Used Extruder Gear for sale (6,876)

Condition: used, Year of construction: 2008, control Siemens 840D Ppsdpfowzypnex Ahvjp

Condition: good (used), Year of construction: 2002, max. wheel diameter 275 mm Ppjdpfxetumrps Ahvep gear width 55 mm max. module 6 min. module 1 Control 840 C Siemens total power requirement 100 kW weight of the machine ca. 16,7 t dimensions of the machine ca. 5,2 x 2,3 x 2,4 m m

Condition: good (used), Year of construction: 1998, spindle diameter 90 mm control Siemens SINUMERIK 840 C voltage 400 V stroke position adjustment 100 mm table hole 150 mm no. of strokes 100-1200 Hub/min weight of the machine ca. 8,0 t Key data Normal module: 6 mm Max. workpiece pitch circle diameter: 250 mm Max. tooth width (straight teeth): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance workpiece/jigging spindle: –80 mm to +320 mm Psdpfxjxyadte Ahvjpp Stroke position, stroke length Max. stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Stroke drive Stroke rates infinitely variable Standard: 100 to 1200 DH/min Motor for stroke drive: 9 kW Maximum cutting speed: 150 m/min Feeds Rotation axes (tool C1, workpiece C2 axis): Feed stepless relative to 100 mm pitch circle diameter: 1.0 to 9420 mm/min Radial axis (column slide X1 axis): Feed continuously variable: 1.0 to 9420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / weight Total connected load: 26 kVA Total weight (standard version): approx. 9,000 kg

Condition: used, max. wheel diameter 300 mm gear width 200 mm Pedpfx Ahjxu Nttovepp max. module 12 min. module 0,5 total power requirement 2 kW weight of the machine ca. 1 t dimensions of the machine ca. 0,8 x 1,2 x 1,5 m

Condition: good (used), Year of construction: 1975, max. wheel diameter 630 mm y-travel 560 mm gear width 180 mm max. module 8 min. module 1 workpiece dia. 750 mm table diameter 450 mm Ppsdpfjyb Sx Tsx Ahvjp draw-in arbor diameter 58 mm spindle stroke 200 mm adjustment range 230 mm distance between table/spindle 225-450 mm taper Morse 4 down feeds 0,03 mm/Hub roll feed 10n: 0,18-0,74 mm/Hub no. of strokes 12n: 47-300 Hub/min electrics - voltage/frequency 380/50 V/Hz weight of the machine ca. 5500 kg The machine was raised by 100 mm.

Condition: good (used), Year of construction: 1972, max. wheel diameter 80 mm gear width 60 mm max. module 3 Ppjdpfxow N S D Sj Ahvjp min. module 0,1 total power requirement 0,4 kW weight of the machine ca. 120 kg dimensions of the machine ca. 0,6x0,6x0,75 m

Condition: used, max. wheel diameter 40 mm gear width 45 mm max. module 1 clamping length max. 75 mm Ppsdsyh Rmgepfx Ahvjp number of teeth 5 - 399 hob turning speeds 320 - 3200 U/min weight of the machine ca. 0,6 t Fully Automatic Gear Hobber with Loader for small gears

Condition: used, Year of construction: 2003, Control BWO tip circle diameter max. 700 mm root circle diameter min. 50 mm height of profile max. 35 mm number of spindle speeds 0 - 5400 min-1 table load capacity max. 500 kg Overall size 370x220x300 cm Total weight, approx. 15000 kg Number of working hours 94082 h Equipment: BWO control system All axes CNC controlled Oil mist extraction Coolant cleaning system with cooling unit Dittel balancing unit Accessories: Grinding wheels Ø400mm incl. Grinding wheel flanges 1 diamond dressing roller, manufacturer Dr. Kaiser, Ø160mm Counterholder tip Control cabinet: Width 70 cm x length 280 cm x height 220 cm Ppjdext Ur Sepfx Ahvop Machine: Width 220 cm x length 370 cm x height 300 cm Coolant system: Width 170 cm x length 240 cm x height 250 cm

