Used Plasma Bevel for sale (997)

Year of construction: 2007, condition: used, Pulsed plasma nitriding system, manufacturer PLATEG Plasma Technik Grün, type PulsPlasma PP 800, 2000 x 2900, mono with tandem preparation, system no. A 5811, with 1 plasma generator, type PP 800/160, no. AN 7491, year of manufacture 2006/2007, 600 V output voltage, 800 A pulse current, 480 kVA pulsed power, 190 kW connected load, process control type Stange 510, stainless steel vacuum chamber Ø 2000 mm (usable volume 1800 mm), height 2900 mm (usable height 2200 mm), wall thickness 10 mm, batch weight 7,500 kg, process temperature max. 600°C, vacuum pump by Leybold, 13 kW, 2,000 m³/h, DN 160, with pressure sensor and manometer, gas supply, cooling water supply with internal recirculator, overall dimensions: 7,840 mm x 3,470 mm x approx. 7,400 mm height, with control cabinet including 2 cooling units. Ncodpfxjyazhze Ahvep

Condition: new, Year of construction: 2025, -Tfon Bevel Wizard® Linear. -Precision Beveling for Linear & Non-Linear Applications. -The TFON Bevel Wizard® Linear is a high-performance beveling solution designed to deliver exceptional accuracy on both straight and contoured sheet edges. Engineered with flexibility at its core, it features an advanced Trace Tracking System that automatically adjusts to variations in material thickness and geometry—ensuring precise and consistent edge processing even for complex parts. -Key Features 🔹 Advanced Trace Tracking System: Intelligently detects and adapts to diverse edge shapes and contours in real time. 🔹 Wide Beveling Range: Adjustable bevel angles from -30° to +80°, ideal for a broad range of applications. - Optimized for Large Workpieces Capable of processing materials up to 12,000 mm in length and 100 mm in thickness. - Industrial-Grade Durability: Built to last with a solid 10,000 kg frame for long-term reliability. 🔹 Superior Surface Finish: Delivers a high-quality finish with a consistent Emery Band Rotation Speed of 30 m/min and a Ø135 mm contact wheel. -Technical Specifications: Beveling Angle Range: -30° to +80° -Material Thickness: 4 – 100 mm -Minimum Material Width: 250 mm Minimum Material Length: 250 mm Maximum Material Length: 12,000 mm Part Feed Speed: 1.5 – 5 m/min Part Completion Speed: 3 meters/day Maximum Part Indentation: Ø400 mm Emery Band Rotation Speed: 30 m/min Contact Wheel Diameter: Ø135 mm Nodpfx Aert Tpnohvscp Emery Band Drum Diameter: Ø400 mm Machine Weight: 10,000 kg Engineered for precision. Built for performance. Designed for industrial excellence Tfon Bevel Wizard® Linear — Where Accuracy Meets Efficiency.

Year of construction: 2015, condition: ready for operation (used), Two plasma machines Plasma Technology for surface cleaning and pretreatment are available. Vacuum chamber internal dimensions X/Y/Z: 190mm/190mm/320mm, vacuum chamber volume: 11.5l, plasma generator power: 400W, working pressure range: 0.05mbar-0.6mbar, max. process gas prepressure: 2bar, machine dimensions X/Y/Z: approx. 500mm/300mm/600mm. Documentation available. An on site inspection is possible. Ncsdpfxoyrg Hmj Ahvsp

Condition: new, Year of construction: 2024, NEW Plasma Cutting Machine. Dimensions: 3,000 mm x 1,500 mm Max. steel cutting thickness: 22 mm Ncedpfx Astu E Dujhvsp Max. stainless steel cutting thickness: 12 mm Supplied with CAD CAM software. DWG and DXF data transfer via USB and network card. CE certification. ISO 9001, GB/T 19001. 120 A generator. The operational cost is extremely low – only 5.5 kW and compressed air!

