Used Web Guiding System for sale (8,509)

Year of construction: 2018, condition: like new (used), Weber screwing system: - Screw bunker with orientation and feeding system - dosing system - pneumatic feeding system - screwing gun - festo pneumatic gun travel operation system - frequency regulator 4 complete, barely used, systems for sale. Price is per set / negotiable. Screwing gun heads can be changed and adapted for multiple different types of screws. Contact for more information. Lredpfx Aeif Rvajf Esu

Condition: used, functionality: fully functional, fuel type: gasoline, overall weight: 32 kg, DGUV certified until: 03/2026, Year of construction: 2018, machine/vehicle number: 20008074, Equipment: UVV, Specifically designed for compaction of pipe collars in trenches. Other areas of application: compacting edge zones of walkways; installation of drainage systems. Due to its low weight, it is easy, flexible, and safe to operate even on slopes and in very confined spaces. Lodpexpu Tbofx Af Eoru

Year of construction: 2017, condition: excellent (used), Bluhm weber legi-air 4050 labeling machine Lredpfx Afsfp A I Eo Eou More pieces in stock! year built: 2016-19 Print resolution 8 dots/mm (203 dpi) 12 dots/mm (300 dpi) 24 dots/mm (600 dpi) Print speed Up to 400 mm per second Tamp sizes (mm) Tamp-Blow standard of 12.5 x 7 to 160 x 300 mm, label lengths must be limited in accordance with label quality, longer or smaller labels are possible using special tamps Label gap Minimum 3 mm Label roll 300 mm diameter, up to 450 running meters, core 76 mm (3"), outside winding (optional inside winding) Data interfaces RS232, RS422, RS485, Ethernet Optional: Profibus Dimensions (L x H x W) 770 x 560 x 580 mm, Applies to system with 250 mm stroke Display controller Multi-language operator guidance 5.7" VGA touch display Service interval indicator Polling, editing and saving of label data USB connection for memory medium or keyboard Compressed air connection 6 bar, the compressed air must be clean, dry and oil-free

Condition: excellent (used), machine/vehicle number: 577EK51, REF: MM6187 1 x Webomatic double chamber vacuum packing machine supplied with 16 x filler plates. Technical specification ⚙️ Ljdpfoxn Rz Eox Af Ejru ✅ Model - ED 120. ✅ Serial number - 577EK51. ✅ Sealing bars - 4 x 640mm long. ✅ Distance between sealing bars - 580mm. ✅ Vacuum pump - Busch RA 0100 E 5Z1. ✅ Electrical requirements - 400 V / 50 hz / 3 phase. ✅ Power - 2.2 kW / 5.4 Amps.

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, Vertical Turning Lathe – WEBSTER & BENNETT R48R 2PB C-axis, driven tools Condition: Used Year of manufacture: 2006 CNC: Siemens 840D Powerline Technical Specifications Faceplate diameter: 1,200 mm Turning diameter: 1,200 mm Number of slides (ram): 1 Ram stroke: 1,200 mm Ram cross-section: 200 × 200 mm Lrsdpfx Asxl E R Njf Eou Max. workpiece height under crossbeam: 1,200 mm X-axis travel: 1,200 mm C-axis: available (C-Axis) Drives / Speeds Main spindle motor: 37 kW Main spindle speed: 0.2 – 430 rpm Milling spindle motor: 17 kW Milling spindle speed: 20 – 3,000 rpm Tool changer Turning: 50 positions, Capto C6, robot handling Milling: 10 positions, ISO 50, robot handling Other features Magazine and stations for turret/tool holders Machine weight: approx. 18 t Scope of delivery as described above only. Further options/accessories only as per written agreement.

Condition: used, axle configuration: 2 axles, loading space length: 7,400 mm, loading space width: 2,450 mm, loading space height: 2,650 mm, first registration: 05/2017, wheelbase: 5,240 mm, color: silver, Year of construction: 2017, Maximum front axle load: 10,000 kg Maximum rear axle load: 10,000 kg Unladen weight: 4,940 kg Payload: 15,060 kg Lrodpfexmkhcox Af Eeu gross vehicle weight (GVW): 20,000 kg Height: 400 cm Extendable body: Yes APK (Technical Inspection): valid until 05.2026 Contact Gert Woudenberg for further information.

