Used Turning Insert for sale (9,575)

Condition: like new (used), Year of construction: 2020, operating hours: 4,300 h, functionality: fully functional, spindle motor power: 15,000 W, spindle speed (min.): 6,000 rpm, spindle speed (max.): 6,000 rpm, rotational speed (max.): 6,000 rpm, feed length X-axis: 135 mm, feed length Z-axis: 530 mm, bar passage: 51 mm, feed rate X-axis: 30 m/min, feed rate Z-axis: 40 m/min, chuck outer diameter: 152 mm, bar diameter (max.): 51 mm, overall weight: 8,100 kg, Equipment: documentation/manual, We offer this Doosan PUMA TT1300SYYB CNC turning and milling center, in like-new condition, manufactured in 2020. Manufacturer: Doosan Model: PUMA TT1300SYYB Year of manufacture: 2020 Condition: Like new Category ID: 1128 Type ID: 2239 Machine type: CNC turning and milling center If you have any questions or require further information, please do not hesitate to send us a message or call us. For sale: a nearly new Doosan PUMA TT1300SYYB from February 2020, equipped with an LNS SPRINT 565 S2 automatic bar feeder with motorized chucks and only 3,800 cutting hours. It is a high-end, multitasking CNC lathe with a double spindle and double motorized turret, featuring an independent Y-axis in both positions. A unique machine in its category, designed for complete machining in a single setup. -Synchronized double spindle -Double turret with motorized tools -Upper and lower Y-axis (SYYB configuration) -Simultaneous machining of both sides -Drastic reduction in cycle times -High precision and thermal stability -Spindle speed up to 6,000 rpm -Bar capacity up to Ø51 mm -2 Hainbuch chucks Special price: 165,000 EUR, WORKING HOURS: ONLY 3,800 CUTTING HOURS. Available for inspection and test run. Simultaneous machining with two turrets. Automatic transfer between the main and sub-spindle. Possibility of finishing the complete part in a single operation. Bljdpsyryymjfx Amysk Ideal for use with a bar feeder. Significant reduction in cycle times compared to a single-spindle lathe.

Condition: good (used), Year of construction: 2005, Parts shown by hand not come. Bodpfsznmbujx Amyslk

Condition: excellent (used), Year of construction: 2015, machine/vehicle number: 203836, clamping force: 800 kN, screw diameter: 30 mm, displacement volume: 99 cm³, injection weight: 90 g, total length: 3,800 mm, total width: 2,100 mm, total height: 3,100 mm, overall weight: 8,500 kg, type of input current: three-phase, input frequency: 50 Hz, input voltage: 400 V, For sale is a vertical injection molding machine from the manufacturer ENGEL, model Insert 330V/80 Rotary (800 kN / 80t). Technical data: Machine type: Insert 330V/80 Rotary Year of manufacture: 2015 Machine number: 203836 Design/Construction: Vertical unit with rotary table Control system: ENGEL CC300 Drive technology: Ecodrive CLAMPING UNIT: Clamping force: kN 800 (80 t) Clamping unit design: Vertical / column-free or barrier-free Table design: 2-station rotary table INJECTION UNIT: Injection unit type: Type 330 Screw diameter: 30 mm Theoretical displacement volume: 99 cm³ Injection part weight: 90 g/shot Nozzle type: Needle-close nozzle Injection unit installation position: Vertical, from above HYDRAULICS, DRIVE, CONTROL CABINET & INTERFACES: Drive concept: ENGEL Ecodrive (energy-optimized) Automation interface: Euromap 67.1 Safety systems: Light curtain / protective enclosure for the work area MACHINE DIMENSIONS, TRANSPORT, AND WEIGHTS Installation dimensions (basic machine): 3,800 x 2,100 x 3,400 Transport dimensions: 3,800 x 2,100 x 3,100 mm Required hall height: 3,800 mm Blodpjznl Erefx Amyjk Total weight: 8,500 kg Upon request, transport and loading can be arranged throughout Europe for an additional fee. Prices plus VAT. Inspection possible by appointment. Contact us; our team will be happy to assist you. Trade-in or exchange possible! Machine purchase/sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Gjbn N Ay Dowza Dxogoil Do you need a high-quality, yet affordable, metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: excellent (used), Year of construction: 2006, For sale: A reliable vertical CNC machining center Yamazaki Mazak Nexus VCN-510C – a high-end production machine from the renowned Japanese manufacturer MAZAK, known for its precision, durability, and stable operation in industrial manufacturing environments. Bledpeyha Ivjfx Amyok The VCN-510C is ideally suited for machining steel, aluminum, and workpieces requiring high accuracy and repeatability. Thanks to the MAZATROL 640M control, the machine offers intuitive operation and rapid production setup. Technical specifications: Year of manufacture: 2006 Control: MAZATROL 640M X-axis travel: 1,050 mm Y-axis travel: 510 mm Z-axis travel: 510 mm T-slot table Automatic tool changer (ATC) Central lubrication Electrical cabinet Weight: 7,100 kg Low operating hours

