Used Cnc Router for sale (8,850)

Condition: good (used), Year of construction: 2012, functionality: fully functional, Schiess CNC vertical lathe with C axis, year 1992, retrofitted in 2012 Fedpfoxpqm Rex Ah Njgc CNC: NUM 1060 FLEXIUM 2 tables, table diameter 2000mm – max turning diameter 2500mm – max table speed 201 rpm – table power 56 KW Load capacity (table included): 16,000kg Movable crossrail with 12 positions, 50mm pitch Available space under spindle nose: min. 795mm, max. 1345mm RAM Z stroke: 1000mm C axis with 360,000 positions – milling spindle max speed 1600 rpm – milling spindle power 22KW – 2 gear ranges Tool magazine: 20 turning tool positions, 35 milling tool positions 1 milling head WIDAFLEX UTS80 1 milling head ISO 50 Renishaw MP60 touch probe (for parts) Tool presetter – Transmit function: G20 / G21 – No rigid tapping Chip conveyor Front door: partial opening M0 / full opening

Condition: used, Year of construction: 1997, travel distance X-axis: 3,708 mm, travel distance Y-axis: 1,208 mm, travel distance Z-axis: 1,002 mm, feed length X-axis: 5,000 mm, feed length Y-axis: 5,000 mm, feed length Z-axis: 5,000 mm, rapid traverse X-axis: 15 m/min, rapid traverse Y-axis: 15 m/min, rapid traverse Z-axis: 15 m/min, spindle speed (max.): 3,000 rpm, spindle speed (min.): 35 rpm, CNC Bed-Type Milling Machine – Universal ZAYER 20 KF 4000 Year of manufacture: 1997 CNC control: HEIDENHAIN TNC 426/430 Technical specifications: X travel: 3708 mm Y travel: 1208 mm Z travel: 1002 mm Table size: 4000 x 1000 mm Tool holder: SK 50 Spindle speeds: 35–3000 rpm Spindle motor: 22 kW Feed range: 6–5000 mm/min Rapid traverse: 15 m/min Machine weight: approx. 19.5 t ADDITIONAL INFORMATION Fgedpfjwtpfpex Ah Nsc Electronic handwheel Automatically swivelling milling head vertical/horizontal +/-120° (stepless) Milling head automatically swivelling in the rear axis / 90° rotation Coolant system The machine can be inspected under power. Delivery time: immediately Sale from location Westerkappeln Dismantling, loading available on request.

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Equipment: documentation/manual, For sale is a state-of-the-art CNC-controlled waterjet center consisting of 2 machines Fgjdpfeua U Tzsx Ah Nsc Machine 1: Robot with processing cell and integrated SERVO turning table. Machine 2: Robot with 2 processing cells and 2 integrated SERVO turning tables. This waterjet center is ideal for companies looking for a flexible and efficient solution for demanding cutting tasks. They are characterized by high precision, flexibility and reliability. - Robot arm NJ-16-3.1 Foundry: The robot has a load capacity of 16 kg and a working radius of 3100 mm. It is particularly robust and flexible, equipped with an IP65 protection class and is flange-mounted directly behind the cell. - SERVO turning table: With a maximum load of 500 kg and a faceplate center width of 2800 mm, the interpolating turning table offers maximum precision and repeatability. - Processing cell: The processing cell measures 2350 x 4500 mm and is equipped with sound insulation. - High-speed roller shutter: Integrated into the cell wall, the high-speed roller shutter ensures safe access and complies with Machinery Directive 2006/42/EC. - SL-VI 30 Plus high-pressure pump: This pump achieves a pressure of up to 4136 bar, ideal for precise cutting processes. - Water cutting head: The water cutting head is a central component of the system and offers maximum precision. It is equipped with a high-pressure line feed, a manual change system for quick replacement. Additional features: - CNC control: Siemens 840D controller with integrated PROFINET for controlling the robot and integrated S7 319 safety technology. - Cyclone separator: Efficient system for particle separation - Programming options: The robot is programmed using simulation software, machining takes place in the CAM system and the programs are transferred via G-code. Main features Rotary table cells: - Robot arm NJ-16-3.1 Foundry: This robot has a load capacity of 16 kg and a working radius of 3100 mm. With an IP65 protection class, it offers a high level of robustness and flexibility. - SERVO rotary tables: The system is equipped with two SERVO rotary tables, each with a load capacity of 500 kg. These rotary tables enable precise machining of large workpieces with a maximum component size of 1000 x 1000 x 1000 mm. The repeat accuracy is ±0.15 mm with a rotation of 180° in just 5 seconds. - Machining cell: The machining cells each have a size of 2350 x 4250 mm. - 2 high-speed roller shutters: Integrated into the front wall of each cell, the cold-resistant and antistatic high-speed roller doors ensure safe access to the processing cell. The waterjet center offers outstanding processing flexibility and is suitable for various industrial PUR waterjet applications. Price on request or guide price < €300,000 Contact: For more information or to arrange a viewing appointment, please contact us on the telephone number provided.

