Used Pattern Makers Lathe for sale (5,986)

Condition: used, functionality: fully functional, VERTICAL TURNING LATHE FRORIEP KZ 250 TABLE DIAMETER: 2500 MM MAXIMUM TURNING DIAMETER: 2800 MM MAXIMUM WORKPIECE HEIGHT: 1650 MM RAM TRAVEL: 1000 MM TOOL CHANGER: 15 POSITIONS Nodpfx Afjzzv T Hs Ssdb CNC CONTROL: ECS 4801 MACHINE IS INSTALLED AND OPERATIONAL

Condition: excellent (used), Model 6 P, 3600 mm planing table Nedsyr S D Dspfx Af Sedb Engine power: 38 kW, 52 hp

Condition: used, Year of construction: 1998, Spindle speeds 6000 rpm Spindle bore 54 mm Turning length 350 mm Ndodpfx Aszy Unyjf Sjb Turning dia. 170 mm Swing over bed ways 420 mm Swing over cross slide 280 mm X/Z - 165/350 mm No. of stations in turret 12 pcs Control: Fanuc 21i-T Equipped with: 6 tool holders

Condition: used, Year of construction: 2004, functionality: fully functional, turning length: 307 mm, turning diameter: 250 mm, spindle bore: 51 mm, travel distance X-axis: 185 mm, travel distance Z-axis: 370 mm, Key figures at a glance: 250 mm maximum turning diameter, 420 mm swing over bed, 307 mm maximum turning length, 51 mm spindle bore, Ndjdpfx Afjzr Ir As Ssb 4000 rpm maximum spindle speed, 5.5/7.5 kW main motor, an 8-station turret, 185 mm X-axis travel and 370 mm Z-axis travel. The year of manufacture is 2004 and the control system is a Fanuc Series 21i-TB. The machine plate states a supply of 220 V, three phase, 50/60 Hz, 42 A and a maximum power supply of 16.1 kVA, with control voltages of 100 V AC and 24 V DC. Buyers on a 400 V network should plan for a matching transformer. The approximate footprint is 1600 x 1280 x 1890 mm at a weight of around 2800 kg

Condition: ready for operation (used), Year of construction: 1998, operating hours: 29,700 h, functionality: fully functional, turning diameter over cross slide: 400 mm, turning diameter: 400 mm, travel distance X-axis: 250 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 800 mm, rotational speed (max.): 3,000 rpm, total height: 1,950 mm, total length: 3,600 mm, total width: 1,880 mm, quill diameter: 70 mm, quill stroke: 500 mm, overall weight: 5,900 kg, Equipment: rotational speed infinitely variable, Angelini DG 13 lathe Control: Fanuc OT/C Year of manufacture: 1998 Spindle speed: 3,000 rpm Drive power: 18.5 kW Travel: Z-axis: 800 mm X-axis: 250 mm Tailstock diameter: 70 mm Hydraulic tailstock stroke: 500 mm Center height: 250 mm Distance between centers: 800 mm Max. turning diameter: 400 mm 1 chip conveyor Tool turret: 12 stations with driven tools VDI40 C-axis enables 3D interpolation turning with face and cylindrical surface machining Ndedpfx Afozzzu Aj Sob Optional with driven tools. Documentation and export available for an additional charge. Inspection possible while the machine is powered on. We will gladly send you further details or arrange an on-site inspection.

Condition: good (used), Year of construction: 2004, machine/vehicle number: 2420701, CNC multi-spindle automatic lathe, make Index, type MS52C2-1, year 2004, serial no. 160024, - robot cell, - 7 clamping devices, - 3 rigid tool holders simple, - 3 rigid tool holder multiple, - 4 powered tool holders, - Suction Büchel Handlings and assembly robot cell Stäubli Unimation incl. basket translator with basket stack for raw and finished parts, two shuttles on top of each other for supply/removal baskets, Integrated measuring station Commissioning 2021 Connected load 24 kW, control, make Index, type C200-4D (Siemens 840 D basis), - 2 steering positions, - 6 spindles, - travel X/Y 300 x 500 mm, - bar diameter max. 52 mm, - - spindle speed max. 5000 rpm, -12 tool carriers, coolant system, - Industrial robot, make Stäubli, - programming panel, - extraction device, - settling device, - Accesories Ndodpfjlmkucox Af Seb

