Used Bent Press for sale (12,331)

Condition: used, Year of construction: 2021, machine/vehicle number: HB 2022-A-073, pressing force: 300 t, Portal straightening press with 300 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 55 mm/sec c) table size 2500x1600mm d) open height 700 mm e) total size approx. LBH 4500 x 2300 x 3700 mm f) Oil temperature indicator on the tank g) Lubrication via grease nipple h) table in grid construction,with T grooves according to customer's request, otherwise 22mm i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 50 T to 300 T via MONITOR k) bridge moves by two gear motors, via racks l) Cylinder moves to the left and to the right via toothed racks m) Machine body double painted n) Cylinder induction hardened Type of construction Press design PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Forces Pressing force max. 3,000 kN Free ripping force max. 500 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 700 mm Stroke and min. opening 700 mm/ 0 mm Table height above floor approx. 9ß0 mm Height above floor (headroom) approx. 3700 mm Hall height min. 5.000 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 22 T Speeds Fast closing with 17 mm sec. Pressing speed 8 mm sec. Opening 55 mm sec. Giedpsh Agnuefx Ahvep Sound pressure Sound pressure level, measured at 1.5m height at the control panel after max. 78 db(A) DIN 45635-T16-KL3 Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 350 bar Pressing pressure build-up time 02. mz sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 93 L/min Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Hydraulic connection Main motor IE3 22 kW Total connection Approx. 30 kW

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 400 t, Gantry straightening press with 400 T capacity a) idle and pressing speed up to 17 mm/sec. b) opening speed up to 60 mm/sec c) table size 6000x3000mm d) open height 1500 mm e) total size approx. LBH 6000 x 5000 x 4500 mm f) Oil temperature indicator on the tank g) Lubrication via grease nipple h) Table in grid construction, i) operation on swivel arm, mounted on the bridge j) pressure adjustment from 60 T to 400 T via MONITOR k) Bridge moves by two gear motors, via toothed racks l) Cylinder moves to the left and right via toothed racks m) Machine body powder coated, or double painted n) T-slots according to customer requirements o) cylinder induction hardened PORTAL PRESS Thermally neutral 80 - 120 °C Number of operating sides 3 side Forces Pressing force max. 4000 kN Free ripping force max. 600 kN Pressure build-up time Closed die Steel to steel Max. 3 sec. Dimensions Max. Opening width 1500 mm Stroke and min. opening 1500 mm/ 0 mm Table height above floor approx. 900 mm Height above floor (headroom) approx. 4500 mm Hall height min. 5500 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.8 mm/m Weight Total weight of press without operating materials and table plate approx. 52 T Speeds Giedohyc Nwjpfx Ahvep Fast closing with 17 mm sec. Sound pressure Sound pressure level, measured at 1.5 m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 280 bar Pressing pressure build-up time 2-3 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH approx. 150 L/min Oil volume approx. HLPD 46 MW 900 liters Ambient temperature max. 45 °C Oil temperature max. 55 °C Electrical system Main supply 400 V AC Control voltage 24V DC Frequency 50 Hz Connection hydraulics Main motor IE3 30 kW Total connection Approx. 35 kW

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 20 t, Double column press 20 T capacity, a) Closing speed up to 10 mm/sec b) opening speed up to 30 mm/sec c) table size between columns 1400x1100 mm d) ram size between columns 1400x1100 mm e) Manual lubrication (via grease nipple) f) UKF pump-cooling-filtration ( electrical cooling ) g) Pressure adjustment from 4 T to 20 T ( adjustable via rotary control ) h) Travel adjustable via slide control Type of construction Press design Double column press ,hydraulic Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 200 kN Free ripping force max. 20 kN Pressure build-up time Closed tool Steel on steel Max. 4 sec. Dimensions Max. Opening width 500 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 2800 mm Hall height min. 3,500 mm Parallel deviation at 20°C #ERROR! mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.4 mm/m Weight Total weight of the press without operating materials approx. 3 to Table cut-out Size 1100x850 mm Speeds Fast closing with 9 mm sec. Pressing speed 9 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of press/driving cylinders 2 pcs. Operating pressure max. 280 bar Pressing pressure build-up time 3-5 sec. Pressure accuracy during pressing stroke +/- 5 bar Giodpfx Ahshmbhqsvop Main pump BOSCHREXROTH/PARKER approx. 35 L/min Oil volume approx. HLP 46 D 150 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Circulation pump for cooling ACS approx. 6.5 L/min Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 5 kW