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 162881, turning diameter over cross slide: 410 mm, turning length: 1,000 mm, turning diameter: 340 mm, spindle bore: 80 mm, rotational speed (max.): 3,800 rpm, TECHNICAL DETAILS Swinging diameter over bed: 530 mm Swinging diameter over carriage/slide: 410 mm Distance between centers: 1,000.00 mm Maximum turning diameter: 340 mm Maximum machining length: 1,000 mm Travel X-axis: 260 mm Travel Z-axis: 1,016 mm Travel X-axis (B-axis): 139 mm Travel Z-axis (B-axis): 965 mm C-axis: 360° Control: Okuma OSP-P200LA Spindle speed: 38–3,800 rpm Speed ranges: stepless, automatic range selection Spindle nose: Option A2-8 Big Bore Spindle bore: 80 mm Main drive motor: 22.37 kW Fedpfsy U T Dljx Ah Njgc Torque: 412.17 Nm Upper multitasking turret: V-12 NC turret Lower turret: V8 (VDI) Indexing time without lifting: 0.18 s Speed of driven tools: 45 – 4,500 rpm Motor for driven tools: 7.08 kW Feeds X/Z: 333.16 / 416.56 mm/s Feed C: 3.333 rpm Tailstock spindle diameter: 90 mm Tailstock taper: MK #5 Tailstock travel: 120 mm MACHINE DETAILS Machine weight: 8,800 kg Supply voltage: 220/480 V Phases: 3-phase Frequency: 60 Hz Rated apparent power: 31 kVA Full load current: 81.7/37.5 A Largest motor rated current: 96 A Short-circuit rated values: 30/10 kA

Condition: ready for operation (used), Year of construction: 2022, functionality: fully functional, turning diameter: 220 mm, spindle speed (max.): 4,000 rpm, travel distance X-axis: 240 mm, travel distance Y-axis: 90 mm, travel distance Z-axis: 580 mm, No minimum price – guaranteed sale to the highest bidder! The new price of the machine was €342,000! Due to inquiries, the auction has been extended by 2 weeks. TECHNICAL DETAILS Max. bore / max. passage: 220 mm Max. turning diameter: 220 mm Distance spindle nose – tailstock center: 614 mm Center distance: 800 mm Travel X1 and X2: 167.5 mm Travel X3: mm Travel Z1 and Z2: 515 mm Travel Z3: 580 mm Travel Y: +45 / -45 mm Rapid traverse X: 30 m/min Rapid traverse Z: 30 m/min Rapid traverse Y: 20 m/min Axis acceleration: 9.8 m/s² Main spindle Max. speed: 4,000 rpm Outer diameter front bearing: 170 mm Inner diameter front bearing: 110 mm Spindle nose: ASA 6" A2 Spindle inner diameter: 72.5 mm Draw tube bore: 66 mm Chuck diameter: 210 mm Chuck bore: 66 mm Spindle power max. / S3 25% / S1: 35.5 / 28.3 / 23.5 kW Spindle torque max. / S3 25% / S1: 205 / 180 / 150 Nm Counter spindle / Sub spindle Max. speed: 4,000 rpm Outer diameter front bearing: 170 mm Inner diameter front bearing: 110 mm Spindle nose: ASA 6" A2 Spindle inner diameter: 72.5 mm Draw tube bore: 66 mm Chuck diameter: 210 mm Chuck bore: 66 mm Power max. / S3 25% / S1: 35.5 / 28.3 / 23.5 kW Torque max. / S3 25% / S1: 205 / 180 / 150 Nm Tailstock / Counter support Morse taper: CM3 Tailstock travel: 580 mm Max. force: 500 kgf Turret / Tool holder Number of stations: 24 Tool cross-section: 20×20 / 25×25 mm Tool change time: 0.1 s Clamping force at 45 bar: 3,200 kgf Driven tools Number of rotary stations: 12 Max. speed: 12,000 rpm Power max. / S1: 14 / 10 kW Max. torque max. / S1: 42 / 32 Nm Liquids / Tanks / Supply Coolant tank, side: 510 l Coolant tank, rear: 330 l Hydraulic oil tank: 18 l Lubricating oil tank: 4 l Installed power: 87 kVA Fedpfx Ahsy Ukhhj Negc Operating voltage: 400 V, 50 Hz ±5% Optional voltage according to table: [230 V, 50 Hz ±5%] Max. ambient temperature: 35 °C MACHINE DETAILS Control model: FANUC 31iPLUS Dimensions & Weight Dimensions (L x W x H): 2,860 × 2,377 × 2,289 mm Total weight: 11,000 kg Internal volume: 1.7 m³ EQUIPMENT Coolant supply through left spindle Hainbuch AXZUG 65 collet chuck (standard) 2702/0008 for left spindle SMW-Autoblok BBD 175 3-jaw chuck 56 with a set of soft jaws for right spindle Measuring arm Hinged band chip conveyor with side discharge Upper turret station (T1) double high-pressure pump (6+15 bar, 55 l/min) Inner turret station (12) double high-pressure pump (6+15 bar, 55 l/min) Machine status light Automatic part unloader Part unloader with pneumatic opening and closing function for catching ejected parts Pneumatic part ejector for counter spindle with 100 mm stroke, stroke adjustment and end position sensor Unimag interface for bar feeder

