Used Cnc Portal Milling Machine for sale (84,618)

Condition: excellent (used), Year of construction: 1995, functionality: fully functional, High precision drilling and milling machine Fehlmann model Picomax 51 CNC Heidenhain TNC 360 very good condition CE conform Hnsdpfjuxprljx Ah Nog Hthrgw39X Technical Data: >> Year of construction: 1995 >> Travel X/Y/Z 420/ 240/ 120 mm >> Travel distance W 450 mm >> Clamping surface (L x W) 730 x 280 mm >> Permissible table load 75 kg >> Distance table - spindle nose 0 - 560 mm >> Feed speed X/Y 1 - 7200 mm/min >> Feed speed Z 1 - 3600 mm/min >> Tool quick-change system SF 32 >> Infinitely variable speed range 9200 rpm >> Drive power 4 kW >> Space requirement approx. (W x D x H) 2.0 x 1.5 x 2.4 m >> Fourth axis dividing head About the machine : We offer a high-precision drilling and milling machine Fehlmann model Picomax 51 CNC in very good condition with CE conformity. It has a Heidenhain TNC 360 contouring control. The program creation in the user-friendly Heidenhain plain text dialog is particularly easy. HEIDENHAIN TNCs are workshop-oriented contouring controls with which you can program conventional milling and drilling operations directly on the machine in easy-to-understand plain-language dialog. The tool holders (see pictures) are included. Mechanically and electrically tested. Take the opportunity to inspect and try out this machine under power on site.

Condition: used, Year of construction: 2000, travel distance X-axis: 9,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 1,500 mm, table width: 1,200 mm, table load: 5,000 kg, table length: 9,500 mm, Bed Milling Machine 5-axis Table size 9500 x 1200 mm. Movement x-Axis 9000 mm. y-Axis 1500 mm. z-Axis 1500 mm. Max table load 5000 kg/mtr Swiveling of vertical milling head 1°x1º CNC Control Heidenhain TNC 430 CB Hnsdpfsx Tucmsx Ah Nog If you have any questions concerning the machine, please do not hesitate to contact us by phone or e-mail. Feel free to view our other advertisements for a complete overview of our stock.

Condition: new, travel distance X-axis: 6,200 mm, travel distance Y-axis: 2,600 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 20,000 m/min, feed rate Z-axis: 15,000 m/min, table length: 6,000 mm, table width: 2,400 mm, spindle speed (max.): 6,000 rpm, table load: 19,000 kg, position of the milling head: vertikal, torque: 1,350 Nm, spindle nose: SK 50, spindle motor power: 53 W, warranty duration: 12 months, Equipment: rotational speed infinitely variable, Control and Motors: HEIDENHAIN TNC 640 digital contouring control HEIDENHAIN package (motors, measuring systems, handwheel) Hnjdpfx Ahshy Avte Nsg IKZ: Internal coolant supply, 70 bar Additional equipment: Carousel tool changer with double gripper, 60 positions Double screw conveyor (longitudinal) Hinged belt chip conveyor (crosswise) Preparation for 4th axis (rotary table) Fully enclosed, closed at the top Accuracies: Positioning accuracy: 0.045 mm Repeatability: 0.030 mm Only inquiries from Germany will be answered

Condition: used, machine/vehicle number: 186137200089, used TOS tool milling machine model FNG 40 CNC Year of manufacture: 1988 with Heidenhain path control TNC 155 with fixed angular table 800x400mm Travel paths: X/Y/Z = 500/400/400mm Speed range: 10-3150 rpm Spindle: SK40 Chip guard, attachable Documentation for the machine and control is available. Hnodoxf Inkjpfx Ah Neg The machine is located in 71334 Waiblingen-Beinstein and can be inspected by appointment.