Year of construction: 2000, condition: ready for operation (used), A Plasma Finish low-pressure plasma system for surface treatment of workpieces is available. Chamber volume: approx. 15l, internal chamber dimensions X/Y/Z: 250mm/250mm/250mm, plasma frequency: 2.45GHz, plasma type: microwave, power range: 100W-600W, machine dimensions X/Y/Z: approx. 700mm/900mm/1850mm, weight: approx. 300kg. Documentation available. An on-site inspection is possible. Ncodpoxghn Tofx Ahvop

Year of construction: 2018, condition: good (used), functionality: fully functional, Temperature Control Unit plasma plasTemp Primus 90 Stock No.: 503642 Machine/Device Type: Temperature Control Unit Manufacturer: plasma Model: plasTemp Primus 90 Year of Manufacture: 2018 Technical Data for plasTemp Temperature Control Unit Primus 90 / Compact TK-90-9-50: - Circulation medium: Water up to 90°C - Max. external volume at 90°C: 50 liters - Heating capacity: 9.0 kW - via two stainless steel tubular heaters - made of highly corrosion-resistant Incolloy - Cooling capacity: 70 kW at a temperature difference of 80 K between tool inlet and cooling water; minimum pressure difference in cooling water circuit: 3 bar - Pump: Bronze submersible pump, Qmax = 40 l/min, Pmax = 3.8 bar - Motor power: 0.5 kW - Features: • Microprocessor controller, self-optimizing SBC - with digital display of setpoint and actual values for supply temperature Ncjdpfxsx A Swds Ahvjp • Maximum temperature monitoring • Automatic filling system with level monitoring • Output socket for collective fault signal • Acoustic alarm buzzer for alerts • Operating hours counter • Heating control via Solid State Relay (SSR) • Leak monitoring • Leak stop mode (suction operation) • Extraction function for tool change • Manual fill option • Dirt filter • Unit mounted on rubberized castors • Connections: Tool hose connector G 1/2" (14 mm), Cooling water hose connector G3/8" (14 mm) • Electrical connection: CEE plug 16A • Dimensions: L=0.73m, W=0.27m, H=0.58m • Weight: 50 kg Max. operating temperature: 90°C Heating capacity: 9 kW Circulation medium: Water

Year of construction: 2015, condition: good (used), Temperature control unit plasma plasTemp Primus 160 Stock no.: 503636 Machine type/Device type: Temperature control unit Manufacturer: plasma Model: plasTemp Primus 160 Year of manufacture: 2015 Compact K-160-9-24 Nodpsx A Svtjfx Ahvscp Max. operating temperature: 160° Heating capacity: 9 kW Circulation medium: Water

Condition: used, Year of construction: 2011, functionality: fully functional, For sale: 4 temperature control units by Plasma: Medium: water Temperature: max. 90°C Heating capacity: 9 kW Cooling capacity: 30 kW Alarm function Nodpfxex Ek Rdj Ahvocp Flow measurement Automatic water change function PT 100 sensor Interface for TTY 20 mA via 9-pin D-Sub connector

Year of construction: 2012, condition: used, functionality: fully functional, The temperature control unit from Plasma, model "Primus", is available for sale with the following technical specifications: Medium: water, Maximum temperature: 150°C, Heating capacity: 9 kW, Cooling capacity: 30 kW, Special equipment: reinforced pump K6 at 60 l/min up to max. 6 bar. The pressure booster pump is used to increase the cooling water pressure during filling; this is necessary if the system pressure is higher than the cooling water pressure. PT 100 sensor. Interface: On/Off, Alarm, PT 100, Temperature monitoring. Ncjdpfjx Eg T Eox Ahvsp

Year of construction: 2018, condition: good (used), functionality: fully functional, Temperature control unit plasma plasTemp Primus 90 Stock no.: 503644 Machine type / Device type: Temperature control unit Manufacturer: plasma Model: plasTemp Primus 90 Year of manufacture: 2018 Technical data plasTemp temperature control unit Primus 90 / Compact TK-90-9-50 Nedpfx Ajxt Rddjhvscp - Circulating medium: Water up to 90°C - Max. external volume at 90°C: 50 liters - Heating capacity: 9.0 kW, via two stainless steel tubular heaters made of highly corrosion-resistant Incolloy - Cooling capacity: 70 kW at a temperature difference between mold supply and cooling water of 80 K, pressure difference in the cooling water circuit min. 3 bar - Pump: Bronze submersible pump with Qmax = 40 l/min, Pmax = 3.8 bar - Motor power: 0.5 kW - Features: • Self-optimizing microprocessor controller, SBC • Digital display for setpoint and actual value of supply temperature • Maximum temperature monitoring • Automatic filling with level monitoring • Output socket for collective fault signal • Acoustic alarm indicator • Hour meter • Heating control via solid-state relay (SSR) • Leakage monitoring • Leak-stop operation (suction mode) • Draining for tool change • Manual filling • Dirt filter • Unit mounted on rubberized castors • Connections: Mold hose nozzle G 1/2” (14 mm), cooling water hose nozzle G 3/8” (14 mm) • Electrical connection: CEE plug 16A • Dimensions: L=0.73m, W=0.27m, H=0.58m • Weight: 50 kg Max. operating temperature: 90°C Heating capacity: 9 kW Circulating medium: Water

