Used Cnc Center for sale (18,596)

Condition: used, Year of construction: 1986, functionality: limited functionality, machine/vehicle number: 275564, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,400 mm, travel distance Z-axis: 1,200 mm, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, controller manufacturer: Heidenhain, controller model: TNC426, table width: 1,200 mm, table length: 1,600 mm, spindle speed (max.): 3,000 rpm, spindle motor power: 45,000 W, number of slots in tool magazine: 60, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Oerlikon - Präzisons - Horizontal boring and milling machine Model: Sirius MCP-60/HM4.CNC Control: Heidenhain TNC426 Gujdpfx Ajvcb Snefish Rotatability: 360° Door size: 2000x1700mm (hxw) Work tables Number of pallets: 2 Pallet dimensions: 1600x1200mm; 1200x1200mm Pallet and tool changer Tool system Tool holder: SK-50 Electronic handwheel Documents Electrical Mechanical Spare parts catalog Tool changer and pallet changer must be repaired, as well as the mechanical brake of the Y-axis. The machine is connected and can be inspected and tested by appointment.

Condition: new, Year of construction: 2025, functionality: fully functional, workpiece weight (max.): 170 kg, grinding spindle speed: 45,000 rpm, spindle speed (min.): 5,000 rpm, spindle speed (max.): 45,000 rpm, clamping diameter: 140 mm, clamping length: 1,100 mm, warranty duration: 12 months, Workpiece Clamping Diameter : ø 3 – 140 mm Workpiece Length : 50 – 1.100 mm Centre Hole Diameter : ø 1 – 100 mm Workpiece Weight : max. 170 kg Center Hole Angle : 60 ° Accuracy : < 1 µm (Submicron accuracy) Spindle Speed : 5.000 – 45.000 rpm Grinding Cone Movements : 3+1 Rotation Orbital rotation Stroke movement +1 Workpeice rotation Quirlig Grinding Technique : Included (Cross-hatched grinding pattern) Grinding Process : Robotic, Complete-CNC Control Panel : Beckhoff CNC Movements : Z1-Axis, Z2-Axis, Workpiece clamping Feeding : Stäubli robot arm for loading, unloading and aligning Automatic Grinding Cone Dressing : Included Automatic Compensation After Dressing: Included Indurstry 4.0 Compatibility : Available Workpiece Rotation : Available (as a option) Dust Extraction And Filtration : Available (as a option) Sectors: : Precision Grinding, Aviation, Automotive, Machinery etc. Benefits: Sub-micron Precision: Achieve sub-micron (< 1 µm) precision in grinding thanks to Swiss engineering and a robust machine design. Sustainable Reliability: Ensure reliable and sustainable processing. Gujdpfx Aju Nmi Njfioh Non-Stop Production: Achieve continuous production with robotic arm feeding, automatic dressing, and automatic compensation features, eliminating the need for constant operator oversight. Quirlig Grinding Technique: Experience an optimized grinding process with the Quirlig Grinding Technique. Properly ground center holes that have cross-hatched grinding pattern. The cross-hatched grinding pattern ensures that oil is retained when the workpiece is placed between the centers during the cylindrical grinding process, creating a micro oil layer. The micro oil layer prevents unwanted "dry running" during cylindrical grinding. Easy to Use Complete-CNC Control Panel: Utilize a full CNC control panel that allows you to control all axes of the machine, manage robotic feeding, and perform automatic dressing with the Beckhoff control panel. Easily save all grinding programs and monitor machine working times, efficiency, and errors. Industry 4.0: Fully compatible with Industry 4.0 applications, thanks to the Beckhoff control panel. Low Maintenance Costs: Enjoy low maintenance costs throughout the machine's service life, thanks to Swiss-quality construction. The Zentroflex A-series center hole grinding machines are designed to deliver high-precision cylindrical grinding in the aviation, automotive, and machinery sectors for mass-production. Additionally, the Zentroflex A-series is the ideal solution for recovering parts distorted after heat treatment or for reducing cylindrical grinding costs. With 6-Axis robot arm and servo motors on all axes of the machine, Zentroflex A-series center hole grinding machines operate completely autonomously. All loading and unloading operations are performed by the robot arm. All axis movements of the machine are also performed autonomously with servo motors. Cone dressing and compensation are also performed automatically. All movements and measurements of the machine are performed from the CNC control panel. Contact us for more details.

