Tool and Cutter Grinder

Haller UFS 155 *Generalüberholt*

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, MAZAK QUICK TURN NEXUS 100-II MSY Max. machining diameter: 280 mm Max. machining length: 400 mm Max. milling speed: 4,500 rpm Max. spindle speed: 6,000 rpm Max. bar diameter: 42 mm Machine is equipped with: - CNC control: Mazatrol Matrix - KITAGAWA 3-jaw chuck B-206 for main spindle - KITAGAWA 3-jaw chuck B-205 for 2nd spindle - Tool Eye - C-axis - Y-axis - Interface for bar loader magazine Dedpfxey S A Ris Ac Hjck - Automatic parts catcher - Reinforced coolant pump - 8 units of fixed tool holders - 2 units of powered tool holders

Condition: used, Year of construction: 1980, grinding length 500 mm Dcjdpfx Acjwb Hygo Hek grinding width 200 mm workpiece height 290 mm Machine from the German Federal Institute of Physics and Metrology - geometrically revised - electrics tested, fully functional, relevant parts replaced - all wear parts replaced - colour light grey, colour condition good Equipment: - electro magnet 500x200mm - grinding spindle overhauled 2-axis display for Y and Z axes Automatic delivery for Y and Z axes Y-axis with zero shutdown Manual hand dresser Stepless speed for grinding wheel V-constant via disc wear Paper band filter system, used Max. height with 250 disc diameter 290mm max. grinding area 600x250mm max. load incl. magnet 100kg Warranty: 1 year on geometry and electronics, Germany-wide Delivery: ex works Shipping time: immediately Payment: before pickup Acceptance at our premises Shipping according to your specifications

Condition: used, Year of construction: 2000, grinding diameter 360 mm grinding length 1600 mm centre height 180 mm internal diameter 0 mm grinding depth 0 mm swing diameter 0 mm total power requirement 40 kW weight of the machine ca. 10000 kg dimensions of the machine ca. m K A R S T E N S (Germany) Universal “CNC” - Cylindrical Internal and Face Grinding Machine also for grinding excentric and cam profiles and polygons and even suitable for Threadgrinding Model K 51 – 1500 Year 2000 Serial No. 99 093 Height of centres 180 mm Distance between centres / grinding length 1,700/1.600 mm Dsdpjt Hw Rdefx Ac Heck Cylindrical Grinding: Grinding Ø, approx. 5 - 360 mm Grinding wheel: Ø x width x bore 500 x 100 x 127 mm Grinding spindle speeds (35 m/s / 50 m/s) 1.900 / 2.200 rpm Drives of cyl./int/face spindle units 7.5/4,0/7,5 kW Grinding Wheelhead: 3 Positions = B-Axis Head swivels in 3 positions = 240 ° / 17,5 degree X-axis adjustment in total 360 mm Increments for infeed 0,001 – 125 mm Workpiece wheelhead = C-Axis Spindle speeds steplessly adjustable 10 – 1.000 rpm Spindle taper / Spindle bore MK 4 / 24 mm Table speeds 0,01 – 10.000 mm/min Total electrical load 40 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: * Very versatile CNC Grinding Machine for almost all grinding purposes like External/Internal and Face grinding as well as for Excentric- / Cam- / Polygone Grinding and even for Thread Grinding * Free programmable CNC System make BWO Model 900 C with many grinding cycles and for easy input of the work-parameters. Graphic support, any many more features. * 3 position wheelhead with 3 Grinding spindles as B-Axis, one with measuring feeler (Z - Position) * MOVOMATIC Measuring Device Model ES 400 for diameter control, Probe head CR 60, to be mounted on table. * MPM Automatic Grinding wheel balancing Device, Dressing devices with diamantflees mounted on table surface and also motorized Diamantroll Profile dresser on table (for thread profiles, etc.) * Workhead and tailstock can be easily moved on table by air cushion. Hydraulic quill on tailstock. * No Coolant Device available ! Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock as inspected. Payment : Net, after conclusion of contract.