Condition: good (used), Year of construction: 2000, functionality: fully functional, turning diameter 570 mm Njdjzxpxqjpfx Af Sjdb turning length 2000 mm control Heidenhain TURN PLUS centre height 265 mm rapid travel - longitudinal/face 10/7 m/min spindle turning speed range 1-2500 U/min weight of the machine ca. 3,6 t dimensions of the machine ca. 5,5 x 2 x 2 m Additional information Equipment: Heidenhain TURN PLUS CNC control 3-jaw manual chuck Multifix tool holder 3 steady rests

Condition: new, Year of construction: 2026, functionality: fully functional, turning diameter over cross slide: 1,260 mm, spindle bore: 130 mm, turning diameter over bed slide: 1,600 mm, total length: 6,100 mm, total width: 2,130 mm, total height: 2,300 mm, overall weight: 15,100 kg, rapid traverse Y-axis: 1,870 m/min, rapid traverse Z-axis: 3,740 m/min, workpiece weight (max.): 6,000 kg, Hardened and ground guide rail The gears in the spindle head have a long service life and produce little noise. The spindle system is characterized by high rigidity and accuracy. Ndodpszzdbfjfx Af Seb A quick feed mechanism is mounted on the carriage. Thanks to the clutch in the spindle head, the lathe starts smoothly and decelerates quickly.

Condition: new, Year of construction: 2026, spindle bore: 51 mm, – Maximum turning diameter: 1000 mm – Turning diameter over bed: 360 mm – Turning diameter over cross slide: 230 mm Ndodpfx Aoz Altrof Seb – Spindle bore: 51 mm – Infinitely adjustable spindle speed – Longitudinal and transverse feed – Sino digital display for 2 axes – Cooling system – Lighting – Safety guard – Fixed steady rest – Follower rest – Three-jaw chuck – Four-jaw chuck – Emergency stop – Documentation – 400V

Condition: good (used), Year of construction: 2000, operating hours: 21,594 h, functionality: fully functional, Gildemeister NEF 320 CNC teach-in lathe Heidenhain Manual Plus Year of manufacture: 2000 Machine operating hours: 21,594 Ndedpfx Asyh Hg Njf Seb Max. turning diameter over bed: 320 mm Max. turning diameter over cross-slide: 150 mm Max. turning length between centers: 750 mm Max. spindle bore: 50 mm Motor: 9 kW Spindle speed: 10–4,000 rpm Chuck: Rota-S Plus Multifix quick-change toolpost with tool holders Documentation and accessories Machine is powered up and available for inspection

Condition: used, Year of construction: 1999, turning diameter over bed 330 mm turning diameter over slide rest 195 mm turning length 750 mm center height over bed 160 mm centre distance 650 mm digital readout 3 Achsen HEIDENHAIN bed width 205 mm spindle bore 36 mm spindle taper KK5 DIN 55027 turning speed range 48 - 2500 U/min Ndodpfx Afezy Sb Do Ssb power requirement 3,0 kW 4-jaw-chuck diameter 160 mm quick change toolholder MULTIFIX Typ A taper in tailstock-quill MK 3 dia. of quill 40 mm quill stroke 100 mm voltage 400 V total power requirement 3,2 kW weight of the machine ca. 680 kg dimensions of the machine ca. 1,60 x 0,80 x 1,55 m - Serial-No.: 4432 - HEIDENHAIN 3-axis digital readout - MULTIFIX quick-change tool holder - Collet chuck including collets Ø 8 - Ø 27 mm - Face plate Ø 250 mm - Quick-action drill chuck - Center point

Condition: excellent (used), functionality: fully functional, CNC Heavy-Duty Lathe POREBA TPK-90N × 2000 mm – SIEMENS CNC We offer a heavy-duty CNC lathe POREBA TPK-90N with a turning length of 2000 mm, equipped with a SIEMENS CNC control. The machine is designed for precise machining of large and heavy workpieces. Its robust construction and massive machine bed, characteristic of POREBA heavy-duty lathes, provide high rigidity during machining. Main technical specifications: Manufacturer: POREBA Model: TPK-90N CNC control: SIEMENS Nsdpfsz Atg Tjx Af Ssdb Turning length / distance between centers: 2000 mm Swing over bed: approx. 930 mm Swing over carriage: approx. 630 mm Swing in gap: approx. 1200 mm Spindle bore: approx. 95 mm Max. spindle speed: up to 800 rpm Main motor power: approx. 22 kW Tailstock taper: Morse 6 Main features: SIEMENS CNC control, heavy and highly rigid machine construction, large swing over bed of approx. 930 mm, 2000 mm turning length, suitable for machining large and heavy workpieces, proven design of POREBA heavy-duty industrial lathes. The machine is located in Bydgoszcz, Poland. Inspection and test run are possible by prior arrangement. METALEX – machine tools since 1979.