Condition: ready for operation (used), Year of construction: 2004, operating hours: 40,000 h, functionality: fully functional, sheet thickness steel (max.): 2 mm, sheet thickness aluminum (max.): 3 mm, working width: 2,780 mm, working height: 1,090 mm, TECHNICAL DETAILS Max. sheet length: 2,780 mm Max. sheet width: 1,500 mm Max. bending length: 2,550 mm Sheet thickness (stainless steel): 2.5 mm Max. flange height: 185 mm Sheet thickness (aluminium): 3.0 mm Max. bending angle: ± 135° Working height: 1,090 mm MACHINE DETAILS Dimensions & Weight Dimensions: 12,500 x 7,400 x 2,600 mm Approximate machine weight: 19,000 kg Total power requirement: 43 kW Operating hours: 40,000 h EQUIPMENT Automatic/manual loading via PCD Gsdpfoxhfbtex Afijuh Automatic loading system with lift table Automatic bending center P4-2516 Automatic tool setup ALA, symmetrical CLA Semi-automatic unloading of finished parts via SAP

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, turning length: 1,185 mm, turning diameter: 640 mm, spindle speed (max.): 4,000 rpm, turning diameter over bed slide: 640 mm, counter spindle torque (max.): 5,000 Nm, Turning and Milling Center with Main and Counter Spindle and Comprehensive Equipment! TECHNICAL DETAILS Turning diameter: 640 mm Turning length: 1,185 mm Swing diameter: 640 mm Distance between headstocks: 1,500 mm SLIDE I X-Axis travel: 550 mm Y-Axis travel: 180 mm Z-Axis travel: 1,185 mm B-Axis: 240° Feed rate X-axis: 0 – 40,000 mm/min Feed rate Y-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 70,000 mm/min Feed rate B-axis: 1 – 20 rpm Rapid traverse X/Y/Z: 40 / 24 / 70 m/min Feed force X/Y/Z S6: 7.00 / 11.00 / 7.50 kN Tool interface: HSK 63 Milling spindle speed: 10 – 12,000 rpm Drive power 100% duty cycle: 13.20 kW Drive power 40% duty cycle: 22.00 kW Milling spindle torque: 60 / 100 Nm Max. tool length: 350 / 200 mm Tool diameter: 80 mm Tool diameter with 2 free pockets: 120 mm Max. tool weight: 6 / 10 kg SLIDE II X-Axis travel: 180 mm Z-Axis travel: 1,050 mm Feed rate X-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse X + Z axes: 24 / 36 m/min Feed force Z / X S6: 11.00 / 9.00 kN Turret (positions): 12 Tool holder: DIN 69880 Ø40 Driven tool positions: 12 Speed: 1 – 4,000 rpm Drive power 100% duty cycle: 10.70 kW Torque S1: 32 Nm SLIDE III Z-Axis travel: 1,150 mm Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse Z-axis: 36 m/min Feed force Z-axis S6: 13.00 Nm MAIN SPINDLE Model: ISM90 Speed: 10 – 4,000 rpm Drive power 100% duty cycle: 36.00 kW Drive power 40% duty cycle: 45.00 kW Torque at 40% / 100% duty cycle: 800 / 630 Nm Spindle bore: 80 mm COUNTER SPINDLE Speed: 10 – 5,000 rpm Drive power 100% duty cycle: 21.00 kW Drive power 40% duty cycle: 28.00 kW Torque at 40% / 100% duty cycle: 320 / 240 Nm Spindle bore: 80 mm MACHINE DETAILS Gedpfexf A Edsx Afieuh Electrical Data Total power requirement: 70.00 kW Dimensions & Weight Machine weight: approx. 20.00 t Footprint: approx. 8.50 x 4.50 x H3.10 m Control Control manufacturer: Siemens Control model: SINUMERIK 840D EQUIPMENT Chip conveyor Oil mist separator DMG Automation WH10top Main spindle ISM90: Hollow chuck, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Counter spindle ISM76: Partial hollow chuck, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Pick-off unit with integrated conveyor belt Automatic safety cover Differential pressure clamping With pump stand for coolant: Pump 1: 17 l/min at 80 bar / Pump 2: 20 l/min at 8 bar / Pump 3: 40 l/min at 20 bar Hainbuch collet chuck including collets Ø30, 45, 50, 55, 60, 65, 72, 82, 85, 90 1 workpiece pick-off for turret

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 720052, turning length: 600 mm, turning diameter: 140 mm, bar passage: 65 mm, controller model: Siemens 840 D PowerLine, distance between spindles: 615 mm, TECHNICAL DETAILS Turning diameter: 140 mm Turning length: 600 mm Maximum bar diameter: 65 mm Gsdpjxg Im Aefx Afiouh Distance between spindles: 615 mm Max. spindle speed: 5,000 rpm Main spindle drive power: 20/27 kW Spindle nose: ISO 702/1 140 mm Spindle bearing diameter: 110 mm Max. torque: 105/145 Nm C-axis: 0.001 Chuck diameter: 140 - 160 mm Tool turret: 3 Y-axes: 2 to 3 axes +/- 35 mm B-correction axes: 2 axes +/-1 Driven tool positions: 3 x 12 Tool holder: VDI 25 x 48 DIN 69880 Drive power for driven tools: 8 kW MACHINE DETAILS Control: Siemens 840 D PowerLine Dimensions & Weight Space requirements: approx. 8.0 x 3.5 x 2.5 m Machine weight: approx. 6,500 kg Electrical Data Rated voltage: 400 V AC Rated current: 101 A Rated power: 59 kW Number of phases: 3 Frequency: 50 Hz Control voltage: 24 V DC Total power requirement: 53 kVA EQUIPMENT Index MBL bar loader

