vaumatec Werkzeugmaschinen GmbH & Co.KG

Condition: refurbished (used), Year of construction: 1996, Functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Dimensions and travel paths Tool holder SK 40 Table dimensions mm 4000 x 800 Number of T-slots 6 Distance between T-slots mm 140 Distance between spindle bottom edge min. mm 140 Table top edge max. mm 740 Drilling radius min mm 540 max. mm 1590 U-axis travel path mm 2600 Y-axis travel path mm 1050 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 400 Cutting values Drilling capacity into solid material St 60 mm 40 GG 22 mm 50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 200 Feed drives X-axis - AC servo motor kW 0.25 Y-axis - AC servo motor kW 0.25 Z-axis - AC servo motor kW 4.50 W-axis - AC servo motor kW 2.50 U-axis - AC servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (U/W): m/min. 7.5 / 3 Feed rates infinitely variable mm/min. 5 - 2000 Feed force N 12000 Accuracy Positioning accuracy X, Y axis up to 1200 mm mm ± 0.075 Repeatability X, Y axis mm ± 0.03 Positioning accuracy Z axis mm ± 0.05 Repeatability Z axis mm ± 0.03 Positioning accuracy W axis mm ± 0.05 Repeatability W axis mm ± 0.03 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Total connected load kVA 13.0 CNC control Axes: 5 (X, Y, Z, W, U), expandable Screen: TFT flat screen backlit, easy to read from all sides Position information: Cartesian or polar, dimensions absolute or incremental, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, cutting data suggestions depending on material Tool management: max. 500 tools Sub-program technology: yes Machining cycles: cycles for centering, drilling, thread cutting, reaming, countersinking and boring, freely programmable cycle for special tools, dwell time possible for each cycle Chip breaking / chip removal: possible for drilling cycle Drilling patterns: row of holes, circle of holes, matrix Basic software: programming in dialog, 38 zero point shifts, turning and mirroring, teach-in for X, Y, Z, restart in the program with optional functions for targeted entry Zero point determination: cycles for determining zero points by manually touching the workpiece for: - any clamped right-angled parts - any clamped round parts - mediation of cast and burnt parts - Angular position detection for round parts by touching - reference edges or surfaces Data interfaces USB interface Gbolhcdev If T Tsw Isl Painting (new painting) Standard painting, two-component textured paint Machine upper part light gray RAL 7035 Machine lower part signal blue RAL 5005 Documentation Operating and programming instructions Electronics circuit diagram Spare parts drawings Test report for mechanics, electrics and safety equipment

Condition: new, Year of construction: 2025, Functionality: fully functional, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 8,000 rpm, Traveling column machine New machine Work table clamping area mm 1500 x 1000 Table height mm 750 Number of T-slots 6 Size of T-slots DIN 650 mm 18 Travel paths X-axis mm 1500 Y-axis mm 1000 Z-axis mm 700 Distance table top edge - spindle bottom edge min/max. mm 150 / 850 Main spindle drive for speed 8000 min-1 AC motor, frequency controlled kW 16 at 44% ED Speed range: min -1 15 – 8000 Torque at 44% ED Nm 104 constant up to min -1 1500 Feed drives X-axis AC servo motor kW 3.5 Y-axis AC servo motor kW 2.0 Z-axis AC servo motor kW 3.5 Rapid traverse speeds (X/Y/Z): m/min. 30/30/20 Gbolhcsvwip Djdw Iel Indirect position measuring system. Accuracy Positioning accuracy X, Y axis to 1000 mm mm ± 0.0150 Repeatability X, Y axis mm ± 0.0075 Positioning accuracy Z axis mm ± 0.0150 Repeatability Z axis mm ± 0.0075 Tool magazine 24-way - Tool positions 24 - Tool shaft (DIN 69871 / 69872) SK 40 - Max. tool diameter mm 76 - Max. tool length mm 250 - Max. tool weight kg 8 Machine control Heidenhain TNC 620