Condition: ready for operation (used), Year of construction: 2009, operating hours: 22,000 h, functionality: fully functional, turning length: 600 mm, turning diameter over cross slide: 410 mm, spindle speed (max.): 22,000 rpm, controller model: Heidenhain 4290, Submitting a bid obligates the buyer to collect the machine by June 24, 2026! The machine will be dismantled on June 17, 2026, and then stored temporarily. The Z1 linear guide was recently renewed, and the S2 revolver drive was recently replaced. Fsdpfszcpwcox Ah Nogc TECHNICAL DETAILS Turning length: 600 mm Turning diameter over cross slide: 410 mm Spindle speed: 22,000 rpm Tool turret: 12-position Tool holder: VDI 40 MACHINE DETAILS Control system: Heidenhain 4290 Operating hours Total operating hours: approx. 87,000 h Spindle hours: approx. 22,000 h EQUIPMENT Large accessories package Powered tools from WTO Note: The seller can offer transport of the machine within Europe for an additional fee (offer upon request).

Condition: ready for operation (used), Year of construction: 2002, operating hours: 53,548 h, functionality: fully functional, machine/vehicle number: 01160014061, turning length: 630 mm, turning diameter: 420 mm, vice opening: 66 mm, control type: CNC control, Equipment: chip conveyor, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area Turning diameter: max. 420 mm Turning length: max. 630 mm Spindle bore: 66 mm Turret Tool head: 12 tools, Sauter VDI30 CNC control: 4290 Heidenhain Fgsdpfx Ahsza D Rfe Njc MACHINE DETAILS Electrical data Voltage: 400 V Auxiliary voltage: 230 V / 24 V Frequency: 50 Hz Current: 80 A Connected power: 44 kVA EQUIPMENT C-axis with driven tools Machine chip conveyor Documentation 2 driven tool holders External reference: 598

Condition: ready for operation (used), Year of construction: 2010, operating hours: 5,744 h, functionality: fully functional, machine/vehicle number: 6100000012E, turning length: 393 mm, turning diameter: 228 mm, spindle speed (max.): 3,000 rpm, vice opening: 51 mm, Equipment: chip conveyor, No minimum price – guaranteed sale to the highest bidder! Lathe equipped with a tailstock and chip conveyor! TECHNICAL DETAILS Working range Turning diameter: 228 mm Turning length: 393 mm Distance between centers: 51 mm Spindle speed: max. 3,000 rpm Turret Turret head: Sauter VDI30 MACHINE DETAILS Electrical connection data Voltage: 400 V Frequency: 50/60 Hz Weight: 3,500 kg Operating hours Power-on hours: 20694 Working hours: 5744 EQUIPMENT Chip conveyor with coolant tank and pumps 3 driven tool holders WTO 4 standard holders VDI30 Tool probe Chuck: Kitagawa 210 mm Tailstock Machine manuals Fedpeza D Iwsfx Ah Negc External reference: 603

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, turning diameter over cross slide: 75 mm, turning length: 325 mm, turning diameter: 180 mm, travel distance X-axis: 56 mm, travel distance Z-axis: 176 mm, TECHNICAL DETAILS Swinging diameter over bed: 180 mm Swinging diameter over cross slide: 75 mm Turning length: 325 mm Travel in X-axis: 56 mm Travel in Z-axis: 176 mm Spindle speed range: 20 - 6,300 rpm Spindle bearing diameter in the front bearing: 50 mm Fgedpfx Aozb Ekcsh Nec Feed force in Z-direction max.: 3,000 N Spindle bore: 30 mm MACHINE DETAILS Control: Fanuc 21T Main spindle power max.: 3.7 kW Voltage: 400 V Frequency: 50-60 Hz Dimensions & Weight Dimensions (L x W x H): 2,200 x 1,000 x 1,620 mm Machine weight approx.: 1 t EQUIPMENT Automatic chuck Various accessories Interface for bar feeder

