Used Cnc Center for sale (19,321)

Condition: used, Year of construction: 2014, Working dimensions: X = 3425 mm, Y = 1287 mm, Z = 325 mm. Max. workpiece height: 180 mm. Max. clearance under the hood: Y = 1450 mm / Bumper version = 1370 mm. Includes CabinetControl Base, 1 machine license, and 1 office license. Milling head 7830, 1-stage, power 6.5 kW, air-cooled, n(max.) 1000 - 18000 min-1, infinitely adjustable. Max. power at 12000 min-1 to 18000 min-1 with HSK-F 63 tool holder, with collet chuck with HSK shank. Drilling unit 7884, 14 spindles, 10 vertical spindles individually accessible, arranged in an L-shape, 6 in the X direction and 4 in the Y direction. Drive power 3 kW, 32 mm pitch. Sawing unit: Integrated sawing unit for sawing/grooving in the X direction, n(max.) 1000 - 5650 min-1, infinitely adjustable. Tool holder: A = max. DM = 125 mm. Location: Supplier. Dkodpfxey Tpz Rs Ab Tsp

Condition: good (used), Year of construction: 1998, functionality: unexamined, Angelini DG 13 Year of manufacture: 1998 Control system: Fanuc Dedpfjzhikrjx Ab Tskp Chip conveyor Tool turret: 12 positions Documentation and export are available for an additional charge. Inspection under power is possible. We would be happy to send you further details or arrange an on-site inspection.

Condition: good (used), Year of construction: 2006, Machine used only for plastic. Djdpfxeu Ibiho Ab Tekp Technical details shown in attached pdf document. Parts shown by hand not come.

Condition: used, Year of construction: 1998, turning diameter 850 mm turning length 2000 mm turning diameter over slide rest 690 mm control Siemens type 840 C Cooling through the spindle 23 bar centre height 450 mm spindle diameter in front bearing 200 mm spindle hollow 128 mm power capacity 60 kW turning speeds 7-1800 U/min Torque 7908 Nm workpiece weight 4000 kg tailstock quill diameter 160 mm Dsdoyqv Anepfx Ab Tokp tailstock quill taper MT 5 3 jaw chuck Forckrath 600 mm Tool changer 60 work piece power 30 kW turning speeds 56-3000 U/min weight of the machine ca. 18 t dimensions of the machine ca. 6,3x2,4x3,3 m The machine has been completely overhauled. Capto C6 milling chuck Double prism lathe chuck The machine has many optional accessories that can be purchased separately. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2005, operating hours: 40,300 h, machine/vehicle number: IntNr231576, A used AXA VSC-1M/2E CNC vertical machining center, manufactured in 2006 and equipped with a HEIDENHAIN iTNC 530B CNC control, is for sale. Technical data Design: Moving column machine Dsdpfezatgpjx Ab Tekp Number of axes: 3 axes Machining operations: Milling, drilling, threading Operating mode: CNC operation Swivel machining Tool holder: SK 40 Tool magazine Chip conveyor Coolant system X-axis travel: 1,760 to 9,000 mm Y-axis travel: 550 mm Z-axis travel: 600 mm Distance from table to spindle nose: 180 to 780 mm Table surface: X-travel + 400 mm x Y-travel, 3 T-slots 14 H9, T-slot spacing 160 mm Table load: 800 kg/m² Rapid traverse: 30 m/min The standard tool changer has 22 tool positions; optional extensions up to 216 tool positions are possible. Tool change time: approx. 4 seconds. The machine can be inspected by appointment. Subject to changes and errors in the technical data and specifications, as well as prior sale.

