Used Facing Slide for sale (9,003)

Condition: used, Year of construction: 1973, spindle diameter 140 mm x-travel 2000 mm y-travel 2000 mm z-axis 1500 mm spindle stroke - max. 800 mm spindle taper ISO 50 table surface area 1800 x 1500 mm table load 15000 kg turning speed range 2,3 - 810 U/min total power requirement ca. 30 kW Ksdpfx Ajy Umc Ujh Eodt weight of the machine ca. 31000 kg dimensions of the machine ca. 7300 x 5600 x 4000 mm Equipment: - Faceplate with NC facing slide and NC rotary table - Heidenhain digital readout - Various tool holders - Various clamping devices

Condition: good (used), Machine number: 8025 Type / Model: DZFG 200 x 500 Control: conventional Centre distance: 500 mm Spindle bore: 32 mm Centre height: 160 mm Swing diameter over bed: over cross slide: 315 mm 200 mm Speed range: 56 to 2,800 rpm Feed long: face: 0.02 to 0.8 mm/rev 0.01 to 0.4 mm/rev Connection: 5.5 kW Accessories / Equipment: Condition: good Kdjdpfxoykt Dve Ah Ejt Weight: 1.9 t Dimensions: 2,100 x 1,100 x 1,400 mm

Condition: used, Year of construction: 1973, spindle diameter 130 mm x-travel 3000 mm y-travel 2000 mm total power requirement 4,5 kW weight of the machine ca. 30 t Spindle Ø 130 mm Spindle taper SK 50 Working range: X = column, longitudinal 3,000 mm Y = headstock, vertical 2,000 mm Z = spindle stroke 1,000 mm Lower table 3,300 x 2.400 mm Max. weight on table 10 tons/m² Min./ max position of work spindle above table 770 / 2,770 mm Feeds 0.9 - 2,000 mm/min Quick feed for headstock and column 5,000 mm/min Quill feed 0.5 - 1,200 mm/min Speed range, partially infinitely variable 4.5 - 1,250 rpm Weight, approx. 30,000 kg Accessories / Special Features * HEIDENHAIN Digital Display for 3 axes. Kedpfet Hwt Sox Ah Ejdt * Hardened guideways. * Ball screw spindles. * Infinitely variable spindle speeds and feeds. Feeds can be individually driven with motor. * Moving operating platform. * Hanging control panel. * Manual operating control. * Platform. * Hydrostatics in the column displacement. * Mounting plate 3,200 x 2,500 mm, planed, with t-slots. * Top table approx. 1,400 x 2,600 x height 900 mm, one face is handled. * Hydraulic clamping of column and slides. * Motor driven tool clamp. * Lots of accessories, including tool holders with and without tools, separate chip extractor, clamping aids, 1 angle plate, and other plates. Lots of other accessories. This is a strong machine which is very suitable for heavy cuts and therefore ideal for the machine tool industry and for tool manufacturers. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest. We have other horizontal borers on stock. Please let us know what you need.

Condition: good (used), Year of construction: 2010, functionality: fully functional, Technical details Kjdpfxezzwi Ns Ah Ejdt turning diameter 475 mm turning length 830 mm control HEIDENHAIN MANUALplus 620 swing diameter over slide rest 260 mm centre distance 1000 mm spindle bore 70 mm spindle turning speed range 1 - 3000 U/min feeds - cross 0,001 - 1000 mm/U feeds - longitudinal 0,001 - 2000 mm/U rapid travel - longitudinal/face 10 / 5 m/min tailstock quill diameter 70 mm tailstock quill stroke 120 mm tailstock quill taper MT 5 main drive (40 % ED) 25 kW weight of the machine ca. 2,9 t Additional information * Control HEIDENHAIN MANUALplus 620 * DXF conversion software (processing of contours in DXF format from CAD drawings) * Ethernet and USB interfaces inside the control cabinet * Coolant system (frequency-controlled), 1–4 bar * Glass scale for direct position measurement on the X and Z axes * 4-position PARAT quick-change tool holder, size 2, with several inserts * 3-jaw-chuck RÖHM ZS 200 * Roller guide for easier movement of the tailstock * 2 movable safety doors * Main motor fan control, temperature-controlled, for particularly quiet environments such as laboratory workshops and schools