Condition: refurbished (used), Year of construction: 1997, Functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine design • Work table 1800 x 600 mm with 4T-slots • Boom travel 1050 mm • Drill spindle SK 40 with tool clamping device • Stepless speed programming • Stepless spindle feed via three-phase servo motor • 2 T-slots 18 mm on the machine base frame at the back • 2 T-slots 18 mm on the machine base frame on the left • Thread cutting device • Central lubrication • Coolant device • Machine light • CE marking • Safety device • USB interface Dimensions and travel paths Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Spindle stroke (Z axis) mm 200 Column stroke (W axis) mm 410 Distance from lower edge of spindle - min mm 70 Top edge of table max. mm 680 Distance from bottom edge of spindle - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Work table height mm 900 Cutting values Drilling performance into solid material St 60  40 GG 22  50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100% duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 – 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Gelhcjvv Spkjdw Iobl Feeds continuously variable mm/min 5 – 2000 Accuracy Positioning accuracy X, Y axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen backlit, easy to read from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental dimensions, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Sub-program technology: yes Machining cycles Standard software options: programming in dialog, 38 zero point shifts, turning and mirroring, teach-in for X, Y, Z, restart in the program with optional functions for targeted entry Zero point determination: cycles for determining zero points by manually probing the workpiece for: - any rectangular parts clamped - any round parts clamped - transfer of cast and burnt parts - angular position detection for round parts by probing reference edges or surfaces Test graphics Graphic display of drilling patterns Data interfaces USB

Condition: refurbished (used), Year of construction: 1997, Functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Danumeric 440 overhauled and digitized 2024 Machine version - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60  40 GG 22  50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides Golhcdsu Dg D Aow Isbl legible from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Machining cycles Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphic Graphic display of drilling patterns Data interfaces USB

Condition: good (used), Year of construction: 2000, Functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine design - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Gbjlhcdwju Aa I So Iol Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60  40 GG 22  50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides legible from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Machining cycles Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphics Graphic display of drilling patterns Data interfaces USB

Condition: good (used), Year of construction: 1992, Worktable 500mm x 1200mm Boom travel 600mm Tool holder MK 4 Drilling capacity 32mm in steel Gjlhcdwjtwmy Dj Ijbl Tapping device Coolant system Drill protection device

Condition: good (used), Year of construction: 2003, Functionality: fully functional, travel distance X-axis: 2,900 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 8,000 rpm, Work table Clamping surface mm 3000 x 1000 Table height mm 750 Number of T-slots 6 Size of T-slots mm 18 Travel distance X-axis mm 2900 Y-axis mm 1000 Z-axis mm 700 Distance top edge of table - bottom edge of spindle Spindle lower edge min/max. mm 150 / 850 Main spindle drive for speed 8000 min-1 AC motor, frequency-controlled kW 16 at 44% duty cycle Speed range: min -1 15 - 8000 Torque at 44% ED Nm 96 constant up to min -1 1500 Feed drives X-axis AC servo motor kW 3.5 Y-axis AC servo motor kW 2.0 Z-axis AC servo motor kW 3.5 Rapid traverse speeds (X/Y/Z): m/min. 30/30/20 Indirect measuring system. Positioning accuracy Positioning accuracy X-,Y-axis to 1000 mm mm ± 0.0150 Repeat accuracy X-, Y-axis mm ± 0.0075 Positioning accuracy Z-axis mm ± 0.0150 Repeat accuracy Z-axis mm ± 0.0075 Tool magazine 2x 24-fold Design as disk magazine - Tool positions 16 - Tool shank (DIN 69871 / 69872) SK 40 - Max. tool diameter Tool diameter mm 76 - Max. Tool length mm 300 - Max. Tool weight kg 8 Machine control Heidenhain TNC 426 Splash guard cladding Covering of the entire work area, designed as partial area protection in accordance with the valid guidelines of the German accident prevention regulations (UVV) and the European standard Gbjlhcsttg Egsdw Iel EN 12417, with manually operated work area door including electrical protection and interlock. Machine door with polycarbonate glazing. 30 bar high-pressure coolant unit (IKZ) for the use of tools with internal coolant supply, switchable to 19 liters/min at 30 bar or 19 liters/min at 15 bar complete with separate paper band filter. Internal cooling is also possible with air Clean tank capacity l 500 Degree of filtration my 30 Filter capacity l/min. 120 Hinged belt chip conveyor instead of the chip collection tray with integrated coolant tank, ejecting to the right Discharge width approx. mm 300 Discharge height approx. mm 1050 incl. coolant system Tank capacity liters approx. 150 Delivery rate l/min. 30 Pump capacity bar 2.0 HR 410 HEIDENHAIN hand-held control unit External hand-held control unit with built-in electronic handwheel, connected to the machine via cable, for manual movement of the axes, with emergency stop button Grease - central lubrication documentation Operating and programming instructions Hydraulic and pneumatic diagram Circuit diagram Test log