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: W261, repeat accuracy: 0.05 mm, workpiece weight (max.): 6,300 kg, working length: 4,000 mm, working width: 2,250 mm, working height: 230 mm, No minimum price – guaranteed sale to the highest bidder! The machine’s last inspection was performed at the end of 2025 by a specialist company! TECHNICAL DETAILS Working area X: 4,000 mm Working area Y: 2,250 mm Working area Z: 230 mm Working area for round part machining, diameter max.: 440 mm Working area for round part machining, length max.: 3,700 mm Number of cutting heads: 1 to 4 Cutting carriage distance: max. 1,150 mm Positioning speed, axis-parallel X, Y max.: 60 m/min Positioning speed, simultaneous max.: 84 m/min Cutting speed max.: 50 m/min Travel speed min.: 0.001 m/min Machine tolerance according to VDI/DGQ 3441: ± 0.1 mm/axis Repeatability: ± 0.05 mm/axis Frame load capacity max.: 7,000 kg Load capacity per support rail: 110 kg Number of support rails max.: 70 Workpiece weight, flat part max.: 6,300 kg Workpiece weight, round part max.: 500 kg MACHINE DETAILS Water jet source: Bypump 50 APC Operating pressure: max. 3,800 bar Flow rate: 0 to 5 l/min Nozzle size, single-head operation: max. Ø 0.4 mm Nozzle size, dual-head operation: max. Ø 0.3 mm Nozzle size, dual-head operation: recommended Ø 0.28 mm Dimensions & Weight Machine dimensions (L x W x H): approx. 9,000 mm x 7,550 mm x 2,050 mm Weight: approx. 10,000 kg Operating Hours Operating hours: approx. 41,130 h Cutting hours, head 1 / head 2: 13,720 h / 956 h EQUIPMENT CNC rotary axis Motorized cutting carriage distance adjustment Four-jaw chuck Abrasive hopper Spare parts Note: The second head has been removed, and the cutting assembly has been mounted on head 1 as a spare part. However, the system can operate with two abrasive tools after a new cutting head has been procured. Fgjdpfx Ahozcwupj Njc The drilling spindle is seized.

Condition: ready for operation (used), Year of construction: 2015, operating hours: 43,196 h, functionality: fully functional, travel distance X-axis: 165 mm, travel distance Y-axis: 80 mm, controller model: Fanuc 310 is, spindle speed (max.): 5,000 rpm, counter spindle speed (max.): 5,000 rpm, No minimum price – guaranteed sale to the highest bidder! CNC turning center with comprehensive accessories! A wide range of like-new spare parts is also available! TECHNICAL DETAILS Travel X1 axis: 165 mm Travel X2 axis: 165 mm Travel Y1 axis: 80 (+50 / -30) mm Travel Z1 axis: 678 mm Travel Z2 axis: 640 mm Travel W2 axis: 690 mm Rapid traverse X/Y/Z/W axis: 30 m/min Acceleration X/Y/Z/W axis: 5 m/s² Main and counter spindle Power main spindle: 20 / 25 kW Power counter spindle: 17 kW Speed main spindle max.: 5,000 rpm Speed counter spindle max.: 5,000 rpm Bar diameter main spindle max.: 65 mm Bar diameter counter spindle max.: 45 mm Number of turrets: 2 Number of rotating tools per station: 12 driven positions Tool system: VDI 30 Speed driven tools: max. 4,000 rpm MACHINE DETAILS Control: Fanuc 310 is Coolant tank capacity: approx. 650 l Coolant pump capacity per turret: max. 20 l/min Pump pressure: 7 bar Connected power: 91 kVA Dimensions & Weight Machine dimensions (L x W x H): 4,500 x 1,990 x 2,300 mm Machine weight: approx. 9,500 kg Operating hours Power-on hours: 64,274 h Operating hours: 43,196 h EQUIPMENT IEMCA MASTER 865 MP 43 L bar loader Drive for slides 1 and 2, all 12 positions C-axis for main and counter spindle Y-axis for slide 1 Chip conveyor, belt type Counter spindle collet cleaning with coolant Workpiece discharge including belt Mechanical preparation for oil mist filter Electrical and software interface for bar loader Angular synchronization between main and counter spindle Automatic machine shutdown Fgodpfsza Alhox Ah Noc 2 additional inputs/outputs, 4 M-functions Thread drilling without compensation chuck Piece and time counter Software for polygonal turning for slides 1 and 2 Constant cutting speed Helical interpolation for slide 1 Spindle speed monitoring Four-color warning light Cooling unit for control cabinet Collet chuck type MPF 65/140 without axial feed for main spindle, max. diameter 65 mm Manual collet changer type SACO MPT65/140 and MPF65/140 Differential pressure for counter spindle with the possibility of setting two different clamping pressures 1 set of soft jaws for collet chuck type SMW 175-BBD Collet chuck type SMW 175-BBD for counter spindle including adapter for spindle adjustment Tool wear monitoring system for CNC FANUC Sister tool selection system for Tool Monitor CNC FANUC External flushing of jaws and collets with coolant on main and counter spindle

