Used Dovetailing Machines for sale (66,006)

Condition: ready for operation (used), Year of construction: 1992, sheet width 2050 mm plate thickness 10.0 mm ST pre-bending 8.0 mm ST diameter of upper rolls ~ 205 mm side roll diameter ~ 195 mm Control konv. oil volume 80.0 Liter voltage 380 V total power requirement 5.5 kW weight 3200 kg range L-W-H 4500 x 1500 x 1300 mm Features: - Robust electro-hydraulic 3-roll bending machine - 3-roll concept offers a wide range of bending and rounding options - Pivoting control unit at the front * Operation - Control of all rolls and machine axes * Digital position display * Manual operation via joysticks - Diameters of up to 1.1 times the top roll diameter are possible - Forged and hardened rolls with a hardness of 53-55 HRC - Low-maintenance, stable machine design - Sturdy welded steel construction - Electro-hydraulic folding bearing for easy pipe removal - Pressure gauge / pressure indicator for the rolls Nledpfxexacdvo Ahkjf - Safety device (safety lanyard with switch unit) - Operating instructions (PDF)

Condition: used, Year of construction: 1967, grinding length 450 mm grinding width 250 mm workpiece height 275 mm Njdpfx Ahezwxxdskelf table surface area 550 x 200 mm distance spindle center to table max. 400 mm table speeds 0 - 30 m/min cross feed 0 - 60 mm/Hub rapid traverse cross 1,2 m/min grinding wheel size ø 250 x 30 x ø 51 mm grinding spindle speed 1400 / 2800 U/min total power requirement 4 kW weight of the machine ca. 1 t dimensions of machine L x W x H 1,55 x 1,23 x 1,80 m Accessories: magnetic plate 450 x 200 mm, grinding wheel with flange, wheel trueing attachment

Condition: used, Year of construction: 1999, x-travel 290 mm y-travel 170 mm z-travel 310 mm table surface area 600 x 210 mm spindle taper SK 40 spindle turning speed range 50 - 2600 U/min feeds 9 - 450 mm/min quill stroke 70 mm dimensions of machine L x W x H 1,35 x 1,05 x 1,63 m total power requirement 5,5 kW weight of the machine ca. 720 kg - machine out of teaching shop - Accessories: solid table, vertical head with quill retraction, DRO on 3 axis HEIDENHAIN, various tool fixtures, Nlodjwngkrepfx Ahkof coolant

Condition: used, Year of construction: 2008, x-travel 500 mm y-travel 450 mm z-travel 400 mm Control HEIDENHAIN control MillPlus iT table surface area ø 500 x 380 mm B-axis 0 - 161,955 ° C-axis 360 ° spindle taper SK 40 spindle turning speed range 20 - 18.000 U/min spindle power max. 35 kW Nedpswlvi Eofx Ahkjlf max. torque on the spindle max. 130 Nm feeds -stepless- bis 20.000 mm/min rapid traverse X/Y/Z axis 80 / 50 / 50 m/min rapid traverse B-axis 40 U/min C-axis rapid feed 50 U/min no. of tools in magazin 30 tool diameter if 2 vacant positions 130 mm tool diametre at full load 80 mm tool length - max. 300 mm weight of tools max. 6 kg internal coolant system feed 40 bar total power requirement 52 kVA weight of the machine ca. 6 t dimensions of machine L x W x H 3,67 x 2,25 x 2,91 m = 5-axis machining center with 2-axis NC swivelling rotary table Accessories: electron. handwheel, chip conveyor, coolant, band filter device

Condition: used, Year of construction: 1966, planing lenght 525 mm table surface area 500 x 300 mm dimensions of machine L x W x H 1,98 x 1,06 x 1,42 m Accessories: vice (width of jaws 200 mm) on rotary plate, Nodpfxetumras Ahkolf vertical shaping device, tool clearing

Condition: used, Year of construction: 2007, x-travel 1100 mm y-travel 600 mm z-travel 500 mm table surface area 1300 x 600 mm spindle taper SK 40 spindle turning speed - stepless 10.000 U/min ATC 40 Pos Nedpfx Ahet D N A Hjkslf control HEIDENHAIN, TNC 530 weight of the machine ca. 8,8 t dimensions of machine L x W x H 2,58 x 3,04 x 2,35 m Accessories: 2 hydr. vices make HILMA, model NC 160, width of jaws 160 mm; various tool holders, chip conveyor, coolant