Condition: new, Year of construction: 2021, pressing force: 10 t, Single-column press with 10 T capacity, suitable for continuous shift operation, with these basic data: a) Traversing speed 0 - 10 mm/sec. downwards, b) Opening speed up to 25 mm/sec c) Starting press speed 10 mm/sec, adjustable from 0 to 10 mm/sec. d) Table size 600x300 mm e) Ram size 300x300 mm, with T-slots and central cylinder clamping f) Overall size approx. 1100x600x1850 mm g) Oil temperature display on oil tank h) Pressure setting from 0.5 T to 10 T (adjustable via rotary control) i) Cable remote control for downward/upward movement j) Machine body powder coated, or double painted k) Control cabinet supply cable from above with 3000 mm cable and 16 ampere plug l) Assembly, commissioning, instruction at extra charge Type of construction Press design Single-column press Thermally neutral 80 - 120 °C Number of operating sides 1 side Forces Max. pressing force (at 250 bar) 100 kN Giodehma Smjpfx Ahvjp Free ripping force max. 10 kN Pressure build-up time Closed tool Steel on steel Max. 2 sec. Dimensions Max. Opening width 800 mm Stroke and min. opening 500/300 mm Table height above floor 850 mm Height above floor (headroom) approx. 2850 mm Hall height min. 3,500 mm Parallel deviation at 20°C #ERROR! mm Deflection Determined at max. clamping force with 70% occupancy < = 0.1 mm/m Weight Total weight of the press without operating materials approx. 1.6 to Speeds Fast closing with 10 mm sec. Press speed 10 - 0 mm sec. Sound pressure Sound pressure level, measured at 1.5 m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 250 bar Pressing pressure build-up time . 2 sec. Pressure accuracy during pressing stroke #ERROR! bar Main pump Gear pump approx. 6 L/min Oil volume approx. HLP 46 MW 80 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Hydraulic connection Main motor 2.2 kW Total connection Approx. 3 kW

Condition: new, Year of construction: 2021, pressing force: 10 t, Design Single column press Number of operating sides 1 side Forces Pressing force max. ( at 250 bar ) 100 kN Free ripping force max. 10 kN Pressure build-up time Closed tool steel on steel Max. 2 sec. Gjdpjhaqygjfx Ahvsip Dimensions Max. Opening width 400 mm Stroke and min. opening 350 mm Table height above floor 850 mm Height above floor (headroom) approx. 1850 mm Hall height min. 2.500 mm Total weight of the press without operating materials approx. 1.2 to Speeds Fast closing with 10 mm sec. Press speed 10 - 0 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to DIN 45635-T16-KL3 max. 78 db(A) Hydraulics Number of pressing cylinders 1 pc. Operating pressure max. 250 bar Pressing pressure build-up time 2 sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump Gear pump approx. 6 L/min Oil volume approx. HLP 46 MW 80 litres Electrical system Main supply 400 V AC Control voltage 24 V DC Frequency 50 Hz Hydraulic connection Main motor 2.2 kW Total connection Approx. 3 kW Additional information Single column press with 10 T capacity, suitable for continuous shift operation CE certificate Manufactured according to EU standards Operating instructions, technical documents, documentation in German language Robust machine body with solid welded construction, manufactured according to DIN 8651 Low maintenance and reliable Cylinder with induction hardening and chrome cladding Traversing speed 0 - 10 mm/sec. downwards, Opening speed up to 25 mm/sec Starting pressing speed 10 mm/sec, adjustable from 0 to 10 mm/sec. Table size [...]

