VERTICAL MACHINING CENTER

FPT Industrie RAID

Condition: used, Year of construction: 2005, Travel: X-1500 mm, Y-1300 mm, Z-600 mm Control: iTNC530 Spindle mount: HSK-63A Spindle speed: 15.000 U/min table size: 1500 x 1000 mm max. table load: 2.500 kg Distance between table and spindle: 200-800 mm tool magazine: 30 fold Tool measurement: BLUM Laser chip conveyor: IKZ machine weight: approx. 14,000 kg Cgsdozfwzyspfx Ailew Dimensions: L: 5000 x B: 2400 x H: 2999 mm

Condition: good (used), Year of construction: 2014, DMG MORI DMU 50 Technical Features of this 5-axis machining center Manufacturer: DMG Model: DMU-50 Year: 2014 3D CNC Control: HEIDENHAIN ITNC530 SMART NC Screen Type: DMG ERGOLINE® CONTROL 19” NC Swivel Rotary Table Simultaneous: INCLUDED Table Surface: 630×500 mm Max Weight Allowed on Table: 250 kg / pallet Turning Table (C Axis): 0.001º (±360º) Axis: Longitudinal Traverse (X Axis): 500 mm Cross Traverse (Y Axis): 450 mm Vertical Traverse (Z Axis): 400 mm Rapid Feed (X/Y/Z Axis): 42,000 mm/min Working Feed (X/Y/Z Axis): 10,000 mm/min Tilting Range (B Axis): -5º/+110º Spindle: Spindle Speed: 10,000 r.p.m. Taper: SK40-DIN 69871 Main Motor Power: 25 kW Automatic Tool Changer (ATC): ATC Positions: 60 Max Tool Length: 300 mm Equipment: Chip Conveyor: INCLUDED Active Control Cabinet Cooling: INCLUDED Tool Touch Probe: INCLUDED Direct Measuring System: INCLUDED Cjdsy Smynspfx Ailegw Flushing Gun: INCLUDED Portable Handwheel: INCLUDED Suction System: INCLUDED Internal Coolant: INCLUDED Coolant Deposit with Paper Filter: INCLUDED Others: Machine Dimensions (L x W x H): 5,100 × 3,200 × 2,750 mm Total Power: 27 kVA Machine Weight: 4,500 kg Price on request

Condition: used, Year of construction: 1987, x-travel 500 mm y-travel 380 mm z-travel 300 mm Control FANUC total power requirement 12 kW Cedpfx Aiot Hw H Eolsgw weight of the machine ca. 2300 kg dimensions of the machine ca. m

Condition: excellent (used), Year of construction: 2008, travel distance X-axis: 3,000 mm, travel distance Y-axis: 825 mm, travel distance Z-axis: 1,100 mm, rapid traverse X-axis: 48,000 m/min, rapid traverse Y-axis: 80,000 m/min, rapid traverse Z-axis: 48,000 m/min, table width: 835 mm, table length: 3,500 mm, table load: 3,500 kg, 1 Axis CNC Swivel head, infinitely variable Axis drive with ball screw drive Roller linear guides in all axes Direct path measuring systems Full work area encosure with roof Chip conveyor Coolant unit X - Travel: 3000mm Y - Travel: 825mm Z - Travel: 1100mm B - Axis: - 3 to + 105° Table Length: 3500mm Table Width: 835mm Table load: 3500 Feed rate X-Axis: 48000mm/min. Feed rate Y-Axis: 80000mm/min. Feed rate Z-Axis: 48000mm/min. Spindle Taper: HSK 100ISO/Bt/Mk Power on spindle: 37kW Speeds / ranges: 8000Rpm ATC / revolver: 40 Coolant through spindle / Bar:25 Codpfx Aowyv Nzoilegw Number of controlled axis: 4 Chip conveyor: Yes Coolantsystem: Yes Length: 8000mm Width: 3800mm Height: 3800mm