Condition: used, Year of construction: 2011, total height: 3,000 mm, total length: 5,000 mm, total width: 3,000 mm, overall weight: 12,700 kg, spindle motor power: 18,000 W, DMG DECKEL MAHO DMF 180 travelling column machining center,equipped with Heidenhain iTNC 530 control.Machine equipped with 40 bar through-spindle coolant (IKZ), 60-position tool magazine (chain type with double gripper), chip conveyor, electronic handwheel, air blast through spindle, M&H infrared probe and full enclosure.Table size approx. 2,100 x 700 mm.Operating hours: control ON approx. 63,700 h, machine ON approx. 22,500 h, cutting time approx. 7,750 h Spindle performance: 18 kW Control: Heidenhain iTNC 530 ShopMill Travel Y-axis: 700 - mm Tool Changer: Yes Dimensions (LxWxH) approx.: 5000 x 3000 x 3000 mm Tool holder type: SK 40 Dsdoy Tkdgspfx Ab Tokp Travel Z-axis: 700 - mm Weight approx.: 12,700 kg Travel X-axis: 1800 - mm Grinding spindle speed: 14000 - rpm Year of construction: 2,011 Condition: good Terms of payment: 100% prepayment before pick-up Terms of delivery: From foundation under power: Yes

Condition: used, Year of construction: 2022, turning diameter 420 mm turning length 1350 mm spindle passage 101 mm control Siemens SL 828D ShopTurn number of controlled axis 4 turning speed range 3000 U/min power requirement 22/18,5 kW rapid speed 30 m/min number of tapers in turret head 12/24 BMT 65 number of driven tools in turret 12 BMT 65 Spindel speed of driven tools 5000 U/min Spindelpower on driven tool 7,5/5,5 kW y-axis +/- 65 mm tail stock MT-5 weight 8,0 t dimensions 5,7 x 2,3 x 2,32 m Heavy CNC- lathe with driven tools and Y- Axis in very good condition. First instalation: 03/2023 Appr. 5400 h Power on. - 2x 3-jaw chuck Ø 325 + 400 mm - some fixed tool holders - Tool pre- setter - chip conveyor - 4x driven tool holders Dodpszfqf Ssfx Ab Tekp - 2 + 2 driven toolholders with Capto C4 - oildust collector - band filter system with appr. 1000 ltr. - hydr. steady moveable wit turret SMW Autoblock SLU-X3.1 (Ø 20- 165 mm) - 3 colour signal lamp - coolant gun - some jaws - external programming system MCS40501/2 - build in spindle

Condition: used, Year of construction: 2015, CNC machining center Manufacturer: Chiron Type: FZ 12 W Magnum Year of manufacture: 2015 CNC control: Siemens 840D solution line Travel distances: X/Y/Z = 550 x 400 x 360 mm Spindle speed: 15,000 rpm Tool interface: HSK63 Internal coolant system Dkjdpfxozfppco Ab Tjp Rotary table Integrated workpiece changer 32-tool capacity Glass scales Chip conveyor Laser control for breakage monitoring 2726

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Dodpfx Abozfni Ij Tekp Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: excellent (used), Year of construction: 2011, functionality: fully functional, Turning diameter: 4,000 mm Turning height: 550 mm Dsdpfx Abszfl D As Tskp Chuck: Wagner magnetic chuck Control system: SIEMENS Automatic grinding wheel changer for each grinding spindle