Condition: used, Year of construction: 1977, spindle diameter 150 mm x-travel 4200 mm y-travel 3000 mm dimension of the ram 380x380 mm ram: horizontal adjustment 500 mm spindle travel 1200 mm Radial face slide diameter 780 mm radial face slide travel 250 mm rotary table: Defum type S-1600 Table dimensions 1500x1500 mm table travel 1100 mm Serial no .: 6749, optional: Kdodpfx Ahjyuttxs Est floor plaates (Plattenfeld) The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, L & Z Lathe / DREHMA D 410x1500 / New - Unused / Showroom Machine -CE marking -3-axis digital display -Turning diameter over bed: 410 mm -Turning diameter over cross slide: 225 mm -Turning diameter in the crotch: 580 mm -Turning length: 1500 mm -Spindle bore: 52 mm -Speed range (geared): 45 - 1800 rpm -Automatic longitudinal/facing feeds -Threading / Metric / Inch etc. -Tailstock MK 4 -Drive power: 3.5 kW -Central lubrication Kdjdpfx Ajzv H Ikjh Est -Electric chuck guard -Chuck guard via steel support -Fixed and traveling steady rest -Multifix base with inserts -3-jaw chuck 200 mm -4-jaw chuck 250 mm -Faceplate -Coolant system -Work light -Foot brake -Traveling center & drill chuck -Machine feet -Documentation Dimensions: L x W x H 2.2 x 0.1 x 1.6 meters / Weight 1850 kg Errors and omissions excepted.

Condition: used, overall weight: 16,000 kg, first registration: 01/1999, loading space length: 5,394 mm, loading space width: 2,489 mm, loading space height: 2,576 mm, Year of construction: 1999, Equipment: crane, GLEICH VEHICLE CONSTRUCTION PR.+PL. ? ATLAS AK 190.1 ? 16.3M CRANE? ----VEHICLE HISTORY GERMAN VEHICLE VIDEO AVAILABLE UPON REQUEST 2 UNITS AVAILABLE / 1 WITH FASSI CRANE / 1 WITH ATLAS CRANE ----VEHICLE EQUIPMENT ----VEHICLE DATA GROSS VEHICLE WEIGHT: 16,000 KG OVERALL LENGTH: 7,450 MM ----CRANE PLATFORM MOUNTING POINTS: APPROX. 5.86 M ----CRANE SUPERSTRUCTURE ATLAS CRANE MODEL: AK 190.1 A4 YEAR OF MANUFACTURE: 1999 MAXIMUM WORKING PRESSURE: 300 BAR MAXIMUM LIFTING CAPACITY AT 2.2 M OUTREACH: APPROX. 6,550 TO 7,400 KG MAXIMUM OUTREACH: 16.3 M WITH APPROX. 710 TO 770 KG LIFTING CAPACITY CRANE OPERATED VIA SEPARATE DIESEL ENGINE ----BODY FLATBED WITH CURTAIN SIDE MANUFACTURER: Gleich Fahrzeugbau GmbH FLOOR MADE OF APPROX. 30 MM WATERPROOF BONDED FILM FACED PLYWOOD SIDE PANEL HEIGHT: 800 MM SIDE WALLS FOLDABLE AND REMOVABLE FIXED FRONT WALL REAR WITH DOUBLE DOORS AND BAR LOCKING MECHANISM LASHING POINTS INTEGRATED INTO EDGE PROFILE SUBFRAME MADE OF STEEL, AUXILIARY FRAME ACCORDING TO DIN EN 283 284 ----TARP/CURTAIN ROOF COLOUR APPROX. RAL 9010 SLIDING CURTAIN LIGHT GREY SLIDING ROOF, SIDEWAYS OPENING FRONT AND REAR ----INTERNAL DIMENSIONS LENGTH: 5.4 M HEIGHT: 2.57 M WIDTH: 2.49 M ----CONDITION UVV INSPECTION OF LOADING CRANE PERFORMED NO SAFETY-RELATED DEFECTS FOUND CRANE FULLY FUNCTIONAL CRANE REMOTE CONTROL AVAILABLE ----EXPORT SALES ONLY WITH DEPOSIT (MINIMUM 500 – 2000 €) EXPORT SALES ONLY WITH DEPOSIT MIN. 500 – 2000 € CUSTOMS EXPORT CLEARANCE (EXW) WITHIN 10 MIN. (APPROVED EXPORTER) 5-DAY, 30-DAY PLATES, AND 17–21 DAYS AUSTRIAN PLATES, EURO 1 Kjdpfxjx S Tmne Ah Eodt VEHICLE RESERVATIONS ONLY VIA E-MAIL FUNCTION VERBAL RESERVATIONS ARE NOT VALID! A deposit of at least 500.00 € / 1,000.00 € is required for sales to EU or third countries. (For sales to the EU and third countries, a deposit/guarantee of at least €500.00 / €1,000.00 will be levied.) Subject to changes, errors, and prior sale! See more vehicles on our homepage: Sale is exclusively subject to our terms and conditions – see homepage. Important note – Important information: Despite careful verification of all details in our listing, errors may occur. Some of these may be due to transmission errors in the systems of the various platform providers. Therefore, all specifications are made without guarantee and do not represent legally binding characteristics. Legal notice: This sales advertisement does not constitute an offer in the sense of §145 BGB. Rather, it is information provided for the initiation of a contract. All details are given without guarantee and do not constitute warranted characteristics.