Condition: ready for operation (used), Year of construction: 2011, 5-AXIS Machining Center Brand: DMG MORI Type: DMU 50 Year: 2011 CNC: Heidenhain iTNC530 Equipped with: Integrated rotary table, dia. 630 x 500 mm / 300 kg 13 kW spindle – 10,000 rpm 16-position tool changer 3D probe Csdszgca Dspfx Ailsgw 3D quickset Tool probe Coolant gun Electronic handwheel Chip conveyor Specifications: Table surface 630 x 500 mm X-axis travel 500 mm Y-axis travel 420 mm Z-axis travel 400 mm B-axis -5/+110° C-axis 360,000° Spindle speed 20 - 10,000 rpm Spindle power 13 KW Spindle taper SK 40 Rapid traverse XYZ 24 m/min Machine dimensions with chip conveyor 4670 x 2350 x H 2750 mm Approximate weight 4,680 kg

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,200 mm, travel distance Z-axis: 1,100 mm, table length: 4,500 mm, table width: 2,500 mm, spindle speed (max.): 22,000 rpm, CNC Heidenhain iTNC 640 WORKING AREA: Longitudinal X-axis travel: mm 4.000 Transversal Y-axis travel: mm 2.200 Vertical Z-axis travel: mm 1.100 Maximum speed with interpolating axes: m/min 50 WORKTABLE: Dimensions: mm 4.500 x 2.500 Height: mm 300 Load capacity: T/m² 15 T-slots for workpiece clamping mm 28 DIN 650 (H12), complete with leveling elements. T-slot direction parallel to Y-axis movement. CONTINUOUS POSITIONING UNIVERSAL HEAD WITH ELECTROSPINDLE: Automatic universal head indexed to 360,000 positions (every 0.001°). Rotation is driven by direct drive motors and controlled by the CNC as a positioning axis. Automatic tool clamping. Allows 10° undercut machining. Internal cooling system for bearings and axis motors. Cgedpfx Asyv In Isilsw C-axis rotation range: ± 270° A-axis rotation range: ± 185° Maximum axis rotation speed: rpm 30 Maximum torque available on A/C axes: Nm 450 Axis clamping torque: Nm 1.400 Spindle power (S1/S6): kW 22/33 Spindle torque (S1/S6): Nm 84/128 Maximum spindle speed: rpm 22.000 Constant power range: rpm 3.000 to 18.000 Constant torque range: rpm 10 to 3.000 Tool interface: HSK-A63 DIN 69893 ELECTROSPINDLE HSK-A100 WITH SEMI-AUTOMATIC CHANGE SYSTEM Spindle power (S1/S6): kW 37/43 Spindle torque (S1/S6): Nm 140/165 Maximum spindle speed: rpm 15.000 Constant power range: rpm 2.500 to 12.000 Constant torque range: rpm 10 to 2.500 Tool interface: HSK-A100 DIN 69893 CHAIN TOOL MAGAZINE – 55 POSITIONS, HSK-A100 / HSK-A63 Floor-mounted fixed chain magazine located at the rear of the machine, fully enclosed for operator protection, equipped with a vertical tool change arm and automatic tool pre-selection. Fixed-pocket management system. Hydraulic axis locking Total tools: No. 55 HSK-A63 tools (DIN 69893): Number of tools: No. 30 Max tool diameter: mm 90 Max tool diameter (with adjacent pockets free): mm 160 Max tool length: mm 300 Max tool weight: kg 10 HSK-A100 tools (DIN 69893): Number of tools: No. 25 Max tool diameter: mm 100 Max tool diameter (with adjacent pockets free): mm 160 Max tool length: mm 450 Max tool weight: kg 20 REQUIRED CONNECTIONS Maximum installed power: kVA 177 Maximum current required: A 235 MACHINE EQUIPPED WITH: • Heidenhain HR550 remote electronic handwheel • High-pressure water and air through the spindle • Semi-automatic electrospindle change system with HSK-A63 and HSK-A100 interfaces • Various tooling included with the machine • Renishaw probe • BLUM laser presetting system • AUTOCAL automatic head calibration system • Visormax subscription for remote monitoring • Electrical cabinet air conditioning unit • Cooling system for all axes and the electrospindle • User and maintenance manual and CE declaration of conformity

