# Hydraulic CNC Servo Press Brake MTP 160x3200

The Hydraulic CNC Servo Press Brake MTP 160x3200 is a modern machine designed for precise bending of mild steel, stainless steel, and aluminum sheets. With a pressing force of 160 tons and a bending length of 3200 mm, it is suitable for both serial production and custom fabrication.

The machine is equipped with the MTP-3212 CNC controller and 4 CNC-controlled axes (Y1, Y2, X, R), ensuring high accuracy, repeatability, and fast positioning. The intuitive controller with a large color touchscreen allows easy programming, automatic bending calculations, and storage of programs and tooling data.

The press brake incorporates high-quality components from leading manufacturers, including a Rexroth hydraulic system, Schneider Electric components, and Omron safety devices. Steel hydraulic connections improve reliability and minimize the risk of leaks.

For operator convenience, the machine features a mobile control panel, two front support arms, and LED working area illumination. Safety is ensured by a light curtain, side guards, rear safety protection, and easily accessible emergency stop switches. The machine is supplied with a CE Declaration of Conformity and an English user manual.

## Technical Specifications

* Pressing force: 160 T
* Maximum bending length: 3200 mm
* Maximum sheet thickness: up to 8 mm
* Control system: MTP-3212 CNC
* Number of CNC axes: 4 (Y1, Y2, X, R)
* Distance between side frames: 2600 mm
* Throat depth: 320 mm
* Ram stroke: 180 mm
* Maximum opening height: 455 mm
* Back gauge travel (X-axis): 600 mm
* Tool clamping system: AMADA quick clamping
* Motor power: 11 kW
* Power supply: 400 V / 50 Hz
* Dimensions (L × W × H): 3300 × 1650 × 2500 mm
* Weight: 9600 kg

## Additional Information

* Professional technical support included
Dodozcmrdjpfx Ah Nsuu
* Assistance with tooling selection and bending parameters
* CE Declaration of Conformity included
* English user manual supplied
* Spare parts support during and after the warranty period
* Possibility to extend the warranty beyond the standard warranty period

The machine is sold on an EXW basis. Transportation can be arranged upon request and quoted separately depending on the delivery destination. Our team will be pleased to provide a competitive transport quotation to any location within Europe and worldwide.

For more information about our company, machines, and services, please visit our website.

Metal Technics Polska is a trusted supplier of industrial machinery, offering professional sales support, technical assistance, spare parts availability, and after-sales service for customers throughout Europe.