Condition: ready for operation (used), Year of construction: 2022, operating hours: 3,728 h, functionality: fully functional, machine/vehicle number: 0040001634C, turning length: 500 mm, turning diameter: 240 mm, spindle motor power: 1,400 W, spindle speed (min.): 5,000 rpm, spindle speed (max.): 6,000 rpm, spindle bore: 170 mm, travel distance X-axis: 210 mm, travel distance Y-axis: 525 mm, travel distance Z-axis: 525 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 22 m/min, rapid traverse Z-axis: 30 m/min, torque: 171,192 Nm, feed force X-axis: 3 N, The DMG MORI CTX Alpha 500 was manufactured in 2022. This versatile turning center is equipped with a Siemens controller and LNZ Quick load servo 80S2. Weight: 4,300 kg. Please contact us for more information about this machine. Bsdeyz S T Sspfx Amyslk

Condition: used, Year of construction: 1989, functionality: fully functional, machine/vehicle number: 119, spindle motor power: 5 W, turning length: 160 mm, spindle speed (max.): 6,000 rpm, spindle speed (min.): 99 rpm, turning diameter: 16 mm, overall weight: 2,300 kg, type of input current: three-phase, bar passage: 16 mm, total width: 1,340 mm, total length: 1,850 mm, total height: 1,685 mm, input voltage: 380 V, number of driven tool stations in tool turret 1: 6, number of driven tool stations in tool turret 2: 6, Equipment: documentation/manual, rotational speed infinitely variable, I am offering my lathe for sale, complete with the accessories shown in the pictures. Bjdsy Udcfjpfx Amyolk It includes a bar feeder and a chip conveyor. The machine is controlled by a Yasnac CNC system. The machine has two turrets, allowing for multi-axis and multi-group control.

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, turning length: 850 mm, turning diameter over cross slide: 410 mm, turning diameter: 410 mm, spindle motor power: 28,000 W, spindle speed (max.): 5,000 rpm, spindle bore: 76 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 850 mm, rapid traverse X-axis: 30 m/min, spindle diameter: 315 mm, CNC Siemens 840D WORKING AREA: Maximum rotating diameter: mm 700 Maximum machining diameter: mm 410 X-axis travel: mm 300 Z-axis travel: mm 850 SPINDLE: Spindle nose: mm 170 h5 Bar capacity: mm 76 Chuck diameter: mm 315 Power (40 / 100% ED): kW 28 / 20 Maximum torque (40 / 100% ED): Nm 315 / 225 Maximum spindle speed: rpm 5.000 Peak torque speed: rpm 900 FEED RATES: Rapid traverse X-axis: m/min 30 Rapid traverse Z-axis: m/min 30 Indexing accuracy: 0.025° TOOL TURRET: Number of driven tool stations: 12 VDI 40 DIN 69880 tool shank diameter: mm 40 Power (40% ED): kW 12 Maximum torque (40% ED): Nm 36 Bedpfx Amszqanajyolk Maximum speed: rpm 4.000 TAILSTOCK: Tailstock travel with automatic movement: mm 800 Tailstock taper: MT 5 Maximum tailstock force: daN 800 Machine weight: kg 6.100 Machine equipped with: • Tool presetting system • Set of static tool holders • No. 1 axial driven tool holder • No. 1 radial driven tool holder • Autoblok self-centering chuck Ø 315 mm • High-pressure pump • Operation and maintenance manuals and CE declaration

