Used Cnc Turning Lathe for sale (14,540)

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, travel distance X-axis: 352 mm, travel distance Z-axis: 250 mm, rotational speed (max.): 5,000 rpm, controller model: Fanuc Series 0i Mate-TD, Equipment: chip conveyor, TECHNICAL DETAILS Turning diameter over tool carrier: 70 mm Travel X-axis: 352 mm Travel Z-axis: 250 mm Tool stations: 8 Iaodpfsx E Uzmsx Ah Nsl Bar capacity: 42 mm Max. spindle speed: 5,000 rpm MACHINE DETAILS Control: Fanuc Series 0i Mate-TD EQUIPMENT Machine documentation Power chuck D135 mm Collet chuck 173E Parts catcher Chip conveyor

Condition: good (used), Year of construction: 2013, CNC Swiss-type automatic lathe Make: STAR Model: SR-20R IV type B Year of manufacture: 2013 with: FANUC 31i-B5 control Synchronous spindle Driven tools C-axis Programmable B-axis Y2-axis Iasdpfx Aex Tf N Deh Njl High-pressure pump Backworking unit Oil mist extraction Fire extinguishing system Bar feeder FMB TURBO 2-20

Condition: good (used), Year of construction: 2004, functionality: fully functional, Control system: Mazatrol 640 MT Pro Travel distances: X-axis = 630 mm Y-axis = ±230 mm Z-axis = 1,585 mm B-axis = 225° X2-axis = 230 mm Z2-axis = 1,530 mm Rapid traverse speed of the axes: X-axis = 38 m/min Y-axis = 26 m/min Z-axis = 38 m/min C-axis (spindle rotation): 400 rpm MAIN SPINDLE Drive power: 30 kW Max. torque: 1,200 Nm Speed range: 35 to 3,300 rpm COUNTER SPINDLE Drive power: 26 kW Max. torque: 500 Nm Speed range: 35 to 4,000 rpm MILLING SPINDLE Drive power: 18.5 kW Max. torque: 120 Nm Speed range: 15 to 12,000 rpm Max. turning diameter: 760 mm Max. turning length: 1,500 mm Tool magazine: 80 stations (Capto C6) Coolant/chip removal: - Oil mist extraction - Hinged belt chip conveyor - High-pressure package 70 bar - 7 pressure levels PLC - Dual change filter and oil skimmer Linear scale system for X/Y-axis MACHINE OPTIONS - Synchronous counter-rotation of turning and milling spindle - C-axis 0.0001 degree (counter spindle) - Overload monitoring system for the spindle and axis feed system - Automatic ON/OFF with warm-up function WORKPIECE HANDLING SYSTEM: - Gantry loader GL 200 F (1,500 U) - Hand type D3 (clamp jaws types A, B, C, D, E) - Maximum workpiece weight 2 x 20 kg - Shuttle loop type II (belt conveyor) - 12 pallets 750 x 440 mm - Safety fence - Automatic chuck open/close - Air blast device at the chuck CONTROL OPTIONS - Cylindrical interpolation - Interface set - Option package for 5-axis simultaneous machining - Synchronous tapping, MAZACC2D, - EIA/ISO, tool length compensation - Fully programmable B-axis 0.0001° - Software for 5-axis simultaneous mode - For main and sub spindle 3-jaw quick-change power chuck Ø 315 mm Iedpfxjxy Nzuj Ah Neal Type: SMW KNCSN315 91 The machine can be inspected under power at any time.

Condition: good (used), Year of construction: 2004, functionality: fully functional, Fanuc control, 42 mm spindle bore, sub-spindle, two turrets, FMB bar feeder, chip conveyor. Isdpfx Aex Tfu Toh Neal