Condition: excellent (used), From 2022 with complete documentation and with Zebra ZE500 printer. Good as new. Ljdpfjvt An Sox Af Eoru

Condition: used, Vibratory Feeder with Pneumatic Screwdriver Stand Eco Line Vibratory Feeder, Sorting Device, Bowl Feeder, Vibratory Bowl, Automatic Screwdriver WEBER Type ZSU 24 Machine No.: 1113212 Year of Manufacture: 2003 Vibratory Feeder WEBER ZSU 24 Bowl diameter: 240 mm Bowl internal height: 70 mm Sorting track width: 10 mm Power supply: 230 Volt, 50 Hz Operating pressure: 6 bar (for singulation and screws) Control voltage for pneumatic valves: 24 Volt Ledjxf Up Uspfx Af Eoru - Controller for infinitely variable vibration speed = infinitely variable transport speed - Vibratory bowl in protective enclosure - With pneumatic feeding system - Feed impulse via external electrical control - The feeder was used for feeding screws M5 x 12 mm - Some pneumatic hoses need to be replaced - Siemens S7-200 CPU 224 PLC MISSING Space requirements vibratory bowl L x W x H: 450 x 450 x 315 mm Vibratory bowl weight: 32 kg WEVER Eco Line Screwdriver Stand Guide column: Ø 60 x 525 mm Height adjustment: 345 mm Primary stroke pneumatic cylinder 1 FESTO DZF-32-125-P-A-SM: 115 mm Screwdriver holder diameter: Ø 50 mm Secondary stroke pneumatic cylinder 2 FESTO: 30 mm Screwdriver guide diameter: Ø 37 mm Distance screwdriver guide to table: 135 - 465 mm - 1 piece flat cylinder FESTO, Type DZF-32-125-P-A-SM - 1 piece flat cylinder FESTO, Type probably DZF-32-30-P-A-SM - Screwdriver linear motion frame on linear guide - 3 position sensors on the cylinders - Festo pressure switch - Bosch pneumatic valve Screwdriver stand dimensions W x D x H: 200 x 410 x 1050 mm Screwdriver stand weight: 35 kg good condition Total weight vibratory feeder and screwdriver stand: 67 kg Attention: The original Siemens S7-200 CPU 224 PLC is missing (see picture control cabinet without PLC), therefore, an automatic process is not possible in this condition. The control system also managed the separations of the screws and controlled the screwdriver itself. The vibratory bowl is fully functional even without the PLC, the built-in vibratory bowl controller does not require PLC control. Process: Fasteners are filled into the bowl in bulk and conveyed upward by mechanical vibration (micro-throw principle). The vibratory bowl is automatically switched on or off depending on the fill level of the screw magazine. The screw is then conveyed by compressed air through a plastic hose to the downstream device. The feed impulse for each individual screw is triggered externally by the downstream device.

Condition: good (used), functionality: fully functional, mount diameter: 80 mm, throat depth: 200 mm, spindle mount: MK 1, table width: 320 mm, table length: 250 mm, stroke length: 70 mm, type of input current: three-phase, rotational speed (max.): 1,800 rpm, Equipment: lighting, type plate available, Drilling machine, drilling machine, stand drilling machine, column drilling machine -Manufacturer: Webo, G6 column drilling machine -Motor: 0.75kW 380v 50 Hz morse MK-1 chuck max drill size: M6 -Gearbox: with flat belt coolant pump automatic-manual operation spindle speed per minute -Table size: 320 x 250 mm Lrodpfjwzaqxjx Af Eou -Spindle stroke: 70 mm -Reach: 200 mm -Column Ø: 80 mm -Dimensions: 450/600/H1800 mm -Weight: ca 190 kg