Condition: as good as new (ex-display), Year of construction: 2020, pressing force: 400 t, Hydraulic 400 to column press suitable for continuous shift operation, with these basic data: a) Closing speed 100 - 450 mm/sec. b) Opening speed 50 - 250 mm/sec ( adjustable via touch screen ) c) Pressing speed 5 - 60 mm/sec ( adjustable via touch screen ) Gisdsg Iihwspfx Ahvep d) Piston accumulator with approx. 4 nitrogen bottles e) Table size (clamping surface) 2700 x 1700mm ( seen from the front, between the columns ) f) Total table size 3400 x 1700mm g) 28 T-slots according to customer requirements h) Table, ram and press head are annealed stress-free. i) column diameter 250 mm j) slide size 3400 x 1700mm (clamping surface 2700 x 1700mm ) k) Total size of the machine approx. 3900 x 2200 ( at the bottom ) x 5700 mm height l) Oil temperature monitoring ( adjustable via touch screen ) m) Automatic lubrication ( adjustable via touch screen ) n) Free positioning of the ram ( adjustable via touch screen ) o) KEYENCE light barriers 14 mm on front and rear side p) Circuit oil cooling ( adjustable via touch screen ) q) Pressure holding valve 0 to 600 sec. ( adjustable via touch screen ) r) Table top size 3400 x 1700mm, plane milled s) Laterally monitored doors, 1200mm high, 1000mm wide t) RITTAL control cabinet, 2200 mm wide, up to 20 m from the press u) Pressure setting from 50 to 400 tons ( adjustable via touch screen ) v) Travel limitation optionally via pressure or position w) Programming mode, set-up mode, single stroke + continuous stroke (adjustable via rotary switch ) x) Swivelling control panel with 15 inch touch screen monitor y) Two-hand operation on both sides z) Prepared for automatic material feed ( SIEMENS S 7 1500 ) aa) Machine body primed and painted bb) assembly, commissioning, instruction against separate charge The hydraulics of the presses we offer are completely based on BOSCH-REXROTH/Parker/HAWE components. In the switch cabinet only components are used (SIEMENS) which are easily available in Germany. The safety technology comes completely from SICK except for the light barriers. The control system is supplied by SIEMENS. ( S 7 1500 ) as well as the touch screen monitor with 15 inch. The SIEMENS remote maintenance unit SECOME -Ethernet is included in the scope of delivery. SPECIAL FEATURE: the design chosen by us with two press cylinders and the piston accumulator make it possible to supply the full power with a main motor of 90 kW. Below under 1.3 the technical details Technical data Press design Press design Column press Thermally neutral 80 - 120 °C Number of operating sides 2 sides Forces Pressing force max. 4,000 kN Free ripping force max. 600 kN Pressure build-up time Closed tool steel to steel Max. 2 sec. Dimensions - intended minimum tool height 600 mm Max. Opening width 1600 mm Stroke and min. opening 1000/600 mm Table height above floor 820 mm Height above floor (headroom) approx. 5700 mm Hall height min. 7000 mm Parallel deviation at 20°C +/- 0,1 mm Deflection Determined at max. clamping force with 70% occupancy < = 0.17 mm/m Weight Total weight of the press without operating materials approx. 52 To Speeds ( see attached cycle diagram ) Fast closing 100 - 450 mm/s Pressing speed At F max.

Year of construction: 2021, condition: new, pressing force: 50 t, Here are the technical data of the offered machine: If the press does not exactly meet your requirement profile, please click to request an individual offer exactly according to your needs: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your requirements at surprisingly low prices! Technical data + information: hydraulic 50 T heating press for laboratories It is a lower piston press with an open height of 400 mm ram travel 300 mm heating platen capacity up to 250 degrees heating plate size 200x200mm weight about 1500 kg height 1950 mm hydraulics built in the press body Hydraulic tank with 100 l Giodjgrkigjpfx Ahvop monitored vertical door for the press chamber pressure, position - and speed adjustable via SIEMENS S 7 1200 SIEMENS touch screen monitor with 9 inch Safety technology from SICK (C-press, hydraulic press, hydraulic press, laboratory press, laboratory) Are you looking for a custom-fit machine? Contact us for an individual offer. Our hydraulic presses are manufactured according to German machinery directives, as well as European machinery directives (Directive 2006/42/EC), EC standards and EU safety regulations. Furthermore our presses exceed the Canadian and European safety requirements, because they correspond in all points to the national Brazilian safety guideline NR 12, which is based on these. Our great strength is the special machine construction and the press automation. We sell customized hydraulic presses, press brakes and impact shears at surprisingly low prices. For the hydraulics of the presses we mainly use components of leading European manufacturers.