Condition: good (used), Year of construction: 2008, functionality: fully functional, turning length: 1,520 mm, turning diameter: 540 mm, spindle speed (max.): 10,000 rpm, travel distance X-axis: 550 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,595 mm, rotational speed (max.): 3,500 rpm, number of slots in tool magazine: 40, swivel angle B-axis (min.): -120 °, swivel angle B-axis (max.): 120 °, TECHNICAL DETAILS CNC control: Fanuc 18iT-B Turning length: 1,520 mm Swing diameter: Ø 540 mm Turning diameter over bed: Ø 750 mm Turning diameter over cross slide: Ø 600 mm Bar capacity: 76 mm Turning-milling spindle X-axis travel: 555 mm Y-axis travel: ±80 mm (160 mm total) Z-axis travel: 1,595 mm B-axis indexing: ±120° (240° total) Tool system: Capto C6 Max. tool diameter (continuous): 90 mm Max. tool diameter (without adjacent tools): 120 mm Max. tool length: 300 mm Max. tool weight: 8 kg Tool change time (tool to tool): 1.5 s Number of tools in the magazine: 40 Max. spindle speed: 10,000 rpm Milling spindle motor power (30 min / continuous operation): 15 / 11 kW Lower turret X-axis travel: 185 mm Y-axis travel: 1,640 mm Number of tool positions: 12 Max. speed of driven tools: 4,000 rpm Main spindle Max. spindle speed: 3,500 rpm Chuck size: Ø250 mm Spindle mount: ASA A2-8 Spindle bore: Ø86 mm Draw tube bore: Ø77 mm C-axis – max. indexing angle: 0.001° Main spindle motor power (30 min / continuous operation): 26 / 22 kW Counter spindle Max. spindle speed: 3,500 rpm Counter spindle travel: 1,565 mm Travels and rapid traverses X1 axis travel: 555 mm X2 axis travel: 185 mm Z1 axis travel: 1,595 mm Z2 axis travel: 1,640 mm Y axis travel: ±80 mm (160 mm total) A axis travel: 1,565 mm C1, C2 axis travel: 360° (0.001° resolution) B axis travel: ±120° (240° total) B axis coupling angle: 15° X1, Z1, Z2 axis: 24 m/min Y axis: 16 m/min A axis: 24 m/min C1, C2 axis: 200 rpm B axis: 27 rpm MACHINE DETAILS Weight: 15.5 t Connected load: 93.92 kVA Dimensions: 5,550 x 2,560 x 2,645 mm EQUIPMENT - Fanuc 18iT-B CNC control - Capto C6 tool system - 40-position tool magazine - Lower turret with 12 tool positions Godpfx Afoxf Hrnoisuh

Condition: ready for operation (used), Year of construction: 2005, operating hours: 5,000 h, functionality: fully functional, turning length: 750 mm, turning diameter over cross slide: 250 mm, travel distance X-axis: 140 mm, travel distance Y-axis: 40 mm, travel distance Z-axis: 410 mm, TECHNICAL DETAILS Axis Travel X-axis travel: 140 mm Y-axis travel: +/- 40 mm Z-axis travel (1+2): 450 / 410 mm Turning Capacity Turning length: 750 mm Swing diameter over cross slide: 250 mm Turning diameter: 190 mm Distance between centers: 750 mm Maximum bar diameter: 52 mm Spindle Spindle speed (max.): 4,000 rpm Spindle bore: 91 mm Spindle bearing diameter: 95 mm Main spindle speed range: 60 - 6,000 rpm Main spindle drive power: 22 / 18.5 kW Maximum torque: 198 Nm Sub-spindle (B-axis) travel: 525 mm Feeds Feed rate X (1+2): 18,000 mm/min Feed rate Y: 6,000 mm/min Feed rate Z (1+2): 24,000 mm/min Feed rate B: 24,000 mm/min Turret Number of turrets: 2 Number of tool stations: 2 x 16 positions Square shank height: 20 mm Drill shank diameter: 25 mm Turret indexing time: 0.2 s Toolholder: VDI 30 Speed range - driven tool stations (max.): 6,000 rpm Drive power - driven tool stations: 5.5 / 3.7 / 2.2 kW Rapid Traverse Rapid traverse X (1+2): 18 m/min Rapid traverse Y: 6 m/min Rapid traverse Z (1+2): 24 m/min Rapid traverse B: 24 m/min Rapid traverse C: 400 rpm MACHINE DETAILS Control: MSX 501 Dimensions & Weight Dimensions: 6500 x 3000 x 2500 mm Machine weight: approx. 5.1 t Total power requirement: 73.9 kVA Gjdpfx Afjxgglkjieuh Operating hours: 5,000 h EQUIPMENT LNS bar feeder

