Used Hole Punching Machine for sale (66,754)

Condition: good (used), Schuler PE4s 50/800 high-speed press  Manufacturer: Schuler   Type: PE4s 50/800 High speed press 61/21 600/3 pressing force: 50 t throat depth: 800 mm Stroke rate /min: 125-300 slide stroke: 40 mm Kohler decoiler 500.1 M After the purchase you will also get the documentation We sell a large number of paternosters. In addition to approx. 50 paternosters, there are countless other machines available. After purchase the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying. Fpodpfx Akogryc No Uol Financing through our bank is also possible. komplett-konzept.leasingo.de Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: ready for operation (used), Drilling diameter: 3-25mm, drilling depth: 1000mm, connected load: 36kW, control: EST, 99 drilling memory positions per program, grinding and coordinate programming, plain text programming via input mask. Accessories: paper band filter, coolant cooling system, 4-door control cabinet, high-pressure pump up to 150bar, oil tank, 1 steady rest for smaller diameters at large drilling depths, direction-adjustable holder for drill bushing holders, various drill bushing holders, long clamping table for 0-height, tailstock stop and base plate for machine vice freely movable on the additional table, matching precision machine vice optionally available. Speed, high pressure, Z-axis (feed), X/Y-axes, and W-axis (approach slide) programmable via control. CPU and card rack defective (fan fault), machine therefore not operational, drives and guideways were fully functional until last operation. An on-site inspection is possible. Fpodeylbrqjpfx Ak Usl

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, total height: 4,700 mm, ram adjustment: 100 mm, installation height: 550 mm, table height: 1,200 mm, total width: 1,700 mm, total length: 2,700 mm, table length: 2,100 mm, table width: 1,000 mm, pressing force: 200 t, control cabinet height: 2,245 mm, control cabinet width: 2,400 mm, input voltage: 400 V, distance between side stands: 520 mm, distance between stands: 2,100 mm, overall weight: 48,000 kg, year of last overhaul: 2025, input frequency: 50 Hz, ZEULENRODA Punching and Forming Machine - Cast Iron Version - HR 200-2000 NL The punching machine is sustainably manufactured as a new machine, using carefully inspected, reusable cast iron components (table, headstock, and side supports). Press ram newly manufactured in a vibration-damping cast iron design. Fsdpfx Akszu Avbe Ujpl Drive system with a compact drive unit and a 2-connecting rod power transmission. • Total pressing force 200 t • Stroke rate 30...120 min-¹ • Working capacity 29 kNm • Ram adjustment 100 ±0.01 mm • Ram stroke, adjustable 30 - 150 mm • Press force monitoring • Hydraulic overload protection • Main control panel + Two-hand control panel • Hardware and software interface for strip lubrication / roller feed / strip coiler • Control system SIEMENS S7-1500 • Remote maintenance

Condition: like new (used), functionality: fully functional, Hydraulic punching machine Brand: Boschert Model: Ecco Line EL 500 Digital Features: Punching force: 28 t Fpjdpfern Swksx Ak Uel Work table dimensions (width x length): 500 x 1000 mm Maximum sheet thickness: 6 mm (up to a punch diameter of 40 mm) Maximum die diameter: 105 mm (up to 1 mm sheet thickness) Maximum number of strokes: 180 strokes/min Switch-on value: 5 kW Voltage: 3 x 400 V / 50 Hz Total weight: 2 tons Dimensions of the EL-500-Digital punching machine (length x width x height): 2400 x 1580 x 1540 mm Tool cabinet, 4 tool drawers Foot pedal Includes all the accessories shown in the pictures.

Condition: used, Year of construction: 1996, functionality: fully functional, Italian-built C-frame eccentric press by S. Giacomo srl, Vittorio Veneto. CE certified. Year of manufacture: 1996, serial no. 6759. Rated at 130 metric tons (1,300 kN nominal force) with adjustable stroke 14–200 mm and max 55 strokes/min. Supplied complete with a Festo BV-200-250-C pneumatic feed unit — a heavy-duty pneumatic clamp feeder with 200 mm width and 250 mm max feed length, operating on filtered compressed air at 3–6 bar. Suitable for strip/coil feeding in progressive die and blanking operations. Weitere Gebrauchtmaschinen von Mabu, Bruderer, Bihler und Schaal stehen in unserem Lager zum Verkauf. Technical Specifications Model: T 130R CE Serial: 6759 Year: 1996 Nominal force: 1,300 kN (130 t) Stroke (adjustable): 14–200 mm Stroke rate: 55 spm max Installed power: 9.25 kW Main voltage: 400 V Air pressure: 5.5–6 bar Fpsdpfozg U R Ijx Ak Uel Weight: 10,000 kg CE certified: Yes Feeder – Festo BV-200-250-C: Type: Pneumatic clamp feed unit Max feed length: 250 mm Max width: 200 mm Operating pressure: 3–6 bar