Condition: ready for operation (used), CTX 320 2004 With many tools Hainbuch collet set, 6 Live tools Bljdpfezqakusx Amyok 6000 RPM Bar 68,5mm center distance 600 turning over bed, slide: 400, 300 Travel Z,X 450,210 Turret 12 station 5000RPM Weight 4500kb 3905x1553x1830 Ask for film

Condition: excellent (used), Year of construction: 2004, functionality: fully functional, CNC: GE Fanuc Series 18i-TB MAIN SPINDLE CAPACITY Max. workable diameter from bar stock: 83 mm Max. workable diameter from chuck: 200 mm Max. workable length: 300 mm Max. turning diameter: 200 mm Distance between the two spindle centers: 690 mm TAILSTOCK CAPACITY Max. workable diameter from bar stock: 45 mm Max. workable diameter from chuck: 160 mm Max. workable length: 200 mm Max. turning diameter: 160 mm Distance between the two spindle centers: 690 mm MAIN SPINDLE Variable speed range: 100 - 4000 rpm Spindle nose: ASA 8'' Spindle bore: 80 mm Bearing inner diameter: 110 mm Self-centering diameter: 210 mm Collet chuck: DIN 6343 Motor power: 22-26 kW (50%) TAILSTOCK Variable speed range: 100 - 4000 rpm Spindle nose: ASA 5'' Spindle bore: 56 Bearing inner diameter: 90 mm Self-centering diameter: 165 mm Collet chuck: DIN 6343 Motor power: 5.7-7.5 kW (50%) TURRET Number of positions: 12 Type: bidirectional Outer tool shank: 20 x 20 Boring tool shank: Ø 32 Indexing time (1 position): 0.2 sec POWERFUL TOOLS Number of positions: 12 Variable speed range: 100-3000 rpm Motor power: 1.1 - 3.7 kW (25%) MAIN SPINDLE AXES X-axis stroke: 160 mm Z-axis stroke: 390 mm X-axis rapid traverse: 12 m/min Y-axis rapid traverse: 6 m/min TAILSTOCK AXES X-axis stroke: 158 mm Z-axis stroke: 240 mm Y-axis stroke: /// X-axis rapid traverse: 12 m/min Z-axis rapid traverse: 20 m/min Y-axis rapid traverse: /// C-AXIS - CONTROLLED Type: CS (direct) Minimum programmable value: 0.001° Rapid traverse speed: 80 rpm COOLANT Tank capacity: 180 lt Pump flow rate: 150 lt/min Pump motor power: 0.75 kW DIMENSIONS - WEIGHT Overall dimensions with chip conveyor: 4107x2128x2204h mm Center height of the main spindle: 1050 mm Bodpfexhciuox Amyjlk Weight with chip conveyor: 7200 kg

Condition: excellent (used), Year of construction: 1959, Schaublin 102 VM In very good condition. Includes accessories as shown in the pictures. Blodpfozp Uz Sex Amyok Transportation can be arranged.

Condition: used, Year of construction: 2015, Control SYSTEM TX 8i-p spindle headstock ? bar passage 20 mm z-travel 205/80 mm max. turning speeds 10.000 min/-1 number of tool places 8 Pos. max. turning speeds 12.000 min/-1 x-travel 120 mm y-travel -40 / +25 mm z-travel 250 mm number of tool places 8 Pos. max. turning speeds 12.000 min/-1 x-travel 120 mm y-travel -20 / +40 mm z-travel 250 mm spindle passage 18 mm max. turning speeds 10.000 min/-1 x-travel 100 mm Blsdpfx Aszndtnemyjk z-travel 262 mm rated capacity 35 kW connected load 24 kVA In our assessment, the machine is in good used condition and can be inspected under power by appointment. Accessories, tools, and clamping devices shown are included in the scope of delivery only if specified in the additional information. Subject to change, errors in technical data and specifications, and prior sale.