Year of construction: 1979, operating hours: 216 h, condition: reconditioned (used), functionality: fully functional, Twin-screw extruder, parallel Manufacturer: Hans Weber Maschinenfabrik GmbH Type: DS 85 Year of manufacture: 1979/2022 Machine no.: 85-399 Screw geometry: for PVC-hard profiles Screw diameter: 2 x 85 mm Screw length: 17 x D Screw speed: max. 30 rpm Screw torque: 10000 Nm Motor power: 3.3 - 25.0 kW Drive motor: commutator motor Elektra Faurndau Cylinder heating/cooling zones: 4/2 (air cooling with fan) Tool heating zones: 8 Temperature control: 12 x digital temperature controllers (PMA KS40) Accessories: Melt pressure sensor and melt temperature sensor Connected load: approx. 60 kW (without tool) Extrusion height: 1100 mm Output capacity: approx. 150 - 180 kg/h for PVC-hard profiles Accessories: Material hopper and connection flange Accessories: Vacuum pump (1.1 kW) incl. material separator Dimensions: 4500 x 1200 x 2100 mm (LxWxH), incl. material hopper Weight: approx. 4000 kg Note: The electrical control cabinet was completely renewed approx. 3 years ago. Lrsdpsxlcfkjfx Af Eju Since then, the extruder has only been in operation for 216 hours. Condition: The extruder was repainted (light gray, RAL 7035) and checked for function.

Condition: good (used), Year of construction: 2004, Table diameter: 1220 mm Max. turning diameter: 1500 mm Table speed range: 4.5 to 100 rpm Feed range: 0.127 mm to 6.35 mm per revolution Maximum height under crossrail: 900/1200 mm Slide travel (X-axis): 1000 mm Main drive motor: 41 kW Lsdjxg Nmkopfx Af Eoru Tool changer: 30 positions Accessories: - 8 clamping jaws - 30 tool holders with full enclosure - Oil mist extraction

Condition: used, bore capacity in steel (diameter) 23 mm throat 310 mm bore stroke 150 mm turning speeds 90 - 2000 U/min 420 x 360 mm total power requirement kW / Volt weight of the machine ca. 650 Kg dimensions 1,2 x 0,8 x 2,4 mm Lodpsvkixrefx Af Eeru Bench drill - Left/right rotation - Advance - Base frame

Condition: excellent (used), bore capacity in steel (diameter) 35 / 45 mm throat 330 mm bore stroke 200 mm morse taper MK 4 table diameter 600 mm spindle turning speed - stepless 80 - 1800 U/min table adjustment - upper 450 mm spindle stroke 400 mm total power requirement 2,5 kW weight of the machine ca. 1,4 t Lrsdpjunt Rpsfx Af Eou dimensions of the machine ca. 2,5 x 1,2 x 0,8 m automatic feed.

Condition: used, bore capacity in steel (diameter) 40 mm throat 380 mm bore stroke 160 mm Ledpfx Afsxddtyo Eeru 4 speeds 60 - 1250 U/min total power requirement 3,3 kW weight 900 kg Features: -Gear drilling machine with a robust design -Column-mounted drilling table -Right/left rotation -Feed -Coolant system

Year of construction: 1997, condition: used, functionality: fully functional, machine/vehicle number: DS 70 087, WEBER DS 7.22 Twin Screw Extruder Ljdpfx Afsxghz Ho Eoru

Condition: as good as new (ex-display), The scope of delivery includes: 01x waste container, second choice Manufacturer: Weber Depth lid closed: 755 mm Depth lid open: 770 mm Height 1,320 mm Lid closed Total width: 1,350 mm Capacity: 360 kg Volume: 770 liters Further data / information: Lsdpfeku Aw Nsx Af Eoru Material color of garbage can: black Lid material color: yellow Usable width: approx. 1,085 mm Usable depth: approx. 640 mm Usable height: approx. 1,000 mm Material: polyethylene (PE) Tires: 4 tires (2x braked) Tare weight: 68 kg Note: Effective width and effective depth are tapered towards the bottom. General information about the item: This item is only offered for collection. Any additional transport or shipment of this item is subject to additional costs, which can be requested from us separately depending on the place of delivery or scope of delivery.

Condition: used, Webomatic TL300 traysealer Lrjdjxdrt Ujpfx Af Esu Very good working machine immediately ready for production.

