Used Pipe Machining Center for sale (68,164)

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, DMG UNIVERSAL MACHINE CENTER DMU80P hi-Dyn Year 2001 X800 Y700 Z 600mm Heidenhain iTNC530 Lsdpfx Asw A Dy Tjg Rjhp NC Rotary Table Ø900x630mm NC B axis Milling Head Spindle 18,000rpm ATC 180 – HSK-A63 Roto Clear window Spindle thru' coolant 40 bar Selling Cheap Cheap sales - 50.000,00 USD

Condition: excellent (used), Manufacturer: Haas Model: VM-6HE Serial number (SN): 1067464 Axes: 3-axis CNC machining center Spindle taper: SK40 Axis travels (X/Y/Z): 1,625 × 812 × 764 mm Table: clamping table Equipment: - chip conveyor Lsdpfx Agsxywiyj Rehp - automatic tool changer (ATC) - tool magazine: 24 positions

Condition: excellent (used), Year of construction: 2005, TECHNICAL DETAILS Travel (X-axis): 750 mm Travel (Z-axis): 800 mm Travel (Y-axis): 850 mm Magazine Positions: 120 Spindle Speed Range: 50–15,000 rpm Spindle Diameter (Front Bearing I.D.): 80 mm Spindle Taper: ISO R297 / Taper No. 40 Tool Holder: MAS I Type P40T Table Pallet Size: 550 × 550 mm Max. Rotary Table Swivel Range: 360° Pallet Height: 750 mm Distances Distance Between Spindle Nose and Table Center: 150–1,000 mm Distance Between Spindle Nose and Table Surface: 50–850 mm Feed Rates Rapid Traverse X-, Y-, Z-Axis: 60,000 mm/min Cutting Feed Rate (X-, Y-, Z-Axis): 0.001–30 mm/min Tool Changer (ATC) Number of Tools: 40 Tool Size (Ø × Length): Ø75 × 470 mm Tool Weight: 8.0 kg Tool Change Time (Tool to Tool): 1.3 s Performance Data Positioning Accuracy (X-, Y-, Z-Axis): ±0.003 mm Repeatability (X-, Y-, Z-Axis): ±0.0015 mm Pallet Load Capacity: 800 kg Thrust Force: 9,800 N MACHINE DETAILS Control: FANUC Series 30i Space Requirements & Weight Footprint: 2,750 × 5,700 mm Machine Weight: 16,000 kg Motors Spindle Drive Motor (15 min rated power): 22 / 18.5 kW Ljdpsxywtljfx Ag Rshp Hydraulic Pump Motor: 3.7 (4) kW Operating Hours Machine Running Hours: 12,976 h Control Powered Hours: 112,997 h

Condition: ready for operation (used), Year of construction: 2003, operating hours: 27,848 h, functionality: fully functional, machine/vehicle number: 1120 000155 3, travel distance X-axis: 800 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain 530, spindle speed (max.): 12,000 rpm, Submitting a bid obligates you to collect the item by the deadline of 16.01.2026! Loading requires a full semi-trailer with a height of 3 m. The consignment consists of 8 packages. TECHNICAL DETAILS Travel X: 800 mm Travel Y: 700 mm Travel Z: 600 mm Spindle speed: 12,000 rpm Tool holder: SK 40 Tool changer: 80 MACHINE DETAILS Control: Heidenhain 530 Ledpfx Ajxywlzsg Rshp Total power requirement: 59 kW Machine weight: approx. 10,600 kg Operating hours Spindle hours: 27,848 h Power-on hours: 89,996 h Note: The machine is sold without lifting beam, clamping device, and chip container.