Condition: good (used), FANUC 31i-B control system C-axis on both spindles Milling drive on the upper turret Milling drive on the lower turret B-axis on the upper turret: +/- 91° Y-axis on the upper turret: +/- 40 mm Y-axis on the lower turret: +/- 32.5 mm Larger main spindle: A5 Bar diameter: 51 mm Larger counter spindle: A5 Bar diameter: 51 mm Polygon turning function Unloading with gripper hand on the upper turret Intelligent handwheel Bljdezncrcspfx Amyek AME inclined bed filter system 10-70 bar

Condition: good (used), CMZ brand CNC lathe, TX66 Y2 Quattro model, year 2012, with powered tooling on both turrets, Y-axis... Bodpfx Amezcu Hioyolk

Condition: ready for operation (used), Year of construction: 1980, A total of four custom-built Wheelabrator turnover molding machines and one small prototype are available. Max. compressed air: 8bar. These are custom-built systems with the corresponding prototype. The maximum product size that can be produced on the four main machines is shown in the image. An on-site inspection is possible. Bsdpfjzp Rgwsx Amyjlk

Condition: good (used), Year of construction: 2007, Ref. no.: 18597 Manufacturer: ENGEL Type: insert 200 H/70 CC 200 Year of construction: 2007 Bljdpfx Aey Au I Ujmysk Clamping unit Clamping force: 70 ton Opening stroke: 305 mm Injection unit Screw diameter: 25 mm Injection volume: 69 cm³ Shot weight: 62 g Injection pressure: 2381 bar Measurements and weight Dimensions: 4,0 x 1,8 x 2,5 m Machine weight: 5600 kg Further information: The ENGEL INSERT 200H/70 is a professional vertical injection moulding machine specially designed for insert molding and precision technical plastic applications. Built with ENGEL’s compact and robust machine concept, this model has been widely used for many years in the automotive, electronics, cable technology and technical plastics industries. One of the major advantages of this machine is its rotary table system. This design allows the operator to load inserts on one side while production continues on the other side. As a result, cycle times are reduced and production becomes safer and more efficient. This system is especially advantageous for manufacturing metal insert parts, connectors, cable components and precision technical products. Compared to conventional horizontal injection moulding machines, the ENGEL INSERT series offers a much more ergonomic and controlled process for insert placement. Thanks to the vertical clamping system, inserts remain stable inside the mould, enabling highly precise production results. The ENGEL control system used on this machine is known for stable process management and reliable operation. Its user-friendly interface allows easy handling in daily production. The machine has approximately 51,944 operating hours and was reportedly in running condition until removed from production. The overall condition of the machine is clean and well maintained. The electrical cabinet is tidy and the mechanical components appear to be in good condition. The ENGEL INSERT series is particularly suitable for: * insert molding applications * metal/plastic combination parts * electronic component production * connector and cable technology * technical plastic parts * precision industrial products With its robust mechanical construction, compact design and professional production capabilities, the ENGEL INSERT 200H/70 represents a reliable and long-lasting production solution for technical plastic manufacturers.

Condition: used, Year of construction: 2018, operating hours: 22,293 h, functionality: fully functional, machine/vehicle number: A320A/1497, turning length: 200 mm, spindle speed (max.): 10,000 rpm, turning diameter: 20 mm, overall weight: 2,200 kg, rotational speed (max.): 10,000 rpm, type of input current: three-phase, working length: 200 mm, input voltage: 200 V, power: 7.1 kW (9.65 HP), travel distance Z-axis: 200 mm, A20-3F7 (2018-02) - with pump We have a used Citizen A20-3F7 machine for sale, manufactured in 2018- Swiss-type automatic lathe Maximum workpiece diameter is 20mm, length 200mm (in GB mode). Maximum main spindle speed is 10,000 rpm. Maximum rear spindle speed is 8,000 rpm. The machine includes: - chip conveyor; - workpiece conveyor; - bar feeder; - oil mist extractor; Bsdpfx Aezp Emljmyjlk - high-pressure pump (70 bar);