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optimill F 80 CNC milling machine direct from the manufacturer. - Machine in cast iron column design for high rigidity - Carousel tool changer with 12 tool positions - All linear guides with stainless steel covers - Automatic central lubrication - Siemens main spindle motor - Siemens servo drive in all axes (closed control loop) - Maximum spindle speed of 10,000 min-1 - The portable, electronic handwheel with enabling switch and emergency stop switch makes it much easier to run in programs SINUMERIK 808 ADVANCED CNC technology from the technology leader SINUMERIK 808D on PC - Control-identical software package that further simplifies the handling of the machine tool Compact and robust - Thanks to a panel-based CNC design with few interfaces and a control panel in protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments Communicative - Front panel USB (IP65) - Serial interface RS232C - RJ45 Ethernet on the rear - Technology-specific keyboard layout - Hard keys with protective membrane Dimensions and weights Length approx. 1995 mm Width/depth approx. 1930 mm Height approx. 1640 mm Weight approx. 2300 kg Rapid traverse speed X-axis 20 m/min Y-axis 20 m/min Z-axis 20 m/min Electrical data Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 12 kVA Horizontal milling table Length 800 mm Width 260 mm Distance vertical spindle - milling table min. 100 mm Distance vertical spindle - milling table max. 550 mm T-slots size 16 mm Number of T-slots 5 T-slot spacing 50 mm Load capacity max. 200 kg Accuracy Repeat accuracy ± 0.01 mm Positioning accuracy ± 0.01 mm Coolant system Coolant pump(s) Drive power 450 W Tank capacity 80 l Pneumatic connection Operating pressure 7 bar Travel distance Hnsdpsw Ea Rtofx Ah Njg X-axis automatic 450 mm Y-axis automatic 260 mm Z-axis automatic 450 mm Distance spindle - column max. 370 mm Vertical spindle Spindle holder BT 40 Speed range 50 - 10000 min¯¹ Power drive motor continuous operation S1 3.7 kW Power drive motor S6-30 % operation 5.5 kW Torque drive motor continuous operation S1 24 Nm Torque drive motor 30% operation S6 36 Nm Feed motor Torque X-axis continuous operation S1 6 Nm Y-axis continuous operation S1 6 Nm Z-axis continuous operation S1 11 Nm Tool changer Carousel type Number of tool positions 12 tools Tool diameter max. 95 mm Tool length max. 300 mm Tool weight max. 8 kg Time tool change chip to chip (C to C) 7 s

Condition: like new (used), Year of construction: 2007, Retrofitted: 2024 Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 4500 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): -10 / 990 mmDistance between columns: 2435 mm Milling head Auto-indexing differential head (UAD - 0,1º)Tool clamping system: HydraulicTaper nose: ISO50Speed range: 6000 rpmSpindle power: 30 kW Feedrates Feedrate: 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 45300 KgMachine dimensions approximate: 10975 x 4768 x 5095 mm Accesories GuardingAutomatic tool changer: ATC30Coolant: External internal high pressure through spindleElectronic handwheel: HR-410 Sales conditions Guarantee: 6 months mechanical spare partsSale price (Ex Work): On request View all technical features Hodpfx Aougbn Esh Nsng

Condition: used, Mecof CNC Bed Type Milling Machine 9m Table with 6.6m Travel, over 2m vertical travel. Hnsdoyacbpopfx Ah Nsg Make: Mecof Type:CNC Bed Type Milling Machine CNC Control Heidenhain 426 Table Size 9,000 mm × 2,200 mm X-Axis Travel 6,626 mm Y-Axis Travel 1,000 mm Z-Axis Travel 2,040 mm Sub-Tables (Qty 2) 1,000 mm × 1,500 mm each Spec Sheet: Mecof CNC Bed Type Milling Machine 9m Table with 6.6m Travel, over 2m vertical travel. Make: Mecof Type:CNC Bed Type Milling Machine CNC Control Heidenhain 426 Table Size 9,000 mm × 2,200 mm X-Axis Travel 6,626 mm Y-Axis Travel 1,000 mm Z-Axis Travel 2,040 mm Sub-Tables (Qty 2) 1,000 mm × 1,500 mm each

Condition: new, Year of construction: 2026, functionality: fully functional, workpiece length (max.): 1,000 mm, workpiece width (max.): 800 mm, workpiece height (max.): 400 mm, spindle speed (min.): 1,000 rpm, spindle speed (max.): 36,000 rpm, Perfect for: Highly efficient 3D milling of small workpieces – precise milling with high output Materials: Plastics, composites such as CFRP/GFRP, model building materials, aluminum Industries: Automotive, aerospace, transportation & logistics, leisure industry, sanitary, boat building, automation _____ Hnodpexdwndofx Ah Nsg Reference number: 1218 Availability: March 2026 Model: 5-axis CNC milling system RT-F 1400 Spindle data: 8 kW / 6.4 Nm; 1,000–36,000 rpm; HSK E 40 Rapid traverse X/Y/Z: 40/40/30 Workpiece dimensions X/Y/Z: 1000 x 800 x 400 mm Control: SIEMENS – Sinumerik One with HT 2 Tool changer: 12 tools Tables: 1 rotary table Tool breakage and length control: Renishaw TS 27 R Other features: Chip tray, anti-slip perforated tread plate Year of manufacture: 2026 Condition: new