Condition: good (used), Year of construction: 1989, operating hours: 64,136 h, Centre height: 350 mm Turning length: 1000 mm Max. swing diameter over bed cover: 600 mm Max. swing diameter over cross slide: 360 mm Spindle bore: 107 mm Speed range: 16 – 3150 rpm Feed range longitudinal & face: 0.5 – 5000 mm/min Rapid traverse longitudinal & face: 9 m/min Main drive: 30 kW Dimensions of machine with chip conveyor (L x W x H): 5400 x 2200 x 2000 mm Weight: 6400 kg Accessories / Special features: • CNC control GILDEMEISTER EPL 2 with TFT display General description: CNC manual input control system with program entry via function and numeric keypad. All information is entered in dialogue with the screen. Integrated menu technology with plain text display of all functions. Operator keypad, display, and electronic handwheel located within a separate chip guard housing. The EPL control offers the following capabilities: • Direct interactive program entry and editing by the operator through the EPL control without manual technological preparation • NC programs in ISO/EIA format can be entered, output, or manually keyed in via the RS 232 serial interface Machining cycles: • Removal cycles for longitudinal, facing, and contour turning, including with allowance • Thread cutting • Undercuts as per DIN 509-Form E and F and DIN 76; grind stock programmable • Axial and radial grooves as per DIN 471 and 472, including bottom finishing • 90° radii and 45° chamfers • Automatic cutter radius compensation for cycles, undercut, groove, radius, chamfer Programming: Dksdpfxovr Eh Ee Ab Tsp • Block-orientated, metric/inch, diameter for absolute entry, radius for incremental entry • Full circle programming, subroutine technology, hide levels for program sections, zero point offset, mode selection via menu Program entry and output: • Interactive via guided menu or direct in dialogue • Hydraulic 3-jaw chuck Ø 315 mm with through spindle bore Ø 80 mm • Hinged chip conveyor • 12-position tool turret VDI 40, 6 standard stations + 6 driven tool stations • Coolant system • RS 232 interface • Electronic handwheel • Electric foot switch for 3-jaw chuck and tailstock quill • Lighting • 12 various standard toolholders (to be finalized on site) Overhauled servo drive for main spindle, 06/2025 Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: good (used), Year of construction: 2012, 5-Axis CNC Machining Center Manufacturer: AXA Machine Model: VPC-2800U Control System: Siemens Year of Manufacture: 2012 Technical Specifications Working Area - X travel vertical (mm): 3,900 - Y travel (mm): 2,940 - Z travel (mm): 1,100 CNC Rotary Table - Clamping area (mm): ø 2,800 Feed Drive - Max. rapid traverse speed in X/Y/Z (m/min): 30/30/25 Working Spindle - Standard drive No.: 140 Spindle speed range (rpm): 30-7,500 Spindle power max. duty cycle 100% (kW): 63 Spindle torque max. duty cycle 100% (Nm): 191 Tool holder: SK50 Swivel Head - Swivel range B-axis (degrees): 90 Djdpezfhdxefx Ab Tjkp - Indexing: freely interpolating Tool Changer - Tool stations: 60 Please note: The machine is NOT equipped with a turning function. Changes and errors in the technical data and information excepted.

Condition: used, Year of construction: 2007, operating hours: 33,122 h, Hermle simultaneous 5-axis CNC machining center Type/Model: U 1130 Condition: Used Year of manufacture: 2007 Operating hours: 33,122 h Spindle hours: 12,054 h Technical data: Travel range X/Y/Z: 1130 (1300) mm x 720 mm x 630 mm Dkedpfx Abozfg U Ne Tjp Feed rate: Manual / setup mode: 1 - 2000 mm/min Programmable X-Y axis: 1 - 30000 mm/min Programmable Z axis: 1 - 20000 mm/min Rotary table: Tool interface: SK 40 Total connected load: 32 kW Space requirement (L/W/H) approx.: 3.66 m x 4.38 m x 2.57 m Weight approx.: approx. 10 tons Equipment: - Heidenhain iTNC 530 control system - Heidenhain TS 640 infrared measuring probe - 16-position tool changer - incl. SK 40 tool interface plus various tools - Machine vise - IKZ (internal coolant supply) - Paper band filter - Oil cooler - Chip conveyor - Control cabinet air conditioning - RS 232 interface - LAN interface Costs for delivery by freight forwarder to the curb, see shopping cart or individual offer for inquiry items.