Condition: like new (used), functionality: fully functional, * Mori Seiki NMV 5000 DCG. * Year: 2008. * Equipment value, including zero points, chucks, BT taper chucks, turning tool chucks, and pallets: 50,000–55,000 euros. * 5-axis continuous machining center. * High-precision Heidenhain linear guides. * Interface for connecting a pallet loader and robot. * Table with turning function. * Independent high-pressure cooling system at 40 bar. * Spindle oil cooling system. * BT 40 tool magazine. * Magazine capacity: 60 tools. * Maximum tool diameter: 125 mm. * Maximum tool length: 300 mm. * Maximum tool weight: 8 kg. * Travel on the X-axis: 730 mm. * Travel on the Y-axis: 510 mm. * Travel on the Z-axis: 510 mm. * Table with turning function. * Maximum workpiece diameter in turning mode: 450 mm. * Maximum turning diameter in turning mode: 700 mm. * Mori Seiki Mapps 4 conversational control. * Spindle speed: 20,000 rpm. * Spindle motor power: 18.5 / 15 kW. * Maximum cutting torque: 135 Nm. * C-axis table: 360,000 x 0.001 * B-axis rotation: +160 / -180 * Rapid traverse X/Y/Z: 50 / 50 / 50 m/min * Renishaw tool measurement system. * Renishaw workpiece measurement system. * Automatic zero-point adjustment. * Automatic cutting power control. * Program memory: 2 MB. * Dynamic zero-point correction (up to 8 points). * Pre-check of tool availability. * Custom macro (999 variables). * Rear chip conveyor. * Tool life management (128 x 2 groups). * Electrical transformer. Blodozp Emfjpfx Amyjk * Documentation, parts list, electrical diagrams, programming, and instruction manual. * Weight: 13,500 kg. * Machine is currently in operation. * Available for inspection by an authorized Mori Seiki technician. * Immediate delivery, subject to immediate sale.

Condition: good (used), Year of construction: 2008, functionality: fully functional, Traub Stamag DNH42/3000, year of manufacture 2008, DNH42, bar feeder, loading magazine, loader. Bsdpfx Amezp Ec Heyelk

Condition: used, Drum turning Rotator, Tank turning Rotator, Used Machine Bodszmynlepfx Amyslk Maximum Tank Diameter: 2000 mm Distance Between Rollers: 1000 mm Load Capacity: 8 tonnes Overall Dimensions: Width: 2650 mm Depth: 1520 mm Height: 750 mm Weight: 1800 kg

Condition: ready for operation (used), Year of construction: 1992, spindle speed (max.): 3,600 rpm, bar diameter (max.): 60 mm, total width: 2,000 mm, total height: 1,900 mm, travel distance X-axis: 180 mm, overall weight: 4,300 kg, controller manufacturer: MAZATROL, controller model: T32-2, product length (max.): 2,700 mm, number of axes: 2, Multi-spindle turning machine manufactured in 1992. This Mazak Quick Turn 18 NSP features a maximum turning diameter of 260 mm and a turning length of 500 mm. It includes a tool turret with 8-fold / 16 positions and a spindle speed range of 36 - 3,600 rpm. If you are looking to get high-quality turning capabilities, consider the Mazak Quick Turn 18 NSP machine we have for sale. Contact us for further details regarding this machine. - Control: MAZATROL T32-2- Max. Turning Diameter: 260 mm- Max. Turning Length: 500 mm- Speed Range Main Spindle: 36 - 3,600 rpm- Speed Range Sub-Spindle: 36 - 3,600 rpm- Travel Z-Axis: 510 mm- Travel X-Axis: 180 mm- Spindle Bore: Ø 70 mm- Bar Loader Length: 3,000 mm- Collet Chuck Holder: For 185 E collets- Collet Chuck Range (Main Spindle): Ø 4 - 60 mm- Sub-Spindle: 3-jaw chuck, Ø 125 mm to Ø 70 mm- Tool Turret: 8-fold / 16 positions- Tool Eye: Measuring probe for tool measurement in working area- Main Spindle Chuck: KITAGAWA 3-jaw chuck Ø 254 mm- Coolant System: Complete coolant equipment- Foot Switch: 2 double foot switches for opening/closing both chucks- Machine Weight: 4,300 kg- Machine Dimensions (L x W x H): 2.7 x 2.0 x 1.9 m Optional - Drip pan (2500 x 2700 mm), IRCO 3000 mm bar loader Technical Specification Counter Spindle Yes Blodpjzarf Rsfx Amysk