Condition: used, pressing force: 30 t, machine/vehicle number: DF0139, pressure:30 t Giodpfx Asfxykhohvep passage width:1000x1000 mm stroke:800 mm total power requirement:3 kW weight of the machine ca.:5 t dimensions of the machine ca.:3360x1300x1360 mm return capacity:3 t column diameter:75 mm traversing speed:bis 200 mm/sec. :0-10 mm/s :200 mm/sec table height over floor:900 mm distance table - lower edge of ram:1000 mm :126 mm diameter of piston:71 mm

Condition: new, Year of construction: 2019, machine/vehicle number: DF0362, pressing force: 250 t, pressure:250 t passage width:1800 mm stroke:600 mm total power requirement:22 kW weight of the machine ca.:24 t dimensions:ca. 3390 x 3400 x 3800 mm Gisdpfjfxyinox Ahvsp column diameter:160 mm return capacity:25 t max. working heidht:800 mm Table dimensions:1800 x 1600 mm :2350 x 1600 mm table height over floor:900 mm hydraulic table shift:25 mm/sec table load:5 t pre-running speed:10 mm/sec pressure speed:10 Return Speed:25 mm/sec speed rapid traverse:10 mm/sec :600 l Oil cooling (electric):1,5 kW (max) :46er / 10 my Monitor SIEMENS:10 Zoll

Condition: as good as new (ex-display), Year of construction: 2016, pressing force: 160 t, pressure:160 t stroke:600 mm total power requirement:7,5 kW weight of the machine ca.:7 t draw back pressure:16 t :1 Stück Column-Diameter:160 mm dayligth:800 mm Giodpfxsfxyi Is Ahvop table surface area:1200 x 800 mm :400 mm table height:850 mm table load:5 t pre-running speed:1 bis 9,8 mm/sec return speed:1 bis 9,8 mm/sec quantity of oil:220 l

Condition: as good as new (ex-display), Year of construction: 2017, machine/vehicle number: DF0052, pressing force: 200 t, pressure:200 t distance between columns:1200x1000 mm stroke:600 mm Gijdefxyirepfx Ahvop total power requirement:32,5 kW weight of the machine ca.:20,5 t dimensions of the machine ca.:4000x2600x5000 m draw back pressure:20 t Master cylinder:1 Stück voltage:400 V frequency:50 Hz :24 V :BOSCH/REXROTH dayligth:800 mm :1200x1000 mit T-Nuten nach Kundenwunsch DIN 650-22 mm work height max.:1100 mm pre-running speed:170 mm/sec return speed:150 mm/sec Speed printing phase:15 mm/sek. Hydraulic block:REXROTH demand for oil:500 l pressure control:über PLC (Mindestdruck 20t) Oil Cooling:elektrisch :220 (im Schaltschrank) V memory:200 Programme :über Monitor von 20-200 t Controll:Zweihandbedienung beweglich :2-10 mm/sec :0-10 sec

Condition: new, Year of construction: 2017, machine/vehicle number: DF0152, pressing force: 80 t, pressure:80 t stroke:500 mm total power requirement:12 kW weight of the machine ca.:5,1 t Controll:Zweihandbedienung cylinder:1 work height max.:800 mm working area:800 x 800 mm Table dimensions:800 x 800 mm pestle plate:2800 x 1300 mm table height:800 mm pre-running speed:9,8 mm/sec work speed:9,8 mm/min return speed:18 mm/sec :700 mm Column-Diameter:75 mm :10 kW main drive:WEG 15 kW pump:REXROTH, Parker elektronische Axialkolbenpumpe kW :25 (bei280bar) t :200 mm :30 mm :80 mm/sek. :REXROTH/Parker :REXROTH/Parker :300 L :ca. 250 L :über PLC (Mindestdruck 10 to :zur Ölabkühlung ? mit Elektroventilator Giedpfx Asfxyh Hshvsp :manuell, über Schmiernippel oder Kartuschen :SIEMENS / MOELLER :auf Schwenkarm :automatisch über 2 Handbetrieb mit Schlüsselschalter, manuell über Bedienpult im Einrichtbetrieb :Zweihandbedienung beweglich, :zur Datenübertragung :Siemens für Fernwartung :zur Hublängeneinstellung :0 ? 10 sec. Oil tank capacity:150 l :800 mm lang, vorne und hinten, 300 mm unten diagonal

Condition: new, Year of construction: 2019, machine/vehicle number: DF0329, pressing force: 350 t, pressure:350 t passage width:3000 mm stroke:900 mm total power requirement:75 kW weight of the machine ca.:60 t dimensions:2660 x 5400 x 5700 mm Giedpsfxygzefx Ahvep return capacity:35 t Table dimensions:3610 x 1600 mm :3610 x 1600 mm table height over floor:900 mm pre-running speed:230 mm/sec return speed:170 mm/sec :2000 l max. working heidht:1700 mm pressure speed:21 mm/sec speed rapid traverse:200 mm/sec Oil cooling (electric):3 kW (max) :S7 1500 Monitor:WEG 12 Zoll

