Used Weinig Multirex for sale (472)

Condition: good (used), Year of construction: 1999, Working width 13-230 mm Working height 6-120 mm 4 spindles u-r-l-o Feed motor power 1.5 kW Dcjdpfx Aox U Ru Ujc Noc Sico counter Steel infeed rollers One rubber outfeed roller External dimensions approx. L x W x H 3100 x 1400 x 2000 mm Weight approx. 2000 kg The data is taken from a brochure, therefore no guarantee is given.

Condition: good (used), Planing width 610 mm Sturdy cast iron construction Edge jointing fence Auxiliary stop 4 kW, 380 Volt Dodpox U Dgdjfx Ac Njcc Two-knife wedge shaft Tables fold upwards Machine ready for immediate use

Condition: good (used), Year of construction: 1966, Milling fence with fine adjustment Sliding table Crosscut saw Aigner table extension with feed unit Holz-Her ETZ, 8 speeds Dcjdpsx U Dfgefx Ac Noc 380 volts

Condition: excellent (used), functionality: fully functional, Four-side planer Weinig Unimat 23E Working width: 230 mm Working height: 160 mm Number of spindles: 6 Dcedpfsx Uxi Tjx Ac Noc Spindle arrangement: 1. Bottom 2. Right 3. Left 4. Top 5. Top 6. Bottom Feed speed adjustable via variator: 6-24 m/min Material feeder Feed driven by cardan shaft Pneumatic pressure rollers Total power: 52 kW

Condition: good (used), WEINIG HYDROMAT H-23 10 SPINDLE MACHINE WITH TILT BEAM SHORT INFEED TABLE 1: BOTTOM 7,5KW 2: RIGHT 11 KW 3: LEFT 11 KW 4: RIGHT 11 KW 30° TILTABLE 5: LEFT 11 KW 6: TOP 11 KW 7: BOTTOM 11 KW 8: TOP 11 KW 9: BOTTOM 11 KW 10: UNIVERSAL 11 KW 360° TILTABLE 60 M/MIN+ ELECTRIC. FEED 14 x DRIVEN TOP FEED ROLLERS Djdpfx Acsycvfms Necc 7 x DRIVEN BED FEED ROLLERS AUTOM. BED LUBRICATION PNEUM. POWERED SIDE PRESSURE ROLLERS PNEUM. POWERED HOLD DOWN ON 7+9 DIMENSION: APPR 5400 X 2000 X 1800 MM WEIGHT: APPR. 7500 KGS DUSTHOODS: 10 x 140 MM DIAMETER

Condition: excellent (used), Year of construction: 2012, Weinig H1000 moulder with E3 infeed and A3 outfeed Weinig Hydromat 1000 with 5 Spindles. (Year 2012) Separate electrical panel Separate remote control panel Automatic lubrication system for bedplates Memory system Full sound enclosure Weinig E3 moulder infeed +pack scissors lift (3000kg). Weinig A3 drop leaf outfeed + pack scissors lift (3000kg) + pack outfeed chain conveyor. No 1. 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer No 2. 7.5kw - Right 6000rpm + profile jointer No 3. 7.5kw - Left 6000rpm + profile jointer No 4 . 7.5kw - Top 6000rpm + Outboard bearing + Straight jointer No 5 . 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer 50mm spindles Beam 0.55kW Dcsdoycvfgspfx Ac Nsc Full documentation included. Extraction manifold included.

Condition: excellent (used), Year of construction: 2003, Weinig Hydromat 23C with 6 Spindles. Separate electrical panel. Automatic lubrication system for bedplates Maximum dimensions 140mm x 230mm No 1.  11kw - Bottom 6000rpm + Outboard bearing - straight jointer prepared No 2. 11kw - Right 6000rpm - straight and profile jointer prepared No 3. 11kw - Left 6000rpm - straight and profile jointer prepared Dcedpfeycvd Aex Ac Nsc No 4 . 15kw - Top 6000rpm + Outboard bearing - jointer prepared No 5 . 11kw - Top 6000rpm + Outboard bearing - straight jointer No 6 . 18.5kw - Bottom 6000rpm + Outboard bearing - straight jointer 7.5 kw feed. 6-60m/min (Possible to increase speed as needed). 50mm spindles Beam 0.55kW Full documentation included. Possible to supply with hydro tooling if needed. Possible to supply with infeed and outfeed if needed.