Year of construction: 2003, condition: ready for operation (used), Travel X/Y/Z: 600mm/700mm/800mm, resolution: 0.001mm, input resolution: 0.001mm, positioning tolerance: 0.01mm, feed rate: 15m/min, rapid traverse: 40m/min, speed: 18000rpm, power: 31kW, control: Heidenhain MillPlus. Documentation available. On-site inspection is possible. Hnedpfx Asx U Dwish Neg

Condition: new, Year of construction: 2024, functionality: fully functional, - Swiveling control panel - CNC control SIEMENS 828D - Motor for horizontal and vertical spindle - Feed motors with inverter - Ball screws for X/Y/Z axes - Automatic 2-stage gear box for spindle speeds - 1 long milling mandrel 27 mm - 3 reducing sleeves (MK1, MK2, MK3) - Pneumatic hydraulic clamping system for the vertical spindle - Spindle protection with safety switch - Protective cover in the work area with electrically secured doors - Counterholder for horizontal milling - LED work light - Automatic central lubrication system - Safety handwheels for X/Y/Z axes - Coolant system with chip tray - Guideway covers - Base plates and adjusting screws - Operating tools - Technical documentation - CE version - Colors: * RAL 7024 - Graphite gray * RAL 7035 - Light gray Technical data: Fixed angle table: - Dimensions of the work surface: 1,000 x 500 mm - T-slots: Number / width x distance: 8 pieces / 14 x 63 mm - Max. table load: 250 kg Vertical table: Hnjdjvupa Ropfx Ah Njg - Dimensions of the work surface: 1,200 x 250 mm - T-slots: Number / width x distance: 3 pieces / 14 x 63 mm Travel paths: - Axis travel paths: automatic/manual - Longitudinal (X): 600 mm - Transverse (Y): 500 mm - Vertical (Z): 400 mm Feed rates: - Control: stepless - Range (X,Y,Z): 0 – 2,000 mm/min. - Rapid traverse - X,Y,Z axes: 5,000 mm/min. - Rapid traverse - Z axis: 4,000 mm/min. Horizontal spindle: - Tool holder: DIN 2080 / ISO 40 - Speed range (2 levels): 0 – 3,200 rpm. Vertical milling head: - Tool holder: DIN 69871 / / ISO 40 - Speed range (2 levels automatic): 0 – 3,200 rpm - Head swivel: +- 90° - Distance spindle nose/angle table: min/max.: 70 – 470 mm - Distance spindle center to column: min./max.: 160 / 660 mm Motors: Main drive power: 7.00 kW Feed motor power X-Y-Z: 2.85 KW Dimensions and weight Dimensions (W x D x H): 2,850 x 1,950 x 1,900 mm Weight: 1,950 kg