Condition: used, Year of construction: 1993, turning diameter ca. 500 mm swing diameter ca. 600 mm travel -x axis ca. 400 mm travel -z axis ca. 600 mm spindle turning speed range 2000 U/min spindle drive 63 kW control SIEMENS control SINUMERIK System 3 tool turret 1 x 12 Pos weight of the machine ca. 9,3 t - R-version, turret right hand side of 3-jaw chuck - Nsdetyp Suspfx Ahkslf Accessories: hydr. 3-jaw chuck 400 mmø, various toolholders for turret, chip conveyor, coolant

Condition: used, Year of construction: 2008, x-travel 1500 mm y-travel 800 mm z-travel 700 mm table surface area 1760 x 700 mm spindle taper SK 40 spindle turning speed - stepless 8000 U/min spindle drive 15 kW feeds 1 - 8000 mm/min rapid traverse X/Y/Z axis 15 / 15 / 12 m/min Nlsdpfxjux Agvs Ahkef table load max. 2500 kg spindle throat 760 mm ATC 40 Pos control HEIDENHAIN, TNC 530 weight of the machine ca. 12,5 t dimensions of machine L x W x H 4,23 x 2,98 x 2,74 m - with coolant through spindle Accessories: NC-dividing unit (=4th Axis) with tailstock, center height 250 mm; 2 hydr. vices make HILMA, model NC 160, width of jaws 160 mm; various tool holders, chip conveyor, coolant - geometrical overhauled in 2022 - - new ball bearing spindle installed on Y-axis in NOV. 2022 - - the magnetic plates shown on the photo are not included -

Condition: used, Year of construction: 1989, x-travel 3000 mm y-travel 940 mm z-travel 1000 mm table surface area 3250 x 800 mm spindle taper SK 50 spindle turning speed range 40 - 1800 U/min Nedpfx Ahjuym Tcokjlf feeds longditudinal/cross/vertical 0 - 2250 mm/min rapid traverse 6 m/min table load 4500 kg control HEIDENHAIN, TNC 355 weight of the machine ca. 10,3 t dimensions of machine L x W x H 4,50 x 2,69 x 2,71 m Accessories: vertical head swivelling in 2 planes with hydr. tool clamping, coolant

Condition: used, Year of construction: 2000, x-travel 600 mm y-travel 400 mm z-travel 400 mm table surface area 800 x 400 mm spindle taper SK 40 Nedpeux Agijfx Ahkelf control HEIDENHAIN TNC 310 spindle turning speed range 10 - 3150 U/min spindle drive 5,5 kW feed - longitudinal/cross 1 - 5000 mm/min feeds vertical mm/min rapid traverse 6 / 6 / 3 m/min total power requirement 10 kVA weight of the machine ca. 2,5 t dimensions of machine L x W x H 2,16 x 1,70 x 2,0 m Accessories: solid table, vertical head with hydr. tool clamping and quill retraction, electron. handwheel, coolant

Condition: used, Year of construction: 1990, grinding length 900 mm grinding width 510 mm workpiece height 400 mm table surface area 800 x 400 mm longitudinal feed of the table max. 980 mm table speed -stepless- 1 - 35 m/min grinding wheel size 355 x 51 x 127 mm cross feed of the table 460 mm cross feed 1 - 40 mm/Hub vertical feed autom. 0,005 - 0,04 mm/Hub rapid traverse vertical 0,5 m/min grinding spindle speed 1450 U/min grinding spindle drive 5,6 kW table load capacity max. 1000 kg dimensions of machine L x W x H 3,2 x 2,17 x 2,47 m total power requirement 10 kW weight of the machine ca. 4,4 t Accessories: magnetic plate 800 x 400 mm, various grinding wheels with and Nledpstqqm Asfx Ahksf without flanges, wet grinding attachment with paper band filter