Condition: used, CNC turning machine MONFORTS, type RNC 300 MultiTurn with driven tools and Y-axis Year of manufacture 2005 CNC control system FANUC Series 18i-TB Maximum turning diameter over the bed cover 380 mm Spindle bore 67 mm Spindle speed 25 - 5000 rpm Tool turret 12 stations Tool holder, cylindrical VDI 30 mm Motor power, spindle drive 23 kW Total power consumption 41 kVA Mains connection 400 volts, 50 Hz, 63 amps - with tailstock, chuck and collet chuck system - 3-jaw chuck SCHUNK ROTA NCD Ø 165 mm with a large number of chuck jaws - Collet chuck system HAINBUCH 65, without collets (only one collet as a sample) - 25 tool holders VDI 30 - 4 driven tools with collet ER 25 - Chip conveyor with integrated coolant system - approx. 20,000 operating hours Machine footprint with chip conveyor L x W x H approx. 4100 x 2600 x 2100 mm Footprint of the base machine L x W x H 3000 x 2400 x 2100 mm Djdezfau Ajpfx Ab Tjkp Weight approx. 6 tons very good condition

Condition: used, Year of construction: 2008, Technical details: turning diameter: 410 mm turning length: 500 mm control: Fanuc 21i TB standard turning diameter: 275 mm travel -x axis: 277 mm travel -y axis: 82 (±41) mm travel -z axis: 500 mm Spindle 1 RPM: 4500 1/min Spindle 1 Power: 18,5/18,5/15 kW Spindle 1 max. bar diameter: 65 mm turret stations / rotary tool stations: 12/12 Power rotary tools: 5,5 kW RPM of rotary tools: 6000 1/min total power requirement: 39,2 kVA weight of the machine ca.: 6,2 t dimensions of the machine ca.: 3,1 x 2,0 x 2,2 m collet chuck: Hainbuch Accerories Chip conveyor Robot interface Dodpezd Un Ijfx Ab Tskp High precision Turning and Milling Centre with Y-axis and robot loading. Stäubli Robot for shaft loading. *

Condition: used, Year of construction: 2008, Technical details: turning diameter: 190 mm turning length: 503 mm control: Fanuc 31i - TA Travel x/z turret 1: 135 / 503 mm Dedpfx Ajzd T I Hjb Tekp Travel x/z turret 2: 135 /503 mm c-axis: Sp. 1 / 2 Spindle 1 RPM: 6000 1/min Spindle 1 Power: 11/7,5 kW Spindle 1 max. bar diameter: 42 mm Spindle 2 RPM: 6000 1/min Spindle 2 power: 11/7,5 kW Turret No.1 stations / rotary tools: 12/12 Turret 1 tool RPM: 6000 1/min Turret 1 power rotary tools: 7,1 / 2,2 kW Turret No.2 stations / rotary tools: 12/12 Turret 2 tool RPM: 6000 1/min Turret 2 power rotary tools: 7,1 / 2,2 kW total power requirement: 53 kVA weight of the machine ca.: 5700 t dimensions of the machine ca.: 2,3 x 1,6 x 1,94 m Accerories Chip conveyor right discharge Robot interface High precision cnc turning center, rotary tools and y-axis on upper turret, Robot loader for shafts. *

Condition: used, Year of construction: 2006, Working area X-Y-Z: 5300 x 1700 x 180 mm Travel length X-Y-Z: 6040 x 1810 x 280 mm Drilling head with 30 + 8 spindles Speed: 6000 rpm Power: 2.2 kW Automatic central lubrication Worktable TV with 10 supports L=1500 4 working zones 2 cross lasers Vacuum pump 250 m³/h Dsdpfox Twd Hox Ab Tskp PC control Windows Vertical milling unit ISO 30 7.5 kW with tool changer RAPID 14 and vector axis Additional drilling unit (E-axis) Dongle for XILOG software Location: Nattheim