Condition: used, Year of construction: 2005, Working area: X=2970 mm / Y=1725 mm Axis travel speeds: X=60 Y=45 Z=25 m/min Weight: 3200 kg Storage location: Nattheim Ledpfx Ajw Dcccsg Rshp

Condition: good (used), Year of construction: 2022, spindle speed (min.): 12,000 rpm, Machine type: CNC-BAZ vertical Lhjdjxyt S Dspfx Ag Rop Model: M1 Pro with 4th axis including tailstock Manufacturer: DMGMORI Control: Siemens 828 D Year of manufacture: 2022 Location: Germany Technical data Travel range X-axis approx. 550 mm Y-axis approx. 550 mm Z-axis approx. 510 mm Table size approx. 850 x 650 mm Max. workpiece weight approx. 600 kg Max. speed approx. 12,000 rpm Spindle motor approx. 13/9 KW Number of tool positions approx. 24 Rapid traverse X / Y / Z approx. 24 m/min Holder taper approx. SK40 Footprint L x W x H approx. 3.1 x 2.7 x 2.9 m Machine weight approx. 5,600 kg Equipment Main spindle 12,000 rpm 13/9 kW - Separate electronic handwheel - 24-place chain magazine - SK40 - Coolant tank - IKZ pump 20 bar - Filter for coolant - Bed flushing switchable via M function - Coolant spray gun - Spindle blowing air switchable via M function - Cabin roof - Measuring probe - 4th axis (Errors in the technical data and information excepted)

Condition: ready for operation (used), functionality: fully functional, travel distance X-axis: 1,020 mm, travel distance Y-axis: 762 mm, travel distance Z-axis: 600 mm, Vertical machining center Manufacturer: HURCO Bebmmvyoubcvtjhwslf Lhjdpfx Ajwag Tqog Rsp Type: BMC 40 / 50 Travel: X-axis 1020 mm Y-axis 762 mm Z-axis 600 mm Table load: 1500 kg Table size 1465 x 870 mm Spindle speeds 30 - 4000 RPM 30-station tool changer Tool-to-tool speed 8 sec. 2000 RPM Spindle mount SK 40 Voltage 400 Drive power 11.2 kW Weight 8000 kg Dimensions L x W x H = 3860 x 3315 x 2775 mm

Condition: excellent (used), Manufacturer: Haas Serial number: 1059169 Spindle taper: SK40 Axis travels (X/Y/Z): 1,016 × 660 × 635 mm Additional equipment: chip conveyor Ljdpfoxywh Ajx Ag Rohp clamping table automatic tool changer (ATC) tool magazine: 24 positions

Condition: used, Year of construction: 2008, Used machine Year of manufacture: 2008 Condition: Well-maintained (ready for demonstration at customer site) Equipment and technical specifications: Console machine Working size X: 3,200 mm Working size Y: 1,470 mm Max. travel height Z: 325 mm Milling unit 7939, 6 kW (S6) Including laser pointer Including traveling disc tool changer 7996 with 18 positions Including stationary tool changer on the right side Including 7893 magazine for manual tool change position 8 consoles including 12 vacuum suction cups for 4-field machining 4 pneumatically raisable and lowerable loading aids Including hand control unit Including 3-field safety tread mats Including saw unit for sawing/grooving in X Including C axis 7997 Horizontal drilling units: 6 Lsdpfx Agexymfko Rshp Vertical drilling units: 16 Double drilling spindle in X Heat exchanger for control cabinet cooling CAMPUS software for CNC machining centers Vacuum pump 100 m³/h Weight: approx. 4,450 kg The tools shown in the tool changer are not included in the scope of delivery! Availability: by arrangement Location: Rhineland-Palatinate

Condition: good (used), Year of construction: 2002, Machine is in good condition. Parts shown by hand not come. Lhjdjtwpamepfx Ag Rep

Condition: used, Year of construction: 2007, Travel range: X=4400 Y=2195 Z=440 mm Working area in X=3650 mm Y=1560 mm Clearance: 330 mm Electrospindle SCM Power 2000, high speed milling spindle with 13 kW power Rotary axis Vector (C-axis) Cleaning blower for tool on the milling unit Tool holder HSK 63 F Speed range 600 - 24,000 rpm, stepless via inverter Motor power 8.5 kW Tool holders: 6 pcs Tool changer: Rapid 12 (12 positions) Vacuum pump 250 m³/h / 5.5 kW Max. vacuum: 0.9 bar Reference stop at the sides of the table Drilling unit with 11 spindles (7 vertical / 4 horizontal) Control: NUM Series 1000 User interface: XILOG Plus PC Office hardware WINDOWS XP Professional Total connected load: max. 27.5 kW Weight: 5200 kg Storage location: Nattheim Lhodpfx Agjw Dcb Sj Rep

