Injection molding machine

Arburg 420 C 1000- 150/60

Condition: excellent (used), Year of construction: 2003, operating hours: 21,200 h, functionality: fully functional, machine/vehicle number: 190332, Equipment: documentation/manual, Injection molding machine 3 colors (horizontal /vertical/ and 3. in L-position with protective housing) The machine can be used as a 2 colour/2K machine and the 3rd can be deactivate immediately available from our warehouse in Hannover Make: Arburg Type: 420C 1000-150/150/60 year of construction 2003 Control: Selogica Hours: 21200 h without turntable +++++clamping unit +++++ Clamping force: 1000 kN / 1000 to. tie bar distance: 420 x 420 mm platen size: 795 x795 mm tool height 300 mm distance platens max. 950 mm ejector 225 mm /66 kN ++++Injection unit 1 (150 unit) ++++ Screw size: 15 mm (high shut-off fixed) Injection volume: 17 ccm Injection weight: 15 gr. Injection pressure: 2750 bar ++++Injection unit 2 (150cc unit) ++++ Screw size: 15 mm (highly screwed fixed) Injection volume: 17 ccm Injection weight: 15 gr. Injection pressure: 2750 bar Pedpfx Aogrzh Esngsgu ++++Injection unit 3 (60cc unit) ++++ Screw size: 15 mm (highly screwed fixed) Injection volume: 17 ccm Injection weight: 15 gr. Injection pressure: 2080 bar Extras 2x core pull 1 ALLROUNDER 420 C 1000 - 150 / 150 / 60 fully hydraulic screw injection molding machine mold clamping force 1000 kN voltage 400 V / 50 Hz 1 Vertical injection unit instead of clamping tie bars mounted on carriers for 2nd injection unit, manually operated, working position adjustable between 70 and 250 mm VE-404/02 1 Open nozzle 15 mm low-wear, without heating tape (1.SPE 150) VE-902/00 1 Technology level 2 - servo-controlled Hydraulic system -two control pumps for controlled machine movements, path-dependent, controlled target ramps. The build-up of the tool clamping force programmable + controlled. Clamping force is servo-controlled via second pump. The nozzle contact force programmable. The contact force can be set manually, the value is maintained in a controlled manner. This technology level is a prerequisite for simultaneous movements of the nozzle, ejector and optional core pullers. Including equipment package for "extended travel movements". VE-132/03 1 Technology level 3 Hydraulic system with 3 control pumps for simultaneous movements of the main axes and for faster movements of the secondary axes. For the 2-K machines as hydraulic system for the 2nd injection unit (prerequisite is technology level 2, VE 132/03) VE-130/40 1 heating tape for open nozzle VE-320/00 1 Injection unit 150 for vertical injection into mold partition for 2-component processing VE-136/02 1 position controlled screw with control valve at the injection unit, incl. controlled back pressure, nozzle contact force manually adjustable VE-561/20 1 position-controlled screw with control valve for multi-component machines, incl. controlled back pressure, nozzle contact force manually adjustable - for injection unit 2 VE-561/30 1 injection unit 60 for horizontal injection into mold partition as 3rd injection unit for multi-component processing (L-position) VE-906/00 1 for VE 906/00 injection unit 60 in L-position: unit lowered by 70 mm, incl. special parting line full protection VE-907/00 1 Plasticizing barrel set 15 mm (without nozzle), with advanced feed and pressure reducing valve, in highly wear resistant design 1 Open nozzle 15 mm wear-resistant, without heating band (L-position) VE-909/00 1 Nozzle tip with radius 15 (L-position) VE-910/00 1 Heating tape for open nozzle (L-position) VE-911/00 1 Position-controlled screw for the third injection

Condition: good (used), Year of construction: 1995, Description Control Sinumerik 810M Spindle speed 5000 rpm Turret head 12 - position Table clamping surface length 850 mm, width 325 mm Very good condition, regularly serviced. Operating instructions German Number of axes 3 (X, Y, Z) Travel path X 420mm, Y 330mm, Z 240mm Control: Sinumerik 810 M Psdpsvt Amujfx Angegu Max. spindle speed 5000 rpm Automatic tool changer for 12 tools SK40 holder Coolant system

