Injection molding machineKraussMaffei
KM 110 - 390 C2
Machine data
- Machine type:
- Injection molding machine
- Manufacturer:
- KraussMaffei
- Model:
- KM 110 - 390 C2
- Year of construction:
- 1998
- Condition:
- ready for operation (used)
Price & Location
- Location:
- Hermann - Hollerith Str. 9, 52249 Eschweiler, Deutschland
Details about the offer
- Listing ID:
- A16840681
- Reference number:
- 13610
- Update:
- 28.01.2025
Description
Manufacturer Krauss Maffei
Type of machine KM 110 – 390 C2
Year 1998
Working hours h
Controlversion MC 3-F
Screentext German
Location Eschweiler - Germany
Clamping unit:
Clamping force 1100 kN
Mould opening force, max. 70 kN
Travel force movable platen opening 35 kN
Travel force movable platen closing 28 kN
Size of mould platens (h x v) 745 x 770 mm
Nlsdpfx Afoub S Uljroi
Distance between tie bars (h x v) 470 x 470 mm
Mould opening stroke 600 mm
Mould height min 300 mm
Max. daylight 900 mm
Hydraulic ejector - stroke 150 mm
Ejector force 22/10 kN
Injection unit:
Screw diameter 35 mm
Ls/D ratio 23
Injection pressure 2429 bar
Stroke volume 156 ccm
Shot weight (PS) 142 gr.
Injection rate 123 ccm/s
Screw speed 391 1/min
Plasticising rate max. 22 g/s
Nozzle pressure 84 kN
Electric and Hydraulic Equipment:
Nominal capacity of pump motor 18,5 kW
Installed heating capacity 12 kW
Adjustable barrel heating zones 5
Reservoir capacity 345 ltr.
Dimensions and weights:
Dimensions of the machine ca. 4,50 x 1,60 x 2,00 m
Total machine weight 6000 kg
Max. mould weight 1485 kg
Accessories:
- Anti vibration pads
- 6 x Water flow
Additional Options:
- 2 x air valve
- 2 x core pull
- Robot interface according to Euromap 12
- Electrical screw drive
- Accumulator