Condition: used, machine/vehicle number: 4396, pressing force: 200 t, pressure:200 t distance between columns:1200x1000 mm stroke:600 mm total power requirement:32,5 kW weight of the machine ca.:20,5 t Giedpfx Aefxyh Aehvep draw back pressure:20 t :1 Stück voltage:400 V frequency:50 Hz :24 V :Rexroth/Bosch dayligth:800 mm working area:1200x1000 mm :1200x1000 mm work height max.:1100 mm :170 mm/sek. :150 mm/sek. :15 mm/sek. quantity of oil:500 l :220 V memory:200 Programme :20-200 über Monitor t :5-170 mm/sec. :0-10 sec :2-10 mm/sec :750x950 mm :300 mm :5-50 t :2-80 mm/sec :1000 kg

Condition: new, Year of construction: 2019, machine/vehicle number: DF0303, pressing force: 160 t, pressure:160 t distance between columns:700 mm stroke:400 mm Return Capacity:16 t Engine Output:15 kW Travel:400 mm :550 mm Ram plate:700 x 600 mm table height over floor:900 mm Table size:700 x 600 mm speed of forward flow:50 mm/sec Pressing speed:10 mm/sec :50 mm/sec Oil cooling (electric):1,5 kW (max) Oil Tank Capacity:300 l weight of the machine ca.:4,3 t dimensions:1150 x 2600 x 2400 m ejector:30 x 30 mm Gsdpfx Asfxygpohvsip ejector stroke:150 mm pressure of ejector:15 t ejector speed:25 mm/sec no. of ejector pins:1 Stück Heating panels (L x B) with 2 measuring sensors diagonally:550 x 500 mm Siemens Control System:S7 1200 Monitor:12 Zoll :2400 ? :1200 ? :1200 ?

Condition: as good as new (ex-display), Year of construction: 2022, machine/vehicle number: NEBR-4397, pressing force: 15 t, Here are the technical data of the offered machine: If the press does not exactly match your requirement profile, please click to request an individual offer exactly according to your needs: Gedpofhcc Iefx Ahvjip Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your requirements at surprisingly low prices! ##### Technical details Pressure 15 t Technology stroke 160 mm Machine weight approx. 330 kg oil tank 10 l robust machine body with solid welded construction, manufactured according to DIN 8651 ##### Additional information low-maintenance and reliable due to robust technology cylinder with induction hardening and chrome plating steel quality: engineering steel LCG ASTM A36 4 support feet with M30 holes for floor mounting ##### Equipment 1.5 T rotating mandrel attachment, mechanical, with locking, toothed shaft and brake and 220 mm travel hydraulic hand pump with max. 15T pressure and 160 mm travel, with return spring back wall projection to the center of the tool holder 280 mm mounting table swivels 180 degrees to the right with 60 mm bore in the center, M 12 T-slots Clearance height between swivel table and slide/turning mandrel guide 450 mm Passage height up to additional table, insertable, 650 and 800 mm Additional table with center hole, 60 mm, insertable, T-slots M12, size 270x200 mm Height of the base with two inserts for additional table 750 mm on the cylinder a pressure plate, hardened, diameter 10 mm bigger than cylinder in the cylinder head tool holder M 30 Pump lever moves from top to bottom Oil tank for 10 L hydraulic oil AW 46 Painting of the machine body: Blue, RAL 5012, pressure paint Painting of the attachments: Anthracite, RAL 7021 hydraulic single-column combination press as a special machine 15 tons, manual (C-press, hydraulic press, hydraulic press) ##### Are you looking for a custom-fit machine? Contact us for an individual offer. Our hydraulic presses are manufactured according to German machinery directives, as well as European machinery directives (Directive 2006/42/EC), EC standards and EU safety regulations. Furthermore our presses exceed the Canadian and European safety requirements, because they correspond in all points to the national Brazilian safety guideline NR 12, which is based on these. Our great strength is the special machine construction and the press automation. We sell customized hydraulic presses, press brakes and impact shears at surprisingly low prices. For the hydraulics of the presses we mainly use components of leading European manufacturers.