Condition: good (used), Year of construction: 1997, Functionality: fully functional, drilling capacity: 40 mm, quill stroke: 200 mm, quill diameter: 80 mm, Machine design - Work table 1800 x 600 mm with 4T-slots - Boom travel 1050 mm - SK 40 drilling spindle with tool clamping device - Infinitely variable speed programming - Infinitely variable quill feed via three-phase servo motor - 2 T-slots 18 mm on the machine base at the rear - 2 T-slots 18 mm on the left machine base frame - Thread cutting device - Central lubrication - Coolant device - Machine light - CE marking - Safety device - USB interface Golhcdwjrmkfno Isbl Dimensions and travels Tool holder SK 40 Column diameter mm 195 Table dimensions mm 1800 x 600 Number of T-slots 4 Distance between T-slots mm 125 Quill stroke (Z-axis) mm 200 Column stroke (W-axis) mm 410 Distance spindle bottom edge - min mm 70 Table top edge max. mm 680 Distance spindle bottom edge - min mm 970 Floor max. mm 1580 Drilling radius mm 540 - 1590 Worktable height mm 900 Cutting values Drilling capacity into solid St 60  40 GG 22  50 Thread cutting St 60 M 36 GG 22 M 42 Main spindle drive AC motor, frequency-controlled kW 5.5 at 100 % duty cycle. Speed range: min -1 15 - 2800 Torque Nm max. 250 constant from min -1 15 - 2000 Feed drives X-axis - AC - servo motor kW 0.25 Y-axis - AC - servo motor kW 0.25 Z-axis - AC - servo motor kW 4.50 W-axis - AC - servo motor kW 2.50 Rapid traverse speeds (X/Y/Z): m/min. 7.5 / 7.5 / 5 Rapid traverse speeds (W): m/min. 3 Feed rates stepless mm/min 5 - 2000 Accuracy Positioning accuracy X-, Y-axis to 1200 mm mm ± 0.075 Electrical data Operating voltage / frequency V / Hz 400 / 50 Control voltage V 24 Hydraulic unit for clamping kW 0.75 Total connected load kVA 13.0 Weight Danumeric 440 (without packaging) with table 1800 x 600 mm kg 2800 CNC control Axes: 4 (X, Y, Z, W), expandable Processor: 32-bit CPU Screen: TFT flat screen, backlit, easy to read from all sides legible from all sides, 215 x 160 mm Position information: Cartesian or polar, absolute or incremental measurements, Unit of measurement: mm or inch or in degrees Interpolation: 2 axes (X, Y) Technology database: tool management, tool suggestions according to machining type, material-dependent cutting data suggestions Tool management: max. 500 tools Subroutine technology: yes Machining cycles Standard software options: Programming in dialog, 38 zero offsets, rotation and mirroring, teach-in for X, Y, Z, restart in program with selection functions for targeted entry Zero point determination: Cycles for determining zero points by manually probing the workpiece for by manually probing the workpiece for: - any clamped rectangular parts - any clamped round parts - Mediation of cast and flame-cut parts - Angular position detection for round parts by touching reference edges or surfaces Test graphics Graphic display of drilling patterns Data interfaces USB

Condition: refurbished (used), Year of construction: 2006, Functionality: fully functional, machine/vehicle number: 65039, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 8,000 rpm, Traveling column machine Generally overhauled 2023 Work table clamping area mm 1500 x 1000 Table height mm 750 Number of T-slots 6 Size of T-slots DIN 650 mm 18 Travel paths X-axis mm 1500 Y-axis mm 1000 Z-axis mm 700 Distance table top edge - spindle bottom edge min/max. mm 150 / 850 Main spindle drive for speed 8000 min-1 AC motor, frequency controlled kW 16 at 44% ED Speed range: min -1 15 – 8000 Torque at 44% ED Nm 104 constant up to min -1 1500 Feed drives X-axis AC servo motor kW 3.5 Y-axis AC servo motor kW 2.0 Z-axis AC servo motor kW 3.5 Rapid traverse speeds (X/Y/Z): m/min. 30/30/20 Indirect position measuring system. Accuracy Positioning accuracy X, Y axis to 1000 mm mm ± 0.0150 Repeatability X, Y axis mm ± 0.0075 Positioning accuracy Z axis mm ± 0.0150 Repeatability Z axis mm ± 0.0075 24-way tool magazine mounted on the right-hand side of the traveling column - Tool positions 24 - Tool shaft (DIN 69871 / 69872) SK 40 Gbolhorg Ex Ijcdw Ijl - Max. tool diameter mm 76 - Max. tool length mm 250 - Max. tool weight kg 8 Machine control Heidenhain iTNC530 optional 620

Year of construction: 1983, Condition: refurbished (used), Work table 600mm x 1200mm cantilever travel 600mm tool holder MK 4 drilling capacity 32mm in steel Thread cutting device Coolant device Electrical system 24V control voltage emergency stop 2-channel Protective device on drill General overhauled 2022 12 months warranty New painting RAL 7035/7031 Gjlhomt Ed Rjcdw Iebl
