Used Drill Head for sale (12,570)

Condition: used, for manual drilling machines for stone, wood, and a few for metal Pjdpfxshagt Ss Amkegl

Condition: used, Year of construction: 1993, Technical details: workpiece thickness - max.: 80 mm workpiece thickness min.: 5 mm plate size without being adjusted: 2000x1000 mm size of plate min.: 100x100 mm longitudinal travel: 2800 mm cross travel: 1000 mm control: CNC Mubea Matic100 hole diameter: min/max:10/40 mm tool taper: Kegel/cone/cono DIN 6327 bore spindle stroke: max. 150 mm positioning accuracy: +/- 0,5 mm spindle speeds:: 112-180-224-280-355-560 U/min traversing speed: 80 m/min feed length: max. 150 mm rapid traverse: 8 m/min work table:: L:2500;B:950 mm workpiece weight: 750 kg Psdpfx Amou Id Ruskegl deburring device max.: d=40 mm work height max.: 1050 mm arm gripping device: 4 Stück/ pcs opening of gripping pliers min/max.: Typ I: 5/45 mm opening of gripping pliers min/max.: Typ II: 45/85 mm air-pressure connection: 6 bar total power requirement: 30 kw Weight approx.: 5,5 t space requirements approx. LxWxH: 5,0 x 5,5 x 2,7 (je nach Aufstellung) m - plate size with beeing adjusted also 1000x4000 mm possible - with roller conveyor 2x1000mm - material supporting table complete with supporting elements, guidance rail for guidance and transportation of the positioning wagons , cooling of the drill via air pressure - control for 2 axis positioning x-axis 80m/min and y-axis 30m/min, - memory capacity approx. 10.000 programs - position wagon/carriage, 2 material support table, material standard gauge railway, - electric cabinet, control panel, hydr. aggregate accessories: - 1 position trolley, 2 material support tables, material web, control panel, hydraulic unit, deburring device Equipment: - 2 pieces drill sleeves, roller track 1800x1000mm and roller tracks 2x1000mm Machine is not under power and ready for transport. *

Condition: used, Technical details: bore capacity in steel (diameter): 13 mm throat: 160 mm bore stroke: 60 mm spindle taper MT: MK2 spindle speed:: 210 - 2580 / 16 step U/min feed: manual mm/U table clamping surface:: 200 x 185 (fest) mm Distance spindle/table max.: 620 mm table clamping surface:: 260 x 265 (verstellbar) Distance spindle/table max.: 160 - 460 mm table rotating: ja ° drill table adjustment: 300 (Handkurbel) mm column diameter: Ø ca. 70 mm total power requirement: 900 Watt weight of the machine ca.: 90 kg dimension machine xH: 0,6 x 0,31 x 1,7 m The machine is equipped with a RÖHM 1-13 drill chuck incl. drill chuck key. Spindle run right. Pgsdsvgbdxjpfx Amkel Small vice included *

Condition: used, Technical details: bore capacity in steel (diameter): 22 mm throat: 205 mm bore stroke: 100 mm spindle taper MT: MK2 spindle speed:: 2 step U/min feed: manuell mm/U Distance spindle/table max.: 150 - 600 mm base plate surface area: 350 x 400 mm table clamping surface:: 360 x 280 mm Pgodpfx Aevxf Iromkel table rotating: 360 ° drill table adjustment: 450 mit Kurbel mm column diameter: Ø 100 mm control voltage: 380 V total power requirement: 0,8 kW weight of the machine ca.: 270 kg dimension machine xH: 0,6 x 0,5 x 1,95 m column drill incl. machine + vice. *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1250 workpiece height max.: - mm distance column till spindle centre: 1250 mm drill head horizontal traverse: 980 mm Pgsdewid Auspfx Amkol vertical adjustment of arm: 800 mm distance table - lower edge spindle: 2,05 x 9,2 x 2,85 mm spindle taper MT: MK4 bore spindle stroke: 280 mm range of revolutions per minute - continous: 28-1.195 3 Steps U/min swivel range of the arm: 90 Grad feed: 0,1/0,2/0,3/0,4/0,8/1,2 6 Steps mm/U column diameter: 300 mm base plate surface area: 1.370 x 750 mm weight of the machine ca.: - t dimension machine xH: 2,05 x 9,2 x 2,85 m Cooling water system with feed Table with clamping surface 1,370mm x 750mm incl. drilling cube *