Condition: used, Year of construction: 2016, MORBIDELLI AUTHOR M400 MAIN FEATURES 5-AXIS MACHINING UNIT "PRISMA: QUALITY AND PRODUCTIVITY AT THE HIGHEST LEVEL XILOG MAESTRO SOFTWARE: EXTREMELY SIMPLE MATIC PROGRAMMING" WORKTABLE: ONE POSITIONING FOR MULTIPLE MACHINING OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (inside stop) mm 3,680 Working area Y-axis (max. loadable piece on rear stops) mm 1,680 Workpiece passage Z / number of Z axes mm 170 / 1 Workpiece length with pendulum machining mm 1,650 Travel speed X-Y axes Pro-Speed m/min 85 Z-axis speed m/min 30 INSTALLATION Installed power KVA 62÷82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air speed m/s 25 Extraction nozzle diameter mm 250 GENERAL CHARACTERISTICS CNC-controlled drilling and milling center in gantry design and work table with workpiece supports, for carrying out: - vertical drilling on the panel surface - horizontal drilling on all four sides of the workpiece - groove milling with disc milling cutters - general milling work 3-4-5 axes MACHINE STRUCTURE The basic structure is a monolithic construction made of thick-walled steel. It is stiffened by welded reinforcements across the entire machine bed, making it extremely stable. The table shape used, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow with a minimum of space requirements. The mobile gantry support is made of a solid monoblock. It is positioned in the X direction on prismatic ground guides via recirculating ball slides. On this mobile unit carrier, the work unit is mounted on prismatic, ground guides and recirculating ball slides. All axes are moved on large-section prism linear guides and recirculating ball bearings with a large contact surface, ensuring optimal gliding even at the highest speeds and accelerations. Precise and rapid positioning of the movable gantry (X-axis) is achieved by a pinion and rack with helical teeth. Large-section recirculating ball screws ensure precise positioning of the work unit along the movable gantry (Y and Z axes). MOTORS, DRIVES AND INVERTERS Perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors, designed to achieve speeds of up to 90 m/min while ensuring the best finishing quality. CONTROL The control unit consists of a numerical control for milling and drilling machines with "Xilog Maestro" graphical user interface based on the Windows 7 Office operating system. 17-inch LCD color screen. QWERTY keyboard. Tilting control panel. Machine interface with Xilog Maestro software. Xilog Maestro Features Programming Parametric graphic programming Import of DXF files (2D; SPLINE, POLYLINE 3D geometries), linear or circular interpolation in three axes, linear in space, spiral in the selected plane. Programming with graphic and syntax aids for drilling and milling operations Automatic optimization of drilling operations and tool change cycles Possibility of Plate zero point shift for drilling on inclined or curved plate sides Dsdpfx Aoy Dta Sjb Tskp

Condition: used, Year of construction: 2007, Working area: 2780 x 1140 mm (vertical milling) 2500 x 950 mm (horizontal drilling) X-Y travel: 2980 x 1271 mm Z-axis travel: 200 mm Passage height: 180 mm The structure of the base body is a monolithic construction made of thick-walled steel. It is stiffened by welded triangular plates across the entire machine bed, making it extremely stable. The triangular shape used for load-bearing parts, with a large base, is the secret to ensuring lasting precision and stability. The machine layout allows the user optimal workflow despite minimal space requirements. The base body constructed in this way therefore offers the machining unit a balanced and secure base with particularly good load distribution. The mobile unit carrier is made of a solid monoblock. It is positioned in the X direction on prismatically ground guides via recirculating ball slides. On this mobile unit carrier, the working unit is mounted on prismatic, ground guides and the recirculating ball slide. Description of the units and accessories (basic) Drilling unit: Drilling head with 10 + 4 spindles · 6 individually accessible vertical spindles in X · 4 individually accessible vertical spindles in Y · 2 horizontal spindles in X (1 + 1) · 2 horizontal spindles in Y (1 + 1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill chuck: M 10 with 11 mm fitting · Extraction nozzle: D = 160 mm Vertical milling unit (position 2) · Tool chuck HSK 63F · Speed 1,500 - 24,000 rpm continuously adjustable via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Right-hand / left-hand rotation · Ceramic bearings · Scope of delivery: 4 tool chucks (right) without collet chuck · Tool changer · Side-mounted tool magazine 7-way (TR7) with full encapsulation to prevent chipping · 7 tool positions for HSK 63F tool holder arranged in a row · maximum tool diameter D=120 mm · maximum weight per holder 4.5 kg · maximum tool weight of all tools 20 kg (TR7) · angular gears can be accommodated Horizontal milling unit (position 1) Horizontal unit with two opposite outputs for milling and grooving. · Speed 9,000 - 18,000 rpm continuously variable via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (For saw D = 120 mm / bore 50 mm) · Motor power 3 kW (4 HP) · Max. tool diameter front milling: 20 mm · Max. tool length front milling: 110 mm · Max. tool diameter rear milling: 12 mm · Max. tool length rear milling: 80 mm · Max. saw blade diameter: 100 mm · Bore saw blade (ER 32): 50 mm · Mandrel diameter saw blade (ER 20): 12 mm Work table The work table is designed to guarantee the operator maximum freedom of movement. The vacuum quick clamping system ensures maximum flexibility with precise positioning and optimal grip of the workpieces. · 4 supports 900 mm continuously adjustable in X · 8 vacuum suction cups round D = 110 mm continuously adjustable in Y (2 per support) · 2 stops in X (1 x left / 1 x right) · 1 stop in Y per support (total 6) · The retractable reference stops are controlled via CNC. · Scope of delivery: 4 plug-on adapters for suction cups · Pendulum machining standard (2 working areas) Axis movement The drive system in X, Y and Z is carried out via ground ball screws of the highest precision class. The ball drive screw of the X-axis is located exactly in the center Djdpfxex Twdyo Ab Tekp