Year of construction: 1983, condition: ready for operation (used), Turning diameter over bed/face slide: 630mm/340mm, turning length: 2000mm, center height: 290mm, clearance: 70mm, speed: 1180rpm, chuck: 400mm wedge bar chuck, tailstock: MK5, total power requirement: 15kW, machine dimensions X/Y/Z: approx. 5000mm/1350mm/1500mm, weight: approx. 4500kg. Including 2x 340mm steady rests, 2x medium steady rests, face plate with a diameter of 630mm, 2x face plates with cross slots, various tool holders, steady rest box, tool cabinet with additional tools, Heidenhain position indicator and 400mm key bar chuck. Documentation available. On-site inspection is possible. Kedpju Av E Hsfx Ah Eodt

Condition: like new (used), Year of construction: 1992, Lathe WEILER Precision center lathe in ergonomic design The Weiler Ergodor is the first German ergonomically designed lathe. It creates a more humane workplace and prevents health problems. The key feature is that the employee can operate this lathe while standing or sitting. Technical data Center width 470 mm Turning length 430 mm Center height 145 mm Rotation Ø over cross slide 160 mm Rotation Ø over bed 300 mm Kdjdpfx Ahevgqu He Ejt Spindle head, short taper flange Bayonet mounting DIN 55022 size 5 or Camlock clamping D 1-ASA-4 Spindle bore 36 mm DIN 55022 size 5 Spindle inner taper Spindle speeds Speeds 30 - 3550 rpm S Speeds 15 - 3550 rpm Brake motor 3 kW Brake motor 1.5/3 kW Face slide travel 150 mm Travel of the top slide 100 mm Feed rates and thread pitches on the gearbox switchable steps 30 Section 2 1.5/3 kW 38 Gear ratio in headstock 3 20 Long feeds 150 mm via change gears 100 mm via toothed belt Face feeds = 1/2 Longitudinal feed values Metric pitches 0.2 - 12 mm Module pitches 0.1 - 4 Dimensions 1450 x 640 x 1500 mm Dimensions 1450 x 640 x 1500 mm Net weight 1000 kg Acceptance according to toolmaker's accuracy DIN 8605 20 Built according to the rules of occupational safety, official test no. A. EM 11 1545/80. Encombrement 1450 x 640 x 1500 mm

Condition: good (used), Year of construction: 1991, Machine type Lathe - cycle-controlled Manufacturer WEILER Type E30 year of construction 1991 Control Weiler Country of origin Germany Additional information Cycle-controlled lathe WEILER - E30 Technical details Turning diameter max. 330 mm Turning length 750 mm Weiler control Center height 165 mm Swing diameter over bed 330 mm Max. turning diameter over facing slide 160 mm Face slide travel 180 mm Longitudinal bed slide travel 395 mm Kedpjr Dvqzefx Ah Esdt Main spindle: Speed range - main spindle 1 - 4,500 min/-1 Drive power - main spindle 9 / 11 kW Max. Torque 165 Nm Spindle head DIN 55027 / 5 Spindle diameter in front bearing 70 mm Spindle bore 40 mm Usable bar diameter ( - ) mm Tool holder: Type MultiFix Turning tool shank cross-section 20 x 20 mm Tailstock: Quill stroke 110 mm Quill diameter 50 mm Tailstock holder MK 3 Feed rates: Rapid traverse max. 10 m/min Feed force 6 / 3 kN Feed range 0 - 20 mm/-1 Thread cutting: metric 0.1 - 400 mm Inch 1/4 - 56 G/1" Module 0.125 - 28 mm.II DP 1 - 224 G/".II Number of threads max. 50 Total power requirement 10 kVA Machine weight approx. 1.5 t Space requirement approx. 2.8 x 2.0 x 2.0 m