Condition: excellent (used), Year of construction: 2006, Ref:11128 . 2006 Longford Inserter-Folder Primarily for the production of greetings cards, but can produce other inserted products at high speed. Comprising; Upper C700 Friction pile feeder for insert, top-loading, bottom feeding. Lower C700 Friction pile feeder for main product, top-loading, bottom feeding. Feeders can be configured in either a single or batch feed mode. Easily integrate with OEM equipment. Heavy duty scoring roller shafts. Robatech IK 40/4 glue control unit. PVA cold gluing system with single head. Bodpfx Amjzmydaeyelk Longford digital control unit Automatic counter with batch marking Belt folding element Hydraulic variable speed Stream delivery conveyor Including accessories, tools and manuals. Specification: Sheet size, Max: 355 x 254 mm Folds to: 177 x 254 mm Min: 102 x 102 mm Folds to: 38 x 76 mm Stock weight : 100 – 400 gsm2 Belt speed : up to 175m/min.

Condition: good (used), Schmedt PraKant Turning-in machine Bljdszmu Nwjpfx Amysk The PräKant is a turning-in machine designed to turn in and press down the edges during the production of book covers and other products. Weight: 150 kg Power supply: 400 V Flexible speed control.

Condition: used, Year of construction: 2023, operating hours: 3,700 h, functionality: unexamined, machine/vehicle number: 22260005, travel distance X-axis: 255 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 382 mm, Equipment: documentation/manual, CNC lathe SCHUSTER VD20 with automation and peripherals Technical data Working area Maximum turning diameter: 250 mm Maximum turning length: 250 mm Number of spindles: 2 Number of tool positions: 12 Control system: SIEMENS Sinumerik 840D SL Year of manufacture: 2023 Serial number: 22260005 Recorded operating hours: 3,635 Electrical connection: 3P~ / N / PE (TN-C-S system) Frequency: 50 Hz Operating voltage: 400 V Control voltage: 24 V DC Total weight: approx. 14,000 kg Travel distances / feeds Z-axis: Travel distance 370 mm, rapid traverse 50 m/min, maximum acceleration 8 m/s², feed force 9,000 N X-axis: Travel distance 250 mm, rapid traverse 30 m/min, maximum acceleration 8 m/s², feed force 9,000 N Y-axis (optional): Travel distance ±40 mm, rapid traverse 15 m/min, maximum acceleration 5 m/s², feed force 15,000 N Bledpfx Amezdtqnjyek Turning spindles Maximum speed: up to 4,500 rpm Nominal speed: 2,500 rpm Spindle nose: DIN 55026-A6 Internal diameter of spindle bearing: Ø120 mm Spindle power (100% duty cycle, S1): 26 kW Spindle torque (100% duty cycle): 100 Nm Equipment / Features The system includes a KUKA handheld control unit, a KNOLL chip conveyor type 280 S-1/160, a DELTATHERM cooling unit type RKV 5.5, a KUKA handling robot of the Industrial Robot Cybertec-2 Series with a corresponding KUKA robot controller type KR C5 Dualcap AC, a KNOLL coolant filter unit type KF 150/950, and an air filter unit type AFS 1100.