Condition: used, Single-column – Eccentric press RICHTER Type PEKRS 80 Year of manufacture 1970 – Overhauled in 2024 Clamping force 80 tons Reach 350 mm Table size 900 x 650 mm Through-hole in the mounting table Ø 200 mm Ram area 700 x 500 mm Stroke rate 70 strokes/min Stroke adjustment 6 – 100 mm Ram adjustment 85 mm Installation height max. 400 mm Arbor hole Ø 50 mm Table height above floor 810 mm Motor power 8 kW Power connection 400 volts, 50 Hz - Pneumatic clutch-brake combination ORTLINGHAUS - Press safety valve HERION XSz 32 - Pneumatic ram balancing cylinders - Overload protection with shear plate in the ram - Grease central lubrication with hand pump Space requirement L x W x H 1800 x 1250 x 2830 mm Weight 5.7 tons Very good condition Technically overhauled and converted to the latest safety standards with new electrical system Control system rebuilt in 05/2024 – suitable for manual feeding operations – Fedpfx Akji Db Ibe Uopl in accordance with DGUV Information 209-030 Press Inspection and Machinery Directive 2006/42/EC Low Voltage Directive 2014/35/EU EN ISO 16092-1: Safety of machinery - Presses - Part 1: General safety requirements EN ISO 16092-2: Machinery - Safety of presses - Part 2: Mechanical presses - Control system with plain text error messages and diagnostic screen for quick fault localization - New electrical cabinet, mounted on the side of the machine - Completely based on SIEMENS, with S7-1200 PROFIsafe PLC and 7" TFT touch display - Two-hand control panel with emergency stop and interlocking - Electric foot switch - Cam mechanism with run-on monitoring - Stroke release via press safety valve HERION XSz 32 with pneumatic pressure gauge - Rewiring of the machine - Updated operating manual The machine is equipped with 6 operating modes: 1 = Setup 2 = Single stroke, two-hand 3 = Single stroke, foot 4 = Continuous operation, foot 5 = Automatic continuous operation 6 = Reverse operation

Year of construction: 1980, condition: ready for operation (used), A Gebrüder Irle CNC large-format deep-hole drilling machine is available. Drilling capacity steel: 40mm, max. drilling depth: 1600mm, drill spindle adjustment: 350mm, vertical drilling unit adjustment: 700mm, power: 30kW, speed: 2940rpm, field range constant power: 1-3, armature range constant torque: 1-35, max. drill spindle torque: 1500Nm, rated speed: 163rpm, spindle flange diameter: 200mm, quill diameter: 2000mm. Feed: 500mm/min, rapid traverse: 1200mm/min, max. feed force: approx. 34.3kN, display: 0.005mm, vertical adjustment travel: 700mm, longitudinal adjustment travel: 13000mm, transverse adjustment travel: 650mm, swivel: 85°. Clamping plate dimensions X/Y/Z: 12500mm/1000mm, guide bed dimensions X/Y: 3350mm/455mm, controls: Heidenhain TNC 310. Documentation available. An on-site inspection is possible. Fsdpfx Aksy Rtfzs Uepl

Condition: good (used), Year of construction: 2005, machine/vehicle number: 4222559205002, Offer 25437 Technical Data: - Pressing force: 500 kN - Stroke infinitely adjustable: 10 - 32 mm - Strokes per minute: 22 - 27 1/min Fjdpfxjx S Ehwe Ak Uspl - Throat depth: 510 mm - Installation height: 350 mm - Drive: 400 V / 4 kW - Punching, for example: up to 27 mm Ø in steel: 14 mm - With special punching saddle, e.g.: up to 39 mm Ø in steel: 9.5 mm - e.g. up to 90 mm Ø in steel: 4 mm - Dimensions (approx.): W 700 x H 1700 x D 1200 mm - Weight (approx.): 1150 kg - Equipped with: - Hydraulic low-pressure centre punch locator - Extended punch holder for punching in section steel - Roller conveyor with gripper feed, control PEHU 101 - Roller conveyor approx. 6000 mm - Foot switch - Emergency stop button

Condition: good (used), Offered here is a multi-spindle drilling machine from Knoevenagel. Specifications: Table size: 58 x 43 cm (with a scale from 0-50 cm) The table is height-adjustable and can be tilted. VGC 18809 420 V, 4.0 A Fjdpfod Sdurox Ak Uspl 15 spindles Please refer to the images for all further information and details regarding the condition.