Condition: used, Year of construction: 2002, x-travel 880 mm y-travel 630 mm z-travel 630 mm table surface area 50 x 700 mm NC-rotary table integriert, 700 mmø spindle taper SK 40 spindle taper DIN 69871 spindle turning speed - stepless 20 - .000 U/min control HEIDENHAIN control TNC 430 feeds x/y/z -stepless 20 - 15.000 mm/min rapid traverse 30 m/min ATC 32 (2 x 16) Pos Nlodpfx Ahetqqmbskof tool diameter 80 / 130 mm workpiece length 315 mm weight of tools max. 8 kg NC-rotary table - speed - max. 15 U/min table load 600 / 500 kg milling head -swivable ° total power requirement 60 kW weight of the machine ca. 9,6 t dimensions of machine L x W x H 4,53 x 2,60 x 2,50 m = 5-axis machining center, table clamping surface 50 x 700 mm with integrated NC-rotary table (=4th axis), movement of milling head via control (=5th axis) Accessories: electron. handwheel, chip conveyor (snailconveyor), coolant

Condition: used, Year of construction: 1984, x-travel 1000 mm y-travel 508 mm z-travel 460 mm size of pallet 1240 x 550 mm numbers of pallets 2 workpiece weight 800 kg spindle taper ISO 40 spindle motor 5,5 kW turning speed range 28 - 4000 U/min no. of tools in magazin 30 control MAZATROL M 1 weight of the machine ca. 5,6 t Njdpfx Aotqqk Ijhkelf dimensions of the machine ca. 4,50 x 3,00 x 2,65 m acc.: chip conveyor

Condition: good (used), Gas metal arc welding machine, arc welding system, MIG/MAG welding system, pulse welding system -Manufacturer: Esab, PULS MIG/MAG welding machine -Type: AristoMig 500W -Max. welding power: 500 A -Features: Water-cooled -Wire feeder case: 4-roller drive Esab type AristoFeed 48-4 -Quantity: 3x Esab, PULS MIG/MAG welding machine available -Price: per piece Nlodpfx Ahsy Ulzioksf -Dimensions: 1200/700/H1730 mm -Weight: 210 kg

Condition: good (used), Gas metal arc welding machine, arc welding system, MIG/MAG welding system -Manufacturer: CLOOS, Qintron water-cooled MIG/MAG welding machine -Type: Qintron 400 -Max. welding power: 400 A -Water-cooled -Wire feed case: Cloos FC 100E-KIT 4-roller drive Nljdpfjx Hgunsx Ahkef -Accessories: incl. ground cable, gas valve, hose assembly (see photos) -Dimensions: 1100/700/H1240 mm -Weight: 181 kg