Condition: used, Year of construction: 1992, grinding length 0800 mm grinding width 500 mm workpiece height 400 mm table-size 800 x 400 mm table speeds 1 - 25 m/min cross feed autom. 0 - 60 mm/Hub grinding wheel size 400 x 100 x 127 mm grinding spindle speed 1400/2800 U/min total power requirement 10 kW voltage 380 V weight of the machine ca. 6 t Machine has cooling arrangement, auto. vert. feed, dressing arrangement and wheel flanges. Control doesn't work continuesly !! Dodpfxowgnz As Ac Hock

Condition: good (used), Year of construction: 2009, Machine will come with robot . 42.000 rpm Dodpfx Ajxfu S Njc Hock

Condition: used, Year of construction: 2007, Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as Saws, milling cutters etc. using the wire-electro-erosion method. Accessories: Total enclosure, Cooling unit for dielectric, automatic fire extinguishing system, Mist extractor N181 Probe, Machine lamp, Djdpewtmg Dofx Ac Hock automatic central lubrication, Workpiece carrier ISO50, Measuring mandrel, Cutter outside diameter: Max. 250 mm Cutting length: max. 260 mm Shank tool diameter: 10 - 250 mm Outside diameter disc-shaped tools: Max. 250 mm Tool weight max.: 20 kg X axis travel: 275 mm Y-axis travel: 300 mm W-axis travel: 200 mm A-axis mounting cone: ISWO 50 E-axis swivel range: 180 ° Required space for the machine: 2535 x 2200 x 2220 mm Weight approx.: 4500 kg Connected load: 4.5 kW (400 V / 50 Hz) colour: gray RAL 7045/7047

Condition: good (used), Year of construction: 2007, travel distance X-axis: 750 mm, travel distance Y-axis: 750 mm, travel distance Z-axis: 725 mm, CNC control Sinumerik 840D NC-rotary table B-axis automatic tool changer for 320 tools pallet changing device, 2 pallets 500 mm x 500mm coolant through spindle device IKZ (80 bar) chip conveyor coolant device Technische Daten / technical details: X-Weg längs / X-travel longitudinal 750 mm Y-Weg senkrecht / Y-travel vertical 750 mm Z-Weg quer / Z-travel cross 725 mm B-Achse / B-axis 360 ° Spindelaufnahme / spindle taper HSK 63A Drehzahlbereich Spindel / spindle speed 50-10000 Upm /rpm Werkzeugplätze / tool places in changer 320 Vorschub / infeed 60000 mm/min Eilgang / rapid feed 60 m/min Antriebsleistung Spindel 40/100% ED / drive capacity spindle 40/100%ED 37/24 kW Gewicht der Maschine ca. / weight ca. 15000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Dcedpfoq Ui Hqex Ac Hjk Technical data, accessories and description of the machine are not binding.

Condition: new, Bernardo DG 32 Pro Drill Grinding Machine Specifications Drill diameter: 2 – 32 mm Point angle: 90° - 135° Speed: 4800 rpm Motor power: 0.25 kW Voltage: 230 V Length: 350 mm Width: 210 mm Height: 305 mm Weight approx.: 32 kg Scope of delivery • SBC diamond grinding wheel • ER 20 collets, 3 – 12 mm, 10 pcs. (3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 11 / 12 mm) • ER 40 collets, 13 – 32 mm, 20 pcs. (13 / 14 / 15 / 16 / 17 / 18 / 19 / 20 / 21 / 22 / 23 / 24 / 25 / 26 / 27 / 28 / 29 / 30 / 31 / 32 mm) Dodpfx Ajgd H U Uec Hock • ER 20 or ER 40 collet chuck Features • Includes a setup for point grinding, i.e., improved centering of the drill tip on the workpiece and reduction of the required feed force • 30 ER collets included in the scope of delivery, which are also suitable for clamping intermediate sizes • Additional station for back-grinding the drill cutting edges (relief angle) • Universally adjustable point angle from 90° - 135° • Rotor with precision ball bearings ensures smooth running • Fast and precise working results due to simple operation • Vibration-free operation due to high inherent weight and rubber feet

Condition: like new (used), Manual profile grinder UTMA model P20 Dedpfx Acoff H E Rj Hsck