Condition: used, Year of construction: 1998, workpiece diameter with ratio 1:10 300 mm workpiece diameter with ratio 1:1 212 mm max. number of teeth 200 Ppjdoul El Tepfx Ahvsp min. number of teeth 6 x-travel 300 mm X - Axis speed 0,1-5.000 mm/sec. y-travel 400 mm Y - Axis speed 0,1-5.000 mm/sec. A - axis -170 / +170 ° control Siemens Sinumerik 840 C total power requirement 38 kW weight of the machine ca. 10 t dimensions of the machine ca. 4,20 x 2,20 x 2,10 m incl. suction

Condition: like new (used), max. wheel diameter 420 mm gear width 120 mm max. module 8 min. module 0,5 control BWO CNC no. of strokes 32-800 Hub/min total power requirement 50 kW weight of the machine ca. 9 t dimensions of the machine ca. 5,3 x 3,9 x 3,4 m Machines increase 100 mm intermediate plate Ppedpfx Ahetycgfjvjp automatic Hublageverstellung automatic Hublängeverstellung 5 axis controlled machine BWO last type C, D, X, Z, L axes are CNC x-travel 360 mm z-travel 154 mm L-travel 137 mm max. table load 1000 kg Control system Total power requirement 50 kW Machine weight approx. 8400 tonnes Space requirement approx. 5.3 x 3.9 x 3.5 m o Straight guide o Machine elevation 200 mm o With automatic workpiece clamping device o Counter holder Year of construction: approx. 1989

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 stroke length max. 0 - 52 mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg Year of construction: Approx. 1970 Ppedpfx Aheu Uu S Tsvop

Condition: good (used), Year of construction: 1978, max. pitch circle 152 mm Number of teeth 8-50 St. weight 7500 kg Technical data – Min./max. foot cone angle: 15° / 55° – Pitch circle diameter: 152 mm – Max. tooth height with 21° finished broach head: 10.7 mm – Max. tooth width at tooth root with 21°: 28 mm – Broach head diameter: 200 mm – Number of teeth range: 8–50 – Max. broach head diameter: .21" Workpiece spindle – Diameter of the tapered bore at the wide end: 99.219 mm – Clamping length at 304.8 mm: 15.478 mm – Taper depth: 15.875 mm – Diameter of the entire spindle bore: 22.225 mm Maximum tooth height: 14.8 mm Maximum tooth width at the root: 28 mm Maximum root angle: 55° Ppedpfsxq Hgcjx Ahvep Minimum root angle: 15° Milling head speed: 32.6-49.7 m/min Feed speeds (seconds per tooth): 2-3.1 Index range: 8-50 mm Diameter of taper bore at large end: 99 mm Taper per foot: 15.4 mm Depth of taper: 15.8 mm Countersink behind the taper: 57.2 x 77.9 mm Diameter of the bore through the spindle: 22.3 mm Power of the main drive motor: 10 HP Rotation of the main drive motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the hydraulic motor (60 Hz/50 Hz): 1800/1500 rpm Rotation of the coolant pump (60 Hz/50 Hz): 3600/3000 rpm Rotation of the chip screw motor (60 Hz/50 Hz): 1800/1500 rpm Footprint (L x W): 320 x 221 cm Total weight of the 726 REVACYCLE machine: approx. 9 t

Condition: good (used), Year of construction: 1998, Max. Pitch circle diameter External gearing 300 mm Max. Pitch circle diameter internal gearing 300 mm Max. Outer diameter of workpiece (equipment) 450 mm max. module 6 gear hobbing width -max. 100 mm Max. Helix angle (with tool Ø 125 mm) +/- 45 ° strokes - infinitely variable 130 - 1300 Hub/min workpiece weight 1000 kg Minimum distance table top - tool spindle -55 / +300 mm Maximum distance table top - tool spindle 200 mm Maximum distance table top - tool spindle 350 mm Manual Upright side shift +/- 25 mm Manual swivelling angle of the tool spindle +/- 0,5 ° Max. Tool speed 15 UpM Max. Workpiece speed 27 UpM Max. Tool diameter 7 Zoll voltage 400 V frequency 50 Hz Max. Line power 70 A total power requirement 48 kW weight of the machine ca. 11 t dimensions of the machine ca. 4,27 x 3,11 x 2,87 m taper in main spindle SK 45 table hole 40 mm Ppjdpfx Ahevu E Nusvop control Siemens Sinumerik 840 C Gleason PFAUTER gear shaping machine Mod. PSA 300 The CNC modular gear shaping machine with skiving cutter for the machining of external and internal cylindrical gears, with straight or helical involute with straight or helical involute toothing, as well as any other profile splitting process. The work cycle is controlled by a CNC unit, with specific software for machining the gears, machining. Field of application --> The PSA 300 has been designed for the production of: - Gears with straight external teeth - Gears with straight internal teeth - Gears with external helical teeth - Gears with internal helical teeth