Condition: used, Year of construction: 2020, max. workpiece length 6360 mm profile spindle 1 Stück main drive 13 kW Control Maestro SCM CNC Machining Center ACCORD 40 FX for windows and doors ----- Available as an OPTION at an additonal cost of 20.000 Euro: extensive window and door tooling among others (window cutting available upon request!): Wooden windows IV 68, 78, 92 Wooden "style" windows Wood-aluminum windows Front doors Lift-and-slide doors Box windows Machine still in operation, available for viewing! Technical Summary (detailed description available upon request!): ----- - ??Working area X-Y = 6360 x 1905 Z = 350 - Automatic table with 8 support rails MATIC - L1825 - 5-axis spindle MAXI - Prisma T, HSK 63 E, 13 kW - RTCP Setting - Self-calibration system for Prisma work unit - Adjustable chip removal device on the electric spindle - Preparation for "Prisma T-S" angle gearbox - BRC - Working unit: Saw blade for face machining, 1 vertical milling cutter connection 3 vertical, independent drill heads, center distance 32 mm 3 vertical drill heads (not independent), center distance 21.5 mm, for mortise drilling 4 horizontal drill heads (2 per side, not independent), center distance 21.5 mm 2 horizontal milling heads (1 per (Page) - TRC 48 - Rear Tool Magazine 48 tool positions (excluding tool holders) Center-to-center distance between positions: 104 mm Max. tool diameter: 350 mm Max. tool length: 320 mm Max. weight per tool: 10 kg (15 kg with HSK 63 E spindle) Max. total weight on the magazine: 250 kg Kedpfxjy Hl Iye Ah Eodt - MACH 5 - Quick-change system: Allows tool changes on the electric spindle in just a few seconds. - Pendulum operation - Automatic lubrication of the axes - eye-M operating console with integrated PC - Additional fixed control panel - TECPAD - Remote control of machine functions - Clamping jaw preparation H145 for worktable with 8 support rails - Front stop row H110 for worktable with 8 support rails - Rear stop row H110 for worktable with 8 support rails - Suction cup H110 145x145 mm - Swivel suction cup H110 145x55 mm - Swivel suction cup H110 180x65 mm - First side stop row H145 for worktable with 8 support rails Second side stop row H145 for worktable with 8 support rails Clamp H145 with round base Clamp H145 with square base N.6 Lifting devices with double stroke H145 Laser and reference stop H145 for sheet (left) - PRO-SPEED safety system - Maestro CNC - Machine operator interface and programming - Maestro ProView - Simulation software Tools are sold in the condition, scope, and with accessories as they are currently in stock. Note regarding window cutouts, tool drawings, and tool system listings: Engelfried GmbH does not guarantee that the tools actually available correspond to the systems listed and drawn. (Technical specifications according to the manufacturer - without guarantee!)

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Weiler Praktikant VCD Precision Lathe (2021) Manufacturer: Weiler Model: Praktikant VCD Precision Lathe Year of manufacture: 2021 Condition: Used, excellent, like new, incl. new maintenance and measurement protocol prior to sale Centre distance: 650 mm Kdedpsztyrqefx Ah Eot Centre height: 160 mm Swing over bed: 320 mm Swing over cross slide: 190 mm Cross slide travel: 150 mm Top slide travel: 110 mm Top slide swivel range: +/-65° Bed saddle guideway length: 350 mm Bed width: 205 mm Tool shank cross-section (H x W): 20 x 20 mm Height from top slide to turning centre: 30 mm Spindle head according to ISO DIN 702-3 (DIN55027) size 5 Spindle diameter in front bearing: 70 mm Spindle bore: 43 mm Main spindle taper metric 50 Drive power: 6 kW Speed range: 30 – 4,000 rpm Number of gear stages: 1 Number of speeds: stepless Number of feeds: 24 Longitudinal feed: 0.02 – 0.63 mm/rev Facing feed: 0.006 – 0.2 mm/rev Quill diameter: 40 mm Quill stroke: 85 mm Quill taper: 3 Morse taper Weight, without packaging and accessories: approx. 1,150 kg Dimensions (L x W x H), net: 1,720 x 890 x 1,700 mm Headstock / Rear cover / Sliding guard: Light grey RAL 7035 Machine base / Machine bed: Basalt grey RAL 7012 Display housing: Blue NCSS 4550-R80B