Condition: refurbished (used), Year of construction: 2018, machine/vehicle number: DF0150, pressing force: 63 t, pressure:63 t passage width:700 mm stroke:500 mm Approx. weight (w/o operational materials):5,1 t Measurements L x W x H:ca. 1500 x1600 x 2995 mm Return Capacity:6 t Engine Output:11 kW Max Working height:700 mm Approaching Speed max. :140 mm/sec Pressure Speed:15 mm/sec. Travel:500 mm Ram plate:600 x 540 mm Table size:750 x 600 mm Table height above ground level:850 mm Oil Tank Capacity:150 l Control voltage:24 V Frequency:50 Hz Siemens Control System:S7 1200 Godpfjfhcc Ujx Ahvjip Monitor:Siemens 12 Zoll Special feature: When operating at 260bar the machine reaches a pressure level of 70 tons.

Condition: like new (used), Year of construction: 2019, pressing force: 400 t, pressure:400 t stroke:900 mm Table dimensions:1200 x 1200 mm Deep-Drawing Pillow:150 t travel away deep-drawing pillow:280 mm Daylight Opening:1100 mm Gjdjfh Izmopfx Ahvjip

Condition: new, pressing force: 400 t, pressure:400 t distance between columns:3400 mm stroke:500 mm total power requirement:55 kW weight of the machine ca.:49 t draw back pressure:26 t pump capacity:131 Lt./min dimensions:7.900 x 5.500 x 4.300 mm :5000 mm :2800 mm table height over floor:700 mm distance between table / ram:1000 mm :700 l Gijdpfxefhcc Ro Ahvop traversing speed:0-33 mm/sec. down speed:0-10 mm/sec :0-25 mm/sec.

Condition: used, Year of construction: 2001, machine/vehicle number: H01-3129, pressing force: 200 t, pressure:200 t passage width:1300x1300 mm stroke:1000 mm total power requirement:37 / 5,5 kW weight of the machine ca.:29500 kg dimensions of the machine ca.:2600x3000x5200 mm speeds::450 mm / freier Fall speeds::20 mm/sek tracking travel:130 / 60 ms oil pressure :283 bar capacity of oil tank:2200 L Gsdpfxsfhcc Ne Ahvjip

Condition: used, Year of construction: 2017, pressing force: 500 t, pressure:500 t passage width:1300x800 mm stroke:600 mm weight of the machine ca.:18 t dimensions of the machine ca.:2400 x 2400 x 5500 m draw back pressure:50 t Controll:Zweihandbedienung cylinder:1 Stück motor:50 kw Oil Cooling:elektrisch column diameter:200 mm work height max.:700 mm Gsdpfjd E Irmox Ahvjip Table dimensions:1900 x 800 mm table height over floor:1000 mm pestle plate:1300 x 800 mm pre-running speed:150 mm/sec work speed:5-10 mm/sec. return speed:150 mm/sec :1500 l quantity of oil:1400 l

Year of construction: 2020, condition: like new (used), pressing force: 150 t, pressure:150 t stroke:500 mm Giodpedxvfiefx Ahvsp Weight of machine approx.:ca. 8,5 t dimensions:1200x1800x3100 mm Engine Output:10 kW Max Working height:1000 mm Approaching Speed max. :9,9 mm/sec Pressure Speed:100t = 9,9 bis 0 mm/sec Table height above ground level (approx.):1000 mm :Schmiernippel column diameter:230 verchromt mm Return Speed:25 mm/sec :500 l demand for oil:ca 400 l Maintenance Balcony:5800 ? :3900 ? :2800 ? :4800 ? :29000 ? :8200 ? Faster Version with approach and working speed at 60mm/sec ist available on request. Price (excl. options): 117.500,--

Condition: new, Year of construction: 2018, machine/vehicle number: DF0116 - Rev.00, pressing force: 110 t, pressure:110 t passage width:1300 mm stroke:1500 mm Gedpfedxvflsx Ahveip Weight of machine approx.:12 t dimensions:ca. 2300 x 2090 x 4200 mm return capacity:11 t Max Working height:1500 mm pestle plate:1730 x 1100 mm table plate:1730 x 1100 mm table height over floor:700 mm column diameter:140 mm Thickness of ram plate:100 mm thickness of clamping plate:100 mm Noise Level (Max.):67 dB Color machine body:7035 RAL Color moving parts:2009 RAL Colour other components:7021 RAL Colour of balcony and casing:1021 RAL motor capacity:18 kW Approaching Speed max. :300 mm/sec pressure speed:15 mm/sec Oil Tank Capacity:150 l Siemens Control System:S7 1200