Condition: used, Technical specifications: Maximum planing width: 240 mm Maximum planing height: 130 mm Spindle diameter: 40 mm Number of spindles: 6 Spindle configuration: bottom 5.5 kW right/left 7.5 kW Dcsdpfx Ajycu R Iec Nec top 5.5 kW top 5.5 kW bottom 5.5 kW universal 5.5 kW 1/4/5/6 spindles on separate motors 2/3 on a single motor Ribbed worktables Ribbed rollers in the table: 2 Upper steel feed rollers: 5 Upper rubber feed rollers: 3 Extraction port diameter: 6 x 140 mm Infinitely variable feed rate Feed drive on cardan shafts Lubrication pump for worktable 2 smooth rollers in the table Pressure: 6 atm. Electric elevation of machine body Power supply: 400 V Total power: 32 kW Overall dimensions: Length: 4600 mm Width: 2000 mm Height: 1800 mm

Condition: good (used), With the OptiControl instrument measuring system from WEINIG, you can optically measure drills, PowerLock and hydraulic instruments and transmit the highly accurate measurement results to the woodworking machine. The device's 20x optical magnification ensures accurate measurement results. The measurement results are transmitted to the planer via a computer and the PowerCom software. The machine can also create completely new profiles. OptiControl PowerCom offers you: Dcjdpfx Asycurrec Nsc measuring instruments recording data from measured instruments creating new profiles Online data transmission optimization of work tasks time saving when setting up the planerTool measuring stand for measuring tool radius and height. Measurements can be read of digital read-outs. Technical details Tool diameter min - 100mm Tool diameter max - 300mm Tool length maximum - 330mm 220v - 50hz Weight - 180 kg Supplied with operating instructions.

Condition: excellent (used), Year of construction: 2004, Weinig Rondamat 960 Powerlock (Automatic straight knife grinder and profile grinder) Dedpsycurlefx Ac Necc Please check in your junk mail if you do not receive a reply within 24hrs from sending your inquiry !!! Specification as follows Weinig Rondamat 960 Powerlock / HSK profile grinder. High pecision knife grinder for sharpening straight knives and profiling using a template. Sharpening straight knives in the cutter block. Manual grinding machine for profile and straight grinding. Grinding wheel diameter min./max.: 150 mm / 225 mm Grinding wheel width: Ceramic 5 mm, Borazone 10 mm Grinding wheel bore: 60 mm Tooling circle min./max.: 100 mm / 300 mm Tool width max.: 240 mm Grinding wheel drive: 1,1 kW Spindle rpm: 1700 / 2000 / 2400 / 3000 U/min Free angle: Radial: (at the back) 10 - 30 degrees, Axial: 0 - 20 degrees For swivel heads up to 60 degrees Coolant tank approx. 50 litres Table feed 0 - 240 mm Electrical connection approx. 2 kW Pneumatic connection value 5 bar Operating voltage 380 V / 50 Hz Full documentation. POWER LOCK SYSTEM option For grinding powerlock tools. Tool holder with manual HSK quick clamping system. Radial table clamping with fine adjustment Max tool width 240mm Max COMFORT PACKAGE option Variable grinding wheel speed 1500 to 3000rpm Lamp Back clearance angle is motorised Grinding wheel advance is motorised Setting of the side clearance angle is pneumatic Hydraulic grinding wheel clamping. Please check in your junk mail if you do not receive a reply within 24hrs from sending your inquiry !!!

Condition: excellent (used), Year of construction: 2012, Weinig H1000 moulder Weinig Hydromat 1000 with 5 Spindles. (Year 2012) Separate electrical panel Separate remote control panel Automatic lubrication system for bedplates Memory system Full sound enclosure No 1. 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer No 2. 7.5kw - Right 6000rpm + profile jointer No 3. 7.5kw - Left 6000rpm + profile jointer No 4 . 7.5kw - Top 6000rpm + Outboard bearing + Straight jointer No 5 . 7.5kw - Bottom 6000rpm + Outboard bearing + Straight jointer 50mm spindles Beam 0.55kW Full documentation included. Extraction manifold included. Dcsdpfx Ajycuq Ioc Nec Possible to supply with Weinig mechanisation if needed (Year 2012)