Year of construction: 2018, condition: good (used), functionality: fully functional, Temperature Control Unit plasma plasTemp Primus 90 Stock No.: 503643 Machine type / Device type: Temperature Control Unit Manufacturer: plasma Model: plasTemp Primus 90 Year of manufacture: 2018 Technical Data plasTemp Temperature Control Unit Primus 90 / Compact TK-90-9-50 Ncsdjxt Rc Hjpfx Ahvjp - Circulating medium: Water up to 90°C - Max. external volume at 90°C: 50 liters - Heating power: 9.0 kW - via two stainless steel tubular heaters - made of highly corrosion-resistant Incolloy - Cooling capacity: 70 kW at a temperature difference between mold supply and cooling water of 80 K; pressure difference in the cooling water circuit at least 3 bar - Pump: Bronze submersible pump with Qmax = 40 l/min, Pmax = 3.8 bar - Motor power: 0.5 kW - Equipment includes: • Self-optimizing SBC microprocessor controller • Digital display of set and actual values for supply temperature • Maximum temperature monitoring • Automatic filling system with level monitoring • Output socket for collective fault reporting • Acoustic alarm indicator • Operating hours counter • Heating control via solid state relay (SSR) • Leakage monitoring • Leak-stop operation (suction mode) • Suction for tool change • Manual filling • Dirt filter • Unit mounted on rubberized casters • Connections: Mold hose nozzle G 1/2" (14 mm), Cooling water hose nozzle G 3/8" (14 mm) • Electrical connection: CEE plug 16A • Dimensions: L = 0.73 m, W = 0.27 m, H = 0.58 m • Weight: 50 kg Max. operating temperature: 90°C Heating capacity: 9 kW Circulating medium: Water

Year of construction: 2015, condition: good (used), Temperature control unit plasma plasTemp Primus 160 Stock no.: 503637 Machine/Device type: Temperature control unit Ncodpfxoxt N Hwo Ahvsp Manufacturer: plasma Model: plasTemp Primus 160 Year of manufacture: 2015 Compact K-160-9-24 Max. operating temperature: 160°C Heating capacity: 9 kW Circulating medium: Water/water

Year of construction: 2015, condition: good (used), Temperature control unit plasma plasTemp Primus 160 Stock No.: 503634 Machine/Device type: Temperature control unit Manufacturer: plasma Model: plasTemp Primus 160 Njdpfx Ajxt N D Nshvecp Year of manufacture: 2015 Compact K-160-9-24 Max. operating temperature: 160° Heating capacity: 9 kW Circulating medium: Water

Year of construction: 2016, condition: good (used), Temperature control unit plasma easytemp 95 Stock No.: 503629 Machine/Device type: Temperature control unit Manufacturer: plasma Model: easytemp 95 Year of manufacture: 2016 Max. operating temperature: 95°C Heating capacity: 6 kW Cooling capacity: 40 kW (80 °C flow / 15 °C cooling water) Heat transfer medium: Water/water Nedpfoxt Nnusx Ahvjcp

Year of construction: 2017, condition: good (used), Temperature control unit plasma easytemp 95 Stock No.: 503628 Machine/Device type: Temperature control unit Manufacturer: plasma Model: easytemp 95 Year of manufacture: 2017 Nedpfx Asxt Nm Rohvocp Max. operating temperature: 95°C Heating capacity: 6 kW Cooling capacity: 40 kW (80 °C supply / 15 °C cooling water) Heat transfer medium: Water

