HARTFORD PRO-800A

HARTFORD PRO-800A

Condition: excellent (used), Year of construction: 2008, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 406 mm, travel distance Z-axis: 508 mm, controller manufacturer: FANUC, controller model: Doosan-FANUC 21i-MB, table width: 430 mm, table length: 920 mm, spindle speed (max.): 20,000 rpm, spindle motor power: 15,000 W, number of spindles: 2, number of slots in tool magazine: 30, tool diameter: 40 mm, number of axes: 4, Equipment: documentation/manual, Tool Standard is CAT-40, 30 pieces of Tool-holders are attached to this machine 4th axis: rotary table included; Renishaw probe ready. through spindle coolant; spindle chiller; rigid tapping; rapid traverse 36,000 mm/min; manual pulse generator; Guodpfx Aox Ncpgengoh air blast; coolant tank & pump; chip tray;

Condition: used, Year of construction: 2012, travel -x axis 1.630 mm travel -y axis 762 mm travel -z axis 650 mm control FANUC - 0I-MD Spindle speed 12.000 min -1 weight of the machine ca. 13 t Milling machining centers - vertical | DOOSAN - DNM 750 equipped with 30-way tool changer, ITC (20 bar) and chip conveyor. The machine only has 13.686 spindle hours. The machine video from the production plant will be shared on request. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Gsdpozw N E Iefx Angeuh #Tags: DNM750 | DNM-750

Condition: new, Year of construction: 2023, Various driven holders BMT 45 and 55, radial and axial, Preziflex mounts, suitable for Doosan CNC lathes. All items available multiple times in stock. Gjdpfjwyp A Ijx Angeuh

Condition: good (used), Year of construction: 2008, Parts shown by hand not come. 12.000 rpm, SK 40 Guedpfxezkkcze Angoh 30 places in tool changer. 4.axis on table will come.

Condition: excellent (used), Year of construction: 2011, XYZ Proturn SLX 1630 ProtoTRAK CNC Gap Bed Centre Lathe Ex Research machine – Superb Condition ProtoTRAK SLX Control (2011) Max’ Distance Between Centres 760mm Max’ Swing over Cross-slide 218mm Max Swing over Bed 400mm Spindle Bore 52mm Spindle Speeds 150 – 2500 rev/min Gedpfx Ajzav D Djngouh Spindle Motor 5.75Kw Spindle Camlock D1-6 Quick Change Tool Post Tailstock MT4 Tailstock Dia’ 60mm Tailstock Travel 127mm Manufactured | 2011 Weight 1560Kgs Supplied with: Two-axis CNC, Two-axis DRO. TRAKing, Constant surface speed. Electronic hand-wheels for X & Z Axes. Joystick for feed & rapids. Interlocked chuck guard and main guard. Quick change toolpost with holders. 3 Jaw chuck 5C Collet Chuck Coolant For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #78211 Machine Serial Number: 16P99080-063 Cost: £17,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 2005, Main Drive Number of axis 3 Movement X-Axis Movement 760 mm X-Axis Rapid Traverse 50 m/min Y-Axis Movement 455 mm Y-Axis Rapid Traverse 50 m/min Z-Axis Movement 460 mm Z-Axis Rapid Traverse 36 m/min Table Table load 200 kg This 3-axis Kitamura 3XiF was manufactured in 2005. It features a robust FANUC 16i-MB control system, a spindle speed of 10,000 rpm, and a BT-40 taper. The machine includes a chip conveyor with an extended neck and a 30-tool changer. Table size is 900 x 410 mm, supporting up to 200 kg. Ideal for precision machining with internal spindle cooling available. Contact us for more information about this machine. Guodpfx Aex D Rc Iongsh Application Types Milling

Condition: good (used), Year of construction: 1998, Used Kitamura machining centers Type: Mycenter 2X Yasnac CNC control Max. spindle speed: 10,000 rpm Excl. clamping on the table Tool holder: SK 40 X: 610 mm Y: 510 mm Gujdoy U I H Ijpfx Angoh Z: 510 mm Tool changer

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 1020 x 510 x 510mm, Table 1200 x 450mm, Spindle speed 8,000rpm, Guedpfx Anjy Tka Usgjh Spindle taper BT40, Spindle Motor 11kW, Fanuc Oi-MC Control, 24 Station ATC, Coolant, Low Volt light, swarf conveyor

Condition: good (used), Year of construction: 2011, functionality: fully functional, DOOSAN DNM 400A – CNC vertical machining center, FANUC, year 2011 We offer for sale a DOOSAN DNM 400A CNC vertical machining center, equipped with a reliable DOOSAN-FANUC i Series control system. The machine is currently in operation and can be demonstrated and tested upon prior arrangement. Technical specifications: Manufacturer: Doosan Infracore Model: DNM 400A Year of manufacture: 05/2011 Guodpfx Anoz Dq Iuegeh CNC control: DOOSAN-FANUC i Series X-axis travel: approx. 762 mm Y-axis travel: approx. 435 mm Z-axis travel: approx. 510 mm Work table dimensions: approx. 920 × 435 mm Max. table load: approx. 600 kg Spindle taper: BT40 / ISO 40 Max. spindle speed: approx. 8,000 rpm Automatic tool changer Coolant system Power supply: 380 V Rated power: approx. 27.4 kVA Machine weight: 4,500 kg A universal CNC vertical machining center suitable for both single-piece and series production. The combination of a robust DOOSAN design and a FANUC control system ensures easy operation and good service availability. The machine is powered on and can be demonstrated in operation.

Condition: ready for operation (used), Year of construction: 2004, travel distance X-axis: 860 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 630 mm, controller manufacturer: FANUC, table load: 500 kg, overall weight: 6,600 kg, spindle speed (max.): 10,000 rpm, spindle motor power: 11,000 W, number of slots in tool magazine: 24, number of axes: 4, This 4-axis HARTFORD MVP-8A was manufactured in 2004. It features impressive travels of 860 mm in the X-axis, 530 mm in the Y-axis, and 630 mm in the Z-axis. The machine includes a robust table size of 1000 x 560 mm with a load capacity of 500 kg, and a maximum spindle speed of 10,000 rpm. If you are looking to get high-quality machining capabilities, consider the HARTFORD MVP-8A vertical machining centre we have for sale. Contact us for further details. • Distance table–spindle face: max. 705 mm • Table dimensions: 1000 × 560 mm • Rapid traverse (X/Y/Z): 24 / 24 / 24 m/min (linear guides) • Automatic tool changer (ATC): 24 positions, arm-type • Control system: Fanuc 21i (black and white display) + Hartrol AI100 Additional equipment Godpjzvbynsfx Angouh • 4th axis rotary table Technical Specification Taper Size SK 40