Condition: used, Year of construction: 1976, Technical details: bore capacity in steel (diameter): 32 mm arm length: ./x. . 400 / 50 mm drill head horizontal traverse: 400 mm drilling head vertical adjustable: 400 mm bore spindle stroke: 150 mm spindle taper MT: 4 grinding spindle speed: 100 - 2000 U/min Arm length: Spindel: min./max: ca. 400 / 50 mm cantilever adjustment vertical: 850 mm cantilever adjustment horizontal: 400 mm arm: Länge: 1360 arm horizontal: schwenkbar mm/min number of revolutions per minute of drill spindle:: 100...2 step U/min. feed steps: 0,1 / 0,2 / - step mm/U Table dimensions: 00 x 510 mm distance table - lower edge spindle: min./max.: 350 / 800 mm total power requirement: 2,4 kW weight of the machine ca.: 1,8 t dimension machine xH: 1,3 x 1,3 x 2,25 m Equipment: 2x foot rail Attachment option for a vertical table Accessories: Various clamping devices Pjdpfowi Iqvjx Amksgl *

Condition: used, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 workpiece height max.: - mm column diameter: 300 mm horizontal adjustment of the boring slide: 400 mm Psdpfx Aev S Ay Semksgl distance table - lower edge spindle: 200 mm spindle taper MT: MK 4 bore spindle stroke: 200 mm range of revolutions per minute - continous: 18steps 14-710 U/min swivel range of the arm: 360 Grad feed: 0,09/0,12/0,25/0,5 mm/U weight of the machine ca.: 2,0 t dimension machine xH: 2,4 x 0,9 x 2,4 m Transportable! Operation via pressure switch Support feet 4x D=16x30mm Height-adjustable 60 mm with ratchet wrench *

Condition: used, Year of construction: 2008, Technical details: Pjdeviqybjpfx Amkegl bore capacity in steel (diameter): 40 mm throat: 350 mm bore stroke: 120 mm bore capacity in cast iron: 60 mm spindle taper MT: MK 4 spindle throat: 350 mm spindle speed:: 50 - 1450 / 18 step U/min feed: automatisch/manuell mm/U Distance spindle/table max.: 25 - 705 mm table clamping surface:: 430 x 430 mm drill table adjustment: 680 mm column diameter: 150 mm distance spindle center to floor plate:: 1210 mm total power requirement: 1,6 kW weight of the machine ca.: 350 kg dimension machine xH: 0,95 x 0,55 x 2,3 m Height-adjustable table(swivel and tilt adjustable ) Table can be swiveled 45° left/right and rotated 360° around the column Thread cutting up to M24 Coolant system A vise is mounted, and a threading device is included with this machine. *

Condition: used, Technical details: bore capacity in steel (diameter): 30 mm bore stroke: 180 mm drill spindle - Morse Taper: 4 x MK 3 spindle throat: 310 mm spindle distance: 490 mm number of drilling stations: 4 headstock adjustment: 300 (manuell) mm feed:: 0,08 - 0,64 / 6 step mm/U spindle speed:: 50 - 1.215 / 19 step U/min distance between table/spindle: max./min.: 500 / 200 mm table surface area: 1820 x 395 mm table adjustment: Höhe: 300 (manuell) mm total power requirement: 4x 1,5 (6,0 kW) kW Podpfx Aou Idu Hjmkogl weight of the machine ca.: 2,8 t dimension machine xH: 2,1 x 1,1 x 2,75 m Further technical data: -Center distance of the drilling spindle 490mm -thread cutting on drilling columns 3 and 4 with automatic switchover -All drilling spindles run with clockwise and counter-clockwise rotation -spindle countershaft and variator -with coolant system *