Condition: used, Year of construction: 2017, machine/vehicle number: IntNr231463, Machine Designation: CNC Short-Turning Lathe Manufacturer: Index Model: ABC Year of Manufacture: 2017 Control System: Fanuc 32i-B Operational Status: Fully operational Operating Hours: approx. ___ hours Technical Data Spindle Bore: Ø 42 mm Travel and Feed Data: X-Axis Travel: approx. 90 mm Z-Axis Travel: approx. 280 mm Rapid Traverse X: approx. 27 m/min Rapid Traverse Z: approx. 36 m/min Upper Turret (Main Tool Carrier): Number of Stations: 8 (1 synchronizable) Tool Mount: VDI 25 Capable of powered tooling Lower Turret: Number of Stations: 6 Non-driven Rear Side: 5 stations for back-working operations Simultaneous Machining: Up to 3 tools at the same time Coolant System & Chip Conveyor Bar Feeder: IRCO ILS MUK 7012-II, Year 2015 Accessories / Tooling / Manuals Machine Dimensions & Weight Machine: approx. 2830 × 1500 × 2200 mm, Weight: approx. 3,500 kg Coolant System & Chip Conveyor: approx. 1600 × 1250 × 1780 mm, Weight: approx. 680 kg Bar Feeder IRCO ILS MUK: approx. 1800 × 1000 × 1280 mm, Weight: approx. 650 kg The machine is fully operational and in good used condition. For further information or to arrange a live demonstration under power, please do not hesitate to contact us. Iaedpox Tftvjfx Ah Nel All technical specifications and details are subject to change and error. Subject to prior sale.

Condition: good (used), Year of construction: 1996, Victor Vturn-20 CNC turning centre, 10 station tool holder, Fanuc Series 0-T CNC, swarf conveyor, fitted air bench, with Hydrafeed Multifeed MLI bar feeder, serial no. 2766 (1996) Iajdpfeyahz Iox Ah Njl

Condition: used, Year of construction: 2001, Daewoo Puma V300 CNC Lathe Fanuc 18 – T Vertical lathe Daewoo PUMA V300 Year of installation: 2001 Kitagawa chuck, diameter 305 mm Max. swing diameter over bed: 550 mm Max. turning diameter: 410 mm Max. turning height: 420 mm Spindle speed: 2,500 rpm AC motor power (cont./30 min.): 18.5 kW Turret with 8 tools Drilling diameter: 50 mm Tool section: 25 mm Control: Fanuc Series 18-T Isdpfx Aeyahy Dsh Nsal Equipped with chip conveyor Complete with documentation

Condition: excellent (used), Year of construction: 1989, I am selling a CNC lathe Mazak QuickTurn 20N. Lathe in bdb condition. Equipment: MAZATROL T-2, control MAZATROL CAM-T-2. Iaedpfx Asu U R E Aoh Nol

Condition: as good as new (ex-display), Year of construction: 2025, The machine is currently on display. Optiturn Premium CNC lathe available directly from the manufacturer. S600M – The OPTIMUM Premium CNC lathe with Siemens SINUMERIK 828D PPU 290 Touch Panel control system stands out for its performance, speed, precision, and long service life. • Heavy-duty design • Renishaw probe arm for manual tool measurement • Ball screw drive for improved accuracy, rigidity, and thermal stability • Siemens servo motors on all axes • All servo motors equipped with integrated encoders for maximum accuracy • 45° slant-bed design for increased working capacity • Hydraulic 3-jaw chuck, Ø 200 mm • Sauter tool turret VDI 40 with 8 tool stations and live tooling • Hardened and precision-ground ball screws for high rapid traverse speeds on all axes • Manual tool measurement capability • Tailstock with hydraulic quill • Heat exchanger • Portable electronic handwheel with enabling button and emergency-stop impact switch greatly simplifies program setup • Belt-type chip conveyor • Work light for complete illumination of the work area • Coolant system with cleaning pistol Linear guides • Maximum static and dynamic rigidity • High positioning accuracy • Smooth, backlash-free movement • Hydraulic VDI 40 turret • All 12 positions powered by an integrated motor, rated for speeds up to 4,000 rpm Machine bed • Heavily ribbed • 45-degree slant • High rigidity and durability • Facilitates chip removal SAFETY Integrated Overall package • Safety Integrated • Residual material detection and processing • ShopMill step programming • Network drive management • 3D simulation • Trace recording SIEMENS OSS Plus additional package • 12 months; Item No. 3589020 • 24 months; Item No. 3589021 • 36 months; Item No. 3589022 Dimensions and Weights Length approx. 4,570 mm Width/Depth approx. 1,845 mm Height approx. 1,955 mm Weight approx. 4,200 kg Work Area Chuck diameter: 320 mm Turning length: 475 mm Swing over bed: 570 mm Swing over cross slide: 400 mm C-Axis Angular accuracy: 51" Repeatability: 20" Motor Torque X-axis: 11 Nm Z-axis: 11 Nm Speed range: 30 – 4,000 rpm Rapid traverse speed X-axis: 24 m/min Z-axis: 30 m/min Electrical Data Connection voltage: 400 V Network frequency: 50 Hz Electrical connection Total connected load: 40 kVA Accuracy Isdew Ebmiepfx Ah Njal Repeatability: ±0.002 mm Positioning accuracy: ±0.004 mm Chuck passage diameter: 51 mm Slant bed: 45° Tailstock Mount: MT 5 Quill stroke: 100 mm Quill diameter: 100 mm Quill actuation: hydraulic Spindle Spindle mount: DIN ISO 702-1 No. 6 Main spindle hydraulic chuck: 200 mm Spindle nose: A2-6 Main spindle bore: 65 mm Travel X-axis: 235 mm Z-axis: 530 mm Vertical spindle Continuous duty motor output S1: 11 kW Motor output S6-30% duty cycle: 22 kW Drive motor torque: 70 Nm Drive motor torque S6-30% duty cycle: 140 Nm Feed Force Feed force X-axis: 8.4 kN Feed force Z-axis: 5.6 kN Tool Turret Type: Servo VDI 40 - DIN5480 Number of tool stations: 12 Drive motor output: 4.82 kW Max. permissible speed at tool coupling: 6,000 rpm Max. tool torque: 20 Nm

