CNC machining center COMEC COMEC MD TOP XL

COMEC MD TOP XL

CNC Machining Center
Manufacturer: COMEC
Type: MD TOP XL
The ideal solution for CNC machining of narrow, complex workpieces.
COMEC makes it easy for you.
Head configurations can be individually configured for:
- Sawing with a 360-degree axis
- Milling heads for horizontal and vertical machining
- Drilling heads with individually selectable spindles, vertical and horizontal
- Multi-spindle row drilling heads, individually selectable, also horizontally
- Horizontal milling head with a 360-degree C-axis

Specially designed clamping table, travels in the X direction automatically and is program-controlled.
Individual equipment options are available, for example:
Base frame
Heavy-duty base machine stand, electrically welded.
Maximum workpiece sizes:
X-axis 3350 mm
(or 1500 + 1500 mm in two working areas)
Y-axis 200 mm
Z-axis 180 mm
Traversing tool carrier
3 axes CNC controlled.
Linear and interpolating.
Positioning speed of the tool carrier max. 70 m/min.
Vertical drive spindles
1 drive spindle for 1 drilling head with individually selectable drilling spindles
5 vertical drilling spindles, spacing 32 mm
3 horizontal double-output spindles on the Y-axis, spacing 32 mm
3 horizontal double-output spindles on the X-axis, spacing 32 mm
1 Vertical milling electro-spindle
8.0 KW, 12,000/18,000 RPM. Tool holder ISO 30 taper + ER 32 collet for manual tool change with quick release.
1 Milling / Sawing / Drilling spindle
With motor 7.0 KW, 8,000 - 12,000 RPM.
360 C-axis, interpolating
With attachment with 180 double output for saw blade and drilling/milling tool
Iiodpozvgl Nsfx Abnef
Horizontal electro-spindle
1 Milling spindle
With motor 5.6 KW / 12,000 - 18,000 RPM
With ER 32 collet
4 + 4 workpiece supports
Adjustable on guides with 4+4 pneumatic clamping cylinders, with 2+2 horizontal clamping cylinders and front and side stops.
Automatic magazine CA 2
Adjustable on linear guides, fixed on the left (zero)
With easy access for the operator and a high degree of autonomous operation.
With coated discharge chute for the machined workpieces.
CONTROL UNIT - CAD CAM
Free-standing control cabinet next to the machine
Industrial PC with operator interface with 17" color touchscreen.
SSD 120 GB, interface: Ethernet USB / RS 232
Programming with 3-D supported display
Option for network connection for programming and remote support.
Remote control console for controlling the machine by the operator during tests and setup.
PROTECTIVE CABIN
Surrounded with solid sheet metal panels
With front protective screens, controlled by the work cycle
Chip conveyor
With outlet to the right side, with motor 0.37 KW
Connection 400 V / 50 Hz