Condition: used, Technical details: bore capacity in steel (diameter): 16 mm throat: 190 mm bore stroke: 60 mm Distance spindle/table max.: 250 mm range of revolution per miute: 410 / 725 / 1100 / 1700 bei 4step U/min spindle taper MT: MK 2 Pjdsu Id Dzspfx Amkjgl table surface area: 155 x 155 mm vertical adjustment: Tisch/table = 180 mm table rotating: 360 ° base plate surface area: 175 x 175 mm distance spindle center to floor plate:: max. 360 mm column diameter: 70 mm machine weight ab.: 65 kg dimensions L x W x H: 0,6 x 0,3 x 0,85 m Drill sleeve equipped with drill chuck 1 - 16 mm table rotatable *

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 20 mm throat: 220 mm bore stroke: 85 mm Distance spindle/table max.: max. 260 mm range of revolution per miute: Keilriemen U/min spindle taper MT: 2 table surface area: 220 x 280 mm base plate surface area: 225 x 280 mm distance spindle center to floor plate:: max. 380 mm total power requirement: 0,33 kW machine weight ab.: 125 kg dimensions L x W x H: 0,8 x 0,4 x 0,8 m Pgjdpsu Id D Uofx Amkel The machine is currently in the technical department. Table rotatable 380 V with connection cable 2500mm *

Condition: used, Technical details: Pgjdeu Idt Nspfx Amksl number of spindles: 4 bore capacity in steel (diameter): 30 mm bore stroke: 200 mm drill spindle - Morse Taper: MK3 spindle throat: 350 mm spindle distance: Mittenstand: 490 mm headstock adjustment: 500 mm feed:: 0,07; 0,15; 0,25; 0,33 / 4step mm/U feed:: manuell und automatisch spindle speed:: 70 ... 1.600 / 8step U/min distance between table/spindle: max. 430 mm distance between table/spindle: min. 180 mm table surface area: 1820 x 400 mm table adjustment: 250mm mit Handkurbel mm total power requirement: 10,8 kW dimension machine xH: ca. 1,0 x 2,1 x 2,8 m All spindle heads with clockwise and counter-clockwise rotation Drill head 1 to 3 clockwise and counter-clockwise rotation without tapping function Drill head 4 with automatic thread-cutting function, rawhide chuck up to Ø 33mm All drill heads and the table are height-adjustable. Equipment: Coolant supply i.D. *

Condition: used, Technical details: number of spindles: 4 bore capacity in steel (diameter): 2-16 mm bore stroke: 140 mm drill spindle - Morse Taper: MK 3 spindle throat: 280 mm spindle distance: 455 mm headstock adjustment: 250 via Hand - Kurbel mm feed:: 0,08 - 0,12 - 0,20 - 0,31 / 4 steps mm/U feed:: automatic + manuell spindle speed:: 180 - 2000 / 8 steps U/min Pgedpsu Idugsfx Amkel distance between table/spindle: min. 3x 140mm und 1x 260mm mm distance between table/spindle: max. 3x 700mm und 1x 820mm mm table surface area: 1800 x 350 mm table adjustment: 300 via Hand mm total power requirement: 6,3 kW weight of the machine ca.: 2,4 t dimension machine xH: 2,1 x 0,9 x 2,2 m Application: Drilling, countersinking; reaming and thread cutting. Each drill spindle has its own drive motor Equipment: Foot pedal/operation Hand crank *

Condition: used, Technical details: material thickness: 1,0 mm Pgjdpfx Asu N E Evjmkol material width: 17,0 mm internal diameter: 30,0 mm external diameter: 78,0 mm Spare part for bench drill BT 2 Patt spring - Return spring - Spiral spring Declaration of conformity according to ISO/IEC 17050-1 Acceptance test certificate 3.1 according to DIN EN 10204 available *

Condition: used, VERTICAL MILLING HEAD Accessory for a Fritz Heckert FSS 400 milling machine Weight: 285 kg Dimensions (LxWxH): 550 x 500 x 550 mm Swivels 90° to the right / left Clamping surface: 500 x 400 mm Taper: SK 45 Flange diameter: D = 260 mm Mounting: 4 holes, diameter D = 17.5 mm Pgsdsv U I Sljpfx Amkel *