Condition: used, Year of construction: 2019, functionality: fully functional, Control System (Standard) - HEIDENHAIN TNC-640 HSCI control unit with software option 1&2 (see control system options), DCM collision protection function - 5-axis simultaneous operation - Block processing time 0.5 sec. - NC memory capacity 21 GB on SSDR memory card - USB interface - Ethernet network interface - 1024-block look-ahead function - 3D tool length compensation function - DCM (Dynamic Collision Monitoring) - TSC (Spindle Thermo-Compensation) - Tool center point control (TCPC) - smarT.NC (alternative operating mode for dialog and plain text programming in a mix, particularly suitable for beginners) Linear axes: - Travel ranges X/Y/Z: 600/600/500 mm Linear roller guides: - Manufacturer: INA - Size: 45x45 mm Linear axis accuracy: - Manufacturer: HEIDENHAIN length measuring systems - Resolution linear glass scale: 0.0001 mm - Positioning accuracy X/Y/Z axis: 0.005 mm - Repeatability X/Y/Z axis: ±0.0025 mm Rotary axis accuracy: - High-precision angle encoder for A- and C-axis - A-axis positioning accuracy: ± 30" - C-axis positioning accuracy: ± 5" Ball screw (oil-lubricated): - Manufacturer: INA - Pitch: 12 mm - Max. speed X/Y/Z axis: 36,000 mm/min Swivel and rotary axis: - Swivel axis (A): - Swivel range: +120° / -120° - Drive: Worm gear (optional: direct drive) - Brake: hydraulic (1,200 Nm / 50 bar) - Speed: 16.6 min-1 - Rotary axis (C): - Rotation angle: 360° (0.001° increments) - Drive: Direct drive (torque motor) - Brake: hydraulic (2,900 Nm / 50 bar) - Speed: 90 min-1 Swivel and rotary table: - Table diameter: Ø500 x 420 mm - Max. table load: 600 kg - Max. load height: 430 mm - T-slots (number / size / slot spacing): 7 x 14 mm x 75 mm Spindle: - Manufacturer: ROYAL Precision Tools Corporation - Drive type: direct - Spindle motor / SIEMENS motor 1PH8133 - Power S1/S6 (40%): 25/35 kW - Max. torque S1/S6 (40%): 134/261 Nm - Max. speed 15,000 min-1 - Spindle taper: DIN SK-40 / MAS BBT-40 (Option: HSK-A63) - Spindle oil cooler Coolant management: - External coolant supply around the spindle nose - Internal coolant supply through the spindle 20 bar with Njdszwxicopfx Ahkelf cartridge filter 40 µm, pumps adapted in the coolant tank - Number of magazine positions: 30 (optional: chain with 32, 48, or 60) - Magazine type: Carousel / Fixed position, coded - with tool change arm (double gripper) - Max. tool length: 300 mm - Max. tool diameter: Ø78 mm - Max. tool diameter: Ø120 mm with locked neighboring positions - Max. tool weight: 7 kg Chip management: - Hinged band chip conveyor Other standard equipment features: - Automatic central lubrication - High-pressure chip flushing / chip shower - Coolant gun - Control cabinet air conditioning - Coolant flushing gun - Work area lighting - 3-color warning light (cycle active / completed / alarm message) - Hand tool kit, leveling bolts, nuts, shims - EMC and safety modules for CE compliance - Portable, electronic handwheel - CE compliant with European directives - Hydraulic and pneumatic supply prepared through the table (3x 80 bar hydraulic and 1x 6 bar pneumatic connection). - Oil skimmer

Condition: refurbished (used), Year of construction: 2015, functionality: fully functional, We have a Buhrs - W+D BB700 16K S2 year 2015 servo envelope inserting system available. 12 station base system!!!!! The condition of this machine is very good and the machine has always received its mandetory maintenance. The machine is prepared for a Mueller and/or KERN transactional channel for feeder/collating/folding A4 documents. The Mueller and/or KERN system channel can be offered in or excluded at the machine. We can even offer the Mueller channel as a continues system with a Mueller unwinder, paper cutter, merger and folding station. Other feeders and camera's optional possible! Year of built: 2015 Configuration: - 12 station base - 11x RF2 rotary feeder (other feeders possible) - Divert bin 1, 2 - Conveyor Prepared for a Mueller and/or KERN transactional channel for feeder/collating/folding A4 documents. Envelope formats: - min. 105 × 162 mm C6/DL - max. 250 × 353 mm B4 Product formats: - min. 80 × 105 mm A6 - max. 229 × 324 mm C4 Product thickness: Nsdpjxyfmgefx Ahkelf - 3 mm for rotary feeder - 10 mm for shuttle feeder - 15 mm for vacuum/friction feeder - 70 gsm 16,000 cycles per hour

Condition: excellent (used), Catalogue number 7979 TECHNICAL DATA - Max. diameter of processed dowels: 130mm - Installed bushing: 57mm - Min. input material length: 800mm - Knife head drive motor: 18.5kW - 4 feed speeds + forward/reverse - Feed motor: 2.2kW In order: - Infeed traction rolls, toothed: 6 pcs - 3-knife head - Outfeed traction rolls, smooth: 6 pcs - Extraction port diameter: 140mm - Additional bushings included: 40, 45, 50, 75mm - Dimensions (L/W/H): 3100x1300x1400mm - Weight: 2100kg Njdpfszwwwlex Ahkolf ADVANTAGES – Polish manufacture – 3-knife head – Additional bushings included: 40, 45, 50, 75mm – Used dowel rounding machine, very good condition Net price: 31,900 PLN Net price: 7,590 EUR (based on exchange rate of 4.2 PLN/EUR) (Prices may change with higher fluctuations)