Condition: ready for operation (used), Year of construction: 2015, A CNC vertical long-bed machining center Mazak is available. Travel X/Y/Z: 3000mm/800mm/720mm, B-axis: 110°, C-axis: 360°, table diameter: 600mm, long-bed table dimensions X/Y: 3500mm/820mm, max. table load: 2500kg, spindle interface: BT40, speed: 18000rpm, rapid traverse: 50m/min, tool stations: 48, coolant pressure: 70bar. Machine dimensions X/Y/Z: approx. 5250mm/3650mm/3200mm, weight: approx. 16100kg, control: Mazatrol Matrix 2, spindle hours: 18502h. Including rotary table Nikken CNC 601MA, high-pressure coolant, center partition wall, Renishaw probe, touch probe RMP 60Q, CAD/CAM software Topsolid 7.18 and postprocessor. Documentation available. An on-site inspection is possible. Cedox Ih Dmopfx Ailjgw

Condition: ready for operation (used), Year of construction: 2015, operating hours: 12,244 h, spindle speed (max.): 4,500 rpm, travel distance X-axis: 275 mm, travel distance Z-axis: 700 mm, spindle motor power: 11,000 W, total height: 1,620 mm, overall weight: 4,200 kg, controller manufacturer: SIEMENS, controller model: 840D-SolutionLine, number of slots in tool magazine: 16, number of axes: 2, This 2-axis SPINNER TC 600-65MC horizontal turning machine was manufactured in 2017, featuring a Siemens 840D control system and a 16-position indexing turret. It includes a main spindle with a speed of up to 4,000 rpm and a power of 24 kW. The machine offers a swing diameter over bed of 425 mm and a maximum turning diameter of 310 mm. Consider the opportunity to buy this SPINNER TC 600-65MC horizontal turning machine. Contact us for more information about this machine. Additional equipment • Full splash guard cladding + coolant unit • Work area light + pneumatic equipment • Panoramic window for optimum visibility into the work area Machine Benefits Technical Machine Benefits • Center distance: approx. 600 mm • Max turning diameter: 310 mm • Torque: main spindle (fanuc, s6 40%) 178 nm, main spindle (siemens, s6 40%) 301 nm • Quill stroke: 120 mm • Adjustment travel: 475 mm Csdpfxex D E Hno Ailsgw • Speed of rotating tools: 6000 1/min • Driven tool power: (fanuc, 30 min) 3. 7 kw, (siemens, 40%) 6. 0 kw Extra Information Media Pneumatics max. operating pressure: 10 bar Normal pressure: 6 bar Hydraulics max. operating pressure: 30 bar Control Unit Control system: Standard Siemens 840D, Option Fanuc 21i Operating voltage: 400 V Mains frequency: 50/60 Hz Control voltage: 24 V DC Interfaces: USB, Ethernet, SPINNER-UNIMAG bar feed (electric) Technical Specification Through-spindle Coolant No Counter Spindle No Driven Tools Yes Taper Size VDI 30

Condition: new, Year of construction: 2025, operating hours: 1 h, functionality: fully functional, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,000 mm, controller manufacturer: STYLE CNC Machines, number of slots in tool magazine: 24, motor manufacturer: FANUC, Delivery after consultation Cedpew Ty S Ssfx Ailjgw Ref: 24F048 Year of construction: 2025 Condition: Showroom Specifications: - X-axis: 4000 mm - Y-axis: 1000 mm - Z-axis: 1000 mm - 26 kW (S6) main motor - 8000 rpm - BT-40 - Automatic tool changer (24 positions) - Remote service (IXON) + network connection - Stronger coolant pump incl. spray gun - Upgraded to the latest STYLE software available

Condition: ready for operation (used), Year of construction: 2006, CNC machining center DMC 635V Year of manufacture 2006 Heidenhain TNC 530i control Control approx. 58,400 hours Program run approx. 19,980 hours According to the sticker in the control cabinet, the spindle and motor were replaced in January 2019 at 10,660 hours. No documentation available. Machine runs smoothly Travel distances X 635 Y 510 Z 460 Codpfjw Tir Uex Ailjgw Tool holder SK 40 20-position tool changer Table 790×560 with chip conveyor Weight approx. 3700 kg This offer is directed exclusively at commercial enterprises within the meaning of §14 BGB (German Civil Code). No sale to private individuals.