Condition: as good as new (ex-display), Year of construction: 2025, The machine is on display and has only been used for demonstration purposes. Optimill F50 E CNC milling machine, direct from the manufacturer. F50 E – The OPTIMUM CNC milling machine with Siemens SINUMERIK 808D Advanced control system stands out for its performance, speed, precision, and long service life. Hodpjw Ea Swofx Ah Neng • Column design made of cast iron for high rigidity • Carousel-type tool changer with eight tool stations • All linear guides with stainless steel covers • Automatic central lubrication • Siemens main spindle motor • Siemens servo drive on all axes (closed-loop system) • Maximum spindle speed of 10,000 rpm • The portable electronic handwheel with enabling button and emergency stop slam switch greatly facilitates program setup • Coolant system with 70-liter coolant tank • Tool change carried out automatically or at the push of a button (electropneumatic tool clamping system) • Heavy-duty, precision-milled table – generously sized and finely surface-machined • Large access doors to minimize cleaning and maintenance times • LED machine lamp for full illumination of the work area • Additional SIEMENS package: material defect warranty and free on-site service (OSS) SINUMERIK 808D • Software package identical to control version, ensuring process reliability • LED tool number display • MCP with rotary switch for feed and spindle override • Absolute encoders – no reference run required • Higher accuracy Control • 8.4” LCD color display with 800 x 600 resolution Additional SIEMENS OSS package • 12 months; Item No. 3589010 • 36 months; Item No. 3589012 Dimensions and weights Length approx. 2030 mm Width/depth approx. 1600 mm Height approx. 1980 mm Weight approx. 1900 kg Electrical data Connection voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 10 kVA Horizontal milling table Length 690 mm Width 225 mm Vertical spindle to table distance min. 90 mm Vertical spindle to table distance max. 410 mm T-slot size 14 mm Number of T-slots 3 T-slot pitch 63 mm Maximum load 150 kg Accuracy Repeatability ± 0.015 mm Positioning accuracy ± 0.015 mm Pneumatic connection Operating pressure 6 bar Travel X-axis automatic 330 mm Y-axis automatic 220 mm Z-axis automatic 320 mm Spindle to column distance min. 280 mm Spindle to column distance max. 280 mm Vertical spindle Spindle taper BT 30 Speed range 10,000 rpm Drive motor power S1 continuous operation 3.7 kW Drive motor power S6-30% duty cycle 5.5 kW Drive motor torque S1 continuous operation 24 Nm Drive motor torque S6-30% duty cycle 36 Nm Feed speed X-axis 15,000 mm/min Y-axis 15,000 mm/min Z-axis 15,000 mm/min Feed motor torque X-axis S1 continuous operation 3.5 Nm Y-axis S1 continuous operation 6 Nm Z-axis S1 continuous operation 6 Nm Tool changer Type: carousel Number of tool stations: 8 Max. tool diameter: 100 mm Max. tool length: 200 mm Max. tool weight: 6 kg Tool-to-tool change time: 7 s

Condition: like new (used), Year of construction: 2004, Retrofitted: 2025 Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Technical features Dimensions Table dimensions: 5600 x 2000 mmNumber of T slots: 13T slots dimensions: 22 mm Traverses of axis X axis traverse: 5000 mmY axis traverse: 3250 mmZ axis traverse: 1000 mmVertical capacity (VC): 450 / 1450 mmDistance between columns: 2700 mm Milling head Auto-indexing differential head (UAD - 0,1º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871)  /  Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 25000 kgMachine weight approximate: 56000 KgMachine dimensions approximate: 13200 x 5425 x 5350 mm Accesories Guarding: 2 sliding doors and new perimetral wire-mesh security omatic tool changer: OptionalChip conveyor: 1 transversal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features Hnjdpfx Ahou T S Dws Neg

Condition: good (used), Year of construction: 2004, Ref. -No.: 10604 Manufacturer: UNION Type: TC 110 Year of construction: 2004 Type of control: CNC Control: SINUMERIK 840 D Powerline Storage location: Halberstadt Country of origin: Germany X-Travel: 2000 mm Y-Travel: 1250 mm Z-Travel: 1000 mm W-Axis: 550 mm Table Height: 1050 mm Spindle Diameter: 110 mm Number of T-slots: 10 Max. Workpiece Weight: 6000 kg Clamping Area: 1250 mm T - groove width: 22 mm T - slot spacing: 125 mm Tool Taper: ISO 50 Max. Torque: 1639 Nm Feed Speeds X/Y/Z Axis: 6000 mm / min Rapid Traverse X-Axis: 15000 m / min Rapid Travel Y-Axis: 15000 m / min Hjdpfx Ahex Sw Nmj Nong Rapid Traverse Z-Axis: 15000 m / min Feed Capacities X/Y/Z: 16000 x 16000 x 20000 N swivel angle: 360 °

Condition: new, Year of construction: 2026, rotational speed (max.): 36,000 rpm, Perfect for: Highly efficient 3D milling of small workpieces – precise machining with high output Materials: Plastics, composites such as CFRP/GFRP, model-making materials, aluminum Industries: Automotive, aerospace, transport & logistics, leisure industry, sanitary engineering, boatbuilding, automation _____ Reference number: 1221 Availability: April 2026 Model: 5-axis CNC milling machine G-S-F/B (25-10) Spindle data: 8 kW / 6.4 Nm; 1,000-36,000 rpm; HSK E 40 Rapid traverse X/Y/Z: 80/80/60 Workpiece dimensions X/Y/Z: 2,500 x 1,000 x 600 Control: FANUC Tool changer: 13 tools Tables: 1 rotary table Vacuum system: yes Tool breakage and length control: Renishaw TS 27 R Miscellaneous: on request Hsdpox S E Nbsfx Ah Neng Year of manufacture: 2026 Condition: new