Condition: used, Year of construction: 2006, · Working area: 2,650 x 1,240 mm · X-Y travel: 2,995 x 1,385 mm · Z-axis travel length: 200 mm · Clearance height: 180 mm C-axis deactivated – 3-axis machine The base structure is a monolithic construction made of thick-walled steel. It is reinforced throughout the entire machine bed with welded-in triangular plates, which makes it extremely stable. The use of the triangle shape with a broad base for load-bearing parts is the key to lasting precision and stability. The machine layout allows the operator an optimal workflow despite minimal space requirements. The resulting base frame thus provides the machining unit with a balanced and secure foundation, ensuring excellent load distribution. The mobile unit carrier is built as a solid monoblock. It is positioned in X-direction on ground prismatic guides with recirculating ball carriages. The working unit is again mounted on ground prismatic guides and a recirculating ball carriage on this mobile unit carrier. Description of aggregates and accessories (basic equipment) Drilling unit: Drill head with 12 + 6 spindles · 7 individually selectable vertical spindles in X · 5 individually selectable vertical spindles in Y · 4 horizontal spindles in X (2+2) · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Grid: 32 mm · Drill interface: M 10 with 11 mm fitting Grooving saw unit in X: · Integrated in drill head · Grooving saw blade with max. diameter 120 mm Main milling unit (Position 2): · Tool holder HSK 63F · Speed: 1,500 - 24,000 rpm stepless via inverter · Motor power 4.4 kW (6 HP) from 12,000 rpm (S1) · Motor power 6.6 kW (9 HP) from 12,000 rpm (S6) · Clockwise/counterclockwise rotation · Ceramic bearings · Includes: 4 pcs. tool holders (right) without collet Djdpjx Twccefx Ab Tokp Tool changer R8L: Automatic tool changer for 8 tools. Mounted on the rear unit carrier for quick tool access. · Number of tool stations: 8 · Max. tool diameter: 120 mm · Max. weight per tool: 4.5 kg · Max. total weight all tools: 22 kg · Holder for 1 angle gear · Moves in X direction Horizontal milling unit (Position 1): Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 – 18,000 rpm stepless via inverter · 1 output for collet 3-20 mm (ER 32) · 1 output for saw/collet 3-12 mm (ER20) (for saw D=120 mm / bore 50 mm) · Motor power: 3 kW (4 HP) · Max. front milling tool diameter: 20 mm · Max. front milling tool length: 110 mm · Max. rear milling tool diameter: 12 mm · Max. rear milling tool length: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER 32): 50 mm · Saw blade arbor diameter (ER 20): 12 mm Work table: The work table is designed to guarantee the operator maximum freedom of movement. The quick vacuum clamping system provides maximum flexibility for precise positioning and optimal holding of workpieces. · 6 supports, 1000 mm, steplessly adjustable pneumatically in X direction · 12 round vacuum cups D = 110 mm, steplessly adjustable in Y (2 pcs. per support) · 2 stops in X (1 left / 1 right) · 1 stop in Y per support (6 in total) · Retractable reference stops are CNC controlled · Pendulum machining standard (2 work zones) --- other clamping systems available as options --- Axis movement: The drive system in X, Y and Z is via ground recirculating ball screws...

