CNC machining centre WILLEMIN 508MT
Willemin-Macodel 508MT

Name: Willemin-Macodel 508MT
Brand: Willemin-Macodel
Availability: InStock

Year of construction

2016

Condition

Used (fully functional)

Location

Saint-Genix-les-Villages France

CNC machining centre WILLEMIN 508MT Willemin-Macodel 508MT

Machine data

Machine type:: CNC machining centre WILLEMIN 508MT

Manufacturer:: Willemin-Macodel

Model:: 508MT

Year of construction:: 2016

Condition:: reconditioned (used)

Functionality:: fully functional

Operating hours:: 9,701 h

Price & Location

Location:: Le Jasmin, 73240 Saint-Genix-les-Villages, France

Call

Technical details

Travel distance X-axis:: 450 mm

Travel distance Y-axis:: 200 mm

Travel distance Z-axis:: 425 mm

Rapid traverse X-axis:: 40 m/min

Rapid traverse Y-axis:: 40 m/min

Rapid traverse Z-axis:: 40 m/min

Nominal power (apparent):: 35 kVA

Controller manufacturer:: FANUC

Controller model:: series 31i-B5

Overall weight:: 3,300 kg

Spindle speed (max.):: 42,000 rpm

Spindle nose:: A2-4"

Number of spindles:: 2

Number of slots in tool magazine:: 72

Tool length:: 150 mm

Tool diameter:: 80 mm

Input voltage:: 400 V

Type of input current:: three-phase

Equipment:: documentation/manual

Details about the offer

Listing ID:: A22006168

Reference number:: 90188

Update:: 27.05.2026

Description

CNC machining centre WILLEMIN MACODEL W508MT

TECHNICAL CHARACTERISTICS:

Year of manufacturing: 2016
CNC control: FANUC series 31i-B5
Number of simultaneous axes: 5
Stroke X axis: 450 [mm]
Stroke Y axis: 200 [mm]
Stroke Z axis: 425 [mm]
Traversing feeds X, Y and Z axes: 40000 [mm/min]
Axes acceleration: 10 [m/s²]
Max. bar diameter in turning spindle: 42 [mm]
Main spindle max. speed: 6000 [rpm]
Main spindle max. power: 7.5 [kW]
Angular A axis stroke: 360 [°]
Resolution A axis: 0.001 [°]
Drive A axis: Torque-motor
Spindle taper A axis: A2-4"
B axis swivelling stroke: -15 [°] / +100 [°]
Resolution B axis: 0.001 [°]
Drive B axis: Torque-motor
Spindle type: HSK-E40
Max. spindle speed: 42000 [rpm]
Tool changer magazin number of stations: 72
Max. tool lenght: 150 [mm]
Max. tool diameter: 80 [mm]
Tool change time: 1 [sec]
Chip to chip time: 3 [sec]
Lubrication tank capacity: 150 [l]
Collant pump flow rate: 60 [l/min]
Rated current: 50 [A]
Total power required: 35 [kVA]
Supply voltage: 400 [V]
Working hours: 9701 [h]
Machine weight: 3300 [Kg]

INCLUDED EQUIPMENT:

x1 Back working unit with integrated 3-position turret on linear slide
Nodpfsy Uwp Esx Ad Rslb
x1 Vise on back working unit
x1 Counter-spindle on back working unit
x1 42,000 rpm spindle with air/oil lubrication
x1 RENISHAW OMP40-2 part probe
x1 BLUM LaserControl NT laser measuring system for tool setting and tool monitoring
x1 DETECTOR FRANCE type 202 tool breakage detection device
x1 A2-4" collet chuck
Set of 58 HSK-E40 tool holders
x1 Self-tightening drill chuck
LNS Super Hydrobar bar feeder, type 6.42 HS 3.2
Various equipment for LNS Super Hydrobar bar feeder
Set of technical manuals
x1 parameter backup system

Machine visible under power in our premises by appointment.

Price on request, loading on truck included.

Possibility of shipping Worldwide.

The information on this page has been obtained by the best of our ability. Therefore, its accuracy can not be guaranteed.

Machines similar to Mikron, Hermle, DMG Mori, Mazak, Hedelius, AXA, Chiron, Matec, Reiden, Lagun, Haas, and Alzmetall, including CNC milling, drilling, and tapping machines, as well as CNC grinding machines.