Condition: used, Year of construction: 1987, functionality: fully functional, Angle milling head - Manufacturer: Waldrich Siegen - Model: ET500 Hnedpfx Aorfw R Hsh Neg - Order no.: 11290/731

Condition: used, Year of construction: 2002, x-travel 889 mm y-travel 495 mm Control Siemens spindle tunring speed 3.400 U/min table-size 254 x 1.371 mm In our assessment, the machine is in good used condition and can be inspected under power by appointment. Hedpfxjx Sr E Nj Ah Nsng Accessories, tools, and clamping devices shown are only included in the scope of delivery if this is noted in the additional information. Technical data and specifications are subject to change without notice and errors. Prior sale is reserved.

Condition: as good as new (ex-display), Year of construction: 2025, Machine is in the exhibition and was only used for demonstration purposes. Optimill F 3 Pro CNC milling machine (training machine) directly from the manufacturer. Hodpfxsw Ea R Hs Ah Nong F 3 PRO - The OPTIMUM CNC milling machine with Siemens control SINUMERIK 808D Advanced is characterized by performance, speed, precision and long service life. All linear guides with stainless steel covers Automatic central lubrication Servo drive from SIEMENS in all axes (open control loop) Max. Spindle speed 4000 min-1 Machine light in the work area Portable, electronic handwheel with enabling switch and emergency stop switch. Makes running in programs considerably easier Tools can be changed at the touch of a button Access doors very generously designed to reduce cleaning and maintenance time to a minimum Software package "SINUMERIK 808D on PC" included. (Practical training software so that workpieces can be programmed and simulated offline on the PC. Software can be downloaded free of charge at). SINUMERIK 808 ADVANCED - CNC technology from the technology leader, paired with a revolutionary operating concept The SINUMERIK 808D ADVANCED control is a panel-based CNC control. The compact and user-friendly entry-level solution is used for simple milling applications. Features such as simple operation, commissioning and maintenance are the perfect basis for equipping CNC machines. Compact and robust Thanks to a panel-based CNC design with few interfaces and a control panel in protection class IP65, the SINUMERIK 808D ADVANCED is perfectly prepared for use in harsh environments. The small dimensions allow it to be used in compact machines INCLUDED RJ45 Ethernet port 8.4" LCD color display with 800 x 600 resolution Prepared for remote maintenance Dimensions and weights Length approx. 1410 mm Width/depth approx. 1372 mm Height approx. 2007 mm Weight approx. 1000 kg Drilling/milling capacity Cutter head size max. 50 mm End mill size max. 25 mm Electrical data Supply voltage 400 V Mains frequency 50 Hz Electrical connection Total connected load 5 kVA Horizontal milling table Length 620 mm Width 180 mm Distance vertical spindle - milling table min. 50 mm Distance vertical spindle - milling table max. 295 mm T-slots size 12 mm Number of T-slots 3 T-slot spacing 50 mm Load max. 30 kg Accuracy Repeat accuracy ± 0.02 mm Positioning accuracy ± 0.01 mm Coolant system Coolant pump(s) Drive power 95 W Tank capacity 30 l Travel distance X-axis automatic 355 mm Y-axis automatic 190 mm Z-axis automatic 245 mm Vertical spindle Spindle holder BT 30 Speed range 4000 min¯¹ Explanation Speed range Please note that the maximum spindle speed must be reduced by approx. 20 % in continuous operation Power drive motor continuous operation S1 1.5 kW Power drive motor S6-30 % operation 2.2 kW Torque drive motor continuous operation S1 9.5 Nm Torque drive motor 30% operation S6 14 Nm Feed rate Speed X-axis 10000 mm/min Y-axis 10000 mm/min Z-axis 10000 mm/min Feed motor torque X-axis continuous operation S1 1.9 Nm Y-axis continuous operation S1 3.5 Nm Z-axis continuous operation S1 3.5 Nm

Condition: like new (used), Year of construction: 2004, Retrofitted: 2024/2025 Numerical control: HEIDENHAIN TNC-530 Hnedougbpijpfx Ah Nsg Technical features Dimensions Table dimensions: 4000 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmDistance between columns: 2530 mm Milling head Universal manual UM40Tool clamping system: HydraulicTaper nose: ISO50Speed range: 20 - 3.000 rpm (5.000 rpm direct exit)Spindle power: 30 kW Feedrates Feedrate: 7000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 45300 KgMachine dimensions approximate: 10926 x 4768 x 5110 mm Accesories GuardingExternal coolant. Electronic handwheel: New HR-510 Sales conditions Guarantee: 6 months mechanical partsSale price (Ex Work): On request View all technical features