Condition: ready for operation (used), Year of construction: 1989, turning diameter over cross slide: 340 mm, turning length: 560 mm, turning diameter: 560 mm, spindle bore: 63 mm, overall weight: 5,500 kg, Fanuc OT Length capacity: 560 mm Diameter over slide: 340 mm, turning diameter: 560 mm Ndedpfxozbam Eo Af Sjb Turret: 10 stations Spindle: 11 kW Chip conveyor

Condition: ready for operation (used), Year of construction: 2003, CNC: GE Fanuc Series 18i-TB No. 02 motorized turrets Y-axis on rear turret Sub-spindle Nodpfjzmgh Ejx Af Sodb TOP loader

Condition: used, functionality: fully functional, Used TAPER TAP MACHINE, FAMUP (SERRMAC) MDR16. TAPER TAP MACHINE, SERRMAC WITH PEDESTAL COOLING SYSTEM AND TANK, USED. Ndjdpfx Afezht Izo Seb

Condition: used, Used parallel lathe, 250x1000, SIBIMEX CU500, with display,56MM BAR CLEARANCE Njdpfsz Az Rqsx Af Ssdb

Condition: used, Year of construction: 1986, RAFAMET UBD150N wheel lathe Range of wheel tread diameters: 700 to 1,300 mm Maximum wheelset weight: 3,500 kg Nedpfx Ajz A Ehtof Sodb

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, turning length: 3,000 mm, turning diameter over bed slide: 480 mm, controller model: Siemens 840D, TECHNICAL DETAILS Swinging diameter over bed: 520 mm Swinging diameter over carriage: 480 mm Turning length: 3,000 mm C-axis: yes C-axis speed range: 0–20 rpm Number of tools: 12 Driven tools: 6 Spindle bore: 103 mm Main spindle head size: 8 MACHINE DETAILS Control system: Siemens 840D Main drive Main drive: 1-stage AC main drive Drive power: 53 kW Duty cycle: 50 % Njdpfxjzwmztj Af Sodb Speed range: 30–3,000 rpm EQUIPMENT Forkardt 3 NHF 315-82 A8 power chuck with centrifugal force compensation and hard, ground-in top jaws Outer diameter of power chuck: 315 mm Bore diameter of power chuck: 82 mm Maximum bar diameter: 63 mm Including draw tube and mounting for power chuck

Condition: excellent (used), Year of manufacture: 1973 Distance between centers: 500 mm Distance between centers (vertical): 125 mm Swinging diameter over bed: 270 mm Swinging diameter over cross slide: 120 mm Spindle bore: 32 mm Spindle nose: Camlock D1-3 Spindle speed: 225 - 3000 rpm Tailstock quill: MK 2 Weight: approx. 930 kg Dimensions W x D x H: approx. 1473 × 730 × 1280 mm Nodpfszyyn Sox Af Sodb Condition: very good Accessories: see pictures Through hole in the chuck: 28 mm Collet system: Schaublin B32 Automatic feed: 4 - 260 mm/min Cuttable metric threads: 0.25 to 8 mm Cuttable inch threads: 112 to 3 threads per inch