Condition: good (used), Year of construction: 1982, max. wheel diameter 600 mm gear width 500 mm max. module 15 min. module 1 total power requirement 2 kW weight of the machine ca. 2 t dimensions of the machine ca. 2x1,5x2 m The rounding of the teeth is obtained by coordinating alternative movement of the cutter and rotary movement of the piece. The alternative movement of the cutter is obtained by rotating a cam, shaped in order to obtain radius or cusp rounding. A series of 4 cams allows to work modululus from 1 and 16 included. An regulation device allows change the modulus between the minimum and maximum value of every cam. The rotation of the piece is controlled by a three-stage gear wheel which forms the dividing system. The piece lock and the movement of the rapid entry of the cutter to the piece is controlled by pneumatic servo devices. The practicality and rapidity of the equipment, as well as the wide range of profiles available on the cams and the ability to process internal gears, make the machine a universal machine suitable for machining small and Ppodpowftuxofx Ahvop large series. --> technical features Max module: 15 --> Max diameter: 600 mm --> Spindle/head speed: 1450 - 2100 - 2800 rpm --> Production output teeth per minute: 35 - 50 - 75 --> Motor output spindle: 2800 rpm - 1.5 HP --> Motor power piece rotation (self-braking): 1.5 HP --> Motor power automatic (self-braking): 0.35 HP --> Motor power cooling system: 0.25 HP --> Dimensions: 2000 x 1500 mm --> Total weight: 2000 kg Accessories Cam x 5 Indexing wheels Tools Serial no. 152/0589/94 Machine with full enclosure Counter support

Condition: good (used), Year of construction: 1991, weight of the machine ca. ca. 6 t The design of the basic machine is characterised by the following features: - horizontal position of the workpiece spindle; vertical position of the milling spindle or milling head of the milling head - The workpiece is held between the workpiece headstock (left) and the tailstock (right). - the radial slide is mounted on the base (X-axis) - the axial slide moves on the radial slide (Z-axis) - the shift milling head is equipped with an automatic angle adjustment (A-axis); the shift slide (Y-axis) moves diagonally to the workpiece diameter - CNC controlled - IBH control Ppedsub Amfspfx Ahvop - loading device - Many accessories Technical data: - largest milling module with hobs according to DIN 8002: 4.5 mm - largest milling module for high-performance milling: 3.0 mm - Number of teeth: 2 - 999 - max. workpiece diameter for manual loading: 200 mm - max. workpiece diameter for automatic loading: 150 mm - maximum workpiece length: 400 mm - largest / smallest milling cutter diameter: 102/40 mm - maximum cutter length: 230 mm - largest / smallest milling arbor diameter (standard): 32/16 mm - Axial slide path = largest milling length Z-axis: 300 mm - Radial slide path X-axis: 140 mm - Milling cutter shift path Y-axis: 100 mm - Milling stock path W-axis: 420 mm - Swivelling angle of shift milling head (left/right) A-axis: 50°/60° Milling coordinates: - Z-axis: 100 - 400 mm - X-axis: 1ß0 - 150 mm - Y-axis (end face of milling spindle): 50 - 230 mm - W-axis (face of tailstock spindle): 165 - 585 mm - Milling cutter speed range standard B-axis: 0 - 1500 rpm - Workpiece speed C-axis: 0 - 350 rpm Feed speeds: - X-axis: 3500 mm/min - Z-axis: 3500 mm/min - Y-axis: 4000 mm/min - W-axis: 5500 mm/min - V-axis (gantry loader): 80000 mm/min