Condition: used, Year of construction: 1966, Technical details: bore capacity in steel (diameter): 63 mm arm length:: 2000 workpiece height max.: 1270 mm spindle taper MT: MK 5 drill depth: 400 (Hub) mm quill stroke: 400 mm feed: 0,05 - 0,32 m/min revolutions per minute spindle:: 14 - 1000 (40/50/63/160+200 o.Funktion) U/min column turnable: 360 ° electrics - voltage/frequency: 380/50 V/Hz base plate: 1900 x 950 mm total power requirement: 13 kW weight of the machine ca.: 7,9 t space requirements approx. LxWxH: 3,9 x 1,5 x 3,4 m Psdpfx Ameu Id Dbokegl This radial drilling machine has an electric sliding table! Further features: - Distance from spindle center to stand: 360 - 2000mm - Distance from drill chuck to table top: 1270mm - Distance from spindle to base plate: 1220 - 4520mm - Drilling capacity in St 60: 63mm at feed rate 0.32 - Drilling capacity in GG 22: 80mm at feed rate 0.5 - Horizontal travel of the drilling head: 1640mm - Vertical travel of the drill head: 980mm - Distance from spindle nose to base plate: 430-1770mm Equipment: - Coolant pump (out of function) - Support stand - 1 electrically driven sliding table 1250 x 1000mm type TI 18 with digital display (interface to the machine) - incl. machine vice Not all revolutions are currently selectable. i.D. *

Condition: new, This is a new machine which is manufactured in Romania by the manufacturer Emsil. Customer wishes can be taken into account depending on technical implementability and are checked in advance by the manufacturer's engineering office. Narwhal features a drilling spindle that is made of hardened, tempered and rectified alloy steel. It is mounted with preloaded oblique precision ball bearings. The machine is also equipped with a milling and boring bar which can handle exceptional power and torque. The bar is made of nitrided alloy steel and is also mounted with oblique preloaded precision ball bearings. It moves on bronze guide bushings. The clamps of both units, used for securing and releasing the tool holder cone with ISO 50 coupling, open and close automatically Rotary Turntable: The table is turned by means of a double pinion gearbox, a central rod wth bearings and hydrostatic sliding block of the centre bearing which is of a suitable size to guarantee maximum precision with large loads, even unbalanced ones. There is a recirculating ball screw slide guide system for the x-axes. Both axes are equipped with a direct measuring system. CNC Axes Control: The 9 axes of the machine are monitored at all times. The monitoring system is equipped with a 15'' TFT screen, a control panel, remote diagnostics that alert the user in case of faults, a user memory, network connectivity, remote control of the process, integrated PLC, etc. Pjdpfx Asu Id H Aomkegl The machine is compatible with the multiple control systems such as Heidenhain, Fanuc, Siemens etc. You can choose the sizes of machining of X/Y and Z axes: from 1200 - 3500 / 1000 - 3500 / 400 - 1500mm *

Condition: used, Year of construction: 1982, Technical details: bore capacity in steel (diameter): 28 mm Podpfx Aeu Idkbemkjgl throat: 300 mm bore stroke: 150 mm drill capacity in cast iron: 30 mm spindle taper MT: MK3 spindle speed:: 200; 300; 500; 800; 1250; 2000 / 6 step U/min feed: manuell mm/U Distance spindle/table max.: 50 - 600 mm table clamping surface:: 330 x 300 mm table rotating: nein ° drill table adjustment: 550 (Handkurbel) mm column diameter: Ø 125 mm total power requirement: 1,5 kW weight of the machine ca.: ca. 300 kg dimension machine xH: 0,7 x 0,45 x 1,87 m Equipped with RÖHM Supra 3 - 16mm quick-action chuck Machine vice *

Condition: used, Year of construction: 1989, Technical details: bore capacity in steel (diameter): 28 mm throat: 285 mm bore stroke: 165 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 3 spindle speed:: 65 - 1.750 / 4x steples U/min feed: 0,1; 0,2; 0,3 manuell/automatisch mm/U Distance spindle/table max.: 80 - 680 mm table clamping surface:: 500 x 370 mm table rotating: 360 ° drill table adjustment: 600 vertical mm column diameter: Ø 130 mm total power requirement: 7,5 kW weight of the machine ca.: 273 kg dimension machine xH: 0,9 x 0,6 x 1,9 m The machine can cut threads, change of direction left/right selectable via foot switch and/or depth stop Table can be swiveled and adjusted in height. Psdpfxju Idkzs Amkjgl *