Condition: used, MORI SEIKI NH 4000 DCG is a Horizontal machining center by MORI SEIKI designed to deliver precision, high accuracy and operational reliability. Working capacities (travels, diameters, workpiece lengths) are not provided. Main technical specifications (spindle speeds, feed rates, power supply, dimensions, weight) are not provided. Accessory and equipment details are not specified. Built to achieve tight tolerances, suitable for automotive, aerospace, medical, watchmaking and machine tool applications Lodpfxexykrbj Ag Rohp

Condition: excellent (used), Year of construction: 2022, DMG MORI CMX 50 U 3+2 Ljdpfx Ajxyi Hwsg Rohp Year 2022 Control: Siemens SlimLine Travels: X-500 mm Y-450 mm Z-400 mm B -5 / +110 ° C 360 ° Spindle max. 15,000 rpm Tool magazine for 60 tools BBT40 Through-spindle coolant 70 Bar Chip conveyor Filter paper High-pressure coolant pumps Workpiece probe, tool probe Quickset (rotary axis calibration) Machine in very good condition, available end of December.

Condition: good (used), Year of construction: 2016, 1 used 5-axis machining center Manufacturer: Haas, Model: UMC-750, Year of manufacture: 01/2016, Read spindle hours: 4,960, Feed hours: 10,247 Lhodpfxjxyinne Ag Rjp Travel X/Y/Z = 762x508x508 mm, 10,000/5,000 Bh Tool holder: SK40, 40-position tool changer, NC SRT table size: 630x500 mm, Maximum table load: 300 kg, Maximum swing diameter: 686 mm,

Condition: used, Year of construction: 2017, Machine Description for 2017 Model: Horizontal Machining Center NHX 5000 Manufacturer: DMG MORI Co. Ltd. Type / Model: NHX 5000_M730UM, Series J-NHX5000-C_C01 Year of Manufacture: 2016 Control System: MAPPS M730UM with CELOS / 21.5" ERGOline Touch Technical Data: • Working Area / Travel: - Travel X / Y / Z: 730 / 730 / 880 mm - Pallet size: 500 × 500 mm - Max. workpiece diameter: 800 mm - Max. workpiece height: 1,000 mm - Distance spindle center to pallet surface: 80 – 810 mm - Distance pallet center to spindle reference plane: 70 – 950 mm - Pallet load: 500 kg [optional 700 kg] - Number of pallets: 2 - Minimum table indexing angle: 1° [optional 0.001° rotary table] • Performance / Spindle Speed / Drive Power: - Spindle type: speedMASTER® motor spindle - Spindle speed range: 35 – 15,000 rpm - Power: 30.7 / 26 / 18.5 kW (15% ED / 30 min / continuous) - Torque: 207 / 95.5 Nm (10% / 100% duty cycle) - Tool taper: BT40 / #40 - Tool magazine capacity: 40 tools [optional: 60 / 120 / 180 / 240] - Max. tool diameter: 70 mm (adjacent) / 170 mm (free) - Max. tool length: 550 mm - Max. tool weight: 12 kg - Tool change time (chip-to-chip): 2.5 s - Rapid traverse X/Y/Z: 60 m/min - Feedrate range: 0 – 60,000 mm/min - Acceleration: 1 G • Weight / Dimensions / Electrical Connection: - Machine weight (incl. coolant tank): approx. 12,000 kg - Installation footprint (W × L): 3,078 × 4,784 mm - Overall height: 2,852 mm - Coolant tank capacity: 800 L - Power supply: 37.3 kVA - Compressed air: 0.5 MPa / 420 L/min Equipment / Accessories: - NC rotary table with 0.001° indexing (DDM optional) - Automatic 2-pallet changer (rotary APC) - Two pallets with threaded holes and hydraulic fixture interface - Chip conveyor (rear discharge) Lhodpfxexnkgno Ag Rjp - Direct measuring systems on X/Y/Z axes - Renishaw OMP60 spindle probe system - Tool breakage monitoring in the magazine - High-pressure coolant interface (70 bar, Knoll) - Coolant/air switching device for through-spindle supply - Rotating inspection window - Coolant gun - Oil mist separator interface Ø200 mm (LTA AC3002 optional) - Automatic loading station door - Signal tower (red/yellow/green/blue) - Portable manual pulse generator (handwheel) - Air filter unit for clean compressed air supply - 45 kVA transformer - Knoll KF110/700 high-pressure coolant unit (7.0 MPa, 31 L/min) - Three hydraulic clamping towers with double-jaw chucks - CELOS system with apps (Production, Accessories, Support, Monitoring, Configuration) - MAPPS M730UM control with 21.5" touchscreen and 15.6" sub-display - SmartKey® operator access management This technical description follows industry standards for horizontal machining center listings, ensuring clarity for prospective buyers on leading platforms such as Machineseeker.

