Used Horizontal Drilling for sale (10,402)

Condition: used, Vitap's smart solution for through-hole drilling and grooving with automatic return to the operator. Three controlled axes: - X-axis – continuous workpiece transport via a patented belt system. - Y-axis – drilling head movement, guided by rack and pinion. - Z-axis – drilling, guided by ball screw. Psdpfx Afszutqistsgr The fewer limitations, the greater the progress! With our machine, we do not impose any limits on workpiece length. Simple TPA programming: - You can position the holes individually. - The machining operations are displayed on a virtual workpiece. - If the workpiece dimensions change, the holes can be automatically adjusted. Office software license – Power lies in tranquility. - Perhaps you have better ideas in a quieter environment? This allows you to make better use of the flexible CAD system. - With this license, you can write programs where they are developed and discussed, in the office. Color LCD TFT 19" 5/4 screen USB port for loading programs from any office workstation 3 password-protected access levels (operator, supervisor, assistance) Technical data: - 9 vertical spindles, individually controllable - 2+2 horizontal drilling spindles in X - 1+1 horizontal drilling spindles in Y - 1 grooving saw unit (saw blade diameter 100 mm) - Max. workpiece thickness 50 mm - Max. workpiece weight 50 kg - Max. workpiece size: X unlimited, Y 920 mm, Z 50 mm - Min. workpiece size: X 270 mm, Y 150 mm, Z 10 mm - Workpiece transport speed: 25 m/min - Spindle speed 3,600 rpm - Max. horizontal drilling depth, X and Y axes 30 mm - Max. vertical drilling depth 45 mm - Max. vertical tool diameter 35 mm - Max. horizontal tool diameter 12 mm - Motor power 1.7 kW - CE standard

Condition: used, Year of construction: 2022, total height: 2,400 mm, total length: 5,300 mm, total width: 2,350 mm, Colour: Grey Empty weight: 4.000 kg What are Presale Items at Second Owner? Presale items are machines that we sell in their current condition ("as-is"). We have purchased these machines based solely on photos and sell them with the information provided in the advertisement. Unfortunately, we do not have additional details, such as exact dimensions or machine specifications. Additionally, these machines are often not yet in stock and have not been inspected by us. These machines are offered at competitive prices, which means the prices are lower than usual, but the risk lies entirely with the buyer. Please carefully review the information in the advertisement before making a purchase. If you have any questions, feel free to contact us! - Year: 2022 - Documentation available: Yes - CE marking present: Yes - CE certificate present: No - Serial number: 30B.11.040.22 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 4 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 11 - Type milling table: Beam table - Tool holder: HSK-F63 Podpfx Afszwul Hjtegr - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Horizontal drill spindles [pcs.]: 4 - └ Vertical drilling spindles [pcs.]: 12 - Saw unit present: Yes - Tool changer positions [pcs.]: 12 - System/software: WoodFlash - Safety feature: Safety light curtain - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: PICCHIO 2200 - └ Year of manufacture: 2022 - Tools included: Yes - CNC options: Manual control - CNC documentation available: User keys/licenses, USB stick - Table length [mm]: 3300 - Table width [mm]: 1280 - Working range X [mm]: 3300 - Working range Y [mm]: 1280 - Z-axis working range [mm]: 250 - X-axis maximum stroke [mm]: 4000 - Y-axis maximum stroke [mm]: 1670 - Z-axis maximum stroke [mm]: 500 - Voltage [V]: 400 - Current consumption [A]: 40 - Power [kW]: 18.0 - Installed length [mm]: 6250 - Installed width [mm]: 3494 - Installed height [mm]: 2300 - Transport dimensions: 5300mm x 2350mm x 2400mm (l x w x h) - Transport weight [kg]: 4000kg - Transport packages [pcs.]: 2 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: as good as new (ex-display), 21-spindle single-head drilling machine, suitable for all carpentry needs, ideal for joining a work center to save time and release it from horizontal drilling operations. PNEUMATIC HEAD ROTATION - with lock and stop reference from 0° to 90°at any angle. SIDE REFERENCE FENCES - Adjustable cast iron fences on a metric scale thanks to a magnify glass and nonius. PATENTED SPIRAL SYSTEM - Device for boring depth adjustment, allowing an easy and quick set-up on a millimetric scale according to the different drill lengths. Pgsdpfxjd Supgs Aftsr no of drilling spindles 21 # distance between drilling spindles 32 mm working width 640 mm max drilling depth 65 mm no. of pneumatic work piece clamps 2 # work piece dimensions max 900 x 3000 x 60 mm motor 1,5 kWm 50 Hz, 400 V, 2800 rpm pneumatic pressure requirement 6-8 bar compressed air consumption 10 l/cycle suction DM 80 mm machine dimensions L x W x H = 1030 x 1030 x 1285 mm weight 240 Kg