Condition: as good as new (ex-display), Year of construction: 2025, functionality: fully functional, machine/vehicle number: 2025-09/2404095, turning diameter over cross slide: 224 mm, spindle bore: 51 mm, center height: 180 mm, quill diameter: 32 mm, quill travel distance: 100 mm, total length: 1,680 mm, total height: 1,400 mm, TECHNICAL DATA: Centre distance: 1000 mm Centre height: 180 mm Swing diameter over bed: 360 mm Swing diameter over cross slide: 224 mm Swing diameter without gap bridge: 502 mm Gap bridge length: 235 mm Cross slide travel: 170 mm Top slide travel: 95 mm Max. turning tool cross section: 16x16 mm Chuck mounting: D1 - 4 Spindle mounting (lathe spindle): MT 6 Spindle bore: 51 mm Spindle speed: 70 - 2000 rpm Number of speed ranges: 8 Longitudinal feeds: (32) 0.052 - 0.392 mm/rev Cross feeds: (32) 0.014 - 0.380 mm/rev Metric thread pitch: (26) 0.4 - 7 mm Metric module threads: (26) 0.4 - 7 mm Inch threads, TPI: (34) 4 - 56 TPI Inch module threads, TPI: (34) 4 - 56 TPI Leadscrew pitch: 4 mm Leadscrew diameter: 32 mm Quill mounting: MT 3 Kedpfoxykafox Ah Ejdt Quill diameter: 32 mm Quill travel: 100 mm Motor power: 1500 W Coolant pump: 40 W Electrical connection: 400/50 V/Hz Total length: 1680 mm Total height: 1400 mm Weight: 520 kg Standard accessories: - RÖHM 3-jaw chuck Ø 200 mm - 4-jaw faceplate chuck Ø 200 mm - Face plate Ø 320 mm - 2 fixed centre points - Live centre MT 3 - Travelling steady - Fixed steady - Quick-change tool post set ME - Thread dial and change gear set - Halogen machine lamp - Emergency stop button / No-voltage release - Chuck guard with safety switch - Machine base / chip tray / splash guard - Tool kit / operating manual / CE

Condition: used, Year of construction: 1981, x-travel 650 mm y-travel 450 mm workpiece height 585 mm Control ADCOS CNC 400 total power requirement 15 kW weight of the machine ca. 5000 kg dimensions of the machine ca. m H A U S E R (Switzerland) CNC Controlled Hi Precision Double Column Jig Grinder Model S 40 – CNC 311 / ADCOS 400 CNC Year 1981 / CNC modernized in 2008 # 0126 _____ Table size approx. 630 x 770 mm Table load capacity approx. 500 kg Table travel longitudinal max. (X) 650 mm Grinding head slide cross max. (Y) 450 mm Vertical adjustment of cross rail max. (W) 500 mm Grinding spindle stroke max. (Z) 140 mm Stroke number of grinding head (4cycles) 0,5-12 m/min. Kdsdpfx Ahst Hw S Uj Ejt Vertical distance between Table/grinding spindle 0-585 mm Distance between columns 750 mm Conical grinding max. 16 ° Grinding-Ø bore approx. 230/360 mm 18 spindle speeds depending on spindle motor infinitely variable 4.500-80.000 rpm Fine feeds in X and Y-axis and W-axis 0,5-1.500/3.000/800 mm/min. Planetary speed (C) 5-250 rpm U-axis, radial feed 6 mm Total electrical load approx. 15 kW - 400 V – 50 cycles Weight approx. 4.500 kg Accessories/ Special Features: • CNC Pathcontrol replaced and modernized into a ADCOS Control Model CNC 400, (German Manufacturer) including large monitor and relevant software, electronic handwheel, for following axis: X=Table length, Y= spindlehead carriage cross, Z= Quill vertical/stroke, C=Quill-Rotation,U=Circular Infeed, w=Vertical adjustment of cross rail. • Z-axis as rapid stroke for shorter processing times, plunge-cut grinding, face grinding, Pre-selection of reversing stops (start movement + teach-in) and of stroke speed (infinitely variable), • U-axis as manual and controlled feed-axis radial, mounted on grinding head, with electr.display of feeding size 1 Grinding motor mounted on spindle, maybe up to a spindle speed of 30.000 rpm, • Mounted accustic grinding contact-display device KSV 5 • Separate standing coolant facility, switching- and control cabinet, separate hydraulic system, central lubrication system, dust suction, etc Condition : very good / can be inspected under power Delivery : ex stock – as inspected Payment : net – after completion of contract