Condition: like new (used), Year of construction: 2022, operating hours: 1,496 h, functionality: fully functional, turning diameter over cross slide: 600 mm, turning length: 510 mm, turning diameter: 300 mm, spindle bore: 51 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 205 mm, travel distance Z-axis: 560 mm, spindle motor power: 15 W, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 36 m/min, type of input current: AC, overall weight: 3,600 kg, power: 30 kW (40.79 HP), input voltage: 400 V, Equipment: documentation/manual, rotational speed infinitely variable, 5-axis CNC lathe "DN Solutions model LYNX 2100LMSA" with sub-spindle, driven tools and CNC FANUC i-PLUS iHMI complete with "TOP model FUSION" bar loader. Ijdstq Aylepfx Ah Neal

Condition: used, Year of construction: 2010, turning length: 6,500 mm, turning diameter: 880 mm, spindle bore: 165 mm, controller manufacturer: Siemens, controller model: 840 D, _____ In General: Year of manufacture:2010 Control system:Siemens 840 D Rotation diameter:900 mm Turning diam.: 880 (750) mm Turning length:approx. 6,500 mm Spindle bore: 165 mm Tool holder:Capto C 8 Spindle: Speed:1,600 rpm Power: 60 kW Torque:4,472 Nm C-axis: 0,001° Spindle boar:165 mm Iedpfx Aox Axyljh Njal 3-Jaw Chuck: SMW Autoblock KNCS-N-630-165 Tool carrier (X/Y/Z): Technology:Swivel head with milling spindle Speed:6,000 rpm Power:30 kW Tool holder:Capto C 8 Torque:315 Nm X-axis:920 mm Y-axis:500 mm (-200/+300 mm) Z-axis:6,870 mm B-Axis: 200° (-110° / +90°) Tailsstock + Steady rest: Quill diameter:180 mm Quill stroke:200 mm Steady rest slides: 2 pieces, 400 mm wide Steady rest I: SMW Autoblock SLU (45-310 mm) Steady rest II: SMW Autoblock SLU (125-460 mm) Tool magazin I: Technology: Wheel magazine (double) Number of stations: 72 Tool changer: Double gripper on shuttle Tool diameter max.: 110 mm (250 mm) Tool length max.: 800 mm Tool weight max.: 25 kg Tool magazin II: Technology: Pick-up magazine Max. usable length: 1,550 mm Max. usable weight: 150 kg Equipment: Tool magazine:72 stations Chip disposal:Chip conveyor Coolant supply:Internal coolant system Coolant temperature control:Immersion recooler Workpiece measurement: Touch probe Steady rest:2x SMW Autoblock Lynette 3-Jaw chuck: SMW Autoblock KNCS-N-630-165 Tool holder: Various Capto C8