Condition: ready for operation (used), Radial Drill, Used Equipment Brand: CSEPEL Model: R.F. 2a Description: Column Diameter: 350 mm Vertical Travel of the Arm: 1200 mm Horizontal Travel of the Drill Head: 1000 mm Psdpfx Ajw Db Nueftjgr Vertical Travel of the Spindle: 400 mm Spindle Diameter: 65 mm 12 Spindle Speeds: 47.5 – 2100 RPM 8 Feed Rates: 0.048 – 1.2 m/min Motor Power: 9 HP

Condition: used, Scheer DB 5 dowel hole drilling machine for the precise and rapid drilling of dowel holes (horizontal and vertical) in solid timber and board materials. The machine is ideal for mass production in furniture manufacturing as well as for precise joints in interior fit-out work. Includes a comprehensive range of dowel bits. Technical data: - Drilling spindles: 21 - Pitch: 32 mm - Passage width: max. 1,000 mm - Swivel mechanism: pneumatic Pgodpfxsztvx To After - Fax: , Mobile: , Machine No. 208695, Jan 2011, Cost price €1,000 - D-89440 Lutzingen, Tel. , Fax: , April 2015, purchase price €500

Condition: used, Used dowel drilling machine Ayen Type DB 1000-B23 for drilling operations in the production of dowel joints in woodworking. The machine features a working width of 720 mm, a maximum clearance of 820 mm and different drilling depths for vertical and horizontal machining. Technical data: Pjdezryr Ujpfx Aftegr - Working width: 720 mm - Max. clearance: 820 mm - Drilling depth, vertical: 45 mm - Drilling depth, horizontal: 120 mm

Condition: used, Year of construction: 2014, total height: 2,800 mm, total length: 10,300 mm, total width: 2,450 mm, Colour: Grey Empty weight: 6.600 kg Price: On request - Year: 2014 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AA2/002546 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: Pjdpfxoytcl Ie Aftogr - - Number of controlled axes [pcs.]: 5 - - Max. spindle speed [rpm]: 24000 - - Main motor power [kW]: 11 - Type milling table: Beam table - Tool holder: HSK-F63 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Motor power [kW]: 3 - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 10 - Tool changer positions [pcs.]: 24 - System/software: Xilog plus - Safety feature: Safety light curtain, Door interlock switches, Enclosed fence - Vacuum pump present: Yes - └ Number [pcs.]: 1 - └ Brand: Becker - └ Type: Vtlf 250 - └ Year of manufacture: 2008 - └ Main motor power [kW]: 5.5 - └ Connection diameter [mm]: 70 - └ Oil free: Yes - Tools included: Yes - CNC options: Offcut conveyor, Manual control - CNC documentation available: USB stick - Table length [mm]: 5200 - Table width [mm]: 1300 - Voltage [V]: 400 - Current consumption [A]: 64 - Transport dimensions: 10300mm x 2450mm x 2800mm (l x w x h) - Transport weight [kg]: 6600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2018, total height: 1,800 mm, total length: 1,750 mm, total width: 1,800 mm, Colour: Grey Empty weight: 975 kg - Year: 2018 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 173180025 - Main motor power [kW]: 3 - Working range X [mm]: 3000 - Working range Y [mm]: 3000 - Working range Z [mm]: 50 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 4 - Vertical drilling unit: Yes - Saw unit present: Yes - Voltage [V]: 400 - Current consumption [A]: 3 - Transport dimensions: 1750mm x 1800mm x 1800mm (l x w x h) Psdpfx Ajyf Hc Isftegr - Transport weight [kg]: 975kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2015, total height: 1,850 mm, total length: 2,300 mm, total width: 1,950 mm, Colour: White Empty weight: 1.240 kg - Year: 2015 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: AB/222595 - Main motor power [kW]: 2.2 - Number of controlled axes [pcs]: 12 - Working range X [mm]: 3050 - Working range Y [mm]: 800 - Working range Z [mm]: 60 Pgodpfjzavvgox Aftjr - X-axis max stroke [mm]: 1040 - Y-axis max stroke [mm]: 1030 - Z-axis max stroke [mm]: 100 - Number of milling spindles [pcs]: 8 - Spindle diameter [mm]: 10 - Min. spindle speed [rpm]: 1000 - Max. spindle speed [rpm]: 4000 - Horizontal drilling unit: Yes - Horizontal drilling spindles [pcs]: 6 - Max. drilling depth [mm]: 18 - Vertical drilling unit: Yes - Vertical drilling spindles [pcs]: 8 - Max. drilling depth [mm]: 30 - Saw unit present: Yes - Safety feature: - Voltage [V]: 400 - Current consumption [A]: 10 - Transport dimensions: 2300mm x 1950mm x 1850mm (l x w x h) - Transport weight [kg]: 1240kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: excellent (used), Horizontal/vertical rotary table Chuck: Ø 350 mm Pgsdpfxozwxivo Aftjr Shelf diameter: Ø 400 mm Height without mandrel: 140 mm Total height: 250 mm Base dimensions: Length 430 mm x Depth 370 mm Weight: approx 150 kg Possibility to work horizontally or vertically The increment is done by the front handle