Condition: ready for operation (used), Year of construction: 2019, functionality: fully functional, machine/vehicle number: AA100001570, travel distance Z-axis: 180 mm, table width: 1,620 mm, table length: 5,510 mm, rapid traverse X-axis: 56 m/min, rapid traverse Y-axis: 56 m/min, TECHNICAL DETAILS Processing table dimensions (L x W): 5,510 x 1,620 mm Z-axis travel distance: 180 mm Maximum vectorial rapid traverse speed X/Y-axis: 56 m/min Spindle unit speed: 4,000 rpm Tool changer slots: 44 Connection diameter: 250 mm MACHINE DETAILS Dimensions & Weight Dimensions: 9,700 x 5,020 x 2,650 mm (LxWxH) Net weight: 5,000 kg Spindle unit motor power: 5.5 kW Air consumption: 4,430 m³/h Air velocity: 25 m/s Voltage: 400 V / 50 Hz EQUIPMENT Godpfx Aoxmgr Rjfiouh PRO-Speed safety system TEPCAD control panel with touchscreen color display Linear tool changer TBR14 Linear tool changer FAST14 Air blower on the electrospindle XY-axis safety guard Vacuum pump 150/300 m³/h 5-axis unit ‘JQX’ version 13.5 kW Fixed pedestal: 145 x 145 H=75 mm Rotatable gondola: 145 x 55 H=75 mm Clamp for 8 rails TV FLEX / TV FLEXDRIVE / TV FLEXMATIC MULTIGRIP 90 round clamp (H83) for TV FLEX / TV FLEXMATIC Maestro connect 1 year (including Gateway Kit plug & play) SCM DIGITAL SOLUTIONS: MAESTRO CONNECT MAESTRO ACTIVE software for human-machine interface (HMI) Maestro software for CNC programming Hardware key for Maestro CNC Advanced Maestro 3D module Additional key for Maestro CNC (USB connection) Windows 10 embedded 64-bit operating system Console with integrated PC eye-M PRO

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm travel z1 700 mm travel x2 190 mm Guedpexn Amtefx Afieh travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min max. torque 47 Nm work piece power 5,5 kW C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min total power requirement 68,4 kVA weight of the machine ca. 7,8 t Accessories: collet fixture on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Condition: ready for operation (used), Year of construction: 2012, operating hours: 8,597 h, functionality: fully functional, turning length: 424 mm, turning diameter: 370 mm, bar diameter (max.): 65 mm, turning diameter over bed slide: 370 mm, milling spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Turning diameter: 370 mm Turning length: 424 mm Swing diameter: 370 mm X1-axis travel: 380 mm X2-axis travel: 155 mm Z1-axis travel: 460 + 155 mm Z2-axis travel: 610 mm y-axis travel: ±105 mm B-axis travel: ±120° Bar diameter: 65 mm Spindle 1 Maximum speed: 6,000 rpm Number of speed ranges: 2 (winding switch) Spindle mounting: JIS A2-5 Spindle bore: 61 mm C-axis resolution: 0.0001° Spindle diameter (front bearing): 100 mm Maximum torque (40% DC/continuous): 223/158 Nm Spindle 2 Maximum speed: 6,000 rpm Number of speed ranges: 1 Spindle mounting: 80 g6 flat nose Spindle bore: 38 mm C-axis resolution: 0.0001° Spindle diameter (front bearing): 70 mm Maximum torque (15% DC/continuous): 49/22 Nm Tool Spindle Number of tool stations: 1 Tool shank type: C5 Spindle diameter (front bearing): 65 mm Tool change time (tool to tool): 1.2 s Maximum tool diameter with adjacent positions occupied: 70 mm Maximum tool diameter with adjacent positions free: 130 mm Maximum tool length: 250 mm Maximum tool length (over 70 mm diameter): 210 mm Guedpfx Ajxf A Apefieh Maximum tool weight: 5 kg Minimum indexing increment for B-axis: 0.0001° Maximum spindle speed: 12,000 rpm Maximum torque (15% DC/continuous): 49/22 Nm Turret 2 Number of tool stations: 10 Maximum shank diameter for boring bars: max. 32 mm Feed Drives Rapid traverse X-axis (tool spindle): 40,000 mm/min Rapid traverse Y-axis (tool spindle): 40,000 mm/min Rapid traverse Z1-axis (tool spindle): 50,000 mm/min Rapid traverse X2-axis (lower turret): 30,000 mm/min Rapid traverse Z2-axis (lower turret): 30,000 mm/min Rapid traverse A-axis (workpiece unloading unit): 36,000 mm/min Rapid traverse B-axis: 100 rpm Rapid traverse C-axis: 250 rpm Tool Magazine Tool magazine: chain magazine, 76 positions Control Control: MSX-711-IV Mori Seiki Control system: MAPPS MACHINE DETAILS Power-on hours: 75,992 h Total power consumption: 45 kW Weight and Dimensions Machine weight: approx. 10.5 t Space required: approx. 2.71 × 2.43 × 2.40 m Operating Hours Head 1 Operating time: 48,606 h Machining time: 8,597 h Operating Hours Head 2 Operating time: 48,382 h Machining time: 2,664 h EQUIPMENT Renishaw HPRA Blum Laser Control Direct measuring system X, Y, Z, B SMW Autoblok KSZ-MB-040-Z140 collet chuck Workpiece conveyor belt Bar feeder Breuning Irco ILS-RBK-10012 Knoll band filter KF10/500 / HPC via milling spindle, 7-stage up to 70 bar Chip conveyor ConSep 2000