Condition: as good as new (ex-display), Year of construction: 2024, Machine is in the exhibition and was only used for demonstration purposes. Optiturn S400 HSC CNC Premium CNC lathe direct from the manufacturer. S400 HSC - The OPTIMUM Premium CNC milling machine with Siemens control SINUMERIK 828D is characterized by performance, speed, precision and long service life. Heavy-duty design - Compact design - .SIEMENS servomotors in all axes - Renishaw measuring arm for tool measurement - All servomotors with integrated encoder for maximum accuracy - Main spindle designed as motor spindle - 45° inclined bed design for particularly large machining diameters and unhindered chip flow into the chip flow into the chip tray - Hydraulic three-jaw lathe chuck Ø 170 mm with soft jaws - Servo tool changer VDI 30 with 12 tool positions - Hardened and precision-ground ball screws for high rapid traverse speeds in all axes axes - Faster tool change speed - High hydraulic clamping force - Heavy-duty cutting without vibration, to realize machining automation and high efficiency in extreme cases - Dimensionally stable linear guides ensure a long service life thanks to maximum static and dynamic rigidity rigidity - Device for manual tool measurement - Heat exchanger - Portable, electronic handwheel with enabling switch and emergency stop switch makes it much easier to run in programs. programs considerably - Belt-type chip conveyor ensures efficient chip removal - Work light for complete illumination of the work area - Coolant device with cleaning gun - RJ45 and power interface - EMC (electromagnetic compatibility) Ijdpfx Ajw Ebn Hoh Noal - Additional package SIEMENS material liability for defects and free online/on-site service OSS Plus see "Additional package SIEMENS OSS Plus" on page 117 - 1 year maintenance contract Basic included Machine data Electrical connection 400 V / 3 Ph ~50 Hz Total connected load 25 kVA Spindle Drive motor S1 operation 11.6 kW Torque drive motor S1 operation 65 Nm Drive motor S6-30% operation 14.4 kW Torque drive motor S6-30% operation 81 Nm Spindle holder A2-5 Spindle bore Ø 56 mm Chuck opening Ø 45 mm Hydraulic lathe chuck Ø 170 mm Coolant system Coolant pump power 700 W Tank capacity 160 liters Hydraulic system Hydraulic pump output 1.5 kW Tank capacity 36 liters Machine data Turning Ø max. 220 mm Turning length 320 mm Rotation Ø over cross slide 300 mm Rotation Ø over machine bed 500 mm Inclined bed 45° Speed range Spindle speeds* 30 - 6,000 min-1 Tool changer Type Servo VDI 30 Number of tool positions 12 Accuracy Repeat accuracy ± 0.004 mm Positioning accuracy ± 0.004 mm Travel distance X-axis 180 mm Z-axis 350 mm Feed force Dynamic X-axis 3.6 kN Z-axis 3.6 kN Feed speed X-axis / Z-axis 30 m/min. Motor torque X-axis / Z-axis 6 Nm Dimensions Length x width x height 2,000 x 2,250 x 1,550 mm Total weight 2,600 kg

Condition: reconditioned (used), Year of construction: 2008, functionality: fully functional, turning diameter over cross slide: 900 mm, turning length: 2,001 mm, turning diameter: 650 mm, spindle bore: 166 mm, spindle speed (max.): 1,500 rpm, spindle speed (min.): 15 rpm, travel distance X-axis: 362 mm, travel distance Z-axis: 2,155 mm, spindle motor power: 45 W, rapid traverse X-axis: 16 m/min, rapid traverse Z-axis: 18 m/min, total height: 2,170 mm, total length: 6,750 mm, total width: 2,250 mm, overall weight: 11,750 kg, bar passage: 165 mm, Equipment: documentation/manual, rotational speed infinitely variable, 2-axis CNC lathe “DOOSAN mod. PUMA 480L” with Fanuc 21i-TB CNC complete with “AUTOBLOK K5Z” steady rest Iasdpfx Ahju Ut Elo Nel

Condition: used, Year of construction: 2007, controller manufacturer: Siemens, controller model: 840 D, _____ Description: Year of manuf. : 2007 Control : Siemens 840 D Turning diam. : 250 mm Turning length : 650 mm In General: Year of construction:2007 Control:Siemens 840 D Bar capacity:65 mm Turning diameter:350 mm Turning length:650 mm Main spindle: Technology:Motor spindle Speed:5,000 rpm Power max.:35 kW Torque max.:370 Nm C-axis:0.001 Bar capacity:65 mm Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Hollow clamping cylinder Sub spindle: Technology:Motor spindle Speed:5,000 rpm Power:26 kW Torque:290 Nm Iasdoxtr Iwopfx Ah Nsl C-axis:0.001 Chuck:Hainbuch Spanntop size 65 Clamping cylinder:Partial hollow clamping cylinder Z-axis:670 mm X-axis:175 mm Tool carrier i (X/Y/Z): Technology:Tool turret, 12 stations Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:300 Y-axis:80 mm ( +/- 40 mm) Z-axis:650 mm Tool carrier II (X/Z): Technology:Tool turret, 12 stations Tool holder:VDI 30 Tool drive:4,000 rpm, 11 kW, 28 Nm X-axis:180 Z-axis:650 mm Equipment: Chip disposal:Chip conveyor Coolant supply:IKZ system Measuring systems:Direct in all X-axes (glass scales) Bar loader:IRCO Breuning Part removal:Finished part gripper + indexing belt Emulsion mist separator:Mechanical Set-up mode:Electronic handwheel