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Pgedpfx Ajxwaz Hsftsr

Condition: used, Year of construction: 2014, operating hours: 11,517 h, total height: 2,880 mm, total length: 10,000 mm, total width: 2,700 mm, Colour: White Empty weight: 6.000 kg - Year: 2014 - Documentation available: No - CE certificate present: No - Serial number: 070614/B/1-407 - Operating hours: 11517 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 4 - - Main motor power [kW]: 10 - - C-axis present: Yes Psdpfex E Uk Uex Aftegr - Type milling table: Flat table - Drilling unit present: Yes - └ Motor power [kW]: 3.6 - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 18 - Tool changer positions [pcs.]: 12 - System/software: TWINCAT - Safety feature: Enclosed fence, Safety mat - Vacuum pump present: Yes - └ Number [pcs.]: 2 - └ Brand: Becker - └ Year of manufacture: 2023 - └ Main motor power [kW]: 18.5 - └ Capacity [m³/h]: 600 - └ Vacuum pressure [bar]: 250 - └ Oil free: Yes - CNC documentation available: USB stick - Table length [mm]: 5150 - Table width [mm]: 1600 - Working range X [mm]: 7220 - Working range Y [mm]: 1580 - Z-axis working range [mm]: 180 - Voltage [V]: 400 - Transport dimensions: 10000mm x 2700mm x 2880mm (l x w x h) - Transport weight [kg]: 6000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: ready for operation (used), machine/vehicle number: 154.1004.094, Professional Neolt Electro Foam Trim Plus 310 horizontal cutting machine for foam board, PVC, cardboard and similar materials. This is a high-quality Italian industrial cutter with a maximum working width of 310 cm, suitable for sign making, printing industry and production environments. Main features: • Manufacturer: Neolt (Italy) • Model: Electro Foam Trim Plus 310 • Working width: 310 cm • Electric cutting system • High precision cutting • Suitable for foam board, PVC, cardboard and similar materials Included accessories • Multiple blade holders: 5 mm, 10 mm, 20 mm and 30 mm • Spare blades included • Original manual • Electrical spare parts (circuit boards etc.)• Additional accessories and components Condition: Machine is in good working condition and fully functional. Cutting accuracy is very good. The main unit is clean and well maintained. Support tables show normal signs of use. Additional information: • Maximum cutting thickness up to 30 mm (depending on blade holder) • Currently equipped with 10 mm blade holder • Mounted on wheels for easy movement • Support tables included Logistics Machine available for immediate pickup. Located in Finland. Loading assistance available. Extra Video available showing cutting operation! Pgjdpfjywpcpox Aftsr Complete set with accessories and spare parts – ready for professional use! Keywords: foam board cutter Neolt cutter electric cutter horizontal cutter foam trim sign making equipment large format cutter