Condition: used, Year of construction: 2018, Delivery time approx. 5 months. Machine from educational use – TOP condition, low hours (edging unit unused). No tools included. Dismantling, delivery, assembly, commissioning, and training not included in the price. Includes Maestro 3D and Pro View. MORBIDELLI P200 Working area X-Y: 3,110 x 1,620 mm, workpiece height Z180 mm Edge banding made for you: The CNC machining center is equipped with a comprehensive selection of edge banding tools to meet any woodworking requirement. Dkedpeyuw Srefx Ab Tjp MAIN ADVANTAGES · High performance with the advanced H80C edge banding unit, 8,000 rpm drilling spindles. The most robust spindle technology on the market, offering over 1,000 maintenance-free operating hours. · Better equipped: Suction cups can be disabled and configured via the FLEX worktable to optimally adapt the machine to requirements. · Easier, more intuitive programming thanks to the integrated CAD-CAM module for edge banding technologies “MAESTRO EDGE”. · Easier operation: The lowered frame ensures the worktable is always accessible. The control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, no safety barriers are needed. Base structure: The base frame is a monolithic construction made from thick-walled steel, reinforced across the entire machine bed with welded square plates for exceptional rigidity. The bed’s shape, with a wide base, is the secret to lasting precision and stability. The load-bearing structure consists of a particularly robust, monolithic steel base, heavily ribbed and highly stiffened; the extra-wide support was specially designed to give the machine maximum stability, ensuring lasting precision regardless of operating conditions—with no need for floor anchoring. The base provides a large, solid support for the moving gantry: the working unit is thus equipped with a balanced, stable, and resilient support capable of handling the highest loads, ensuring top-quality performance and greater accuracy. The moving gantry is made from a robust single piece anchored to the base, sliding along top-quality prismatic guides with recirculating ball carriages. The working unit is attached and moves along the Y and Z axes on prismatic guides with recirculating ball carriages. Movement of the lower carriage (X-axis) and the working unit along the moving carriage (Y-axis) is enabled by rack-and-pinion transmission with helical teeth. This design results in greater tooth-on-tooth engagement, delivering higher acceleration and greater speed along the X and Y axes. The specially designed helical gearing ensures reduced wear on mechanical components and quieter operation. The vertical Z-axis is driven by a ball screw, ensuring perfect balance with dynamic loads and smooth acceleration and deceleration. The main milling unit is directly coupled to the Z-axis carriage for maximum finishing quality.

Condition: good (used), Parts on table not come. Marked with red. Dkedpfx Ajwxdyxsb Tsp

Condition: good (used), Year of construction: 2007, Machine is in good condition, Parts shown by hand not come. Dksdpfxowk Nm Ij Ab Top SK 40, 24 tool places in tool changer. 10.000 rpm