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optiturn L44 CNC Premium CNC lathe direct from the manufacturer. L44 CNC - The OPTIMUM Premium CNC milling machine with Siemens SINUMERIK 828D control is characterized by performance, speed, precision and long service life. Dimensions and weights Width/depth max. 2300 mm Length approx. 2530 mm Width/depth approx. 1595 mm Height approx. 1795 mm Weight approx. 2600 kg Working areas Lathe chuck diameter 150 mm Lathe chuck Hydraulic control of the clamping movement Center height 223 mm Center width 850 mm Swing diameter over machine bed 446 mm Swing diameter in the bed bridge 520 mm Swing diameter over cross slide 240 mm Bed width 300 mm Motor torque X-axis 6 Nm Ijdsw Ea Tujpfx Ah Njal Z-axis 8.5 Nm Speed range Number of speed ranges 1 Speed range 10 - 3000 min¯¹ Electrical data Drive motor power 7 kW Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 23 kVA Accuracy Repeat accuracy ± 0.005 mm Positioning accuracy ± 0.005 mm Hydraulic system Motor output 0.75 kW Tank capacity 50 l Coolant system Coolant pump output 270 W Tank capacity 90 l Machine data Chuck opening diameter 40 mm Motor(s) Torque drive motor 33 Nm Tailstock Mounting MK 4 Quill stroke 165 mm Quill diameter 52 mm Spindle Spindle holder DIN ISO 702-1 No. 5 Spindle bore/bar passage diameter 52 mm Control system Type Sinumerik 828D PPU 240 System software SW 24 CNC memory 3 MB Look Ahead 50 Block change time 3 ms Number of tools 128 Travel distance X-axis 250 mm Z-axis 760 mm Vertical spindle Power drive motor continuous operation S1 7 kW Power drive motor S6-30 % operation 16 kW Drive motor torque 33 Nm Drive motor S6-30 % operation 80 Nm Feed rate Speed X-axis 15000 mm/min Z-axis 15000 mm/min Feed force Feed force X-axis 7.5 kN Feed force Z-axis 5.3 kN Tool changer Hydraulic type; VDI 30 Number of tool positions 8 pcs Mounting height, width square max. 20 x 20 mm Boring bar mounting diameter max. 25 mm SIEMENS SAFETY INTEGRATED Equipment Main spindle - Solid design Machine bed - Heavily ribbed - High rigidity and durability Guideways - Stable flat bed guide Recirculating ball screw - For high rapid traverse speeds in all axes - Less wear and tear - For high positioning and repeat accuracy Cast body - Hardened HRC48-52 and heat-treated Machine feet - Six pieces - Optimum alignment of the machine Heat exchanger - Closed switch cabinet with intelligent cooling management - Optimum temperature even at high outside temperatures Tool changing system - Eight tool stations - Hydraulic VDI30 tool changer - Pick-up height max. 20 mm Hydraulic unit - Motor power 750 W - Tank capacity 50 liters - Clamping pressure / operating pressure 2,500 - 2,942 kPa Three-jaw chuck - Hydraulic three-jaw lathe chuck Ø 150 mm - Hydraulic loosening and clamping via foot switch - Simple clamping of workpieces - Hard and soft block jaws Central lubrication system - Automatic supply at intervals - Reduces wear on bearings, ledges and ball screws - With float switch. An acoustic signal sounds if the oil level is too low

Condition: good (used), Year of construction: 2011, functionality: fully functional, turning length: 760 mm, turning diameter over cross slide: 780 mm, turning diameter: 376 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 51 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 4,000 rpm, Equipment: rotational speed infinitely variable, 6-axis CNC lathe with sub-spindle, driven tools and Y axis Ijdstvl U Hopfx Ah Nsal