Condition: good (used), 6 Head Multi-head Horizontal Bandsaw Saw pulley diameter: 915mm Sawblade width (max): 100mm Standard saw speed 35m/s Timber width Max: 305mm – 450mm Maximum opening saw to chain bed: 305mm Feed chains to saw lines 292mm Main motor: 6x 18.5kw Dcsdpeycuqnefx Ac Nec Feed speeds (variable): 15 – 60m/min std, 7.5 – 30m/min (optional) Type of feed: internal overhead feed system with driven chains synchronised with chain bed Operators control station including speed control and start stop controls Working height 800mm

Condition: reconditioned (used), Year of construction: 1985, functionality: fully functional, 4-sided 8-head planer. head arrangement: lower horizontal, right vertical, left vertical, upper horizontal, right vertical, lower horizontal, upper horizontal, and the last universal, a new inverter and new cables were installed, smooth feed regulation. The machine has been completely renovated. Weight 4600 kg Dcjdpfx Aovtpk Hoc Nec

Condition: excellent (used), Year of construction: 1994, Weinig 925 Rondomat profile knife grinder Stock code: 15443 Price: request for quotation $ Subcategory: Knife grinders Producer: Weinig Model: 925 Condition: used Tag number: 15443 Machine type: Grinding machines UMCC: G6775 Producer: Weinig Model: 925 Rondomat Year: 1992 Serial number: 925-438 Description: Weinig 925 Rondomat profile knife grinder We offer turnkey services with this machine. Printable page Get a quote General technical data Shaft length 9-1/2 inches Maximum tool diameter 9 inches Motor 1.5 HP, 220/440 V 8-7/8 Maximum wheel diameter Variable grinding wheel speeds: 1700, 2000, 2250, 2800 rpm Dcsdpfx Acsn Ut Sls Njc Relief angle for back relief: 15 - 45 degrees Axial: 0 - 10 degrees Cooling liquid

Condition: used, Tenoning spindle 1 St. Number of milling agregates 4 St. Spindle diameter 50 mm 1 used Weinig Unicontrol 6 window system ----- Manufacturer's description: For the production of individual parts, elements, and small series. Spindle arrangement: One cross-cutting saw, one single-sided tenoning and slotting spindle, one right-hand profiling spindle, one tenoning and slotting spindle, and profiling spindle suitable for holding multiple tools stacked on top of each other, with pneumatic spindle movement. Slotting table with motorized table movement and automatic transfer to the continuous, chainless rubber roller feed of the profiling unit. Feed height adjustment manually. Workpiece clamping via 2 pneumatic clamping cylinders. Length stop with scale and magnifying glass for frame or sash external dimensions. Tool positions (longitudinal and transverse machining) controlled via selector switch on the control panel. Technical Specifications ----- Crosscut Saw ----- Number of Tools: 1 Spindle Speed: 2,800 rpm Spindle Diameter: 40 mm Max. Tool Diameter: 350 mm Motor: 3 kW Mortise and Slot Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Spindle Speed: 3,500 rpm Spindle Diameter: 50 mm Tool Clamping Length: 320 mm Max. Tool Diameter: 320 mm Motor: 11 kW Profile Spindle ----- Number of Tools: 3/4 pcs. for wood thicknesses IV 68 - IV 92 Spindle Speed: 6,000 rpm Spindle Diameter: 50 mm Tool clamping length 320 mm Max. tool diameter 232 mm Motor 11 kW Special equipment: Synchronous spindle ----- Pneumatically timed forward/backward for tear-free rerouting of window sashes, frames, and doors. Spindle diameter 50 mm, 4 kW Tool clamping length 120 mm, zero tool diameter 112-140 mm Max. tool diameter 232 mm, spindle speed 6000 rpm Motor boost for synchronous spindle from 4 kW to 7.5 kW Screen control for 99 window types. One type can contain up to 8 different parts, each with 2 end profiles and 2 longitudinal profiles. Production options: single parts, double parts, frame-by-frame, series, rerouting. Data entry via keyboard with integrated operator guidance and error diagnostics. 1 Grooving spindle from above ----- Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm, with 10 x 4 mm key Clamping length: 13 mm Clamping length: 40 mm Axial stroke, 2 positions Radial stroke, 2 positions Max. tool diameter: 130 mm Grooving spindle motor boost from 2.2 to 3 kW 1 Fitting milling unit, right: ----- For milling fitting grooves in the circumferential milling pass or for grooving in the longitudinal profile. Dedpfsx Tu N Hex Ac Necc Pneumatic horizontal movement with selector switch on the control panel. Motor power: 2.2 kW Speed: 6000 rpm Spindle diameter: 40 mm Clamping height: 125 mm Tool cutting radius: min. 140 mm, max. 180 mm Home position below table level: 10 mm Special design of the fittings milling machine: Clamping length 150 mm Axial stroke 80 mm, 3 positions 3 tools Radial cycle, 2 positions Motor booster for the hinge milling spindle from 2.2 to 3 kW Hinge milling spindle for 230 mm tool diameters in and above the table Electric height adjustment of the feed with selector switch on the co...