Condition: good (used), Year of construction: 2007, functionality: fully functional, turning diameter: 545 mm, spindle speed (max.): 12,000 rpm, travel distance X-axis: 410 mm, travel distance Y-axis: 140 mm, travel distance Z-axis: 570 mm, Equipment: chip conveyor, The MAZAK Integrex 100-IV is a compact and highly precise CNC turning and milling center designed for complete machining of complex workpieces in a single setup. Thanks to the combination of turning and milling functions, as well as the integrated B and Y axes, the machine is particularly suitable for demanding precision parts in the medical technology, mechanical engineering, and precision engineering industries. The machine was manufactured in 2007 and is equipped with the powerful MAZATROL Matrix control. This enables both dialog-oriented and ISO programming and offers modern functions for efficient and productive manufacturing. Bedpfx Aezpyvhjmyjlk Key technical data: The travels are 410 mm in the X-axis, 140 mm in the Y-axis (±70 mm), and 570 mm in the Z-axis. The B-axis has a swivel range of 225°, enabling complex 5-axis machining. The C-axis of the main spindle operates with a high positioning accuracy of 0.001°. The maximum turning and swing diameter is 545 mm each. The main spindle reaches speeds of up to 6,000 rpm with a power of approximately 11 kW, which enables dynamic and precise turning operations. The integrated milling spindle operates with speeds of up to 12,000 rpm with a power of approximately 5.5 kW and is ideally suited for milling, drilling, and threading operations. The machine features a tool changer (available) with a maximum tool length of 210 mm and a KM tool holder, which ensures high rigidity and fast tool changes. Equipment: The equipment includes: • Chip conveyor • Tool measurement system "Tool Eye" With a machine weight of approximately 5,040 kg, the Integrex 100-IV impresses with its compact design, high precision, and flexibility – ideal for economical complete machining in modern production environments. You are in the best hands with us – professional, reliable, and with a passion for machines! Necoyir I Rs Eanhd Held PS CNC Service Germany GmbH & Co. KG All information is subject to change without notice.

Condition: excellent (used), Year of construction: 2003, functionality: fully functional, turning length: 1,530 mm, turning diameter over cross slide: 280 mm, turning diameter: 280 mm, spindle speed (max.): 4,000 rpm, spindle bore: 88 mm, travel distance X-axis: 565 mm, travel distance Y-axis: 230 mm, travel distance Z-axis: 1,599 mm, rapid traverse X-axis: 24 m/min, rapid traverse Y-axis: 16 m/min, spindle nose: 8, spindle diameter: 210 mm, Equipment: documentation/manual, CNC MSG 501 MAPPS II WORKING AREA Swing over bed: mm 910 Swing over cross slide: mm 850 Maximum distance between spindle noses: mm 1.828 Maximum turning diameter: mm 280 Maximum turning length: mm 1.530 Bar capacity – Main spindle: mm 75 Bar capacity – Sub-spindle: mm 65 AXES TRAVELS Milling head X-axis travel: mm 565 Milling head Y-axis travel: mm ±115 Milling head Z-axis travel: mm 1.599 Turret X-axis travel: mm 155 Turret Z-axis travel: mm 1.479 MAIN SPINDLE Maximum spindle speed: rpm 4.000 Spindle nose: JIS A2-8 Spindle bore: mm 88 Minimum spindle indexing angle: 0.001° Spindle torque (continuous / 30 min): Nm 490 / 583 SUB-SPINDLE Maximum spindle speed: rpm 4.500 Spindle nose: JIS A2-6 Spindle bore: mm 73 Minimum spindle indexing angle: 0.001° Spindle torque (continuous / 30 min): Nm 349 / 368 MILLING HEAD Minimum B-axis indexing angle: 0.001° Maximum spindle speed: rpm 8.000 Spindle taper: Capto C6 Tool magazine capacity: 40 tools Maximum tool diameter (without adjacent tool): mm 90 (125) Maximum tool length: mm 400 Maximum tool weight: kg 8 TOOL TURRET Number of tool stations: 12 tools Tool shank size: mm 25 Maximum boring bar diameter: mm 40 Driven tools speed range: rpm 4,000 FEED RATES Rapid traverse X-axis: mm/min 24,000 Rapid traverse Y-axis: mm/min 16.000 Rapid traverse Z-axis: mm/min 24.000 Rapid traverse B-axis: min⁻¹ 27 Rapid traverse C-axis: min⁻¹ 300 Rapid traverse turret X-axis: mm/min 20.000 Rapid traverse turret Z-axis: mm/min 24.000 MACHINE DIMENSIONS Machine height: mm 2.735 Floor space required: mm 5.130 × 3.194 Machine weight: kg 14.800 Machine equipped with: Bedozpybqjpfx Amyolk • Set of static and driven tool holders • Several Capto C6 tool holders • Ø 210 mm manual three-jaw chuck for the main spindle • Ø 210 mm manual three-jaw chuck for the sub-spindle • Instruction manuals and CE Declaration of Conformity