Condition: good (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 845000756E, turning diameter: 400 mm, spindle bore: 103 mm, spindle speed (max.): 3,200 rpm, travel distance X-axis: 265 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 1,050 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, total height: 2,400 mm, total length: 6,000 mm, total width: 2,400 mm, overall weight: 8,000 kg, bar passage: 90 mm, center height: 360 mm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840 D, input voltage: 400 V, input frequency: 50 Hz, input current: 80 A, nominal power (apparent): 50 kVA, operating hours of spindle: 4,617 h, Equipment: documentation/manual, DMG MORI ECOTURN 510 CNC lathe - Chuck diameter: 250 mm - Diameter in the front bearing: 140 mm - Feed drive in the X and Z axes: 40 x 10 mm - Feed forces X/Z: 7.5 kN - Y-axis feed force: 7000 N Nsdpozxzc Iefx Af Sodb - Rapid traverse C1 axis: 100 m/min - Travel measuring system X/Y/Z: absolute rotary - Positioning uncertainty X: 0.008 mm, Z: 0.010 mm - Working area, distance between centers: 1150 mm - Max. swivel range above the bed: 680 mm - Swivel range above the X slide: 465 mm - Travel of the Y-axis: 120 mm (+/- 60 mm) The machine is equipped with a tailstock and a 12-position tool turret, including the tool holders located in the turret, as well as a three-jaw chuck SMW AUTOBLOK, diameter: 300 mm, including a chip conveyor, filter extraction, and documentation. FCA D-73529 Schwäbisch Gmünd - to be loaded onto a truck.

Condition: good (used), Year of construction: 2012, functionality: unexamined, machine/vehicle number: HK06, spindle bore: 48 mm, total length: 1,600 mm, total width: 900 mm, total height: 1,600 mm, spindle speed (max.): 2,500 rpm, spindle speed (min.): 48 rpm, overall weight: 800 kg, input voltage: 400 V, input frequency: 50 Hz, input current: 7 A, WEILER PRAKTIKANT GS Lead and Feed Spindle Lathe - Connection: 5.5 kVA - Distance between centers: approx. 700 mm - Center height above bed: 160 mm - Turning diameter above bed: 320 mm - Center height above cross slide: approx. 100 mm - Turning diameter above cross slide: approx. 200 mm The machine is equipped with a tailstock, a Multifix tool holder, and a quick-change chuck, including a three-axis digital display from the manufacturer FAGOR. Ndedpszxzmysfx Af Sjb FCA D-72589 Westerheim - loaded onto a truck.

Year of construction: 1967, condition: used, Swing over bed: 540mm, swing over carriage: 280mm, max. cross slide travel: approx. 410mm, max. compound slide travel: approx. 140mm, tailstock quill travel: 225mm, main spindle speed steps: 24, spindle speed: 9-1400rpm, 32 longitudinal feeds: 0.063-2.24mm/rev, 32 cross feeds: 0.032-1.12mm/rev, metric thread pitch: 0.25-560mm, module threads: module 0.1-50, diametral pitch threads: pitch 160-0.5, center height above flat guideway: 265mm, center height above top of V-way: 247mm, bed width: 403mm, main spindle with spindle nose according to DIN 55022: size 11, spindle bore: 103mm, internal taper: 1:20, largest diameter: 109mm, Morse taper of centers: No. 5, leadscrew pitch, standard: 12mm, tailstock quill diameter: 80mm, standard drive power: 18.5kW, rated speed of drive flange motor: 1400rpm, turning tool cross-section according to DIN 770: 25x25mm, max. faceplate diameter: 500mm, max. three-jaw and four-jaw chuck diameter according to DIN 6350: 315mm, weight: 3t, with work light, coolant system with chip tray, four-way tool post with face serration for one-hand operation on the compound slide, operating manual and fixed steady rest. An on-site inspection is possible. Ndedpfezzqblex Af Sob

Year of construction: 1985, condition: used, Spindle nose: A11, turret: VDI60, voltage: 380V, rated current: 153A, fuse protection: 160A, control: Philips B2T, one tool position for boring bars is defective, no driven tools, without chuck, with documentation and maintenance records, the machine was mechanically overhauled in 2010. An on-site inspection is possible, available from mid-December 2026. Nodoz Agfpjpfx Af Sodb

Condition: good (used), turning diameter over bed 520 mm turning diameter over slide rest 320 mm turning length 1000 mm turning speeds 21 - 1500 U/min spindle bore 52 mm transmission ratio 18 total power requirement 5,5 kW Nsdpezyy E Dofx Af Sedb weight of the machine ca. 1500 kg dimensions of the machine ca. 2200 x 1100 x 1400 mm

Condition: ready for operation (used), Year of construction: 2012, spindle bore: 75 mm, spindle speed (max.): 2,400 rpm, rotational speed (max.): 2,400 rpm, quill diameter: 75 mm, Fanuc OITD Capacity: 1750 x 560 mm Diameter: 390 mm on carriage 12-position turret Tool guards Nsdpozzdtuofx Af Sodb Set of VDI tool holders