Condition: used, Year of construction: 2005, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, controller manufacturer: HEIDENHAIN, controller model: ITNC 530, CONTROLS .. CNC controls HEIDENHAIN ITNC 530 WORKING RANGE -CUBIC- .. number of processing axes (excl parallel axes): 5 .. X-axis travel: 600 mm .. Y-axis travel: 450 mm .. Z-axis travel: 450 mm .. rotating range B-axis from: -115 ° .. rotating range B-axis up to: 30 ° .. rotating range C-axis from: 0 ° .. rotating range C-axis up to: 360 ° TABLE .. clamping surface diameter: 450 mm .. workpiece load (max): 200 kg SPINDLE / HEAD .. spindle revolutions (max): 20000 /min AXIS DRIVES .. rapid traverse X: 22000 mm/min TOOL MAGAZINE .. number of positions: 220 ELECTRICAL SPECIFICATIONS .. mains voltage: 400 V .. mains frequency: 50 Hz DIMENSIONS / WEIGHTS .. space requirements -left/right-: 4400 mm .. space requirements -front/back-: 3400 mm .. total height: 2700 mm .. total weight approx.: 8000 kg ATTACHMENTS .. digital display: yes .. chip conveyor: yes .. coolant unit: yes .. band filtration unit: yes Lhsdpfx Agexydwwo Rep .. through spindle coolant attachment: yes .. closed cabin: yes .. European CE standards: yes Equipped with: - ATC 220 KSK-A63 - 7 compartment pallet changer system 3R - Tool magazine with 220 tool slots

Condition: used, Year of construction: 2025, Working area: X=3500 mm Y=950 mm Z=80 mm 24" LED color display Software: Woodflash CNC board Operation Milling spindle 12 kW HSK F63 Drilling head DH 17 6H 1S 11 vertical spindles 6 horizontal spindles 1 grooving saw in X-direction Double clamp drive X-axis controlled central extraction Automatic central lubrication Storage location: customer Lsdpfx Agoxymahs Rohp

Condition: used, Year of construction: 2005, - Fagor 8055 CNC control - Additional tank for internal spindle cooling (15 bar) 400 liters - Year of construction 2005 Technical data: - Travel X/Y/Z: 610 / 455 / 520 mm Lodstvf Htepfx Ag Rehp - Rapid traverse: 24 m/min - Working spindle speed: 8000 rpm - Tool holder: BT40 - Table size: 762 x 363 mm - Maximum table load: 350 kg - Motor power: 18 kW - Operating voltage: 400 V - Weight: 3140 kg