Condition: as good as new (ex-display), Year of construction: 2021, pressing force: 20 t, Hydraulic 20 T single-column production press for the manufacture of lightweight concrete parts. Here are the technical data of the offered machine: If the press does not exactly meet your requirements, please click here to request an individual offer exactly according to your wishes: Contact us for an individual offer HIDROBRASIL manufactures presses exactly according to your wishes at surprisingly favourable prices! Technical data + information: a) Closing speed up to 10 mm/sec b) Opening speed up to 20 mm/sec c) Maximum open height 300 mm d) Pressing speed 4 - 10 mm/sec. ( adjustable via rotary control ) e) Die size 600x800 mm f) Ram size 950x600 mm g) Manual lubrication (via grease nipple) h) Pressure setting from 5 T to 20 ( adjustable via rotary control ) Gedeia Nc Topfx Ahvoip i) Travel 300 mm j) Installation, commissioning, instruction at extra charge Technical Data Press type C Press, hydraulic Thermal neutral 80 - 120 °C Number of operating sides 1 side Forces Pressing force max. 200 kN Free ripping force max. 10 kN Pressure build-up time Closed die Steel on steel Max. 3 sec. Dimensions Max. Opening width 350/50 mm Stroke 300 mm Table height above floor, approx. 900 mm Height above floor (headroom) approx. 1900 mm Hall height min. 2,500 mm Parallel deviation at 20°C +/- 0.4 mm Deflection Determined at max. clamping force with 2/3 occupancy < = 0.6 mm/m Weight Total weight of the press without operating materials approx. 2.2 to Speeds Fast closing with 10 mm sec. Press speed 10-5 mm sec. Sound pressure Sound pressure level, measured at 1.5m height at the control panel according to max. 78 db(A) DIN 45635-T16-KL3 Hydraulics Number of press cylinders 1 pc. Plus 1 ejector, 110 mm stroke, max. operating pressure 255 bar Pressing pressure build-up time 03. apr sec. Pressure accuracy during pressing stroke +/- 5 bar Main pump BOSCHREXROTH/ASC approx. 6 L/min Oil volume approx. HLP 46 D 100 litres Ambient temperature max. 40 °C Oil temperature max. 55 °C Flow temperature °C Electrical system Main supply 400 V AC Control voltage 24 V Frequency 50 Hz Hydraulic connection Main motor 3 kW Total connection Approx. 4 kW (C-press, hydraulic press, hydraulic press, concrete press) Are you looking for a customised machine? Contact us for an individual offer. Our hydraulic presses are manufactured in accordance with German machinery directives, as well as European machinery directives (Directive 2006/42/EC), the EC standards and EU safety regulations. Furthermore, our presses exceed the Canadian and European safety requirements, as they comply in all points with the national Brazilian safety directive NR 12, which is based on these. Our great strength is the construction of special machines and press automation. We sell customised hydraulic presses, press brakes and impact shears at surprisingly favourable prices. For the hydraulics of the presses, we mainly use components from leading European manufacturers.

Condition: new, Year of construction: 2022, pressing force: 100 t, Estimated Equipment Weight 3500 Kg Giedpfxohmi T Us Ahvop Equipment Dimensions (front x depth x height) (Ca. Aussenmasse) 1354 x 2005 x 2595 mm Table Dimensions (Useful Area) front x depth (Tischgroesse) Ø1050 mm Opening between table and hammer (Daylight) 350 mm Hammer stroke (Stoessel-Verfahrweg) 300 mm Drive power (Leistung in KW) 14,24 Kw Motor Rotation 1500,00 RPM Pump Flow 44,50 LPM Pump Motor Ratio 27,59 cm³/Rot Working Force (Zylinderleistung) 100,00 Ton Return Force (Rückzugskraft) 10 Ton Forward Speed 250 mm/s Working Speed with Pressure (Arbeitsgeschwindigkeit) 3~15 mm/s Return speed (Hebegeschwindigkeit) 150 mm/s Working Pressure (Maximaler Arbeitsdruck) 210,00 Bar Cylinder quantity 2 pc Stem Diameter 41,76 mm Cylinder Diameter 250,97 mm Cylinder stroke (Stoessel-Verfahrweg) 300,00 mm Reservoir Capacity (Volumen des Oeltanks) 350,00 Liters Extractor Cylinder 5,00 T Cylinder travel (Stoessel-Verfahrweg) 150,00 mm