Condition: new, functionality: fully functional, paper weight (min.): 65 g/m², paper weight (max.): 400 g/m², paper width (min.): 120 mm, paper width (max.): 330 mm, total length: 1,220 mm, total width: 730 mm, total height: 1,090 mm, Equipment: documentation/manual, New, original packed Plockmatic LCT3500 Large Capacity Tray New price €24,400 Suitable for the following machines: - Ricoh Pro C7200s Series - Ricoh Pro C9200 Series Technical specifications: Paper Size Min. Ricoh Pro™ C7200s Series: 120 x 210 mm Paper Size Min. Ricoh Pro™ C9200 Series: 120 x 487.8 mm Paper Size Max. 330x700 mm Stock Range: 65 - 350gsm (up to 400gsm dependent on paper type and quality) Paper Types: Plain, Index, Coated, Recycled paper Nlsdpfxewq St Rj Ahksf No. of Trays: Dual (Vacuum) Tray Capacity: 3500 sheets of 80gsm plain paper (2 x 1750 sheets) Double Feed Detection: Optical and ultrasonic sensors, two independent systems Auto Sheet Size Detection: Yes, on standard paper sizes Tray Status Indicators: Individual tray LEDs in segments of four indicating paper amount and status

Condition: new, overall weight: 140 kg, total height: 1,010 mm, total length: 660 mm, total width: 700 mm, empty load weight: 120 kg, New, originally packaged Ricoh RB5030 Ring Binder. New price of €33,340 euros Suitable for the Ricoh Pro 8310 / 8320, among others Paper size: A4 / 8.5 x 11'' LEF Paper Weight: 64 - 256 g/m2 Nsdpfx Ahjwra Daskslf Number of holes: 21 Stack capacity: 11 sets Ring Bind capacity: 2 to 100 pages Ring Supply: Black or white, up to 50 or 100 pages

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, HURCO VM10i VERTICAL MACHINING CENTRE Year: 2015 Axis X 660 mm Axis Y 406 mm Axis Z 508 mm Rotary table (4th axis) no Type of CNC Table length 762 mm Table width 406 mm Nlodpfezwwndex Ahkef Max. part weight 340 kg Number of tool pockets 20 Spindle taper Max. spindle speed 10000 rpm Spindle motor power 11 kW

Condition: excellent (used), functionality: fully functional, machine/vehicle number: 156521, measuring range X-axis: 750 mm, measuring range Y-axis: 500 mm, measuring range Z-axis: 500 mm, workpiece weight (max.): 250 kg, total height: 3,020 mm, type of input current: AC, total width: 2,092 mm, total length: 2,140 mm, table width: 900 mm, table height: 860 mm, table length: 1,300 mm, travel speed (max.): 520 mm/min, table load: 250 kg, ambient temperature (max.): 40 °C, ambient temperature (min.): 15 °C, maximum load weight: 250 kg, Equipment: type plate available, For sale is a used ZEISS GageMax 7/5/5 Navigator 3D coordinate measuring machine with serial number 156521 and manufactured in 2011. The machine has a measuring range of 750 × 500 × 500 mm and is designed for workpieces up to 250 kg. It is equipped with a ZEISS VAST XT probe system. The measuring volume also includes a multi-probe changer with various probe holders. According to the original auction description, the offered lot includes accessories and computer equipment. The available images show, among other things, a computer, monitor, keyboard, mouse, and other components belonging to the machine. The scope of delivery is based on the images or the components available during inspection. Technical data: Manufacturer: ZEISS Model: GageMax 7/5/5 Navigator Njdpfx Ahezwwkxokelf Serial number: 156521 Year of manufacture: 2011 Measuring range X/Y/Z: 750 × 500 × 500 mm Maximum workpiece weight: 250 kg Probe system: ZEISS VAST XT Multi-probe changer included Computer equipment included Last documented calibration: 02/2025 The machine is in used condition. A current functional test was carried out by ZEISS. An on-site inspection is possible by arrangement and is expressly welcome. The machine is preferably sold for collection. Loading and transport can be arranged by agreement. Scope of delivery as shown in the images. Subject to prior sale.

