Coordinate measuring machine

Hexagon Global S Green 7.10.7

Condition: excellent (used), CNC-swiss type automatic lathe brand: STAR type: SR-38B new in: 2017 equipped with: FANUC 31i - B control subspindle back working driven tools Fgodpjxl Etqofx Ab Tsk 2x c-axis programmable b-axis y2-axis x3-axis switchable between guide bush and non-guide bush modes high pressure pump ol mist parts conveyor chip conveyor fire extinguishing system automatic barloader FMB LSK 38

Condition: used, Year of construction: 2009, operating hours: 6,000 h, functionality: fully functional, travel distance X-axis: 800 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 500 mm, controller model: Heidenhain iTNC530, spindle speed (max.): 36,000 rpm, GF Mirkon XSM600U X: 800 Y: 600 Z: 500 A: +30/-100 degrees C: 360 degrees continuous HSK50 spindle: max. 36,000 rpm, 25 kW HR410 handwheel Fjdpfx Abswa R A Ns Tjgk 60-station tool changer Rotary table including 3R clamping system Chip conveyor Coolant system with 20 bar internal coolant supply Blum laser tool measurement M&H 3D probe Pallet automation with 21 pallets - the pallets are not included in the scope of delivery This machine is offered on a customer order basis!

Year of construction: 2024, condition: new, Working space 1100 x 660 x 816 mm (W x D x H) Blasting chamber Dust-tight vacuum cabin in stable sheet steel construction Working gloves special rubber, wear resistant, cotton inside, firmly connected to the cabin against dust leakage Doors Blasting chamber W x D x H = 1100 x 660 x 816 mm Two side doors, dust-tight closing, double-walled, sound-absorbing foam, lockable, with electrical shut-off safety device Blasting media recovery Via coordinated MHG recovery system Operation ON/OFF switch for suction and lighting, Fjdpfx Aeh Hxubob Tegk pressure regulator, manometer and foot switch Viewing panels

Condition: like new (used), Year of construction: 2012, operating hours: 23,252 h, travel distance X-axis: 735 mm, travel distance Y-axis: 650 mm, travel distance Z-axis: 560 mm, controller manufacturer: 3D-Control Siemens 840D, workpiece diameter (max.): 840 mm, workpiece weight (max.): 600 kg, total height: 2,897 mm, total length: 3,567 mm, total width: 2,615 mm, table width: 650 mm, table length: 650 mm, overall weight: 12,100 kg, spindle speed (min.): 18,000 rpm, tool length: 315 mm, tool weight: 8,000 g, Year of construction: 2012 CNC controller: 3D-Control Siemens 840D Axes X-axis travel mm: 735 Y-axis travel mm: 650 Z-axis travel mm: 560 C-axis degrees: 360º (0,001) A-axis degrees: ±120(0.001) Feed rates m/min: 40 Rapid traverse m/min: 40 Fsdpfoxrr I Iex Ab Togk Acceleration in the axes m/s2: 6 Milling/turning table nc: Number of pallets: 1 Table dimensions mm: Ø650 Maximum workpiece size (D x H) mm: Ø840x500 Max. workpiece weight kg: 600 Spindle Spindle speed rpm: 18000 Spindle drive power kW: 13/9 (40%ED/cont) Cooling Cooling through the Spindle Center bar: 40 Tank capacity: 600 Tool system Tool holder: SK 40 Tool magazine slots: 30 Tool changer: Double Gripper With free neighboring places mm: 160 Max. Tool Length mm: 315 Max tool weight kg: 8 Chip-to-chip time s: 4.9 Equipment Electronic Handwheel Chip conveyor Rigid table with integrated rotary table Infrared probe Internal cooling lubricant supply Rinsing gun Paper band filter Machine running times Under power: 23252 Spindle Working: 6497 Basic machine dimensions / weight Length mm: 3567 Width mm: 2615 Height mm: 2897 Weight kg: 12100

Condition: excellent (used), Year of construction: 2014, CNC Heidenhain iTNC 530 Electronic handwheel Milling head 13,000 spindle hours Speed: 20 – 14,000 rpm Motor power: 18.9 kW Tool holder: SK40 Continuous feed rate up to 20,000 mm/min Clamping table: 2100 x 700 mm Max. table load: 1,500 kg X axis: 1,800 mm Y axis: 700 mm Z axis: 700 mm Tool magazine capacity: 30 positions Max. tool in magazine: length 300 mm, Ø130 mm Through-spindle coolant Chip conveyor: 5,890 x 1,030 x h1,550 mm, weight 770 kg Tool set: 25 pcs BLUM tool probe Complete documentation Transport dimensions: 3,423 x 7,060 x h2,622 mm Fgjdpfx Asxbyrmob Tsk Weight: 12,380 kg Videos available.