Condition: ready for operation (used), Year of construction: 2011, machine/vehicle number: 65352, functionality: fully functional, travel distance X-axis: 3,765 mm, travel distance Y-axis: 1,585 mm, travel distance Z-axis: 170 mm, number of axes: 3, number of slots in tool magazine: 12, TECHNICAL DETAILS Milling spindle Number of controlled axes: 3 Tool holder: ISO 30 Motor power: 1.7 kW Drilling unit Drilling tool available: Yes Vertical drilling spindles: 10 pcs. Table and working area Type of milling table: Flat table Table length: 3,750 mm Table width: 1,560 mm Working area X-axis: 3,765 mm Working area Y-axis: 1,585 mm Working area Z-axis: 170 mm Z-axis travel max.: 324 mm Material clamping system: Pneumatic Tool changer and control Pgodszuwt Iopfx Aftjr Number of tool changer positions: 12 pcs. MACHINE DETAILS System/Software: BiesseWorks Vacuum pump Brand: Busch Type: MM1322AVM Capacity: 360 m³/h Connection diameter: 60 mm Oil-free: Yes Dimensions & Weight Dimensions (L x W x H): 5,600 x 2,250 x 2,550 mm Installed length: 6,465 mm Installed width: 4,794 mm Installed height: 2,550 mm Shipping weight: 2,500 kg Shipping packages: 2 pcs. EQUIPMENT Tools included Vacuum pump Busch MM1322AVM Safety mat CE marking

Condition: used, Year of construction: 2018, operating hours: 500 h, Throughfeed machining, workpiece machining from below, and automatic workpiece return to the operator. 3 controlled axes: X axis - uninterrupted workpiece transport via DDT (double dynamic transport system) with a brushless motor Y axis - drilling head travel Z axis - drilling - Double "0" reference: new laser generation for detecting the start and end of the workpiece. The program can adjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge materials. - Side stops with rollers consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning on the 0 line. - Rear workpiece outlet - Automatic 4-position tool changer - No workpiece length limitation - Monitor LCD TFT 19" 5/4 - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Pgedpfx Afezuxdbetor Technical data Number of independent, vertical spindles: 12 Number of independent, horizontal spindles on the X axis: (2+2) Number of horizontal drilling spindles on the Y axis: (2+2) 1 saw (Ø 100mm) Electric spindle 5 kW with ISO30 taper (RPM 12000-24000) Max. workpiece weight: 80 kg Max. workpiece dimensions: X unlimited, Y 1200 mm, Z 50 mm Min. workpiece dimensions: X 270, Y 185 (70op), Z 4 mm Feed rate: 25m/min Spindle speed: 3500 RPM Max. horizontal tool Ø 12mm Max. drilling depth horizontal on the X and Y axis 30mm Max. drilling depth vertical: 45 mm Max. vertical tool Ø 35mm Air consumption 2000 m3/h Extraction speed 30 m/s Extraction nozzle 2xØ. 100mm + 1xØ.50 mm Motor: 1.7 kw Compressed air: 7 bar Max. air consumption: 60 nlt/min CE STANDARDS - Office software - license - Adjustable zero point for 4-sided formatting - CE compliant - Status: 05/28/2026: approx. 500 operating hours and a new PC has been installed.