Condition: used, Bore: 40 mm Dcjdpfx Acex Tu Rwj Njc Cutting circle (ø): 125 mm Length: 170 mm Material: steel Blades: Planer strip knives Z2 + chamfer cutter Available: 2 pieces Price per piece: €239.00 + VAT

Condition: excellent (used), Year of construction: 1995, Weinig Profimat 23E four side planer - German production - year of production 1995 - right and left spindles with a face milling cutter ensuring parallelism and a right angle of 900 - element width measurement - electronic width adjustment TECHNICAL PARAMETERS: planing width 230 mm Dcjdeibq Niopfx Ac Njc planing height 120 mm electronic planing width control 1 lower spindle 4 kW 2 right spindle 4 kW 3 left spindle 4.2 kW (face milling) 4 spindle right 4.2 kW (face milling) 5 upper spindle 7.5 kW element width measurement electric height adjustment of the feed rollers electric height adjustment of the upper spindle spindle diameter 40 mm six top steel rollers yen top roller, rubber one roll in the table top pulling pneumatic pressure feed on cardan shafts pre-table length 2470 mm diameter of nozzles 140 mm Machine dimensions 456x240x220 weight 4000 kg

Condition: used, Working width: 260 mm Dcjdpfx Acox Ttbno Nsc Working height: 160 mm Spindles: 5 Spindle 1: Bottom / 7.5 kW / 40 mm Spindle 2: Right / 11 kW / 40 mm Spindle 3: Left / shared motor with right / 40 mm Spindle 4: Top / 11 kW / 40 mm Spindle 5: Bottom / 4 kW / 40 mm Feed: 4 kW Weinig Profimat 23 planing and profiling machine for four-sided planing and profiling of timber in construction grade version, in excellent original condition and incl. planing heads (2 x 270 mm // 2 x 170 mm)

Condition: good (used), Year of construction: 2010, Weinig Conturex C126 CNC Window production machine Description; Year of construction: 2010 Working width 40-260mm Working heigth 25-150mm Powergrip clamping table Table loading length single table 4 x 2280mm Workpiece length single table cycle 220-2700mm Table loading length double table (combined) 2 x 4630mm Workpiece length double table cycle without follow up 220-5000mm Workpiece length double table cycle with follow up 5000-6000mm Dcsdpfx Asx Tq I Eoc Noc Fully new PC & Software 2025 Full description on request Available approx. summer 2026 (Despite our great care all changes, mistakes in technical data, prices and all information is subject to (typing) errors. No guarantee on printed data! Availability subject to prior sales). (Alle Änderungen und Irrtümer in den technischen Daten, Angaben und Preisen vorbehalten! Keine Garantie auf gedruckte Daten!. Verfügbarkeit vorbehaltlich Zwischenverkauf). Prices excl. advertisement cost MachineSeeker / Preise exkl. Inserierungskosten MaschinenSucher Best woodworkingmachines from the Netherlands Holland Die besten holzbearbeitungsmaschinen aus die Niederlande De beste gebruikte machines uit Nederland