Condition: like new (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: 25582, Equipped with: Fanuc 30ia Control Hydraulic System Coolant System Chip Conveyor Pneumatics Lube System Jib Crane Change Gears Mist Collector Transformer Work Light Stack Light Specifications: Extreme Ratio: 10:1 Root Angle Range (B-Axis): -5 deg. TO 90 deg. Equivalent Root Angle Range: -8 deg. to 90 deg. (Equivalent refers to cradle type machine.) Face Hobbing: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -152 mm TRI-AC Cutter w/13 Blade Groups Max. Full Depth: 0.550" Max. Face Width: 1.6" Face Milling: Examples of Maximum Gear Pitch Diameter -35 Degree Spiral -7.5" Diameter Cutter Max. Full Depth: 0.625" Max. Face Width: 1.6" Max. Swinging Base Travel (B-Axis): -5 deg. to 90 deg. Max. Vertical Travel (Y-Axis): -4" to 7" Max. Horizontal Travel (X-Axis): -6" to 4" Sliding Base Travel (Z-Axis): 2" to 12" Machine Center to Work Spindle Face (Fixed): 4.5" Tooth Number: 5 to 200 Inclusive Cutting Diameters: Conventional Face Milling: 1.1" to 7.5" Helixact: 100mm to 200mm Fine Pitch: 102mm to 152mm Coarse Pitch: 152mm only Speeds: B-Axis--Swinging Base (Degrees per Second): 30deg./sec. A-Axis--Work Spindle (Face Milling)(RPM): 0-75 A-Axis--Work Spindle (Face Hobbing)(RPM): 0-375 C-Axis--Cutter Spindle (RPM): 30-500 X-Axis--Horizontal (Inches per Second): 4.92"/sec. Kedpfx Ahezn Aymj Eedt Y-Axis--Vertical (Inches per Second): 4.92" Z-Axis--Sliding Base (Inches per Second): 4.92"/sec. Work Spindle: Diameter of Taper at Large End (#39 Taper): 3-29/32" Taper per Foot: 39/64" Depth of Taper: 3" Floor Space: 95.75" x 63.5" Height (less mist collector): 90.75" Approx. Weight: 22,000 lbs

Condition: ready for operation (used), Year of construction: 2007, operating hours: 1,688 h, functionality: fully functional, machine/vehicle number: G3138-0826, turning diameter over cross slide: 375 mm, turning diameter: 590 mm, spindle speed (max.): 3,000 rpm, travel distance X-axis: 220 mm, travel distance Y-axis: 750 mm, controller model: Fanuc 21i-T, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Spindle speed max.: 3,000 rpm Turning diameter over bed: 590 mm Turning diameter over slide: 375 mm Distance between centers: 750 mm Spindle bore: 78 mm Travel in X-axis: 220 mm Travel in Z-axis: 750 mm MACHINE DETAILS Control model: Fanuc 21i-T Power: 22 kW Operating hours: 1,688 h Shipping weight: 6,100 kg EQUIPMENT Three-jaw chuck Kedpozza Uuefx Ah Esdt Chip conveyor Turret CE marking

Condition: used, Year of construction: 1969, rotary table diameter 1000 mm grinding height 500 mm grinding head - power requirement 15/5,5 kW total power requirement 30 kW weight of the machine ca. 18 t dimensions of the machine ca. m S I E L E M A N N (Germany) Hydraulic Rotary Table Internal and Face Grinding Machine with two grinding heads and with horizontal workpiece clamping Model RFsB 100 Year 1969 / fully reconditioned by the manufacturer in 1990 Kjdpfou Su Apox Ah Esdt _____ Max workpiece Ø 1,000 mm Max. height of workpiece, approx. 400 mm Mounting height under grinding spindles approx. 500 mm Grindable Bore Ø, approx. 50 – 900 mm Max. Workpiece weight approx.. 900 kg Distance between Table bore and column 1.150 mm Table Ø / Face plate Ø, approx. 1,000 mm Table speeds, hydraulic, infinitely variable, right/left 5 – 60 rpm Table/workpiece infeed, 5 steps 0.0025 – 0.025 mm/stroke Table stroke approx. 500 mm Distance between grinding spindle and machine body 600 mm Surface Grinding Head Ø (Segmented wheel) 450 mm Grinding slides stroke, max. 500 mm Grinding slide speeds, infinitely variable 0.2 – 1 m/m Max. Internal Grinding spindle Ø 140/100 mm Grinding cup wheel Ø, up to approx. 200 mm Motor for Surface Grinding 15 kW / Motor for Internal Grinding Spindle 5,5 kW Total electrical load, approx. 30 kW - 380 V - 50 Hz Weight, approx. 18,000 kg Accessories / Special Features • The rotary table carries the workpiece and is also actuating the automatic grinding infeed • The relevant Grinding head can be swivelled in by turning the Column (hydraulic lift) so the workpieces can be ground in one setting with exact angles. • Built-on magnetic face plate, Ø approx. 1,000 mm, with 5 T-slots and stepless adjustment for the magnetism • Automatic workpiece infeed, with automatic depth stop. • Separate Height adjustment of internal grinding head, Grinding spindle Ø 100 mm. • Dressing devices mounted on each grinding head, Separate Switch Cabinet and hydraulic unit, • No Coolant Device available This machine is ideal for grinding bulky and heavy workpieces like housings, gears (!) bearing rings, cylindrical knives, etc. Condition: Good. Machine can be inspected soon under power Delivery : Ex stock as inspected. Payment : Net, after conclusion of contract.