Condition: used, Year of construction: 2011, controller manufacturer: Mitsubishi, controller model: TX-8i, _____ Description: Year of manuf. : 2011 Control : Mitsubishi TX-8i Turning length : 50 mm Mainspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Barcapacity:15 mm Movement in Z1:50 mm Workpiececlamping:Collet chuck Subspindle: Technology:Belt-driven spindle Speed:12.000 rpm Power:4 kW Torque:7 Nm Movement in X4/Z4:222/139 mm Rapid travers in X3/Z4:15 m/min Workpiececlamping:Collet chuck Toolcarrier I (X/Y): Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Movement in X1/Y1:35/37,5 mm Rapid travers in X1/Y1:15 m/min Toolcarrier II (X/Z): Technology:Turret with 6 stations (Complete drive) Taper:ø25 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Movement in X2/Z2:35/50 mm Rapid travers in X2/Z2:15 m/min Front attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:12.000 rpm, 4 kW, 7 Nm Number of driven stations:4 Movement in X3/Z3:222/139 mm Rapid travers in X3/Z3:15 m/min Iajdjx E Inmepfx Ah Nel Rear attachment: Number of stations:4 Taper:ø28 mm Distance between stations:32 mm Tooldrive:8.000 rpm, 1,5 kW, 2,4 Nm Number of driven stations:4 Movement in X4:39 mm Rapid travers in X4:15 m/min Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Coolant pump Rawmaterialfeed:Bar loader, FMB minimag 20/3200 Finishedpartremoval:Workpiecehandling (Tube) Oilmistseparation:Interface mechanical prepared Toolholder:Misc. static and driven toolholder

Condition: as good as new (ex-display), Year of construction: 2025, Optiturn L34 HS CNC lathe directly from the manufacturer. L34 HS - The OPTIMUM CNC lathe with Siemens control SINUMERIK 808D Advanced PPU 150. Strutted machine bed made of gray cast iron - Elaborate spindle bearings - Emergency stop switch - Central lubrication - Spindle and feed motors from Siemens - Maintenance-friendly protective housing - Rear access flap for maintenance - Safety switch on the front sliding door - Turning turret is located behind the turning center (left turning tool) - Linear guide - Software package "SINUMERIK 808D on PC" included. (Practical training software, so that workpieces can be programmed and simulated offline on the PC. Free to download Technical data Electrical connection 400 V / 3 Ph ~50 Hz Total connected load 6.5 kVA Spindle Drive motor S1 operation 3.7 kW Torque drive motor S1 operation 23.6 Nm Torque at the spindle 40 Nm Spindle holder DIN 6350 A2-3 Spindle bore Ø 46 mm Coolant system Coolant pump output 95 W Tank capacity 75 liters Machine data Center height 165 mm Center width 600 mm Rotation Ø over cross slide Ø 146 mm Rotation Ø over machine bed Ø 350 mm Speed range Yvwdh0 Spindle speeds* 30 - 3500 min-1 Tool turret Type electric Number of tool positions 6 tools Mounting height, width square max. 16 mm Mounting diameter of boring bar max. 16 mm Iodpfx Ahow Ebm Nj Neal Accuracy Repeat accuracy ± 0.01 mm Positioning accuracy ± 0.01 mm Travel distance X-axis 145 mm Z-axis 465 mm Feed speed X-axis 6,000 mm/min. Z-axis 8,000 mm/min. Machine leasing possible via Siemens Finance. Liquidity required.

Condition: used, Year of construction: 2014, controller manufacturer: Siemens, controller model: 840 Dsl, _____ Description: Iaedpfxoxy Ub Ho Ah Nol Year of manuf. : 2014 Control : Siemens 840 Dsl Turning diam. : 120 mm Turning length : 380 mm In General: Year of manufacture:2014 Control system:Siemens 840 Dsl Turning diameter:120 mm Turning length:380 mm Bar capacity:32 Main spindle: Technology:Belt spindle Speed:8,000 rpm Bar capacity:32 mm C-axis:0.001° Sub spindle: Technology:Belt spindle Speed:8,000 rpm Bar capacity:32 mm C-axis:0.001° Tool carrier: Technology:Tool turret Number of stations:16 Tool drive:8 stations Speed:6,000 rpm Tool holder:VDI 16 X-axis:400 mm Z-axis:400 mm Automation: Technologie:Industrieroboter Hersteller:Fanuc Typ:ARC Mate 100iC 6L Equipment: Position measuring systems:Directly in X/Z-axis Measuring probe:Marposs T18 Coolant supply:Minimum quantity lubrication Automation:Fanuc robot system