Condition: good (used), Year of construction: 2014, functionality: fully functional, Sheet width: 3000 mm Sheet length: 1500 mm Sheet thickness: 8 mm Workpiece weight: 200 kg Punching force max.: 220 kN Total power requirement: 9.5 kW Space requirement approx.: 7395 x 6540 x 2072 mm Equipment: Punch head: - Hydraulic single-tool chuck with 360° rotation - Manually adjustable clamping force Fodpjy Sak Tjfx Ak Uopl - Programmable clamp (active/passive/re-positioning) - Spray lubrication for punch - Stroke counter for punch - Level monitoring for threading and tool lubrication Control system: - Open control system based on Sinumerik 840 D - 12" TFT color display - Teleservice via internet - Automatic shutdown Data transfer: - USB interface - RJ-45 network connection Safety: - CE marking - Dual light curtains - Rapid shutdown of hydraulics - Bulge detection Programming: - TruTops Punch via network access 1 x MultiTool function 1 x MultiShear function 1 x Thread forming function 1 x Deburring and rolling technology 1 x SoftPunch function 4 x individually openable clamping jaws 4 x height-adjustable clamping jaws 1 x Re-positioning cylinder 1 x Sensor for stripper (included in rest material-free processing) - GripMaster - Rest material grippers with sensor technology - Shear lift table 400 mm - Tilting rest material pallet 3000 x 1500 mm - SheetMaster - Operating hours: 65,000 h

Condition: excellent (used), Year of construction: 2021, functionality: fully functional, Slot drilling machine, like new, hardly used. Fpsdpfxsy Tk Ufs Ak Uol

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Fsdpfsrtrx Rjx Ak Uspl Siemens 840D Control (2) Drill Heads 20-Tool Rack HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: excellent (used), Year of construction: 2006, Bihler RM 40E stamping and bending machine Compact machine system for the production of stamped and bent parts from strip and wire. Quick tool clamping system User-friendly P CNC 4E machine and process control Compatibility with RM 35, RM40, and RM4 tools Item condition: very good Manufacturer's description, deviations possible. You are purchasing the machine as shown in the pictures. Type: RM 40E No. 27907 Year of manufacture: 2006 Fjdpfx Aksg Inzks Ujpl 1x 184-01-0022.0 Basic machine RM 40 including central lubrication and pneumatic system including P-CNC 4E control according to installation plan 184-00-0085.3 including tool: 484 0027 2x 142-04-0347.0 Wide slides (items A9 and A16) 1x 142-55-0007.0 Angle lever unit with right lever (item A7) Without feeder, press, and center punch including light barrier for personnel protection Financing through our bank is also possible. komplett-konzept.leasingo.de You can find more items - new and used - in our shop! International shipping costs on request!

Condition: used, Punching tool, punching stamp, sheet metal punch with tension screw, hand punching tool, screw hole punch, sheet metal punch square Fjdpfx Aket Hmi Ao Uspl -Manufacturer: RUS, square hole punch with tension screw -Size: 69 x 69 mm -Total dimensions: Ø 128 x 120 mm -Weight: 4.8 kg

Condition: good (used), Year of construction: 1979, total height: 1,805 mm, total width: 1,700 mm, total length: 2,090 mm, sheet thickness steel (max.): 3 mm, working range: 960 mm, overall weight: 1,200 kg, Copy nibbling machine PIONIER K 1200/6, steel capacity 6 mm, circular nibbling up to Ø 500 mm, throat depth 1220 mm, throat height 200 mm, working length 960 mm, motor 1.3 / 2.2 kW, stroke 10 mm, dimensions 2090x1400x1800 mm, weight 1200 kg, operating manual Fedpfxeyq Savo Ak Uopl

Condition: good (used), Year of construction: 1989, functionality: fully functional, pressing force: 30 t, We offer this good Bihler GRM 80 punching and bending machine, year of construction 1989. with 5 slides, 30T press, straightener, feeder Fjdpfx Akoywty Eo Uspl with decoiler Tooling is not included If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 1998, Haffner Door Lock Mortising Machine used, in good condition Manufacturer: Haffner Model: SL 100 Machine No.: 5372 Column-type machine Chain mortising unit Door support Workpiece support Spindle for lever hole Spindle for faceplate Lubrication device Extraction port D 80/100 mm Fedpfoyuty Sjx Ak Uopl Required space approx. 1200 mm x 700 mm x 2000 mm Weight approx. 300 kg Location: 54634 Bitburg Delivery in as-inspected condition, without warranty or guarantee

Year of construction: 1984, condition: good (used), Bihler RM 40 (1984) - Multislide punching stamping bending former Fodpfxeh T Ulye Ak Ujpl Machine is shown with 5 slides, however, a 6th one is available. Several pay-offs for strip or for wire are available. Machine with 8-tons press and 5 or 6 slides - hydraulic clamping for wire or strip. One machine if fitted with a additionnal feeding system from the back of the machine, thru the center hole