Condition: new, The LabCenter 260 CNC is a robust and compact Vertical Machining Center designed specifically for CNC training and the production of small workpieces. This innovative machine offers the full functionality of larger production machines while being mobile and professional, making it ideal for laboratories and training environments. Equipped with the SIEMENS 808D Advance control, the LabCenter facilitates an intuitive introduction to CNC applications. It boasts a continuously variable main spindle speed of up to 5000 revolutions per minute and features precisely machined cast iron frames, durable dovetail guides, and preloaded ball screws with servo drives on all axes. With a maximum travel of 160 mm on the X-axis and a table size of 400x145 mm, this C-Frame Vertical CNC Center enhances productivity with its efficient 4-station tool changer and mobile base, which allows for convenient tool and material storage. Ensure seamless operation with the included electronic hand-wheel, central lubrication, and comprehensive operating manual. KNUTH guarantees quality and precision in all aspects. To experience the benefits of this Vertical Machining Center, order online today. Guodpfx Ajuy Ihhsfijh

Year of construction: 2012, condition: excellent (used), YASDA YBM Vi40 CNC jig boring machine / machining center machine in perfect condition incl. accessories (see photos) For the complete photo gallery: See attached PDF file (from page 4) TECHNICAL DATA Travels X-axis: 900 mm Y axis: 500 mm Z axis: 450 mm Distance from the table surface to the spindle tip: 100 to 550 °. Rotary table diameter: 400 mm Pallet loading capacity: 200 kg Table surface configuration: 44-M12 thread C axis: 360 ° Table tilt axis movement range (B axis): +- 110 ° Distance between center of tilt axis and rotary table: 0 mm Rotary axis (C axis): 100 rpm Max. rotation of the inclination axis: 20 rpm Motor for rotary axis: 4,2 kW Motor for inclination axis: 4,5 kW Spindle type: SA40-24`000-18,5 Spindle speed range: 100 - 24`000 rpm Spindle speed range programming: Programming by direct input of a 5-digit S-command Number of spindle speed ranges: 1 Type of spindle conical bore: HSK-63A Inner diameter of spindle bearing: 65 mm diameter Rapid traverse Speed: X,Y,Z axis: 20`000 rpm Feed rate: X,Y,Z axis: Max. 5000 rpm C-axis: 100 rpm B axis: 20 rpm Smallest input increment: 0.0001 mm/deg Automatic tool changer: 60 tools Selection method: Any selection Tool shank type: HSK-63 A Max. tool diameter Tool diameter: 100 mm Max. tool diameter Tool diameter at full setting: 70 mm Max. Tool length: 250 mm Max. Tool weight: 7 kg Tool balance weight: within G2.5 Machine dimensions: 3220 x 3885 x 3515 mm Machine weight: 15`000 kg Gujdpfxopqx H Ts Afieh No responsibility is taken for the accuracy, completeness and timeliness of the information.

Year of construction: 2022, condition: ready for operation (used), Main Drive Number of axis 5 Guodoxnr Igjpfx Afioh This 5-axis SCM Accord 500 CNC processing center was manufactured in 2022. Ideal for complex and precise machining tasks, it offers advanced control technology and robust construction. If you are looking to get high-quality milling capabilities consider the SCM Accord 500 machine we have for sale. Contact us for more information about this machine. Application Types CNC Wood Machining

Condition: used, Year of construction: 2019, max. swing dia. 695 mm max. working diameter 235 mm max. working diameter 340 mm max. bar material dia. 65 mm spindle bore 76 mm max. Spindle speed 5.000 U/min. control MAZAK SmoothC turret stations 12 Gujdpfxoxnqzlj Afioh driven tools turning speeds 4.500 U/min CNC Turning- and Milling Center | MAZAK - QT-Compact 200MY L equipped with C- and Y-axes, a 12-station turret set up for driven tools, a tailstock, a chip conveyor, an automation package, and an LTA air filtration system The machine is in good condition and can be inspected under power. For further technical details, please refer to the attached offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: QTC200MYL | QTC 200MY L | QT-200MYL

Condition: used, Year of construction: 2001, travel distance X-axis: 220 mm, travel distance Z-axis: 635 mm, This Gildemeister CTX-400 S2 horizontal lathe with CNC control is being auctioned online in our industrial auction / machinery auction for mechanical engineering companies – clearing out machinery inventory and restructuring. Godpfxexnqbfj Afisuh