Condition: used, max. wheel diameter 0-200 mm max. module 25 min. module 0,5 Psdpfx Ahetuxa Uevjpp

Condition: used, max. wheel diameter 180 mm gear width 45 mm max. module 4 min. module 0,5 stroke length max. 0 - 52 mm spindle taper innen MK 4 table diameter 160 mm table bore diameter 75 mm no. of strokes 355 - 630 Hub/min feed range 0,008 - 0,4 mm/Hub dimensions of the machine ca. 2,30 x 1,50 x 2,36 m power capacity 6 kW weight of the machine ca. 2.500 kg With rack and pinion unit Psdpfxstycg Se Ahvopp Change gear set Year of construction: Approx. 1981

Condition: good (used), max. wheel diameter 630 mm gear width 375 mm max. module 10 clamping table 550 mm table hole 125 mm milling spindle speeds infinitely variable 62 - 390 U/min taper MORSE 5 axial-feeds 0,40 - 6,80 mm/U radial feeds 0,10 - 1,76 mm/U dist. cutter spindle - workpiece spindle 50 - 425 mm no. of teeth min. 8 milling cutter dia. x width 192 / 215 mm shifting 200 mm main drive motor 7,5 kW total power requirement 21 kVa weight of the machine ca. 8,2 t Equipment of the machine: - Universal milling head with tangential displacement - Pressure reducing valve for counterholder - Magnetic chip transport - Year of construction approx. 1976 Pedpfjua It Usx Ahvepp

Condition: excellent (used), Year of construction: 2018, General Information Pedpfx Aheywyvtjvepp • Type: Measuring Center • Manufacturer: Gleason Metrology Systems Corporation, Ohio • Model: GMS • Model designation: 475 • User designation: Gear Analyzer 475GMS • Serial number: 7406 • Year of manufacture: 2018 • Operating hours: unknown • Next calibration: 08/2026 • CE marking: available • Including PC with control unit • Documentation with operating manual available Machine Description • Gleason Gear Analyzer Measuring Center Model 475GMS • Measuring center for the complete measurement of all types of gears • Suitable for the measurement of gear cutting tools • Suitable for the measurement of prismatic workpieces • Integrated surface roughness measurement • Currently used for testing manufactured components for precision gearboxes Machine Specifications Workpiece Capacity • Workpiece diameter: max. 475 mm • Workpiece weight: max. 300 kg Power Supply • Power consumption: 20 A • Operating voltage: 230 V AC / 50 Hz Machine Dimensions • Dimensions: approx. 2,130 x 1,640 x 1,130 mm (H x W x D) Machine Weight • Weight: approx. 3,500 kg net Special Features • Loader unit mounted in front of the measuring center • Loader unit retrofitted in February 2022

Condition: like new (used), Year of construction: 2023, General Data • Machine type: Gear Skiving Machine Ppedpjywyt Ssfx Ahvsp • Machine number: 32335 • Year of manufacture: 2023 • Operating hours: unknown (The machine was only used for testing purposes and never in production.) Machine Description • Gear skiving machine for machining soft and hard materials • Designed for producing skivable profiles on cylindrical workpieces • Especially suitable for internal and external geared cylindrical gears • Equipped with integrated resharpening unit • Resharpening unit axes: +A3, +C3, +X3 • Integrated pivoting gripper for workpiece handling • Workpieces are transported from the transfer station to the workpiece table • Machining is performed using a skiving cutter • The machine was temporarily installed in another facility • Reportedly, the machine was only operated for one hour – short test run Machine Specifications Workpiece Dimensions • Internal diameter range: 40 – 300 mm • External diameter range: up to 450 mm Spindle • Tool spindle (C2): 2,990 rpm • Grinding spindle of the resharpening unit (C3): 12,000 rpm Tool Holder • Tool interface: HSK B125 Control System • Control: Sinumerik 840 D Special Features • Integrated resharpening unit with +A3, +C3, and +X3 axes • Integrated pivoting gripper for automated workpiece transport Other • Total power consumption: approx. 100 kVA • Operating voltage: 400 V AC / 50 Hz • Machine dimensions: approx. 3,900 x 5,700 x 5,400 mm (H x W x D) • Machine weight: approx. 11,000 kg Optional Accessories • Hydraulic unit • Chip conveyor • Coolant chiller with filter and centrifuge