Condition: refurbished (used), functionality: limited functionality, Year of construction: 2003, operating hours: 24,000 h, pipe diameter (max.): 100 mm, pipe length (max.): 4,100 mm, bending angle (max.): 183 °, bending radius (max.): 300 mm, wall thickness: 8 mm, Transfluid DB 2090 DB CNC Mandrel Tube Bending Machine. Excellent High Quality Germany Machine, with fully refurbished main hydraulic pumps and main head fully reconditioned. Only requires new encoder to be fitted and this machine is ready to go. Features include. 100mm x 1.6mm Tube Maximum Capacity at 1.5D Anticipated Mandrel Withdrawal Fully automatic setup of clamps and follower Boosted Follower for tight radius thin wall tube bending. Long bed with 4000mm over mandrel. Comes with huge amount of tooling worth over AU$150k. Tooling Included: 101.6mm 152mm CLR 101.6mm 200mm CLR 76.2mm 114mm CLR Fgsdpfxstrd T Te Ah Nec 76.2mm 200mm CLR 76.2mm 238mm CLR 63.5mm 96mm CLR 57.2mm 86mm CLR 50.8mm 76mm CLR 44.5mm 67mm CLR 40 x 40 120mm CLR 50 x 50 150mm CLR 60.3mm 150mm CLR 48.3mm 120mm CLR

Condition: good (used), Year of construction: 2007, Traub TNX 65/42 Milling and Turning Center Mfd. 2007 Serial #7060107 Commissioned in 2010 TX 8i-S control (Mitsubishi/Traub based control with Mitsubishi drives and motors) 15 CNC axis’s (4) X-Y-Z turrets with 10 positions each. Up to 20 tools per turret Fgjdpeq Npqmofx Ah Nec 65 mm thru hole main and sub spindle (sub spindle has coolant flush) Foot pedal control for clamp/unclamp of spindle chucks Servo driven gantry receiver Hydraulic swivel w/ pneumatic finished part and bar remnant gripper Finished part conveyor belt RESY paper band coolant filter Knoll Coolant tank with BKW refrigerated coolant temperature control 20 Bar High pressure and 8 Bar Low pressure coolant pumps Knoll chip conveyor FMB Turbo 5-55 magazine bar feeder (new in 2010) 2) Single stick turning tool holders 2) Double stick turning tool holders 1) Cut-off tool holder 1) Overdriven double radial live ER Collet tool holder 1) Overdriven radial live ER Collet tool holder 4) Radial live ER Collet tool holders 1) Radial live End Mill tool holder 1) Angle adjustable live ER Collet tool holder 2) Radial live Shell Mill tool holders 2) Axial live End Mill tool holders 6) Axial live ER Collet tool holders 43) Additional tool holders on separate list (see supplemental attachment) Hainbuch main spindle collet chuck Rohm sub spindle 2 jaw chuck 2 Spare sets of spare Z-axis ball screws and bearing packs.