Condition: used, Year of construction: 2005, functionality: fully functional, Mazak Quick Turn Nexus 200 CNC lathe (2005) Manufacturer: Mazak Type: Quick Turn Nexus 200 Universal 500 CNC Lathe Year of manufacture: 2005 Mazatrol 640T control Condition: used, under power, in production Max. swing diameter 675 mm Max. turning diameter 380 mm Max. turning length 511 mm Speed range 35 – 5,000 rpm Main drive power 26 kW Max. torque 350 Nm Spindle bore 76 mm Number of tool positions 12 Godpfxoxnngre Afiouh Rapid traverse X-axis 30.0 m/min Rapid traverse X-axis 30.0 m/min Tailstock mount MK5 Tailstock stroke 525 mm Number of tools 12 Turret indexing time 0.2s Length 2473mm Width 1780mm Height 1840mm Weight approx. 5000kg Scope of delivery – 1 set of manuals – Machine feet – Automatic parts catcher conveyor belt – Swarf conveyor hinge belt – Collet chuck – 6x tool holders – High-pressure pump 20 bar – Tool Eye – Bar loader prepared Note: without LTA oil mist extractor

Condition: used, Year of construction: 2007, Technical Specifications: • Power supply: 3-phase / 50 Hz • Voltage: 400 V • Control voltage: 24 V • Rated current: 68 A Included Equipment: • Bar feeder IEMCA Master 880 MP/33 L Serial number: 020721SA07 Year of manufacture: 2007 Air pressure: 6 bar Voltage: 400 V / 3 ~ / 50 Hz Current: 6 A Weight: 1,360 kg Manufacturer: IGMI S.p.A. (BUCCI Industries), Faenza, Italy Gsdpfxexnlv Ro Afijuh

Condition: good (used), Year of construction: 2007, operating hours: 30,000 h, CNC Lathe Hardinge Quest 6/42 SP Technical Data and Scope of Supply TECHNICAL DATA Manufacturer: Hardinge Model: Quest 6/42 SP Year of manufacture: 2007 Control: GE Fanuc 18i-TB Supply voltage: 400 V Phases: 3 Frequency: 50 Hz Machine current: 78 A Spindle drive: 44 A Control voltage: 115/24 V Operating hours: approx. 30,000 h Spindle mount: A2-5 Bar capacity: 42 mm Chuck size: 150 mm Max. workpiece length with collet: 381 mm Max. workpiece length with chuck: 270 mm Max. turning diameter: 309 mm X-axis travel: 89 mm Z-axis travel: 406 mm Rapid traverse X-axis: 28 m/min Rapid traverse Z-axis: 38 m/min Turret: 12 station VDI 30 Indexing time: 0.1 s Machine length: 2,576 mm Depth: 2,025 mm Height: 1,905 mm Weight: approx. 5 t SCOPE OF OFFER Includes (not exhaustive): Gjdpfsxflprex Afijuh - CNC lathe Hardinge Quest 6/42 SP - Toolholder set - Chip conveyor - Transformer - Chip tray - Renishaw probe For the exact scope of supply, please refer to the photo documentation. The CNC Lathe Hardinge Quest 6/42 SP with Fanuc 16i/18i/21i control system from 2007 is a high-precision machine designed for a wide range of turning operations. It features a robust A2-5 spindle mount, a 42 mm bar capacity, and a 150 mm chuck, allowing flexible machining of different workpiece sizes. With a maximum turning diameter of 309 mm, even larger components can be machined reliably. The axes provide generous travel ranges of 89 mm (X) and 406 mm (Z), as well as high rapid traverse speeds, ensuring maximum productivity. The 12-station VDI 30 turret with an extremely short indexing time of 0.1 seconds guarantees fast tool changes and minimizes downtime. Thanks to the solid construction and the proven Fanuc control, the Hardinge Quest 6/42 SP is ideally suited for series production with the highest accuracy demands. No guarantee is given for the correctness, completeness or currentness of the information provided.

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 Guedpfx Afjxnld Ujijh 4 working zones 2 cross lasers Vacuum pump 250 m³/h PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Location: Nattheim

Condition: used, Year of construction: 2001, Technical Specifications: • Power supply: 3 Ph / 50 Hz • Voltage: 400 V • Control voltage: 24 V • Rated current: 76 A • Total power: 42 kW • Machine weight: 4,800 kg • Electrical cabinet weight: 440 kg Included Equipment: • Bar feeder IEMCA Master 880/33R P Serial number: 0200141S02 Year of manufacture: 2001 Supply voltage: 380 V / 3 Ph / 50 Hz Control voltage: 220 V / 24 V Power consumption: 6 A Machine weight: 120 kg Gjdoxnlk Uopfx Afieuh