Condition: used, Year of construction: 2002, functionality: fully functional, stroke length: 2,600 mm, overall weight: 12,000 kg, punching force: 20 t, Amada Europe 2510 machine, in perfect working condition. Sheet metal working dimensions: 3500 mm x 1500 mm, with thicknesses up to 5 mm. Equipped with a fully operational automatic loading system. Fjdpfx Akjywwzto Uepl

Condition: used, MURATEC WIEDEMANN MOTORUM 2048 CNC TURRET PUNCH MACHINE MAKE MURATA WIEDEMANN, MADE IN JAPAN MODEL MOTORUM 2048 CONTROL FANUC 30i TOUCH SCREEN YEAR 2016 CAPACITY 20 TONS SHEET SIZE (WITH ONE REPOSITIONING) 1250mm x 2500mm SHEET THICKNESS MAX. 6.35 mm Y, X STOKE Y AXIS: 1360.0 mm X AXIS: 2550.0 mm PUNCHING ACCURACY +- 0.1mm THROAT DEPTH 1340.0 mm MAX ALLOWABLE SHEET WEIGHT 150 KG Fpjdpfxexvch Tj Ak Ujl HIT RATE 1.0T 25 mm PITCH 8.3 mm stroke: 355 HPM 0.5 mm PITCH 1.4 mm stroke: 900 HPM SIMULTANEOUS AXIS SPEED 125 m/MIN PUNCHING ACCURACY +- 0.1 mm TURRET INDEX SPEED 35 RPM COMPRESSED AIR QUANITY: 100NL/MIN PRSSURE: 0.5 MPa POWER SUPPLY 19 kVA PLUS GOOD SET OF TOOLING ONE OWNER FROM NEW VERY LESS HOURS SAFETY GUARDS

Condition: used, Used machine Used row drilling machine of the company Ganner type RB 107 Fjdpfxew I Unwj Ak Uopl serial no.: 121627 Motor power: 1,5 kW Motor speed: 2800 rpm 1 drill beam with 26 spindles, center distance 32 mm 3 hold-down devices 1 foot switch Availability: short term Location: Röllbach

Condition: good (used), Hoza EMU punch This machine is ideal for punching out small molded parts from paper, rubber or textile goods. It has a high pressing force and fits on any stable table. The cut is initiated via a two-hand safety control. Forged blades or steel rule blades can be used in the machine. Knife stroke: 30 mm Max. punching format: 150 x 100 mm Weight: approx. 150 kg Color: hammer blow blue Dimensions: 450 x 360 x 600 mm Further items in other sizes - new and used - can be found in our store! Fpodpfxeuzhmts Ak Uel International shipping costs on request!

Condition: used, Year of construction: 2004, sheet width 1000 mm plate length 2000 mm Fjdpfx Aksyi Hpcs Uopl plate thickness 6 mm Punching capacity 280 kN Control Boschert connected load 18 kVA fuse 3 x 20 A total power requirement 15 kW weight of the machine ca. 11 t dimensions of the machine ca. 4,5 x 2,8 x 2,0 m Multi-tool various stamps / dies Software / Dongle Metalix cncKad V10

Condition: good (used), Year of construction: 2007, functionality: fully functional, drilling depth: 1,150 mm, overall weight: 12,000 kg, drill diameter: 32 mm, Heidenhain iTNC530 cnc control 12-fold tool changer Technische Daten / technical details: Wege: / travels: X-Achse längs (Tisch) / X-axis longitudinal (table) 1800 mm Z-Achse quer (Ständer) / Z-axis cross (column) 1700 mm W-Achse quer (Bohreinheit) / W-axis cross (drilling unit) 1150 mm Y-Achse senkrecht (Bohreinheit) / Y-axis vertical (drilling unit) 1200 mm B-Achse (Rundtisch) / B-axis (rotary table) 360 ° Fjdpfx Akswcldaj Uspl A-Achse (Bohreinheit) / A-axis (drilling unit) -25 - +15 ° Bohrbereich-Tiefbohren (ELB): / drilling area-deep drilling (ELB): Durchmesserbereich / diameter range 6-32 mm max. mögliche Bohrtiefe / max. drilling depth 1150 mm Antriebsleistung / drive capacity 40 kW Gewicht der Maschine ca. / weight ca. 12000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. For more technical details please look at the photos

Condition: used, Punching tool, punching stamp, sheet metal punch with tension screw, hand punching tool, screw hole punch, sheet metal punch square -Manufacturer: RUS, square hole punch with tension screw Fpedpfxjt Hmivj Ak Uol -Size: 90 x 90mm -Total dimensions: Ø 157 x 135 mm -Weight: 6.8 kg