Condition: used, Year of construction: 2015, operating hours: 19,402 h, total height: 2,250 mm, total length: 2,500 mm, total width: 1,900 mm, Colour: White Empty weight: 1.600 kg Price: On request - Year: 2015 - Documentation available: Yes - └ Type Documentation: User manual, Electrical diagrams, Technical data, Operating system - CE marking present: Yes - CE certificate present: No - Serial number: AB/224221 - Operating hours: 19402 - Number of milling spindles [pcs.]: 1 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 1 - - Max. spindle speed [rpm]: 18000 Pgjdpfx Aszmvfteftsr - - Main motor power [kW]: 5.6 - Type milling table: Flat table - Tool holder: ISO30 - Material clamp system: Pneumatic - Drilling unit present: Yes - └ Motor power [kW]: 2.64 - └ Horizontal drill spindles [pcs.]: 6 - └ Vertical drilling spindles [pcs.]: 11 - Saw unit present: Yes - Tool changer positions [pcs.]: 0 - System/software: SCM Maestro - Safety feature: Door interlock switches, Safety light curtain - Tools included: Yes - CNC options: Barcode reader, Manual control - CNC documentation available: USB stick, User keys/licenses - Table length [mm]: 3960 - Table width [mm]: 840 - Working range X [mm]: 3050 - Working range Y [mm]: 900 - Z-axis working range [mm]: 60 - Voltage [V]: 400 - Current consumption [A]: 35 - Fuse [A]: 63 - Power [kW]: 10.0 - Installed length [mm]: 4500 - Installed width [mm]: 1900 - Installed height [mm]: 2250 - Transport dimensions: 2500mm x 1900mm x 2250mm (l x w x h) - Transport weight [kg]: 1600kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: used, Year of construction: 2019, - Magazine loading system - Clamping table for frame parts - 3 horizontal, longitudinal drilling units from the rear - 4 vertical drilling units from above 1 Drilling machine Manufacturer: KOCH Type: BL 2500 NC select line - used - Year of manufacture: 2019 Workpiece dimensions Workpiece length 150 - 2500 mm Workpiece width 20 - 300 mm Workpiece thickness 10 - 50 mm Material: Solid wood Magazine loading system 1 with workpiece return. Workpiece insertion via 2 parallel-controlled servomotors. The number of workpieces in the magazine depends on the workpiece weight. Manual workpiece insertion Clamping table for frame parts 1 By inserting 3 support segments into the longitudinal drilling units, workpieces can be inserted manually and clamped with clamping cylinders and templates. This also allows for special workpiece dimensions. Work cycle triggering via 2 manual controls on the swappable control panel. 3 horizontal, longitudinal drilling units from the rear Construction width 160 mm Drilling motor 2 kW Longitudinal adjustment (X) with LCD display Vertical adjustment (Z) With dust extraction 4 vertical drilling units from above (supported on one side in a linear guide) Adjustable over the entire working width (X), reading LCD display. Adjustable in working depth (Y), reading LCD display One vertical clamping cylinder mounted directly on the unit Counterpieces for through-holes are available as an option. Drilling motor 1.5 kW at 50 Hz Drilling stroke 50 mm Podpfx Ajzuynhsftsgr Speed 2,800 rpm Total drill length 70 mm With 4 rotary indexing heads with quick adjustment (for vertical drilling units) with fixed stops at 0 and 90 degrees Positioning control KOCH NUMERIC Basic 1 Positioning control with Beckhoff C6920 industrial PC Intel Celeron 2.2GHz CPU 2.5 320GB HDD 1x RS232, 2x USB, 1x Ethernet available 15-inch touch panel Operating system Windows 7: English User interface in English Input of all machine commands via the touch panel Software is prepared for an online connection. The configuration of the online connection (network) and commissioning are carried out by the customer or their software company. USB port on the PC 4 x Dynamic NC axis (with bearing control) for Z axes Connection data 1 Electrical connection 400 V, 50 Hz, 3 phases Voltage fluctuations max. + 6 % to - 10 % If protected by an RCD (residual current device) on the customer's side, an all-current sensitive (R CCB, Type B) RCD with a rated residual current of /= 300 mA must be used. Air connection 7 bar Dust extraction air velocity min. 30 m/s Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: excellent (used), Year of construction: 1993, Catalogue number 7718 TECHNICAL DATA - Number of spindles: 23 pcs - Head prepared for screw-in drills - Distance between outermost spindles: 704 mm - Distance between spindles: 32 mm Pgedoztv Iuopfx Aftor - Pneumatic clamps: 2 pcs - Table surface dimensions: 1200x850 mm - Height to table surface: 930 mm - Feed cylinder stroke: 70 mm - Max drilling diameter: 12 mm - Drilling adjustment vertical/horizontal and at an angle - Drilling unit adjustment pneumatic - Main motor: 2×0.75 kW - Dimensions L/W/H: 1270x1330x1350 mm - Weight: approx. 700 kg ADVANTAGES – Made in Poland – 23 spindles – Head prepared for screw-in drills – Not repainted – DTR technical documentation – Used drilling machine, very good condition Net price: 8900 PLN Net price: 2120 EUR based on exchange rate of 4.2 EUR (Prices may change depending on currency fluctuations)

Condition: new, Six-sided drilling machine Manufacturer: Quick Type: KQ-62Lite New machine Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Pjdpfx Afezvgndstsgr Optional - Machine including workpiece return Other configurations available upon request.