Condition: used, Year of construction: 2021, Machine Description for 2021 Model: Horizontal Machining Center NHX 5000 Manufacturer: DMG MORI Bielefeld Hilden GmbH Type / Model: NHX 5000, Fanuc 31iB with CELOS ERGOline Touch Year of Manufacture: 2021 Control System: FANUC 31iB with CELOS / 21.5" Multi-Touchscreen / MAPPS system Technical Data: • Working Area / Travels: - Travel X / Y / Z: 730 / 730 / 880 mm - Pallet size: 500 × 500 mm - Pallet quantity: 2 (with threaded holes) - Minimum B-axis indexing angle: 0.001° (DD direct drive) - Max. rotary table speed: 100 rpm - Pallet load: 500 kg - Hydraulic coupling with 2 hydraulic and 2 air circuits (max. 7 MPa) - Automatic indexing setup station • Performance / Spindle Speed / Drive Power: - Spindle: speedMASTER® motor spindle - Speed range: 35 – 20,000 rpm - Power: 37 / 26 / 18.5 kW (15% / 30 min / continuous duty) - Torque: 221 / 107 / 86.8 Nm - Tool taper: SK40 (7/24 taper, face contact) - Tool magazine capacity: 60 tools (ring-type, random selection) - Max. tool diameter: 70 mm (adjacent) / 170 mm (free) - Max. tool length: 550 mm - Max. tool weight: 12 kg - Chip conveyor: rear discharge with drum filter - Through-spindle coolant interface (8-step pressure control, up to 7 MPa) - Coolant / air switching via spindle - External coolant system: INTERLIT TMF300/600 compact filter unit (70 bar / 32 L/min) • Weight / Dimensions / Electrical Connection: - Machine weight: approx. 12,000 kg - Coolant tank capacity: 800 L - Transformer: 54 kVA - Power supply: 400 V, 50 Hz Equipment / Accessories: - Renishaw OMP60 spindle probe system (optical transmission) - Tool breakage detection system in the magazine - Hydraulic coupling on both pallets with integrated pressure regulation (7 MPa) - Automatic door for setup station - Rotating inspection window (air-driven) - Oil mist extraction system: LTA AC3002 (1,050 m³/h, dual electrostatic stages) - INTERLIT TMF300/600 high-pressure coolant filter system (70 bar, 32 L/min) - EtherNet/IP robot interface - IoTconnector, NETservice, Machine Data Connector (MDC), DMG MORI Messenger - CELOS with touchscreen and MAPPS functionality - Four-color signal light tower - Handheld control device (mobile handwheel) - Central coolant preparation for through-spindle supply - Drain circuit for auto-coupler (to prevent pressure drop) - 10 programmable external M-codes - 2 hydraulic clamping towers (each with 6 hydraulic 2-jaw chucks, GHHY-2B-200.00/K) - Voltage: 400 V, 50 Hz configuration - Air filter unit (T105A-1000MSP) Lhedpfx Aexnkdmsg Rjp This summary uses industry-standard terminology and structure suitable for platforms such as Machineseeker or TruckScout24.

Condition: used, Year of construction: 2016, Working area: X=3300 mm Y=1280 mm Z=150 mm Pass-through height. Operator terminal: 24" LED color display. Handheld terminal for controlling axis speeds. Software: "Woodflash". Vacuum pump 90 m³/h, 50 Hz or 108 m³/h, 60 Hz. Milling spindle 12 kW HSK F63 (12,000 rpm). 12-position linear tool changer on the left side of the machine frame + pickup position. Drilling head DH 16 4H 2S: Vertically 12 spindles, horizontally 4 spindles, 2 grooving saws. Storage location: Supplier. Lhedoxylihepfx Ag Rjp