Year of construction: 2017, condition: good (used), Temperature control unit plasma easytemp 95 Stock no.: 503627 Machine type/Device type: Temperature control unit Manufacturer: plasma Model: easytemp 95 Ncodext Nm Djpfx Ahvjp Year of manufacture: 2017 Max. operating temperature: 95°C Heating capacity: 6 kW Cooling capacity: 40 kW (80°C supply / 15°C cooling water) Heat transfer medium: Water

Condition: good (used), Year of construction: 2007, max. wheel diameter 500 mm gear width 200-400 mm module 12 turning speeds 0-3250 U/min bracke pressure bis max. 95 Nm inner taper Konus #39 Control Fanuc 16 total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid Njdpfx Ahjvr Hf Eovecp gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Nm.

Condition: used, Year of construction: 1978, functionality: fully functional, wheel diameter: 500 mm, Bevel Gear Milling Machine ZFTKK 500 (spiral bevel) For sale: bevel gear milling machine ZFTKK 500 designed for machining spiral bevel gears. The machine is ideal for gear production applications, offering high precision and consistent repeatability. Technical specifications: Max. gear diameter: 500 mm Max. module: 10 mm Max. face width: 71 mm Ncodpfx Aeyw Rpkohvsp Number of teeth: 6 – 100 Max. ratio: 1:6 Radial adjustment: 30 – 220 mm Bevel angle adjustment: 0 – 90° Cutting speed: 40 – 80 m/min Machine in very good technical condition, ready for operation.

Condition: used, Year of construction: 1997, max. wheel diameter 275 mm gear width 150 mm max. module 6 min. module 1,5 total power requirement 62 kW weight of the machine ca. 12 t dimensions of the machine ca. 4,7x4,4x2,45 m max. wheel diameter mm gear width mm max. module 6 min. module 1.5 max. workpiece diameter 275 mm tooth width max. 5.5 mm spiral angle 0 - 60 ° number of teeth 5 - 120 transmission ratio min. 1:1 transmission ratio max. 1:10 milling drive motor 20 kW workpiece drive 14.5 kW total power requirement 62 kVA weight of the machine ca. 12 t dimensions of the machine ca. 4,7 x 4,387 x 2,45 m Tool spindle (D-axis) - workpiece spindle speed (infinitely) 60 to 350 [...] Tool positioning axis (E-axis) - swivel range 0 to 360° - swivel speed max. 19.5°/s Workpiece spindle (B-axis) - mounting diameter outer cone (1: 4) 140 mm - standard internal cone (1:20) 99.218 mm - workpiece spindle speed max. 300 [...] - workpiece spindle passage 90 mm Workpiece positioning axis (Y-axis) - travel 870 mm Ncodpfx Ajul Etdshvsp - speed max. 4.5 m/min Roller rotation axis (A-axis) - swivel range 315° - swivel speed max. 40°/s Axis intersection (Z-axis) - travel range max. +/- 50 mm - speed max. 0.657 m/min Workpiece swivel axis (C-axis) - swivel range -8.5 to 98° - swivel speed max. 21.5 °/s Milling depth axis (X-axis) - travel from -25 to 640 mm - max. speed 6 m/min Machinen distance (V-axis) - travel 150 mm - speed max. 1.6 m/min

Condition: good (used), Year of construction: 2002, max. wheel diameter 275 mm gear width 55 mm max. module 6 min. module 1 Control 840 C Siemens total power requirement 100 kW Nedpfx Aetumrpshvocp weight of the machine ca. 16,7 t dimensions of the machine ca. 5,2 x 2,3 x 2,4 m m

Condition: good (used), Year of construction: 1972, max. wheel diameter 80 mm gear width 60 mm max. module 3 min. module 0,1 Ncjdpfx Ahjw N S D Sovep total power requirement 0,4 kW weight of the machine ca. 120 kg dimensions of the machine ca. 0,6x0,6x0,75 m