Condition: used, bore capacity in steel (diameter) 30 mm throat 315 mm bore stroke 170 mm taper MK 4 MK table-size 650 x 350 mm feeds 0,07 - 0,15 - 0,25 - 0,35 mm/U turning speeds 80 - 1800 U/min total power requirement 2,2 KW weight of the machine ca. 0,9 t dimensions 1,2 x 0,8 x 2,3 m Lodovkizyjpfx Af Esru Pillar drilling machine with: Feed Left-right rotation Coolant system

Condition: good (used), T-slot clamping plate for a radial drilling machine Dimensions L x W x H: 2500 x 1130 x 260 mm Lodsv N Et Nspfx Af Ejru T-slot width: 20 mm Number of T-slots: 3 T-slots not continuous across the entire length Weight: approx. 2 t Siegfried Volz Machine Tools Rüschebrinkstr. 151 - 153 DE - 44143 Dortmund - Wambel

Condition: used, Year of construction: 1986, machine/vehicle number: 8240, Bandanzahl : 1 max. Arbeitsbreite : 1100 mm max. Arbeitshöhe : 150 mm 1. Band : Kombiaggregat Ausführung 1. Walze : Stahlkontaktwalze Schleifschuh 1. Aggregat : starr, höhenverstellbar Schleifbandlänge 1. Aggregat : 2500 mm Schleifbandbreite 1. Aggregat : 1150 mm Antrieb Aggregat 1 : 15 kW Lrjdpfxswaukde Af Eju Steuerung : Handbedienpult Elek./pneu. Bandoszilation : Ja Einlasshöhe : variabel (unterer Tisch verfährt) Tischhub : elektro-motorisch Tischanzeige : digital Betriebsdruck : 7 bar Arbeitshöhe bzw. Aufgabetischhöhe : 850 mm Beschreibung : neuer Teppich Gewicht ca. : 1700 kg

Condition: used, Year of construction: 2017, controller model: , _____ Description: Year of manuf. : 2017 Material thickness : 100 mm Material size : 1350 mm Working area Maximum clear passage width:1350 mm Sheet thickness range:0.3 to 100 mm Stepless adjustable feed speed:0.5 to 10 m/min :Electric sheet thickness adjustment :Electric tool positioning Power supply Operating Voltage:Three-phase 400 V with neutral and protective earth (3 x 400 V/N/PE) Frequency:50 Hz Power Consumption:36 kW Lrsdpsw Ubt Hefx Af Eou Supply Line Fuse:63 A Supply Cable Cross-Section:16 mm² Control Voltage:24 V DC Short-Circuit Current Rating:10 kA Machine Weight:approx. 3,500 kg Dimensions (W/D/H):approx. 2,120 x 3,093 x 2,400 mm Aggregates / Units / Stations Contact Roller Unit:Adjustable working speed from 3 to 18 m/s Multi-Rotation Brush R2:Equipped with 3 brush heads, each with 2 brushes Conveyor Belt Cleaning:Dry cleaning system Vacuum System:Integrated vacuum with a 5.5 kW blower Workpiece Thickness Measurement:Automatic height detection Extraction System:No extraction unit included

Condition: ready for operation (used), machine/vehicle number: 331/43, drilling capacity: 3 mm throat: 100 mm Lrodpfx Afjfnbgqo Eeu spindle turning speed range: 6300/9000 rpm engine: 380 V, 0,18 kW space needed: 470 x 250 x 520 mm weight: 39 kg

Condition: good (used), I sell a set of hydraulic tools for rescue Weber- Hydraulic. - Hydraulic shears. Lsdpfx Afjvgnr Ae Ejru - Arm spreader. - Hydraulic pump.

Condition: used, bore capacity in steel (diameter) 40 mm Lredpfx Aom Rlavjf Esu throat 360 mm bore stroke 135 mm taper MK 4 MK table-size 630 mm feeds ja mm/U turning speeds 120 - 1120 U/min total power requirement 2,4 KW weight of the machine ca. 0,9 t dimensions 1,2 x 0,8 x 2,75 m

Condition: excellent (used), I sell a set of hydraulic tools for rescue Weber- Hydraulic. - Hydraulic shears. - Arm spreader. - Hydraulic pump. Lrsdpfx Asvgnttjf Eou