Condition: used, Year of construction: 2017, INDEX C200 Mfd. 2017 Tooling in photos to be divided between 3 C200 machines available. Power-on hours: ~49,960 h Hydraulic hours: ~48,700 h Main spindle hours: ~24,800 h Counter spindle hours: ~24,000 h Stroke mm 20 Clamping pressure min.Max. bar 8/80 Piston Area pressure cm^2 57 Area piston thrust cm^2 57 pressure Force Max. CN 45,6 Tensile force Max. CN 45,6 10350989 1 INDEX C200 CNC-turning machine with 3 revolvers with Siemens-Based Index C200 control system SINUMERIK 840D SolutionLine - Rigid cast iron bed, perpendicular angle to the ground, excellent gradient chips - The kinematics of tool head movements guarantees maximum damping, reducing tool wear - Patented plate supports with excellent properties damping and stiffness The motion of the X-axis is derived through kinematics. "double scissors" guaranteeing high dynamics - Thermosymmetric spindle Control system Index C200 Identical to SIEMENS SINUMERIK 840d SolutionLine - Modular multiprocessor control system, SINAMICS with 120 drives - Siemens Operate control box, display in language Germany - language switching WINDOWS and flat screen - 2x USB 2.0 connection on the control panel, 2x USB connection on the control panel - NCU 720.3 B PN NCK - Integrated PLC 317-3 PNDP and ET200S - Security features implemented in software through SIEMENS Safety-Integrated and ProfiSave Extended machining cycles consisting of: Einstechzyklus Freistechzyklus Gewindestrehlen with 4 point move Lighting work. space in LED design 1 flat color TFT screen, 18.5" PCT-Touch IP65 front panel 10142338 1 Main spindle dia 65 Spindle end AD140mm, ID 85mm Material passage Max. mm 65 Speed max. 1 / min 5000 Front bearing diameter mm 110 Power 100% / 40% kW 31,5/32 Torque Max. 100%/40% Nm 125/170 Continuously synchronous variable speed drives Main spindle with hollow clamping cylinder D65/20 for pincer clamping or Chuck clamping Hydraulic control with clamp metering C axis of main spindle Drive: hollow spindle motor clamping cylinder, metering system directly on the spindle Resolution 0.00014 degrees Positionsstreubreite (VDI/DGQ 3441) Psmax = 0.01 degree 11040430 pressure clamping device Clamping pressure 8-75 bar adjustable For anti-spindle clamping cylinder 10038475 1 tool carrier 1 X-axis work vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000 Z-axis work vehicle mm 320 Z-axis quick feed m / min 50 Z-axis acceleration m / s^2 9 Z-axis shear force N 5000 Fsdpfx Ahsy Um Rro Njgc Y-axis working vehicle mm 100 Y-axis quick feed m / min 15 Y-axis acceleration m / s^2 9 Y-axis shear force N 5000 Offer: 1702114 - 02 / 30.3.2017 CNC-lathe INDEX C200 (GP3790. 0000F) Revolver 1: 14 stations with cylindrical shank clamping D25x48 (DIN 69880), W-grooves on the revolver-higher repeated accuracy when replacing the tool. Centering plate set, V-strips, not content of delivery, must be ordered separately. Gearshift revolver AC motor, hydraulic locking A driven tool is possible in each station of the revolver 1 . Power 25% kW 10 Torque 25% Nm 16 Speed max. 1 / min 8000 10720950 1 tool carrier 2 X-axis working vehicle mm 110 X-axis quick shift m / min 30 X-axis acceleration m / s^2 9 X-axis shear force N 5000

Year of construction: 2020, condition: excellent (used), machine/vehicle number: 101262, Porta Solutions MULTICENTER 3 SPINDLE 3 Spindle Machining Center Fgsdevn T Daepfx Ah Noc Mfd. 2020 SN: 101262 Control: Fanuc Panel i Chip Conveyor

Condition: used, Year of construction: 2024, Tsugami B0205-VR CNC Swiss-Type Lathe Mfd. 2024 Hours: 73 NEVER RAN PRODUCTION! Accessories & Options: Fanuc 0i-TF Control Fire Trace Fire Suppression (5 lbs) B0-WORK-KIT MKIII Work Conveyor Through Sub-Spindle Coolant with Pump Abile Programming Software Edge Scout 320 Barfeed Two Channel Sets Specifications: Max Machining Diameter: .787" Max Headstock Stroke: 6.69" (Guide Bushing) / 1.771" (Chucker) Main Spindle Speed: 10,000 rpm Fgodpfx Aoy Um N Ieh Nsc Sub Spindle Speed: 12,000 rpm Live Tool Spindle Speed: 8,000 rpm Tool Positions: 21 Sub Spindle Max Machining Diameter: .787" Sub Spindle Front Ejection Max Length: 3.15" Max Tool Spindle Slotting Cutting Diameter: 1.18" Rapid Traverse Rate: 36M/min Main Spindle Motor: 7.5 hp | Sub Spindle Motor: 5.0 hp Coolant Tank Capacity: 47 gal. System Input Power: 13.0 KVA Compressed Air: 60 psi Dimensions: 69" x 41.5" x 67" | Weight: 3,968 lbs

Condition: excellent (used), Year of construction: 2022, Swiss CNC Chucker-Convertible Sliding Headstock Lathe W/ "B" Axis Fedpsyq S Utefx Ah Nogc

Condition: good (used), Year of construction: 2015, Maximum turning diameter 255mm, distance between collet chucks 639mm, Fgodpfx Ahozcy Ils Noc swing over bed 270mm, spindle speed 4,000rpm, milling speed 6,000rpm, sub-spindle speed 5,000rpm, main spindle bar capacity 66mm, sub spindle bar capacity 52mm, 3 X 12 station turrets, spindle power 15Kw, Y axis + /- 40mm, swarf conveyor, coolant., Fanuc 31i.