Year of construction: 2007, condition: ready for operation (used), - USED - 8-AXIS CNC LATHE WITH MILLING HEAD, DOWN TURRET HEAD AND COUNTER SPINDLE MAX ROTATING DIAMETER: 660 mm MAX TURNING LENGTH: 1495 mm MAX TURNING DIAMETER: 660 mm BAR CAPACITY: 65 - 65 mm Fedpfow Ey R Hsx Ab Togk SPINDLE: 35-5000 rpm; 22 kW; 254 mm COUNTER SPINDLE: 35-5000 rpm; 18,5 kW; 254 mm HEAD: CAPTO C6 ; -30°+195° ; 15-12000 rpm; 18,5 kW X-AXIS TRAVEL: 580 mm X2-AXIS TRAVEL: 150 mm Y-AXIS TRAVEL: 160 mm Z-AXIS TRAVEL: 1545 mm Z2-AXIS TRAVEL: 1490 mm B-AXIS TRAVEL: 1550 mm RAPID FEEDS X-Y-Z: 38 - 26 - 38 m/min TURRET HEAD: 9 POS TOOL MAGAZINE: CHAIN-TYPE ; 80 POS HIGH PRESSURE COOLANT: 18 Bar CONTROL UNIT: MAZATROL MATRIX WEIGHT: 11800 Kg OVERALL DIMENSIONS: 5090 x 3270 x 2830 mm ACCESSORIES: SWARF CONVEYOR ; PAPER FILTER ; TOOL SETTER

Year of construction: 1990, condition: excellent (used), Equipment The machine can be upgraded with new software and control system according to customer requirements. Measuring range X = 850 mm Y = 1200 mm Z = 600 mm Measurement accuracy 2,5µ + L/250 Price: on request! Fgsdpfjff Eaksx Ab Tsk We would be happy to provide you with a detailed offer! Please note: Our offer is directed exclusively to professional customers. (Changes and errors in the technical data, information and prices as well as prior sale reserved)

Condition: ready for operation (used), Year of construction: 2021, Travel X/Y/Z: 630mm/530mm/465mm, tool holder: SK40, speed: 12000rpm, tool positions: 32, table dimensions X/Y/Z: 920mm/540mm, machine dimensions X/Y/Z: 2600mm/2350mm/2750mm, weight: approx. 6500kg. Documentation available. On-site inspection is possible. Fgsdpfx Aswm Nphjb Tok

Condition: excellent (used), Year of construction: 2016, Takisawa TMM 250 3 turn-mill center, year 2016, Fanuc turning length:1300 Turning diameter: 350 mm Spindle speed (max.): 4000 1/min 9 axes 2 x spindles 2 x C-axis Fgsdpfx Absrt Ip Ns Tek Swing diameter 780 mm Turning diameter max. 350 mm Turning length max. 1,300 mm Chuck diameter left 250 mm Chuck diameter right 200 mm Upper tool carrier with Y-axis 260 mm and B-axis 230° / +/- 115° Complete with 30-position tool changer Lower tool carrier 15-position turret - all positions driven Complete simultaneous 5-axis machining with turning/milling support. Tool changer with 30 tool positions Workpiece magazine, to the right of the machine, with gantry handling Driven tools on the turret. C-axis for left and right spindle Chip conveyor Internal coolant supply through milling spindle 20 bar Due to high office costs (customs regulations) we do not deliver to Turkey Turkey, Iran, Russia and Belarus.

Condition: as good as new (ex-display), Year of construction: 2023, operating hours: 31 h, 3D Coordinate CNC measuring device Profitech Innometrik Advanced in gantry design (demo unit at a special price) Open Cable Special features of the gantry design: Gantry design with a low center of gravity, wide bearing separation and optimum stiffness to mass ratio. The granite guideways ensure a uniform thermal, dimensional, torsional and geometric stability of the machine. 24 air bearings for smooth movement of the three axes. High dynamics for better performance, the machine can achieve high accelerations like comparable medium and large CMMs. Thermally compatible materials and components minimize the influence of ambient temperature fluctuations on measurement results, Air filter and regulator. Fodpfx Abedyah Ss Togk Z-axis pneumatic counterweight system. Granit table with thread inserts of size M10. Passive vibration isolation pads Technical specifications Measurement paths: X: 500mm Y: 600mm Z: 400mm Max workpiece weight: 250kg Weight of the machine: 850kg Dimensions over everything: 1290x1160x2350mm Accuracy according to DIN EN ISO 10360-2 or ISO 10360-4: Volumetric probing deviation: MPEP = 2.2μm Volumetric length measurement deviation: MPEE = 2.2+ L / 350 (μm) Environmental conditions: Room temperature standard: 18-22 ° C Operating temperature 10-35 ° C Air Supply: Minimum air pressure: 6bar Air consumption: 90NI / min Also configurable as a complete package with touch probe, software commissioning and training. (Annual maintenance & calibration can also be offered)