Condition: excellent (used), Year of construction: 2011, TECHNICAL DATA Linear Axes (Slides X, Y, Z) Travel distances: Axis X: 250 mm Axis Y: 200 mm Axis Z: 300 mm Rapid traverse (X, Y, Z): 30 m/min Feed force (X, Y, Z): 3700 N Resolution (X, Y, Z): 0.0001 mm Rotary Motion of Motor Spindle – Axis B Rotary travel range: -15° to +100° Rotary travel range (with tailstock): Tailstock in position: -20° to +45° Tailstock removed: -20° to +90° Maximum speed: 20 rpm Drive torque: 750 Nm Hydraulic clamping: 50 bar Holding torque: 300 Nm Resolution: 0.0001 mm Milling Motor Spindle HSK E40 Power at 100% duty cycle: 10 kW Power at 25% duty cycle: 15 kW Nominal torque (100%): 8 Nm Nominal torque (25%): 12 Nm Speed range: 50 – 30,000 rpm Axis A (Bar capacity Ø 40 mm) Spindle type: A4 Max. bar diameter: 40 mm Max. speed: 35 rpm Drive torque (nominal): 112 Nm Drive torque (max.): 238 Nm Resolution: 0.0001° Axis clamping (Axis A): Pressure: 70 bar Holding torque: 130 Nm Tool Changer Number of tool discs: 2 Positions per disc: 24 Gedpewv Hnmefx Afijuh Max. tool weight: 1 kg Rotational speed: 60 rpm Max. tool diameter (adjacent positions occupied): 50 mm Max. tool diameter (adjacent positions free): 63 mm Max. tool length (from spindle nose): 95 mm Coulisse de Reprise Travel distance: 80 mm Feed force: 1700 N Tilting moment: 90 Nm Resolution: 0.0001° Hydraulic pressure for tilting motion: 100 bar Workpiece Manipulator Pneumatic vertical slide gate: Ø 25 mm Stroke: 710 mm Linear travel per motor revolution: 70.4 mm/rev Max. transfer speed: 60 m/min Max. workpiece weight: 5 kg Max. manipulator stroke: 1120 mm (2×560 mm) Max. vertical travel: 150 mm Part pick-up Ø/length: Ø 32 mm / 100 mm Part ejection Ø/length: Ø 32 mm / 100 mm Accuracy: +/- 0.05 mm Grip force: 45 N (at 6 bar) Max. gripper opening: 14 mm (2×7 mm) Pneumatic Equipment Operating pressure: 6 bar Hydraulic System Operating pressure: 95 – 105 bar Coolant System Coolant tank volume: 80 liters Chip pan volume: 30 liters Kinematic viscosity in operation: 10 – 15 cSt SCOPE OF DELIVERY Includes (not limited to): Willemin Macodel W 408 B machining center Extraction unit Fire suppression system Probe Coolant system Oil chiller Data backup Complete operator documentation Exact scope of delivery as per photo gallery No guarantee is given for the correctness, completeness, or currentness of the information provided.

Condition: used, Year of construction: 2010, · Working area: 2700 x 1300 mm · Travel X-Y: 3070 x 1750 mm · Travel length Z-axis: 270 mm · Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The layout of the machine allows the user an optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. The working unit is in turn attached to this mobile unit carrier on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit F12: Drilling head with 12 + 6 spindles · 7 individually accessible vertical spindles in X · 5 individually accessible vertical spindles in Y · 4 horizontal spindles in X (2 + 2) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm (6,000 rpm optionally available) · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fit · pneum. Feed stroke: 60 mm Grooving saw unit in "X" · Integrated in the drill head · Grooving saw blade with a diameter of up to 120 mm Main milling unit: · Tool holder HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 6.6 kW (9 HP) from 12,000 rpm (S1) · Motor power 7.5 kW (10 HP) from 12,000 rpm (S6) · Right / left rotation · Ceramic bearings (other power classes are optionally available) Tool changer R4 Automatic tool changing device for 4 tools. Traveling on the rear unit carrier to allow quick access to the tools. · Number of tool positions: 4 · Max. tool diameter: 120 mm · Max. weight per tool: 4.5 kg · Max. total weight of all tools: 16 kg · Mount for 1 angle gear · Traveling in X (other and larger tool changers are optionally available) Work table The work table is designed to guarantee the operator maximum freedom of movement. The quick vacuum clamping system ensures maximum flexibility with exact positioning and optimal hold of the workpieces. · 6 supports 1000 mm continuously pneumatically adjustable in X · 12 round vacuum suction cups D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) 1 stop in Y per support (6 in total) · The retractable reference stops are controlled by CNC · Pendulum machining as standard (2 work areas) --- other clamping systems are optionally available --- Axis movement The drive system in X, Y and Z is via ground recirculating ball bearings of the highest precision class. Such characteristics are important to ensure balanced movement even with more complex work. The movement of the various axes is carried out by brushless three-phase servo motors / brushless AC motors. These offer excellent positioning speeds thanks to very short ramp times. Furthermore, the measuring system is fully integrated into these motors. These features make this type of drive completely maintenance-free. · Rapid traverse in Godpsxnld Iofx Afieuh