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, CNC Precision Surface and Profile Grinding Machine This machine is ideally suited for precision applications in tool and mold making. Technical Details: Grinding surface: 800 x 450 mm Grinding area: 800 x 400 x 375 mm Table load (max.): 700 kg X-axis = Longitudinal movement of worktable Table longitudinal stroke: 20 - 850 mm Table drive: Electromechanical with toothed belt drive Table speed: 5 - 35,000 mm/min Table setup: Electric handwheel and direction push button Y-axis = Vertical movement Fedpfxjzcyyhs Ah Nogc Distance from table to spindle center: 140 - 525 mm Vertical drive: Electromechanical with ball screw Vertical speed: 50 - 2,000 mm/min Vertical adjustment via electric handwheel and direction pushbuttons Minimum infeed 0.001 mm Measuring system: glass scale Z-axis = Transverse movement Maximum transverse travel 400 mm Drive type: electromechanical with ball screw Transverse speed 50 - 2000 mm/min Transverse travel adjustment via electric handwheel and direction pushbuttons Measuring system: glass scale C-axis = Grinding spindle Grinding spindle motor 7 kW Grinding spindle speed 1400 rpm Grinding wheel standard 300 x 50 x 76.2 mm Spindle bearing: Precision roller bearing Lubrication: Lifetime lubrication Connected load: approx. 19 kVA Total weight: 3500 kg Equipment: - Electro-permanent magnetic chuck Clamping surface 800 x 400 mm, Pole spacing 18 mm, with 16-stage holding force control and automatic Magnetic pole reversal for demagnetization - Leveling blocks For setting up and leveling the machine - Grinding wheels and two flanges - Partial enclosure Open at the top for loading with a sliding door - Dressing system Consisting of a holder for a prism arm or fork dresser Practicle arm for single-point diamond (MK O) or shaped diamond - Grinding spindle speed control Peripheral speed 10-32 m/s The peripheral speed of the grinding wheel is kept constant (V-constant control) with a 7 kW grinding spindle motor - Universal paper belt filter unit UPF 100 Tank capacity approx. 280 liters, Pump capacity 20 liters/minute at 1.5 bar - Air purifier Flow rate approx. 1000 m³/h - Compressed air ports For easier removal of large workpieces with a manual compressed air valve in the machine's work area. - Mobile balancing unit With optical operator guidance for dynamic balancing of the grinding wheel directly in the machine. Imbalance size and position are calculated automatically. With transport case. - Cleaning set Hand-held impulse nozzle for cleaning the work area - Documentation/Manual For sale is our reliably operating grinding machine from mold making. The machine was purchased new in 2016 and is in good technical condition, having been used for a maximum of 20 hours per week. It runs perfectly and is being sold solely due to an investment in a larger model.

Condition: used, Year of construction: 2021, Horizontal precision lathe M.C.M. ATL HEAVY PLUS 900x14000 with CNC control Fanuc Condition: Used Year of manufacture: 2021 Technical data: Centre height: 900 mm Swing diameter over bed: 1800 mm Swing diameter over cross slide: 1400 mm Distance between centres: 14000 mm Max. workpiece weight between centres: 15000/18000 kg Fjdpfjywhhkex Ah Negc Bed width: 1100 mm Number of bed ways: 3 (2+1) Equipment: - FANUC CNC control, model FANUC 32i-B with MANUAL GUIDE i - Automatic turret with 12 positions and driven tool stations (Baruffaldi) MOD. TBMA 320 BDI 60 + C-axis - Chip conveyor (front) - Chip conveyor (rear) - 2 steady rests, diameter up to 600 mm - 2 steady rests, diameter up to 1100 mm