Year of construction: 1992, condition: ready for operation (used), Turning diameter over bed/face slide: 420mm/280mm, turning length: 1000mm, spindle bore: 78mm, max. speed: 3550rpm, drive power: 35kW, tool positions: 12 (with driven tools), tool holder: VDI50, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 4100mm/2300mm/2200mm, weight: approx. 10000kg, control: Siemens 840T with C-axis. After a buffer battery replacement, the software of the machine was deleted, whereby some machine parameters were deleted without documentation and automatic operation is currently impossible. Expected to be available from Q1, 2025. Kjdpeu D H Hwefx Ah Eedt

Condition: like new (used), Year of construction: 1970, turning height: 4,000 mm, workpiece weight (max.): 100,000 kg, turning diameter: 17,000 mm, faceplate diameter: 5,000 mm, Universal machine 5-axis (turning, milling) Froriep 40KE 500/600-400 Spheromill Kedpfsym Ri Usx Ah Eedt Year of construction: 1970 (modernized 1984 and 2006) Control: Siemens 840D Milling length: 8500 mm Working height max: 4000 mm Maximum turning diameter: 17,000 mm Table diameter: 5000 mm Ram setting: -15 degrees to +90 degrees Table speed max: 40 rpm (100 kW) Maximum working load: 100 tons Accessories Milling head (800 rpm / 60 kW) Universal milling head (630 rpm) Facing slide for diameter max. 1000 mm Grinding equipment 90 degree angle head (630 rpm) 90 degree angle head (450 rpm) - small

Condition: excellent (used), Year of construction: 2002, functionality: fully functional, KRÜSI chalet building machine / log house production line type CM 40 Year of construction 2002 Krüsi CM40, consisting of the following components: Circular saw ( cross-cut saw ) Horizontal and vertical log house router Groove milling machine (horizontal) boring mill Infeed table 6m Outfeed table 6 m KRÜSI chalet building machine / log house production line type CM 40 Manufacturer Krüsi Maschinenbau AG CH-9105 Schönengrund AR Year of manufacture 1996 CE-marked Kdjdpfx Aozvrf Ijh Eot Ie Dkovfv Tfjk Ddfetk Condition: good, technically checked and cleaned / ready for use Functional principle Processing of wood for chalet construction / log house construction The beams can be processed in a single operation - Cutting to length - Horizontal and vertical milling of necks / grooves in one clamping operation - Drilling - Milling the face grooves Workpiece: - Cutting height max. 200mm - Cutting width max. 250mm Robust construction in welded design. Machine (horizontal and vertical milling unit) with 4 special milling motors, with hardened and ground guides for maximum machining accuracy. Slide guidance with dust-protected and preloaded ball-bearing rollers. Working range up to 200 x 250 mm. Completely ready for use, with contactor control, motors protected by thermal relay. Electrical equipment for voltage 380 V, 50 Hz, with protective covers, Central connection for on-site chip extraction, with 2 eccentric clamps, without milling tool (folder). With hydropneumatic horizontal and vertical feed, electrically controlled, together with the start-up of the milling motors. Rapid traverse and feed infinitely variable. Fully wired and installed, including air maintenance unit. Patches with a thickness of more than 14 cm must be processed in two tensions. Machine description / equipped with: 1. sawing unit: Manual feed Spindle adjustment with analog dimension display Saw blade-Ø max. / bore-o 400 / 30 mmm Carbide-tipped with cutting depth limiter (synchronous operation) Adjustable riving knife Motor speed min. 1 / 2900 Power kW 2.2 2nd CM milling unit ( log house unit ) Hydropneumatic feed Spindle adjustment with digital dimension display Horizontal trimming unit Milling cutter Ø 180mm Milling cutter width max.130mm From cutter width 60 mm only use aluminum alloy cutters with reversible cutting edges 2 hydropneumatic feed motors kW 2.2 each Hydropneumatic feed Rapid traverse and work feed infinitely adjustable 3rd drilling unit: Manual feed Spindle adjustment with analog dimension display Drill holder collet ER 25 Clamping Ø max. mm 16 Drill Ø max. mm 32 Motor min'1 1450, kW 1.8 4. face milling unit Hydropneumatic feed Spindle adjustment with digital dimension display Cutter Ø max. mm 230 Cutter width max. mm60 Motor min1 / 2900, kW 3.0 2 V-belts SPZ 9.5x1000 La Pneumatic Operating pressure on site min/max MPa (bar) 0.7/1 (7/10) Air consumption Nm3/h 8 Electrical system Operating voltage V / Hz 380, 50 Rated power kW 8.8 -15.8 depending on version On-site back-up fuse A 3 x 25 tr