Condition: good (used), Year of construction: 1985, Ref. -No.: 10595 Manufacturer: GILDEMEISTER MAX MüLLER Type: MD 6S Year of construction: 1985 Type of control: CNC Control: EPL 4 Storage location: Halberstadt Country of origin: Germany Tool holder type: 2 x VDI 50 Centre Distance: 1765 mm Spindle passage: 101 mm Swing diameter over bed: 720 mm Swing diameter over cross slide: 490 mm Lathe chuck diameter, max.: 400 mm Power Capacity: 50 kW Weight Of The Machine Ca.: 16 t Hjdpfxsx Sw Nae Ah Nsng Turning Speed Range: 10 - 2800 rpm Quill holder: MK 5 Further information: - Equipment - Powered tools - Tailstock - Automatic quill stroke - Chip conveyor - Automatic sliding safety doors - Hydraulic steady rest - 2 turrets

Condition: new, Year of construction: 2025, feed length X-axis: 80 mm, feed length Y-axis: 80 mm, feed length Z-axis: 60 mm, Perfect for: Applications in model and mold making, as well as milling of other materials – a versatile powerhouse with a rapid traverse of 80 m/min Materials: Plastics, composites such as CFRP / GFRP, model-making materials, aluminum Industries: Automotive, aerospace, transport & logistics, leisure industry, sanitary equipment, boat building, automation _____ Reference number: 1210 Available from: immediately CNC machine type: 5-axis CNC milling machine G-S-F/UNI (35-15) Spindle data: 13 kW / 10.3 Nm; 12,000-24,000 rpm; HSK F 63 Rapid traverse X/Y/Z: 80/80/60 m/min Workpiece dimensions X/Y/Z: 3500 x 1500 x 700 mm Control: SIEMENS – Sinumerik One with hand terminal HT 2 Tool changer: 10 tools Tables: 1 table Hsdpfx Aex S Eqlsh Nsng Vacuum system: yes Tool breakage and length monitoring: Renishaw TS 27 R Other: on request Year of manufacture: 2025 Condition: new

Condition: like new (used), Year of construction: 2007, Retrofitted: 2025 Numerical control: NUEVO/NEW HEIDENHAIN TNC-i640 Hnjdpfx Ahsxaqh Nj Nog Technical features Dimensions Table dimensions: 4500 x 2000 mmNumber of T slots: 11T slots dimensions: 22 mm Traverses of axis X axis traverse: 4000 mmY axis traverse: 3000 mmZ axis traverse: 1000 mmVertical capacity (VC): 240 - 1240 mmDistance between columns: 2500 mm Milling head Auto-indexing differential head (UAD - 0,1º)Tool clamping system: HydraulicTaper nose: ISO50Speed range: 6000 rpmSpindle power: 30 kW Feedrates Feedrate: 5000 mm/minRapid feedrate (X / Y,Z): 15000 / 12000 mm/min Weight and dimensions Maximum weight on table: 10000 KgMachine weight approximate: 35500 KgMachine dimensions approximate: 10975 x 4770 x 5345 mm Accesories Guarding with 2 doors and new perimetral safety fenceAutomatic tool changer: ATC-60 (sale option with no ATC)Chip conveyor: 1 transversalElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsSale conditions: On request View all technical features

Condition: good (used), Year of construction: 1998, Ref. -No.: 10583 Manufacturer: MTE Type: BF 4200 Year of construction: 1998 Type of control: CNC Control: Heidenhain TNC 426 Storage location: Halberstadt Country of origin: Germany Hnjdpfx Asx Sw Ivsh Nsg X-Travel: 4000 mm Y-Travel: 1200 mm Z-Travel: 1500 mm Turning Speeds: 2.500 RPM Rapid Traverse X/Y/Z: 400 m / min Table surface area (LxW): 4200 x 1000 mm Tool changer: 40 Table load max.: 13.000 kg Tool Taper: SK 50 Weight: 20 t Number Of T-Slots: 7 Pcs Width of the T-slots: 22 mm Distance between the grooves: 140 mm Further information: - Heidenhain Handrad HR410 - 3D-Scanner, Infrarot - Die Kugelspindel auf Achsen Z und Y laufen eingespannt und aufgelagert auf kombinierte radial/axial Rollager und radial Kugellager mit bzw. 250 N/qm, Steifigkeit. Maschine kann unter Strom besichtigt werden.