Condition: excellent (used), Catalogue number: 7715 TECHNICAL SPECIFICATIONS - Maximum workpiece width: 220 mm - Maximum workpiece height: 130 mm - 8 spindles: 1) Bottom horizontal 220 mm 5.5 kW 2) Right vertical 130 mm 7.5 kW 3) Left vertical 130 mm 7.5 kW 4) Right vertical 130 mm 5.5 kW 5) Top horizontal 220 mm 11 kW – 5th spindle electrically adjustable up/down 6) Bottom horizontal 220 mm 5.5 kW 7) Bottom horizontal 220 mm 5.5 kW – 7th spindle with support + Jointer system (cutterhead sharpening) 8) Universal 220 mm, 360° adjustable, 7.5 kW - All spindles adjustable vertically and laterally - Spindle diameter: 40 mm Feed system (top): - 6 double-toothed infeed rollers, driven, + 1 single roller - 3 double smooth rubber outfeed rollers, driven + 3 single rollers - Digital length counter Dedpfow Ipcvjx Ac Njcc Feed system (bottom): - Swivelling toothed steel infeed roller integrated into lower table - 3 smooth steel feed rollers - Feed drive via Cardan rollers - Pneumatic pressure rollers - Stepless feed speed adjustment + 2-speed gearbox: 10–60 m/min - Feed motor: 10 kW - Electric thickness adjustment - Body lifting motor: 0.75 kW - Centralised table lubrication - Extraction connection diameters: 5x140 mm, 3x120 mm - Machine dimensions (LxWxH): 4680x1780x1850 mm - Control cabinet dimensions (on pallet): 1020x1000x2230 mm - Weight: approx. 5000 kg ADVANTAGES - Equipped with 8 cutterheads - Universal spindle - Ideal for wet and dry timber - Made in Germany, WEINIG brand - Unpainted (original finish) - Very low operating hours - Used thickness planer, like new Net price: 165,900 PLN Net price: 39,500 EUR (based on exchange rate 4.2 EUR) (Prices may change with significant exchange rate fluctuations)

Condition: used, Year of construction: 1962, Used machine Dedpfx Asw Sbbroc Nscc Year of manufacture: 1962 Equipment and technical data: Planing width: 630 mm Working height: 250 mm Table length: 1100 mm Extraction nozzle: 160 mm Knives: 4 strip planing knives The machine does not have a motor brake! Location: Flörsheim Availability: short notice

Year of construction: 1997, condition: excellent (used), max width of the workpiece 23cm max height of the workpiece 18cm Dodpfx Ajk Dxraec Nscc 1 lower horizontal spindle 2 right vertical spindle 3 left vertical spindle 4 top horizontal spindle heads adjustable up / down, right / left spindle diameter 40mm Hydraulic side feed on the feeding table

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, Weinig Powermat 600 Year of manufacture: 2014 5 spindles Feed motor: 3 kW 1st motor: 7.5 kW 2nd motor: 11 kW 3rd motor: 7.5 kW 4th motor: 7.5 kW Spindle configuration – bottom, right, left, top, bottom Soft start Heated control cabinet (Webasto) Pneumatic pressure tables Manual adjustment of tables Electronic brakes Manual axis adjustment Variable feed speed control Djdjxwtwbopfx Ac Nscc

Condition: used, Year of construction: 2004, functionality: fully functional, WEINIG Unicontrol / Univar 12 – Tenoning and Profiling Centre (Year 2004) Very well-maintained machine from window and door production. Versatile machining centre for longitudinal and transverse processing, including tenoning, slotting, profiling, and grooving units. Including OERTLI tooling. Technical Highlights - Workpiece dimensions: width 40–220 mm, height 40–100 mm, length up to 2600 mm - Feed speed: 3–25 m/min (cross), 4–18 m/min (longitudinal) - Unitec tenoning spindle: 11/15 kW, Ø 50 mm, tool Ø up to 320 mm Dcjdpfsyccdvox Ac Nec - Univar profiling spindle: 11 kW, 6000 rpm, tool Ø up to 240 mm - Several grooving and hardware groove units (each 3.0 kW) - Crosscut saw 3.0 kW, tool cutting circle 400 mm - Pneumatics 6–10 bar, extraction system according to layout plan Condition - Fully functional - Dust-tested - Immediately available - Inspection possible at any time by appointment - Delivery date by agreement Price - Including dismantling and loading; FCA Slovakia

Condition: excellent (used), Catalogue number 7784 TECHNICAL DATA - Spindle diameter: 30 mm - Working height of spindle: 150 mm - Interchangeable spindle - Spindle locking - Adjustable up/down + angle - Original cast iron fence with full adjustment - 4 spindle speeds + left/right: 3000/5000/6000/10000 rpm - Table dimensions: 1120x800 mm - Motor: 3.7 kW - Dimensions (L/W/H): 1100x1400x1160 mm - Weight: 775 kg ADVANTAGES – German-made – Used milling machine – Very good condition Net price: 6,900 PLN Net price: 1,640 EUR Net price calculated at a rate of 4.2 PLN/EUR Dsdpoxt I Adsfx Ac Njcc (In case of significant exchange rate fluctuations, the price may change)