Condition: ready for operation (used), Year of construction: 2002, clamping force: 1,000 kN, screw diameter: 25 mm, Hydraulic injection moulding machine manufactured in 2002. This Arburg 420 C 1000-150/60 features a clamping force of 1,000 kN and a maximum mold height of 750 mm. It includes a screw diameter of 25/22 mm and a maximum injection volume of 54/30 cm³. If you are looking to get high-quality injection moulding capabilities, consider the Arburg 420 C 1000-150/60 machine we have for sale. Contact us for further details. Pgjdoz Dk Sgjpfx Angsu • Space between columns: 420 x 420 mm • Maximum mold height: 750 mm • Minimum mold height: 350 mm • Screw diameter: 25/22 mm • Maximum injection volume: 54/30 cm3 • Maximum injection pressure: 2500/2340 Bar • Centering ring: 125 mm • Hot runners in the machine: 2 • Core puller: 1

Condition: excellent (used), Year of construction: 2004, clamping force: 1,000 kN, Arburg 420C-1000-60-150 ( 123) 2-component with robot and cage Year of production: 2004 TECHNICAL DATA Screw Dia [mm]: 18/30 Shot Weight [g]: 17/65 Injection Pressure [bar]: 2500/2210 Clamping Force [kN]: 1000 Tie Bar Distance [mm]: 420x420 Platen Size [mm]: 570x570 Mould Height min. [mm]: 250 CONTROL Type of Controls: Selogica Monitor: Yes Control Cabinet: Yes Language: German OTHER Pgjdsvt Rwuepfx Angsu Power [kW]: 34,5 Workinghours [h]: 61792 Dimensions [m]: 4,6x1,8 Weight [kg]: 4000 CR - CORE PULL R - ROBOT ZP - AIR VALVE without hopper

Condition: used, Year of construction: 1982, Center height: 220 mm Center width: 1250/1300 mm Swing diameter: over bed 440 mm Spindle bore: Spindle mount: Tailstock taper: 5 MK Pjdpfx Aovzn Itsngegu Spindle speeds: 11.2 - 2240 rpm Feeds: longitudinal/transverse 0.1-2.8/0.05-1.4 mm/rev Thread pitches: Electrical connection: 380 V, 11 kW Space required: 3400 x 1400 x 1300/1700 mm Weight: approx. 2700 kg

Condition: reconditioned (used), Year of construction: 2002, Multicomponent Arburg IMM (Horizontal & Vertical) Clamping force 100 tons. Year 2002. Machine will be delivered RE-Conditioned (full checked tested and operate) Ask us for our service of Start Up with Warranty of working condition. Technical details CLAMPING FORCE 1000 kN SCREW DIAMETER Horizontal bimetalic 25mm Pgsdpfx Asp Audqengeu SCREW DIAMETER Vertical 18mm INJECTION PRESSURE 2500 BAR INJECTION VOLUMEN horizontal 54gr INJECTION VOLUMEN Vertical 20gr DISTANCE BETWEEN TIE BARS (h x v) 420x420mm MIN. MOULD HIGHT 250mm DAYLIGHT MAX 750mm WORKING HOURS 79.115 YEAR OF BUILDING 2002

Condition: ready for operation (used), Year of construction: 2003, operating hours: 21,200 h, functionality: fully functional, machine/vehicle number: 190332, clamping force: 1,000 kN, injection weight: 15 g, ejector force: 66,000 N, ejector stroke: 225 mm, plate length: 795 mm, No reserve price – guaranteed sale to the highest bidder! Auction of a 3-color injection molding machine! TECHNICAL DETAILS Clamping force: 1,000 kN Tie bar spacing: 420 x 420 mm Mounting platens: 795 x 795 mm Mold height: 300 mm Maximum platen distance: 950 mm Ejector stroke: 225 mm Ejector force: 66 kN Injection Unit 1 (150 series) Screw diameter: 15 mm Injection volume: 17 cm³ Pgjdsy Hki Aopfx Angeu Shot weight: 15 g Injection pressure: 2,750 bar Injection Unit 2 (150 series) Screw diameter: 15 mm Injection volume: 17 cm³ Shot weight: 15 g Injection pressure: 2,750 bar Injection Unit 3 (60 series) Screw diameter: 15 mm (high abrasion resistant) Injection volume: 17 cm³ Shot weight: 15 g Injection pressure: 2,080 bar MACHINE DETAILS Control system: Selogica Clamping unit: hydraulic Operating hours: 21,200 h FEATURES 1 vertical injection unit, mounted on supports for the 2nd injection unit instead of on the clamping unit tie bars, manually operated, working position adjustable between 70 and 250 mm 2 x core pull Open nozzle 15 mm wear-resistant, without heating band (1st injection unit 150) Technology level 2 – servo-regulated hydraulic system with two variable displacement pumps Technology level 3 hydraulic system with three variable displacement pumps for simultaneous movements Heating band for open nozzle Injection unit 150 for vertical injection into the mold parting line for 2-component processing Position-regulated screw with control valve on the injection unit, including regulated back pressure Position-regulated screw with control valve for multi-component machines – for injection unit 2 Injection unit 60 for horizontal injection into the mold parting line as the 3rd injection unit For VE 906/00, injection unit 60 in L-position: unit lowered by 70 mm Plasticizing cylinder assembly 15 mm (without nozzle), with advanced feed and pressure reducing valve Open nozzle 15 mm wear-resistant, without heating band (L-position) Nozzle tip with radius 15 (L-position) Heating band for open nozzle (L-position) Position-regulated screw for the third injection unit Documentation/manual