Condition: as good as new (ex-display), Year of construction: 2025, Optiturn L28 HS CNC lathe directly from the manufacturer. L28 HS - The OPTIMUM CNC lathe with Siemens control SINUMERIK 808D Advanced PPU 150. Strutted machine bed made of gray cast iron - Elaborate spindle bearings - Emergency stop impact switch - Central lubrication - Reference switch - Maintenance-friendly protective housing - Rear access flap for maintenance - Safety switch on the front sliding door - Turning turret is located behind the turning center (left turning tool) - Linear guide - Software package "SINUMERIK 808D on PC" included. (Practical training software, so that workpieces can be programmed and simulated offline on the PC. Free to download free of charge - Two-year SIEMENS warranty included Technical data Electrical connection 400 V / 3 Ph ~50 Hz Total connected load 3.75 kVA Spindle Drive motor S1 operation 2.2 kW Torque drive motor S1 operation 14 Nm Torque at the spindle 28 Nm Spindle holder DIN 6350 A2-3 Spindle cone 5C Spindle bore Ø 30 mm Cooling lubricant system Coolant pump output 95 W Tank capacity 25 liters Machine data Center height 169 mm Center width 430 mm Rotation Ø over cross slide Ø 200 mm Rotation Ø over machine bed Ø 300 mm Speed range Spindle speeds* 40 - 4,000 min-1 Tool turret Iasdpfsw Ebngsx Ah Njl Type electric Number of tool positions 6 tools Mounting height, width square max. 16 mm Mounting diameter of boring bar max. 16 mm Accuracy Repeat accuracy ± 0.01 mm Positioning accuracy ± 0.01 mm Bhajn7pvcu Travel distance X-axis 145 mm Z-axis 465 mm Feed speed X-axis 10,000 mm/min. Z-axis 12,000 mm/min. Machine leasing possible via Siemens Finance. Liquidity required.

Condition: used, _____ Description: Year of manuf. : 2022 Ijdpfx Aewu I Irsh Noal Control : Okuma OSP-P300 SA Turning diam. : 650 mm Turning length : 1000 mm Main spindle: Technology:Motor spindle Speed:4,200 rpm Power:22 kW Torque:427 Nm spindle bore:91 mm Hollow clamping cylinder:86 mm C-axis:High precision package Chuck:SMW KNCS-N 275-86 K8 Sub spindle: Technology:Motor spindle Speed:5,000 rpm Power:22 kW Torque:420 Nm spindle bore:80 mm Hollow clamping cylinder:77 mm C-axis:High precision package Chuck:SMW BHD-FC 210-52-3 Tool carrier X/Y/Z/B: Technology:Milling spindle Speed:12.000 rpm Power:22 kW Torque:120 Nm Tool holder:HSK 63 Y-axis:250 mm (+/- 125 mm) B-axis:240° Tool magazin: Number of stations:80 Equipment: Measuring systems:Direct in X/Y/Z axis (glass scales) Chip disposal:Chip conveyor Coolant supply:IKZ system, 70 bar Coolant temperature control:Deltatherm E4 Chip rinsing:working area, manual gun Accuracy package:C-axis high accuracy Software package:5-axis auto-tuning Software option:Multifunction tool Gear cutting software package:Gear hobbing, gear peeling Control extension:Dialogue programming Workpiece measurement:Renishaw measuring probe Tool measurement:Tool setter Tool breakage monitoring:Renishaw TRS2 B-axis:NC function and turning function Bar loader:LNS Quickload Servo III+ Automation preparation:Robot interface Work area door:Automatic Set-up mode:Electronic handwheel

Condition: used, Year of construction: 2021, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Description: Year of manuf. : 2021 Control : Siemens 828D - ShopTurn Turning diam. : 405 mm Turning length : 956 mm Mainspindle: Technology:Belt-driven spindle Speed:3.000 rpm Power (max.):42 kW Torque (max.):858 Nm Bar capacity:91 mm Workpiececlamping:3-Jaw chuck, Samchully HS-12 Toolcarrier (X/Z): Technology:Turret with 12 stations Taper:BMT65 Tooldive:5.000 rpm, 5,6 kW, 40 Nm Movement in X/Y/Z:245/1.040 mm Rapid travers in X/Y/Z:24/30 m/min Tailstock: Technology:Towed with hydraulic Quill Cone:MT5 Quill-ø:110 mm Iasdpfoxybxfex Ah Nsl Stroke:100 mm Equipment/Accessory: Chipmanagement:Chip conveyor Coolingmanagement:Internal coolant pump with Oilskimmer and Highpressure, 10bar Toolmeasurement:Automatic Measuringarm, Marposs Rawmaterialfeed:Interface Barloader prepared Finished Partremoval:Parts catcher with Box Oilmistseparation:Interface machanical prepared Setup operations:Electronic Handwheel Further Equipment:Rinsing pistol