Condition: excellent (used), Year of construction: 2014, operating hours: 10,000 h, Fanuc α-D21MiA5 CNC Machining Center Spindle speed: 24,000 rpm (High Power Version) X-axis travel: 500 mm Y-axis travel: 400 mm Z-axis travel: 330 mm 4th and 5th axes: Yes Rapid traverse: X-axis: 54 m/min Y-axis: 54 m/min Z-axis: 54 m/min Worktable load capacity: 300 kg Tool changer load capacity: 23 kg Max. tool weight: 2 kg Tool diameter: 150 – 12,000 rpm: 80 mm 12,000 – 15,000 rpm: 60 mm 15,000 – 20,000 rpm: 45 mm 20,000 – 24,000 rpm 40 mm SCOPE OF OFFER INCLUDES (list is not exhaustive): Fanuc α-D21MiA5 CNC machining center Lehmann dividing head 4th and 5th axis Tool holder set Renishaw touch probe Fire extinguishing system Guodpfx Afewgn Hlsieh Coolant tank / high-pressure pump Absolent oil mist separator Operating documentation Exact scope of offer as per photo gallery No liability is assumed for the accuracy, completeness, or timeliness of the information.

Condition: used, Year of construction: 2011, Basic machine Stk Volt 400 EU Stk #93.07.31 Series 800 TV working areas 5020x1905 Stk # 52.19.14 8 Matic supports (Y=1825 mm) with 3 basic modules Stk # 52.19.92 for automatic vacuum suction cups Additional basic module for automatic vacuum suction cups Matic Stk # 52.19.99 4 working areas H= 50 Stk # 52.21.63 Front and rear stops H=50- 8 traverse Stk # 52.24.11 Integrated additional stops H=50 mm for 8 traverse Stk # 52.24.15 Central double rail (removable) with 6 stops Stk # 52.24.18 H=50 mm suction cup TV 145 x 30 H50 Stk # 52.18.69 Suction cup TV 145 x 55 H50 Stk # 52.18.70 Suction cup TV 145 x 145 H50 Stk # 52.18.71 8 Posi-Aids H50 Stk # 52.21.66 Group 800 - Electrospindle Prisma K 11 kW Stk # 52.21.80 Drilling head F50L2 (38V-80X-40Y-L0/90°) Stk # 52.22.51 PBTC-On Pos.3 Electrospindle PB+Rapid 6 Stk # 52.21.96 Tool magazine Rapid 12 on board (X,Y-traveling) Stk # 52.22.90 Stk # 52.22.92 Vacuum pump with 250 (300) M3/H50(60) HZ Item # 52.21.97 Gusdpfoxnldhsx Afioh Storage Location: Supplier

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 MAIN FEATURES 5-AXIS MACHINING UNIT "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE MATIC PROGRAMMING" WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (inside stop) mm 3,680 Working area Y-axis (max. loadable piece on rear stops) mm 1,680 Workpiece passage Z / number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Travel speed X-Y axes Pro-Speed m/min 85 Z-axis speed m/min 30 INSTALLATION Installed power KVA 62÷82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL CHARACTERISTICS CNC-controlled drilling and milling center in gantry design and work table with workpiece supports, for carrying out: - vertical drilling on the panel surface - horizontal drilling on all four sides of the workpiece - groove milling with disc milling cutters - general milling work 3-4-5 axes MACHINE STRUCTURE The basic structure is a monolithic construction made of thick-walled steel. It is stiffened by welded reinforcements across the entire machine bed, making it extremely stable. The table shape used, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow with a minimum of space requirements. The mobile gantry support is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via recirculating ball slides. On this mobile unit carrier, the work unit is mounted on prismatic, ground guides and recirculating ball slides. All axes are moved on large-section prism linear guides and recirculating ball bearings with a large contact surface, ensuring optimal gliding even at the highest speeds and accelerations. Precise and rapid positioning of the movable gantry (X-axis) is achieved by a pinion and rack with helical teeth. Large-section recirculating ball screws ensure precise positioning of the work unit along the movable gantry (Y and Z axes). MOTORS, DRIVES AND INVERTERS Perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors, designed to achieve speeds of up to 90 m/min while ensuring the best finishing quality. CONTROL The control unit consists of a numerical control for milling and drilling machines with "Xilog Maestro" graphical user interface based on the Windows 7 Office operating system. 17-inch LCD color screen. QWERTY keyboard. Tilting control panel. Machine interface with Xilog Maestro software. Xilog Maestro Features Programming Parametric graphic programming Import of DXF files (2D; SPLINE, POLYLINE 3D geometries), linear or circular interpolation in three axes, linear in space, spiral in the selected plane. Programming with graphic and syntax aids for drilling and milling operations Automatic optimization of drilling operations and tool change cycles Possibility of Plate zero point shift for drilling on inclined or curved plate sides Gedpfx Afexnldbjijuh