Condition: used, Accessories for e.g. a bench drill BFT 130: The spindle head and swivel angle can be swivelled 360° around their own axes. Podpfx Asu Nlgyomkogl Two swivel planes The set angles can be read off on circumferential scales Speed max. 600 rpm. Spindle taper ISO 50 Weight approx. 270kg incl. connecting piece to the drive SK 50 pinoler/head *

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Podpjyli Sfjfx Amksgl Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg dimension machine xH: 0,73 x 0,56 x 0,22 m

Condition: used, Technical details: bore capacity in steel (diameter): 28 mm throat: 345 mm bore stroke: 190 mm drill capacity in cast iron: Ø 35 mm spindle taper MT: MK 4 spindle speed:: 50 - 1280 / 4 steples U/min feed: 0,1; 0,2, 0,3 manuell/automastic mm/U Distance spindle/table max.: 200 - 800 mm table clamping surface:: 450 x 600 mm table rotating: 360 ° table adjustment: vertical 600 mm column diameter: Ø 160 mm weight of the machine ca.: 273 kg dimension machine xH: 1,0 x 0,71 x 2,0 m Thread cutting with right and left rotation via foot switch Table adjustment via hand crank Pgedpfxjyq Rpie Amkel Without coolant tank Machine vice Quick-action clamping chuck Röhm Supra 3 - 16mm i.D. *

Condition: used, Year of construction: 1975, Technical details: bore capacity in steel (diameter): 32 mm Psdpfx Ajvc Aytomksgl throat: 230 mm bore stroke: 160 mm spindle taper MT: 3 feed - manual: Handhebel mm revolution per minute: 100...2000 U/min headstock adjustment: 180° Grad headstock traverse: in Höhe/height/altura 350 mm clamping surface area: 1020x615 mm height over floor: 860 mm column diameter: 102 mm total power requirement: ca. 1,2 kW weight of the machine ca.: 0,5 t space requirements approx. LxWxH: L:1,2xB:0,77xH:2,26 m equipped: - toothed drill chuck up to 16mm Machine on sale as is, without test run. i.D. *

Condition: used, Year of construction: 1957, Technical details: bore capacity in steel (diameter): 32 mm arm length:: 1000 horizontal adjustment of the boring slide: 700 mm vertical adjustment of arm: 600 (motorisch) mm Pedjvhbpqspfx Amkegl swivel range of the arm: 90° rechts/links Grad distance table - lower edge spindle: min./max.: 200 / 1120 mm spindle taper MT: 4 bore spindle stroke: 420 (manuell-automatisch) mm range of revolutions per minute - continous: 20 - 2000 / 3 step U/min feed: 01, / 0,2 / 0,3 / 0,4 / 0,8 / 1,2 mm/U column diameter: 250 mm base plate surface area: 1100 x 600 mm total power requirement: 4,6 kW weight of the machine ca.: 2,5 t dimension machine xH: 1,8 x 0,8 x 2,5 m Tool ejection via expulsion wedge Equipment: Coolant system with pump (without feed) Drill cube L: 760 x W: 500 x H: 510mm / horizontal surface 760 x 500mm and vertical surface 760 x 510mm Machine ilumination *

Condition: used, Year of construction: 1971, Technical details: bore capacity in steel (diameter): 23 mm workpiece height max.: ./x. 2 mm drill capacity in cast iron: Ø 26 mm Pgsdpfev Ay T Dox Amkel spindle taper: MK 3 bore spindle stroke: 135 (manual/automatic) mm range drill spindle revolution per minute: 7step U/min feed range: mm/U Table dimensions: 1200 x 500 mm table surface area: 1070 x 400 mm total power requirement: 3,55 kW weight of the machine ca.: 1,4 t dimension machine xH: 1,7 x 1,2 x 2,2 m Jib Length Arm: -vertical adjustment: 450mm and horizontal adjustment: 610mm -swiveling 360°, hydr. lock Right/left rotation for thread cutting with automatic switchover Operation via control panel Coolant tank with pump *
