 1950 mm 1854 x 1549 x 2210 mm 1320 kg 215 kg 250 kg 203 x 12,7 x 31,75 mm control panel on swiveling arm aut. vertical feed grinding wheel spindle on 4 high precision angular contact bearings electro-magnetic chuck Ihodpfx Ahjwirh Eovow coolant equiptment 34 lt with magnetic separator and dust exhaust manual dresser with diamond grinding wheel grinding wheel flange grinding wheel balancing scale balance arbor LED machine lamp machine and equipment according to the CE-regulations user manual in GERMAN and ENGLISH

Condition: new, neu ca. 6 Monate ab Auftragse Taiwan 119350 € 2255.72 € 610 mm 600 mm 600 x 300 mm 600 x 300 mm 0 - 20 m/min 0 - 3000 mm/min 0,001 mm 350 mm 440 mm 0 - 3000 mm/min 0.001 mm 500 - 1800 1/min 11 kW 3160 mm 2450 mm 2080 mm 3400 x 2200 x 2530 mm 4000 kg 975 mm 195 kg 370 kg 355 x 50 x 127 mm 1,1 / 1,1 kW 3.9 kW 0,005 mm 0,003 mm Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel - RS232, USB I/O connection - SMART Grind Cam (dxf transfer in G code) -PC based control with graphical dialog programming or G-code programming Infinitely variable speed Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle Spindle with 4 angular contact ball bearings (P4, class 7) Longitudinal and cross guides with heavy duty needle roller bearing for low friction, better accuracy and lower maintenance costs All 3 axix with precision ball screws (class C2) and AC servo motors Fully enclosed splash guard with lamp Electromagnetic chuck plate Coolant system 120 lt with automatic paper filter and magnetic separator Automatic diamond roller dresser mounted on the table, with automatic compensation * Grinding wheel Grinding wheel flange Grinding wheel balancing scale Machine and equipment in accordance with CE regulations Operating manual in GERMAN or ENGLISH Accuracy standard ISO 1986-1 Ihedpfx Aswirb Sjhvjw * The exact configuration of the dresser must be clarified before ordering