Condition: used, Year of construction: 2002, Burkhart & Weber MCX 900 – 4-Axis Machining Center - Siemens SINUMERIK 840D CNC control - Double pallet changer, pallet at loading station rotatable, total pallets: 6 - Rack-type tool magazine with 264 tool positions and tool setup station for loading during runtime - Rapid traverse X/Y/Z: 40 m/min / B-axis: 20 rpm - Max. machining force X/Y/Z: 20 kN / Tangential torque B-axis: 20,000 Nm - Renishaw wireless probing system - Year of manufacture: 2002 Technical Data Working ranges: - X-axis: 1,600 mm - Y-axis: 1,400 mm - Z-axis: 1,500 mm - B-axis: 360° / 0.001° Speeds: - Spindle speed: 20 – 6,000 rpm - Gear ranges (2): 20–1,400 / 1,401–10,000 rpm Feed rates and forces: - X/Y/Z-axis rapid traverse/feed: 40,000 mm/min / 20,000 N - B-axis speed/torque: 20 rpm / 20,000 Nm Tool magazine: - Magazine type: rack magazine - Number of tools: 264 Tools: - Max. tool weight: 60 kg - Max. tool length: 560 / 750 mm - Tool holder: DIN 69893 / HSK A-100 - Tool clamping force: 40 kN Pallets: - Pallet size: 800 x 1,000 mm - Pallet changer: double - Pallet weight: 800 kg - Max. allowable pallet weight: 3,150 kg - Pallet design: T-slots - Workpiece loading station: manually rotatable (4 x 90°) Coolant system: - Internal coolant (through tool): 30 l/min / 50 bar - External coolant: 200 l/min / 4 bar Drive power: Ljdpjxxbbwjfx Ag Rshp - S1 operation 100% duty cycle: 37 kW - S6 operation 40% duty cycle: 50 kW Electrical: - Voltage: 3 x 400 V / 50 Hz +10% - Control voltage: 230 V AC / 24 V DC - Rated current: 130 A - Connected load: 65 kW / 75 kVA Hydraulics: - Tank: 240 l - Pressure: 60 bar Pneumatics: - Pressure: 4 – 6 bar - Consumption: 10 m³/h

Condition: used, Year of construction: 2018, Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMIZED PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP OF THE PLATE ALLOWS ABSOLUTELY PRECISION MACHINING NUMERICAL CONTROL WITH 7" COLOR SCREEN: SIMPLE AND INTUITIVE TECHNICAL DATA Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Drilling/slotting work area mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. travel speed of the X-Y axes m / min 25 DRILLING UNIT Vertical spindles number 7 (4X-4Y one of them common) Horizontal spindles (along the Y axis) Number 2 (1+1) Horizontal spindles (along the X axis) Number 1 Fixed groove saw (direction) X Diameter of the groove saw mm 100 Max. thickness of the groove saw mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Speed of the groove saw rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air demand bar 6 Compressed air consumption Nl/cycle 90 Extraction demand m3 / h 1200 Extraction air speed m / sec 20 Extraction nozzle diameter mm 120 GENERAL CHARACTERISTICS Universal CNC drilling machine with work table with fixed gantry and movable workpiece for performing the following machining operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Groove Milling with integrated groove saw in the "X" direction. Self-supporting structure. Machine frame made of tubular steel to provide a large base for the work table. The structure is positioned on three self-leveling feet. The electrical control cabinet is integrated into the machine frame. "Easy Motion" central Bakelite support table: - an MDF sector for through-hole drilling, automatically pivoting for horizontal drilling - an infeed roller that facilitates panel loading - a rear roller conveyor that facilitates panel sliding - left and right stops - a central aligner with manual adjustment. The left and right stops are required to drill the two opposite sides of the panel horizontally in the "X" direction. Panel positioning along the X axis is achieved by means of suction cups. Unit support. This is a gantry structure made of tubular steel. The main machining unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles - Drill chuck D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with a single drill, 1 double drilling head in Y direction (1 + 1 drill chuck D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor power 1.5 kW - Vertical pneumatic travel per spindle 70 mm - Horizontal pneumatic travel of the drilling unit Positioning of the workpiece and drive of the machining unit A CNC-controlled suction cup clamps the workpiece and positions it sequentially under the machining unit during machining. The movement in X and Y axis is carried out on THK guides with transmission on reinforced toothed Movement in Z axis is carried out pneumatically on "ball-bushing" guides with positioning on stop adjustable via the positioning of the working units is carried out via technology and drives with -CONTROL The control was specially developed for use Lhedpjvwbp Aefx Ag Rsp