Condition: used, Year of construction: 2023, controller manufacturer: Siemens, controller model: 828D - ShopTurn, _____ Description: Year of manuf. : 2023 Control : Siemens 828D - ShopTurn Turning diam. : 360 mm Turning length : 520 mm Main spindle: Technology:Belt spindle Speed:6,000 rpm Power (max.):18.5 kW Bar capacity:52 mm Workpiece clamping:3-jaw chuck, Samchully MH-206 V1 Tool holder: Technology:12-station turret Iodpfxoxybxxe Ah Noal Tool holder:BMT55 Tool drive:5,000 rpm Features/Accessories: Chip management:Chip conveyor Coolant management:IKZ pump with oil skimmer and high pressure, 10 bar Tool measurement:Automatic measuring arm Automation:Prepared Finished part removal:Parts catcher with collection box Setup operation:Electronic handwheel

Condition: used, _____ Description: Year of manuf. : 2022 Control : Fanuc 0i-TF Turning diam. : 580 mm Turning length : 3250 mm Mainspindle: Technology:Belt-driven spindle with Gearbox Speed:1.000 rpm Isdpewt Iwqofx Ah Njal Power (max.):45 kW Torque (max.):4.008 Nm Barcapacity:205 mm Workpiececlamping I:3-Jaw chuck, Autogrip AP-230 ø535 mm Workpiececlamping II:Manual 3-Jaw chuck, Chandox SK20 (Rearside Spindlehead) Toolcarrier (X/Y/Z): Technology:Turret with 12 stations Taper:BMT 75 Tooldrive:3.000 rpm, 7 kW, 83 Nm Movement in X/Y/Z:340/160/3.250 mm Rapid travers in X/Y/Z:20/7/12 m/min Tailstock: Technology:Towed tailstock with programmable Sleeve Stroke:150 mm Cone:MK5 Equipment/Accessory: Chipmanagement:Chipconveyor Coolingmanagement:Coolant pump Toolmeasurement:Measuringarm, Renishaw RP3 Oilmistseparation:Mechanical extraction, AR Filtrazioni ARNO 3VF YF Shaftprocessing:Manual Steady rest, ø150-300 mm Toolholder:Misc. static and driven toolholder Setup operations:Electronic Handwheel Further Equipment:Automatic Door (pneumatic), Trafo, Oilskimmer Further Accessory:Misc. Jaws and EWS Quickchangeinserts

Condition: used, Year of construction: 2007, controller manufacturer: Siemens, controller model: 840 D, _____ Description: Year of manuf. : 2007 Control : Siemens 840 D Turning diam. : 100 mm Turning length : 580 mm In General: Year of manufacture:2007 Control system:Siemens 840 D Turning diameter:100 mm Turning length:approx. 580 mm Bar capacity:32 mm Main spindle: Technology:Motorised spindle Speed:8,000 rpm Torque max.:100 Nm Power max.:26 kW C-axis:0.001° Bar capacity:32 mm Clamping cylinder:Hollow clamping cylinder Chuck:Hainbuch Spanntop Sub spindle: Technology:Motorised spindle Speed:8,000 rpm Max. torque:100 Nm. Max. power:26 kW C-axis:0.001° X-axis:145 mm Z-axis:380 mm Clamping cylinder:Partial hollow clamping cylinder Iedpfxexzmp Ee Ah Neal Chuck:Hainbuch Spanntop Tool carrier I (X/Y/Z): Technology:Tool turret Number of stations:12 units Tool holder:VDI 25 Tool drive:6,000 rpm X-axis:220 mm Y-axis:60 (+/- 30) mm Z-axis:320 mm Tool carrier II (X/Z): Technology:Tool turret :Number of stations. 12 units Tool holder:VDI 25 Tool drive:6,000 rpm X-axis:120 mm Z-axis:345 mm Equipment: Chip management:Chip conveyor Coolant supply:Internal coolant system Bar loader:Irco Breuning Parts removal:Parts gripper + indexing conveyor Tailstock:Stroke 250 mm, quill MK 3 Chuck:2x Hainbuch Spanntop Tool holder:Various driven and static holders