Condition: excellent (used), Year of construction: 2003, Tool holder, vertical + horizontal SK 40 Table size L x W 710 x 315 mm Speed range, vertical spindle 63 – 2500 rpm Speed range, horizontal spindle 45 – 1800 rpm Travel ranges: X-axis, longitudinal adjustment, automatic / manual 400 / 420 mm Y-axis, cross adjustment, automatic / manual 220 / 228 mm + cross slide 375 mm Z-axis, vertical adjustment, automatic / manual 350 / 380 mm Adjustment of the quill, vertical, manual 80 mm Machine dimensions, approx. 1550 x 1620 x 1850 mm Machine weight, approx. 1300 kg Accessories / Special features: • 3-axis digital display, manufacturer HEIDENHAIN • Infinitely variable feeds with rapid traverse in the 2nd feed stage • Two working spindles for horizontal and vertical tool holders (vertical milling head does not need to be removed during machining when the horizontal spindle is in use) • Ball screw spindles for the X and Y axes, simultaneous milling in X and Y direction possible • Trapezoidal screw spindle, hardened and ground, for the Z axis (vertical) • All operating elements on one side, in the mobile control panel • Additional manual adjustment of the cross slide increases the working area of the machine, even beyond the table surface • Safety handwheels • Tool holder according to DIN 2080 – steep taper ISO 40 • Automatic central lubrication for speed and feed gears • Vertical milling head with quill, swiveling L+R • Fixed angle table 315 x 710 with 5 slots 12 mm, spacing 63 mm • Tool clamping spindles, horizontal and vertical • Splash guard made of Plexiglas on 3 sides of the horizontal table • Coolant system • CE compliant TOP condition! Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 Njdpfxsziutzo Ahkolf DE - 44143 Dortmund - Wambel / Germany

Condition: good (used), Year of construction: 2004, functionality: fully functional, Charmilles Robofil 240 SL Year of manufacture: 2004 Travel ranges (X / Y / Z): 350 x 220 x 220 mm Travel ranges (U / V): 350 x 220 mm Max. taper angle: +/- 30° at 220 mm height Integrated Collision Protection (ICP) on all 5 axes Maximum workpiece dimensions: 1000 x 550 x 220 mm Maximum workpiece weight: 750 kg Cutting speed of 300 mm²/min Best surface finish: Ra 0.22 µm Available wire diameters: 0.10 mm to 0.33 mm Nedpfx Ahezwv S Iskelf Dimensions of the complete system: 2020 x 2050 x 2000 mm Total weight of the system: 2450 kg The machine is currently in use at our customer's site and will be available from September. We would be pleased to offer the following services: - Cleaning and overhaul of the machine - Commissioning and training - Delivery - Clamping devices - Cooling unit - Transport

Condition: used, Year of construction: 2004, machine/vehicle number: IntNr231232, Hermle C600 U, year of manufacture 2004 Spindle new, with commissioning report Control system: - Heidenhain iTNC 530 - Control system operating hours: 68026 - Machine operating hours: 81237 - Spindle operating hours: 12429 Spindle: - Speed: 16,000 rpm - Tool holder: SK-40 - 30 tool magazine positions Equipment: - Rigid clamping table - NC rotary table, 4th axis (iTNC) - Coolant system - Chip conveyor: none - Electronic handwheel (iTNC) - Tool breakage monitoring - Chip flushing nozzle - Foot switch for clamping/unclamping - Hydraulic unit for clamping/unclamping Travel paths: - X-axis (longitudinal): 600 mm - Y-axis (transverse): 450 mm - Z-axis (vertical): 450 mm Table: - Clamping area: 800 mm x 465 mm - Maximum table load: 250 kg Axes: - Axis rapid traverse: 35 m/min - Acceleration: 5 m/s² - Measuring system X/Y/Z: 0.1 µm Dimensions & Weight: - Machine weight: approx. 6.8 t - Machine dimensions (W x D x H): 2.5 m x 2.4 m x 2.43 m Njdjzwv N Tspfx Ahkjlf The machine can be inspected under power by appointment. Subject to changes, errors in technical data and specifications, and prior sale!