Condition: used, Year of construction: 2019, Technical details: max. wheel diameter: 1000 mm gear width: 250 - 800 mm max. module: 15 cycle time: 1017 h min. module: 20 max. table load: 4000 kg Ppjdpfx Ajywx Ihshvjp clamping diameter: 600 mm total power requirement: 80 KVA weight of the machine ca.: 20 t dimensions of the machine ca.: 5,0 x 6,5 x 3,7 m

Year of construction: 1994, operating hours: 32,303 h, condition: reconditioned (used), functionality: fully functional, Twin-screw extruder, second-hand Manufacturer: Reifenhäuser Type: BT 1000-2-63 K Year of construction: 1994 Machine no.: 32061 Operating hours: 32,303 hours Screw geometry: conical for PVC-hard profiles Screw diameter: 63 - 121 mm Screw length: 1300 mm Screw speed: max. approx. 32 1/min. Nominal torque from gearbox: 1000 daNm Dynamic load rating of the back pressure bearing: 103600 daN Motor power: 43.0 kW, Drive motor: Baumüller DC motor Ppodpfxsyx Dxuo Ahvop Barrel heating/cooling zones: 4/3 (air cooling with fan) Adapter heating zones: 1 Tool heating zones: 5 Temperature control: digital temperature controller (2 x PSG Multipact 88) Max. permissible melt pressure: 500 bar Output: approx. 150 - 200 kg/h for rigid PVC profiles Accessories: Dosing device and material hopper Extrusion height: 1150 mm Dimensions: 4250 x 1200 x 1750 mm without hopper (LxWxH) Weight: approx. 3000 kg Condition: The machine came directly from production and was cleaned by us, repainted (RAL 7035, light gray) and checked for function.

Year of construction: 1979, operating hours: 216 h, condition: reconditioned (used), functionality: fully functional, Twin-screw extruder, parallel Manufacturer: Hans Weber Maschinenfabrik GmbH Type: DS 85 Ppedpfxeyx Dw Do Ahvjp Year of manufacture: 1979/2022 Machine no.: 85-399 Screw geometry: for PVC-hard profiles Screw diameter: 2 x 85 mm Screw length: 17 x D Screw speed: max. 30 rpm Screw torque: 10000 Nm Motor power: 3.3 - 25.0 kW Drive motor: commutator motor Elektra Faurndau Cylinder heating/cooling zones: 4/2 (air cooling with fan) Tool heating zones: 8 Temperature control: 12 x digital temperature controllers (PMA KS40) Accessories: Melt pressure sensor and melt temperature sensor Connected load: approx. 60 kW (without tool) Extrusion height: 1100 mm Output capacity: approx. 150 - 180 kg/h for PVC-hard profiles Accessories: Material hopper and connection flange Accessories: Vacuum pump (1.1 kW) incl. material separator Dimensions: 4500 x 1200 x 2100 mm (LxWxH), incl. material hopper Weight: approx. 4000 kg Note: The electrical control cabinet was completely renewed approx. 3 years ago. Since then, the extruder has only been in operation for 216 hours. Condition: The extruder was repainted (light gray, RAL 7035) and checked for function.

Condition: used, Year of construction: 1967, max. wheel diameter 600/400 mm max. module 10 Pedpoywnukofx Ahvspp min. module 1 number of teeth beliebig slide adjustment - vertical 350 mm grinding wheel diameter 80 mm total power requirement 1 kW

Condition: good (used), Year of construction: 1965, max. wheel diameter 900 mm max. module 6,5 stroke up to 150 mm table diameter 900 mm table hole 360 mm weight 3,7 t External: max. diameter 900 mm Max. gear width 150 mm Ppsdpfx Aoywnt Tjhvop Internal: Max. diameter 630 mm Max. gear width 150 mm Spindle bore table 360 mm Table diameter Ø 900 mm Module 6.5 mm Length 2500 mm Width 2300 mm Height 2600 mm Weight 4100 kg