Condition: used, Year of construction: 1998, workpiece diameter with ratio 1:10 300 mm workpiece diameter with ratio 1:1 212 mm max. number of teeth 200 min. number of teeth 6 x-travel 300 mm X - Axis speed 0,1-5.000 mm/sec. y-travel 400 mm Y - Axis speed 0,1-5.000 mm/sec. A - axis -170 / +170 ° control Siemens Sinumerik 840 C total power requirement 38 kW weight of the machine ca. 10 t Nsdpfsul El Tjx Ahvecp dimensions of the machine ca. 4,20 x 2,20 x 2,10 m incl. suction

Condition: good (used), Year of construction: 1978, max. pitch circle 152 mm Number of teeth 8-50 St. weight 7500 kg Technical data – Min./max. foot cone angle: 15° / 55° – Pitch circle diameter: 152 mm – Max. tooth height with 21° finished broach head: 10.7 mm – Max. tooth width at tooth root with 21°: 28 mm – Broach head diameter: 200 mm – Number of teeth range: 8–50 – Max. broach head diameter: .21" Ncodpoxq Hgcsfx Ahvjp Workpiece spindle – Diameter of the tapered bore at the wide end: 99.219 mm – Clamping length at 304.8 mm: 15.478 mm – Taper depth: 15.875 mm – Diameter of the entire spindle bore: 22.225 mm Maximum tooth height: 14.8 mm Maximum tooth width at the root: 28 mm Maximum root angle: 55° Minimum root angle: 15° Milling head speed: 32.6-49.7 m/min Feed speeds (seconds per tooth): 2-3.1 Index range: 8-50 mm Diameter of taper bore at large end: 99 mm Taper per foot: 15.4 mm Depth of taper: 15.8 mm Countersink behind the taper: 57.2 x 77.9 mm Diameter of the bore through the spindle: 22.3 mm Power of the main drive motor: 10 HP Rotation of the main drive motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the hydraulic motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the coolant pump (60 Hz/50 Hz): 3600/3000 rpm Rotation of the chip screw motor (60 Hz/50 Hz): 1800/1500 rpm Footprint (L x W): 320 x 221 cm Total weight of the 726 REVACYCLE machine: approx. 9 t

Condition: ready for operation (used), Year of construction: 1997, functionality: fully functional, wheel diameter: 275 mm, wheel width: 150 mm, travel distance X-axis: 640 mm, travel distance Y-axis: 870 mm, workpiece diameter (max.): 275 mm, TECHNICAL DETAILS Wheel diameter: 275 mm Wheel width: 150 mm Maximum module: 6 Minimum module: 1.5 Workpiece diameter: 275 mm Maximum face width: 5.5 mm Spiral angle: 0 - 60° Number of teeth: 5 - 120 Minimum gear ratio: 1:1 Maximum gear ratio: 1:10 Milling Depth Axis (X-Axis) Travel: -25 to 640 mm Max. traverse speed: 6 m/min Workpiece Positioning Axis (Y-Axis) Travel: 870 mm Max. traverse speed: 4.5 m/min Axis Shift (Z-Axis) Travel range: +/- 50 mm Max. traverse speed: 0.657 m/min Generating Rotation Axis (A-Axis) Swivel range: 315° Max. swivel speed: 40°/s Workpiece Spindle (B-Axis) Max. workpiece spindle speed: 300 rpm Outer cone (1:4) clamping diameter: 140 mm Inner cone (1:20): 99.218 mm Workpiece spindle bore: 90 mm Workpiece Swivel Axis (C-Axis) Swivel range: -8.5 to 98° Max. swivel speed: 21.5°/s Tool Spindle (D-Axis) Spindle speed: 60 to 350 rpm Tool Positioning Axis (E-Axis) Swivel range: 0 to 360° Max. swivel speed: 19.5°/s Machine Distance (V-Axis) Travel: 150 mm Max. traverse speed: 1.6 m/min MACHINE DETAILS Cutter drive motor Power: 20 kW Workpiece drive Power: 14.5 kW Total connected load: 62 kVA Dimensions & Weight Machine weight: approx. 12 t Space requirement: approx. 4,700 x 4,387 x 2,450 mm EQUIPMENT Ncsdpfx Aoywgy Sohvop 13 cutters

Year of construction: 1985, condition: used, machine/vehicle number: 60802 A 17983 J, cutting circuit: bis 400 A space needed: 820 x 1220 x 930 mm weight: 750 kg Ncsdpfxe Sdrfe Ahvop