Condition: ready for operation (used), Year of construction: 1989, Immediately available from training center: Universal Milling Machine Horizontal - Vertical WMW Auerbach Type FW 250 x 1000 / 2 Year of manufacture: 1989 Table: 1250 x 250 mm Table load capacity: 1250 kg Travel X/Y/Z: 700 / 400 / 500 mm Pgsdpfxozwufao Aftor Heidenhain 3-axis digital readout SK 40 Spindle speeds: 55 – 2800 rpm Feeds: 10 – 630 mm/min, stepless Vertical head Horizontal milling device Drive power: 6.3 kW Weight: 2.5 t Offered at EUR 2,000 – plus VAT, ex location

Condition: used, Year of construction: 2009, total height: 2,500 mm, total length: 40,500 mm, total width: 2,400 mm, Colour: Blue Empty weight: 30.900 kg Price: On request 4 tool changers, 24 pcs each Plus external magazine 117 positions Drilling unit 2, 4x horizontal only Incl. Oertli tools Max. machining length 6 meters NEXUS Software (HMI) Output table 320x360 cm Operating hours cannot be read out - Year: 2009 - Documentation available: Yes - └ Type Documentation: Electrical diagrams - CE marking present: Yes - CE certificate present: No - Serial number: 113040 - Number of milling spindles [pcs.]: 6 - └ Milling spindle 1: - - Number of controlled axes [pcs.]: 3 - - Min. spindle speed [rpm]: 0 - - Max. spindle speed [rpm]: 18000 - - Main motor power [kW]: 20 - └ Milling spindle 2: - - Number of controlled axes [pcs.]: 3 - └ Milling spindle 3: - - Number of controlled axes [pcs.]: 4 - - C-axis present: Yes - └ Milling spindle 4: - - Number of controlled axes [pcs.]: 4 - - C-axis present: Yes - Tool holder: HSK-F63 - Drilling unit present: Yes - └ Motor power [kW]: 2.5 - └ Horizontal drill spindles [pcs.]: 4 - └ Vertical drilling spindles [pcs.]: 6 - Tool changer positions [pcs.]: 24 - System/software: Nexus - Safety feature: Enclosed fence, Door interlock switches - Tools included: Yes - CNC options: Unloading system, Loading system, Label machine - Table length [mm]: 6000 - Table width [mm]: 3800 - Installed length [mm]: 26000 - Installed width [mm]: 9500 - Installed height [mm]: 2850 - Transport dimensions: 40500mm x 2400mm x 2500mm (l x w x h) - Transport weight [kg]: 30900kg Pedpfxjzt Nado Aftsgr Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: good (used), Year of construction: 1979, functionality: fully functional, spindle mount: MK 3, For sale is a column drill press made by Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-ES • Speed: approx. 65 - 1,750 rpm • Quill stroke: approx. 180 mm • Table size: approx. 515 x 415 mm • Year of manufacture: 1979 • With coolant pump Psdpfx Afozvrt Setegr • Condition: Used, functional The machine can be inspected and tested at any time! If interested, two identical machines are available! Shipping costs via freight carrier: approx. €190 Phone number: 01575 2236716 You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale ex works 42855 Remscheid, free loading. Subject to errors in technical data and prior sale.

Condition: good (used), Year of construction: 1979, functionality: fully functional, spindle mount: MK 3, For sale is a pillar drilling machine from the brand Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-E • Speed: approx. 125 - 3,150 rpm • Spindle stroke: approx. 180 mm • Table size: approx. 520x400 mm Pgsdpfx Ajzvrmljftjr • Year of manufacture: 1979 • Weight: approx. 360 kg • Coolant pump can be connected • Condition: Used, functional The machine can be inspected and tested at any time! Shipping costs via freight forwarder: approx. €190 International buyers are welcome! You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale ex works 42855 Remscheid, free loading. Errors in technical data and prior sale reserved.

Condition: good (used), Year of construction: 1989, machine/vehicle number: 8906756, functionality: fully functional, actuation type: pneumatic, overall weight: 84 kg, GRASS BBM /ST with adapter for BLUM fittings Row drilling unit – hinge plate drilling – drilling for base plates – drilling for press-in dowels – adapter for pressing in the hinge plates and base plates. Pedpfxozvn N Nj Aftegr

Condition: excellent (used), Year of construction: 2012, Horizontal conveyor 2500x410 mm year 2012 price: € 1,750.00 Podpfx Asznb Ebjftjgr contact: Mr. Rainer Eckerle