Condition: used, Year of construction: 2021, functionality: fully functional, grinding length: 6,000 mm, grinding width: 800 mm, total height: 800 mm, Technical specifications: • Application: Surface grinding and profile grinding • Grinding area: 6000 x 800 x 800 mm • Grinding wheel: 500 x 100 x 203.20 mm • Spindle power: 43 kW • Connected load: 89 kW • Operating hours: approx. 4,400 machine operating hours / approx. 1,600 spindle operating hours • Year of manufacture: 2021 The machine is currently fully functional and can be inspected at the supplier’s premises by appointment. Price is quoted ex works in Lower Saxony; the machine will be prepared/packaged for transport. The machine can be taken over immediately. Equipment: • CAM profile grinding software “WinWop” Fgodpfx Ahozcycco Nsc • Diamond roll dressing unit with 160 mm diamond wheel • Coolant recirculation system • Grinding mist extraction system • Automatic balancing • Spark detection system • Belt filter system with magnetic separator • VPN connection for remote diagnostics/remote maintenance

Condition: used, As-new CNC Vertical Machining Center, Milling Machine VMC, BAZ, HSC Milling, Machining Center TAIKAN B540Z Fgsdpfx Ahow Ed U No Njc Serial No. 1171009 Year of manufacture: 2017 CNC path control: SIEMENS Sinumerik 828 D Basic Travel range for working area X: 488 mm, Y: 400 mm, Z: 230 mm X-axis travel for tool change position X: 540 mm Table size 520 x 400 mm Spindle taper ISO 25 Distance spindle nose - table 165 - 395 mm Max. spindle speed 36,000 rpm, infinitely variable Feed rate 0 to 10,000 mm/min Rapid traverse 15 m/min Table load capacity 200 kg Max. tool length 120 mm Max. tool diameter 80 mm Max. tool weight 0.8 kg Tool change time approx. 10 sec. Axis drives 0.8 kW each Spindle drive 3.5 kW at 100% duty cycle Electrical connection 400 Volt, 50 Hz, 7.5 kW CNC path control SIEMENS Sinumerik 828 D Basic - Software: NCU V04.05+SP06+HF01 - Interfaces: LAN, USB and CF-Card - Measuring system for tool setting: METROL tool sensor - Vertical milling spindle = high-frequency spindle with liquid cooling and external recooling unit - Tool changer with 13 tool stations - Electronic handwheel - Coolant system - Protective enclosure with sliding door - Central lubrication - incl. 10 tool holders ISO 25 with ER20 collet chuck and a set of collets Transport dimensions (L x W x H): 1800 x 1500 x 2300 mm Weight: 2,900 kg Excellent condition – as new Machine comes from a showroom with very few operating hours.

Condition: reconditioned (used), Year of construction: 2006, functionality: fully functional, travel distance X-axis: 250 mm, travel distance Y-axis: 200 mm, travel distance Z-axis: 300 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: FANUC, controller model: 16i-MB, overall weight: 1,700 kg, spindle speed (min.): 500 rpm, spindle speed (max.): 30,000 rpm, spindle motor power: 10,000 W, spindle nose: HSK-E40, number of slots in tool magazine: 48, tool length: 95 mm, tool diameter: 63 mm, input voltage: 400 V, type of input current: three-phase, input current: 25 A, CNC Machining center WILLEMIN W 408MT TECHNICAL CHARACTERISTICS: Year of manufacturing: 2006 CNC control: FANUC 16i-MB Number of axes: 5 Stroke X axis: 250 [mm] Fsdozcx Dfepfx Ah Nogc Stroke Y axis: 200 [mm] Stroke Z axis: 300 [mm] Feed rate on X, Y and Z axes: 30000 [mm/min] Max. bar diameter in turning spindle: 32 [mm] Main spindle max. speed: 6000 [rpm] Main spindle max. power: 3.7 [kW] Angular C axis stroke: 360 [°] B axis swivelling stroke: 115 [°] Spindle type: HSK-E40 Min. spindle speed: 500 [rpm] Max. spindle speed: 30000 [rpm] Spindle power: 10 [kW] Tool changer magazin number of stations: 48 Max. tool lenght: 95 [mm] Max. tool diameter: 63 [mm] Lubrication tank capacity: 80 [l] Collant pump flow rate: 40 [l/min] Rated current: 25 [A] Supply voltage: 400 [V] Machine weight: 1700 [Kg] More information upon request.

Condition: good (used), Year of construction: 2013, Main and counter spindle C-axis on main and counter spindle 2 x 12-position turret VDI 40 Y-axis Chuck flushing device Tool monitoring Brankamp Coolant system 980 liters with belt filter Conveyor belt Oil mist separator Chip conveyor without bar feeder Fgsdey Ivyispfx Ah Nsc

Condition: excellent (used), Year of construction: 2009, operating hours: 28,742 h, functionality: fully functional, bar passage: 65 mm, FANUC Series 31i-Model A 3 turrets Parts conveyor Magazine Further details on request Fedpfx Ajydmbujh Njgc