Condition: used, Year of construction: 2011, AXA DBZ 40 - Vertical Twin-Station Machining Center - Heidenhain iTNC 530 CNC control with digital drive regulation - CNC with all controls on a movable control panel - Pendulum package - Increased spindle speed 30 - 8,000 rpm - 2 AXA RTA 2-300 face plates, 300 mm diameter, center height 200 mm - Counter bearing size 50, hydraulically clamped, center height 200 mm - Swiveling of rotary table axis by hand - Machine table extensions left & right 1350 mm each - Heidenhain direct linear measuring system on all axes - Hardened precision steel guides mounted on hand-scraped or ground bases – counter guides coated with Turcite - X-/Y-base slide, Z-column, slides, and headstock made from high-quality cast iron - Coolant system with integrated 100 l tank and pump for external cooling - Coolant through the spindle - Chip conveyor, mounted on the left - 2 IFS oil and emulsion mist extraction units - Spindle dust protection package (wipers) - Oil level monitoring - Automatic sliding doors - 2 hand cleaning guns Ledpfxoxu Ezmo Ag Rehp - Spindle renewed in 2022 - Year of manufacture: 2011 Technical Data - X-axis travel: 2x 750 mm - Y-axis travel: 500 mm - Z-axis travel: 600 mm - Distance table to spindle nose: 180 - 780 mm Machine table: - Clamping area left and right: 1350 x 500 mm each - T-slots (3): 14 mm - Table load capacity with uniform, distributed load: 800 kg/m² Accuracy according to AXA inspection protocol: - Repeat accuracy: ± 0.005 mm - Positioning accuracy per 1000 mm per axis X/Y/Z: 0.015 mm Feed rates: - Max. feed force: 9000 N - Rapid traverse in X/X/Z: 25 / 25 / 20 m/min - Feed rate in all axes: 1 - 9999 mm/min Main drive / Spindle: - Main drive AC - hollow shaft motor 40 % duty cycle: 30 kW - Speed range, stepless: 30 - 8000 rpm - Spindle torque 40 % duty cycle: 143 Nm - Tool clamping: by drawbolt / disc springs - Tool clamping force: 12000 N - Spindle diameter in front bearing: 65 mm - Tool holder / drawbolt: SK40 DIN69871A/69872A Tool changer: - Carousel magazine slots: 22 - Tool change time: approx. 7 s - Chip-to-chip time: approx. 9 s - Max. tool weight / max. tool length: 8 kg / 400 mm - Tool diameter / with free adjacent pockets: 85 / 135 mm General data: - Electrical connection: 3x 400/230V/N/PE - Control voltage: DC 24 V - Dimensions (LxHxD): approx. 4200 x 2700 x 2300 mm - Weight: approx. 8,500 kg

Condition: used, Year of construction: 2011, Working size in X-direction: 2770 mm Working size in Y-direction: 1220 mm Working thickness (Z-dimension): 80 mm Machine design: Gantry-type machine Main spindle power: 11.0 kW Main spindle speed: 1500 - 24000 rpm Vector controlled spindle: Yes Clamping system: HSK 63 F Spindle cooling: Air cooling Number of axes: 3 Tool changer: Yes Tool changer positions: 10 Ljdpfx Aevvi Hteg Rehp Keyboard: Yes Mouse: Yes Programming system: Xilog Plus DXF interface: Yes Online connection possible: Yes CD-ROM drive: Yes Table type: Matrix table Stop system: Stop cylinders Number of vacuum pumps: 1 Vacuum pump capacity: 250 m³/h Safety: Safety tread mats Storage location: Sonnefeld

Condition: used, Year of construction: 2004, Storage location: Nattheim Lhsdpfx Aevvi Hyog Rop