Condition: good (used), Year of construction: 1999, operating hours: 95,239 h, functionality: fully functional, machine/vehicle number: 173937, clamping force: 2,000 kN, screw diameter: 55 mm, clearance between the columns: 520 mm, mold height (min.): 250 mm, total length: 5,100 mm, total width: 1,800 mm, total height: 2,200 mm, overall weight: 6,630 kg, Equipment: documentation/manual, The machine ran perfectly until the last day before the new machine was delivered to us. Pgjdpfsv D Nxljx Angsu The machine is therefore in good used condition. Due to a lack of space in the injection molding shop, the machine is being sold and is no longer powered. The pump / injection unit / clamping unit are sealed. The machine manual is available Videos of the machine are available Pump operating hours: 95239 Automatic operating hours: 86082 Repairs from recent years: Filter replaced annually 05/2024 Fan in the control cabinet replaced 07/2023 New valve for Y201 and Y210 nozzle forward/backward 02/2023 New keypad installed. Field with motor and heater 12/2022 Ejector sealed. Injection unit sealed including new piston

Condition: excellent (used), Year of construction: 2001, machine/vehicle number: 184686, clamping force: 1,000 kN, screw diameter: 25 mm, clearance between the columns: 420 mm, displacement volume: 54 cm³, injection weight: 45 g, opening stroke: 500 mm, For sale is an Arburg injection moulding machine, model 420 C 1000-150/60. The machine is in excellent technical condition and has been very well maintained. Technical data: Podpfx Asx Itamengegu Year of manufacture: 2001 Clamping force: 1000 kN Tie bar spacing: 420 x 420 mm Opening stroke: 500 mm Mould installation height: 250 mm Mould mounting plate: 570 x 570 mm Ejector stroke: 175 mm Screw diameter: 25 mm Calculated shot volume: 54 cm³ Shot weight: 45 g/PS The machine is offered without periphery. Rotary table, material conveying systems, temperature control units and other accessories are not included.

Year of construction: 2003, condition: good (used), For sale is a 2 component injection molding machine brand Arburg and type 420 C The machine comes from a production where much importance is attached to maintenance and cleanliness. Likewise, the maintenance and repair are carried out there immediately by skilled personnel Pjdpfelwxpisx Angsgu Arburg 420C 1000-150/60; clamping force: 1000 kN Year of construction 04/2003; screw diameter Ø25mm each installed; 9x mold heaters; 2x core pull hydraulic; 1x pneumatic valve gate; 9x temperature sensors; 1x cavity pressure sensor; Currently approx. 36,684 hours; 1x spare cylinder Ø18mm for unit 2 additionally available Prices plus VAT Viewing possible by appointment. Contact us, our team is happy to help you. Trade-in or exchange possible! Machines purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES ETC. Do you need a high-quality but inexpensive metalworking machine for your production? Or do you want to sell yours? For more information or to contact us, please visit our website

Condition: reconditioned (used), Year of construction: 2000, functionality: fully functional, 2000 Arburg projector. 130 tons of closing force. The machine is delivered completely reconditioned in our facilities in Heras (Cantabria). New gaskets in the sealing body. We can show it in operation. Technical details CLOSING POWER 1300 kN PLATE DIMENSIONS 660x840 OPENING STROKE 575mm MAXIMUM DISTANCE BETWEEN PLATES 800/850 Pgsdpfx Anorxtpdsgju DISTANCE BETWEEN COLUMNS 420x420/470x470 SPINDLE 50mm INJECTION VOLUME 353cm3 INJECTION WEIGHT 117 YEAR OF MANUFACTURE 2000 INJECTION PRESSURE 2500bar