Condition: used, Year of construction: 1992, spindle diameter 100 mm x-travel 1500 mm y-travel 1250 mm z-travel 1800 mm turning speeds 7,1-1120 U/min table surface area 1200x1200 mm w-axis 800 mm Radial face slide 600 mm radial face slide travel 200 mm digital readout Heidenhain The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. Kdodpfjyqvmyex Ah Eet About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), Benzinger TNL NCS1J Lathe  Manufacturer's machine data, deviations possible.  centre height: 80 mm max. turning length 100 mm max. turning diameter over. bed 220 mm max. revolving diameter over. face slide 140 mm max path length in x 300 mm max path length in z 240 mm Mains connection: 380 V 50 Hz Complete factory closure, Ksdpfx Aheg Icb Ee Eedt large selection of storage platforms, pallet racks, shelf racks, paternosters. High-quality industrial machines, lathes, grinding machines, hand machines. Financing through our bank is also possible. komplett-konzept.leasingo.de Further articles - new and used - you will find in our shop! International shipping costs on request!

Condition: used, Year of construction: 1973, turning diameter over bed 490 mm turning diameter over slide rest 280 mm turning length 2000 mm Kodpfx Aotqqvvjh Eedt centre height 245 mm centre distance 2000 mm spindle bore 62 mm total power requirement 7,5 kW weight of the machine ca. 3,5 t dimensions of machine L x W x H 3,78 x 1,17 x 1,42 m Accessories: 3-jaw chuck 240 mmø, face plate 400 mmø, MULTIFIX-tool post, solid steady, coolant

Condition: refurbished (used), Machine is located at our premises in Burscough. We welcome any inspections prior to sale. Spindle Diameter 4" / 101.6mm Spindle Taper 50 INT Kodpszwmrlofx Ah Eedt Main spindle travel 30" / 762mm Spindle speeds 10 - 1300rpm Vertical Y Travel - 48" / 1219mm Main Motor 25 HP Equipment - Facing head, outer (tailstock) steady Vast amount of tooling, rotary table, angle plates. DRO Pendant control This machine has undertaken a full machine rebuild and all slides re ground. Exceptional condition

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, spindle diameter: 100 mm, spindle speed (min.): 7 rpm, spindle speed (max.): 1,120 rpm, total height: 3,000 mm, total length: 6,000 mm, total width: 3,000 mm, table length: 1,250 mm, table width: 1,250 mm, type of input current: three-phase, spindle stroke: 900 mm, overall weight: 14,000 kg, year of last overhaul: 1999, Machine in excellent condition, used only for small operations. Condition of the slides: very good. Its green color is still the original. Functional and available quickly. Equipped with a Heidenhain visual display and measuring scale, on 4 axes: X/Y/Z/B. Tooling included with this machine: see the photos below. Great deal, priced below market value. Technical specifications: 🔹 Spindle Spindle diameter: 100 mm Spindle taper: ISO 50 Spindle travel (W-axis): 900 mm Rotation speed: 7.1 to 1,120 rpm Main motor power: 11 kW to 15 kW 🔹 Travels X-axis (Longitudinal): 1,600 mm Y-axis (Vertical): 1,120 mm Z-axis (Cross): 1,250 mm W-axis (Spindle travel): 900 mm 🔹 Rotary Table Table surface: 1,250 × 1,250 mm Maximum allowable load on the table: 3,000 kg (3 tons) Table rotation: 360° (manual or motorized) 🔹 Facing Head Facing head diameter: 600 mm Kdjdpfx Ahezunfbj Est Max. boring/facing diameter: 900 mm Facing head speed: 7.1 to 224 rpm Facing head slide travel: 210 mm 🔹 Dimensions and Weight Overall dimensions (L × W × H): ~ 6,000 × 3,000 × 3,000 mm Total machine weight: ~ 14,000 kg (14 tons)