Condition: like new (used), Year of construction: 2010, Retrofitted: 2025/2026 Hedpjxlliljfx Ah Neng Numerical control: HEIDENHAIN TNC-i530 Technical features Dimensions Table dimensions: 8500 x 2500 mmNumber of T slots: 17T slots dimensions: 22 mm Traverses of axis X axis traverse: 8000 mmY axis traverse: 3800 mmZ axis traverse: 1500 mmVertical capacity (VC): 168 / 1668 mmDistance between columns: 3100 mm Milling head Auto-indexing differential head UAD (every 0,02º)Tool clamping system: HydraulicTaper nose: ISO50 (DIN69871) / Pull stud: DIN69872Speed range: 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 7200 / 12000 mm/min Weight and dimensions Maximum weight on table: 35000 kgMachine weight approximate: 79000 KgMachine dimensions approximate: 22700 x 7660 x 6800 mm Accesories Guarding: 2 sliding doors with a new perimetral wire-mesh safety fenceAutomatic tool changer: ATC-60Chip conveyor: 2longitudinal hinge typeElectronic handwheel: New HR-510Coolant: External internal high pressure through spindle Sales conditions Guarantee: 6 months mechanical spare partsPrice and sale conditions: On request View all technical features

Condition: good (used), Year of construction: 2003, Ref. -No.: 10454 Manufacturer: DOOSAN Type: DAEWOO PUMA 300 MSC Year of construction: 2003 Type of control: CNC Control: FANUC 18i-TB Storage location: Halberstadt Country of origin: South Korea Hodpfx Aox Sw E Ieh Neng Machine-No.: 0MS19XX Turning Speeds: 4500 RPM Bar passage: 62 mm Turning Length: 595 mm Turret places: 12 Pcs Further information: - 4 axes (X/Z/C/B) - counter spindle - driven tool station - finished part removal system - conveyor belt - chip conveyor - Powercool coolant system - LNS Quickload Servo 3 bar loader - tool holder - collet holder - collets Machines can be inspected under power by appointment.

Condition: good (used), Year of construction: 1981, Ref. -No.: 10447 Manufacturer: SKODA Type: WD 200 Year of construction: 1981 Retrofit: 2010 Type of control: CNC Control: SIEMENS SINUMERIK 840D Storage location: Halberstadt Country of origin: Germany X-Travel: 9000 mm Y-Travel: 4000 mm Z-Travel: 1450 mm W-Axis: 2000 mm Bed width: 2000 mm Bed height: 550 mm Spindle Diameter: 200 mm Quill Stroke: 1600 mm Rotary Table (Lxw): 4000 x 4000 mm Table Load: 80000 kg Clamping Area: 3000 x 3000 mm Turning Speeds: 257 - 2570 RPM Spindle taper: 120 Automatic feeds: 342 mm / rev Spindle Turning Speed - Stepless: 1,5 - 630 RPM Max. Torque On The Boring Spindle: 20000 Nm Rapid Traverse: 16000 m / min Drive Capacity - Spindle Motor: 9,8 - 35,5 kW Total Power Requirement: 75 kW Bore Depth: 2000 mm Vertical headstock movement on the column: 3150 mm transverse movement of the stand on the bed: 4000 mm Lowest position of the spindle axis above the bed: 1100 mm Spindle speed when moving the quill forward: 1,6 - 300 max. rpm Drill feeds (spindle, quill) continuously variable in the range: 1,6 - 1600 mm / min Milling feeds (headstock vertical, column horizontal) infinitely variable: 1,6 - 1600 mm / min Machine length: 11350 mm Machine width: 5450 mm Machine Height: 7350 mm Weight Of The Machine Ca.: 65 t Further information: Threading: Hjdpsx Sw Ezofx Ah Nong 22 metric threads, pitch range 0.5 - 12mm 32 Whitworth threads, pitch range 28 - 1 (gears) Accessories: - console for tools - 1 set of operating tools - ejector and fastening wedges for spindle - lubricating press - 1 set of spare parts for electrical equipment - clamping base plate - setting stick with electrical equipment Machine can be inspected under power by appointment.