Condition: used, Year of construction: 2008, Technical details: standard turning dia.: 200 turning length: max. 810 mm control: MSX-701 MAPPS III greates pass round over bed: 800 mm Max. distance between centres: 1130 mm max. turning diameter: 320 mm max. workpiecediameter: 300 mm bar material dia.: 65 mm Traverse X-Axis 1: 210 Traverse X-Axis 2: 210 mm Traverse X-Axis 3: 210 mm Traverse Y-Axis 1: 110 (+65/-45) mm Traverse Y-Axis 2: 110 (+45,/-65) mm Traverse Z-Axis 1: 300 mm Traverse Z-Axis 3: 300 mm Traverse Z-Axis 2: 810 mm Traverse B-Axis: 870 mm turning speed range - spindle: 5.000 1/min Number of spindle speed ranges: 2 . spindle nose: JIS A2-6 spindle bore: 73 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° turning speed range - spindle: 5.000 1/min spindle nose: JIS A2-6 spindle bore: 73 mm bar material dia. max: 65/52 mm spindle bearing diameter: 120 mm C-Axis: 0,001 ° Number of Turrets: 3 . Number of tool stations: 16 x 3=48 pos Schank height for square tool: 20 mm Diameter of boring bar: 32 mm turret changing time (4-stations): 0,18 sec Number of driven tools: 16 x 3=48 pos Dsdpfx Abjzd Su Ej Tokp max. spindle speed driven tools: 6.000 U/min. Rotary tool machining ability: M16 / Ø16 . rapid traverse X-axis: 30 m/min rapid traverse Y-axis: 20 m/min rapid traverse Z-axis: 50 m/min drive capacity - spindle motor: 25 / 22 kW power capacity - driven tools: 7,5 / 5,5 kW total power requirement: 92,7 kVA weight of the machine ca.: 9,4 t dimensions of the machine ca.: 4,0 x 2,8 x 2,4 m Accerories Chip conveyor Coolantsystem C-axis in main and sub spindle Y-axis 2 x part counter total counter tool setting Overhead partsgripper with conveyor belt. Spindle 1 Chuck SMW KNCS-N 210 / 52 mm Spindle 2 Collet Chuck Hainbuch Spanntop nova Kombi Axfix 65 Robot interface Lehmann Robot with parts belt for feeding and disposal CNC Turning- and Milling Center MORI SEIKI NZ 2000 T3Y2 The NZ2000 T3Y has 2 spindles and 3 turrets, and 2 turrets have the Y-axis function and built-in milling motors. This not only allows synchronized machining using 3 turrets, but also achieves heavy-duty cutting and high-speed machining using rotary tools thanks to the built-in motor turrets. For shaft parts loading and unloading there is a Lehmann Robot with conveyor belts for loading and unloading. The machine can also be sold without robot. *

Condition: ready for operation (used), Year of construction: 2004, 5-axis CNC machining center MAKA MM 7t, in portal design with two tables and two 5-axis head units for alternating operation. Year of construction: 2004 • High-performance CNC milling center for 5-axis machining, ideal for machining aluminum components / deep-drawn parts / GRP components. • Equipped with automatic central lubrication and control cabinet with air conditioning unit. • CNC control BWO 920, memory 8 MB, in the integrated PC. • Mobile control panel stand. Technical data: Working areas / cube dimensions: Dkjdpezhbgfofx Ab Tsp with tool length 130 mm and diameter 60 mm X-axis: 2 x 1,500 mm Y-axis: 2,250 mm Z-axis: 650 mm, at 120 mm tool height A-axis: 540° (+/- 270°) B-axis: 200° (+/- 100°) Rapid traverse speed: X/Y-axis: 60 m/min. Z-axis: 24 m/min. A/B-axis: 10,000 °/min. 2 high-speed milling spindles HSD 7.5 kW (S1), HSK-F63 Speed continuously adjustable from 2,000 – 24,000 rpm, Rated power from 12,000 rpm, with ceramic bearings, water-cooled. Tool holder HSK-F63 with tool changer. 1 traveling drum tool magazine per head unit, for 10 tools up to Ø 60 mm and – depending on the tool diameter – 130 mm length from the base. 2 tables with aluminum table top 1,500 x 2,250 mm with grid drilling. 1 pneumatic clamping system per table. 1 vacuum clamping system per table. 2 minimum quantity lubrication systems with spray nozzles. Work safety: 2 manually operated sliding doors for front loading. In alternating operation, the loading and unloading area is secured with two electrically driven roller shutters, 1 partition wall (removable) between the tables. With protective cabin for the machine rear area, side access door, the cabin is open at the top. Current location: southern Thuringia / Germany, where the machine can be inspected.
